Champion Power Equipment 100330-1 User manual

OPERATOR'S MANUAL
MODEL #100330-1
37 TON FULL BEAM LOG SPLITTER
Made in China - REV 20200416 Champion Power Equipment, Inc., Santa Fe Springs, CA USA
or visit championpowerequipment.com
READ AND SAVE THIS MANUAL. This manual contains important safety precautions which should be read and understood before operating the product. Failure to
do so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com

100330-1 - 37 TON FULL BEAM LOG SPLITTER TABLE OF CONTENTS
2
TABLE OF CONTENTS
Introduction...................................................3
Safety Definitions ..........................................3
Important Safety Instructions.......................4
Fuel Safety .........................................................6
Training .............................................................6
Preparation .........................................................7
Operation ...........................................................7
Maintenance and Storage .........................................7
Safety and Dataplate Labels.......................................8
Safety Symbols.....................................................9
Operation Symbols ............................................... 11
Quickstart Label Symbols........................................ 11
Controls and Features ................................. 12
Log Splitter ....................................................... 12
Engine ............................................................ 13
Parts Included .................................................... 14
Assembly ..................................................... 15
Open Shipping Crate ............................................. 15
1) Install the Tow Bar ............................................ 15
2) Install the Fenders ............................................ 15
3) Install the Wheels ............................................. 15
4) Install the Support Leg........................................ 16
5) Install the Beam ............................................... 16
6) Install the Engine and Hoses.................................. 16
7) Install the Log Catchers....................................... 18
Add Engine Oil.................................................... 18
Add Fuel .......................................................... 19
Add Hydraulic Oil ................................................. 20
Before Each Use Inspect the Log Splitter ....................... 21
Changing Beam from Horizontal to Vertical Orientation ........ 21
Towing Log Splitter Safety....................................... 21
Log Splitter Location............................................. 22
Operation.....................................................22
Starting the Engine............................................... 22
Stopping the Engine.............................................. 23
Log Splitter Operation............................................ 24
Operation at High Altitude ....................................... 24
Maintenance ................................................25
Cleaning the Log splitter......................................... 25
Changing the Engine Oil ......................................... 25
Cleaning and Adjusting the Spark Plug(s) ....................... 25
Cleaning the Air Filter ............................................ 26
Changing the Hydraulic Oil....................................... 26
Maintenance Schedule........................................... 27
Storage ........................................................27
Log Splitter Storage.............................................. 27
Engine Stored for Less than 30 Days ........................... 27
Engines Stored for Over 30 Days ................................ 28
Specifications..............................................29
Log Splitter Specifications....................................... 29
Engine Specifications ............................................ 29
Oil Specifications................................................. 29
Hydraulic Oil System ............................................. 29
Fuel Specifications ............................................... 29
Spark Plug Specifications........................................ 29
Valve Specifications.............................................. 29
Important Message About Temperature......................... 29
Parts Diagram .................................................... 30
Parts List ......................................................... 31
Engine Parts Diagram 44.104 ................................... 32
Engine Parts List 44.104......................................... 33
Engine Parts Diagram R338P.................................... 35
Engine Parts List R338P ......................................... 36
Troubleshooting...........................................38

100330-1 - 37 TON FULL BEAM LOG SPLITTER INTRODUCTION
3
INTRODUCTION
Congratulations on your purchase of a Champion Power Equipment
(CPE) product. CPE designs, builds, and supports all of our
products to strict specifications and guidelines. With proper
product knowledge, safe use, and regular maintenance, this
product should bring years of satisfying service.
Every effort has been made to ensure the accuracy and
completeness of the information in this manual at the time of
publication, and we reserve the right to change, alter and/or
improve the product and this document at any time without prior
notice.
Since CPE highly values how our products are designed,
manufactured, operated and are serviced, and also highly value
your safety and the safety of others, we would like you to take the
time to review this product manual and other product materials
thoroughly and be fully aware and knowledgeable of the assembly,
operation, dangers and maintenance of the product before use.
Fully familiarize yourself, and make sure others who plan on
operating the product fully familiarize themselves too, with the
proper safety and operation procedures before each use. Please
always exercise common sense and always err on the side
of caution when operating the product to ensure no accident,
property damage, or injury occurs. We want you to continue to use
and be satisfied with your CPE product for years to come.
When contacting CPE about parts and/or service, you will need to
supply the complete model and serial numbers of your product.
Transcribe the information found on your product’s nameplate
label to the table below
CPE TECHNICAL SUPPORT TEAM
1-877-338-0999
MODEL NUMBER
100330-1
SERIAL NUMBER
DATE OF PURCHASE
PURCHASE LOCATION
SAFETY DEFINITIONS
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols, and their explanations,
deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger.
The instructions or warnings they give are not substitutes for
proper accident prevention measures.
DANGER
DANGER indicates a hazardous situation which,if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTICE indicates information considered important, but not
hazard-related (e.g., messages relating to property damage).

