Charge City User manual

137381 Rev 1 (02/20)
Bicycle Owner‘s Manual
For E-Bike Models
This manual contains important safety,
performance and service information. Read it
before you take the first ride on your new bicycle,
and keep it for reference.

Bicycles Cannot Protect You
Bicycles are lightweight, human-powered vehicles, even Ebikes. Unlike a car, much like a
motorcycle, there is no restraint system for your body, no protective structure around your body.
Crash worthiness cannot be a design criterion. A rider sits on a bicycle and can be easily thrown
of for many reasons including overly hard use of the front brakes or striking an obstacle.
Like any sport, bicycling involves risk of injury and damage. By choosing to ride a bicycle, you
assume the responsibility for that risk, so you need to know — and to practice — the rules of safe
and responsible riding and of proper use and maintenance. Proper use and maintenance of your
bicycle reduces risk of injury.
Many of the Warnings and Cautions say, “You may lose control and fall”. Because any fall can
result in serious injury or even death, we do not always repeat the warning of possible injury or
death.
Because it is impossible to anticipate every situation or condition that can occur while riding, this
Manual makes no representation about the safe use of the bicycle under all conditions. There are
risks associated with the use of any bicycle which cannot be predicted or avoided, and which are
the sole responsibility of the rider.
Safety Messages
In this manual, particularly important information
is presented in the following ways:
Indicates a hazardous situation which, if not avoided, may
result in death or serious injury.
CAUTION
Indicates special precautions that must be taken to avoid
damage.

About This Owner’s Manual
This manual meets EN ISO-4210 and 16 CFR 1512 Standards
In case of a conflict between the instructions in this manual and information provided by a component
manufacturer, always follow the component manufacturer’s instructions.
If you have any questions or do not understand something, take responsibility for your safety and
consult with a bicycle dealer or the bicycle’s manufacturer.
NOTE: This manual is not intended as a comprehensive use, service, repair or maintenance manual.
Please see a bicycle dealer or professional bicycle mechanic for all service, repairs or maintenance
not covered in this manual.
Bicycle Dealers and professional bicycle mechanics may also be able to refer you to classes, clinics or
books on bicycle use, service, repair or maintenance.
Component and Accessory Manuals
Additional safety, performance and service information for specific components such as suspension
or pedals, fenders, lighting on your bicycle, or for accessories such as helmets or lights that you
purchase, may also be available. Make sure you read and follow all the manufacturers’ literature that
was included with your bicycle or accessories.
Drive System Manufacturer Manuals
Manufacturers’ instructions contain important operations, service and
maintenance information.
In addition to this manual, you must read and follow the manufacturers’
instructions for all components of the drive-assist system:
• Drive Unit
• Drive Controller
• Drive Batery
• Drive Batery Charger
Download links to this manual and applicable manufacturers’ drive system
manuals or product websites are available via the Support section of our
website: .chargebikes.com.

