Central Pneumatic 66902 Installation manual

2-IN-1 FINISH NAILER/STAPLER
Model 66902
SET UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2009 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improve-
ments, actual product may differ slightly from the product described herein. Tools required for assembly
and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 09l

SKU 66902 For technical questions, please call 1-800-444-3353. Page 2
SAVE THIS MANUAL
Keep this manual for the safety warn-
ings and precautions, assembly, operat-
ing, inspection, maintenance and cleaning
procedures. Write the product’s serial
number in the back of the manual near the
assembly diagram (or month and year of
purchase if product has no number). Keep
this manual and the receipt in a safe and
dry place for future reference.
Safety Alert Symbol and Signal
Words
In this manual, on the labeling,
and all other information provid-
ed with this product:
This is the safety alert
symbol. It is used to alert
you to potential personal
injury hazards. Obey all
safety messages that
follow this symbol to avoid
possible injury or death.
DANGER indicates
a hazardous
situation which, if not
avoided, will result in death or
serious injury.
WARNING
indicates a
hazardous situation which, if
not avoided, could result in
death or serious injury.
CAUTION, used
with the safety
alert symbol, indicates a
hazardous situation which, if
not avoided, could result in
minor or moderate injury.
NOTICE is used to
address practices
not related to personal injury.
CAUTION, without
the safety alert
symbol, is used to address
practices not related to
personal injury.
IMPORTANT SAFETY
INSTRUCTIONS
INSTRUCTIONS PERTAINING
TO A RISK OF FIRE,
ELECTRIC SHOCK, OR
INJURY TO PERSONS
WARNING – When using tools, basic pre-
cautions should always be followed,
including the following:
General
To reduce the risks of electrica.
shock, re, and injury to persons,
read all the instructions before us-
ing the tool.
Work area
Keep the work area clean and wella.
lighted. Cluttered benches and dark
areas increase the risks of electric
shock, re, and injury to persons.
Do not operate the tool in explo-b.
sive atmospheres, such as in the
presence of ammable liquids,
gases, or dust. The tool is able to
create sparks resulting in the ignition
of the dust or fumes.
Keep bystanders, children, andc.
visitors away while operating the

SKU 66902 For technical questions, please call 1-800-444-3353. Page 3
tool. Distractions are able to result in
the loss of control of the tool.
Personal safety
Stay alert. Watch what you are do-a.
ing and use common sense when
operating the tool. Do not use the
tool while tired or under the inu-
ence of drugs, alcohol, or medica-
tion. A moment of inattention while
operating the tool increases the risk
of injury to persons.
Dress properly. Do not wear looseb.
clothing or jewelry. Contain long
hair. Keep hair, clothing, and
gloves away from moving parts.
Loose clothes, jewelry, or long hair
increases the risk of injury to persons
as a result of being caught in moving
parts.
Avoid unintentional starting. Bec.
sure the Trigger (42) is off before
connecting to the air supply. Do not
carry the tool with your nger on the
trigger or connect the tool to the air
supply with the trigger on.
Do not overreach. Keep properd.
footing and balance at all times.
Proper footing and balance enables
better control of the tool in unexpect-
ed situations.
e. Use safety equipment. A
dust mask, non-skid safety
shoes and a hard hat must
be used for the applicable
conditions. Wear heavy-duty work
gloves during use.
f. Always wear eye protec-
tion. Wear ANSI-ap-
proved safety goggles.
g. Always wear hearing
protection when using
the tool. Prolonged expo-
sure to high intensity noise
is able to cause hearing loss.
Do not attach the hose or tool toh.
your body. Attach the hose to the
structure to reduce the risk of loss of
balance if the hose shifts.
Always assume that the tool con-i.
tains fasteners. Do not point the tool
toward yourself or anyone whether it
contains fasteners or not.
WARNING – Do not re fastener on j.
top of another fastener. This is able
to cause the fastener to be deected
and hit someone, or cause the tool to
react and result in a risk of injury to
persons.
WARNING – Remove nger from k.
the Trigger when not driving fas-
teners. Never carry the tool with
nger on trigger, the tool is able to re
a fastener.
Tool use and care
Use clamps or another practicala.
way to secure and support the
workpiece to a stable platform.
Holding the work by hand or against
the body is unstable and is able to
lead to loss of control.
Do not force the tool.b. Use the
correct tool for the application. The
correct tool will do the job better and
safer at the rate for which the tool is
designed.
Do not use the tool if the Triggerc.
does not turn the tool on or off.
Any tool that cannot be controlled