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY INSTRUCTIONS
WARNING
Cancer and Reproductive Harm – www.P65Warnings.ca.gov
DANGER
Log splitter engine exhaust contains carbon monoxide,
a colorless, odorless, poison gas. Breathing carbon monoxide
will cause nausea, dizziness, fainting or death.
If you start to feel dizzy or weak, get to fresh air immediately.
Operate log splitter outdoors only in a well ventilated area.
DO NOT operate the log splitter inside any building, including
garages, basements, crawlspaces and sheds, enclosure or
compartment.
DO NOT allow exhaust fumes to enter a confined area through
windows, doors, vents or other openings.
DANGER
Using an engine indoors CAN KILL YOU IN MINUTES. Engine
exhaust contains carbon monoxide. This is a poison you cannot
see or smell.
NEVER use inside a home or garage, EVEN IF doors and
windows are open.
ONLY use OUTSIDE and far away from windows, doors,
and vents.
Install battery-operated carbon monoxide alarms or plug-in
carbon monoxide alarms with battery back-up according to the
manufacturer’s instructions.
DANGER
Rotating parts can entangle hands, feet, hair, clothing and/or
accessories. Traumatic amputation or severe laceration can
result.
Keep hands and feet away from rotating parts.
Tie up long hair and remove jewelry.
Operate equipment with guards in place.
DO NOT wear loose-fitting clothing, dangling drawstrings or
items that could become caught.
WARNING
Operation of this equipment may create sparks that can start
fires around dry vegetation.
A spark arrestor may be required. The operator should contact
local fire agencies for laws or regulations relating to fire
prevention requirements.
WARNING
Sparks can result in fire or electrical shock.
When servicing the engine:
Disconnect the spark plug wire and place it where it cannot
contact the plug.
DO NOT check for spark with the plug removed.
Use only approved spark plug testers.
WARNING
Running engines produce heat. Severe burns can occur on
contact. Combustible material can catch fire on contact.
DO NOT touch hot surfaces.
Avoid contact with hot exhaust gases.
Allow equipment to cool before touching.
Maintain at least 3 ft. (91.4 cm) of clearance on all sides to
ensure adequate cooling.
Maintain at least 5 ft. (1.5 m) of clearance from combustible
materials.
WARNING
Crush Hazard
Wedge can cut through skin and break bones. Keep all limbs
away from wedge and endplate.
WARNING
Projectile Hazard
Pieces of log may be ejected from the splitter while operating.
Wear ANSI approved safety glasses when operating. Be alert.
WARNING
Keep Operator Work Zone Clear
Keep work zone clear of debris while working to ensure safe
footing.

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
5
WARNING
Before removing the pin installed into the front support leg
make sure hitch is installed onto vehicle. Releasing the pin
before will cause support leg to slide up and possibly cause
injury.
WARNING
Skin Injection Hazard. High pressure hydraulic oil can inject
under your skin.
Make sure all fittings are tightly secure before applying
pressure. Relieve system of pressure before servicing.
WARNING
Towing Hazard
ALWAYS check all local and state or provincial regulations
regarding towing, licensing and lights before towing your log
splitter. Review towing safety warnings in your towing vehicle
manual. Drive safely. Be aware of the added length of the log
splitter. NEVER ride or transport cargo on the log splitter. DO
NOT exceed the maximum 45 MPH (72 KM/H) towing speed.
WARNING
Rapid retraction of the starter cord will pull hand and arm
towards the engine faster than you can let go. Unintentional
startup can result in entanglement, traumatic amputation or
laceration. Broken bones, fractures, bruises or sprains could
result.
When starting engine, pull the starter cord slowly until
resistance is felt and then pull rapidly to avoid kickback.
CAUTION
Parts of the hydraulic circuit (cylinder, pump, valve-body,
hoses) can become very hot during operation.
WARNING
In most states towing on public streets is either prohibited or
would require further licensing or modifications. Please check
with your local authorities or DMV regarding regulations,
restrictions and registration.
CAUTION
Improper treatment or use of the log splitter can damage it,
shorten its life and void your warranty.
Use the log splitter only for intended uses.
Operate only on level surfaces.
DO NOT expose log splitter to excessive moisture, dust,
or dirt.
DO NOT allow any material to block the cooling slots.
DO NOT use the engine if:
–Equipment sparks, smokes or emits flames
–Equipment vibrates excessively

