CFE CFE-5100 User manual

Residential ESS Lithium-ion Battery
CFE-5100/CFE-5100S/CFE-2400
WiFi Configuration Guidance
Published: 0511, 2023
Version 1.3

1
WiFi Configuration Guidance
CFE-5100/CFE-5100S/CFE-2400 have a built-in WiFi module to work with Smart BESS App
Please read this manual carefully before doing WiFi Configuration
Smart BESS is designed for users to monitor the battery status like SOC, voltage and
warning information.
1. Download the APP
iPhone: Scan the code or search Smart BESS in App Store.
Android: Scan the code or search Smart BESS in Google Play.

2
2. Instructions for Smart BESS APP
2.1 Registration
Open the Smart BESS APP, Click Register Account and create your account here.
2.2 WiFi Configure
2.2.1 iPhone instruction
Connect to WiFi of the house before WiFi configuration;
Select WiFi Config ;
SSID is the WiFi name of the house, which is obtained automatically;

3
Input the password of the WiFi;
Click Next;
Press the Reset on the battery for around 3 seconds until the Run light goes fast flash
Back to iPhone WiFi setting page
Connect to Battery WiFi named ‘hiflying_softap’;
Back to Smart BESS , the APP will automatically configure WiFi for the battery;

4
Scan the QR code to watch iPhone WiFi configuration video instruction.
2.2.2 Android instruction
Connect to WiFi of the house before WiFi configuration;
Select WiFi Config ;
SSID is the WiFi name of the house, which is obtained automatically;

5
Input the password of the WiFi;
Click Start, and select GO TO SETUP ;
Press the Reset on the battery for around 3 seconds until the Run light goes fast flash;
Back to mobile phone WiFi setting page;
Connect to Battery WiFi named ‘hiflying_softap’;
Back to Smart BESS , the APP will automatically configure WiFi for the battery;

6
Scan the QR code to watch WiFi configuration video instruction.
3. Add Battery
Connect back to your home WiFi
Go Add Battery and scan the bar code of the battery;
You can customize the battery name, and the PCS should input the Number of SW3 on
the battery;
Click Confirm to add the battery to My battery
4. My battery list
After the battery added to the list, you will be allowed to check the BMS information of
the battery .
Tap the battery serial Number with dark blue background, the System overview will
show.

7
5. Fault Warning
Clicking on the Warning & Services, you can see the battery warning information.
6. Online Upgrade
Once you got the WiFi configured individually for all the CFE batteries you have, you can
contact CFE Technical support Group for upgrading the battery firmware version for the
latest firmware
7. Notes
7.1 The WiFi must be strong and stable for at least 30mins when doing online upgrade;
7.2 The length of WiFi name and password for WiFi Config should be less than 16 digits;
7.3 Each battery must be configured WiFi Separately when doing online upgrade;

8
7.4 It is recommend having the communication cables and power cables between batteries
disconnected before the online upgrade;
7.5 The online upgrade will normally take 20 mins;
7.6 After the online upgrade the BMS will turn off automatically, the batteries need to be
restarted manually;
7.7 The WiFi frequency should be 2.4G;
7.8 If after pressing the reset for more than 3 seconds and the run light doesn’t fast
flash,please turn the battery off for more than 30 seconds, than try again.
