Champion Power Equipment 200940 User manual

OPERATOR'S MANUAL
MODEL #200940
EARTH AUGER
Champion Power Equipment, Inc., Santa Fe Springs, CA USA
SAVE THESE INSTRUCTIONS. This manual contains important safety precautions which should be read and understood before operating the product. Failure to do
so could result in serious injury. This manual should remain with the product.
Specifications, descriptions and illustrations in this manual are as accurate as known at the time of publication, but are subject to change without notice.
REGISTER YOUR PRODUCT ONLINE
at championpowerequipment.com
3352-M-OP RE V 20211108 EN
or visit championpowerequipment.com
WARNING
To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. If you do not
understand the warnings and instructions in the operator’s manual, do not use this product.
NOTICE
Do not use E15 or E85 fuel (fuel containing ethanol greater than 10%) in this product. The use of E15 will damage your engine and void
your warranty. FUEL MIXTURE for this product is powered by a 2-cycle engine and requires pre-mixing gasoline and 2-cycle oil in a
50:1 ratio. Pre-mix unleaded gasoline and 2-cycle engine oil in a clean container approved for gasoline.
DO NOT mix quantities larger than usable in a 30-day period.

200940 - EARTH AUGER TABLE OF CONTENTS
2
TABLE OF CONTENTS
Introduction...................................................3
Safety Definitions ..........................................3
Important Safety Instructions.......................4
Fuel Safety ........................................................ 5
Safety and Dataplate Labels...................................... 7
Safety Symbols.................................................... 8
Operation Symbols ............................................... 10
Quick Start Label Symbols....................................... 10
Controls and Features ................................. 11
Earth auger....................................................... 11
Parts Included .................................................... 12
Tools Needed ..................................................... 12
Assembly ..................................................... 13
Unpacking ........................................................ 13
Assemble the Fishtail Point to the Auger Bit .................... 13
To Assemble Auger Bit to Powerhead ........................... 13
Operation..................................................... 13
Fueling and Refueling ............................................ 13
Starting the Engine............................................... 14
Stopping the Engine.............................................. 16
Operating the Auger.............................................. 17
Transporting the Auger .......................................... 17
Maintenance...................................................... 18
Cleaning the Earth auger ........................................ 18
Cleaning and Adjusting the Spark Plug(s) ....................... 18
Cleaning the Air Filter ............................................ 19
Earth Blade and Fishtail Point ................................... 19
Adjusting the Governor........................................... 19
Maintenance Schedule........................................... 19
Storage ........................................................20
When storing 1 month or shorter: ............................... 20
When storing longer than a month:.............................. 20
Specifications..............................................20
Earth auger Specifications....................................... 20
Engine Specifications ............................................ 20
Oil Specifications................................................. 20
Fuel Specifications ............................................... 20
Temperature Specifications...................................... 20
Troubleshooting........................................... 21

200940 - EARTH AUGER INTRODUCTION
3
SAFETY DEFINITIONS
The purpose of safety symbols is to attract your attention to
possible dangers. The safety symbols, and their explanations,
deserve your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The
instructions or warnings they give are not substitutes for proper
accident prevention measures.
DANGER
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
NOTICE indicates information considered important, but not
hazard-related (e.g., messages relating to property damage).
INTRODUCTION
Congratulations on your purchase of a Champion Power Equipment
(CPE) product. CPE designs, builds, and supports all of our
products to strict specifications and guidelines. With proper
product knowledge, safe use, and regular maintenance, this
product should bring years of satisfying service.
Every effort has been made to ensure the accuracy and
completeness of the information in this manual at the time of
publication, and we reserve the right to change, alter and/or
improve the product and this document at any time without prior
notice.
CPE highly values how our products are designed, manufactured,
operated, and serviced as well as providing safety to the operator
and those around the earth auger. Therefore, it is IMPORTANT to
review this product manual and other product materials thoroughly
and be fully aware and knowledgeable of the assembly, operation,
dangers and maintenance of the product before use. Fully
familiarize yourself, and make sure others who plan on operating
the product fully familiarize themselves too, with the proper safety
and operation procedures before each use. Please always exercise
common sense and always err on the side of caution when
operating the product to ensure no accident, property damage,
or injury occurs. We want you to continue to use and be satisfied
with your CPE product for years to come.
When contacting CPE about parts and/or service, you will need to
supply the complete model and serial numbers of your product.
Transcribe the information found on your product’s nameplate
label to the table below
CPE TECHNICAL SUPPORT TEAM
1-877-338-0999
MODEL NUMBER
200940
SERIAL NUMBER
DATE OF PURCHASE
PURCHASE LOCATION

