Char-Griller Portable Table Top 2-2424 User manual

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg.
OWNER’S MANUAL
Model# 2-2424
Table Top
Charcoal Grill
Keep your receipt with this manual for Warranty.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 2
STOP! CALL Char Griller FIRST! DO NOT RETURN PRODUCT TO STORE
CALL Char Griller [phone] This product has been built to the highest quality
standards. Call us should you have any questions not addressed in these instruc-
tions, or for service information.
No Returns on
Used Grills
PARTS LIST AND TOOLS REQUIRED
(Tools Not Included)
Pliers 7/16" nut driver
Parts List::
1 Cooking Chamber
2 Damper Circle
2 Cast Iron Grates
2 Metal rod handle
1 Wood handle
1 Wire rack (for wood)
1 Side Drawer / Ash pan / Fire grate
1 Cast Iron Lifter
1 Lock Bracket
Phillips Head Screwdriver
Have your grills serial number (located on the back of the grill body or on the leg)
when calling.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 3
ASSEMBLY INSTRUCTIONS
Read all safety warnings and instructions carefully before
assembling and operating your grill.
Note: All nuts go on the inside of the grill.
1. Remove and unwrap the grill and all of its parts from the packaging.
2. Attach the legs to the underside of the grill body using four 1/2” hex bolts and
nuts see below.
3. Attach the wood handle to the lid using two 1/2” hex bolts and nuts. Put lock-
washers under nuts. See above.
4. Attach long metal handle to each side of the grill body with two 1/2” hex bolts
and nuts. See below.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 4
5. Attach the small “U” shaped handle to the side of the drawer with hex nuts. See
below.
6. Attach a damper circle to each side of the grill with 1/2” hex bolts, flat washer,
lock washers and hex nuts. Starting from the outside going in: the 1/2” hex bolt goes
through the flat washer then side drawer wall then the damper circle then another flat
washer then a lock washer then 1/2” hex nut. See below.
7. Install the slide in drawer making sure the edges of the ash pan go under the
guides that are welded to the inside of the body. See above.
8. Finally install the fire grate and cast iron cooking grates.
Damper Circle
Damper Circle
“U” Shaped Handle
Slide Drawer
Fire Grate

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 5
GRILL PREPARATION &
OPERATING INSTRUCTIONS
PLEASE NOTE: NO RETURNS ON USED GRILLS
Read all safety warnings and instructions carefully
Before assembling and operating your grill.
1. Cure GRILL prior to your initial use to protect the interior and exterior finish and
to prevent unnatural flavors to your first meals. (A) Lightly coat ALL INTERIOR
SURFACES (including GRILLS, GRATES, AND INSIDE OF BARREL.) with vegetable
oil (spray vegetable oil is easiest but do not use near hot coals or fire). (B) Build
a medium sized fire on the fire grate. (C) After coals ash over, spread out coals,
replace cooking grates, close lid and heat at approximately 250 F for two hours.
Re-coat GRATES and return to grill at approximately 200 F for two hours. You
can lightly coat the exterior of the grill body (while warm) with vegetable oil. This
will extend the life of the finish, much like waxing a car. Your GRILL will then be
ready for use. NOTE: Grill will drip a lot of oil during this process and for several
uses but will slow over time. NEVER EXCEED 400 BECAUSE THIS WILL DAM-
AGE THE FINISH AND CONTRIBUTE TO RUST. PAINT IS NOT WARRANTED AND
WILL REQUIRE TOUCH-UP. THIS UNIT IS NOT WARRANTED AGAINST RUST.
2. To START FIRE –stack 15 briquettes in pyramid and saturate with lighter fluid
(DON’T USE GASOLINE). Light coals in several places, close lid after briquettes
ash over or _ gray, spread them out and start cooking. If one end burns faster,
use tongs to move coals from one end to the other for even heat. ALWAYS FOL-
LOW CHARCOAL AND LIGHTER FLUID MANUFACTURERS’ INSTRUCTIONS AND
WARNINGS. USE OUTDOORS ONLY ON NONCOMBUSTIBLE SURFACE –15’
AWAY FROM WOOD AND COMBUSTIBLE MATERIAL.
3. Control heat with amount and type of FUEL, DUAL DAMPERS and ADJUSTABLE
FIRE GRATE. Adjust GRATE one end at a time. Wood burns hotter than coals.
