CC&T 548- 24/30 User manual

C C
& T CAROLINA CHAIR & TABLE COMPANY
Thank you for purchasing a Carolina Chair & Table Company product. This product has been designed for easy assembly and is
constructed for durability. Please take this time to read and follow the assembly instruction cerefully. If a part or hardware is
missing or you have any difficulties in assembling this product, please contact us Toll-Free at 18002283876.
ASSEMBLY INSTRUCTION
#548- 24/30 SADDLE STOOL
PARTS CHECK LIST
CODE COMPONENTS Q'TY
A STOOL SEAT 1 PC
B
C
PARTS CHECK LIST
CODE DESCRIPTION Q'TY
D
E
F
G
PHILLIPS HEAD SCREWDRIVER
TOOL NEEDED ( NOT INCLUDED )
LEG FRAME ( L & R ) 2 PCS
STRETCHER 2 PCS
JCBC SCREW M6 x 40MM 4 PCS
SPRING WASHER 1/4" x 13 4 PCS
PH SCREW M4 x 38MM 4 PCS
ALLEN KEY M4 x 100MM 1 PC
1. 2.
A
B
C
F
Loosely tighten PH screws.
Loosely tighten PH screws.
F
B
C
C
B
x 2 x 2

3.
4.
G
D
E
A
Fully tighten all PH and JCBC screws.
x 4
