Changhong Electric UD49YC5500UA User manual

TV
Operation Manual
Service E-mail: [email protected]
CHANGHONG TRADING CORP., USA
17800 Castleton St. Suite 306, City of Industry, CA 91748
TEL: [phone]
FAX: [phone]
Model: UD49YC5500UA
49
Web site: www.changhongUSA.com

REGULATORY INFORMATION
This equipment generates,uses,and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communication. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
CAUTION
DO not attempt to modify this product in any way without written authorization from
supplier. Unauthorized modification could void the user's authority to operate this
product.
It is not recommended to keep a certain still image displayed on the screen for a long
time as well as displaying extremely bright images on screen.
Figures and illustrations in this User Manual are provided for reference only and
may differ from actual product appearance. Product design and specifications
may be changed without notice.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER
(OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated "dangerous
voltage" within the products enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning
1

WARNING
To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To
Rain Or Moisture.
The ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, table-cloths, curtains, etc.
The Apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.
Attention should be drawn to the environmental aspects of battery disposal. Don’t
throw used batteries in dustbin. Please contact your retailer in order to protect the
environment.
When you install your TV, maintain a distance of at least 4 inches between the TV
and other objects (walls, cabinet sides, etc.) to ensure proper ventilation. Failing to
maintain proper ventilation may result in a fire or a problem with the product caused
by an increase in its internal temperature.
No naked flame sources, such as lighted candles, should be placed on the
apparatus.
To prevent the spread of fire, keep candles or other open flames away from this
product at all times.
The device may malfunction when under electrostatic discharge. It can be manually
resumed by recycling the power off and on again.
CAUTION connecting the Power Cord
Most appliances recommend they be placed on a dedicated circuit; that is, a single
outlet circuit which powers only that appliance and has no additional outlets or
branch circuits.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or cracked wire insulation are
dangerous. Any of these conditions could result in electric shock or fire. Periodically
examine the cord of your appliance, and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the appliance, and have the cord replaced
with an exact replacement part by an authorized servicer. Protect the power cord
from physical or mechanical abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the
point where the cord exits the appliance.
The MAINS plug is used as the disconnect device, and the disconnect device shall
remain readily operable.
Operating Temperature: 5°C to 35°C Operating Humidity: ≤80%
Storage Temperature: -15°C to 45°C Storage Humidity: ≤90%
Warning
2
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo
are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.

Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/ TV technician for help.
ENERGY STAR is a joint program of the U.S. Environmental Protection Agency and
the U.S. Department of Energy helping us all save money and protect the
environment through energy efficient products and practices.
Home mode is the default as-shipped television configuration and settings. Home
mode is the setting in which the product qualifies for ENERGYSTAR. Any changes to
default as-shipped television configuration and settings would change the energy
consumption. Enabling certain optional features and functionalities may increase
energy consumption beyond the limits required for ENERGY STAR qualification.
is a trademark of SRS Labs, Inc. TruSurround HD technology is
incorporated under license from SRS Labs, Inc.
SRS TruSurround HD™ creates an immersive, feature-rich surround sound
experience from two speakers, complete with rich bass, high frequency detail and
clear dialog.
Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference and
(2) this device must accept any interference received, including interference that may
cause undesired operation of the device.
3

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
7. Do not block any of the ventilation
openings. Install in accordance with the
manufacturer's instructions.
5. Do not use this apparatus near water.
8. Do not install near any heat source such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers)
that produce heat.
6. Clean only with a dry cloth.
9. Do not defeat the safety purpose of the
polarized or grounding type plug. A
polarized plug has two blades with one
wider than other. A grounding type plug
has two blades and a third grounding
prong. The wide blade or the third
prong is provided for your safety. When
the provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
Safety instructions
4

10. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.
13. Unplug this apparatus during
lightning storms or when unused for
long periods of time.
11. Only use the attachments/
accessories specified by the
manufacturer.
12. Use only with a cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
14. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in
any way, such as power supply cord
or plug is damaged, liquid has been
spilled or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been
dropped.
ON DISPOSAL
-The fluorescent lamp used in this product contain a small amount of mercury.
-Do not dispose of this product with general household waste.
-Disposal of this product must be carried out in accordance to the regulations of your
local authority.
NOTE
-If the TV feel cold to the touch, there may be a small "flicker" when it is turned on.
This is normal, there is nothing wrong with TV.
-Some minute dot defects may be visible on the screen, appearing as tiny red,
green, or blue spots. However there have no adverse effect on the monitor's
performance.
-Avoid touching the screen or holding your finger(s) against it for long periods of time.
Doingso may produce some temporary distortion effect on the screen.
Safety instructions
5