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
6
Fuel Safety
DANGER
GASOLINE AND GASOLINE VAPORS ARE HIGHLY
FLAMMABLE AND EXPLOSIVE.
Fire or explosion can cause severe burns or death.
Gasoline and gasoline vapors:
–Gasoline is highly flammable and explosive.
–Gasoline can cause a fire or explosion if ignited.
–Gasoline is a liquid fuel but its vapors can ignite.
–Gasoline is a skin irritant and needs to be cleaned up
immediately if spilled on skin or clothes.
–Gasoline has a distinctive odor, this will help detect potential
leaks quickly.
–In any petroleum gas fire, flames should not be extinguished
unless by doing so the fuel supply valve can be turned OFF.
This is because if a fire is extinguished and a supply of fuel is
not turned OFF, then an explosion hazard could be created.
–Gasoline expands or contracts with ambient temperatures.
Never fill the gasoline tank to full capacity, as gasoline needs
room to expand if temperatures rise.
When adding or removing gasoline:
DO NOT light or smoke cigarettes.
Turn the engine off and let it cool for at least two minutes before
removing the gasoline cap. Loosen the cap slowly to relieve
pressure in the tank.
Only fill or drain gasoline outdoors in a well-ventilated area.
DO NOT pump gasoline directly into the engine at the gas station.
Use an approved container to transfer the fuel to the engine.
DO NOT overfill the gasoline tank.
Always keep gasoline away from sparks, open flames, pilot lights,
heat and other sources of ignition.
When starting the engine:
DO NOT attempt to start a damaged engine.
Make certain that the gasoline cap, air filter, spark plug, fuel lines
and exhaust system are properly in place.
Allow spilled gasoline to evaporate fully before attempting to start
the engine.
Make certain that the log splitter is resting firmly on level ground.
When operating the log splitter:
DO NOT move or tip the log splitter during operation.
DO NOT tip the log splitter or allow fuel or oil to spill.
When transporting or servicing the log splitter:
Make certain that the fuel valve is in the OFF position, the gasoline
tank is empty.
Disconnect the spark plug wire.
When storing the log splitter:
Store away from sparks, open flames, pilot lights, heat and other
sources of ignition.
Do not store log splitter or gasoline near furnaces, water heaters,
or any other appliances that produce heat or have automatic
ignitions.
WARNING
Never use a gasoline container, gasoline tank or any other fuel
item that is broken, cut, torn or damaged.
Training
1. Read the Operator’s Manual completely before attempting to
use this log splitter.
2. Do not allow anyone to operate your log splitter who has not
read the Operator’s Manual or has not been instructed on the
safe use of the log splitter.
3. Never allow children or untrained adults to operate this
machine.
4. Many accidents occur when more than one (1) person
operates the log splitter. If a helper is assisting in loading logs
to be split, never actuate controls until helper is clear of the
area.
5. Never allow anyone to ride on the machine.
6. Never transport cargo on the log splitter.
7. High fluid pressures are developed in hydraulic log splitters.
Pressurized hydraulic fluid escaping through a pin hole
opening can puncture skin and cause sever blood poisoning.
Therefore, the following instructions should be heeded at all
times.
–Do not operate the unit with frayed, kinked, cracked or
damaged hoses, fittings, or tubing.
–Stop the engine and relieve hydraulic system pressure
before changing or adjusting fittings, hoses, tubing, or
other system components.
–Do not adjust the pressure settings of the pump or valve.
–Do not check for leaks with your hand. Leaks can
be detected by passing cardboard or wood over the
suspected area. Look for discoloration. If injured by
escaping fluid, see a doctor at once. Serious infection or
reaction can develop if proper medical treatment is not
administered immediately.

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
7
8. Keep the operator zone and adjacent area clear for safe,
secure footing.
9. If your log splitter is equipped with an internal-combustion
engine and intended for use near any unimproved forest,
brush, or grass covered land, the engine exhaust should be
equipped with a spark arrestor. Make sure you comply with
local, state, and federal codes. Take appropriate fire-fighting
equipment with you.
10. Log splitters should be used only for splitting wood. Do not
use for other purposes unless the manufacturer provides
attachments and instructions.
11. Only split wood WITH the grain. NEVER split perpendicular to
the grain
Preparation
1. Be thoroughly familiar with all controls and with proper use of
the equipment.
2. Safety Gear:
–Always wear safety shoes or heavy boots when operating
the machine.
–Always wear safety glasses or goggles when operating
the machine.
–Never wear jewelry or loose-fitting clothing that might
become entangled in moving or rotating parts of the
machine.
3. Make sure the splitter is on a level surface. Block tires and
ensure support leg is secure to prevent unintended movement
of the log splitter during operation.
–Always operate the splitter from the manufacturer’s
indicated operator zone.
4. Logs to be split on ram-type units should be cut as squarely
as possible.
5. Fuel:
–Use an approved fuel container.
–Never add fuel to a running or hot engine.
–Fill fuel tank outdoors with extreme care. Never fill fuel
tank indoors.
–Replace gasoline cap securely and clean up any spilled
fuel.
Operation
1. Before starting this log splitter, review all safety rules. Failure
to follow these rules may result in serious injury to the
operator or bystanders.
2. Be sure to confirm all hose connections and hose clamps are
tight before each use. It is possible for connections to vibrate
loose over time.
3. Never leave the machine unattended with the power source
operating.
4. Never operate the machine when under the influence of
alcohol, drugs or medication.
5. The machine owner should instruct all operators in safe log
splitter operation.
6. Always operate the log splitter with all safety equipment in
place and all controls properly adjusted for safe operation.
7. Always operate the log splitter at manufacturer’s
recommended speed.
8. Always keep hands and feet clear of moving parts.
9. When loading a ram-type log splitter, place your hands on
the sides of the log, not the ends. Never place your hands or
any part of your body between a log and any part of the log
splitter.
10. On ram-type log splitters, never attempt to split more than
one (1) log at a time unless the ram has been fully extended
and a second log is needed to complete the separation of the
first log.
11. On ram-type log splitters on which the logs are not cut
square, the longest portion of the log should be rotated down
and the most square end placed against the ram.
12. Only split logs with the grain of the wood.
13. Use only your hand to operate the log splitter controls.
14. Do not refuel the engine until it has cooled for several
minutes.
Maintenance and Storage
1. Always shut off the power source while repairing or adjusting
the splitter except as recommended by the manufacturer.
2. Clean debris and chaff from the engine cylinder, cylinder head
fins, recoil starter cover, and muffler areas. If the engine is
equipped with a spark arrestor muffler, clean and inspect
it regularly (follow manufacturer’s service instructions).
Replace, if damaged.
3. Never store the unit indoors with fuel in the tank. Fumes
might reach an open flame spark. Allow the engine to cool
before storing in any enclosure.
4. Clear debris from movable parts, but only when the power
source is shut off.
5. Check to be sure all nuts and bolts are tight to assure the
equipment is in safe working condition.

