Chauvet COLORdash Batten-Hex 8 User manual

Quick Reference Guide
English EN
Español ES
Français FR

COLORdash™ Batten-Hex 8 QRG EN
2
About this
Guide
The COLORdash™ Batten-Hex 8 Quick Reference Guide (QRG) has basic
product information such as connection, mounting, menu options, and DMX
values. Download the User Manual from www.chauvetpro.com
for more
details.
Disclaimer
The information and specifications contained in this QRG are subject to change
without notice.
Safety Notes
•DO NOT open this product. It contains no user-serviceable parts.
•DO NOT look at the light source when the product is on.
•CAUTION: This product’s housing may be hot when lights are
operating.
•Mount this product in a location with adequate ventilation, at least
20 in (50 cm) from adjacent surfaces.
•DO NOT leave any flammable material within 50 cm of this product
while operating or connected to power.
•USE a safety cable (included) when mounting this product overhead.
•DO NOT operate this product outdoors or in any location where dust,
excessive heat, water, or humidity may affect it. (IP20)
•DO NOT operate this product if the housing, lenses, or cables appear
damaged.
•DO NOT connect this product to a dimmer or rheostat.
•ONLY connect this product to a grounded and protected circuit.
•ONLY use the hanging/mounting bracket to carry this product.
•In the event of a serious operating problem, stop using immediately.
•The maximum ambient temperature is 113 °F (45 °C). Do not operate
this product at higher temperatures.
Contact
Outside the U.S., United Kingdom, Ireland, or Mexico, contact your distributor
to request support or return a product. Visit www.chauvetpro.com
for contact
information.
What is
Included
•COLORdash™ Batten-Hex 8
•Neutrik® powerCON power
cord
•Safety Cable
•Warranty Card
•Quick Reference Guide

EN COLORdash™ Batten-Hex 8 QRG
3
AC Power
This product has an auto-ranging power supply that can work with an input
voltage range of 100 to 240 VAC, 50/60 Hz.
Power Linking
You can link up to 11 COLORdash™ Batten-Hex 8 products at 120 V, 19
products at 208 V, or 20 products
at 230 V. Never exceed this number. Power
linking cords can be purchased separately.
AC Plug
Connection
Wire (U.S.)
Wire (Europe)
Screw Color
AC Live
Black
Brown
Yellow/Brass
AC Neutral
White
Blue
Silver
AC Ground
Green/Yellow
Green/Yellow
Green
Replacing the
Fuse
1. Disconnect this product from power.
2. Using a flat-head screwdriver, unscrew the fuse holder cap from the
housing.
3. Remove blown fuse and replace
with a good fuse of the same type and
rating.
4. Screw the fuse holder cap back in place and reconnect power.
DMX Linking
The COLORdash™ Batten-Hex 8 will work with a DMX controller using a
regular DMX serial connection. A DMX Primer is available from
www.chauvetpro.com.
DMX Connection
The COLORdash™ Batten-Hex 8 uses a regular DMX data connection for its
DMX personalities: 6 Ch, 8 Ch, 12Ch, 13Ch, 48Ch, 53Ch, 68Ch-A
,
68Ch-W, 96Ch, HSV, and HSI
. See the User Manual to connect and configure
for DMX operation.
Note:
For optimum control of the 16-bit dimming channels in the
13Ch
,
68Ch-A, 68Ch-W, and 96Ch personalities, be sure that Dim mode is set to Off.
Master/Slave
Connection
The COLORdash™ Batten-Hex 8 uses the DMX data connection for its
Master/Slave mode. See the User Manual to connect and configure for
master/slave operation.

COLORdash™ Batten-Hex 8 QRG EN
4
Mounting
Product
Mounting
Diagram
Control Panel
Description
Button
Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the
currently selected value into the selected function
<UP>
Navigates upwards through the menu list and
increases the numeric value when in a function
<DOWN>
Navigates downwards through the menu list and
decreases the numeric value when in a function
Overhead Mounting
Floor Mounting
Mounting Clamp
(such as CLP-15 or CLP-15N
clamp
from CHAUVET®)
Safety Cable
(such as CH-05 cable from
CHAUVET®)

