Chauvet Q-WASH 560Z-LED User manual

User Manual

Edition Notes
Q-Wash 560Z-LED User Manual Rev. 05
Edition Notes
The Q-Wash 560Z-LED User Manual Rev. 05 covers the description, safety
precautions, installation, programming, operation, and maintenance of the Q-Wash
560Z-LED. CHAUVET® released this edition of the Q-Wash 560Z-LED User Manual
in August 2011.
Trademarks
CHAUVET® is a registered trademark of CHAUVET & Sons Inc. (d/b/a CHAUVET®
or Chauvet). The CHAUVET® logo in its entirety including the Chauvet name and
the dotted triangle, and all other trademarks on this manual pertaining to services,
products, or marketing statements (example: It’s Green Thinking™) are owned or
licensed by CHAUVET®. Any other product names, logos, brands, company names,
and other trademarks featured or referred to within this document are the property of
their respective trademark holders.
Copyright Notice
CHAUVET® owns the content of this user manual in its entirety, including but not
limited to pictures, logos, trademarks, and resources.
© Copyright 2011 CHAUVET®. All rights reserved.
Electronically published by CHAUVET® in the United States of America.
Manual Usage
CHAUVET® authorizes its customers to download and print this manual for
professional information purposes only. CHAUVET® expressly prohibits the usage,
copy, storage, distribution, modification, or printing of this manual or its content for
any other purpose without its written consent.
Document Printing
For better results, print this document in color, on letter size paper (8.5 x 11 inches),
double sided. If using A4 paper (210 x 297 mm), configure your printer to scale the
content accordingly.
Intended Audience
Any person in charge of installing, operating, and/or maintaining this product should
read the guide that shipped with it as well as this manual in their entirety before
installing, operating, or maintaining this product.
Disclaimer
CHAUVET® believes that the information contained in this manual is accurate in all
respects. However, CHAUVET® assumes no responsibility for any error or
omissions in this document. CHAUVET® reserves the right to revise this document
and to make changes from time to time in the content hereof without obligation of
CHAUVET® to notify any person or company of such revision or changes. This
does not constitute in any way a commitment by CHAUVET® to make such
changes. CHAUVET® may issue a revision of this manual or a new edition of it to
incorporate such changes.
Document Revision
The Q-Wash 560Z-LED User Manual Rev. 05 supersedes all previous versions of
this manual. Please discard any older versions of this manual you may have,
whether in printed or electronic format, and replace them with this version.
Author Date Editor Date
D. Couppe 8/24/11 B. Pillow 8/29/11

Table of Contents
Q-Wash 560Z-LED User Manual Rev. 05 -i-
Table of Contents
1. Before You Begin ................................................................................................ 1
What is Included..................................................................................................................1 
Unpacking Instructions........................................................................................................1 
Typographic Conventions...................................................................................................1 
Icon Meaning.......................................................................................................................1 
Product at a Glance ............................................................................................................1 
Safety Notes........................................................................................................................2 
Expected LED Lifespan ......................................................................................................2 
2. Introduction ......................................................................................................... 3
Product Description.............................................................................................................3 
Features..............................................................................................................................3 
Additional Features......................................................................................................................3
Product Overview................................................................................................................4 
Product Dimensions............................................................................................................5 
3. Setup .................................................................................................................... 6
AC Power............................................................................................................................6 
AC Plug .......................................................................................................................................6
Fuse Replacement ......................................................................................................................6
DMX Linking........................................................................................................................7 
DMX Modes.................................................................................................................................7
Master/Slave Connectivity...........................................................................................................7
Mounting .............................................................................................................................8 
Orientation...................................................................................................................................8
Rigging........................................................................................................................................8
4. Operation ............................................................................................................. 9
Control Panel Description...................................................................................................9 
Control Options...................................................................................................................9 
Programming.......................................................................................................................9 
DMX Operation............................................................................................................................9
Stand-alone Operation ................................................................................................................9
Master/Slave..............................................................................................................................10
Display Mode.............................................................................................................................10
Software Version.......................................................................................................................10
Keylock......................................................................................................................................10
Fan............................................................................................................................................10
Reset.........................................................................................................................................10
Dimmer Curve ...........................................................................................................................11
Fader Reversal..........................................................................................................................11
Range Limitation........................................................................................................................11
Reset Control.............................................................................................................................12
Move-in Black............................................................................................................................12
Power........................................................................................................................................12
Color Settings............................................................................................................................12
Fan Control................................................................................................................................13
Color Calibration........................................................................................................................13
White Calibration.......................................................................................................................13
System Default..........................................................................................................................14
Edit Custom...............................................................................................................................14