200940 - EARTH AUGER IMPORTANT SAFETY INSTRUCTIONS
4
IMPORTANT SAFETY INSTRUCTIONS
DANGER
Earth auger exhaust contains carbon monoxide, a colorless,
odorless, poisonous gas. Breathing carbon monoxide will
cause nausea, dizziness, fainting or death. If you start to feel
dizzy or weak, get to fresh air immediately.
OPERATE THE EARTH AUGER OUTDOORS ONLY IN A WELL
VENTILATED AREA AND POINT EXHAUST AWAY.
NEVER operate the earth auger inside any building, including
garages, basements, sheds or other confined spaces.
DO NOT allow exhaust fumes to enter a confined area through
windows, doors, vents or other openings while operating the
auger.
DANGER
Using an engine indoors CAN KILL YOU IN MINUTES. Engine
exhaust contains carbon monoxide. This is a poison you cannot
see or smell.
DANGER
Contact your local utility company to locate underground
electrical lines or pipes prior to using this product. Failure to do
so may result in serious personal injury or death and possible
damage to equipment or property.
DANGER
DO NOT allow untrained individuals or children to use this unit.
DANGER
Rotating parts can entangle hands, feet, hair, clothing and/or
accessories. Traumatic amputation or severe laceration can
result.
Keep hands and feet away from rotating parts.
Tie up long hair and remove jewelry.
Operate equipment with guards in place.
DO NOT wear loose-fitting clothing, dangling drawstrings or
items that could become caught.
WARNING
–Clear the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the machine.
–Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes and other possible
serious injuries.
–Keep all bystanders, children, and pets at least 50’ (15m)
away when operating the earth auger.
–Always wear sound protection (ear mufflers or ear plugs) to
reduce the risk of hearing loss associated with long term
engine sound level(s).
–Always wear heavy long pants, boots, gloves, and a long-
sleeve shirt. Do not wear loose clothing, jewelry, short
pants, sandals, or go barefoot. Secure long hair so it is
above shoulder level to prevent entanglement in rotating
parts.
–Do not operate this unit when you are tired, ill, or under the
influence of alcohol, drugs, or medication.
–Do not operate in poor lighting.
–Always wear a face filter mask in dusty conditions to
reduce the risk of injury associated with the inhalation of
dust.
–Keep firm footing and balance. Maintain a firm grip on the
handle with both hands while using the auger.
–Do not overreach. Overreaching can result in loss of
balance or exposure to hot contact surfaces or rotating
parts.
–This engine is equipped with a spark arrestor. Never
operate the unit without a spark arrestor screen.
–Although the earth auger contains a spark arrester,
maintain a minimum distance of 5 ft. (1.5 m) from dry
vegetation to prevent fires.
–Always inspect the unit before each use for loose
fasteners, fuel leaks, etc. Replace damaged parts.
–Use only identical manufacturer’s replacement parts and
accessories. Use of any other replacement parts may
create a hazard or cause product damage and void your
warranty.
–Maintain the equipment per maintenance instructions
located in this Operator’s Manual
DANGER
Rotating blades can cause severe bodily injury. Stop the engine
and ensure blades have stopped rotating before installing/
changing parts or performing maintenance.