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
8
Top Back
A
B
Safety and Dataplate Labels
These labels warn you of potential hazards that can cause serious injury. Read them carefully.
If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement.
C
LABEL DESCRIPTION
A
1117-L-SF-A
DANGER PELIGRO DANGER
K485 2945 109 30%K
ColorsLPN 1117-L-S F
Rev A
Size 190 x 44 mm
Artwork Notes
3mm corner radius; 2mm safe margin
Revision Changes
---
This ar twork belongs to C hampion Power Equi pment. The conte nts are confiden tial and privileg ed and shall not be disc losed to or used by or f or
outside p arties withou t the explicit conse nt of Champion Power E quipment.
Safety Symbols
B
2018-L-OP-A
ESSENCE SANS PLOM SEULEMENT.
Indice d’octane minimal de
87. Maximum 10 % d'éthanol.
La clasificación mínimo de 87
octano. Máximo de etanol de 10%.
GASOLINA SIN PLOMO SOLAMENTE.UNLEADED FUEL ONLY.
Minimum octane rating of 87.
Maximum 10% ethanol.
K109 --- --- ---
ColorsLPN 2018 -L-OP
Rev B
Size Special
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
WHITE substrate.
Revision Changes
-Cha nge octan e rating 8 5 to octane r ating 87
(20200409)
This ar twork belongs t o Champion Power Eq uipment. The contents are confi dential and privi leged and shall not be d isclosed to or use d by or for
outside p arties withou t the explicit conse nt of Champion Power E quipment.
Fuel
C
1966-L-SF-A
DO NOT TOUCH!
Hot surface.
WARNING
¡NO TOCAR!
Superficie caliente.
ADVERTENCIA
AVERTISSEMENT
NE TOUCHEZ PAS!
Surface chaude.
K485 152 --- ---
ColorsLPN 1966-L-S F
Rev A
Size 59 x 47 mm
Artwork Notes
3mm corner radius; 2mm safe margin; whit e to be
prin ted shown i n 50% proce ss magent a
Revision Changes
---
This ar twork belong s to Champion Power Equipment. The c ontents are co nfidential and privileged and shall not be disclos ed to or used by or for
outside parties without the explicit c onsent of Champion Power Equipment .
Hot Surface
D
CHAMPION POWER EQUIPMENT, INC.
12039 SMITH AVENUE
SANTA FE SPRINGS, CA 90670
USA / É.-U.
1-877-338-0999
WWW.CHAMPIONPOWEREQUIPMENT.COM
MADE IN CHINA / FABRIQUÉ EN CHINE
1275-L-PR-B
MANUFACTURE DATE
DATE DE FABRICATION
SERIAL NO.
N° DE SÉRIE
MODEL
MODÉLE 100330-1
XXXX
XXXXXXXXXXXX
K--- --- --- ---
ColorsLPN 1275-L-PR
Rev B
Size 51 x 64 mm
Artwork Notes
3mm corner ra dius; 2mm safe margin; to be printe d
on sec urity s ubstr ate; magenta text to be filled in
during time of produc tion
Revision Changes
B: Show text “SERIAL NO.”
Updated height from 67 mm to 64 mm
This ar twork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
Dataplate
D

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
9
Safety Symbols
These labels warn you of potential hazards that can cause serious injury. Read them carefully.
If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement.
SYMBOL MEANING
Read Operator’s Manual. To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Eye and Ear Protection. Always wear safety goggles or safety glasses with side shields, and as
necessary a full face-shield as well as full ear protection when operating this product.
Footwear. Always wear safety shoes or heavy boots when operating the machine.
Gloves. Always wear nonslip, heavy-duty protective gloves when operating this product.
Safety Alert. Precautions that involve your safety.
Risk of Fire. Fuel and its vapors are extremely flammable and explosive. Fire can cause severe
burns or death. Do not add fuel while the product is operating or still hot.
Skin Injection Hazard. High pressure hydraulic oil can inject under your skin.
Make sure all fittings are tightly secure before applying pressure. Relieve system
pressure before servicing.
Always keep hands away from the wedge and the ram. Moving parts can crush or cut.