Bike Models
Charge City . . . . . . . . . . . . 6
Charge Comfort . . . . . . . . . . 8
Charge XC . . . . . . . . . . . .
Frame Labels . . . . . . . . . . . 12
Purchase Record . . . . . . . . . .13
Important Safety
Information
A Special Note for Parents . . . . . . 14
Restricting Use of the Bike . . . . . .15
Bicycles Have Sharp Surfaces. . . . .15
Cancer Risk . . . . . . . . . . . .15
Teaching Your Child the Rules . . . . .16
Intended Use of the Bike. . . . . . .19
Understanding E-bikes. . . . . . . 20
E-bike Operation . . . . . . . . . . 21
Follow Laws & Regulations . . . . . 22
Your Insurance Policies . . . . . . .13
Bateries and Chargers. . . . . . . 23
Drive System Maintenance . . . . . 25
No Modifications . . . . . . . . . 26
Kickstands . . . . . . . . . . . .27
Trailers . . . . . . . . . . . . . .27
Racks . . . . . . . . . . . . . .27
Foreign Objects . . . . . . . . . 29
Contents
Riding Safety
Required Safety Devices . . . . . . 30
Bicycling Inherent Risk . . . . . . 30
Always Wear a Helmet . . . . . . . .31
23 Safety Points . . . . . . . . . 32
What to Know Before
Your First Ride . . . . . . . . . . 34
Riding Of-Road . . . . . . . . . 35
Of Road Respect . . . . . . . . 36
About Bicycle Suspension . . . . . 36
Stay In Control . . . . . . . . . . 36
Wet Weather Riding . . . . . . . . 36
Jumping . . . . . . . . . . . . .37
Mountain Bikes & Maintenance . . . .37
Bicycle Reflectors . . . . . . . . .37
Riding at Night, Dusk, and Dawn . . . 38
Bicycle Lights . . . . . . . . . . 40
Riding in Trafic/Commuting. . . . . . 41
Adjustment (Fit) Instructions
Stand Over Height . . . . . . . . 42
Saddle Height . . . . . . . . . 43
Saddle Front to Back Adjustment . . 46
Saddle Angle Adjustment . . . . . 46
Handlebar Height and Angle . . . . .47
Handlebar Control Positions . . . . 48
Folding Stem Instructions . . . . . 49
Changing the Handlebar Position . . 50
Adjusting the Folding
Stem Lever Tension . . . . . . . . 52

Technical Information
About Wheels . . . . . . . . . . 54
Charge City/Comfort
Front Wheel Removal . . . . . . . .57
Charge City/Comfort
Front Wheel Installation . . . . . . 58
Charge City/Comfort
Rear Wheel Removal/Installation . . . 59
Charge XC Front Wheel Removal . . . 60
Charge XC Front Wheel Installation . . .61
Charge XC Rear Wheel
Removal/Installation . . . . . . . 62
Brakes . . . . . . . . . . . . . 63
About Seat Posts. . . . . . . . . 67
Shiting Gears . . . . . . . . . . 69
About Pedals . . . . . . . . . . .72
About Bicycle Suspension . . . . . .75
About Tires and Tubes . . . . . . . .76
About Changing Adding Accessories . . 81
About Using Bicycle Racks . . . . . 82
Water Botles . . . . . . . . . . 83
Inspect for Safety
Nothing Last Forever,
Including Your Bike . . . . . . . . 85
Understanding Metals . . . . . . . .87
Understanding Composites . . . . . .91
Understanding Bicycle
Component Inspection . . . . . . 94
Maintenance
Basics of a Good
Maintenance Schedule . . . . . . 98
Cleaning Your Bike . . . . . . . . 100
Importance of Lubrication . . . . . 100
Bicycle Repair/Work stands . . . . . 101
Tightening Torques . . . . . . . . 102
Limited One-Year Warranty . . 109
FCC Part 15 Compliance. . . . 105
Pre-Ride Checklist . . . . . . 106

6
Charge Bicycle Owner’s Manual E-Bike Models
Charge City
137381 Rev 1 (02/20)
12
23
7
9
18
8
3
19 20
1
2
21
22
24
14
6
5415
25
26
6
13
10
17
16
E-Bike Models
Charge City
Parts
1. Drive Unit
2. Batery, External
3. Charge Port
4. Drive Display
5. Throtle
6. Stem
7. Saddle
8. Light, Front
9. Light, Rear
10. Kickstand
12. Seat Post
13. Seat Clamp
14. Fork, Rigid
15. Shiter, Twist, Rear
16. Fender, Front
17. Fender, Rear
18. Rear, Rack
19. Derailleur, Rear
20. Chain
21. Pedal
22. Brake Rotor
23. Frame Serial Number
24. Tire Valve
25. Lever, Brake, Rear
26. Lever, Brake, Front
Identification

