Intimidator Beam 355 IRC User Manual Rev. 1
BEFORE YOU BEGIN
1. BEFORE YOU BEGIN
What Is Included
• Intimidator Beam 355 IRC
• Power Cord
• Hanging Bracket
• Warranty Card
• Quick Reference Guide
Unpacking Instructions
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
Claims
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Text Conventions
Convention Meaning
1–512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified
<ENTER> A key to be pressed on the product’s control panel
ON A value to be entered or selected
Symbols
Symbol Meaning
Electrical warning. Not following these instructions may cause electrical damage to
the product, accessories, or the user.
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetdj.com.
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2017 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
CHAUVET, the Chauvet logo, and Intimidator Beam 355 IRC are registered trademarks or trademarks of
Chauvet & Sons LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other
company and product names and logos referred to herein may be trademarks of their respective
companies.

Page 2 of 20
BEFORE YOU BEGIN
Intimidator Beam 355 IRC User Manual Rev. 1
Product at a Glance
Use on Dimmer Auto Programs 
Outdoor Use Auto-ranging Power Supply 
Sound-Active Replaceable Fuse 
DMX User-Serviceable 
Master/Slave 
Safety Notes
• ONLY connect this product to a grounded and protected circuit.
• DISCONNECT from power before cleaning or replacing the fuse.
• DO NOT look at the light source when the product is on.
• Make sure the power cord is not crimped or damaged.
• Never disconnect this product from power by pulling on the cord.
• When mounting this product overhead, ALWAYS use a safety cable.
• DO NOT allow flammable materials close to the product when it is operating.
• DO NOT touch the product’s housing when it is on because it will be hot.
• The voltage of the outlet to which you are connecting this product must be within the range
stated on the decal or rear panel of the product.
• This product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose
this product to rain or moisture.
• Always mount this product in a location with adequate ventilation, at least 20 in (50 cm)
from adjacent surfaces.
• Be sure that no ventilation slots on the unit’s housing are blocked.
• Never connect this product to a dimmer or rheostat.
• Replace the fuse with the same type and rating.
• Never carry the product by the power cord. Use only the handle to carry this product.
• Themaximum ambient temperature is104 °F (40 °C).Donot operate this productat higher
temperatures.
• In the event of a serious operating problem, stop using immediately.
• DO NOT open this product. It contains no user-serviceable parts.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Keep this User Manual for future use. If you sell the product to someone else, be sure that
they also receive this document.

Page 3 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
INTRODUCTION
2. INTRODUCTION
Product Overview
Carry
Handles
DMX
In/Out
Fuse
Holder
Power
In
Menu
Buttons Power Out
LCD
Display Safety Loop
Moving
Head
Yoke
LED
Indicator
Infrared
Sensor
Product Dimensions
18.9 in
480 mm
8.7 in
220 mm
12.7 in
322 mm

Page 4 of 20
SETUP
Intimidator Beam 355 IRC User Manual Rev. 1
3. SETUP
AC Power
The Intimidator Beam 355 IRC has an auto-ranging power supply and it can work with an input voltage
range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power
outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to
the product’s specifications chart. The listed current rating indicates the product’s average current draw
under normal conditions.
•Always connect the product to a protected circuit (a circuit breaker or fuse). Make
sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
•Toeliminate unnecessary wear and improve its lifespan, during periodsof non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0 to 100% switch.
Fuse Replacement
1. Disconnect the product from power.
2. Using a flat-head screwdriver, unscrew the fuse holder cap from the housing.
3. Remove the blown fuse.
4. Replace with a fuse of the same type and rating.
5. Screw the fuse holder cap back in place and reconnect power.
Disconnect the product from the power outlet before replacing the fuse.
Power Linking
The product provides power linking via the Edison outlet located in the back of the product. Please see the
diagram below for further explanation.
Power Linking Diagram
1st Product
2nd Product
3rd Product
Additional
Products
Power
Source
You can power link up to 5 Intimidator Beam 355 IRC products on 120 VAC or up
to 9 Intimidator Beam 355 IRC products on 230 VAC.

