CET PMC-350 User manual

Revision Date: April 18, 2019
PMC-350-C Quick Start Guide
Version 1.0
Package Contents
a. PMC-350-C Meter with all plug-in connectors installed
b. Factory Test Report
c. CD with PMC-350-C User Manual
d. Quick Start Guide (this document)
Meter Overview
Serial Number Label Wiring Label Wiring Label (1xIR+4xTC) Warning Label and SN & DevEUI Label
Using the Front Panel Buttons
<▼>
Data Display Mode
The Default Display shows the kWh Import measurement under the Energy menu. Pressing this button scrolls
through the available measurements in this menu.
Setup Configuration Mode
Before an item is selected, pressing this button scrolls to the next setup parameter. If the selected parameter is a
numeric value, pressing this button increments the selected digit. If the selected parameter is an enumerated
value, pressing this button scrolls through the selection list.
<↩>
Setup Configuration Mode
Pressing this button for two seconds toggles between Data Display mode and Setup Configuration mode. Once
inside the Setup Configuration mode, pressing this button selects a parameter for modification. Once selected, the
parameter value blinks while it’s being changed.
If the selected parameter is a numeric value, the cursor is at the right most digit by default. Pressing this button
moves the cursor one position to the left. If the cursor has reached the left most digit, pressing this button again
will save the current numeric value into memory.
Mounting the Meter
The PMC-350-C should be installed in a dry environment with no dust and
kept away from heat, radiation and electrical noise source.
Before installation, make sure that the DIN Rail is already in place
Move the DIN Rail locking clip at the back of the PMC-350-C
downward to the “unlock” position
Align the top of the mounting channel at the back of the PMC-350-C
at an angle against the top of the DIN rail as shown in figure right
Rotate the bottom of the PMC-350-C towards the back while
applying a slight pressure to make sure that the device is completely
and securely fixed on to the DIN Rail
Push the DIN Rail locking clip upward to the “lock” position to secure
the PMC-350-C on to the DIN Rail

Revision Date: April 18, 2019
Wiring Diagrams
3P4W with 3CTs 3P3W with 3CTs 3P3W with 2CTs
1P3W with 2CTs 1P2W L-N with 1CT 1P2W L-L with 1CT
RS-485 Wiring
The PMC-350-C provides one standard RS-485 port that supports
the Modbus RTU protocol. Up to 32 devices can be connected on
a RS-485 bus. The overall length of the RS-485 cable connecting
all devices should not exceed 1200m.
If the master station does not have a RS-485 communications
port, a RS-232/RS-485 or USB/RS-485 converter with optically
isolated outputs and surge protection should be used.
LoRaWAN Connection
The DevEUI information can be found on a label underneath the
Front Panel. The AppEUI and AppKey should be pre-configured at
the factory according to the customer’s specification.
Basic Setup Parameters
Menu
Parameters
Description
Range/Options
Default
PW
Password
Enter Password
0 to 9999
“0”
TYPE
Wiring Mode
The wiring connection of the meter
DEMO/1P3W/3P3W/3P4W/1P2W L-N/1P2W L-L
3P4W
PT1
PT Primary
PT Primary
1 to 1,000,000 V
380 V
PT2
PT Secondary
PT Secondary
1 to 690V
380 V
CT1
CT Primary
CT Primary
1 to 30,000A
5 A
CT2
CT Secondary
CT Secondary
1 to 5A
5 A
ID
Meter Address
Meter Address
1-247
100
BD
Baud rate
Data rate in bits per second
1200-38400 bps
9600
CFG
Comm. Port Configuration
Data Format
8N2/8O1/8E1/8N1/8O2/8E2
8E1