7
E-Bike Models
Charge City
Item Specification
Intended Use ASTM CONDITION , General Purpose Riding
Frame 6061 Aluminium
Fork 1 1/8 Cromoly fork
Front Wheel 700c alloy, 32 hole double wall rim, w/alloy loose ball bearing hub
Rear Wheel 700c alloy, 32 hole double wall rim, with Bafang Hub Drive Motor
Tires Goodyear Transit Tour 700×40 puncture resistant with reflective
sidewalls.
Pedals Fiberglass reinforced folding Nylon pedal. 9/16.
Crank Alloy 38 teeth (Length: 170mm on size S/M, 175mm on size L/XL)
Chain KMC  speed
Gearing 7 speed with 14 - 34 tooth range.
Rear Derailleur Shimano Altus 7 speed
Shiter Shimano Tourney 7 speed shiter with optical gear display
Handlebar Lightweight 6061 Aluminium with 60mm rise t 31.8 mm dia.
Grips Charge Comfort Ergo Sot Rubber Grip
Stem TransX  degree rotateable stem with +7 degree rise, 80 mm
length, 31.8 mm clamp
Brakes Promax cable actuated disc brakes with 160mm rotors front and
rear
Saddle Ergonomic Charge Comfort Saddle. Length: 145mm
Seatpost 6061 Aluminium. 30.9×350, 0 mm ofset.
Rack Integrated Rear Rack
Fenders Lightweight and stainless steel, front and rear full coverage
fenders
Kickstand Alloy center mount with height adjutable foot
Extras Tire Pressure Indicator Valve Caps
Batery 4WH Removable Rechargeable Li Ion Batery. Samsung E
cells.
Charger 2 Amp Batery Charger : p/n K
Controller 2W ON/OFF Switch. Assist Up and Down butons.
Display Intelligent batery capacity indication, Real Time Speed
Indication, Power Assist Level indication
Motor 2W Bafang Hub Drive Motor. 45 Nm of (drive) torque.
Lights Spanninga LED Rear Light, and LED Front Light with integrated
horn.
Pedal Assist 5 Support Modes
Throtle Yes
Specifications

8
Charge Bicycle Owner’s Manual E-Bike Models
Charge Comfort
137381 Rev 1 (02/20)
11
20
7
9
15 8
2
16 17
1
3
18
21
21
13
6
5414
22
23
6
12
10
24
Charge Comfort
Parts
1. Drive Unit
2. Batery, Rack
3. Charge Port
4. Drive Display
5. Throtle
6. Stem
7. Saddle
8. Light, Front
9. Light, Rear
10. Kickstand
11. Seat Post
12. Seat Clamp
13. Fork, Suspension
14. Shiter, Rear
15. Rear, Rack
16. Derailleur, Rear
17. Chain
18. Pedal
19. Brake Disc, Front
20. Frame Serial Number
21. Tire Valve
22. Lever, Brake, Rear
23. Lever, Brake, Front
24. Chain Guard
Identification

9
E-Bike Models
Charge Comfort
Intended Use ASTM CONDITION , General Purpose Riding
Frame 6061 Aluminium
Fork 1 1/8 Cromoly fork
Front Wheel 700c alloy, 32 hole double wall rim, with alloy loose ball bearing
hub
Rear Wheel 700c alloy, 32 hole double wall rim, with Bafang Hub Drive Motor
Tires Goodyear Transit Tour 700×40 puncture resistant with reflective
sidewalls.
Pedals Fiberglass reinforced folding Nylon pedal. 9/16.
Crank Alloy 38 teeth. Length: 170mm
Chain KMC  speed
Gearing 7 speed. 14 - 34 tooth range.
Rear Derailleur Shimano Altus 7 speed
Shiter Shimano Tourney 7 speed shiter with optical gear display
Handlebar Lightweight 6061 Aluminium with 60 mm rise 31.8 mm.
Grips Charge Comfort Ergo Sot Rubber Grip
Stem TransX  degree rotateable stem with +7 degree rise, 80 mm
length, 31.8 clamp
Brakes Promax cable actuated disc brakes with 160mm rotors front and
rear
Saddle Ergonomic Charge Comfort+ Saddle. Length: 155mm
Seatpost Lightweight and durable 6061 Aluminium. 30.9×350, 0mm ofset.
Rack Integrated Rear Rack
Fenders Lightweight and stainless steel, front and rear full coverage
fenders
Kickstand Alloy center mount with height adjutable foot
Extras Tire Pressure Indicator Valve Caps
Batery 4WH Removable Rechargeable Li Ion Batery. Uses Samsung
E cells.
Charger 2 Amp Batery Charger : p/n K
Controller 2W ON/OFF Switch. Assist Up and Down butons.
Display Intelligent batery capacity indication, Real Time Speed
Indication, Power Assist Level indication
Motor 2W Bafang Hub Drive Motor. 45 Nm of (drive) torque.
Lights Spanninga LED Rear Light, and LED Front Light w integrated horn.
Pedal Assist 5 Support Modes
Throtle Yes
Specifications