EN COLORdash™ Batten-Hex 8 QRG
5
Menu Options
Main Level
Programming Levels
Description
Auto
Auto 0–12
Speed 0–100
Automatic programs
Fade
Selects rolling fade effect
Static Fix C
R
Red
G
Green
B
Blue
A
Amber
W
White
P
Ultraviolet (UV)
RG
Red/Green
RB
Red/Blue
RA
Red/Amber
RW
Red/White
RP
Red/UV
GB
Green/Blue
GA
Green/Amber
GW
Green/White
GP
Green/UV
BA
Blue/Amber
BW
Blue/White
BP
Blue/UV
AW
Amber/White
AP
Amber/UV
WP
White/UV
RGB
Red/Green/Blue
RGA
Red/Green/Amber
RGW
Red/Green/White
RGP
Red/Green/UV
RBA
Red/Blue/Amber
RBW
Red/Blue/White
RBP
Red/Blue/UV
RAW
Red/Amber/White
RAP
Red/Amber/UV
RWP
Red/White/UV
GBA
Green/Blue/Amber
GBW
Green/Blue/White
GBP
Green/Blue/UV
BAW
Blue/Amber/White
BAP
Blue/Amber/UV
AWP
Amber/White/UV
BWP
Blue/White/UV
GAW
Green/Amber/White
GAP
Green/Amber/UV
GWP
Green/White/UV
RGBA
Red/Green/Blue/Amber
RGBW
Red/Green/Blue/White
RGBP
Red/Green/Blue/UV
RGAW
Red/Green/Amber/White

COLORdash™ Batten-Hex 8 QRG EN
6
Menu Options (cont.)
Main Level
Programming Levels
Description
Static (cont.)
Fix C (cont.)
RGAP
Red/Green/Amber/UV
RGWP
Red/Green/White/UV
RBAW
Red/Blue/Amber/White
RBAP
Red/Blue/Amber/UV
RBWP
Red/Blue/White/UV
RAWP
Red/Amber/White/UV
GBAW
Green/Blue/Amber/White
GBAP
Green/Blue/Amber/UV
GBWP
Green/Blue/White/UV
GAWP
Green/Amber/White/UV
BAWP
Blue/Amber/White/UV
RGBAW
Red/Green/Blue/Amber/White
RGBAP
Red/Green/Blue/Amber/UV
RGBWP
Red/Green/Blue/White/UV
RGAWP
Red/Green/Amber/White/UV
RBAWP
Red/Blue/Amber/White/UV
GBAWP
Green/Blue/Amber/White/UV
RGBAWP
Red/Green/Blue/Amber/White/UV
Manu C
R
Value 0–255 Combine red, green, blue, amber, white,
and UV to create a custom color
(0–100%)
G
B
A
W
P
Dim Mode
Off
No dimmer
DIM 1–3
Dimming curves DIM 1 (fast) to
DIM 3 (slow)
BackLite
10S
Turns off display backlight after 10 sec of
inactivity
20S
Turns off display backlight after 20 sec of
inactivity
30S
Turns off display backlight after 30 sec of
inactivity
On
Display backlight always on
Info
Auto
Test
Turns on all LEDs in sequence for testing
FixHours
Shows total product hours
Version
Shows installed software version
Address 001–510
Selects DMX address (highest channel
restricted to personality chosen)

EN COLORdash™ Batten-Hex 8 QRG
7
Menu Options (cont.)
Main Level
Programming Levels
Description
Channel
6 Ch
6-channel: RGBAW+UV control
8 CH
8-channel: dimmer, RGBAW+UV, strobe
12Ch
12-channel: dimmer, RGBW+UV, strobe,
color macro/white balance, auto
programs, auto speed, dimmer speed
13Ch
13-channel: 16-bit RGBAW+UV, dimmer
speed
48Ch
48-channel: RGBAW+UV pixel control
53Ch
53-channel: RGBAW+UV pixel control,
auto programs, auto speed, strobe,
dimmer, dimmer speed
68Ch-A
68-channel amber: 16-bit RGBA pixel
control, W+UV
68Ch-W
68-channel white: 16-bit RGBW pixel
control, A+UV
96Ch
96-channel: 16-bit RGBAW+UV pixel
control
HSV
3-channel: HSV control
HSI
3-channel: HSI control
M &S Mode
Master
DMX mode (Master)
Slave
Slave mode
White Balance
R
Value 125–255
Sets red LED maximum value
G
Sets green LED maximum value
B
Sets blue LED maximum value
Temp
XX° C
Shows product’s temperature (°C)
COLORdash™ Batten-Hex 8 Sections for DMX Control
The diagram below shows the sections used in the 48Ch, 53Ch, 68Ch-A,
68Ch-W and 96Ch DMX modes.
1
2
3
4
5
6
7
8

