Cerio CS-1008G-8PX User manual

PoE Series CS-1008G-8PX
8 Port 10/100/1000M Gigabit PoE+ Switch
User’s Guide
FCC Certifications
This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received; including
interference that may cause undesired operation.
CE Mark Warning
This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 class A for ITE,
the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of the
Member States relating to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it may be possible that information in this document
is not up-to-date. Please check with your local distributors for the latest information. No part of this document can be
copied or reproduced in any form without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their respective companies.
Copyright © 2016, All Rights Reserved.
Unpacking Information
Thank you for purchasing our PoE series products. Before installation,
please check that your package contains the following items.
Open the shipping cartons of the switch and carefully unpack its
contents. The carton should contain the following items:
1.CS-1008G-8PX Main Unit x1
2.Quick Installation Guide Booklet x1
3.Power Adapter x1
4.Warranty Card x1
Application
Introduction
Power Over Ethernet
The CERIO CS-1008G-8PX is a powerful and complying with
IEEE 802.3af/at Power over Ethernet standard which provides DC
48~57V Gigabit over Ethernet cables high-performance Gigabit
Ethernet switch, with all 8 ports capable of 10/100Mbps or
1000Mbps autonegotiation operation which means the switch could
automatically negotiate with the connected partners on the network
speed and duplex mode. It is ideal for micro-segmenting large
networks into smaller, connected subnets for improved performance,
enabling the bandwidth demanding multimedia and imaging
applications. Moreover, the 10/100/1000Mbps autosensing ability
provides an easy way to migrate 10Mbps to 1000Mbps network with
no pain.
The CS-1008G-8PX supports 8 Port 10/100/1000M Gigabit
port Power over Ethernet (PoE+) allows you to expand your network
via Ethernet cable to where there is no power line or outlet but where
you want to fix devices such as APs, IP Cameras or IP Phones, etc..
No longer need to worry about the complicated cables and long
distance which may cost you a lot of time and money. By integrating
the data transmitting cable and power cord, it eliminates the effort
constructing your network. Over current protection and circuit
shorting protection are also supported to ensure the safety. It also
support desk top and wall mounting for easy installation.
Key Features
Complying with IEEE 802.3 10Base-T, IEEE 802.3u100Base-TX,
IEEE 802.3ab 1000Base-T, IEEE 802.3afPoE ,IEEE 802.3at PoE+
8 Ports 10/100/1000Mbps Auto-Negotiation Gigabit Switch,
including 8 Ports PSE/ PoE+ function, complying with IEEE
802.3af/at standard
Supporting the power up to 30Watt/15.4Watt/ 7.5Watt/4Watt for
each PSE/PoE+ port with bundle Power Adapter have 90Watt
share for 8 PoE ports
Full/Half-Duplex capability on each TX port
Supports Store & Forward architecture and performs forwarding
and filtering
Auto-learning networking configurations
Supporting the flow control: back pressure for Half duplex and
IEEE 802.3x for Full-duplex mode
Support Jumbo Frame 9K
Non-blocking & Non-head-of-line blocking full-wire speed
forwarding
Supports TP interface Auto MDIX function for auto TX/RX swap
Automatic Source MAC Address Learning and Aging
Supports up to 4K MAC addresses
Up to 1.5Mb bits buffer

Installation
The setup of the switch can be performed using the following steps:
Visually inspect the DC jack and make sure that is fully secured
to the power adapter
Make sure that there is proper heat dissipation from and
adequate ventilation around the Switch. Do not place heavy
objects on the Switch
Cables Installation
The Switch support 8 port 10/100/1000Mbps Gigabit Ethernet ports and
Port 1 – Port 8 are Gigabit PoE Enabled ports, these PoE port will
automatically activate when a compatible terminal is identified. The
Switch will supply power through the Ethernet port to the connected PoE
powered device (PD) For legacy devices that are not compatible, the PoE
port will not offer power to this device. This feature allows users to freely
and safely mix legacy and Power over LAN compatible devices on their
network.
The Switch supports 10Mbs Ethernet or 1000Mbps Gigabit Ethernet and
it runs both in half and full duplex mode using two pair of Category 5
cable. These RJ45 ports are Auto-MDI type port. The Switch can auto
negotiate the MDI-II or MDI-X type, so you can connect any RJ-45 cable
regardless if it is a standard or crossover cable.
Gigabit Ethernet Port / PoE Ports (Port 1~8)
These ports support network speeds of either 10Mbps or 100Mbps or
1000Mbps, and can operate in half and full-duplex transfer modes.
These ports also support automatic MDI/MDIX crossover detection
And These all ports are 802.3af (PoE) and 802.3at(PoE+), the PoE port
will automatically activate when a compatible terminal is identified. The
PoE switch will distribute power through the Gigabit ethernet ports to the
connected PoE device. For devices that are not compatible, the PoE port
will not supply the power to this device. This feature allows user’s to
freely and safely utilize the 802.3af (PoE) and 802.3at(PoE+) for Power
over Lan devices on their network.
Hardware Overview
LED Indicator:
Complete LED indicators displays the status of the PoE Switch and
network status
The front panel LEDs provides instant status feedback, and assists
to monitor and troubleshoot when required.
Power LED Power : (Power Indicator)
On :
Power On
Off : Power Off
PoE LEDs (Port 1 ~ Port 8) ( PoE Status )
Green : When the PoE powered device (PD) is connected
and the port distributes power successfully
Off :
When the PoE port has failed, possible reason are:
PoE Power circuit shortage
Power over current:
over the power current of PD’s classification Out of
PoE voltage of 48 ~ 57 VDC output
No PoE power device (PD) connected
LINK/ACT Status LEDs (Ports 1~8)
Green
The port is 1000M Link / Act connected.
Blinking Green A valid link is established, and there is data
transmitting/receiving.
Amber
10/100M Link / Act connected.
Product Specifications
Standards & Hardware Specifications
Network
Standards
Conformance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX,
IEEE 802.3ab 1000Base-T,
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet (PoE)
IEEE 802.3at Power over Ethernet Plus (PoE+)
Port Configuration
8ports RJ-45 connectors for 10/100/1000Mbps
(With 8 Ports PSE/ PoE+ function )
Media Access Protocol
CSMA / CA
Network Media
10BASE –T: UTP Cat. 3 or up,
100BASE-TX: UTP Cat. 5 or up,
1000BASE-T: UTP Cat. 5 or up
Transmission Method Store and Forward
MAC Address Table
4K
Built-in Buffer 1.5M bits
Jumbo Frame 9K
Data Transfer Rate
10/100/1000Mbps (Half-duplex),
20/200/2000Mbps (Full-duplex)
Auto MDI/MDIX
Yes
LED Indicators
Per Gigabit Port:(Link/Act): Status x 8
PoE : Status x 8
Per Unit: Power x 1
Internal Bus Speed
16Gbps
Environmental & Mechanical Characteristics
Power Supply
90Watt External Power Adapter
PoE Power
Budget
80Watt shared for all PoE Ports
Power Consumption
2.8Watt
PoE Power Output
Up to 30W per port
Power Requirement DC In : Input Voltage: 48 ~ 57Volt
Operating
Temperature
0° to 55° C
Storage Temperature
-40° to 70° C
Operating Humidity 10% to 90% non-condensing
Storage Humidity 5% to 90% non-condensing
Dimension
( W x H x D )
160 x 85 x 25mm
Unit Weight
0.36kg
Case of Materials Metal
Certification FCC, CE, RoHS-compliant