SKU 66902 For technical questions, please call 1-800-444-3353. Page 4
with the trigger is dangerous and
must be repaired.
Disconnect the tool from the aird.
source before making adjust-
ments, doing tool maintenance,
clearing jams, touching the safety,
leaving work area, loading, or un-
loading the tool. Such precautionary
measures reduce the risk of injury to
persons.
Store the tool when it is idle out ofe.
reach of children and other un-
trained persons. A tool is dangerous
in the hands of untrained users.
Maintain the tool with care.f. A prop-
erly maintained tool is more efcient
and reduces the risk of binding and is
easier to control.
Check for misalignment or bind-g.
ing of moving parts, breakage of
parts, and any other condition that
affects the tool’s operation. If dam-
aged, have the tool serviced before
using. Many accidents are caused
by poorly maintained tools. There is a
risk of bursting if the tool is damaged.
Use only accessories that areh.
identied by the manufacturer for
the specic tool model. Use of an
accessory not intended for use with
the specic tool model, increases the
risk of injury to persons.
Use only those fasteners listedi.
in the Accessories section of this
manual. Fasteners not identied for
use with this tool by the tool manu-
facturer are able to result in a risk
of injury to persons or tool damage
when used in this tool.
Service
Tool service must be performeda.
only by qualied repair personnel.
When servicing a tool, use onlyb.
identical replacement parts. Use
only authorized parts.
Use only the lubricants suppliedc.
with the tool or specied by the
manufacturer.
Air source
a. Never connect to an air
source that is capable of
exceeding 90 PSI. Over
pressurizing the tool may
cause bursting, abnormal operation,
breakage of the tool or serious injury
to persons. Use only clean, dry,
regulated compressed air at the rated
pressure or within the rated pressure
range as marked on the tool. Always
verify prior to using the tool that the
air source has been adjusted to the
rated air pressure or within the rated
air-pressure range.
Never use oxygen, carbon dioxide,b.
combustible gases or any bottled
gas as an air source for the tool.
Such gases are capable of explosion
and serious injury to persons.
SAVE THESE
INSTRUCTIONS.

SKU 66902 For technical questions, please call 1-800-444-3353. Page 5
SYMBOLS AND
SPECIFIC SAFETY
INSTRUCTIONS
Symbol Denitions
Symbol Property or statement
PSI Pounds per square inch of pressure
CFM Cubic Feet per Minute ow
SCFM Cubic Feet per Minute ow at
standard conditions
NPT National pipe thread, tapered
NPS National pipe thread, straight
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
eye protection.
Warning marking concerning Risk of
Puncture Injury. Wear heavy-duty
work gloves.
Read the manual before set-up and/
or use.
WARNING marking concerning Risk
of Hearing Loss. Wear hearing
protection.
WARNING marking concerning Risk
of Respiratory Injury. Wear NIOSH-
approved dust mask/respirator.
WARNING marking concerning Risk
of Explosion.
Specic Safety Instructions
Operators and others in work area1.
MUST wear ANSI-approved safety
goggles with side shields during
use. The employer is responsible to
enforce use of eye protection by the
operator and others in the work area.
Keep ngers away from Trigger 2.
when not driving fasteners to
avoid accidental ring.
Always assume the tool contains3.
fasteners.
Do not point the tool toward yourself4.
or anyone whether it contains fasten-
ers or not.
Do not actuate the tool unless the5.
tool is placed rmly against the work-
piece.
Respect tool as a working implement.6.
No horseplay. This tool is not a toy7.
and can be deadly if misused.
Do not load the tool with fasteners8.
when any one of the operating con-
trols is activated.
Do not remove, tamper with, or other-9.
wise cause the tool operating controls
to become inoperable.
Do not operate the tool if any portion10.
of the tool operating controls is inop-
erable, disconnected, altered, or not
working properly.
Disconnect the tool from the power11.
source when:
Unattended.a.
Performing any maintenance orb.
repair.
Clearing a jam.c.
Moving the tool to a new location.d.
The written approval of the tool man-12.
ufacturer must be obtained prior to
making any modications to the tool.
Refer to the tool maintenance instruc-13.
tions for detailed information on the
proper maintenance of the tool.