Page 5 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
SETUP
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
Orientation
The Intimidator Beam 355 IRC may be mounted in any position; however, make sure adequate ventilation
is provided around the product.
Rigging
• Before deciding on a location, always make sure there is easy access to the product for
maintenance and programming purposes.
• Make sure adequate ventilation is provided around the product.
• Make sure that the structure or surface onto which you are mounting the product can support the
product’s weight. (see the Technical Specifications)
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
• When power linking multiple products, mount the products close enough for power linking cables to
reach.
• The bracket adjustment knobs allow for directional adjustment when aiming the product to the
desired angle. Only loosen or tighten the bracket knobs manually. Using tools could damage the
knobs.
• The rubber feet also serve as floor supports. When mounting the product on the floor, make sure
that the product and cables are away from people and vehicles.
Mounting Diagram
Safety Cable
(such as CH-05 from
Chauvet)
Mounting Clamp
(such as CLP-15 from Chauvet)
Mounting Bracket
Rubber Feet for Floor
Mounting
(x4)
When using only one mounting clamp with this fixture, you must use a clamp with
a captive bolt to prevent accidental loosening.

Page 6 of 20
OPERATION
Intimidator Beam 355 IRC User Manual Rev. 1
4. OPERATION
Control Panel Operation
To access the control panel functions, use the four buttons located underneath the display. Please refer to
the Product Overview to see the button locations on the control panel.
BUTTON FUNCTION
<MENU> Press to find an operation mode or to back out of the current menu option
<UP> Press to scroll up the list of options or to find a higher value
<DOWN> Press to scroll down the list of options or to find a lower value
<ENTER> Press to activate a menu option or a selected value
Menu Map
MAIN LEVEL PROGRAMMING LEVELS DESCRIPTION
Address 001–512 Sets the DMX starting address
Run Mode
DMX 14CH Selects DMX mode
08CH
Slave Slave1–4 Selects Slave mode 1, 2, 3, or 4
Auto Selects Auto mode
Sound Selects Sound mode
IR Selects infrared control
Manual
Pan
000–255
0–540°
Tilt 0–270°
Color Selects color options
Gobo Selects gobo options
Prism/Frost Selects prism and rotation effect
Dimmer Sets dimmer value
Shutter Sets shutter value and strobe effect
Setup
Pan Reverse OFF Normal pan operation
ON Reverse pan operation
Tilt Reverse OFF Normal tilt operation
ON Reverse tilt operation
Screen Reverse OFF Normal display
ON Reverse display
Pan Angle 540 Selects the 540° pan angle range 360 Selects the 360° pan angle range
180 Selects the 180° pan angle range
Tilt Angle 270 Selects the 270° tilt angle range 180 Selects the 180° tilt angle range
90 Selects the 90° tilt angle range
Totem Mode OFF Totem mode off UP Selects upward pan and tilt range
DOWN Selects downward pan and tilt range
Sensitivity 001–100 Sets sound sensitivity
Reset Resets the product
Factory Set Loads factory defaults
Sys Info
Ver: V_ Displays the software version
Running Mode _ _ _ _ _ _ _ Displays the current running mode
DMX Address _ _ _ Displays the current DMX address
Temperature _ _ _ Displays current temperature in °C

Page 7 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
OPERATION
Configuration (DMX)
The Intimidator Beam 355 IRC works with a DMX controller. Information about DMX is in the CHAUVET
DMX Primer, which is available from the Chauvet website http://www.chauvetlighting.com/downloads/
DMX_Primer_rev05_WO.pdf.
Starting Address
When selecting a starting DMX address, always consider the number of DMX channels the selected DMX
mode uses. If you choose a starting address that is too high, you could restrict the access to some of the
product’s channels.
The Intimidator Beam 355 IRC uses up to 14 DMX channels, which defines the highest configurable
address to 499.
If you are not familiar with the DMX protocol, download the DMX Primer from www.chauvetdj.com.
To select the starting address, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Address.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select the starting address, from 001–512.
5. Press <ENTER>.
DMX Personalities
The Intimidator Beam 355 IRC has two DMX personalities, a 14-channel personality, and a 8-channel
personality.
To choose which DMX personality to use, follow the steps below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Run Mode.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select DMX.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select the DMX personality, from 14CH or 08CH.
7. Press <ENTER>.
Gobos
0~7 8~15 16~23 24~31
32~39 40~47 48~63