200940 - EARTH AUGER IMPORTANT SAFETY INSTRUCTIONS
5
WARNING
Sparks can result in fire or electrical shock.
When servicing the earth auger:
Disconnect the spark plug wire and place it where it cannot
contact the plug or any other metal object.
DO NOT check for spark with the plug removed.
Use only approved spark plug testers.
WARNING
Running engines produce heat. Severe burns can occur on
contact. Combustible material can catch fire on contact.
DO NOT touch hot surfaces.
Avoid contact with hot exhaust gases.
Allow equipment to cool before touching.
Maintain at least 3 ft. (91.4 cm) of clearance on all sides to
ensure adequate cooling.
Maintain at least 5 ft. (1.5 m) of clearance from combustible
materials.
WARNING
Rapid retraction of the recoil cord will pull hand and arm
towards the engine faster than you can let go. Broken bones,
fractures, bruises or sprains could result.
When starting engine, pull the recoil cord slowly until
resistance is felt and then pull rapidly to avoid kickback.
CAUTION
Prolonged exposure to vibrations, also known as vibration
white finger, through use of gasoline-powered equipment,
such as this auger, could cause blood vessel or nerve damage
in fingers, hands, and joints. If symptoms occur such as
numbness, or loss of feeling in the fingers, hands, or joints,
discontinue the use of this auger and seek medical attention.
Fuel Safety
DANGER
GASOLINE AND GASOLINE VAPORS ARE HIGHLY
FLAMMABLE AND EXPLOSIVE.
Fire or explosion can cause severe burns or death.
Gasoline and gasoline vapors:
–Gasoline is highly flammable and explosive.
–Gasoline can cause a fire or explosion if ignited.
–Gasoline is a liquid fuel but it’s vapors can ignite.
–Gasoline is a skin irritant and needs to be cleaned up
immediately if spilled on skin or clothes.
–Gasoline has a distinctive odor, this will help detect potential
leaks quickly.
–Gasoline expands or contracts with ambient temperatures.
Never fill the gasoline tank to full capacity, as gasoline needs
room to expand when temperatures rise.
–In the case of any petroleum gasoline fire, flames should never
be extinguished unless the fuel supply valve can be turned
OFF. By not doing so, if a fire is extinguished and the supply
of fuel is not turned OFF, an explosion hazard could be created.
When adding or removing gasoline:
DO NOT light or smoke cigarettes while handling gasoline.
Always store or transfer gasoline in an EPA/CARB compliant fuel
tank.
Never pump gasoline directly into the earth auger at the gas
station.
Always drain gasoline outdoors in a well-ventilated area.
Always loosen fuel cap slowly to release vapor pressure and to
keep fuel from escaping around the fuel cap.
Always replace and tighten the fuel cap securely after fueling.
Always stop the engine and allow to cool for a minimum of two
minutes before refueling.
Never remove the fuel cap or add fuel while the engine is running
or when the engine is hot.
DO NOT overfill the gasoline tank.
In the event of spilled fuel, wipe the fuel from the earth auger
and move 10 ft. (3m) away from refueling site before starting the
engine to avoid potential ignition of fuel vapors.
Save these instructions. Refer to them frequently and use them
to instruct others who may use this product. If you loan this
equipment, provide these instructions also.

200940 - EARTH AUGER IMPORTANT SAFETY INSTRUCTIONS
6
When starting the earth auger:
DO NOT attempt to start a damaged earth auger.
Always check that the gasoline cap, air filter, spark plug, fuel lines
and exhaust system are properly in place.
Always be certain that the earth auger is resting firmly on level
ground.
When operating the earth auger:
DO NOT move or tip the earth auger during operation.
When transporting or servicing the earth auger:
Always check that the fuel valve is in the OFF position and the
gasoline tank is empty.
Disconnect the spark plug wire.
When storing the earth auger:
WARNING
Always store gasoline in a cool, well-ventilated area, safely
away from sparks, open flames, pilot lights, heat and other
sources of ignition.
WARNING
Never use a gasoline container, gasoline tank, or any other fuel
item that is broken, cut, torn or damaged.

