Champion LASAR L-1502C User manual

ChampionAerospaceLLC
1230Old NorrisRoad
Liberty,SouthCarolina, U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
®
LASAR®Installation, Operation,
and Troubleshooting Manual
SCOPE:
This manual provides detailed installation, operation, and troubleshooting instructions
and technical information about the LASAR®system.
L-1502C
ISSUED
MO DAY YEAR
01 18 96
REVISED
MO DAY YEAR
03 01 09
PAGE NO.
COVER
PAGE REV.
C
CHAMPION AEROSPACE PROPRIETARY INFORMATION
THIS DOCUMENT IS PROPRIETARY PROPERTY OF CHAMPIONAEROSPACE LLC. IT IS NOTTO BE COPIED OR REPRODUCED
INANY MANNER, NOR SUBMITTED TO OTHER PARTIES FOR EXAMINATION WITHOUT PRIOR WRITTENAPPROVAL.

MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96
L-1502
03 01 09 C
i

L-1502
MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96 03 01 09 Cii
Log of Revisions
Pages
Rev. No. Description Revised Date
A Modified format. All 5/20/96
B Modified Format. Added provisions All 6/27/97
for cockpit enunciator light and tachometer.
Added LVCH connector lubricant. Added
Troubleshooting with a computer. Various
text changes to improve clarity.
C Thisrevisionchanges thecompanyfrom All 3/01/09
UnisonIndustries to ChampionAerospaceLLC

MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96
L-1502
03 01 09 C
Table of Contents
0.0 NOTICES................................................................................................................. 0-1
0.1 COPYRIGHT STATEMENT...............................................................................................................0-1
0.2 SOFTWARE LICENSE AGREEMENT ..............................................................................................0-1
0.3 GENUINE SLICK PARTS ..................................................................................................................0-2
0.4 RELEVANT PUBLICATIONS.............................................................................................................0-2
0.5 WORLDWIDENETWORK ................................................................................................................. 0-3
0.6 HOWTO USETHISMANUAL ........................................................................................................... 0-3
1.0 TECHNICAL REFERENCE..................................................................................... 1-1
1.1 OVERVIEW .......................................................................................................................................1-1
1.2 SYSTEM CONFIGURATION.............................................................................................................1-1
1.3 MODES OF OPERATION .................................................................................................................1-1
1.4 FUEL OCTANE REQUIREMENTS
1.5 DEFINITIONS....................................................................................................................................1-3
1.6 SELECTING THE CORRECT LASAR®
SYSTEM CONFIGURATION.............................................................................................................1-5
2.0 INSTALLATION .......................................................................................................2-1
2.1 GENERAL .........................................................................................................................................2-1
2.2 INSTALLATION OF BASELINE LASAR ............................................................................................2-1
2.2.1 DISCONNECTAIRCRAFT BATTERY...............................................................................................2-1
2.2.2 LASAR®CONTROLLER INSTALLATION .........................................................................................2-2
2.2.3 ENGINE PREPARATION ..................................................................................................................2-3
2.2.4 INSTALL MAGNETO DRIVE GEARS................................................................................................2-4
2.2.5 ENGINE SET-UP...............................................................................................................................2-4
2.2.6 INSTALL SENSOR MAGNETO - LEFT ENGINE POSITION ............................................................2-4
2.2.7 INSTALL NON-SENSOR MAGNETO - RIGHT ENGINE POSITION ................................................2-5
2.2.8 ALIGN THE ENGINE CRANKSHAFT TO TDC .................................................................................2-5
2.2.9 ALIGN LEFT MAGNETO TO TDC ....................................................................................................2-5
2.2.10 ALIGN ENGINE CRANKSHAFT TO BTDC .......................................................................................2-6
2.2.11 SYNCHRONIZE LEFTAND RIGHT
MAGNETO CONTACT POINTS........................................................................................................2-6
2.2.12 CHECK SENSOR AND CONTACT
POINT SYNCHRONIZATION ............................................................................................................2-6
2.2.13 INSTALL IGNITION HARNESS .........................................................................................................2-7
2.2.14 CONFIRM MAGNETO SWITCH OPERATION .................................................................................2-7
2.2.15 INSTALL LOW VOLTAGE CONTROL HARNESS.............................................................................2-8
2.2.16 CONNECT MANIFOLD PRESSURE SOURCE ................................................................................2-9
2.2.17 CHECK LASAR®INSTALLATION....................................................................................................2-10
2.2.18 LABEL FUEL TANK FILLER OPENING ..........................................................................................2-10
2.2.19 RECONNECTAIRCRAFT BATTERY..............................................................................................2-11
2.2.20 GROUND TEST LASAR®SYSTEM ................................................................................................2-11
2.2.21 COMPLTE DOCUMENTATION .......................................................................................................2-11
2.3 INSTALLATION OF LASAR®SYSTEMS WITH
CYLINDER HEAD TEMPERATURE CONTROL ............................................................................. 2-11
2.3.1 IDENTIFY CYLINDER FOR LASAR®CHT PROBE INSTALLATION ..............................................2-11
2.3.2 INSTALL M5430-XX CHT PROBE ASSEMBLY...............................................................................2-12
2.3.3 INSTALL LOW VOLTAGE CONTROL HARNESS...........................................................................2-12
2.3.4 RECONFIRM COMPLETION OF ALL STEPS IN
SECTION 2.2 ..................................................................................................................................2-13
iii