UsingtheRemoteControl
When using the remote control, aim it at remote sensor on the television. If there is an
operate.
•Point the remote control at the REMOTE SENSOR located on the television.
•When using this television in a very brightly lit area, the infrared REMOTE CONTROL
SENSOR may not work properly.
•The recommended effective distance for using the remote control is about 7 metres.
Installing Batteries in the Remote Control
1. Open the cover at the back of the remote control.
2. Install two AAA size batteries. Make sure to match
the “+” and “-” ends of the batteries with the
diagram inside the compartment.
3. Replace the cover.
Battery Replacement
You will need to install the batteries into the remote control to make it operate following
the instruction below.
When the batteries become weak, the operating distance of the remote control will be
greatly reduced and you will need to replace the batteries.
Notes on Using Batteries:
The use of the wrong type of batteries may cause chemical leakage and/or explosion.
Please note the following:
•Always ensure that the batteries are inserted with the + and - terminals in the correct
direction as shown in the battery compartment.
•Different types of batteries have different characteristics. Do not mix different types.
•Do not mix old and new batteries. Mixing old and new batteries will shorten battery life
and/or cause chemical leakage.
• Replace batteries as soon as they do not work.
•Chemicals which leak from batteries may cause skin irritation. If any chemical matter
seeps out of the batteries, wipe it up immediately with a dry cloth.
• The batteries may have a shorter life expectancy due to storage conditions. Remove the
batteries whenever you anticipate that the remote control will not be used for an
extended period.
•The batteries (battery pack or batteries installed) shall not be exposed to excessive heat
such as sunshine, fire or the like.
CAUTION:
•It may result in an explosion if batteries are replaced incorrectly.
•Only replace batteries with the same or equivalent type.
Getting Started
object between the remote control and the remote sensor on the unit, the unit may not
6

CableInstallation
Before the installation and use, please read carefully the relevant content in “Warning and
Safety instructions”.
NOTE:
• When you plug or unplug the TV, computer or other equipments, you must make sure
that the AC power has been already shut down;
• When unplugging the power cable or signal cable, please hold the plug (the insulated
part), do not draw the body of the cable.
2. The RF output terminal can be connected with the RF input port of the TV.
3. The output AV terminal of a DVD can be connected with the AV input port of the TV
through an AV cable.
NOTE:
• Component and AV can not be used at same time for they share of one audio channel.
Component Y signal and AV video signal share one channel.
• Both Audio signals of AV and COMPONENT are input from "R - Audio - L".
4. The output COMPONENT (YPbPr) terminal of a DVD can be connected with the
COMPONENT (YPbPr) input port of the TV through an AV cable.
5. Connect one end of the VGA cable with the VGA port on the computer, connect the
other end of the VGA cable with the VGA port on the TV, and tighten the bolts
clockwise on each end of VGA cable.
NOTE:
• While connecting the 15-pin VGA, please do not insert the plug with enormous force,
otherwise the connector or a pin might be broken.
6. Connect one end of the HDMI cable with HDMI output port, connect the other end of
the HDMI cable with the HDMI port on the TV.
NOTE:
• While connecting the HDMI, please aim it carefully, and do not insert with enormous
force, otherwise the connector or a pin might be broken.
• HDMI1 and MHL share one port.
7. Sending the TV's digital audio signal to external audio equipment via the Digital Audio
Output port.
8. Check and make sure that all AV cables are connected with the corresponding ports
correctly.
9. Connect the AC power cable with 100-240V AC power supply.
NOTE：
• The range of input power for the TV is 100-240V~, 50/60Hz. Do not connect the TV
power input port with the AC power out of the above range.
• Please hold the insulated part of the plug when you are unplugging the power cable. Do
not touch directly the metallic part of the cable.
Connection and Setup
1. Take out the TV from the wrapping package and put it in a drafty and flat place.
7