Table of Contents
-ii- Q-Wash 560Z-LED User Manual Rev. 05
Menu Map.........................................................................................................................15 
Extra Menu........................................................................................................................16 
DMX Values......................................................................................................................17 
BASIC........................................................................................................................................17
ADVANCED...............................................................................................................................18
5. Technical Information....................................................................................... 19
Product Maintenance........................................................................................................19 
Troubleshooting Guide......................................................................................................20 
Returns Procedure............................................................................................................21 
Claims...............................................................................................................................21 
Contact Us ........................................................................................................................21 
Technical Specifications ...................................................................................................22 

Before You Begin
Q-Wash 560Z-LED User Manual Rev. 05 -1-
1. Before You Begin
What Is
Included
One Q-Wash 560Z-LED
One IEC Power Cord with Edison Plug (US market)
One Safety Cable
Two Omega Brackets
Warranty Card
Quick Reference Guide
Unpacking
Instructions
Immediately upon receiving this product, carefully unpack and check the container in which
you received it. Make sure that you have received all the parts indicated above and that
they are all in good condition. If the material inside the container (this product and any
other accessory included with it) appears damaged from shipping, or if the container shows
signs of mishandling, notify the shipper immediately. In addition, retain the container and
all the packing material for inspection.
See the Claims section in the Technical Information chapter.
Typographic
Conventions
Convention Meaning
1~512 A range of values in the text
50/60 A set of mutually exclusive values in the text
“COLORado™ 1 UM” The name of another publication or manual
<SET> A button on the product’s control panel
Settings A product function or a menu option
MENU > Settings A sequence of menu options
1~10 A range of menu values from which to choose in a menu
Yes/No A set of two mutually exclusive menu options in a menu
ON A unique value to be entered or selected in a menu
Icon Meaning
Icon Meaning
This icon indicates critical installation, configuration, or operation
information. Failure to comply with this information may render the
product partially or completely inoperative, damage third-party
equipment, or cause harm to the user.
This icon indicates important installation or configuration
information. Failure to comply with this information may prevent
the product from functioning correctly.
This icon indicates useful, although non-critical information.
The term “DMX” used throughout this document refers to the USITT DMX512-A
transmission protocol.
Product at a
Glance
Use on Dimmer

Auto Programs

Outdoor Use

Auto-ranging Power Supply

Sound Activated

Replaceable Fuse

DMX

User Serviceable

Master/Slave

Duty Cycle


Before You Begin
-2- Q-Wash 560Z-LED User Manual Rev. 05
Safety Notes
It is important to read all these notes before starting to work with this product. The Safety
Notes include important safety information about the installation, usage, and maintenance
of this product.
There are no user serviceable parts inside this product. Any reference to servicing
you may find from now on in this User Manual will only apply to properly
CHAUVET® certified technicians. Do not open the housing or attempt any repairs
unless you are certified to do so.
Please refer to all applicable local codes and regulations for the proper installation
of this product.
PersonalSafety
Avoid direct eye exposure to the light source while the product is on.
Always disconnect this product from its power source before servicing.
Always connect this product to a grounded circuit to avoid the risk of electrocution.
Do not touch this product’s housing when operating because it may be hot.
MountingandRigging
This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
Make sure there are no flammable materials close to this product while operating.
When hanging this product, always secure it to a fastening device using a safety cable
(included).
Do not carry this product from the head; always use the handles.
PowerandWiring
Always make sure that you are connecting this product to the proper voltage, as per
the specifications in this manual or on the product’s sticker.
Never connect this product to a dimmer pack or rheostat.
Never disconnect this product by pulling or tugging on the power cable.
Operation
Do not operate this product if you see damage on the housing, lenses, or cables. In
any of these cases, have the damaged parts replaced by an authorized technician at
once.
Do not cover the ventilation slots when the product is operating to avoid internal
overheating.
Do not aim this product toward the Sun. Otherwise, the lenses could concentrate the
solar energy and cause internal overheating.
The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate this product
at a higher temperature.
In case of a serious operating problem, stop using this product immediately!
In the unlikely event that your CHAUVET® product may require service, please
contact CHAUVET® Technical Support.
Expected LED
Lifespan
LEDs gradually decline in brightness over time, mostly because of heat. Packaged in
clusters, LEDs exhibit higher operating temperatures than in ideal, single LED conditions.
For this reason, using clustered LEDs at their fullest intensity significantly reduces the
LEDs’ lifespan. Under normal conditions, this lifespan can be of 40,000 to 50,000 hours. If
extending this lifespan is vital, lower the operational temperature by improving the
product’s ventilation and reducing the external temperature. In addition, limiting the overall
projection intensity may also help to extend the LEDs’ lifespan.