200940 - EARTH AUGER IMPORTANT SAFETY INSTRUCTIONS
7
Safety and Dataplate Labels
These labels warn you of potential hazards that can cause serious injury. Read them carefully.
If a label comes off or becomes hard to read, contact Technical Support Team for possible replacement.
LABEL DESCRIPTION
A
PELIGRODANGER DANGER
3136-L-SF-B
10 ft.
3 m
485 152 109 K2945
ColorsAPN 3136 -L-SF
Rev B
Size 120 x 36 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
white substrate.
Revision Changes
B-Changed to10ft/3m
This ar twork belongs to Champion Power E quipment. The co ntents are con fidential and pr ivileged and shal l not be disclosed t o or used by or for
outside parties with out the explicit con sent of Champion Po wer Equipment.
Engine Danger Icon
B
3138-L-SF-A
485 K---
--- ---
ColorsLPN 3138-L-SF
Rev A
Size 20 x 20 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
white substrate.
Revision Changes
---
This ar twork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
Hot Surface Warning
C
3137-L-SF-A
WARNING Operation of this equipment may create sparks that can star t fires around dry vegetation. A
spark arrestor may be required. The operator should contact local fire agencies for laws or
regulations relating to fire prevention requirements.
ADVERTENCIA Operación de este equipo puede crear chispas que pueden iniciar incendios en
vegetación seca. Un parachispas puede ser requerido. El operador debería contactar
las agencias locales de incendios para leyes o regulaciones relacionadas con requisitos de prevención de incendios.
AVERTISSEMENT Le fonctionnement de cet équipement peut créer des étincelles qui peuvent déclencher des
incendies autour de la végétation sèche. Un pare-étincelles peut être nécessaire. L'utilisateur
doit communiquer avec le service d'incendie local pour les lois et les règlements relatifs à la prévention des incendies.
---152 ---K---
ColorsAPN 313 7-L- SF
Rev A
Size 129 x 44 m m
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
white substrate.
Revision Changes
---
This ar twork belongs t o Champion Power Equ ipment. The cont ents are confid ential and privile ged and shall not be di sclosed to or used by o r for
outside p arties withou t the explicit conse nt of Champion Power E quipment.
Spark Arrestor Warning
D
3280-L-SF-A
50:1 NOTICE
AVISO
AVIS
2945
ColorsAPN 3280-L-SF
Rev A
Size 94 x 38 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
white substrate.
Revision Changes
---
This ar twork belongs to Champion Power Equipment. The content s are confiden tial and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.
Fuel Requirements
E
CHAMPION POWER EQUIPMENT, INC.
12039 SMITH AVENUE
SANTA FE SPRINGS, CA 90670
USA / É.-U.
1-877-338-0999
WWW.CHAMPIONPOWEREQUIPMENT.COM
MADE IN CHINA / FABRIQUÉ EN CHINE
3282-L-PR-A
MANUFACTURE DATE
DATE DE FABRICATION
SERIAL NO.
N° DE SÉRIE
MODEL
MODÈLE 200940
XXXX
XXXXXXXXXXXX
K--- --- --- ---
ColorsAPN 3282-L-PR-A
Rev A
Size 51 x 64 mm
Artwork Notes
3mm co rner rad ius; 2mm sa fe margin ; to be print ed
on sec urity su bstrate ; magenta t ext to be fill ed in
duri ng time of pr oducti on
Revision Changes
---
This ar twork belongs to Champion Power E quipment. The co ntents are con fidential and pr ivileged and shal l not be disclosed t o or used by or for
outside parties with out the explicit con sent of Champion Po wer Equipment.
Dataplate
A
B
C
D
E

200940 - EARTH AUGER IMPORTANT SAFETY INSTRUCTIONS
8
Safety Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
SYMBOL MEANING
Read Operator’s Manual. To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Eye and Ear Protection. Always wear safety goggles or safety glasses with side shields, and as
necessary a full face-shield as well as full ear protection when operating this product.
Footwear. Always wear safety shoes or heavy boots when operating the machine.
Gloves. Always wear nonslip, heavy-duty protective gloves when operating this product.
Safety Alert. Precautions that involve your safety.
Risk of Fire. Fuel and its vapors are extremely flammable and explosive. Fire can cause severe
burns or death. Do not add fuel while the product is operating or still hot.
Hot Surface. To reduce the risk of injury or damage, avoid contact with any hot surface
Open Flame alert. Fuel and its vapors are extremely flammable and explosive. Keep fuel away
from smoking, open flames, sparks, pilot lights, heat, and other ignition sources.

200940 - EARTH AUGER IMPORTANT SAFETY INSTRUCTIONS
9
SYMBOL MEANING
Toxic Fumes. The engine exhaust from this product contains chemicals known to the state of
California to cause cancer and birth defects and other reproductive harm.
Risk of Asphyxiation. This engine emits carbon monoxide, an odorless, colorless poison gas.
Breathing carbon monoxide can cause nausea, fainting or death. Use only in a well ventilated
area.
10 ft.
3 m Clearance. Keep all objects including others at least 10 feet (3m) from this machine.
Only one person should operate the log splitter and load the logs
Amputation Hazard. Rotating parts can entangle hands, feet, hair, clothing and/or accessories.
Traumatic amputation or severe laceration can result.
Serious Personal Injury or Property Damage. Before inspecting, cleaning, or servicing the
auger, shut off the engine. Wait for all moving parts to stop, disconnect spark plug wire and move
it away from the spark plug. Failure to follow these instructions could result in personal injury or
damage to the auger.

