Chamberlain MC100AMLR User manual

The Universal Garage Door Opener Remote
Control can be programmed to operate up to two
motors. Each button on the remote control works
independently of the other and must be
programmed separately.
The images throughout this manual are for
reference only and your product may differ from
the images shown.
MC100AML
UNIVERSAL GARAGE DOOR OPENER
REMOTE CONTROL

To prevent possible SERIOUS INJURY or DEATH from a
moving door:
ALWAYS keep remote controls out of reach of children. NEVER permit
children to operate or play with remote control transmitters.
•
Activate a door ONLY when it can be seen clearly, is properly adjusted
and there are no obstructions.
•
ALWAYS keep a door in sight until completely closed. NEVER permit
anyone to cross the path of a moving door or gate.
•
BATTERY
CR2032 Battery
Screw
Replacing the battery:
1
WARNING! This product contains a button/coin cell battery.
To prevent possible SERIOUS INJURY or DEATH:
• The battery is hazardous.
• Keep new and used batteries away from children.
• Do not ingest battery. Chemical burn hazard.
• If the coin cell battery is swallowed or placed inside any part
of the body, it can cause severe or fatal injuries in 2 hours or
less.
• If the battery compartment does not close securely, stop using the product
and keep away from children.
• If you think batteries might have been swallowed or placed inside any part
of the body, call the 24-hour Poisons Information Centre on 13 11 26 in
Australia, or the 24-hour National Poisons Centre on 0800 764 766 in
New Zealand, or seek immediate medical attention.
• Dispose of used coin/button cell batteries immediately and safely. Flat
batteries can still be dangerous.

Visit chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal
for up to date information on the models that the universal remote is
compatible with.
The Universal Garage Door Opener Remote Control is compatible
with:
COMPATIBILTY TABLE
2
Brand Code Type Frequency Learn
Button
Label
Model Number:
ATA TrioCode128 433.47 / 433.92 /
434.37MHz
DOOR
CODE
GDO6, GDO7, GDO8, GDO9 ENDURO, GDO9
DYNAMO, GDO10, GDO11, TEMPO™ ATS-2
ATA TrioCode 433.47 / 433.92 /
434.37MHz
DOOR
CODE
GDO6, GDO7, GDO8, GDO9 ENDURO, GDO9
DYNAMO, GD1O, GDO11, RD40
ATA SecuraCode 433.92MHz DOOR
CODE
GDO4, GDO5 Securacode, GDO6, GDO7, GDO8
Avanti Rolling 433.92MHz LEARN MPS6, MPS12, DPS12, T6-MPS, T8-MPS T8-DPS
B&D TriTran+ 433.47 / 433.92 /
434.37MHz
CODE SET CADP, CADS, CADP DIAMOND, CAD P
DIAMOND WQ, CAD DIAMOND PD, CAD
PRODIGY, CAD ADVANCE, FIRMAMATIC,
SHEDMASTER
B&D TriTran 433.47 / 433.92 /
434.37MHz
CODE SET
or DOOR
CODE
CADP, CADS, CADP DIAMOND, CAD
P DIAMOND WQ, CAD DIAMOND PD,
FIRMAMATIC, SHEDMASTER, SDO3
B&D Billion Code 433.92MHz CODE SET CAD4, CAD5, CADP, CADR, FAM4, FAM5,
FAMR, EASYLIFTER 4, EASYLIFTER 5
EASYLIFTER R, CAD P DIAMOND, CAD P
DIAMOND WQ, CAD P DIAMOND PD
Boss Fixed 433.92MHz RADIO
SET
RD 11, BOL6 (433MHz Variant)
Chamberlain Security +2.0 433.30 / 433.92 /
434.54MHz
LEARN or
“S”
RollerLift, RollerLift Plus, HandyLift Plus 2.0,
HandyLift Deluxe 2.0, HandyLift MyQ,
HandyLift Deluxe, SectionalLift,
SectionalLift Plus, PowerLift, PowerLift Plus,
PowerLift MyQ, PowerLift Lite
Chamberlain Security + 433.92MHz LEARN HandyLift, HandyLift Plus, CR550, ML500,
ML700, ML750, MLR500, MLR750
Chamberlain Billion Code 433.92MHz CODE SET Refer to B&D Billion Code compatibility above
Guardian Rolling 433.92MHz RADIO
SET
RD2
HercuLift Rolling 433.92MHz LEARN RDO V6
HomEntry Rolling 433.30 / 433.92 /
434.54MHz
LEARN or
“S”
HE60, HE60R, HERD01, HESDO1
Merlin Security +2.0 433.30 / 433.92 /
434.54MHz
LEARN or
“S”
Commander Essential, Commander Elite,
Commander Extreme, Commander Ultimate,
EntryLift, PowerAce, TiltMaster, CyclonePro,
Commander MyQ, SilentDrive Essential,
SilentDrive ELite, QuietDrive, SilentDrive,
WeatherDrive, SilentDrive Elite MyQ,
OverDrive, WhisperDrive, MJ3800
Merlin Security + 433.92MHz LEARN MR60, MR600, MR800, MR650, MR850,
MR1000, MT60, MT60P, MT600, MT800,
MT1000, MT3850, M230T, CG3800, MJ3800.
MT5580, MT5580P, MRC 950,
Merlin Legacy 433.92MHz LEARN ProLift & PowerLift 430R, 230T (Motors
manufactured after 2001)
MotorLift Security + 433.92MHz LEARN ML500, ML700, ML750, MLR500, MLR750
Steeline Security +2.0 433.30 / 433.92 /
434.54MHz
LEARN or
“S”
ST50EVOB, ST50EVOC, SR60, RD11
Superlift Rolling 433.92MHz CODE SDO 3 DC
Taurean Rolling 433.92MHz RADIO
SET
NOVA 1000

