celesco SPD-4-3 User manual

optional cordset
#9036810-0040
optional cordset
#9036810-0040
celesco.com version: 1.0 / item no: SPD-MANUAL
brown - pin 1
black - pin 4
8–40
Vdc –
+4–20 mA
return
12–32
Vdc
0–10 Vdc
common
brown - pin 1
black - pin 4 white - pin 2
–
+
SPD Installation Guide
Includes: SPD-4-3, SPD-12-3, SPD-25-3
& SPD-50-3
4–20 mA Output
Electrical Connection
Output Signal
alternate installation
Cable Exit/ Connector Direction
0–10 Vdc Output
Electrical Connection
included M12 mating plug
Electrical Connector
2.4” [60mm]
customer supplied electrical cable,
(.25 in [6 mm] max. dia.)
contact view
2
3
1
4
mating plug
(contact view)
2
3
1
4
1- V+ (8-40 Vdc)
2- n/c
3- n/c
4- Output Signal (4-20mA)
Pin# Description
mating plug
(contact view)
2
3
1
4
1- V+ (12-32 Vdc)
2- Output Signal (0-10Vdc)
3- n/c
4- Common
Pin# Description
To change cable exit direction, simply
remove the 3 mounting bracket screws
and rotate sensor body to 1 of 4 options.
To change connector direction, remove the
4 cover screws and carefully rotate to desired
direction.
0% fs.
Output 100% fs.
4...20 mA
0...10 Vdc
4 – 4.25 mA 19.2 – 20 mA
0 – .2 Vdc 9.5 – 10 Vdc
0% 100%
2.32 [58,9]
1.97
[50,1]
Ø1.47
[37,2]
.70
[17,7]
1.06
[26,9]
1.24
[31,6]
Ø.53 [13,3]
1.48 [37,7]
1.97 [50,1]
3×Ø.08 [2,0] thru
on 2.30 [58,4] b.c.
90° apart
.57 [14,6]
2.50 [63,4]
1.56 [39,5]
.57
[14,4]
.99
[25,1]
Top View (w/o bracket)
Front View (w/o bracket) Front View (with bracket) Side View (w/o bracket) Side View (with bracket)
Top View (with bracket)
2.23 [56,6]
.72
[18,3]
Ø.15 [3,9]
thru
(2 plc.)
1.19 [30,1]
2.34 [59,5]
2.09
[53]
Ø1.47
[37,2]
2.23 [56,6]
.54 [13,8]
2.52 [64,0]
3.60
[91,4]
1.00
[25,4]
1.10
[27,9]
.6
[15,2]
in [mm]
.15 [3,9]
.19
[4,8]
.50
[12,7]
Ø.15 [3,9]
.165
[4,19]
Ø.191 [4,19]
Ø.375 [9,52]
.165
[4,19]
Ø.191 [4,19]
Ø.375 [9,52]

optional cordset
#9036810-0040
optional cordset
#9036810-0040