Introduction
Q-Wash 560Z-LED User Manual Rev. 05 -3-
2. Introduction
Product
Description
The Q-Wash 560Z-LED is an RGBWA LED moving yoke, wash product.
The Q-Wash 560Z-LED consists of a base section and a moving yoke with a pan range of
up to 540º. The moving head, which has a tilt range of 270º, contains the 91 RGBW LEDs
and the zoom motors. The base section has the 3- and 5-pin DMX input and output
sockets, the IEC power input connector and the LCD based control panel.
Features
12 or 15-channel RGBWA LED moving yoke wash product
Pan: 540
Tilt: 270
RGBWA color static mixing with or without DMX control
Continuously variable zoom (6º~32°)
Electronic strobe (0~20 Hz)
Electronic dimmer (0~100%).
High power setting
Built-in automated programs
Remote product reset and vector speed channel
255-step fully customizable program
Recall auto or custom programs via control panel or DMX
Color temperature presets (3,200~10,000 K)
Color calibration
Fan speed control
Additional
Features
3- and 5-pin DMX input and output connectors
LCD display with password protection

Introduction
-4- Q-Wash 560Z-LED User Manual Rev. 05
Product Overview
PowerInput
IECSocket
PowerSwitch
Fuseholder
3‐pinDMXIn
3‐pinDMXOut
5‐pinDMXOut
5‐pinDMXIn
Controlpanel
FRONT
BACK

Introduction
Q-Wash 560Z-LED User Manual Rev. 05 -5-
Product Dimensions

Setup
-6- Q-Wash 560Z-LED User Manual Rev. 05
3. Setup
AC Power
The Q-Wash 560Z-LED has an auto-ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
Make sure that you are connecting this product to the proper voltage, as per the
specifications in this guide or on the product’s sticker.
Always connect this product to a protected circuit with an appropriate electrical
ground to avoid the risk of electrocution or fire.
To determine the power requirements for the Q-Wash 560Z-LED, refer to the label affixed
to the side of the product. Alternatively, you may refer to the Technical Specifications chart
in the Technical Information chapter of this manual.
The listed current rating indicates the maximum current draw during normal operation. For
more information, download the Sizing the Circuit Breakers document from the
CHAUVET® web site: www.chauvetpro.com.
Never connect this product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
AC Plug
The Q-Wash 560Z-LED comes with a power input cord terminated with an IEC connector
on one end and an Edison plug on the other end (US market). If the power input cord that
came with your product has no plug or you need to change the Edison plug, use the table
below to wire the new plug.
Connection Wire (US) Wire (Europe) Screw Color (US)
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
Make sure to disconnect the product’s power cord before replacing a blown fuse,
and always replace it with a fuse of the same type and rating.
Fuse Replacement
1. Wedge the tip of a flat head screwdriver into the slot of the fuse holder and
pry it out of its housing.
2. Remove the blown fuse from its holder and replace with a fuse of the exact
same type and rating.
3. Insert the fuse holder back in its place, and reconnect power.
The fuse is located
inside this compartment.
Remove it using a flat
head screwdriver.