More airflow is more heat.
4. For no flare-ups, cook with lid in the down position. Add water soaked hardwood
chips for a smoked flavor.
5. Suggestion: Screw 3/4'" cup hooks (not furnished) on front of the wood shelf to
hang cooking utensils.
6. Burn out may be rust out. Ashes left in bottom too long hold moisture and rust
through any thickness of steel. This grill is made of steel and cast iron, which
WILL RUST, ESPECIALLY IF NOT PROPERLY CARED FOR.
7. Do not use self-starting charcoal as it will give unnatural flavor. Burn lighter flu-
id completely before closing lid.
8. After using, coat vegetable oil on interior grates and bare metal while warm to
reduce rust. On the EXTERIOR, remove dust with wire brush and touch up with a
high heat paint, available at most hardware/auto stores.
9. You may place a coffee can on bottom shelf under the hole in the grill to catch
drippings.
10. HEAT GAUGE may obtain moisture, which will steam out during cooking. Gauge
may be calibrated in oven.
11. You may fill unwanted holes with Nuts & Bolts (Not Provided). NOTE: Smoke will
escape from areas other than the smokestack. This should not affect your cook-
ing.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 6
GRILLING RECIPES
DIRECT METHOD
STEAK (& ALL MEATS): Cook food directly above coals/heat. Generally speaking, to
grill meats, raise fire grate to high position (hot) and sear for one minute on each
side with the lid open to seal in flavor and juices. Then lower fire grate to medium
position with lid closed and cook to desire doneness.
Control heat with dual dampers and adjustable fire grate.
BETTER BARBECUE: Place grilled meat back in the marinade for several minutes
before serving –it will become tastier and juicier. CAUTION: Boil extra marinade
first to kill bacteria remaining from the raw meat.
Tip: Cooking with a MEAT THERMOMETER ensures food is fully cooked. Insert into
thickest part not touching bone & allow five minutes to register. Internal tempera-
tures for BIRDS should be 170F to 180F and meat should be 140F for rare, 160F
medium and 170F for well done.
MARINATED FLANK STEAK: Mix marinade ingredients in nonmetal dish. Let steak
stand in marinade for no less than 4 hours in refrigerator. Brown each side for 5
minutes, but center should remain rare. Cut steak diagonally across the grain into thin
slices before serving. Grill with fire grate in high (hot) position with lid open or closed.
MARINADE: 1/2 cup vegetable or olive oil, 1/3 cup soy sauce, 1/4 cup red wine
vinegar, 2 tbs. Lemon juice, 1 tsp. Dry mustard, 1 minced clove garlic, 1 small
minced onion, 1/4 tsp pepper.
QUAIL OR DOVES: Cover birds in Italian dressing (Good Seasons or Kraft Zesty),
marinate overnight, pour off dressing and cover with Texas Pete Hot Sauce for 6
hours. Wrap birds in thick bacon secured by a toothpick. *Place on grill –keep
turning until bacon is black. Grill for 20 minutes. Sear with lid open and fire grate
in high (hot) position for 1 min each side before lowering grate and closing lid. *OR
SMOKE by placing birds in center of GRID with fire in both ends of FIRE BOX.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 7
KABOBS: Alternating on skewers any combination of meat, onions, tomatoes, green
peppers, mushrooms, zucchini, circular slice of corn-on-the-cob, or pineapple. Meat
could consist of chunks of shrimp, scallops, lobster, chicken, sausage, pork, beef,
etc. Marinate the meat in refrigerator for several hours. Grill each side approximately
7 minutes turning occasionally while basting with marinade. Leave a small amount of
room between pieces in order to cook faster. Grill with lid up and the fire grate in the
lowest position. See marinade recipe on last page.
KABOB MARINADE: Mix 1 cup soy sauce, 1/2 cup brown sugar, 1/2 cup vinegar,
1/2 cup pineapple juice, 2 teaspoons salt, 1/2 teaspoon garlic powder and bring to a
boil. Marinate beef in mixture a minimum of 4 hours.
HOT DOGS: Grill with lid up and fire grate in high (hot) position for approximately 6
minutes, turn every few minutes.
