charismaTec OG Doculus Lumus User manual

Version 7v0 EN
RFID ICAO Check
IR LED (870 nm)
UV* / UVC Change
AS Anti-Stokes
(IR Laser 980 nm)
Oblique Light
(8 LEDs)
UV* Light
(4 LEDs)
FUV / Torchlight
(Front UV* or White Light)
Incident Light
(4 LEDs)
*) UV Light: 365 nm
Device Options
Rotation Right
Rotation Left
LILI Additional
Lithium-Ion Battery
Quick Guide
Doculus Lumus
®

www.doculuslumus.com
1s 2s 3s 4s
UV*
UVC
Press button
FUV Front UV
Torch (365 nm)
Torch
(white light/
see-through light)
Rotating Oblique
Light
(manual / automatic)
Rotating Incident
Light
(manual / automatic)
Steady Light /
Documentation
Mode
UVC (4 LEDs,
for 254 nm features)
IR Infrared LED
(870 nm)
Button Combination
Application
Optionally keep pressed
LED Pattern Explanation
Low battery/ Empty rechargeable battery IR LED / AS IR Laser is active
RFID ICAO Check
Search for Transponder Red LED blinks fast ICAO Type A (ISO 14443) Green LED blinks once recurring ICAO Type B (ISO 14443) Green LED blinks twice recurring Type A (ISO 14443) Red and green LED blink once recurring Type B (ISO 14443) Red and green LED blink twice recurring Standard RFID Chip Red and green LED blink alternating
Time