COLORdash™ Batten-Hex 8 QRG EN
8
DMX Values
68Ch-A
Channel
Function
Value
Percent/Setting
1
Red1
000 ó255
0–100%
2
Fine Red1
000 ó255
Fine control (16-bit)
3
Green1
000 ó255
0–100%
4
Fine Green1
000 ó255
Fine control (16-bit)
5
Blue1
000 ó255
0–100%
6
Fine Blue1
000 ó255
Fine control (16-bit)
7
Amber1
000 ó255
0–100%
8
Fine Amber1
000 ó255
Fine control (16-bit)
9
Red2
000 ó255
0–100%
10
Fine Red2
000 ó255
Fine control (16-bit)
11
Green2
000 ó255
0–100%
12
Fine Green2
000 ó255
Fine control (16-bit)
13
Blue2
000 ó255
0–100%
14
Fine Blue2
000 ó255
Fine control (16-bit)
15
Amber2
000 ó255
0-100%
16
Fine Amber2
000 ó255
Fine control (16-bit)
17
Red3
000 ó255
0–100%
18
Fine Red3
000 ó255
Fine control (16-bit)
19
Green3
000 ó255
0–100%
20
Fine Green3
000 ó255
Fine control (16-bit)
21
Blue3
000 ó255
0–100%
22
Fine Blue3
000 ó255
Fine control (16-bit)
23
Amber3
000 ó255
0–100%
24
Fine Amber3
000 ó255
Fine control (16-bit)
25
Red4
000 ó255
0–100%
26
Fine Red4
000 ó255
Fine control (16-bit)
27
Green4
000 ó255
0–100%
28
Fine Green4
000 ó255
Fine control (16-bit)
29
Blue4
000 ó255
0–100%
30
Fine Blue4
000 ó255
Fine control (16-bit)
31
Amber4
000 ó255
0–100%
32
Fine Amber4
000 ó255
Fine control (16-bit)
33
Red5
000 ó255
0–100%
34
Fine Red5
000 ó255
Fine control (16-bit)
35
Green5
000 ó255
0–100%
36
Fine Green5
000 ó255
Fine control (16-bit)
37
Blue5
000 ó255
0–100%
38
Fine Blue5
000 ó255
Fine control (16-bit)
39
Amber5
000 ó255
0–100%
40
Fine Amber5
000 ó255
Fine control (16-bit)
41
Red6
000 ó255
0–100%
42
Fine Red6
000 ó255
Fine control (16-bit)
43
Green6
000 ó255
0–100%
44
Fine Green6
000 ó255
Fine control (16-bit)
45
Blue6
000 ó255
0–100%
46
Fine Blue6
000 ó255
Fine control (16-bit)
47
Amber6
000 ó255
0-100%
48
Fine Amber6
000 ó255
Fine control (16-bit)

EN COLORdash™ Batten-Hex 8 QRG
9
DMX Values (cont.)
68Ch-A
(cont.)
Channel
Function
Value
Percent/Setting
49
Red7
000 ó255
0–100%
50
Fine Red7
000 ó255
Fine control (16-bit)
51
Green7
000 ó255
0–100%
52
Fine Green7
000 ó255
Fine control (16-bit)
53
Blue7
000 ó255
0–100%
54
Fine Blue7
000 ó255
Fine control (16-bit)
55
Amber7
000 ó255
0–100%
56
Fine Amber7
000 ó255
Fine control (16-bit)
57
Red8
000 ó255
0–100%
58
Fine Red8
000 ó255
Fine control (16-bit)
59
Green8
000 ó255
0–100%
60
Fine Green8
000 ó255
Fine control (16-bit)
61
Blue8
000 ó255
0–100%
62
Fine Blue8
000 ó255
Fine control (16-bit)
63
Amber8
000 ó255
0–100%
64
Fine Amber8
000 ó255
Fine control (16-bit)
65
White (all)
000 ó255
0–100%
66
Fine White (all)
000 ó255
Fine control (16-bit)
67
UV (all)
000 ó255
0–100%
68
Fine UV (all)
000 ó255
Fine control (16-bit)
68Ch-W
Channel
Function
Value
Percent/Setting
1
Red1
000 ó255
0–100%
2
Fine Red1
000 ó255
Fine control (16-bit)
3
Green1
000 ó255
0–100%
4
Fine Green1
000 ó255
Fine control (16-bit)
5
Blue1
000 ó255
0–100%
6
Fine Blue1
000 ó255
Fine control (16-bit)
7
White1
000 ó255
0–100%
8
Fine White1
000 ó255
Fine control (16-bit)
9
Red2
000 ó255
0–100%
10
Fine Red2
000 ó255
Fine control (16-bit)
11
Green2
000 ó255
0–100%
12
Fine Green2
000 ó255
Fine control (16-bit)
13
Blue2
000 ó255
0–100%
14
Fine Blue2
000 ó255
Fine control (16-bit)
15
White2
000 ó255
0-100%
16
Fine White2
000 ó255
Fine control (16-bit)
17
Red3
000 ó255
0–100%
18
Fine Red3
000 ó255
Fine control (16-bit)
19
Green3
000 ó255
0–100%
20
Fine Green3
000 ó255
Fine control (16-bit)
21
Blue3
000 ó255
0–100%
22
Fine Blue3
000 ó255
Fine control (16-bit)
23
White3
000 ó255
0–100%
24
Fine White3
000 ó255
Fine control (16-bit)