HAMBURGERS: Mix in chopped onions, green peppers, salt, sear 3/4 inch patties
on each side with fire grate in high position for a few minutes. Lower fire grate to
medium position and grill with lid down to avoid flare-ups. Cook each side 3 to 7
minutes according to desired doneness. Cook ground meat to 150 internally or until
juice runs clear (free of blood) for prevention of E-coli. Burgers can be basted with
marinade when turning and/or other ingredients can be mixed in with the ground
beef such as chili sauce or powder; or you may marinate by allowing to stand in mari-
nade for 1 or 2 hours at room temperature before cooking; or let stand in covered
dish in refrigerator up to 24 hours. Bring to room temperature before cooking. See
meat marinade on page 9.
SHRIMP (Peeled) & Crayfish: Place on skewers, coat with melted butter and gar-
lic salt. Grill 4 minutes on each side or until pink. Cocktail sauce optional.
BAKED POTATOES: Rub with butter and wrap in foil and cook on grill with lid down
for 50 minutes. Turn after 25 minutes (no need to turn if smoked). Squeeze to
check for doneness.
SWEET CORN IN HUSKS: Trim excess silk from end and soak in cold salted water 1
hour before grilling. Grill 25 minutes –turning several times.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 8
SMOKIN’ RECIPES: using the Charcoal Grill side of the Duo with a WATER PAN
(also called INDIRECT METHOD).
Pan not included. Disposable bread pan is recommended. SMOKE BY COOKING
SLOWLY (See chart on page 27 for smoking times). 1) Place water/drip pan on left
side of fire grate. 2) Place hot coals on right side (damper end) of fire grate. The
charcoal basket accessory helps confine coals to one side. 3) Place meat above
water pan. 4) Place fire grate in low position. 5) Close lid & control heat with damp-
ers & adjustable grate.
You may want to sear certain foods before smoking by placing meat directly above
coals with LID open and FIRE GRATE in high (hot) position for several minutes. Add
flavor soaked wood chips to the fire and add 1 part marinade, beer or wine to 3
parts water to the drip pan. OPENING THE SMOKING CHAMBER WILL EXTEND
COOKING TIME. Cooking with meat thermometer ensures food is fully cooked. In-
sert thermometer into thickest part not touching bone, and allow five minutes to
register. Internal temperature for birds should be 170F to 180F or when leg moves
easily in joint. Meat should be cooked to internal temperature of 140F for rate,
160F for medium and 170F for well done. Check the water level when cooking more
than 4 hours or when you can’t hear the water simmering. Add water by moving
meat over and pouring water through GRILL into WATER PAN. IF THE SMOKE IS
WHITE, THE FIRE’S RIGHT. IF THE SMOKE IS BLACK, ADD SOME DRAFT.
SMOKED TURKEY: Empty cavity rinse and pat dry with paper towel, tuck wing tips
under the back and tie legs together. Place in center of cooking grid directly above
foil drip pan of water. Smoke for 12 minutes per pound. Allow several extra
minutes per pound if stuffed to allow for expansion. Use a meat thermometer for
best results (190F internal).
SMOKED BAKED HAM: Fully cooked canned ham or smoked and cured whole ham
or shank or butt portion. Place fire grate in the lowest position and a drip pan under
the meat. Remove rind and score fat diagonally to give a diamond effect. Insert a
whole clove in to the center of every diamond. Place ham with fat side up in center
of cooking grid directly above drip pan. Close lid. About 9 minutes per pound is sug-
gested for fully cooked hams. Smoked or cured ham which is not fully cooked
should be cooked to an internal temperature of 160F. Baste with ham glaze 3 or 4
times during last 30 minutes of cooking time. Garnish with pineapple rings about
15 minutes before end of cooking time.
HAM GLAZE: 1 cup of light brown sugar, firmly packed, 1/2 cup orange juice, 1/2
cup honey, combine sugar, juice and honey. Let marinade sit for at least 4 hours.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 9
SMOKED HOT DOGS STUFFED: Slit hot dogs lengthwise, within 1/4 inch of each
end. Stuff hot dogs with cheese and relish and wrap in bacon. Place on cooking
grid over drip pan and smoke 15-20 minutes or until bacon is crisp.
