Celsius CONDOR User manual


- 1 -

- 2 -
IMPORTANT SAFETY NOTICE
NOTE THE FOLLOWING PRECAUTION BEFORE ASSEMBLING OR OPERATING THE
MACHINE.
1. Assemble the machine exactly as the descriptions in the instruction manual.
2. Check all the screws, nuts and other connections before using the machine for the first time
and ensure that the trainer is in the safe condition.
3. Set up the machine in a dry level place and leave it away from moisture and water.
4. Place a suitable base (e.g. rubber mat, wooden board etc.) beneath the machine in the area
of assembly to avoid dirt and etc..
5. Before beginning training, remove all objects within a radius of 2 meters from the machine.
6. DO NOT use aggressive cleaning articles to clean the machine, only use the supplied tools
or suitable tools of your own to assemble the machine or repair any parts of machine.
Remove drops of sweat from the machine immediately after finishing training.
7. Your health can be affected by incorrect or excessive training. Consult a doctor before
beginning a training program. He can define the maximum setting (Pulse. Watts. Duration of
training etc) to which you may train yourself and can get precise information during training.
This machine is not suitable for therapeutic purpose.
8. Only do training on the machine when it is in correct working way. Use only original spare
parts for any necessary repairs.
9. This machine can be used for only one person’s training at a time.
10.Wear training clothes and shoes which are suitable for fitness training with the machine. Your
training shoes should be appropriate for the trainer.
11.If you have a feeling of dizziness, sickness or other abnormal symptoms, please stop training
and consult a doctor asap.
12.People such as children and handicapped persons should only use the machine in the
presence of another person who can give aid and advice.
13.The maximum user’s weight is 100kg, and for home use only.
14.WARNING: the safety level of the equipment can be maintained only if it is examined
regularly for damage and wear, e.g. ropes, pulleys, connection points;
15.Please examine the equipment carefully before you use it, especially the components most
susceptible to wear, e.g. handlebar, end caps and screws which touching the ground or the
connection points frequently.
16.Please stop using the equipment immediately once there’re any defective components and
keep it out of use before you replace the components or repair it by designated agent.
17.Please notice that the unsupervised children should keep away from the equipment.
18.Saddle post: the minimum insertion depth should not lower than the mark of STOP and it has
210mm adjusting range.
19.WARNING! Heart rate monitoring systems may be inaccuracy. Over exercise may result
serious injury or death. If you feel faint stop exercise immediately.
20.The braking system is adjustable.
21.Before beginning this or and exercise program, consult your doctor. This is especially
important for people over the age of 35 or those with health problems. Read all instructions
before using the exercise bike.

- 3 -
EXPLODED DIAGRAM

- 4 -
PARTS LIST
NO. DESCRIPTION QTY NO. DESCRIPTION QTY
1 Main frame 1 20 Allen bolt M8XL72 2
2 Round end cap 2 21 Pedal (L/R) 1/1
3 Handlebar foam grip 2 22 Crank(L/R) 1/1
4 Computer 1 23 Leveler end cap 2
5 Handlebar 1 24 Rear stabilizer 1
6 Front handlebar cover 1 25 Allen Bolt M8XL90 2
7 Allen Bolt M8X15 8 26 Arc washer D8X2 XΦ25 XR39 2
8 Pulse sensor wire 2 27 Pop-pin knob M16X1.5X32 1
9 Rear handlebar cover 1 28 Saddle post bushing 1
10 Tapping screw ST4.2X18 1 29 Vertical saddle Post 1
11 Handlebar post 1 30 Knob Nut M10 1
12 Extension sensor wire 1 31 Flat washer D10 1
13 Mast shield 1 32 Square end cap 2
14 Lower sensor Wire 1 33 U-shaped slider 1
15 Flat washer D8 4 34 Horizontal saddle Post 1
16 Roller end Cap 2 35 Saddle 1
17 Cross tapping screw ST3.5X20 4 36 Spring washer D8 8
18 Front stabilizer 1 37 Cross screw M5X10 2
19 Arc washer D8XΦ19X1.5XR30 2 38 Power adaptor 1
NOTE:
Most of the listed assembly hardware has been packaged separately, but some hardware
items have been preinstalled in the identified assembly parts. In these instances, simply
remove and reinstall the hardware as assembly is required.
Please reference the individual assembly steps and make note of all preinstalled hardware.
PREPARATION: Before assemblin , make sure that you will have enou h space around the
item; Use the present toolin for assemblin ; before assemblin please check whether all
needed parts are available.
It is stron ly recommended this machine to be assembled by two or more people to avoid
possible injury.

- 5 -
ASSEMBLY INSTRUCTION
STEP 1
Attach the front Stabilizer (18) to the Main frame (1) with the Allen bolts (20) and Arc washers (19),
and then fix the rear Stabilizer (24) to the Main frame (1) with the Allen bolts (25) and Arc washers
(26) as shown.
Note: The Leveler end caps of the rear Stabilizer can be ADJUSTED to keep the equipment stable.
STEP 2
A: Slip the Mast shield (13) onto the Handlebar post (11);
B: Connect the lower Sensor wire (14) to the extension Sensor wire (12);
C: Fix the Handlebar post (11) on the Main frame (1), using the Allen bolts (7), Spring washers (36),
and Flat washers (15) as shown.
D: Slip down the Mast shield (13) and fit in the place.