COLORdash™ Batten-Hex 8 QRG EN
10
DMX Values (cont.)
68Ch-W
(cont.)
Channel
Function
Value
Percent/Setting
25
Red4
000 ó255
0–100%
26
Fine Red4
000 ó255
Fine control (16-bit)
27
Green4
000 ó255
0–100%
28
Fine Green4
000 ó255
Fine control (16-bit)
29
Blue4
000 ó255
0–100%
30
Fine Blue4
000 ó255
Fine control (16-bit)
31
White4
000 ó255
0–100%
32
Fine White4
000 ó255
Fine control (16-bit)
33
Red5
000 ó255
0–100%
34
Fine Red5
000 ó255
Fine control (16-bit)
35
Green5
000 ó255
0–100%
36
Fine Green5
000 ó255
Fine control (16-bit)
37
Blue5
000 ó255
0–100%
38
Fine Blue5
000 ó255
Fine control (16-bit)
39
White5
000 ó255
0–100%
40
Fine White5
000 ó255
Fine control (16-bit)
41
Red6
000 ó255
0–100%
42
Fine Red6
000 ó255
Fine control (16-bit)
43
Green6
000 ó255
0–100%
44
Fine Green6
000 ó255
Fine control (16-bit)
45
Blue6
000 ó255
0–100%
46
Fine Blue6
000 ó255
Fine control (16-bit)
47
White6
000 ó255
0-100%
48
Fine White6
000 ó255
Fine control (16-bit)
49
Red7
000 ó255
0–100%
50
Fine Red7
000 ó255
Fine control (16-bit)
51
Green7
000 ó255
0–100%
52
Fine Green7
000 ó255
Fine control (16-bit)
53
Blue7
000 ó255
0–100%
54
Fine Blue7
000 ó255
Fine control (16-bit)
55
White7
000 ó255
0–100%
56
Fine White7
000 ó255
Fine control (16-bit)
57
Red8
000 ó255
0–100%
58
Fine Red8
000 ó255
Fine control (16-bit)
59
Green8
000 ó255
0–100%
60
Fine Green8
000 ó255
Fine control (16-bit)
61
Blue8
000 ó255
0–100%
62
Fine Blue8
000 ó255
Fine control (16-bit)
63
White8
000 ó255
0–100%
64
Fine White8
000 ó255
Fine control (16-bit)
65
Amber (all)
000 ó255
0–100%
66
Fine Amber (all)
000 ó255
Fine control (16-bit)
67
UV (all)
000 ó255
0–100%
68
Fine UV (all)
000 ó255
Fine control (16-bit)

EN COLORdash™ Batten-Hex 8 QRG
11
DMX Values (cont.)
53Ch
Channel
Function
Value
Percent/Setting
1
Red 1
000 ó255
0–100%
2
Green 1
000 ó255
0–100%
3
Blue 1
000 ó255
0–100%
4
Amber 1
000 ó255
0–100%
5
White 1
000 ó255
0–100%
6
UV 1
000 ó255
0–100%
7
Red 2
000 ó255
0–100%
8
Green 2
000 ó255
0–100%
9
Blue 2
000 ó255
0–100%
10
Amber 2
000 ó255
0–100%
11
White 2
000 ó255
0–100%
12
UV 2
000 ó255
0–100%
13
Red 3
000 ó255
0–100%
14
Green 3
000 ó255
0–100%
15
Blue 3
000 ó255
0–100%
16
Amber 3
000 ó255
0–100%
17
White 3
000 ó255
0–100%
18
UV 3
000 ó255
0–100%
19
Red 4
000 ó255
0–100%
20
Green 4
000 ó255
0–100%
21
Blue 4
000 ó255
0–100%
22
Amber 4
000 ó255
0–100%
23
White 4
000 ó255
0–100%
24
UV 4
000 ó255
0–100%
25
Red 5
000 ó255
0–100%
26
Green 5
000 ó255
0–100%
27
Blue 5
000 ó255
0–100%
28
Amber 5
000 ó255
0–100%
29
White 5
000 ó255
0–100%
30
UV 5
000 ó255
0–100%
31
Red 6
000 ó255
0–100%
32
Green 6
000 ó255
0–100%
33
Blue 6
000 ó255
0–100%
34
Amber 6
000 ó255
0–100%
35
White 6
000 ó255
0–100%
36
UV 6
000 ó255
0–100%
37
Red 7
000 ó255
0–100%
38
Green 7
000 ó255
0–100%
39
Blue 7
000 ó255
0–100%
40
Amber 7
000 ó255
0–100%
41
White 7
000 ó255
0–100%
42
UV 7
000 ó255
0–100%
43
Red 8
000 ó255
0–100%
44
Green 8
000 ó255
0–100%
45
Blue 8
000 ó255
0–100%
46
Amber 8
000 ó255
0–100%
47
White 8
000 ó255
0–100%
48
UV 8
000 ó255
0–100%