SMOKED CHICKEN PARTS AND HALVES: Rinse pieces in cold water and pat dry
with paper towels. Brush each piece with vegetable oil and season to taste with salt
and pepper. Brown pieces directly above coals with lid open and grate in high or
medium position for several minutes. Then place pieces on cooking grate directly
above drip pan. With the grate in the low position, cook with lid down for 55 to 60
minutes or until done. Do not use vegetable oil or salt and pepper if using mari-
nade.
SMOKED VENISON: Place leg of venison in a container or "hefty bag" and marinate
for 2-4 days, turning daily. Marinate bacon overnight in its marinade. Remove roast
from refrigerator at least an hour before cooking. Season generously with seasoned
salt and coarse ground black pepper. Wrap 1 lb. Bacon over the top of the roast,
and smoke 20/25 minutes per pound, or until tender. Do not overcook.
Venison Marinade: 1 cup Balsamic or wine vinegar, 1 cup olive oil, 2 oz. Worcester-
shire, 1/2 oz. Tabasco, 2 tbs. Season All, 1 to 2 chopped jalapenos, 3 oz. Soy sauce.
Bacon Marinade: 2 ox. Wine vinegar, 2 oz. Worcestershire, 4 dashes Tabasco.
SMOKED SHRIMP & CRAYFISH: Mix in a foil pan 1/2 cup butter, two cloves of
crushed garlic, Tabasco, sliced green pepper, 1 tbls each of minced onions, salt and
juices from one lemon. Add shrimp and/ or crayfish and smoke 45 minutes.
SMOKED VEGETABLES: Turnips, potatoes, carrots, okra, mushrooms, peeled on-
ions, zucchini, squash, etc. Put in pan and cover with water and cook for several
hours while cooking the meat. Or place vegetables on grill and smoke for 50
minutes, either wrapped in foil or not.
SMOKED FISH: Marinate in brine (1/4 cup dissolved in 1 qt of water) or marinate
fish in 1 cup white wine, 1 cup soy sauce mixed with 1 cup lemon juice. Marinate
overnight in covered dish in refrigerator. Let air on rack 20 minutes before placing
on Pam sprayed grill. Smoke 25 minutes.
SMOKED SPARE/BACK RIBS: Peel off tough layer of skin on back side. Rub all
surfaces with seasoning. Place ribs in center of grid above drip pan and smoke ap-
proximately 1 1/2 hours or until meats pulls away from bone. Baste with barbecue
sauce during last 30 minutes.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 10
CHICKEN MARINADE: Combine 1/2 cup soy sauce, 1/4 cup vegetable oil, 1/4 cup
red wine vinegar, 1 teaspoon oregano, 1/2 teaspoon sweet basil, 1/2 teaspoon gar-
lic powder with parsley, 1/4 teaspoon pepper. Pour over chicken pieces in nonmet-
al dish. Cover and refrigerate overnight, turning occasionally. Use marinade to
baste chicken while cooking.
MEAT MARINADE: For steaks, chops, and burgers: Combine q cup soy sauce, 2
coarsely chopped large onions and 2 cloves garlic (halved) in an electric blender;
cover, process at high speed 1 minute or until mixture is very smooth. Stir in 1/4
cup bottle gravy coloring (Kitchen Bouquet and Gravy Master) and 2 teaspoons
Beau Monde seasoning (or substitute 1 teaspoon MSG and 1 teaspoon seasoned
salt). Allow meat to stand in marinade at room temperature for 2 hours or refriger-
ate up to 24 hours in a covered dish. Bring meat to room temperature before cook-
ing.
SHISH KABOB MARINADE: Mix 1 cup soy sauce, 1/2 cup brown sugar, 1/2 cup
vinegar, 1/2 cup pineapple juice, 2 teaspoons salt, 1/2 teaspoon garlic powder and
bring to a boil. Marinate beef in mixture a minimum of 4 hours.

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 11
 Use caution when assembling and operating your grill to avoid
scrapes or cuts from sharp edges.
 Do not use gasoline, kerosene or alcohol for lighting charcoal. Use
of any of these or similar products could cause an explosion possi-
bly leading to severe bodily injury.
 Keep children & pets away from grill. Supervision is necessary and
do not leave grill unattended when in use. Use caution when mov-
ing grill to prevent strains. Keep grill at least 15 feet from any com-
bustible material (decks, buildings, fences, trees, bushes, etc).