Setup
Q-Wash 560Z-LED User Manual Rev. 05 -7-
DMX Linking
You may link the Q-Wash 560Z-LED to a DMX controller using a standard DMX serial
connection. If using other DMX compatible products with this product, you can control them
individually with a single DMX controller.
If you are not familiar with the DMX standard, or if you need information about the DMX
cables needed to link this product to a DMX controller, you may download the DMX Primer
document from the CHAUVET® web site: www.chauvetpro.com.
DMX Modes
The Q-Wash 560Z-LED uses the standard DMX data connection for its Basic and
Advanced DMX modes. You will find information about these DMX modes in the Operation
chapter (configuration details), and the DMX Values section (individual channel values).
Master/Slave
Connectivity
The Master/Slave mode allows a Q-Wash 560Z-LED product to control one or more
products of the same model without a DMX controller. The controlling product becomes the
“master” when running the Auto1, Auto2, or Custom programs. You must configure the
controlled (slave) products to operate in “SLAVE” mode from their respective control
panels. During the Master/Slave operation, the slave products will operate in unison with
the master product.
DO NOT connect a DMX controller to the products operating in Master/Slave mode.
Otherwise, the signals from the DMX controller may interfere with the signals from
the master product.
The Operation chapter of this manual provides detailed instructions on how to
configure the Master and Slave units.

Setup
-8- Q-Wash 560Z-LED User Manual Rev. 05
Mounting
Before mounting this product, read and follow the safety recommendations indicated in the
Safety Notes section (page 2 of this manual).
Orientation
Always mount this product in a safe position with adequate room around it for ventilation,
head motion, configuration, and maintenance.
Rigging
CHAUVET® recommends following the general guidelines below when mounting this
product.
When selecting an installation location, consider ease of access to the product for
operation, programming adjustments, and routine maintenance.
Make sure to mount this product away from any flammable material, as indicated in the
Safety Notes section or obstructions that may block the moving head.
Never mount the product in places where rain, high humidity, extreme temperature
changes, or restricted ventilation may affect it.
If hanging this product, make sure that the location where you are mounting it can
support its weight. Please see the Technical Specifications section of this manual for
the weight requirement of this product.
Procedure
The Q-Wash 560Z-LED comes with two omega brackets to which you can attach clamps.
You must supply your own clamps and make sure that they are capable of supporting the
weight of this product. You will have to use two mounting points per product. The omega
brackets also serve to anchor this product to a panel. For floor standing operation, this
product has built-in rubber feet.
ProductMounting
Diagram
SafetyCable(included)
Clamp(notincluded)
Omegabracket(included)
OverheadMounting FloorStanding

Operation
Q-Wash 560Z-LED User Manual Rev. 05 -9-
4. Operation
Control Panel
Description
Button Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the currently selected value
in to the current function
<UP> Navigates upwards through the menu list and increases the numeric value
when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric
value when in a function
Control Options
You can set the Q-Wash 560Z-LED start address in the 001~512 DMX range. This allows
for the control of up to 34 products in the 15-channel ADVANCED personality.
Programming
Refer to the Menu Map on page 15 to learn how the menu options relate to each other.
The menu map has a Menu Level and a variable number of programming levels for each
option.
To go to an option in the Menu Level, press <MENU> repeatedly until the option shows on
the display. Press <ENTER> to select it. This will take you to the first programming level for
that option.
To select an option or value within the current programming level, press <UP> or <DOWN>
until shown on the display. Press <ENTER> to accept. If there is another programming
level, you will see that first option or you will see the selected value.
To exit to the previous menu level, press <MENU>.
In the EDIT menu, <UP> and <DOWN> will only change the value of the current
option. To change to the next option, press <ENTER>.
DMX Operation
1. Select DMX operation.
a) Go to MENU > INTRO > RUN.
b) Select DMX512.
2. Select a DMX mode.
a) Go to MENU > INTRO > CHANNELS.
b) Select BASIC or ADVANCED.
3. Select the starting address.
a) Go to MENU > INTRO > ADDRESS.
b) Select a starting address, 001~498 (Advanced) or 001~501 (Basic).
The highest possible starting address for each DMX mode is:
DMX Mode DMX Address
Basic 501
A
dvanced 498
Stand-alone
Operation
1. Go to MENU > INTRO > RUN.
2. Select a stand-alone operation mode (AUTO 1, AUTO 2, CUSTOM, or
TEST).
Of all the stand-alone operation modes indicated above, only “CUSTOM” is editable
(see Edit Custom).