COLORdash™ Batten-Hex 8 QRG EN
12
DMX Values (cont.)
53Ch
(cont.)
Channel
Function
Value
Percent/Setting
49 Auto Programs
000 ó010
011 ó027
028 ó044
045 ó061
062 ó078
079 ó095
096 ó112
113 ó129
130 ó146
147 ó163
164 ó180
181 ó197
198 ó214
215 ó231
232 ó255
No function
Auto program 1
Auto program 2
Auto program 3
Auto program 4
Auto program 5
Auto program 6
Auto program 7
Auto program 8
Auto program 9
Auto program 10
Auto program 11
Auto program 12
Fade program
Random auto program (Auto 1–12)
50
Auto Speed
000 ó255
Slow to fast (when channel 49 is 011–255)
51
Dimmer
000 ó255
0–100%
52 Strobe
000 ó010
011 ó255
No function
0–20 Hz
53 Dimmer Speed
000 ó051
052 ó101
102 ó152
153 ó203
204 ó255
Preset dimmer speed from display menu
Dimming curve off (linear dimmer)
Nonlinear dimming curve 1 (fastest)
Nonlinear dimming curve 2
Nonlinear dimming curve 3 (slowest)

EN COLORdash™ Batten-Hex 8 QRG
13
DMX Values (cont.)
48 Ch
Channel
Function
Value
Percent/Setting
1
Red 1
000 ó255
0–100%
2
Green 1
000 ó255
0–100%
3
Blue 1
000 ó255
0–100%
4
Amber 1
000 ó255
0–100%
5
White 1
000 ó255
0–100%
6
UV 1
000 ó255
0–100%
7
Red 2
000 ó255
0–100%
8
Green 2
000 ó255
0–100%
9
Blue 2
000 ó255
0–100%
10
Amber 2
000 ó255
0–100%
11
White 2
000 ó255
0–100%
12
UV 2
000 ó255
0–100%
13
Red 3
000 ó255
0–100%
14
Green 3
000 ó255
0–100%
15
Blue 3
000 ó255
0–100%
16
Amber 3
000 ó255
0–100%
17
White 3
000 ó255
0–100%
18
UV 3
000 ó255
0–100%
19
Red 4
000 ó255
0–100%
20
Green 4
000 ó255
0–100%
21
Blue 4
000 ó255
0–100%
22
Amber 4
000 ó255
0–100%
23
White 4
000 ó255
0–100%
24
UV 4
000 ó255
0–100%
25
Red 5
000 ó255
0–100%
26
Green 5
000 ó255
0–100%
27
Blue 5
000 ó255
0–100%
28
Amber 5
000 ó255
0–100%
29
White 5
000 ó255
0–100%
30
UV 5
000 ó255
0–100%
31
Red 6
000 ó255
0–100%
32
Green 6
000 ó255
0–100%
33
Blue 6
000 ó255
0–100%
34
Amber 6
000 ó255
0–100%
35
White 6
000 ó255
0–100%
36
UV 6
000 ó255
0–100%
37
Red 7
000 ó255
0–100%
38
Green 7
000 ó255
0–100%
39
Blue 7
000 ó255
0–100%
40
Amber 7
000 ó255
0–100%
41
White 7
000 ó255
0–100%
42
UV 7
000 ó255
0–100%
43
Red 8
000 ó255
0–100%
44
Green 8
000 ó255
0–100%
45
Blue 8
000 ó255
0–100%
46
Amber 8
000 ó255
0–100%
47
White 8
000 ó255
0–100%
48
UV 8
000 ó255
0–100%