LOCATING THE LEARN BUTTON
NOTE: When programming a Merlin or Chamberlain Security+2.0 opener
follow the below steps:
1. Press & release the LEARN button on the opener.
2. Press & release the remote button you wish to program. The code has
been learnt and the next press of the remote button should activate the door.
When programming two doors at the one site, we recommend programming
the TOP button first. This is to avoid accidentally operating a
preprogrammed door. Alternatively turn off any preprogrammed doors.
The Bottom Button is the PROGRAMMING button and is the only button
that can commence the programming sequence, irrespective of which button
you choose to control the door.
The operate buttons require a firm press, this is to eliminate accidental
activation due to mishandling the remote.
This remote only operates with 433.92MHz radio control systems.
PROGRAMMING TIPS
de
de
Learn Button
Indicator LED
DN UP PS
123
Learn Button
Sectional & Tilt Door Openers
Roller Door Openers
3
In order to program the Universal Remote, the LEARN button on the
garage door opener must be located. This will need to be activated
during the programming sequence.
The LEARN button may also be labelled, CODE, CODE SET,
DOOR CODE, RADIO SET, ‘S’, or similar.
Refer to your Opener Owner’s Manual for more information.
Here are examples of the LEARN button position

4
TEST
Test the remote control by pressing the button you programmed to control
the door. If the garage door opener does not activate, repeat the
programming steps, view the programming videos on
chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal or
contact Customer Service AU: 1800 638 234 NZ: 0800 653 667
PROGRAMMING THE REMOTE
Start with your garage door closed. Ensure that the door is clear of all
obstructions.
Press and hold the Bottom Button (for
approximately 15 seconds) on the
remote control until the blue LED stays ON
solid, then release the button. (The blue
LED will remain ON for 60 seconds).
Press the LEARN button on your garage door opener for 2-3 seconds,
then release it.
Immediately Press & Release the remote control button you would like
to program. The Blue LED will commence blinking for 12 seconds.
Once the Blue LED changes to solid, immediately Press & Release
the same button on the remote again. The remote will now try to pair
to the opener.
The Blue LED on the remote control will begin to flash once every three
seconds while trying to pair to the opener, (this may take up to 60
seconds). When the door begins moving, immediately (within 3
seconds) press the remote button again.
The coding process is complete and your remote should now be
programmed to the garage door opener.You can repeat this process
using the other remote button to program another garage door opener.
Blue LED
2
1
3
4
Bottom
Button
In order to program the Universal Remote, the LEARN button on the
garage door opener must be located. Please refere to page 3 as well as
the compatibility table on page 2 for the lean button label used for various
brands.
These are generic instructions for most garage door openers, for
ATA branded openers refer to the instructions on page 5. Read through
all steps before commencing, and become familiar with the control buttons.
Once the programming sequence has commenced its important to
continue from one step to another reasonably quickly. Time between
steps is critical.
This is also a good time to view our Instructional videos on our website.
chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal.
5
6