L-1502
MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96 03 01 09 C
2.4 INSTALLATION OF LASAR®SYSTEM WITH
COCKPIT ENUNCIATOR LIGHT ....................................................................................................2-13
2.4.1 INSTALL ENUNCIATOR LIGHT ASSEMBLY ..................................................................................2-13
2.4.2 INSTALL LOW VOLTAGE CONTROL HARNESS...........................................................................2-13
2.4.3 RECONFIRM COMPLETION OF ALL STEPS IN
SECTION 2.2 ..................................................................................................................................2-14
2.5 INSTALLATION OF LASAR®SYSTEMS WITH
TACHOMETER DRIVE SIGNAL .....................................................................................................2-14
2.5.1 CONTACT TACHOMETER MANUFACTURER ..............................................................................2-14
2.5.2 INSTALL LOW VOLTAGE CONTROL HARNESS...........................................................................2-14
2.5.3 RECONFIRM COMPLETION OF ALL STEPS IN
SECTION 2.2 ..................................................................................................................................2-14
3.0 LASAR®OPERATION ............................................................................................. 3-1
3.1 LASAR®SYSTEM PRE-FLIGHT CHECK..........................................................................................3-1
3.2 LASAR®SYSTEM POST-FLIGHT CHECK .......................................................................................3-1
3.3 MIXTURE LEANING .........................................................................................................................3-1
3.4 IN-FLIGHT RESTART .......................................................................................................................3-2
3.5 GROUND HANDLING.......................................................................................................................3-2
4.0 DOCUMENTATION .................................................................................................4-1
5.0 LASAR®SYSTEM MAINTENANCE SCHEDULES................................................. 5-1
5.1 LASAR®SYSTEM MAINTENANCE SCHEDULES ...........................................................................5-1
5.1.1 INSPECTION INTERVALS ................................................................................................................5-1
5.1.2 100 HOUR INSPECTIONS ...............................................................................................................5-1
5.1.3 500 HOUR INSPECTIONS ...............................................................................................................5-1
5.1.4 MAGNETO PARTS REPLACEMENT SCHEDULE ...........................................................................5-1
5.2 LASAR®CONTROLLER MAINTENANCEAND INSPECTION .........................................................5-2
5.2.1 RECOMMENDED 100 HOUR INSPECTIONS..................................................................................5-2
5.2.2 RECERTIFICATION ..........................................................................................................................5-2
5.3 LOW VOLTAGE CONTROL HARNESS MAINTENANCE
AND INSPECTION............................................................................................................................5-2
5.3.1 RECOMMENDED 100 HOUR INSPECTIONS..................................................................................5-2
6.0 TROUBLESHOOTING ............................................................................................6-1
6.1 TROUBLESHOOTING GUIDE..........................................................................................................6-1
6.2 TROUBLESHOOTING THROUGH A COMPUTER INTERFACE .....................................................6-8
iv