COLORdash™ Batten-Hex 8 QRG EN
14
DMX Values (cont.)
13Ch
Channel
Function
Value
Percent/Setting
1
Red
000 ó255
0–100%
2
Fine Red
000 ó255
Fine control (16-bit)
3
Green
000 ó255
0–100%
4
Fine Green
000 ó255
Fine control (16-bit)
5
Blue
000 ó255
0–100%
6
Fine Blue
000 ó255
Fine control (16-bit)
7
Amber
000 ó255
0–100%
8
Fine Amber
000 ó255
Fine control (16-bit)
9
White
000 ó255
0–100%
10
Fine White
000 ó255
Fine control (16-bit)
11
UV
000 ó255
0–100%
12
Fine UV
000 ó255
Fine control (16-bit)
13 Dimmer Speed
000 ó051
052 ó101
102 ó152
153 ó203
204 ó255
Preset dimmer speed from display menu
Dimming curve off (linear dimmer)
Nonlinear dimming curve 1 (fastest)
Nonlinear dimming curve 2
Nonlinear dimming curve 3 (slowest)
8 Ch
Channel
Function
Value
Percent/Setting
1
Dimmer
000 ó255
0–100%
2
Red
000 ó255
0–100%
3
Green
000 ó255
0–100%
4
Blue
000 ó255
0–100%
5
Amber
000 ó255
0–100%
6
White
000 ó255
0–100%
7
UV
000 ó255
0–100%
8 Strobe
000 ó010
010 ó255
No function
0-20 Hz
6 Ch
Channel
Function
Value
Percent/Setting
1
Red
000 ó255
0–100%
2
Green
000 ó255
0–100%
3
Blue
000 ó255
0–100%
4
Amber
000 ó255
0–100%
5
White
000 ó255
0–100%
6
UV
000 ó255
0–100%
HSV
Channel
Function
Value
Percent/Setting
1
Hue
000 ó255
0–100%
2
Saturation
000 ó255
0–100%
3
Value
000 ó255
0–100%
HSI
Channel
Function
Value
Percent/Setting
1
Hue
000 ó255
0–100%
2
Saturation
000 ó255
0–100%
3
Intensity
000 ó255
0–100%

EN COLORdash™ Batten-Hex 8 QRG
15
DMX Values (cont.)
12Ch
Channel
Function
Value
Percent/Setting
1
Dimmer
000 ó255
0–100%
2
Red
000 ó255
0–100%
3
Green
000 ó255
0–100%
4
Blue
000 ó255
0–100%
5
Amber
000 ó255
0–100%
6
White
000 ó255
0–100%
7
UV
000 ó255
0–100%
8 Strobe
000 ó010
011 ó255
No function
0–20 Hz
9 Color Macro +
White Balance
000 ó010
011 ó030
031 ó050
051 ó070
071 ó090
091 ó110
111 ó130
131 ó150
151 ó170
171 ó200
201 ó205
206 ó210
211 ó215
216 ó220
221 ó225
226 ó230
231 ó235
236 ó240
241 ó245
246 ó250
251 ó255
No function
R: 100% G: 0–100% B: 0
R: 100%–0 G: 100% B: 0
R: 0 G: 100% B: 0–100%
R: 0 G: 100%–0 B: 100%
R: 0–100% G: 0 B: 100%
R: 100% G: 0 B: 100%–0
R: 100% G: 0–100% B: 0–100%
R: 100%–0 G: 100%–0 B: 100%
R: 100% G: 100% B: 100% A: 100%
White 1
White 2
White 3
White 4
White 5
White 6
White 7
White 8
White 9
White 10
White 11
10 Auto Programs
000 ó010
011 ó027
028 ó044
045 ó061
062 ó078
079 ó095
096 ó112
113 ó129
130 ó146
147 ó163
164 ó180
181 ó197
198 ó214
215 ó231
232
ó
255
No function
Auto program 1
Auto program 2
Auto program 3
Auto program 4
Auto program 5
Auto program 6
Auto program 7
Auto program 8
Auto program 9
Auto program 10
Auto program 11
Auto program 12
Fade program
Random auto program (Auto 1–12)
11
Auto Speed
000 ó255
Slow to fast (when channel 10 is 011–255)
12 Dimmer Speed
000 ó051
052 ó101
102 ó152
153 ó203
204 ó255
Preset dimmer speed from display menu
Dimmer curve off (linear dimmer)
Nonlinear dimming curve 1 (fastest)
Nonlinear dimming curve 2
Nonlinear dimming curve 3 (slowest)