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
10
SYMBOL MEANING
Always keep feet away from the wedge and the ram. Moving parts can crush or cut.
Hot Surface. To reduce the risk of injury or damage, avoid contact with any hot surface
Open Flame alert. Fuel and its vapors are extremely flammable and explosive. Keep fuel away
from smoking, open flames, sparks, pilot lights, heat, and other ignition sources.
Hold logs on sides when loading. Keep hands and feet away from cylinder, wedge,
and partially split logs.
Never place hands or any part of the body between a log and any part of the log splitter.
Do not split logs against the grain. Split logs end to end in the direction of the grain only.
Toxic Fumes. The engine exhaust from this product contains chemicals known to the state of
California to cause cancer and birth defects and other reproductive harm.
Risk of Asphyxiation. This engine emits carbon monoxide, an odorless, colorless poison gas.
Breathing carbon monoxide can cause nausea, fainting or death. Use only in a well ventilated
area.
Clearance. Keep all objects including others at least 10 feet (3m) from this machine.
Only one person should operate the log splitter and load the logs
Never operate on an incline. Make sure the splitter is on a level surface. Block tires and ensure
support leg is secure to prevent unintended movement of the log splitter during operation.
MAX. 45 MPH (72 km/h)
DO NOT exceed the maximum 45 MPH (72 KM/H) towing speed.
Always check all local, state or provincial regulations regarding towing, licensing and lights before
towing your log splitter. Review towing safety warnings in your towing vehicle manual.
In most states towing on public streets is either prohibited or would require further licensing or
modifications. Please check with your local, state, or provincial authorities regarding regulations,
restrictions and registration.
Any modifications required to meet these laws are the responsibility of the purchaser.

100330-1 - 37 TON FULL BEAM LOG SPLITTER IMPORTANT SAFETY INSTRUCTIONS
11
Operation Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
SYMBOL MEANING
STOP or OFF
Fuel/Gasoline Valve ON/OFF
Quickstart Label Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
Starting the Engine
DANGER
Move log splitter outside and far away from windows,
doors and intake ventilation covers.
1. Check oil level.
Recommended oil is 10W-30.
2. Turn the fuel valve to “ON” position.
3. Move choke lever to “CHOKE” position.
4. Pull the recoil cord.
5. Move the choke lever to “RUN” position.
2107-L-OP-A
1
10W-30

21
2
3
54
K376 485 152 CG1
ColorsLPN 2107-L-OP
Rev A
Size 75 x 35 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
WHITE substrate.
Revision Changes
---
This artwork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
Stopping the Engine
In an emergency, turn the engine switch to the “OFF”
position.
Under normal operation:
1. Turn the fuel valve to the “OFF” position.
2. Let the engine run until fuel starvation has stopped the
engine. This usually takes few minutes.
Important: Always ensure that the fuel valve is in the “OFF”
position when the engine is not in use.

100330-1 - 37 TON FULL BEAM LOG SPLITTER CONTROLS AND FEATURES
12
CONTROLS AND FEATURES
Read this operator’s manual before operating your log splitter. Familiarize yourself with the location and function of the controls and
features. Save this manual for future reference.
Log Splitter
1. 2 in. (5.1 cm) Ball Coupler – For towing the log splitter
behind your vehicle.
2. Hydraulic Cylinder – 5 in. (12.7 cm) bore × 23 in.
(58.4 cm) stroke. Rated to 3600 psi.
3. Control Valve Handle – Controls the movement of the
cutting wedge.
4. Wedge
5. Splitting Beam
6. Log Cradle – Prevents logs from rolling off beam.
7. Log Catchers
8. Engine – 338cc, OHV.
9. Tires – Maximum travel speed is 45 MPH (72 KM/H).
10. Beam Lock Pin – Secures in either horizontal or vertical
position.
11. Beam Bracket – Holds splitting beam in place.
12. Support Leg – Supports log splitter while operating. Raise
leg for towing.
13. Safety Chains – For use while towing.
1
13
3
2
4
10
11
5
6
7
8
9
12

100330-1 - 37 TON FULL BEAM LOG SPLITTER CONTROLS AND FEATURES
13
Engine
1. Muffler
2. Air Filter – Protects the engine by filtering dust and debris
from the intake air.
3. Choke – Used to start the engine.
4. Fuel Valve – Used to turn fuel supply on and off to engine.
5. Recoil Starter – Used to manually start the engine.
6. Engine Switch – Used to STOP the engine.
7. Oil Drain Bolt – Used to drain the oil from the engine.
8. Oil Fill Cap/Dipstick –Used to check and fill oil level.
9. Gasoline Tank – 1.6 gal. (6.1 L)
10. Fuel Cap – Remove to add fuel.
1
2
9
10
3
4
5
67
8

