CEBIEN UP-I Original operating instructions

< / >
Manual includeds UP-I and UP-IS models.
Please make sure that you should identify your correct model and follow its instruction.
● It is an environment-friendly product developed in accordance with the [Water Saving Regulations]
according to the [Water Saving Law] of the Environmental Ministry in Korea.
● The installation drawings may be partially different from the actual appearance. This is only for
helping to understand for installation process.
● In order to improve the quality of products, interior and exterior parts are subject to change without
notice.

UP-I / UP-IS
Quick installation drawing
Carefully read the installation drawings & procedures and do installation.
Manufacturer or distributors will not be responsible for malfunction if you install
products at your disposal without following installation instruction.
Installation procedure
Tile finishing
Make hole on tile and mount stop valve
Install product(body/pipe/slide bar/multi pocket)
Assemble shower head/hand shower
Inspect product’s performance
Use spirit level
Hot Cold
Hot
Hot
Cold
Cold
Stop valves direction to 7 o’clock
Pipe connection
(Red hose is for hot water)
Drilling with nylon anchor and screw
Assembling screws

Refer to drawing and reel in sealing (teflon) tape on thethreading
part of provided two stop walves (taping it 8~12 times)
Secure upper & lower holes for screw bolt and make
hole on 6 points of ‘A’ (use spirit level)
( 6.5mm drill bit, depth: 50mm)
make hole on 6 points of ‘A’ make hole on 6 points of ‘A’
1) Unlock the stop valves with using flat-head screw driver (un-clockwise) and
allow the water come out for a while to remove any dust in the valves.
2) After removing any dust in the valves, lock them again
It attects water flow if there is dust in the valves

Fix the lower 2 points with screw bolts.
Match product body to upper 2 holes on ‘A’ spot and check level
Hot
Cold
Connect hose
Connect each flexible pressure hose
(from the product body) to stop valves with hand first
With using spanner, fasten them tightly
(Careful for flexible hoses not to be folded)
● Blue marked water pressure hose:
connect to stop valve for cold water
● Red marked water pressure hose:
connect to stop valve for hot water
Unlock the stop valves with using flat-head screw driver
(un-clock wise) to open the valve. Make sure to check level
Mount body
Insert 2 screw bolt in the upper 2 holes of product body and fix it
Make sure to check level
Use spirit level
Procedure of anchor bolts-fixing
Design cap – Screw bolt – Insert cap – Nylon anchor
Finish it with design cap

1) Connect pipe ‘c’ to ‘b’
2) Adjust the height of upper pipe ‘c’ for user
3) Connect the assembled pipe with product body
Fasten pipe adapter not to leak out water

1) Check leverl and mark the hole with pencil
2) Make holes and insert nylon anchor
1) Fix screw bolt with insert cap on the wall with
using plus head screw driver
2) Put on side covers
Connect shower head with upper pipe
1) Assemble shower hose ‘h’ with product body
* Insert rubber o-ring in the shower hose
2) Assemble hand shower
Check all the functions after completing installation and keep turning on
until clear water ome out and use it.

Mark drilling points where the slide bar is located.
Drilling and insert nylon anchor.
Fix slide bar on the wall with screw bolt.
1) Assemble shower hose ‘h’ with product body
* Insert rubber o-ring in the shower hose
2) Assemble hand shower to shower hose on the other side.
Check all the functions after completing installation and keep
turning on until clear water ome out and use it.

Before requesting (after sales) service
Water does not come out.
-Is the house water supply cut off?
-Isn’t the water supply valve locked?
-Have you pulled the hot / cold water handle firmly forward?
(Turn the handle clockwise to warm water, counterclockwise to cold water)
Low water pressure
hot or cold water come only.
-Is the water pressure originally weak or the pipeis too narrow?
-Is the water main valve open toolittle?
-Is the shower main valve open toolittle?
-Is your home or water heating system turned off?
-Did you push the hot / cold water handle to the left or right?
Water temperature changes
during the shower
-You may experience the water temperature change during its usage.
But mostly it is caused by the capacity of boiler or hot water supply system.
-If you use water at the same time in the kitchen,
balconyor elsewhere in the house during the shower,
the water pressure or temperature may change. It is not a product defect.
Shower head, hand shower
is blocked or water is leaned
to one side.
-Is the shower head or hand shower nozzle blocked with some foreign material?
-Clean the nozzle using a sharp pin(needle, clothing pin),
and if it is not improved, ask to Seller for repairing
Water leakages from the
head shower orconnection
part
-Is the hand shower securely assembled?
-Is the shower hose connected to the main unit securely fastened?
(Please fully tighten the head to the right)
-Is the rubber ring in the hand shower broken or missing?
-Is the flat packing ring of the shower hose connected to the main body missing?
(Please put a rubber ring orpacking to connect place)
Water drops downfrom the
shower head
Leftover water in the shower head may drops down. It is not a malfunction
Safety regulations
This is for user's safety and to prevent property damage. Please read as below carefully and use it correctly.
Do not disassemble,
repair or modify unnecessarily
Do not apply excessive force or
shockduring the operation
Do not keep close electrical
appliances such as hair dryers,
electric shavers and etc.
Do not install in areas where the
water pressure is too low.
Be sure to open the hot / cold water
handle slowly and put it in the
center position after use.
Do not throw or drop the
hand shower.
>It may cause malfunction.
>It may cause damage.
>Water may cause electric leakage or electric shock.
>In case of water tank (roof water tank) type apartment,
top floors do not show product performance properly.
(Necessary minimum water pressure: 2.0 kg / cm2 or more)
>This is to prevent burns by hot water.
>It may cause injury or damage to the feet or head.
Please be aware that the hand with foam is slippery.

Product Warranty
CEBIEN Shower Customer Service
- According to the consumercompensation standards, CEBIEN compensates for the products as follow;
- In case of a product malfunctions, please contact your dealer.
(If you cannot contactthe dealer, contact customer service team of CEBIEN.)
Model name Date of purchase Dealer
Contractor
(vendor) Contact point
- This product is for home use, the warranty period is 2 years, and the parts retention period is 3 years.
- If you use the product for business purpose, your warranty will be shortened by half.
Free service
Types of consumer damage
When critical repair is needed within 1 month after
purchase due to performance or functional defectoc-
curs during the normal use.
Repairable
Unrepairable Unable to repair due to un-retention
parts
The same defects occur up to 3 times
Remuneration contents
Within warranty After warranty
Free repair
Free repair Paid repair
Cannot be repaired
Paid Service
If it is not malfunction
If it is not a malfunction, please refer tothe service manual before requesting visit repair service. Visit repair
service is subject to charge. (If repair is not possible, it shall be subject to the separate policy)
Simple case such as product features description or the service not
accompanying disassembly of the product.
-Failure to install due to movement of product or moving house
-When requesting reinstallation of the productwhich sales conditionshad
been customer’sown installation at the time of purchase.
-Reinstalling the product due to the failure of installer
-In case Hand Shower /Fixed Shower is broken
-In case of product failure or damage due to excessive work during
construction
-Product’s wear due to long-term use
Paid service from the 1st time
Paid service from the 1st time
In case of malfunction due to consumer’s misuse
When a malfunction occurs due to carelessness by the consumer or arbitrary repairs or modifications
In case of a malfunctionoccurs due to the repairing of unqualified technician
In case of failure due to the use of non-genuine parts specified by CEBIEN
Check if there is any installation problem (leakage, water pressure, shaking) before using the product.