200940 - EARTH AUGER IMPORTANT SAFETY INSTRUCTIONS
10
Operation Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
SYMBOL MEANING
Fuel Mixture:
50:1 (Unleaded Gas : 2 Cycle Oil)
Engine Switch ON
Engine Switch OFF
Choke Control - Cold Start Run
SYMBOL MEANING
Run
Throttle: Slow
Throttle: Fast
Quick Start Label Symbols
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these
symbols will allow you to more safely operate the product.
Starting the Engine
1. Check fuel. Make sure fuel-to-oil mixture is 50:1 and add if
necessary.
2. Press the engine switch to the “ON” position.
3. Primer bulb. Press primer bulb 7-10 times, or until bulb is full
of fuel.
4. Move the choke lever to the “CHOKE” position
5. Pull the recoil starter.
6. Allow the engine to idle for 15 seconds.
7. Move the choke lever to the “RUN” position.
Stopping the Engine
1. Press the engine switch to the “OFF” position.
3282-L-OP-A
1
50 : 1
2
3
7-10X
7
5
6
15 s
1
4
K485 298 376 ---
ColorsAPN 3282-L-OP
Rev A
Size ~50.7 x 74.3 mm
Artwork Notes
3mm corner radius; 2mm safe margin; to be printed
on
white substrate.
Revision Changes
---
This artwork belongs to Champion Power Equipment. The contents are confidential and privileged and shall not be disclosed to or used by or for
outside parties without the explicit consent of Champion Power Equipment.

200940 - EARTH AUGER CONTROLS AND FEATURES
11
CONTROLS AND FEATURES
Read this operator’s manual before operating your earth auger. Familiarize yourself with the location and function of the controls and
features. Save this manual for future reference.
Earth auger
Auger
1. Throttle/Speed control
2. Engine ON/OFF switch
3. Engine
4. Soft grip handles
5. Clevis pin with double wire snap
6. 8 in. (20.3 cm) Auger bit
7. Earth blade (replaceable)
8. Fishtail bit point (replaceable)
Engine
1. Fuel primer bulb
2. Air filter
3. Choke lever
4. Spark plug
5. Muffler
6. Fuel tank
7. Fuel tank cap
8. Recoil starter handle
1
3
4
5
6
7
8
2
1
2
3
5
6
7
8
4

200940 - EARTH AUGER CONTROLS AND FEATURES
12
Parts Included
Assembly Parts
Part Part Qty. Hardware Needed Hardware Qty. Tool Needed
52cc Auger Powerhead,
handle bars and grips 1Clevis pin 1N/A
8 in. (20.3 cm) Auger bit 1N/A N/A
Fishtail point 1N/A Adjustable wrench
Accessories
Spark plug socket ..................................................1
2-Stroke oil ....................................... 2.6 fl. oz. (76 ml)
Tools Needed
–Adjustable wrench

200940 - EARTH AUGER ASSEMBLY
13
ASSEMBLY
Your earth auger requires some assembly. This unit ships from our
factory without oil. It must be properly serviced with fuel and oil
before operation.
If you have any questions regarding the assembly of your earth
auger, call our Technical Support Team at 1-877-338-0999.
Please have your serial number and model number available.
Unpacking
1. Set the shipping carton on a solid, flat surface.
2. Remove all contents from the carton.
Assemble the Fishtail Point to the Auger Bit
1. Insert the threaded end of the fishtail point into the threaded
hole on the end of the auger bit and rotate clockwise to hand
tighten.
2. To tighten securely, grasp the auger bit shaft with one hand
while placing an adjustable wrench on the fishtail bit point
and tighten until it is securely in place.
To Assemble Auger Bit to Powerhead
1. Insert the power head output shaft into the auger bit shaft
and align the hole in the output shaft with the holes in the
auger bit shaft.
2. Insert the Ø9.5 x 45 mm clevis pin completely through the
aligned holes on the powerhead output shaft and auger bit
tube so it is extended out of the other side.
3. Place the open triangle looped eClevis pinknd of the double
wire snap around the exposed end of the Ø9.5 x 45 mm clevis
pin to secure the bit to the power head output shaft.
OPERATION
Fueling and Refueling
Fuel Mixture
WARNING
Do not smoke or allow smoking near fuel or the earth auger.
Mix and pour fuel outdoors WHERE THERE ARE NO SPARKS
OR FLAMES.
NOTICE
This engine is certified to operate on unleaded gasoline
intended for automotive use. DO NOT USE E15 or E85 (fuel
containing ethanol greater than 10%) in this engine. Use of
gasoline containing more than 10% ethanol will damage the
engine and void your warranty.
–This product is powered by a 2-cycle engine and requires pre-
mixing gasoline and 2-cycle oil in a 50:1 ratio.
–Pre-mix unleaded gasoline and 2-cycle engine oil in a clean
EPA/CARB compliant fuel container approved for gasoline.
–DO NOT mix quantities larger than usable in a 30-day period.