100330-1 - 37 TON FULL BEAM LOG SPLITTER CONTROLS AND FEATURES
14
Parts Included
Part Part Qty. Hardware Needed Hardware
Qty. Tool Needed
Wheels 2Castle Nut 230mm open-end wrench
Axle Cap 2Mallet
Support Leg 1Pin 1
R-Pin 1
Tow Bar 1Bolt M12 × 85 218mm wrench or socket
Nut M12 219mm wrench or socket
Engine 1
Bolt M10 × 45 416mm wrench
Lock Nut M10 417mm wrench
Flat Washer 4
Beam 1Bolt M18 ×115 127mm wrench or socket
Nut M14 122mm wrench or socket
Fenders 2
Bolt M10 ×25 416mm wrench or socket
Nut M10 417mm wrench
Lock Washer 4
Flat Washer 4
Oil Return Hose 127mm open-end wrench
High Pressure Hose 127mm open-end wrench
Suction Hose 1C-Clamp 2Flat head screw driver or
8mm socket
Log Catchers 2
Bolt M10 ×30 26mm allen wrench
Bolt M10 ×20 416mm wrench or socket
Nut M10 217mm wrench
Lock Washer 6
Flat Washer 6
Accessories
–Oil Funnel

100330-1 - 37 TON FULL BEAM LOG SPLITTER ASSEMBLY
15
ASSEMBLY
If your log splitter is already assembled, skip the assembly
instructions in this manual.
If unassembled, please read and follow these instructions.
If you have any questions regarding the assembly of your log
splitter, call our Technical Support Team at 1-877-338-0999.
Please have your serial number and model number available.
Open Shipping Crate
1. Set the shipping crate on a solid, flat surface
2. Carefully cut the shipping bands and remove lid of shipping
crate.
3. Locate all hardware before beginning assembly.
1) Install the Tow Bar
Attach the tow bar (55) to the bracket on top of the hydraulic oil
tank (43) with two M12 × 85 bolts (34), Ø12 washers (3) and M12
lock nuts (2).
2
334
43
55
2) Install the Fenders
1. Attach the fender (35) to the side of the hydraulic oil tank with
an M10 × 25 bolt (36), Ø10 washer (22), Ø10 lock washer
(21) and M10 nut (26). The safety reflector should be facing
the back of the hydraulic oil tank.
36
35
22 21
26
2. Repeat with second fender on opposite side.
3) Install the Wheels
1. Remove the two plastic shipping caps from the wheel hubs.
2. Slide the wheel (40) onto the axle.
–Be sure the tire valve stem is facing out.
3. Thread the castle nut (38) on the axle and tighten by hand.
Use a wrench to tighten another ¼ turn.
4. Spin the wheel (40) to distribute the bearing grease.
5. Loosen the castle nut (38) and re-tighten by hand.
6. Install the cotter pin (42) through the axle and castle
nut (38).
7. Wheel should spin freely but when grasped on both sides,
should not move from side to side (40).
8. Install the axle cap (37) using a soft face mallet or hammer
and wood block.
9. Repeat for the other wheel.
37
38 42
40
NOTICE
Keep dirt and debris away from the wheel bearings during
assembly.
CAUTION
Over-tightening the castle nut will cause the bearings to run
hot and fail prematurely.

100330-1 - 37 TON FULL BEAM LOG SPLITTER ASSEMBLY
16
4) Install the Support Leg
Insert the support leg (60) into the leg holder on the tow bar and
secure with pin (57) and R-pin (56).
57 56
60
5) Install the Beam
Stand the beam (1) vertical on the foot plate.
1. Roll the tank into position so the pivot holes of the tank and
beam are aligned.
2. Insert the bolt (29) and secure it with the washers (31), (32)
and lock nut (33).
3. Tighten the lock nut (33) onto the bolt (29).
1
31
32
33
29
NOTICE
The bolt (29) should slide with little resistance in the slotted
hole
–When in the vertical position, the bolt should be at the rear/
bottom of the slotted hole (see Fig. A)
–When in the horizontal position, the bolt should be at the
front/top of the slotted hole (see Fig. B)
If the bolt does not slide to the correct position when the beam
is transitioned, loosen the nut in half turn increments until it
does.
FIG A FIG B
4. Pivot the beam to the horizontal position and secure it with
the lock pin (54) and R-clip (56) through the tow bar.
54
56
WARNING
The beam is extremely heavy and should only be handled
with 2 or more people. DO NOT try and lift or handle the beam
without assistance.
6) Install the Engine and Hoses
CAUTION
Red shipping plugs must be removed from hydraulic pump
prior to installing hoses.
Hydraulic pump may contain
residual oil from
testing procedures
during production.
We recommend using an oil
tray under the pump before
removing the shipping plugs.