Page 8 of 20
OPERATION
Intimidator Beam 355 IRC User Manual Rev. 1
DMX Channel Assignments and Values
14Ch
CHANNEL FUNCTION VALUE PERCENT/SETTING
1 Pan 000 255 0–540°
2 Fine Pan 000 255 Fine control of panning
3 Tilt 000 255 0–270°
4 Fine Tilt 000 255 Fine control of tilting
5 Pan/Tilt Speed 000 255 Pan/Tilt speed, fast to slow
6 Color Wheel
000 006 White
007 013 Yellow
014 020 Pink
021 027 Green
028 034 Red
035 041 Light Blue
042 048 Kelly Green
049 055 Orange Red
056 063 Dark Blue
064 070 White + Yellow
071 077 Yellow + Pink
078 084 Pink + Green
085 091 Green + Red
092 098 Red + Light Blue
099 105 Light Blue + Kelly Green
106 112 Kelly Green + Orange Red
113 119 Orange red + Dark Blue
120 127 Dark Blue + White
128 191 Color cycling rainbow with increasing speed
192 255 Reverse color cycling rainbow with increasing speed
7 Gobo Wheel
000 007 Open
008 015 Gobo 1
016 023 Gobo 2
024 031 Gobo 3
032 039 Gobo 4
040 047 Gobo 5
048 063 Gobo 6
064 079 Gobo 6 shake, from slow to fast
080 087 Gobo 5 shake, from slow to fast
088 095 Gobo 4 shake, from slow to fast
096 103 Gobo 3 shake, from slow to fast
104 111 Gobo 2 shake, from slow to fast
112 119 Gobo 1 shake, from slow to fast
120 127 Open
128 191 Cycle effect with increasing speed
192 255 Reverse cycling effect with increasing speed
8 No function 000 255 No function

Page 9 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
OPERATION
9 Prism/Frost
000 007 No function
008 012 Prism on
013 130 Prism rotation with increasing speed
131 247 Reverse prism rotation with increasing speed
248 255 Frost effect
10 No function 000 255 No function
11 Dimmer 000 255 0-100%
12 Shutter
000 003 Closed
004 007 Open
008 076 Strobe effect with increasing speed
077 145 Pulse strobe
146 215 Random shutter
216 255 Open
13 Control Function
000 007 No function
008 015 Blackout while pan/tilt moving
016 023 Blackout while moving color wheel
024 031 Blackout while moving gobo wheel
032 039 Blackout while pan/tilt/moving color wheel
040 047 Blackout while pan/tilt/moving gobo wheel
048 055 Blackout while pan/tilt/moving color wheel/moving gobo
wheel
056 087 No function
088 095 No function
096 103 Reset pan
104 111 Reset tilt
112 119 Reset color wheel
120 127 Reset gobo wheel
128 135 Reset Frost
136 143 Reset prism
144 151 No function
152 159 All reset
160 255 No function
CHANNEL FUNCTION VALUE PERCENT/SETTING

Page 10 of 20
OPERATION
Intimidator Beam 355 IRC User Manual Rev. 1
08Ch
14 All Programs
000 007 No function
008 023 Auto program 1
024 039 Auto program 2
040 055 Auto program 3
056 071 Auto program 4
072 087 Auto program 5
088 103 Auto program 6
104 119 Auto program 7
120 135 Auto program 8
136 151 Sound-controlled program 1
152 167 Sound-controlled program 2
168 183 Sound-controlled program 3
184 199 Sound-controlled program 4
200 215 Sound-controlled program 5
216 231 Sound-controlled program 6
232 247 Sound-controlled program 7
248 255 Sound-controlled program 8
CHANNEL FUNCTION VALUE PERCENT/SETTING
1 Pan 000 255 0–540°
2 Tilt 000 255 0–270°
3 Color Wheel
000 006 White
007 013 Yellow
014 020 Pink
021 027 Green
028 034 Red
035 041 Light Blue
042 048 Kelly Green
049 055 Orange Red
056 063 Dark Blue
064 070 White + Yellow
071 077 Yellow + Pink
078 084 Pink + Green
085 091 Green + Red
092 098 Red + Light Blue
099 105 Light Blue + Kelly Green
106 112 Kelly Green + Orange Red
113 119 Orange red + Dark Blue
120 127 Dark Blue + White
128 191 Color cycling rainbow with increasing speed
192 255 Reverse color cycling rainbow with increasing speed
CHANNEL FUNCTION VALUE PERCENT/SETTING