Operation
-10- Q-Wash 560Z-LED User Manual Rev. 05
Master/Slave
The Master/Slave mode allows a group of Q-Wash 560Z-LED products (the slaves) to
simultaneously duplicate the output of another Q-Wash 560Z-LED (the master), whether
auto/custom or static modes, without a DMX controller.
1. Set the master unit:
a) Select a stand-alone mode, as indicated above.
2. Set each of the slave units:
a) Go to MENU > INTRO > RUN.
b) Select SLAVE.
Do not connect a DMX controller to the master or slave products.
The master unit should be the first unit in the DMX daisy chain.
Display Mode
This mode defines how the LCD’s backlight will work.
1. Go to MENU > INTRO > DISPLAY.
2. Select a display mode (60 CLOSE or BRIGHT).
When in the “60 CLOSE” setting, the LCD’s backlight will turn off after 60 s.
When in the “BRIGHT” setting, the LCD’s backlight will stay on.
Software Version
This option will show the installed software version.
1. Go to MENU > INTRO > INFO.
2. The display will show Edition.
3. Press <ENTER> to see the installed software version.
Keylock
This option enables or disables the LCD key.
1. Go to MENU > INTRO > KEYLOCK.
2. Select YES or NO.
When in the “YES” setting, the user will have to enter the password after 30 seconds
of control panel inactivity or each time he/she turns the product on.
The default (non-modifiable) password is
<UP>, <DOWN>, <UP>, <DOWN>, and <ENTER>.
Fan
You can select the fan operation mode, as follows:
1. Go to MENU > INTRO > FAN.
2. Select HIGH, NORMAL, LOW, or AUTO.
The product’s controller will force the fan to High if the product’s internal
temperature becomes too high, despite any manual or DMX setting.
Reset
This option allows you to reset all custom settings to their default values.
1. Go to MENU > INTRO > RESET.
2. Select YES or NO.

Operation
Q-Wash 560Z-LED User Manual Rev. 05 -11-
Dimmer Curve
This setting determines how fast the output of the Q-Wash 560Z-LED changes when the
operator modifies the values of the Red, Green, Blue, White, Amber, and Dimmer faders.
This setting gives the user four different options to simulate the dimming curve of an
incandescent lighting product.
To select the dimmer curve, do the following:
1. Go to MENU > INTRO > DIMMER.
2. Select DIMMER 0~4.
DIMMER 0: The output is proportional (linear) to the Dimmer and RGBW channel
values.
DIMMER 1~4: The output follows the Dimmer and RGBW channel values based on the
corresponding dimmer curve. DIM1 is the fastest and DIM4 is the
slowest.
Fader Reversal
This option allows you to define how the pan, tilt, and dimmer increase based on the
direction you move the corresponding fader.
1. Go to MENU > INVERT > PAN.
2. Select a fader direction (NORMAL or REVERSE).
3. Go to MENU > INVERT > TILT.
4. Select a fader direction (NORMAL or REVERSE).
5. Go to MENU > INVERT > DIMMER.
6. Select a fader direction (NORMAL or REVERSE).
7. Go to MENU > INVERT > USE.
8. Select YES to activate the new settings or NO to stop using them.
When in NORMAL, the pan, tilt, and dimmer values will increase as the position
of the respective fader increases.
When in REVERSE, the pan, tilt, and dimmer values will decrease as the position
of the respective fader increases.
Range Limitation
When it is necessary to limit the pan or tilt range, you can do the following:
1. Go to MENU > RANGE > P/START.
2. Select the starting point for the limited pan (000~255).
3. Go to MENU > RANGE > P/FINISH.
4. Select the finishing point for the limited pan (000~255).
5. Go to MENU > RANGE > T/START.
6. Select the starting point for the limited tilt (000~255).
7. Go to MENU > RANGE > T/FINISH.
8. Select the finishing point for the limited tilt (000~255).
9. Go to MENU > RANGE > USE.
10. Select YES to activate the new settings or NO to stop using them.