200940 - EARTH AUGER OPERATION
14
–When mixing fuel, always use clean, fresh, regular unleaded
gasoline with a minimum octane rating of 87 and an ethanol
content of 10% or less by volume.
–Always use premium 2-cycle oil, or an equivalent high quality
synthetic 2-cycle oil.
–DO NOT use automotive oil or 2-cycle marine outboard
oil. These oil types will damage your engine and void your
warranty.
–Always follow instructions on the 2-cycle oil container for
mixing fuel.
–A mixture with a 50:1 ratio is obtained by mixing 1 gallon (3.8
liters) of gasoline with 2.6 ounces of 2 cycle oil (77 ml).
–After adding 2 cycle oil to gasoline, gently slosh/shake the fuel
container to ensure proper mixing.
–When refueling, always stop the engine and allow to cool
before refueling.
Filling the Fuel Tank
1. Place the earth auger on a flat, level surface, resting on the
handle with the throttle/speed control assembled to it so that
the fuel tank cap is pointing upward.
2. Clean the surface around the fuel cap to prevent
contamination.
3. Loosen the fuel cap slowly by turning counterclockwise.
4. Pour the fuel mixture carefully into the tank.
5. Only fill the fuel tank to 80% of the full capacity. Fuel level
can be seen via the clear fuel tank.
6. Clean and inspect the fuel cap gasket before replacing the
fuel cap.
7. Replace the fuel cap and tighten it by turning it clockwise.
8. Wipe spilled fuel from the product.
9. If you spill fuel on the unit, wait 10 minutes after wiping.
10. Move at least 10 ft away from refueling area before starting
the product.
NOTICE
It is normal for smoke to be emitted from a new engine during
first use.
Starting the Engine
WARNING
DO NOT attempt to crank or start the engine before it has
been properly filled with the required fuel to oil 50:1 mix ratio.
Damage to the earth auger as a result of failing to follow these
instructions will void your warranty.
Cold Engine
1. Place the handlebar with the throttle/speed control assembly
side flat to the ground surface.
2. Move the engine On/Off switch to the “ON” (I) position.

200940 - EARTH AUGER OPERATION
15
3. Set the choke lever to the “CHOKE” position.
4. Slowly press the primer bulb 7-10 times or until fuel is visible.
5. While standing on the operator side of the auger, place your
foot on the handlebar that is on the ground to stabilize the
unit. Grip the other handlebar with the other hand and tilt the
auger so that the auger bit is off of the ground.
6. Holding the unit firmly, pull the recoil starter grip 2 times to
prime with fuel, then pull until engine starts. Use short pulls
and do not allow the rope to snap back. Do not pull more than
6 times.
7. Once the engine starts, stand the auger up in the vertical
position and allow to run for 10-15 seconds.
8. After the engine runs for 10-15 seconds, move the choke
lever to the RUN position.
Warm Engine
1. Place the handlebar with the throttle/speed assembly side flat
to the ground surface.

200940 - EARTH AUGER OPERATION
16
2. Move the engine On/Off switch to the “ON” (I) position.
3. Ensure that the choke lever is in the “RUN” position.
4. While standing on the operator side of the auger, place your
foot on the handlebar that is on the ground to stabilize the
unit. Grip the other handlebar with the other hand and tilt the
auger so that the auger bit is off of the ground.
5. Holding the unit firmly, pull starter handle until engine starts.
Use short pulls and do not allow the rope to snap back.
6. Once the engine starts, stand the auger up in the vertical
position.
WARNING
Rapid retraction of the recoil cord could pull your hand and
arm towards the engine faster than you can let go. Broken
bones, fractures, bruises or sprains could result.
NOTICE
Manually adjusting or turning the choke lever to the CHOKE
position during idle will cause the engine to stop.
NOTICE
If the engine does not start, return to the “Start a Cold Engine”
and repeat the steps that follow.
Stopping the Engine
1. Release the throttle/speed control to stop the auger bit from
rotating.

