Char-Broil 03505770 User manual

Fire Bowl 03505770 / 42803943 (01-13-04)
Tools needed
for assembly:
Straight or
Phillips screwdriver
Adjustable wrench
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out of bowl in breezy conditions. Adequate fire
extinguishing material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
CAUTIONCAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
WARNING
Do not use this unit on a wood deck or on combustible
surfaces such as dry grass, leaves, mulch, etc. Do not
use this unit near heat sensitive or combustible structures
such as vinyl or wood siding.
Caldera Fire Bowl
Model • 03505770
Assembly Instructions
FOR OUTDOOR USE ONLY

STOP!
Missing a part?
No need to go back to the store!
The store where you made your purchase
does not stock parts for this item. If you
need parts, whether they are missing or
damaged, call the Customer Service toll
free Help Line.
Call us and we will gladly ship
the part you need
FREE OF CHARGE.
Call Our Help Line
Parts List - Model 03505770
Item Description
55700419 Bottom Ring Kit
55700420 Top Ring Kit
55700400 Leg Kit
55700421 Fire Bowl Kit
55700422 Ash Catcher Kit
40010813 Outer Carton
42000005 Hardware Bag
42803943 Assembly Instructions
1-800-232-3398

2
1Make sure legs are on the inside of ring, attach legs to lower ring
as shown using 4X from the outside and 4X on the inside. Tighten
nuts after all four legs are attached.
Repeat this step for areas 2, 3 and 4.
Making sure the legs are on the inside of ring, attach legs to
upper ring as shown using (4) 1/4 - 20 x 1/2” Carriage Bolts from
the outside and (4) 1/4 - 20 Keps Lock Nuts on the inside.
Tighten nuts after all four legs are attached.
Repeat this step for areas 2, 3 and 4.
1
23
4
2
3
4
1
B
C

3
Lower bowl onto assembled base
Completed view of Caldera Fire Bowl After
Assembly
Assembly of Ash Catcher
Using (3) 10-24 Combo Truss Head Machine Screws from inside
the bowl and (3)10-24 Keps Lock Nuts, attach ash catcher to the
bottom side of bowl. Tighten all nuts when ash catcher bracket is
attached to bowl.
Limited Warranty
The manufacturer warrants the Fire Bowl for replacement or repair of parts and/or workmanship for a period of ninety (90) days.
Paint is not warranted and will require touch-up.
These limited warranties are made exclusively to the original customer presenting proof of purchase. These warranties are limited to
non-commercial residential use only. Any returned goods must be shipped prepaid. These warranties do not cover normal wear and
tear or damages resulting from abuse or misuse. This warranty excludes incidental or consequential cost due to damages or losses
or property of any nature.
NOTICE: Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an
implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights and
you may also have other legal rights which may vary from state to state.
For warranty service, CALL TOLL FREE: 1-800-232-3398.
HARDWARE
Hardware is shown actual size. You may have spare hardware after assembly is complete.
#10-24x3/8”
Combo Truss Head
Machine Screw
Qty: 3
1/4-20x1/2”
Carriage Bolt
Qty: 8
1/4-20
Keps Lock Nut
Qty: 8
#10-24
Keps Lock Nut
Qty: 3