10
Charge Bicycle Owner’s Manual E-Bike Models
Charge XC
137381 Rev 1 (02/20)
13
9
14
11
19
10
4
12
20 21
1
3
22
23
24
15
7
7
5 16
26
27
76
4
28
29 24
17
18
2
Charge XC
Parts
1. Drive Unit
2. Batery, Internal
3. Batery, Door
4. Charge Port
5. Drive Display
6. Power Buton
7. Assist Control
8. Stem
9. Saddle
10. Light, Front
11. Light, Rear
12. Kickstand
13. Seat Post
14. Seat Clamp
15. Fork, Suspension
16. Shiter, Rear
17. Fender, Front
18. Fender, Rear
19. Rear, Rack
20. Derailleur, Rear
21. Chain
22. Pedal
23. Brake Disc
24. Frame Serial Number
25. Tire Valve
26. Lever, Brake, Rear
27. Lever, Brake, Front
28. Brake Caliper, Front
29. Rear Cassete
Identification

11
E-Bike Models
Charge XC
Intended Use ASTM CONDITION , General Purpose Riding
Frame 6061 Aluminium. Tapered 1.5” 1 1/8” headtube
Fork SR Suntour XCM , 100mm coil fork with preload adjuster
Front Wheel WTB ”, 32 hole double wall rim, with Shimano MT thru axle
hub (15mm)
Rear Wheel WTB ”, 32 hole double wall rim, with Shimano MT -
speed thru axle hub (15mm)
Tires Goodyear Peak 29×2.25 puncture resistant with reflective
sidewalls.
Pedals Fiberglass reinforced folding Nylon pedal. 9/16.
Crank Shimano E  teeth with alloy guard (Length: 1MM)
Chain KMC  speed.
Gearing 8 speed. 11- 34 tooth range.
Rear Derailleur Shimano Altus 8 speed
Shiter Shimano Rapidfire Plus 8 speed with optical gear display
Handlebar Lightweight 6061 Aluminium with 60mm rise to provide heads up,
confident handling. 31.8.
Grips Charge Comfort Ergo Sot Rubber Grip
Stem TransX  degree rotateable stem with +7 degree rise, 80mm
length, 31.8 clamp
Brakes Shimano MT Hydraulic disc brakes with 180mm rotors
Saddle Ergonomic Charge Comfort Saddle. Length: 145mm
Seatpost Lightweight and durable 6061 Aluminium. 30.9×350, 0mm ofset.
Rack Integrated Rear Rack
Fenders Lightweight and stainless steel, front and rear full coverage
fenders
Kickstand Dropout mounted
Extras Tire Pressure Indicator Valve Caps
Batery Shimano E WH Integrated Batery with ABUS Lock
Charger Shimano 2 Amp E Smart Charger
Controller Shimano E. Ergonomic, adjustable layout. Superb fingertip
shiting of support setings
Display Shimano E Cycle Computer
Motor Shimano E W
Lights Spanninga LED Rear Light, and LED Front Light integrated horn.
Pedal Assist 3 support modes plus Power Walk Assist
Throtle No
Specifications