100330-1 - 37 TON FULL BEAM LOG SPLITTER ASSEMBLY
17
NOTICE
Oil Inlet (High Pressure) and Oil Return Hoses
Some hoses may be preassembled by the factory, check your
hoses per below instructions to ensure proper assembly.
–These hoses are black and have swivel nuts on both ends.
–The Oil Inlet Hose sends hydraulic oil from the pump to the
control valve/cylinder.
–The Oil Return Hose returns hydraulic oil from the control
valve/cylinder to the tank.
–Hose connections do NOT require thread seal tape. The
O-ring seals against the face of the fittings on the pump
and hose.
Suction Hose
–This is the clear hose that connects the hydraulic tank to
the pump inlet.
–Secure both ends of hose with hose clamps.
Engine
1. Place the engine on the engine mounting platform with the
recoil cover facing outward towards the wheel and align
the 4 holes on the engine base with the holes in the engine
platform.
2. Install a M10 × 45 bolt up through the hole on the engine
platform and through the hole on the engine base.
3. Place a washer on the M10 x 45 bolt and thread a M10 nylon
lock nut onto the bolt and tighten securely. Tighten to
11.8 lbf-ft − 14.7 lbf-ft (16-20 Nm) or fully, then ¼ turn
further.
4. Repeat steps 2 and 3 for the remaining bolts, washers and
lock nuts.
Suction Hose
5. Using the provided d32 hose clamps, connect one end of the
clear oil hose to the hydraulic oil tank (C) just beneath the
engine and the other end to the pump inlet on the side of the
pump (D). Securely tighten the clamps on both ends of the
clear hydraulic hose with either a flat head screw driver or
8mm socket
(Torque: 2.9 lbf-ft (3.9 Nm) to 4.4 lbf-ft (6.0 Nm)).
C
D
Oil Return (Low Pressure) Hose
6. Place an o-ring into the control valve outlet fitting (E) and oil
filter inlet fitting (F). Make sure the o-ring is properly placed
in the inner groove. Connect one end of hose to the control
valve outlet (E). Connect the other end of the hose to the oil
filter inlet (F). Securely tighten both ends of the hydraulic
hose with a 27mm wrench
(Torque: 52 lbf-ft (70.5 Nm) to 66 lbf-ft (89.5 Nm)).
E
F
Oil Inlet (High Pressure) Hose
7. Place an o-ring into the control valve outlet fitting (E) and oil
filter inlet fitting (F). Make sure the o-ring is properly placed
in the inner groove. Connect one end of hose to the control
valve outlet (E). Connect the other end of the hose to the oil
filter inlet (F). Securely tighten both ends of the hydraulic
hose with a 27mm wrench
(Torque: 44 lbf-ft (59.7 Nm) to 52 lbf-ft (70.5 Nm)).
A
B

100330-1 - 37 TON FULL BEAM LOG SPLITTER ASSEMBLY
18
7) Install the Log Catchers
Large Log Catcher (Engine Side)
1. With the log catcher angled upward, align the four holes
on the log catcher with the 4 threaded holes on the splitter
beam.
2. Place a M10 flat washers (22) and M10 lock washers (21)
onto the four M10 x 15 bolts (20) and thread them through
the holes on the log catcher and into the holes on the splitter
beam and tighten securely.
20
22
21
Small Log Catcher (Hydraulic Hose Side)
3. With the log catcher angled downward and under the lip of
the splitter beam, align the two holes on the log catcher with
the two holes on the beam lip.
4. Place the two M10 x 15 bolts (A) through the holes on the
beam and through the holes on the log catcher. Place a M10
flat washer (B) and a M10 lock washer (C) onto the bolt (A)
from the bottom side and thread the M10 nuts (D) onto the
bolts and tighten securely.
CORRECT ASSEMBLY
ORIENTATION
A
C
B
D
INCORRECT ASSEMBLY
ORIENTATION
A
C
B
D
Add Engine Oil
CAUTION
DO NOT attempt to crank or start the engine before it has been
properly filled with the recommended type and amount of oil.
Damage to the engine as a result of failure to follow these
instructions will void your warranty.
NOTICE
The recommended oil type is 10W-30 automotive oil.
-20 020 40 60
Ambient temperature
Recommended Engine Oil Type
80 100 120
-28.9
°F
°C -17.8 -6.7 4.4 15.6 26.7 37.8 48.9
10W-30
5W-30 Synthetic
10W-405W-30
1. Place the log splitter on a flat, level surface.
2. Remove oil fill cap/dipstick to add oil.
3. Using a funnel, add up to 16.9 fl. oz (500 ml) of oil (not
included) and replace oil fill cap/dipstick. DO NOT OVERFILL.
4. Check engine oil level daily and add as needed.
MAX
OIL DIP STICK
NOTICE
Once oil has been added, a visual check should show oil about
1-2 threads from running out of the fill hole.
If using the dipstick to check oil level, DO NOT screw in the
dipstick while checking.
NOTICE
Check oil often during the break-in period. Refer to the
Maintenance section for recommended service intervals.