 When adding charcoal and/or wood, use extreme caution.
 Never move grill when it is in use or when it contains hot coals or
ashes.
 Do not place grill near flammable liquids, gases or where flamma-
ble vapors may be present.
 Use caution since flames can flare-up when fresh air suddenly
comes in contact with fire. When opening the lid, keep hands, face
and body safe from hot steam and flame flare-ups.
IMPORTANT SAFETY WARNINGS
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR GRILL

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 12
 Do not exceed a temperature of 400 F. Do not allow charcoal and/
or wood to rest on the walls of grill. Doing so will greatly reduce the
life of your grill.
 Always wear oven mitts to protect hands from burns. Avoid touching
hot surfaces.
 When opening lid, make sure it is pushed all the way back so it
rests against the lid support brackets. Use extreme caution as hood
could fall back to a closed position and cause bodily injury.
 Close lid and all dampers to help suffocate flame.
 Always hold an open lid from the wooden handle to prevent it from
closing unexpectedly.
 Never leave coals and ashes unattended. Before grill can be left
unattended, coals and ashes must be removed. Use caution to pro-
tect yourself and property. Carefully place remaining coals and ash-
es in a noncombustible metal container and saturate completely
with water. Allow coals and water to remain in metal container 24
hours prior to disposing.
 To protect against bacteria that could cause illness, keep all meats
and refrigerated and thaw in refrigerator or microwave; keep raw
meats separate from other foods; wash everything that contacts
raw meats; cook thoroughly; and refrigerate leftovers immediately.
Cook meats medium to well one.
THESE WARNINGS APPLY ALSO TO THE "SIDE FIRE BOX"
IMPORTANT SAFETY WARNINGS
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR GRILL

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 13
ACCESSORIES
ORDER FORM
TO ORDER
Visit our online store at:
www.chargriller.com
or
CALL: 912-638-4724
or
FAX: [phone]
or MAIL:
P.O. Box 30864
Sea Island, GA
31561
Table Top Model# 2-2424
 Cover
Custom Fit, Weather Resistant
Protects grill finish
Grill cover #2455
 Apron
Machine Washable
Two Front Pockets
Adjustable Straps
Name_______________________________________ Telephone___________________
Street Address____________________________________________________________
City / State / Zip__________________________________________________________
Email___________________________________________________________________
Please bill my credit card:
EXPIRATION DATE
VISIT OUR WEB SITE FOR SHIPPING COST
www.CharGriller.com
Model# 2-2424 Table Top
Check or Money Order (Sorry—No C.O.D.s)
Check orders will be held 2 weeks before shipment
Qty. Prodcut Price
Adjustable Fit Apron
Cover For Grill
Shipping Charge
Total
Prices & policies subject to change
15% Restocking Fee on all returns
No Returns on Used Product.
Please Call For updated Pricing
and Product Availability.
Georgia Customers add a 7% sales tax.
Washington state Customers add a 10%

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 14
Page intentionally left blank for notes

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 15
Page intentionally left blank for notes

OM2-2424TTB.1 ™ & © Char-Griller / A&J Mfg. 16
P.O. Box 30864
Sea Island, GA
31561
912-638-4724
www.CharGriller.com
Warranty Information —Charcoal Grill
Char-Griller® will repair or replace any defective part of its grillers/
smokers for a period of up to one year from the date of purchase. Char-
Griller® will also repair or replace the body (bottom half) of its grillers/
smokers if the metal is rusted through or burned through for a period up
to five years. Char-Griller will repair or replace any defective part of its
side fire boxes for a period up to one year from the date of purchase.
Proof of purchase, proof of purchase date, photo and prepaid return of
the item in question may be required. Misuse, abuse, or commercial use
nullifies all warranties. Paint/finish is not warranted. Products are not
warranted against rust.
The warranty is for replacement of defective parts only. Manufacture will
not be responsible for damage resulting from accident, alteration, mis-
use, abuse, hostile environments, improper installation, installation not in
accordance with local codes of service of unit.
This limited warranty does not cover any scratches, dents , corrosion or
discoloring by heat, abrasive and chemical cleaners nor any components
used in the installation of the appliance.
Save your receipt for all warranty claims.