Operation
-12- Q-Wash 560Z-LED User Manual Rev. 05
Reset Control
It is possible to select how you can reset the product, whether with the DMX controller or
only from the control panel.
1. Go to MENU > SPECIAL > RESET.
2. Select DMX or SYSTEM.
DMX: Enables the DMX controller to reset the product (Control function).
SYSTEM: Restricts the reset function to the control panel.
Move-in Black
This option allows you to activate or deactivate the move-in black 3-seconds delay.
1. Go to MENU > SPECIAL > BLACK.
2. Select YES to enable the 3 seconds delay or NO to make the blackout
immediate.
Power
You may use this function to boost the output power for specific, short-term applications.
1. Go to MENU > SPECIAL > POWER.
2. Select NORMAL or HIGH.
The product will return to Normal if the LEDs’ temperature becomes too high.
Color Settings
The COLOR setting determines how the Q-Wash 560Z-LED generates the white color
based on various RGB settings.
1. Go to MENU > SPECIAL > COLOR.
2. Select OFF, RGBTOW, or UC.
UC: When the RGB faders are set to “255”, the output matches that of less
efficient products (Universal Color).
RGBTOW: When the RGB faders are all set to “255”, the resulting output is defined by
RGB-W (see MENU > EXTRA > CALIB).
OFF: When the RGB faders are all set to “255”, the output is maximum, although
the resulting white color may not be balanced.

Operation
Q-Wash 560Z-LED User Manual Rev. 05 -13-
Fan Control
This option defines how you can control the fan speed, whether with the DMX controller or
only from the control panel.
1. Go to MENU > SPECIAL > FAN.
2. Select DMX or SYSTEM.
DMX: Enables the DMX controller to control the fan speed (Control function).
SYSTEM: Restricts the control of the fan speed to the control panel.
Color Calibration
If necessary, you may adjust the color temperature of each of the macros (White1~11).
1. Go to MENU > EXTRA.
2. Press <ENTER> (PASSWORD) will show on the display.
3. Press <ENTER> (**** will show on the display).
4. Enter the password, as explained in Keylock (CALIB will show on the
display).
5. Press <ENTER> (3200K will show on the display).
6. Use <UP> or <DOWN> to select another color temperature (3400~10000 K),
or press <ENTER> to edit the current temperature.
7. Select RED, GREEN, or BLUE.
8. Select a value (000~255).
9. Repeat for the other colors.
White Calibration
You may calibrate the white color shown when the RGB faders are at “255” and the
MENU > SPECIAL > COLOR setting is RGBTOW.
1. Go to MENU > EXTRA.
2. Press <ENTER> (PASSWORD) will show on the display.
3. Press <ENTER> (**** will show on the display).
4. Enter the password, as explained in Keylock (CALIB will show on the
display).
5. Press <ENTER> (3200K will show on the display).
6. Use <UP> or <DOWN> to select RGBW.
7. Select RED, GREEN, or BLUE.
8. Select a value (000~255).
9. Repeat for the other colors.

Operation
-14- Q-Wash 560Z-LED User Manual Rev. 05
System Default
To default all the product’s parameters to their default values, do the following:
1. Go to MENU > EXTRA.
2. Press <ENTER> (PASSWORD) will show on the display.
3. Press <ENTER> (**** will show on the display).
4. Enter the password, as explained in Keylock (CALIB will show on the
display).
5. Use <UP> to select DEFAULT.
6. Press <ENTER> (NO will show on the display).
7. Select YES and press <ENTER> to default the product or press <MENU> to
exit.
Edit Custom
This function allows you to program up to 255 steps in a single custom program.
1. Go to MENU > EDIT.
2. Press <ENTER> to go to STEP.
3. Press <ENTER> to select a value. The current value (001~255) will show on
the LCD.
4. Press <UP> or <DOWN> to select a new value.
5. Press <ENTER> to accept the value.
6. Press <ENTER> to go to PAN.
7. Repeat steps 1 through 6 for TILT, SPEED, RED, GREEN, BLUE, WHITE,
DIMMER, STROBE, ZOOM, DIMSPEED, and TIME.
8. Press <ENTER> to go to USE.
9. Select YES to save the settings for this step or NO to delete them.
10. Repeat steps 3 to 8 for the other steps.
The product will execute all the steps in the CUSTOM program and stop.
To make the product start over add a last step whose duration is 0 seconds.
Example:
Step 1: Time = 5 Use = Yes
Step 2: Time = 4 Use = Yes
Step 3: Time = 6 Use = Yes
Step 4: Time = 0 Use = Yes (This step creates a loop)
Step 5: Time = 0 Use = No
(Unused steps)
Step 255 Time = 0 Use = No