InstallationGuide
When the TV is initially powered on, a sequence of on-screen prompts will assist in
configuring basic settings. Press the ENTER button to start the guide. Press the button
■Language: Press the ▲/▼button to select the desired language using the OSD(On
Screen Display).
■Time Zone: Press the ▲/▼button to select your time zone.
■Time Format: Press the ▲/▼button to select 12-hour or 24-hour.
■Antenna: Press the ▲/▼button to select the signal type for channels.
■Auto Tuning: Scans and saves available programs automatically.
NOTE:
• If the TV doesn't receive any channels, please check your aerial connection or the
country you selected, then try an auto tuning again.
• If the TV just receives some of the channels, it means the aerial's reception isn't good
enough and an antenna service is recommended.
HotelMenu
■Hotel Enable: Set the Hotel Enable On/Off by pressing the ◄/►buttons.
• When Hotel Mode is On, the Channel function is locked.
■On Source: Set the default signal source by pressing the ◄/►buttons. (The default
signal source will be displayed when the TV is turned on.)
■On Channel: Set the default channel by pressing the ◄/►buttons. (The default
channel will be displayed when the TV is turned on.)
■On Volume: Set the default volume by pressing the ◄/►buttons. (The default volume
is the volume when the TV is turned on. Remember the default volume should be less
than the maximum volume).
■Volume Max.: Set max volume by pressing the ◄/►buttons. When the max volume is
lower than the default volume, the max volume is the priority.
■Logo Select: When the "Hotel Enable" and "Logo Select" are both ON, the Logo is
displayed when power on.
■BACKUP: "BACKUP" means to write the TV data to USB device. The function is
supposed to be used when all the settings have been completed and the "Hotel
Enable" is ON.
■RESTORE: "RESTORE" means to read data from USB device and write to local flash,
then the machine needs a restart to initiate the parameters.
Connection and Setup
►
◄
to go to the next step. Press the button to return to the previous menu.
Press the button to display the Source Menu, then press “2012” to enter into
the Hotel Mode to adjust the relative settings.(only in TV mode)
8
INPUT

Remote Control
SOUND
1 23
4 5 6
7 8 9
0
CH LI ST
INFO
OK
EXIT RECALL
ASPECT FAV CH
CC SLEEP MTS
AUDIO
TVAVHDMIUSB
OK
EXIT RECALL
OK
EXIT RECALL
1 23
4 5 6
INFO
1.This product is RF remote control whose code must be connected to the TV code
successful, the n RF remote control could be used.
2.Codes Connection Method:Close to TV(codes area), press "MENU" and
"INPUT" buttons at the same time.
3.If indicator light shining, it means that codes connection successfully then
buttons could be released.
re-condes connections are needed.
4.If indicator light winking or not shining ,it means codes connection failed and
9
SOUND
1 23
4 5 6
7 8 9
0
CH LIST
INFO
OK
EXIT RECALL
ASPECT FAV CH
CC SLEEP MTS
AUDIO
TV
AV
HDMI
USB
codes area
INPUT
INPUT
INPUT
INPUT

The buttons of the original remote control are as following:
Definition of the buttons on the remote control:
1. : Enter or quit the standby mode.
:Mute or restore sound.
INFO: Press to display the current program
information on the screen.
again to exit it.
:Choose the aspect ratio.
:Selects the MHL mode directly; Moves back to
the main screen(In MHL mode).
menus or to quit some operations.
:Return to the previous menu screen.
(In MHL mode)
:Return to last viewed progra.
password importation.
select channel.
NOTE:
•All pictures in this
manual are examples,
for reference only.
Actual product may
differ from the pictures.
•The buttons not
mentioned here are not
used.
Remote Control
:It takes in effect in some inter faces (In MHL mode).
SOUND
1 23
4 5 6
7 8 9
0
CH LIST
INFO
OK
EXIT RECALL
ASPECT FAV CH
CC SLEEP MTS
AUDIO
TVAVHDMIUSB
23
24444
25
3.
2.
5. -: In DTV mode, press number buttons and - key to
6. CH LIST: Press to call up the channel list. Press
7. VOL+/VOL-: Increase/Decrease audio volume.
8. CH+/CH-: Scroll to next/previous channel.
9. SOUND: Changes the sound mode.
10. PICTURE: Changes the image mode.
11. MENU: Press to display/exit the on screen
12. INPUT
13. OK/ENTER: Select or confirm menu item.
14. ▲/▼/◄/►: Select direction.
15. EXIT: Quit the current interface.
16.
17.
19.
4. NUMBER BUTTONS: Choose channels or
:Press to display the Favorites program in TV
mode.(You should setup your favorite channels in
Program Edit menu)
18.
TV/AV/HDMI/USB: Quick enter signal source.20.
STILL: Freeze or activate the current picture.
: Stop (in USB mode)
21.
:Play/Pause (in USB mode)
CC: Press to select the closed caption.
22.
23. SLEEP: Set the sleep timer.
MTS: The button can be used to switch between
Stereo/SAP/Mono in TV mode.
AUDIO: Switch Audio language in DTV mode.
24.
COLOR BUTTONS: Red/green/yellow/blue key
navigation link.
:Fast reverse (in USB mode)
:Fast forward (in USB mode)
: Previous (in USB mode)
: Next (in USB mode)
25.
:Select signal source.
10
INPUT