2
1
3
4
Start with your garage door closed. Ensure that the door is clear of all
obstructions
Press and hold the Bottom Button on the remote
control until the blue LED stays ON solid
(approximately 15 seconds), then release the
button. (The blue LED will remain ON for 60
seconds)
Press and Hold the DOOR CODE button on the garage door opener
(Do not release the DOOR CODE button at this point).
Press and Release the remote control button you would like to program.
The Blue LED will commence blinking for 12 seconds.
Once the Blue LED changes to solid, release the DOOR CODE button
immediately and Press and Release the remote button you are
programming.
The Blue LED will begin flashing once every three seconds. Wait until the
door begins moving, and immediately press the remote button again. The
coding process is complete and your remote should now be programmed
to the garage door opener.
You can repeat this process using the other remote button to program
another garage door opener.
ATA BRANDED OPENERS
These programming instructions are for ATA branded garage door openers.
Read through all steps before commencing, and become familiar with the
control buttons. Once the programming sequence has commenced its
important to continue from one step to another reasonably quickly. Time
between some steps is critical.
This is also a good time to view our Instructional videos on our website.
chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal.
Blue LED
Bottom
Button
5
TEST
Test the remote control by pressing the button you programmed to control
the door. If the garage door opener does not activate, repeat the
programming steps, view the programming videos on
chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal or
contact Customer Service AU: 1800 638 234 NZ: 0800 653 667

How do I program the other button on the Universal Remote Control?
After pressing the LEARN button on the motor, go through the same
programming method using the other button. This process will not over
write the first button. The initial 15 second press to put the remote into
learn mode must be performed using the bottom button.
How do I erase previous codes and start fresh?
Codes cannot be erased, only overwritten. A newly programmed code
will take the place of a previous code.
The remote control is not working, the LED is not illuminating.
The LED is also a power indicator, pressing a button on the remote should
cause the LED to illuminate. If the LED does not illuminate after you press
the button, replace the battery using a CR2032 battery.
How can I stop one button from operating two doors?
If one remote control button is operating two doors, you must clear the
memory of the garage door opener that you do not want the button to
activate.
Where is the LEARN button located on my opener?
The LEARN button can either be found on the garage door opener or on an
external receiver. To locate the receiver look for an antenna, some receivers
will require a cover be removed to gain access to the LEARN button.
The LEARN button is often a different colour to the other buttons, and may
be labelled as CODE, CODE SET, DOOR CODE, RADIO SET, “S” or similar.
Refer to your garage door opener manual for information on its location.
Is my garage door opener compatible with the Universal Remote
Control?
Check the compatibility table located on page 2 or for the most up to date
table visit chamberlaindiy.com.au/universal or chamberlaindiy.co.nz/universal.
The Universal remote operates on 433.92MHz systems only.
If I change the battery in the remote control, will I have to reprogram it?
The remote control should retain its memory. If it does not, you will need to
reprogram it.
FREQUENTLY ASKED QUESTIONS
6

Chamberlain Australia Pty Limited / Chamberlain New Zealand
(Chamberlain), warrants to the original consumer purchaser of this product
that it is free from defect in materials and/or workmanship for a period of 1
year from the date of purchase.
The benefits given to you under this Chamberlain Limited Warranty are in
addition to any rights and remedies that you may have under Australian or
New Zealand consumer protection laws. Our goods come with guarantees
that cannot be excluded under the Australian Consumer Law, or New
Zealand Consumer Guarantees Act 1993.
You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
Customer Service:
Australia : 1800 638 234
New Zealand : 0800 653 667
All trade names used herein are trademarks of respective manufacturers listed.
© 2020, The Chamberlain Group, Inc. All Rights Reserved
114-5491-000
ONE YEAR LIMITED WARANTY