12
Charge Bicycle Owner’s Manual E-Bike Models
Frame Labels
137381 Rev 1 (02/20)
Frame Labels
The labels below are located on the bicycle frame. These labels contain important information. Do
not remove them.
Class - E-bikes in the US are defined under
diferent classes (i.e CLASS , CLASS , CLASS ).
The class number of the bike influences where and
under what conditions it is legal to operate.
Authorities can require that the label be displayed
on the bike before it can be ridden in a regulated
area. If the label is not present, you may not be
permited to ride in the area, even if the area is
open to the Class.
Cut-Of Speed - When the bicycle speed exceeds
the cut-of-speed ( in miles-per-hour) the drive
system will stop providing assistance. Assistance
will resume when the bicycle speed drops below
the cut-of speed
Max Power - This is the maximum power (in wats)
the drive system delivers.
Made in - The country where the bicycle was
manufactured
This is the frame warning label. It contains
safety information to anyone who rides the
bike. It also contains contact information.

13
E-Bike Models
Purchase Record
Purchase Record
Fill in immediately and retain as a record of your purchase. Please retain your sales receipt for any
possible warranty claims.
Your Name:
Address:
City/State:
Date Purchased:
Place of Purchase:
Model Information:
Wheel Size:
Model Number:
Date Code:
Frame Serial Number:
Battery Key Serial Number:

14
Charge Bicycle Owner’s Manual Important Safety Information
A Special Note For Parents
137381 Rev 1 (02/20)
A Special Note For Parents
As a parent or guardian, you are responsible for the activities and safety of your minor child, and that
includes making sure that the bicycle is properly fited to the child; that it is in good repair and safe
operating condition; that you and your child have learned and understand the safe operation of the
bicycle; and that you and your child have learned, understand and obey not only the applicable local
motor vehicle, bicycle and trafic laws, but also the common sense rules of safe and responsible
bicycling.
As a parent, you should read this manual, as well as review its warnings and the bicycle’s functions and
operating procedures with your child, before leting your child ride the bicycle.
Make sure that your child always wears an approved bicycle helmet when riding; but also make
sure that your child understands that a bicycle helmet is for bicycling only, and must be removed
when not riding. A helmet must not be worn while playing, in play areas, on playground equipment,
while climbing trees, or at any time while not riding a bicycle.
Failure to follow this warning could result in serious injury or death.
(continued on the next page...)
Important Safety Information
Disregarding or misunderstanding of the any safety warnings, the safety warnings in the manuals
associated with the e-bike parts, and safety labels on the e-bike could result in serious injury or
death.
Anyone assembling, using, maintaining, transporting or storing this e-bike must read, understand, and
follow these safety warnings before performing any of the actions stated.
If you have any questions regarding the safety warnings and labels call
Charge Customer Service at 833-482-3822

15
Important Safety Information
Restricting Use of the Bike
Restricting Use of the Bike
WARNINGS
Use of this e-bike by persons (including children) with reduced physical, sensory or mental
capabilities or persons lacking experience and knowledge in the use of the e-bike could result in
serious injury or death.
The owner of this e-bike must ensure this product is not used by people with the conditions
described above. Always follow the rules, regulations and laws (including age limits) related to
the use of an e-bike in its area of use.
A child may not realize or understand the e-bike has moving parts and components (e.g. batery).
Never allow children to play or come into contact with the e-bike or its parts. Always follow all rules,
regulations and laws regarding age limits and operation in the e-bike area of use.
See also, “Teaching Your Child the Rules ” in this owners manual.
Bicycles Have Sharp Surfaces
Bicycles have exposed sharp surfaces. Exercise caution with chainrings and pointed, aggressive
plaform pedals, as they have sharp and potentially dangerous surfaces. Use caution when working
on your bike. If you slip or fall you could be injured.
Cancer Risk
WARNINGS
This product can expose you to chemicals including lead, which is known to the State of California
to cause cancer and birth defects or other reproductive harm.
For more information go to .PWarnings.ca.gov