TurningonandofftheTV
■Turn on the TV
Connect the power cable, and press the button to turn on the TV.
■Turn off the TV
Press the button on the remote control to enter standby mode.
Do not leave your set in standby mode for long periods of time. It is best to unplug the
set from the mains and aerial.
When there is an accident power off, it is recommended to unplug the power cable
from the power socket.
■No signal
There is No Signal menu on screen when there is no input signal. In TV mode, if there
is no signal in 5 minutes, the TV will turn off automatically. In PC mode, the TV set will
automatically turn off in 60 seconds if there is no input signal. When the VGA cable is
connected, the TV turns on automatically.
ProgramSelection
■Using the CH+/CH- on the panel of TV or on the remote control.
Press CH+ to increase channel number.
Press CH - to decrease channel number.
■Using 0- 9 Digital Buttons.
You can select the channel number by pressing 0 to 9 (in ATV mode).
In DTV mode, press number buttons and then – button to select channel.
■Example
To select - channel (e.g. Channel 1): Press 1.
To select -- channel (e.g. Channel 20): Press 2 and 0 in a short time.
To select --.- channel (e.g. Channel 20.1): Press 2, 0, – and 1 in a short time.
VolumeAdjustment
■Press the VOL+/- button to adjust the volume.
■If you want to switch the sound OFF, press the button.
■You can release mute by pressing the button, or increase the volume.
ChangingtheInputSource
1. You can select the input source by pressing the button on the remote control.
2. Press the▲/▼button to cycle through the available input sources, and press the
button to confirm your choice.
Basic Operation
ENTER
11
INPUT

HowtoNavigateMenus
Before using the TV, follow the steps below to learn how to navigate the menu in order to
select and adjust different functions. The access step may differ depending on the
selected menu.
1. Press the MENU button to display the main menu.
2. Press the◄/►button to cycle through the main menu. Press the ENTER button to
access the submenu.
3. Press the▲/▼button to select the desired sub item, then press the ENTER button.
4. Press the ▲/▼/◄/►button to select the desired value. To save the setting, press
ENTER. The adjustment in the OSD may differ depending on the selected menu.
5. Press the MENU button to return to the previous menu.
6. Press the EXIT button exit from the menu.
NOTE:
When an item in MENU is displayed gray, it means that the item is not available or
cannot be adjusted.
Some items in the menus may be hidden depending on modes or signal sources used.
Buttons on the TV have the same function as corresponding buttons on the remote
control. If your remote control is lost or doesn’t work, you may use the buttons on the
TV to select menus. This manual focuses on operation of the remote control.
ConfiguringtheChannelMenu
Before your TV can begin memorizing the available channels, you must specify the type of
signal source that is connected to the TV (i.e. an Air or a Cable system).
You can select the antenna source in the Input Source menu.
■Antenna: Select the signal type for channels.
■Auto Tuning: Press the ENTER button to start Auto
Tuning which automatically scans and stores all available
programs.
■Program Edit
1. Press the ▲/▼button to select a channel.
2. Press the CH+/CH- button to select the following or
preceding page.
3. Skip: Press the red button to skip the channel.
Favorite: Press the green button to set the favorite
channel.
Menu Operation
12

