Centsys D5-Evo Quick start guide

Master controller settings
Motor 2 (Master)
controller
Motor 1 (Slave)
controller
Two synchronised gates opening
D5-Evo/D10 Synchronisation Diagram
Centurion Systems (Pty) Ltd
Doc number 0.07.D.0071_01032016 - ENGLISH
www.CentSys.com
Slave controller settings
Safety
External gate indication status................................Indicator output.............. AUX IO
    Closedindication.............O
    Partlyclosedindication.....O
    Closingindication............O
    Partlyopenindication.......O
Opening indication........... On
Open indication............... On
    Pedestrianindication........O
    Unknownindication..........O
Autoclose
Autoclose status................................................... On
Autoclose timer.....................................................0 Seconds
• To open the gate fully, all triggering devices (remote controls, tag readers, keypads, intercoms, etc.)
must be programmed/connected to the Master controller.
• If the pedestrian function is required, connect the triggering device’s normally-open output to the
PED terminal on the Slave controller or, in the case of remote controls, learn the remotes to activate
the PED function on the Slave controller.

D5-Evo/D10 Synchronisation Diagram
Wiring of one set of infrared gate safety beams to two synchronised D-Series gate motors
Please Note: Ensure that beam test is
disabled on both controllers
IRB Receiver
12V/24V -
12V/24V -
12V/24V +
12V/24V +
COM
NC
NO
IRB Tx
Master
Controller
Slave
Controller
