ceepo Shadow-R User manual

Shadow-R
Assembly Guide

Shadow-R
Assembly Guide

Shadow-R
2019 Assembly Guide
TABLE OF CONTENTS
1. Frameset Parts .....................................................4
2. Parts included in the BOX................................5
3. Cables Map - Brakes..........................................6
4. Cables Map - Front Derailleur .......................7
5. Cables Map - Rear Derailleur.........................8
6. Headset Installation ...........................................9
7. Di2 Battery Installation...................................10
8. Seatpost Installation..........................................11
9. Front Derailleur Holder Installation...........13
10. Frame Plugs Installation.................................14
11. TOOLBOX Installation .....................................15
12. Bento BOX............................................................16

Shadow-R
Assembly Guide
40T high-modulus carbon
frame
A
40T high-modulus carbon
SideFork
B
B
40T high-modulus carbon
Reversible Seatpost
C
C
Bento Box rubber Lid
D
TOOLBOX Lid
E
E
Removable Rear Derailleur Hanger
F
F
Removable Front Derailleur Hanger
G
G
Di2 Junction Access Lid
H
H
D
A
1. Frameset Parts
4

Shadow-R
Assembly Guide
Rear thru axle
A
Front thru axle
B
Headset including Canecreek Viscoset
C
Expander
D
Mini clamp
F
Grommet for rear shifting (1 pc)
G
Grommet for e-Tap shifting (2 pcs)
H
Grommet for Di2 shifting (2 pcs)
I
Grommet for SRAM eTap (empty hole) (1 pc)
J
Di2 battery adaptor
E
ABCD F
E
2. Parts included in the BOX
G H I J
5

Shadow-R
Assembly Guide
A
B
3. Cables Map - Brakes
Front Brake Cable
Enter outer casing by hole located behind
nose cone (1). Push casing inside until it
reaches (2) opening where you can reach
and help thread casing toward exit hole (3).
Rear Brake Cable
Cable entry (4) is located behind stem.
Thread the cable casing into hole until you
can grab it through tool box opening (5),
then guide it toward brake cable exit (6).
Pay attention to leave enough cable slack
so you can pack the bike for travel and
remove bars if needed.
No special parts or tools needed.
(1)
(3)
(2)
(6)
(5)
(4)
A
B
6

Shadow-R
Assembly Guide
A
4. Cables Map - Front Derailleur
Map Front Derailleur
Enter electric cable by hole located behind
nose cone (1). Thread the electric cable into
frame until you can grab it through tool box
opening (2), then guide it toward brake
cable exit (3).
This frameset is compatible with:
- All electric groups
- All 1By groups
No MECHANICAL Front Derailleur possible.
(2)
(1)
A
(3)
Store the
SRAM Blip Box
in the Bento Box
Can replace the cover
to Shimano junction
7

Shadow-R
Assembly Guide
B
5. Cables Map - Rear Derailleur
Map Rear Derailleur (mechanical)
Enter electric cable by hole located behind
nose cone (1). Thread the electric cable into
frame until you can grab it through tool box
opening (2), then guide it toward brake
cable exit (3).
Map Rear Derailleur (Di2)
Enter electric cable by hole located behind
nose cone (1). Thread the electric cable into
frame until you can grab it through tool box
opening (2), then guide it toward brake
cable exit (4).
You will need to remove the derailleur
hanger to have access to the Di2 cable exit
hole.
(2)
(1)
B
C
C
(3)
(4)
8

Shadow-R
Assembly Guide
6. Headset Installation
The Ceepo Side Fork design is extremely
unique and non-conventional. Because of
the engineering behind the design, Ceepo
provides a special "Cane Creek Viscoset"
headset which is required to be used when
assembling the Ceepo Shadow-R. Installing
the special Cane Creek headset helps to
ensure safe handling.
Please note that the use of any other
headset is NOT authorized by Ceepo for
installation on the Shadow-R or any other
side fork equipped frameset.
Bearing
Bearing
Compression Ring
Spacers
Canecreek Viscoset
Top Cap
Fork post
Lock Ring
Expander
9

Shadow-R
Assembly Guide
7. Di2 Battery Installation
Step 1
Secure battery in the provided battery
holder.
Step 2
Insert the battery inside the frame using the
toolbox opening (1). Hold the battery in
place (inside) by hand while screwing from
the outside.
We suggest to tape or tie wrap excess cable
and Shimano junction to the battery before
installation.
(1)
Di2 Battery Holder
A
Di2 Battery Collar
B
Adaptor Bolts
C
Washer
D
Internal Circlip
E
A
B
B
C
DE
Battery and holder
should be inside the frame
10

Shadow-R
Assembly Guide
8. Seatpost Installation
Ceepo reversible seat post is secured
via 2 clamps.
Clamp A
Wedge type must be placed inside clamp
pocket inside frame , paying attention to
have access to Allen key bolt head so you
can tighten it .
Clamp B
Our Mini–clamp is to be placed on seat post
prior to Installation.
This small clamp remains on seat post when
removing it for travel.
Clamp A Clamp B
6Nm
3Nm
11

Shadow-R
Assembly Guide
8. Seatpost Installation
Ceepo new reversible seat post is only
for Alu railed saddle. If for carbon railed
saddle,please buy the special outter cap
from Ceepo.
Non-serrated for Infinite seat angle
adjustment.
12

Shadow-R
Assembly Guide
9. Front Derailleur Holder
Dual position
Will accept most chainrings ; including big
oval ones.
13

Shadow-R
Assembly Guide
10. Frame Plugs Installation
SRAM eTap
Shimano Di2
This PLUG should be
already installed.
G
G
H
H
I
I
J
14

Shadow-R
Assembly Guide
11. TOOLBOX Installation
Step 1
Velcro tool bag on the lid..
Step 2
Push it inside the frame and secure it using
the 2 quick lock.
Pay attention to check quick lock
engagement before riding. One side
unlocked may result in loss of tool box
riding, endangering rider and other cyclists
along the way.
Tool Bag Put tools inside mesh pocket Insert Co2 cartridge inside the slots.
15

Shadow-R
Assembly Guide
12. Bento BOX
Secure bento box cover at middle section.
Bento is designed to open front and back
Magnets keep the cover closed while riding.
16