Menu Operation
ConfiguringthePictureMenu
■Picture Mode: You can select the type of picture which
best corresponds to your viewing requirements.
Mode: Changes the image mode.
Contrast: Adjusts the signal level between black and
white in the picture. You may use Contrast when the
bright part of the picture is saturated.
Brightness: Adjusts the base level of the signal in the
picture.
Sharpness: Adjusts the level of crispness in the edges
between the light and dark areas of the picture.
Tint: Adjusts the balance between red and green levels.
(Only in the NTSC mode)
Saturation: Adjusts intensity of all colours.
The adjusted values are stored according to the User
mode.
■Color Temp: Select the color temperature of the picture.
■Aspect Ratio: Select your desired aspect ratio. In some special signal conditions, the
image can only display in the full mode.
■DNR: Reduces screen noise without compromising video quality.
■Energy mode: Switch the Energy mode on or off.
■Energy Demo: Switch the Energy demo on or off.
While both Energy Mode and Energy demo are set to "On",
■Backlight: To control the brightness of the screen, adjust the brightness of panel.
Backlight can be adjusted when the Energy mode is set to "Off".
ConfiguringtheSoundMenu
■Sound Mode: You can select a sound mode to suit your
personal preferences.
Mode: Changes the Sound mode. Sound Mode can’t be
adjusted when the SRS is set to On.
120Hz/500Hz/1.5KHz/5KHz/10KHz: Adjust the curve of
5 bands equalizer.
the "Consumption" dial will appear on the TV screen.
■EMR:
■EMR Demo: Switch the EMR Demo LRUD or Off.
Set the EMR Low,Middle,High and Off. Removes blurring and shudders
from scenes with rapid movement.
■Advanced (In PC mode)
H-Pos: Centre the image by moving it left or right.
V-Pos: Centre the image by moving it up or down.
Clock: Adjust the DB15 picture signal sampling clock rate.
Phase: Adjust when characters have low contrast or when the image flickers.
Auto: Adjust the image automatically.
Based on your favorites about which frequency band
need to be adjusted, make small adjustment with certain
13

Menu Operation
■Balance: You can adjust the sound balance of the
■AVC: AVC automatically remains on the same level of
Because each broadcasting station has its
own signal conditions, volume adjustment
may be needed each time the channel is changed.
by making automatic adjustments for each program.
■SRS: You can select a desired Surround Sound mode.
■SPDIF Type: Press ENTER button to select PCM or RAW.
■Audio Delay: Correct audio-video sync problems, when
■Speaker: If you are listening to the sound track of a broadcast or movie through an
external receiver, you may hear a sound echo caused by the difference in decoding
speed between the TV’s speakers and the speakers attached to your audio receiver. If
this occurs, set the TV to External Speaker.
TV When you set Speaker to TV, both the TV’s speakers and the
external speakers are on. You will hear sound through both. The
volume of the external device can’t be adjusted.
External When you set Speaker to External, the TV’s speakers are turned
off. You will hear sound through the external speakers only.
Adjusts the volume with the knob attached to the external
device.
ConfiguringtheLockMenu
Press your password (it is factory preset to 0 0 0 0), Then
you will go the sub-menu as follows.
If you forget, the super password of 1225 is still valid.
■Change Password: You can set your private password.
Press the number buttons on the remote control to set
the new password. When the new password has been
input twice, the setting is finished and saved
successfully.
■System Lock: Set the system lock ON or OFF.
■US: To select the TV/MPAA Rating you want to lock or not.
frequency band at a time. It is suggested to NOT make
large changes.
The adjusted values are stored according to the User
mode.
speakers to preferred levels.
volume if you change programs.
This feature allows users to enjoy stable volume levels
watching DTV and when listening
to digital audio output using
an external device such as an audio receiver (0ms~250ms).
14

Menu Operation
Content Define
FV Fantasy violence
D Suggestive dialogue
L Strong language
S Sexual situations
V Violence
MPAA
Rating Define
G General audience. All ages admitted.
PG Parental guidance suggested. Some material may not be suitable for
children.
PG-13 Parents strongly cautioned. Some material may be inappropriate for
children under 13.
R Restricted. Children under 17 require accompanying parent or adult
guardian.
NC-17 No one 17 and under admitted.
X Adult audience only.
N/A MPAA rating of “N/A”
■Canada: To select the Canada English/Canada French Rating you want to lock or not.
Canada English: These ratings are for programs which are using the English rating
system.
Rating Defined as
C Children
C8+ Children 8 years and older
G General programming
TV-PG Retricted
TV-14 No one 17 and under admitted
TV-MA Adult audience only
TV-None None
TV
Age Define
TV-Y General audience
TV-Y7 Parental guidance suggested
TV-G Parents strongly cautioned
15