COLORdash™ Batten-Hex 8 QRG EN
16
DMX Values (cont.)
96Ch
Channel
Function
Value
Percent/Setting
1
Red1
000 ó255
0–100%
2
Fine Red1
000 ó255
Fine control (16-bit)
3
Green1
000 ó255
0–100%
4
Fine Green1
000 ó255
Fine control (16-bit)
5
Blue1
000 ó255
0–100%
6
Fine Blue1
000 ó255
Fine control (16-bit)
7
Amber1
000 ó255
0–100%
8
Fine Amber1
000 ó255
Fine control (16-bit)
9
White1
000 ó255
0–100%
10
Fine White1
000 ó255
Fine control (16-bit)
11
UV1
000 ó255
0–100%
12
Fine UV1
000 ó255
Fine control (16-bit)
13
Red2
000 ó255
0–100%
14
Fine Red2
000 ó255
Fine control (16-bit)
15
Green2
000 ó255
0–100%
16
Fine Green2
000 ó255
Fine control (16-bit)
17
Blue2
000 ó255
0–100%
18
Fine Blue2
000 ó255
Fine control (16-bit)
19
Amber2
000 ó255
0–100%
20
Fine Amber2
000 ó255
Fine control (16-bit)
21
White2
000 ó255
0–100%
22
Fine White2
000 ó255
Fine control (16-bit)
23
UV2
000 ó255
0–100%
24
Fine UV2
000 ó255
Fine control (16-bit)
25
Red3
000 ó255
0–100%
26
Fine Red3
000 ó255
Fine control (16-bit)
27
Green3
000 ó255
0–100%
28
Fine Green3
000 ó255
Fine control (16-bit)
29
Blue3
000 ó255
0–100%
30
Fine Blue3
000 ó255
Fine control (16-bit)
31
Amber3
000 ó255
0–100%
32
Fine Amber3
000 ó255
Fine control (16-bit)
33
White3
000 ó255
0–100%
34
Fine White3
000 ó255
Fine control (16-bit)
35
UV3
000 ó255
0–100%
36
Fine UV3
000 ó255
Fine control (16-bit)
37
Red4
000 ó255
0–100%
38
Fine Red4
000 ó255
Fine control (16-bit)
39
Green4
000 ó255
0–100%
40
Fine Green4
000 ó255
Fine control (16-bit)
41
Blue4
000 ó255
0–100%
42
Fine Blue4
000 ó255
Fine control (16-bit)
43
Amber4
000 ó255
0–100%
44
Fine Amber4
000 ó255
Fine control (16-bit)
45
White4
000 ó255
0–100%
46
Fine White4
000 ó255
Fine control (16-bit)
47
UV4
000 ó255
0–100%
48
Fine UV4
000 ó255
Fine control (16-bit)

EN COLORdash™ Batten-Hex 8 QRG
17
DMX Values (cont.)
96Ch
(cont.)
Channel
Function
Value
Percent/Setting
49
Red5
000 ó255
0–100%
50
Fine Red5
000 ó255
Fine control (16-bit)
51
Green5
000 ó255
0–100%
52
Fine Green5
000 ó255
Fine control (16-bit)
53
Blue5
000 ó255
0–100%
54
Fine Blue5
000 ó255
Fine control (16-bit)
55
Amber5
000 ó255
0–100%
56
Fine Amber5
000 ó255
Fine control (16-bit)
57
White5
000 ó255
0–100%
58
Fine White5
000 ó255
Fine control (16-bit)
59
UV5
000 ó255
0–100%
60
Fine UV5
000 ó255
Fine control (16-bit)
61
Red6
000 ó255
0–100%
62
Fine Red6
000 ó255
Fine control (16-bit)
63
Green6
000 ó255
0–100%
64
Fine Green6
000 ó255
Fine control (16-bit)
65
Blue6
000 ó255
0–100%
66
Fine Blue6
000 ó255
Fine control (16-bit)
67
Amber6
000 ó255
0–100%
68
Fine Amber6
000 ó255
Fine control (16-bit)
69
White6
000 ó255
0–100%
70
Fine White6
000 ó255
Fine control (16-bit)
71
UV6
000 ó255
0–100%
72
Fine UV6
000 ó255
Fine control (16-bit)
73
Red7
000 ó255
0–100%
74
Fine Red7
000 ó255
Fine control (16-bit)
75
Green7
000 ó255
0–100%
76
Fine Green7
000 ó255
Fine control (16-bit)
77
Blue7
000 ó255
0–100%
78
Fine Blue7
000 ó255
Fine control (16-bit)
79
Amber7
000 ó255
0–100%
80
Fine Amber7
000 ó255
Fine control (16-bit)
81
White7
000 ó255
0–100%
82
Fine White7
000 ó255
Fine control (16-bit)
83
UV7
000 ó255
0–100%
84
Fine UV7
000 ó255
Fine control (16-bit)
85
Red8
000 ó255
0–100%
86
Fine Red8
000 ó255
Fine control (16-bit)
87
Green8
000 ó255
0–100%
88
Fine Green8
000 ó255
Fine control (16-bit)
89
Blue8
000 ó255
0–100%
90
Fine Blue8
000 ó255
Fine control (16-bit)
91
Amber8
000 ó255
0–100%
92
Fine Amber8
000 ó255
Fine control (16-bit)
93
White8
000 ó255
0–100%
94
Fine White8
000 ó255
Fine control (16-bit)
95
UV8
000 ó255
0–100%
96
Fine UV8
000 ó255
Fine control (16-bit)