16
Charge Bicycle Owner’s Manual Important Safety Information
Teaching Your Child the Rules
137381 Rev 1 (02/20)
Teaching Your Child the Rules
We cannot over-state how import this entire owner’s manual is to the rider’s safety.
We also understand Kids need to be taught ... and to have frequently reinforced ... the following rules
and lessons which adults are already expected to know.
We urge you to take the time to familiarize yourself with this owner’s manual and the rules in this
section.
Teach the rules to your child before you let your child ride unsupervised.
1.Rules
• No playing in the road or in the street.
• No riding on busy streets.
• No riding at dawn, dusk or at night.
• Stop for all STOP signs.
• Ride on the right of trafic.
2.Lessons
The lessons that follow relate to some of the most common real situations that children encounter
when riding their bikes. Go over these situations with your child and make sure the lesson objective is
accomplished.
a. Driveway Ride out
When a youngster rides out of the driveway and is struck by a car, that is called a ride out accident.
What can you do? First, realize the danger of your own driveway. If there are obstructions to the view
of passing motorists (like bushes or trees), trim them back. You might park your car in front of the
driveway, if local ordinance permits. This way, your child can’t use the driveway as a launching pad. But
the most important thing you can do is teach your child about driveway safety. Take your child outside
to the driveway and have him/her practice the following steps:
1) Stop before entering the street.
2) Look let, right and let again for trafic.
3) If there’s no trafic, proceed into the roadway.

17
Important Safety Information
Teaching Your Child the Rules
b. Running a Stop Sign
Car/bike crashes can happen when a cyclist runs a stop sign. Most cyclists who get hit riding through
stop signs know that they were supposed to stop. They just thought it would be OK this time; or they
may have been distracted. The thing to impress upon your child is that while he/she may not get hit
every time, running stop signs will eventually result in an accident.
What can you do? Take your child to a stop sign near home. Explain what it means by emphasizing
the following points:
1) Stop at all stop signs, regardless of what is happening.
2) Look in all directions for trafic.
3) Watch for oncoming cars making let turns.
4) Watch for cars behind you making right turns.
5) Wait for any cross trafic to clear.
6) Proceed when safe.
In order to make this lesson stick, you may have to change your own driving habits. If you creep
through intersections controlled by stop signs, you are showing your child that you don’t really believe
what you preach. For your child’s sake, stop at stop signs.
c. Turning Without Warning
Another major accident type involves cyclists who make unexpected let turns. They neither look
behind for trafic, nor do they signal. The key factor here is neglecting to look to the rear. If the cyclist
had looked, he/she would have seen the danger coming up from behind.
What can you do? Of course, you ought to teach your child not to ride across busy streets - at least
until the child has had some advanced training and is old enough to understand trafic. But in the
meantime, for residential street riding, you can teach your child to always look and signal before
turning let. A big part of this lesson is teaching the child how to look to the rear without swerving.
Take your child to a safe area away from trafic or obstructions to practice riding along a straight line
while looking behind. Stand alongside and hold up a diferent number of fingers on your hand ater the
child rides by. Call his/her name. Ater 15 minutes of practice, a ten year old should be able to look
behind his/herself and identify how many fingers you are holding up - without swerving.

18
Charge Bicycle Owner’s Manual Important Safety Information
Teaching Your Child the Rules
137381 Rev 1 (02/20)
d. Riding at Dawn, at Dusk or at Night
Most car/bicycle accidents happen at night where an overtaking car hits a bike. (An overtaking car is
one that comes up from behind and passes the cyclist on the let.) These overtaking accidents can be
very serious.
What can you do? First, you should keep your child from riding at dawn, dusk or at night. It requires
special skills and equipment.
Few children have either. Secondly, make sure your child understands that if he/she gets caught out at
dusk or ater dark on a bike, the thing to do is to call you for a ride home. One suggestion is to have
your child carry a cell phone, and as an added precaution, tape a phone number to the bike so that, in
an emergency, an adult will be able to call home.
e. Following the Leader
There is increased risk of car/bike collision if children are following each other, because if the first one
does something dangerous, those following may do it too.
What can you do? Teach your child to always assess the trafic situation for him/herself. When riding
cyclists are riding in a group, each cyclist should stop for stop signs; each cyclist should look to the
rear before making let turns; and so on. One way to get the message across is to play a game with the
child similar to ‘Simon Says’. In this game, however, the emphasis should not be on doing what ‘Simon
Says’, but rather have the child make a decision based on the situation. The child should learn to
ignore what ‘Simon Says’. Children need to learn to think for themselves to ride safely.
Summary
Teach your child early - the earlier the beter. Learning skills such as looking and avoiding hazards
takes time. Be prepared to repeat lessons until your child understands what you’re trying to get across.
Be patient. Your eforts will be rewarded, knowing that your child is aware of safe riding skills.