Menu Operation
Rating Defined as
G General
8 ans+ Not recommended for younger children
13 ans+ Not recommended for children under age 13
16 ans+ Not recommended for ages under 16
18 ans+ This program is restricted to adults
EXEMPT Unblock
■RRT Setting: Press ENTER button to set RRT rating.
If you try to tune the TV to a program that exceeds the rating limits you set, the TV will
enter program lock mode and a warning message will appear on-screen. Follow the
instructions to temporarily unlock the program.
■Reset RRT: Press ENTER button to reset RRT information.
NOTE:
• RRT setting and Reset RRT can be selected when the TV signal have RRT rating
information.
ConfiguringtheOptionMenu
■Language: Select your preferred On Screen Display
language.
■Audio Language: Select your preferred audio language.
(Available for digital channels if multiple audio languages
are broadcasted.)
■Transparency: Menu transparency selection, you can
select menu transparency according to the different
background picture.
■Closed Caption: You can select Closed Caption, if
available, to be displayed on the screen.
CC Mode: Select CC Mode: CC Off, CC on Mute, CC
On.
Basic CC: Select from below closed-caption modes for
analog programs.
CC1,2,3,4 Displays corresponding caption channel of
analog program. (Usually set to CC1 for most programs.)
of a analog program.
Text1,2,3,4 Displays corresponding text service channel
Canada French: The ratings are for programs which are using French rating system.
PG Parental guidance
14+ Viewers 14 and older
18+ Adult programming
EXEMPT Unblock
16

Menu Operation
Mode: Default/Custom. If set to Custom, Digital CC is available.
Font Style: Default/Font 0~7
Font Size: Default/ Normal/ Large/ Small
Font Edge Style: Default/ None/ Raised/ Depressed/ Uniform/ Left Shadow/ Right
Shadow
Font Edge Color: Default/ Black/ White/ Red/ Green/ Blue/ Yellow/ Magenta/ Cyan
FG Color: Default/ White/ Red/ Green/ Blue/ Yellow/ Magenta/ Cyan
BG Color: Default/ Black/ Red/ Green/ Blue/ Yellow/ Magenta/ Cyan
FG Opacity: Default/ Solid/ Flashing/ Translucent/ Transparency
BG Opacity: Default/ Solid/ Flashing/ Translucent/ Transparency
■Reset: Restore the system settings to the factory default. When the restore is complete,
the Installation Guide is displayed on the screen.
■Installation Guide: This is a guide to help you to setup the TV.
■E-POP: Switch the E-POP on or off. E-POP mode is the optimal setting for store
environments.
■Health Remind: Switch the Health Remind on or off. While Health Remind is set to On,
a prompt picture will remind you to have a break at intervals of two hours.
ConfiguringtheTimeMenu
■Clock: YoucandisplayeithertheDTVSignalStream
Auto Sync: If set it to ON, the TV will sync the local clock
according to the DTV broadcasting time automatically.
Otherwise you can set the time manually.
DST: Selects the DST (Daylight Saving Time) mode.
■Sleep: Select the time to turn the TV to standby mode
automatically.
■Auto Sleep: Select the Auto Sleep time you want. The TV
will enter into standby mode automatically when there is
no operation in set time.
■Time Zone: Select your time zone.
■Time Format: You can choose to use 12-hour format or
24-hour format.
Time or set the System Time.
Digital CC: Applies only to digital channels with closed caption.
Service1,2,3,4,5,6 These are different service data channels.
Option: You can customize the closed caption display characteristics.
17

UsingUSBmode
■To Access/Quit USB mode
Connect an USB device. Press button to display the main menu. Use the
▲/▼to highlight USB, and the ENTER button to access the USB mode. You may
also use the signal source selection menu to exit from the USB mode.
NOTE: • A special USB device may not be supported, and may either not operate, not
be recognized, or operate erratically.
• USB max. load: DC5V@500mA.
■The formats supported
Movie and Music Show: MPEG2, MPEG2_HD, DD, MJPEG.
Photo Show: JPEG.
File Format Support: TXT.
NOTE:
• Special algorithm documents may not be supported by the USB.
• The USB supports the formats mentioned above. If the file format is not supported,
change it to the recognized format.
• Playback may be abnormal when playing files that are too large.
■ Main Operating Interface
Photo/ Music/ Movie/ Text
1. Press ◄/►button to select PHOTO/ MUSIC/ MOVIE/ TEXT in the main menu, then
press ENTER button to enter.
2. Use the arrow buttons and ENTER button to enter the desired disk.
3. Press arrow buttons and ENTER to open the folder.
4. Press CH+/CH- button to page up or page down the files. Use the arrow buttons to
highlight the file. Use the ENTER button to mark or unmark a file. Press button to
play the selected files. If no file is marked, all the files in the folder will be played in
sequence after you press button.
5. Press the INFO button to display the menu screen in playing.
6. Press the button to stop the playing files.
7. Press the EXIT button to return to the previous menu screen.
NOTE:
• The TV/AV/HDMI/USB buttons can't be used when the Media files are playing.
Menu Operation
18
INPUT