200940 - EARTH AUGER OPERATION
17
CAUTION
The auger bit will continue to rotate for a few seconds after the
throttle/speed control is released.
2. Move the engine On/Off switch to the “OFF” (O) position.
WARNING
If the engine does not stop when the engine switch is moved to
the “STOP” position, release the throttle. Allow the engine to
idle. Put the auger down and slide the choke lever to cold start
(closed) position.
Operating the Auger
1. Holding the unit in the vertical position, place the tip of the
fishtail bit point at the desired drilling location.
2. Engage the throttle/speed control and first start digging the
hole at a slow speed to get a good engagement with the soil.
3. Gradually increase the speed as the auger bit enters the soil.
4. As the auger bit penetrates deeper into the soil, occasionally
lift the auger bit partially up out of the hole to disperse the
loose soil. This will keep the hole free of loose soil and
prevent the auger bit from becoming stuck in the hole. This
will also reduce the time it takes to dig a hole and prevent
overworking the engine.
CAUTION
If the auger bit will not turn in a hole, turn engine off and
remove auger bit from the hole. Check auger bit for damage
and remove any debris from auger bit or hole. Secure spark
plug boot away from the engine and frame to alleviate potential
arcing.
Transporting the Auger
WARNING
Before transporting the auger, shut off engine, wait for
all moving parts to stop, and disconnect spark plug wire
and move it away from spark plug. Failure to follow these
instructions could result in personal injury or property damage.
1. Disassemble the auger bit from the power head by removing
the open triangle looped end of the double wire snap from the
exposed end of the Ø 9.5 x 45 mm clevis pin and removing
the clevis pin from the auger bit and power head output shaft.
This will disengage the bit from the power head output shaft.
2. Carry the power head by the handle that does not have the
throttle/speed control with the recoil starter against your leg
so the fuel tank cap is pointed skyward while carrying the
auger bit in the other hand, held by the shaft.

200940 - EARTH AUGER OPERATION
18
MAINTENANCE
Make certain that the earth auger is kept clean and stored
properly. Only operate the unit on a flat, level surface in a clean,
dry operating environment. DO NOT expose the unit to extreme
conditions, excessive dust, dirt, moisture or corrosive vapors.
The owner/operator is responsible for all periodic maintenance.
Complete all scheduled maintenance in a timely manner.
Correct any issue before operating the earth auger.
For service or parts assistance, contact our
Technical Support Team at 1-877-338-0999.
WARNING
Never operate a damaged or defective earth auger.
WARNING
Improper maintenance will void your warranty.
WARNING
Before inspecting, cleaning, or servicing the earth auger, shut
off the engine. Wait for all moving parts to stop, disconnect
spark plug wire and move it away from the spark plug. Failure
to follow these instructions could result in personal injury or
damage to the earth auger.
NOTICE
For Emission control devices and systems, read and
understand your responsibilities for service as stated in the
Emission Control Warranty Statement of this manual.
Cleaning the Earth auger
CAUTION
DO NOT spray earth auger directly with water.
Water can contaminate the fuel system and can enter the
engine through the cooling slots and damage the engine.
1. Use a damp cloth to clean exterior surfaces of the earth
auger.
2. Use a soft bristle brush to remove dirt and oil.
3. Use an air compressor (25 PSI) to clear dirt and debris from
the earth auger.
4. Inspect all air vents and cooling slots to ensure that they are
clean and unobstructed.
Cleaning and Adjusting the Spark Plug(s)
1. Remove the spark plug cable from the spark plug.
2. Use a spark plug socket tool, or a 3/4 in. (19 mm) socket to
remove the plug.
3. Inspect the electrode on the plug. It must be clean and not
worn to produce the spark required for ignition.
4. Make certain the spark plug gap is set within limits. Refer to
the Specifications section for values.
SPARK PLUG GAP
5. Refer to the spark plug types in Specifications when replacing
the plug.
6. Carefully thread the plug into the engine.
7. Use a spark plug socket tool, or a 3/4 in. (19 mm) socket to
install the plug.
8. Attach the spark plug wire to the plug.