19
Important Safety Information
Intended Use of the Bike
Intended Use of the Bike
The intended use of Charge City, Comfort, and XC models is ASTM CONDITION . A description of the
standard is described in the following table:
Condition 2, General Purpose Riding
Bikes designed for riding Condition 1, plus smooth gravel roads and improved
trails with moderate grades where the tires do not lose ground contact.
MAXIMUM WEIGHT LIMIT: Rider: 300 lbs /136 kg , Luggage: 30 lbs/ 14 kg,
Total 330 lbs/ 1250 kg.
Touring Trekking Bikes: Rider: 300 lbs /136 kg , Luggage: 55 lbs/ 25 kg,
Total 355 lbs/ 161 kg
INTENDED For paved roads, gravel or dirt roads that are in good condition, and bike paths.
NOT INTENDED For of-road or mountain bike use, or for any kind of jumping. Some of these bikes
have suspension features, but these features are designed to add comfort, not of-road capability.
Some come with relatively wide tires that are well suited to gravel or dirt paths. Some come with
relatively narrow tires that are best suited to faster riding on pavement. If you ride on gravel or dirt
paths, carry heavier loads or want more tire durability talk to your dealer about wider tires.
Understand your bike and its intended use. Choosing the wrong bicycle for your purpose can
be hazardous. Using your bike the wrong way is dangerous.
Refer to the drive assist system manufacturer’s manual for instructions regarding all the components
of the drive assist system (e.g. Batery, Drive Charger, Display/e-bike Computer). Always follow the
manufacturer’s instructions for intended use and limitations.

20
Charge Bicycle Owner’s Manual Important Safety Information
Understanding E-bikes
137381 Rev 1 (02/20)
Understanding E-bikes
What is an E-bike?
Electric bikes, also known as “E-Bikes” are bicycles equipped with an electric pedal assist drive
system. An E-Bike IS NOT a moped or motorcycle. E-bikes share components common with pedal-
only bikes.
What is a Drive System?
The drive-assist system consists of a drive unit, a batery, a computer control, and various electronic
components (harness wires, sensors, and switches). There are many diferent drive-assist systems for
difering uses and bike types. Likewise there are various drive-assist system manufacturers (Shimano,
BOSCH, Bafang, Yamaha, etc.)
How does the Drive System work?
A Drive System can be throtle based, pedal assist based, or both.
Throtle Controlled Drive
For a drive system equipped with a throtle, it is important to know that when the drive-assist system is
turned ON, the drive unit engages to provide power when the throtle is pressed.
Pedal Assisted Drive
For a drive system that is pedal assist only, It is important to know that when the drive-assist system is
turned ON, the drive unit engages to provide power only while you are pedaling. The amount of power
provided by the drive unit depends on your pedaling force and the assistance mode/level you set with
the handlebar control unit. With a pedal-assist system, if you stop pedaling, the drive-assist will
disengage.
Limit Assistance / Maximum Speed Allowable
The drive-assist system power reduces progressively and cuts of as the bike reaches a the maximum
allowable speed. The drive-assist re-engages when speed drops below the maximum allowable speed
as long as the pedals are turning. Whenever the drive-assist system is turned OFF, you can pedal the
bike normally. The drive system will not engage.