100330-1 - 37 TON FULL BEAM LOG SPLITTER ASSEMBLY
19
CAUTION
The engine is equipped with a low oil shut-off and will stop
when the oil level in the crankcase falls below the threshold
level.
NOTICE
We consider the first 5 hours of run time to be the break-
in period for the engine. During the break in period we
recommend using standard automotive non-synthetic blended
oils. After the break in period synthetic lubricant can be used
but is not required. Avoid bogging or lugging the engine down
and avoid prolonged running at constant RPM. After the 5 hour
break-in period, change the oil. Using synthetic lubricants does
not decrease the recommended oil change interval.
NOTICE
Weather will affect engine oil and engine performance. Change
the type of engine oil used based on weather conditions to suit
the engine needs.
NOTICE
Synthetic oil may be used after the 5 hour initial break-in
period. Using synthetic oil does not decrease the recommended
oil change interval. Full synthetic 5W-30 oil will aid in starting
in cold ambient < 41º F (5º C)
Add Fuel
1. Use clean, fresh, regular unleaded gasoline with a minimum
octane rating of 85 and an ethanol content of less than 10%
by volume. ybc
2. DO NOT mix oil with gasoline.
3. Remove the gasoline cap.
4. Slowly add gasoline to the tank. DO NOT OVERFILL. Gasoline
can expand after filling. A minimum of ¼ in. (6.4 mm) of
space left in the tank is required for gasoline expansion,
although more than ¼ in. (6.4 mm) is recommended. Gasoline
can be forced out of the tank as a result of expansion if
overfilled, and can affect the stable running condition of the
log splitter.
5. Screw on the gasoline cap and wipe away any spilled fuel.
CAUTION
Use regular unleaded gasoline with a minimum octane rating
of 85 and an ethanol content of less than 10% by volume.
DO NOT light cigarettes or smoke when filling the tank.
DO NOT mix oil and gasoline.
Fill tank to approximately ¼ in. (6.4 mm) below the top of the
tank to allow for gasoline expansion.
DO NOT pump gasoline directly into the log splitter at the
pump. Use an approved container to transfer the gasoline to
the log splitter.
DO NOT fill tank indoors.
DO NOT fill tank when the engine is running or hot.
DO NOT overfill the tank.
WARNING
Pouring gasoline too fast through the fuel screen may result in
blow back of gasoline at the operator while filling.
NOTICE
Our engines work well with 10% or less ethanol blend
gasoline. When using ethanol-gasoline blends there are some
issues worth noting:
–Ethanol-gasoline blends can absorb more water than
gasoline alone.
–These blends can eventually separate, leaving water or a
watery goo in the tank, fuel valve and carburetor.
–With gravity-fed supplies, the compromised gasoline can
be drawn into the carburetor and cause damage to the
engine and/or potential hazards.
–There are only a few suppliers of fuel stabilizer that are
formulated to work with ethanol-gasoline blends.
–Any damages or hazards caused by using improper
gasoline, improperly stored gasoline, and/or improperly
formulated stabilizers, are not covered by manufacturer’s
warranty.
It is advisable to always shut off the gasoline supply, run the
engine to starvation and drain the tank when the equipment is
not in use for more than 30 days.

100330-1 - 37 TON FULL BEAM LOG SPLITTER ASSEMBLY
20
Add Hydraulic Oil
If your log splitter was delivered pre-assembled, follow these
instructions:
1. Position the log splitter on a flat, level surface.
2. Remove the plastic shipping plug from the oil tank on the top
of the tank (A) and discard. Replace with the steel oil plug
(with breather hole) shipped with your log splitter (A).
CAUTION
Do not run the log splitter with temporary shipping plug.
Pressure will build up inside the tank and potential damage
could occur.
NOTICE
Hydraulic tank is deliberately overfilled before shipping from
the factory. When the unit has been operated, oil will adjust to
proper level.
3. After running and cycling the unit several minutes (purging air
from the system), turn off the engine and check the hydraulic
oil level using the oil sight glass. Oil level should visibly fill the
glass sight.
If your log splitter was delivered unassembled, follow these
instructions:
1. Make sure the log splitter is on a flat, level surface.
2. Remove the oil plug from the oil tank (A).
3. Add 5 gal. (18.9 L) of hydraulic oil - see specification section
for types of acceptable oil.
4. Check the hydraulic oil level using the oil sight glass.
Oil level should visibly fill the sight glass.
A
WARNING
DO NOT remove the hydraulic oil fill cap when the engine
is running or hot. Hot oil can escape causing severe burns.
Always allow the log splitter to cool completely before
removing the hydraulic oil cap.
High fluid pressure and temperatures are created in the
hydraulic log splitters. Hydraulic fluid will escape through a
pin-size hole opening and can puncture skin and cause severe
blood poisoning.
Inspect hydraulic system regularly for possible leaks.
Never check for leaks with your hand while the system is
pressurized. Seek medical attention immediately if injured by
escaping fluid.
5. Replace and tighten the oil plug and orient the vent hole away
from the operator zone.
6. Start engine. (See starting the engine section)
7. Extend and retract the wedge to purge air from the hydraulic
system. When the wedge motion is smooth,
the system is properly purged.
8. Check the hydraulic oil tank sight glass. Add approximately 1
gallon (3.8 L) of hydraulic oil to bring the level back up to the
sight glass. Do NOT overfill.
9. Check oil level daily and add as needed.
NOTICE
When the outdoor temperature is below 32˚F, Dexron III
transmission fluid can be used. Do not mix hydraulic oil and
transmission fluid. Drain all oil or fluid before adding the other
one.
See hydraulic oil system specifications section for more details
NOTICE
To check oil level, use the oil sight glass on the tank.
The oil sight glass has a marker for the acceptable level of
oil. If oil is below the marker, add oil as needed. DO NOT
OVERFILL.