200940 - EARTH AUGER OPERATION
19
Cleaning the Air Filter
1. Using your fingers, turn the knob on the air filter cover
counterclockwise to loosen the air filter cover.
2. Remove the paper air filter element.
3. Clean filter by gently tapping it on a flat surface. If very dirty,
replace with a new filter.
4. Place the air filter back into the assembly.
5. Reattach the air filter cover.
Earth Blade and Fishtail Point
WARNING
Use only the manufacturer’s replacement part intended for this
auger bit. Do not use any other earth blade or fishtail point.
To install any other brand part to this auger bit can result in
serious personal injury. Replace worn or damaged earth blade
or fishtail point.
1. Remove the mounting hardware (bolts and nuts), and take off
the earth blade.
2. Install new earth blade with new mounting hardware.
3. Tighten the bolts to secure blade.
4. To replace the fishtail point, use an adjustable wrench to
break it loose.
Adjusting the Governor
WARNING
Tampering with the factory set governor will void your
warranty.
The air-fuel mixture is not adjustable. Tampering with the
factory set governor can damage your earth auger. Contact our
Technical Support Team at 1-877-338-0999 for all other service
and/or adjustment needs.
Maintenance Schedule
Follow the service intervals indicated in the following maintenance
schedule.
Service your earth auger more frequently when operating in
adverse conditions.
Contact our Technical Support Team at 1-877-338-0999 to locate
the nearest CPE certified service dealer for your earth auger or
engine maintenance needs.
BEFORE USE
Wipe up fuel leaks, fuel spillage.
Inspect and clean fuel tank.
25 HOURS
Clean cylinder fins and intake cooling vent.
Inspect and clean the air filter.
EVERY 50 HOURS OR EVERY SEASON
Clean and readjust spark plug gap
(gap: 0.6 – 0.8 mm [0.024 – 0.031 in.]), and replace if
necessary.
Inspect and clean the air filter.
ANNUALLY
Replace spark plug.

200940 - EARTH AUGER STORAGE
20
STORAGE
WARNING
Never store the auger indoors or next to appliances where
there is a source of heat, open flame, spark or pilot light as
these conditions can ignite gasoline vapors. DO NOT store the
auger near fertilizer or any corrosive material. Even with an
empty fuel tank, gasoline vapors could ignite. When storing
the auger for short or long periods of time, always be sure that
the engine switch (where applicable) and the fuel valve (where
applicable) are set in the “OFF” position.
NOTICE
You can store the unit with 50:1 TruFuel because it is
pretreated with stabilizer and has NO ethanol content.
NOTICE
The engine works well with 10% or less ethanol blended
gasoline. When using ethanol-blended gasoline there are some
issues worth noting:
Ethanol-blended gasoline can absorb more water than gasoline
alone.
These ethanol blends can eventually separate, leaving
water or a watery goo in the fuel tank, and carburetor. The
compromised gasoline can be drawn into the carburetor and
cause damage to the engine and/or create potential hazards.
If a fuel stabilizer is used, confirm that it is formulated to work
with ethanol-gasoline blends.
–Clean all foreign material from the product. Store idle unit
indoors in a dry, well-ventilated area that is inaccessible to
children. Keep away from corrosive agents such as garden
chemicals and deicing salts.
–Abide by all local regulations for the safe storage and handling
of gasoline.
When storing 1 month or shorter:
–Fuel stabilizer is an acceptable alternative in minimizing the
formation of fuel gum deposits during storage. Add stabilizer to
your fuel container (not the fuel tank on the auger). Run engine
at least 3 minutes after adding stabilizer.
When storing longer than a month:
–Drain all fuel from tank into a container approved for gasoline.
Run engine until it stops.
SPECIFICATIONS
Earth auger Specifications
Model ....................................................... 200940
Auger Bit............................................. 8 in. (20.3 cm)
Overall Dimensions
Weight ............................................. 32 lbs. (14.7 kg)
Length ..............................................25.6 in. (65 cm)
Width .............................................. 10.6 in. (27 cm)
Height..............................................47.2 in. (120 cm)
Engine Specifications
Model ..................................................... JF1E44FB
Displacement.................................................. 52 cc
Type........................................................ 2-Stroke
Spark Plug
OEM Type......................................................LD L6
Replacement Type................................BPMR6A / L6RTC
Gap ...............................0.023 - 0.031 in. (0.6 - 0.8 mm)
Oil Specifications
Type..........................................................2-Cycle
Mixture ................................ 50:1 (gasoline : 2-cycle oil)
Fuel Specifications
Use unleaded gasoline with a minimum octane rating of 87 and
an ethanol content of 10% or less by volume. DO NOT USE E15 or
E85. DO NOT OVERFILL.
Gasoline Capacity ................................... 0.3 gal. (1.1 L)
Temperature Specifications
Starting Temperature Range (°F/°C) ........... 5 to 104/-15 to 40
NOTICE
An important message about temperature: Your product
is designed and rated for continuous operation at ambient
temperatures up to 104°F (40°C). When needed, it may be
operated at temperatures ranging from 5°F (-15°C) to 122°F
(50°C) for short periods of time. If exposed to temperatures
outside this range during storage, it should be brought back
within this range before operation. In any event, the product
must always be operated outdoors, in a well-ventilated area
and away from doors, windows and vents.