- 6 -
STEP 3
Attach the Pedals (21) to the Cranks (22) respectively, viewed from the rider’s exercising position.
Always make sure the Pedals are securely tightened before any exercise.
Note: Both pedals are engraved with L for left and R for right.
To tighten turn the Left pedal COUNTERCLOCKWISE and the Right pedal CLOCKWISE.
STEP 4
Attach the Saddle (35) to the horizontal Saddle post (34), secured the nut under the Saddle.
And then fit the horizontal Saddle post to the vertical saddle post (29), secured it with the Flat
washer (31) and Knob nut (30) as shown. Insert the vertical saddle post (29) into the Main frame (1),
secured with the Pop-pin Knob (27) at a proper height as shown.
NOTE: Spin the Pop-pin Knob (27), loosen the Pop-pin Knob (27) and pull it out, and adjust to the
suitable height according to the users’ height, and then tighten the Pop-pin Knob (27).

- 7 -
STEP 5
A: Feed the Pulse sensor wires (8) out of the Handlebar
post (11) through the computer bracket on the top.
Attach the Handlebar (5) to the Handlebar post (11),
secured with the Allen bolts (7) and Spring washers (36)
as shown.
B: Attach the front Handlebar cover (6) to the Handlebar.
STEP 6
A: Connect all the Wires (8 & 12) to the wires and
socket of the Computer (4), and then install the
Computer
onto the computer bracket on the top of the Handlebar
post (11), secured it with the Cross screws (37) as
shown.
B: Attach the rear Handlebar cover (9) to the Handlebar
post (11), fit the front and rear covers (6 & 9) properly,
and then secure them together with the Cross screw
(10) as shown.
Note: This Bike need power supply via Adaptor (38).

- 8 -
Maintenance and Treatment
1. Verify that all the bolts and nuts are locked properly and the turning parts should be turned
freely without damaged parts.
2. Clean the equipment with soap and slightly damp cloth only. Please do not use any solvent to
clean the equipment.
Malfunctions and Treatment
Malfunction Reason Treatment
Base is unstable.
1. Floor is not flat or there is small
object under the front or rear
stabilizer.
2. The rear stabilizer end caps have
not been leveled when
assembling.
1. Remove the object.
2. Adjust the rear stabilizer end caps.
Handlebar is shaking.
The bolts and saddle post knob are
loose. Tighten the Bolts and saddle post
knob.
Loud noise from the
moving parts. The interval of the parts is improper
tighten. Open the covers to adjust.
No resistance when
riding the upright
bike.
1. The interval of the magnetic
resistance increases.
2. Tensioncontrollerisdamaged.
3. Runningbeltslips.
4. Thebearingsetisdamaged.
1. Open the covers to adjust.
2. Change the tension controller.
3. Open the covers to adjust.
4. Change the bearing set.

- 9 -
WARM-UP an COOL-DOWN
A successful exercise program consists of a warm-up, aerobic exercise, and a cool-down. Do the
entire program at least two and preferably three times a week, resting for a day between workouts.
After several months, you can increase your workouts to four or five times per week.
WARM-UP
The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up
for two to five minutes before strength-training or aerobic exercising. Perform activities that raise
your heart rate and warm the working muscles. Activities may include brisk walking, jogging,
jumping jacks, jump rope, and running in place.
STRETCHING
Stretching while your muscles are warm after a proper warm-up and again after your strength
or aerobic training session is very important. Muscles stretch more easily at these times because of
their elevated temperature, which greatly reduces the risk of injury. Stretches should be held for 15
to 30 seconds. DO NOT BOUNCE.
Remember always to check with your physician before starting any exercise program.
COOL-DOWN
The purpose of cooling down is to return the body to its normal or near normal, resting state at the
end of each exercise session. A proper cool-down slowly lowers your heart rate and allows blood to
return to the heart.
Calf-Achilles Stretch
Inner Thigh Stretch
Toe Touch
Side Stretch
Hamstring Stretch

- 10 -
Warranty Information
This product is guaranteed to be free from quality and manufacturing defects for a period of one (1) year.
If your product becomes defective during this period, Rebel Sport Limited will offer you either a replacement,
credit or refund where a product is faulty; wrongly described; different from the sample shown to you or does
not do what it is supposed to do.
This warranty will not cover substantially modified product; misuse or abuse of the product contrary to user
instructions or packaging label; change of mind and normal wear and tear.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be
of acceptable quality and failure does not amount to a major failure.
To claim the warranty, take the product to the front Service Desk of the brand you purchased it from (Amart
Sports or Rebel). Visit our websites at www.amartsports.com.au and www.rebelsport.com.au for all store
locations. You will need to show receipt or other proof of purchase. Additional information may be required
to process your claim. Should you not be able to provide proof of purchase with a receipt or bank statement,
identification showing name, address and signature may be required to process your claim.
Any expenses relating to the return of your product to the store will normally have to be paid by you. For
online store purchases, Amart Sports or Rebel will pay for the return freight for any product assessed as
having a major failure. Contact our online Customer Service teams first, before arranging for couriers, as we
may have additional options to suggest to you.
The benefits to the customer given by this warranty are in addition to other rights and remedies of the
Australian Consumer Law in relation to the goods or services to which this warranty relates.
This warranty is provided by Rebel Sport Limited A.C.N. 003 283 823, IBC Business Estate, Level 1, 29-33
Amart Sports - Phone: 1300 001 229. Email: orders@amartsports.com.au.