Page 11 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
OPERATION
4 Gobo Wheel
000 007 Open
008 015 Gobo 1
016 023 Gobo 2
024 031 Gobo 3
032 039 Gobo 4
040 047 Gobo 5
048 063 Gobo 6
064 079 Gobo 6 shake, from slow to fast
080 087 Gobo 5 shake, from slow to fast
088 095 Gobo 4 shake, from slow to fast
096 103 Gobo 3 shake, from slow to fast
104 111 Gobo 2 shake, from slow to fast
112 119 Gobo 1 shake, from slow to fast
120 127 Open
128 191 Cycle effect with increasing speed
192 255 Reverse cycling effect with increasing speed
5 No function 000 255 No function
6 Prism/Frost
000 007 No function
008 012 Prism on
013 130 Prism rotation with increasing speed
131 247 Reverse prism rotation with increasing speed
248 255 Frost effect
7 No function 000 255 No function
8 Shutter
000 003 Closed
004 007 Open
008 076 Strobe effect with increasing speed
077 145 Pulse strobe
146 215 Random shutter
216 255 Open
CHANNEL FUNCTION VALUE PERCENT/SETTING

Page 12 of 20
OPERATION
Intimidator Beam 355 IRC User Manual Rev. 1
Configuration (Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
Never connect a product that is operating in any standalone mode to a DMX string
connected to a DMX controller. Products in standalone mode may transmit DMX
signals that could interfere with the DMX signals from the controller.
Automatic Programs
To run the Intimidator Beam 355 IRC in automatic mode, follow the instructions below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Run Mode.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Auto.
5. Press <ENTER>.
Sound-Active Mode
To run the Intimidator Beam 355 IRC in sound-active mode, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Run Mode.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Sound.
5. Press <ENTER>.
Sound Sensitivity
To change the sound sensitivity on the Intimidator Beam 355 IRC, follow the instructions below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Sensitivity.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to increase or decrease the sound sensitivity, from 001–100.
7. Press <ENTER>.
The product will only respond to low frequencies of music (bass and drums).
Manual Mode
To operate the Intimidator Beam 355 IRC manually through the menu, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Run Mode.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Manual.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select from Pan, Tilt, Color, Gobo, Prism/Frost, Dimmer, or Shutter.
7. Press <ENTER>.
8. Use <UP> or <DOWN> to increase or decrease the value of the function, from 000–255.
9. Press <ENTER>.
10. Repeat steps 6-9 until the product is set as desired.

Page 13 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
OPERATION
Configuration (Settings)
Pan Reverse
To set the pan orientation on the Intimidator Beam 355 IRC, follow the instructions below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Pan Reverse.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select OFF (normal pan orientation) or ON (reverse pan orientation).
7. Press <ENTER>.
Tilt Reverse
To set the tilt orientation on the Intimidator Beam 355 IRC, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Tilt Reverse.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select OFF (normal tilt orientation) or ON (reverse tilt orientation).
7. Press <ENTER>.
Screen Reverse
To set the display orientation on the Intimidator Beam 355 IRC, follow the instructions below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Screen Reverse.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select OFF (normal display orientation) or ON (reverse display
orientation).
7. Press <ENTER>.
Pan Angle
To set the pan angle range on the Intimidator Beam 355 IRC, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Pan Angle.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select from 540 (540°), 360 (360°), or 180 (180°).
7. Press <ENTER>.
Tilt Angle
To set the tilt angle range on the Intimidator Beam 355 IRC, follow the instructions below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Tilt Angle.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select from 270 (270°), 180 (180°), or 90 (90°).
7. Press <ENTER>.