COLORdash™ Batten-Hex 8 GRR ES
18
Acerca de Esta
Guía
La Guía de Referencia Rápida (GRR) del COLORdash™ Batten-Hex 8
contiene información básica sobre el producto, como montaje, opciones de
menú y valores DMX. Descargue el Manual de U
suario de
www.chauvetpro.com para información más detallada.
Exención de
Responsabilidad
La información y especificaciones contenidas en esta GRR están sujetas a
cambio sin previo aviso.
Notas de
Seguridad
•NO abra este producto. No contiene piezas reparables por el usuario.
•NO mire a la fuente de luz cuando el producto esté encendido.
•CUIDADO: La carcasa de este producto está caliente cuando las
luces están en funcionamiento.
•Monte este producto en una ubicación con ventilación adecuada, al
menos a 20'' (50 cm) de superficies adyacentes.
•NO deje ningún material inflamable a menos de 50 cm de este
producto mientras esté funcionando o conectado a la alimentación.
•USE un cable de seguridad (incluido)
cuando monte este producto en
lo alto.
•NO ponga en funcionamiento este producto en el exterior o en
cualquier ubicación en la que el polvo, calor excesivo, agua o
humedad puedan afectarlo. (IP20)
•NO ponga en funcionamiento este producto si sospecha que la
carcasa, lentes o cables están dañados.
•NO conecte este producto a un atenuador o reostato.
•Conecte este producto SOLO a un circuito con toma de tierra y
protegido.
•Use SOLAMENTE los soportes de colgar/montar para mover este
producto.
•En caso de un problema grave de funcionamiento, deje de usarlo
inmediatamente.
•La máxima temperatura ambiente es de 113 ºF (45 ºC). No haga
funcionar este producto a temperaturas más altas.
Contacto
Fuera de EE.UU, Reino Unido, Irlanda o México, póngase en contacto con su
distribuidor para solicitar asistencia o devolver el producto.
Visite
www.chauvetpro.com para información de contacto.
Qué va
Incluido
•COLORdash™ Batten-Hex 8
•Cable de Alimentación
Neutrik® powerCON®
•Cable de Seguridad
•Tarjeta de Garantía
•Guía de Referencia Rápida

ES COLORdash™ Batten-Hex 8 GRR
19
Corriente
Alterna
Este producto tiene una fuente de alimentación con detección automática que
puede funcionar con un rango de tensión de entrada de
100 a 240 VCA, 50/60 Hz.
Alimentación en
Cadena
Puede enlazar hasta 11 productos COLORdash™ Batten-Hex 8 a
120 V, 19 a 208 V, o 20 a 230 V. Nunca sobrepase este número. Los cables de
alimentación en cadena se pueden adquirir por separado.
Enchufe CA
Conexión
Cable (EE.UU.)
Cable (Europa)
Color del tornillo
CA Cargado
Negro
Marrón
Amarillo/Latón
CA Neutro
Blanco
Azul
Plata
CA Tierra
Verde/Amarillo
Verde/Amarillo
Verde
Sustitución del
Fusible
1. Desconecte el producto de la toma de corriente.
2. Con un destornillador de punta plana, desatornille la tapa del
portafusibles.
3. Quite el fusible fundido del portafusibles y sustitúyalo con otro del
mismo tipo y categoría.
4. Vuelva a atornillar la tapa del portafusibles en su sitio y conecte de
nuevo la alimentación.
Enlace DMX
El COLORdash™ Batten-Hex 8 funcionará con un controlador DMX usando
una conexión serie DMX normal. Hay un Manual DMX disponible en
www.chauvetpro.com.
Conexión DMX
El COLORdash™ Batten-Hex 8 usa una conexión de datos DMX normal para
sus personalidades DMX: 6 Ch, 8 Ch, 12Ch, 13Ch, 48Ch, 53Ch, 68Ch-A
,
68Ch-W, 96Ch, HSV, y HSI.
Vea el manual de usuario para conectar y
configurar para funcionamiento DMX.
Nota: Para un control óptimo de los canales de regulación de 16 bits en las
personalidades 13Ch, 68Ch-A, 68Ch-W y 96Ch, asegúrese de que la curva de
regulación en el modo Dim está ajustado en OFF.
Conexión
Maestro/
Esclavo
El COLORdash™ Batten-Hex 8 usa la conexión de datos DMX para su modo
Maestro/Esclavo. Vea el Manual de Usuario para conectar y configurar para
funcionamiento Maestro/Esclavo.

COLORdash™ Batten-Hex 8 GRR ES
20
Montaje
Diagrama
de Montaje
del Producto
Descripción del
Panel de
Control
Botón
Función
<MENU>
Sale del menú o función actual
<ENTER>
Habilita el menú actualmente en pantalla o configura
el valor seleccionado actualmente dentro de la
función seleccionada
<UP>
Navega hacia arriba por la lista de menú y aumenta el
valor numérico cuando está en una función
<DOWN>
Navega hacia abajo por la lista de menú y disminuye
el valor numérico cuando está en una función
Montaje en Altura
Montaje en el Suelo
Abrazadera de Montaje
(como la abrazadera CLP-15 o
CLP-15N de CHAUVET®)
Cable de Seguridad
(funciona con CH-05 de
CHAUVET®)