L-1502
MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96 03 01 09 C
0. NOTICES
0.1 COPYRIGHT STATEMENT
All rights reserved. This manual is produced exclusively for use with LASAR®systems, magnetos and
ignition harnesses. It may not, in whole or in part, be copied, photocopied, reproduced, translated or
reducedtoany electronic mediumor machine readableform without priorconsent, in writingfrom
ChampionAerospace. LASAR®is a trademark of ChampionAerospace LLC.
WARNING: IMPROPER OR UNAUTHORIZED APPLICATIONS OF THE INFORMATION
CONTAINED IN THIS MANUAL MAY RESULT IN LOSSES OR DAMAGE TO THE
USER.
The accuracy and applicability of this manual has not been verified for any assembly, component or
part not manufactured by ChampionAerospace. Any use of this manual for other than its intended
purpose or for performing any installation, maintenance, replacement, adjustment, inspection, or
overhaulofany assembly,component or partnot manufacturedbyChampionAerospaceis notapproved,
endorsedor sanctioned byChampionAerospace.
No liability will be assumed by ChampionAerospace for actual, consequential or other types of damages
directly or indirectly resulting from the unauthorized use of this manual for other that its stated purposes.
When performing installation, maintenance, replacement, adjustment, inspection or overhaul of any
LASAR®assembly, component or part, it is imperative that the latest revision of the appropriate
LASAR®manualorproduct supportdocumentbe referenced. Contact ChampionAerospace tobesure
youhave the latestmanual orsupport document revisionbefore performingany work.
All reasonable attempts were made to make this manual as complete and accurate as possible. If you
have any questions, comments, corrections or require clarification of any information contained herein,
pleasewriteto ChampionAerospaceCustomer Service Departmentat 1230OldNorris Road,Liberty,SC
29657or email [email protected].
0.2 SOFTWARE LICENSE AGREEMENT
ChampionAerospace software pre-installed in LASAR®systems is licensed, not sold, under the general
terms of this License. Any individuals or groups of individuals purchasing LASAR®ignitionagree to
become bound by the terms of this agreement.
A. SoftwareDefinition: All softwaresupplied by ChampionAerospaceunder license, whethersupplied
in object or source code, soft or fixed media, separately or embedded in firmware or in another
product. Softwareiswarranted andsupportedby ChampionAerospace, which isresponsible for
meetingapplicable ChampionAerospace productspecifications.
B. Software License Grant: All software programs which are embodied in human readable source
form or a machine readable object form and which include, but are not limited to, programs
havingaseries ofinstructions,statements anddata,and relatedmaterial provided byChampion
Aerospace are the property of ChampionAerospace and/or others and are subject to the terms set
forth in this License, in which the Purchaser is provided solely with personal and nonexclusive
license to use such programs solely for their personal use and for its intended purposes in the
country in which the software was furnished and for execution on the system for which it was
provided.
0-1

MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96
L-1502
03 01 09 C
0-2
C. CopyrightAnd Title: No title to the intellectual property in the software programs or material is
transferred to the Purchaser under this License. All software and its copyrights are owned by
ChampionAerospace and/or its suppliers. The software is protected by United States Copyright
LawsandInternational TreatyProvisions. The written materials,software andfirmware may notbe
copied.
D. Restrictions: The softwarecontains trade secretsand critical engineoperating parameters and
should not be accessed, altered or changed in any matter. The software is protected by a
security system function and any attempt to access, alter or change the software in any form not
approvedbyChampionAerospacewill voidthisLicense andtheproduct warranty,causethe
system to no longer conform to airworthiness standards, and render the system unairworthy, which
can result in equipment damage, personal loss, bodily injury, or death.
0.3 GENUINE SLICK PARTS
The procedures outlined in this manual are generalized for all models of LASAR®systems, using only
genuineChampionAerospace manufacturedparts. Thismanual must notbe used tomaintainor over-
haul a LASAR®system that contains parts not manufactured by ChampionAerospace.
Genuine Slick parts are produced and inspected under rigorous procedures to insure airworthiness and
suitability in LASAR®systems. Parts purchased from sources other thanChampion Aerospace, even
thoughoutwardlyidentical inappearancemay nothavehad the requiredtests and inspectionsper-
formed,maybe differentinfabrication techniques andmaterials, and maybe dangerous wheninstalled in
aLASAR®system. Salvaged parts,reworked partsobtained fromnon-ChampionAerospaceapproved
sources, or parts the service history of which is unknown or cannot be authenticated, may have been
subjectedtounacceptable stressesortemperatures, orhaveother hiddendamage,not discernible
throughroutinevisual or usualnondestructive testing techniques. Thismay render servicework with this
part,even through originallymanufactured byChampionAerospace,unsuitableor unsafefor use ina
LASAR®system. ChampionAerospace expressly disclaims any responsibility for malfunctions, failures,
damageor injury causedby useof non-ChampionAerospaceapproved parts.
LASAR®systems are engineered so that mechanical parts wear at a balanced rate. Consistent and
complimentary wear patterns establish the recommended maintenance intervals defined in LASAR®
service literature, therefore used, service worn parts should never be used to troubleshoot or repair a
system component, nor should original parts be replaced by used service worn parts on magnetos
beingreturned to service. Further,non-ChampionAerospacemanufactured partsmay wearatuneven
anddifferentrates than originalChampionAerospacemanufactured parts,making LASAR®service
literature an inappropriate guide to proper maintenance. Parts not manufactured by Slick, may not fit or
operatelike original ChampionAerospacemanufactured parts. Non-ChampionAerospaceproducts are
not tested to the same standards as originally installed parts and are not authorized for replacement.
For thesereasons, usedservice worn partsor partsnot manufacturedby ChampionAerospace may
adversely affectmagneto reliabilityin waysnot anticipated byChampionAerospace and notreflected in
serviceliterature.
0.4 RELEVANT PUBLICATIONS
L-1500 LASAR®System Master Service Manual which includes:
L-1501T-300 SynchroLASAR®Manual
L-1503 LASAR®System Maintenance and Overhaul Manual
L-1504 LASAR®Application Guide
LASAR®STC and Service Letters appropriate to each installation
F-1100 Slick Master Manual which includes:
L-1177 Ignition Lead Maintenance and Overhaul Manual
L-1178 Ignition LeadAssembly and Installation Manual
L-1318Application Data