Page 14 of 20
OPERATION
Intimidator Beam 355 IRC User Manual Rev. 1
Totem Mode
To activate the Totem mode, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Totem Mode.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select OFF (normal range of motion), UP (upward tilt range), or DOWN
(downward tilt range).
7. Press <ENTER>.
Reset
To reset all functions on the Intimidator Beam 355 IRC, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Reset.
5. Press <ENTER>.
Factory Reset
To restore the Intimidator Beam 355 IRC to factory default settings, follow the instructions below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Setup.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Factory Set.
5. Press <ENTER>.
System Information
To view the system information on the Intimidator Beam 355 IRC, do the following:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Sys Info.
3. Press <ENTER>.

Page 15 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
OPERATION
IRC-6 Infrared Remote Control
The Intimidator Beam 355 IRC is compatible with the IRC-6 infrared remote control from Chauvet. To set
the Intimidator Beam 355 IRC to IR mode, follow the instructions below:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Run Mode.
3. Press <ENTER>.
4. Press <UP> or <DOWN> to select IR.
5. Press <ENTER>.
IRC-6 Operation The list below describes which features each button controls:
•<BLACKOUT> - Keeps shutter closed.
•<AUTO> -Activates Auto mode. Use <+>, <->, or <0>–<9> to select an auto
program.
•<SOUND> - Activates Sound mode.
•<STROBE> - Activates Strobe control. Use <+> or <-> to increase or decrease
the strobe speed from 00 (off) to 20
•<SPEED> - Sets Pan/Tilt Speed. Use <+> or <-> to increase or decrease the pan/
tilt speed from 000 (fastest) to 255 (slowest)
•<SENSITIVITY>-SetsSoundSensitivity.Use<+> or<-> to increaseordecrease
the sensitivity from 001 (lowest) to 100 (highest)
•<%> - Sets Dimmer value. Use <+> or <-> to widen or narrow the shutter.
•<MANUAL> - Cycles through static gobos.
•<FADE> - Cycles through static colors.
•<R> - Sets color wheel rotation speed. Use <+> or <-> to increase or decrease
the speed from 000 (slowest) to 100 (fastest). Press <R> to toggle direction.
•<G> - Sets gobo wheel rotation speed. Use <+> or <-> to increase or decrease
the speed from 000 (slowest) to 100 (fastest). Press <G> to toggle direction.
•<B> - Activates Auto Color/Gobo mode.
•<A> -Sets manual Pan/Tiltvalues. Press <A> to togglebetween pan andtilt. Use
<+> or <-> to increase or decrease the pan/tilt value, from 000–255.
•<W> - Sets manual Prism/Frost values. Use <+> or <-> to increase or decrease
the prism/frost value, from 000–255.
•<+> - Increases a value when in a function.
•<-> - Decreases a value when in a function.
•<0>–<9> - Selects Auto programs 0–9.