Operation
Q-Wash 560Z-LED User Manual Rev. 05 -15-
Menu Map
1
st
Level 2
nd
Level 3
rd
Level Description
INTRO
ADDRESS 001~512 Selects a starting DMX address
RESET NO/YES Resets the product’s custom settings
FAN
HIGH Select the fan’s operation mode.
NOTE: The fan will go to High mode if the product’s
internal temperature becomes too high, despite any
manual or DMX setting
NORMAL
LOW
A
UTO
RUN
DMX512 Selects DMX running mode
A
UTO 1 Selects the first automatic program
A
UTO 2 Selects the second automatic program
CUSTOM Selects the user customizable program
SLAVE Selects the Slave running mode
TEST Starts the product’s test sequence
CHANNELS BASIC Selects the 11-channel DMX mode
A
DVANCED Selects the 15-channel DMX mode
DISPLAY 60 CLOSE Turns off the display after 60 seconds
BRIGHT Keeps the display on
KEYLOCK NO/YES Activates/deactivates the control panel password
DIMMER DIMMER4~1 Slow (DIMMER4) to fast (DIMMER1) dimmer curves
DIMMER0 Linear dimmer
INFO EDITION Shows the version of the installed S/W
INVERT
PAN NORMAL/
REVERSE
Defines the direction of the pan fader
TILT Defines the direction of the tilt fader
DIMMER Defines the direction of the dimmer fader
USE NO/YES Activates the changes
RANGE
P/START
000~255
Sets the pan start point (restricted range)
P/FINISH Sets the pan end point (restricted range)
T/START Sets the tilt start point (restricted range)
T/FINISH Sets the tilt end point (restricted range)
USE Activates the changes
SPECIAL
BLACKD NO/YES Activates the move-in black delay (3 s)
RESET DMX The DMX controller can reset the product
SYSTEM The control panel can reset the product
POWER NORMAL/
HIGH
LEDs illuminate at normal or high intensity
NOTE: The product will return to Normal if the LEDs’
temperature becomes too high
COLOR UC RGBW = 255: The output matches that of older products
RGBTOW RGBW = 255: The RGBW output is set by RGB-W
OFF RGBW = 255: The RGBW output is maximum
FAN DMX The DMX controller can set the fan speed
SYSTEM The control panel can reset the fan speed
EDIT
STEP
000~255
Selects the program step
PAN Selects the pan position
TILT Selects the tilt position
SPEED Selects the pan/tilt speed
RED
Combines red, green, blue, white, and amber to obtain a
custom color
GREEN
BLUE
WHITE
AMBER
Continues on the next page

Operation
-16- Q-Wash 560Z-LED User Manual Rev. 05
Continued from previous page
1
st
Level 2
nd
Level 3
rd
Level Description
EDIT
(Cont.)
DIMMER 000~255 Selects the dimmer value
STROBE 01~20 Selects the strobe frequency and mode
ZOOM 000~255 Select the zoom position
DIMSPEED Selects the dimmer speed
TIME Selects the step duration
USE NO/YES Activates the changes
EXTR
A
PASSWORD **** Opens the Extra menu (see below)
Extra Menu
1
st
Level 2
nd
Level 3
rd
Level 4
th
Level Description
CALIB
3200 K RED
000~255
Sets color temperature for White 1
GREEN
BLUE
3400 K RED Sets color temperature for White 2
GREEN
BLUE
4200 K RED Sets color temperature for White 3
GREEN
BLUE
4900 K RED Sets color temperature for White 4
GREEN
BLUE
5600 K RED Sets color temperature for White 5
GREEN
BLUE
5900 K RED Sets color temperature for White 6
GREEN
BLUE
6500 K RED Sets color temperature for White 7
GREEN
BLUE
7200 K RED Sets color temperature for White 8
GREEN
BLUE
8000 K RED Sets color temperature for White 9
GREEN
BLUE
000 K RED Sets color temperature for White 10
GREEN
BLUE
8500 K RED Sets color temperature for White 11
GREEN
BLUE
10000 K RED Sets color temperature for
SPECIAL > COLOR > RGBTOW
GREEN
BLUE
DEFAULT DEFAULT NO/YES N/A Defaults the product to factory settings