L-1502
MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96 03 01 09 C
0-3/(0-4 Blank)
0.5 WORLDWIDENETWORK
ChampionAerospacesystemsare availablethrough an internationalnetwork ofaircraft distributors that
offeroutstandingproduct support,delivery and service. SeeDistributor List FormL-1051for details.
0.6 HOWTO USETHIS MANUAL
Thismanualprovides installation,operation,and troubleshootinginstructionsfor theLASAR®system.
LASAR®publication number L-1503 LASAR®Maintenance Manual should be referenced for details
relating to the maintenance of LASAR®systems.
The information in this manual is divided into six sections. Section One provides an overview on
system components and a basic technical reference on the design and operation of LASAR®systems.
Section Two contains installation instructions for all components of the LASAR®system. Section Three
provides instructions for the operation of the LASAR®system. Section Four lists the documentation
required after installation of the LASAR®system. Maintenance requirements and troubleshooting steps
are contained in Sections Five and Six.
It is recommended that this entire manual be thoroughly read before beginning any installation,
maintenance, or troubleshooting procedure.

L-1502
MO DAY YEAR
Champion Aerospace LLC
1230Old NorrisRoad
Liberty,SouthCarolina,U.S.A. 29657
©2009 ChampionAerospaceLLC
www.championaerospace.com
CHAMPION AEROSPACE LLC PROPRIETARYINFORMATION - Subject to the restrictions on the Title page
ISSUED PAGE REV.PAGE NO. REVISED
MO DAY YEAR
01 18 96 03 01 09 C
1-1
1.0 TECHNICAL REFERENCE
1.1 OVERVIEW
LASAR®is the integration of microelectronics with conventional magneto designs to provide
controllable ignition timing capable of optimizing engine performance while providing redundant me-
chanical backup ignition for safety. LASAR®senses engine RPM, manifold pressure, cylinder head
temperature (CHT) and other engine operating parameters, then selects the optimum ignition timing
from a three dimensional nonlinear Engine Personality Map (EPM) which is programmed into the
system’s microprocessor. The controller then signals the dual-mode magnetos when to initiate a spark
event, and controls the size and shape of the spark at the spark plug to optimally ignite the fuel in the
cylinder. At sea level takeoff power, ignition timing is set to the same fixed ignition timing as
conventional magnetos. At reduced power settings or higher altitudes, ignition timing continuously
varies between TDC and 50 degrees BTDC to optimize efficiency of the fuel combustion.
Automatic timing advance from the LASAR®system may cause cylinder head temperatures (CHTs) to
increase as fuel is burned more efficiently within the combustion chamber. Incremental CHT rise due
to ignition timing advance from a non-CHT controlled LASAR®system is typically 20°F. To
accommodate LASAR®system installations on airframes with marginal engine cooling or on airframes
where engine cooling characteristics have not been determined, LASAR®systems are offered with CHT
control circuitry that incrementally reduces the timing advance angle as CHTs approach a preset
maximum limit, thereby reducing CHT rise due to advanced ignition timing. If ignition timing advance is
reduced by the CHT control feature, engine performance improvements resulting from optimized
ignition timing will be reduced. In extreme situations where the engine continually operates at
maximum cylinder head temperatures, LASAR®will command the same ignition timing as provided by
conventional magnetos, resulting in comparable engine performance.
Two different limits (climb and cruise) are used to control CHT rise due to ignition timing advance.
These limits vary between installations and are preprogrammed into the LASAR®controller software.
During engine operation, the LASAR®system initially selects the climb limit whenever power is first
applied to the controller. The climb limit remains selected until a 15 minute timer expires. The 15
minute timer begins to count when CHT exceeds the cruise limit for the first time. Once the 15 minute
timer expires, the cruise CHT limit remains selected, including subsequent climbs.
Some airframe installations include an enunciator light mounted in the cockpit which becomes
illuminated when the LASAR®system is operating in the backup mode, or when the controller is
receiving power when the engine is not running. In automatic mode operation, a normally closed relay
within the controller is energized which isolates the enunciator light from ground and prevents
illumination of the light. In backup mode operation, the relay is not energized, allowing a ground path
for the light which then becomes illuminated.
With installation of LASAR®systems, existing engine speed signals from “P” leads and/or magneto
rotor sensors are not available. Electrical tachometers may be modified to correctly interpret the
LASAR®system’s four pole rotor magnets, or the speed signal provided the LASAR®controller.
1.2 SYSTEM CONFIGURATION
The controller is the heart of the LASAR®system. As a microprocessor based solid state device, the