Page 16 of 20
OPERATION
Intimidator Beam 355 IRC User Manual Rev. 1
Master/Slave Mode
The Master/Slave mode allows a single Intimidator Beam 355 IRC product (the “master”) to control the
actions of one or more Intimidator Beam 355 IRC products (the “slaves”) without the need of a DMX
controller. The master product will be set to operate in either Stand-Alone mode or with the IRC-6, while
the slave products will be set to operate in Slave mode. Once set and connected, the slave products will
operate in unison with the master product.
Configure the products as indicated below.
Slave products:
1. Press <MENU>.
2. Use <UP> or <DOWN> to select Run Mode.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to select Slave.
5. Press <ENTER>.
6. Use <UP> or <DOWN> to select from Slave1, Slave2, Slave3, or Slave4.
• Select Slave1 for 100% synchronized actions.
• Select Slave2, Slave3, or Slave4 for a delayed show, creating a wave effect.
7. Connect the DMX input of the first slave product to the DMX output of the master product.
8. Connect the DMX input of the subsequent slave products to the DMX output of the previous slave
product.
9. Finish setting and connecting all the slave products.
Master product:
1. Set the master product to operate in Stand-Alone mode or with the IRC-6.
2. Make the master product the first product in the DMX daisy chain.
• Configure all the slave products before connecting the master to the daisy chain.
• Never connect a DMX controller to a DMX string configured for Master/Slave
operation because the controller may interfere with the signals from the master.
• Do not connect more than 31 slaves to the master.
Zero Adjust Mode
The Intimidator Beam 355 IRC contains a passcode protected mode which allows the user to calibrate and
adjust several of the product’s operating parameters.
In order to access this mode, do the following:
1. Press and hold <MENU> for at least 3 seconds.
2. Use <UP> (increases the selected value) and <DOWN> (selects the next value) to enter the
passcode: 2323.
3. Press <ENTER>.
In this mode, the starting positions for the following can be adjusted:
PARAMETER DEFAULT FUNCTION
PAN 147 Pan motor
TILT 128 Tilt motor
COLOR 128 Color wheel
GOBO 128 Gobo wheel
PRISM 128 Prism assembly
DIMMER 070 Shutter assembly
To adjust the starting position of one of these parameters, follow the instructions below:
1. Access the Zero Adjust mode.
2. Use <UP> or <DOWN> to select the parameter to be adjusted.
3. Press <ENTER>.
4. Use <UP> or <DOWN> to increase or decrease the selected value, from 000–255.
5. Press <ENTER>.

Page 17 of 20
Intimidator Beam 355 IRC User Manual Rev. 1
MAINTENANCE
5. MAINTENANCE
Product Maintenance
Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of
the light source’s life and/or mechanical wear. To maintain optimum performance and minimize wear, clean
your lighting products at least twice a month. However, be aware that usage and environmental conditions
could be contributing factors to increase the cleaning frequency.
To clean the product, follow the instructions below:
1. Unplug the product from power.
2. Wait until the product is at room temperature.
3. Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on the external
surface/vents.
4. Clean all transparent surfaces with a mild soap solution, ammonia-free glass cleaner, or isopropyl
alcohol.
5. Apply the solution directly to a soft, lint free cotton cloth or a lens cleaning tissue.
6. Softly drag any dirt or grime to the outside of the transparent surface.
7. Gently polish the transparent surfaces until they are free of haze and lint.
Always dry the transparent surfaces carefully after cleaning them.

Page 18 of 20
TECHNICAL SPECIFICATIONS
Intimidator Beam 355 IRC User Manual Rev. 1
6. TECHNICAL SPECIFICATIONS
Dimensions and Weight
LENGTH WIDTH HEIGHT WEIGHT
12.7 in (322 mm) 8.7 in (220 mm) 18.9 in (480 mm) 25.4 lb (11.6 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power POWER SUPPLY TYPE RANGE VOLTAGE SELECTION
Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging
PARAMETER 120 V, 60 HZ230 V, 50 HZ
Consumption 163 W 157 W
Operating Current 1.5 A 0.8 A
Power linking current (products) 13.6 A (5 products) 13.6 A (9 products)
Fuse F 3 A, 250 V F 3 A, 250 V
POWER I/O U.S./WORLDWIDE UK/EUROPE
Power input connector powerCON®-compatible powerCON®-compatible
Power output connector powerCON®-compatible powerCON®-compatible
Power Cord plug Edison (U.S.) Local Plug
Light Source
TYPE COLOR QUANTITY POWER CURRENT LIFESPAN
LED White 1 100 W 27 A 50,000 hours
Photometrics
STROBE RATE BEAM ANGLE ILLUMINANCE @ 2 M
0 to 20 Hz 3° 262,800 lux
Thermal
MAXIMUM EXTERNAL TEMPERATURE COOLING SYSTEM
104 °F (40 °C) Fan-assisted convection
DMX I/O CONNECTOR CHANNEL RANGE
3-pin XLR 8 or 14
OrderingPRODUCT NAME ITEM CODE UPC NUMBER
Intimidator Beam 355 IRC 09011369 781462217174
