Chauvet Legend 1200E Wash User manual

User Manual

Legend™1200E Spot User Manual I 8/13/2009 10:57 AM
Edition
Notes
CHAUVET released this edition of the Legend™1200E Spot User Manual Rev.
02c in July 2009.
The Legend™1200E Spot User Manual Rev. 02c covers the description, safety
precautions, installation, programming and maintenance of the CHAUVET
Legend™1200E Spot lighting fixture.
Copyright
Notice
No person, group of persons or entity can reproduce any part of this publication,
store it in a retrieval system, or transmit it, in any form or by any means, whether
mechanical, electronic, photocopying, recording, or otherwise, without prior written
permission of CHAUVET.
© Copyright 2009 CHAUVET
All rights reserved
Printed in the P.R.C.
Disclaimers
CHAUVET believes that the information contained in this manual is accurate in all
respects but CHAUVET does not warrant it. CHAUVET assumes no responsibility
for any error or omissions in this document. CHAUVET reserves the right to revise
this document and to make changes from time to time in the content hereof
without obligation of CHAUVET to notify any person or company of such revision
or changes. This does not constitute in any way a commitment by CHAUVET to
make such changes. CHAUVET may issue a revision of this manual or a new
edition of it to incorporate such changes.
Trademarks
All products, brand names, or companies mentioned in the document that are not
directly or indirectly related with CHAUVET may be trademarks or enabled
trademarks of their respective companies.
Intended
Audience
CHAUVET provides The Legend™1200E Spot User Manual Rev. 02c with each
Legend™1200E Spot fixture. Any person in charge of installing, operating and/or
maintaining the Legend™1200E Spot fixture should read this manual in its
entirety before installing, operating or maintaining the fixture.
CHAUVET
Publications
Hot Line
If you have any comments about the accuracy of this document or general
suggestions regarding how we can improve it, please call us at [phone]
(US callers) or [phone] (international callers), ext. 43.
The latest versions of all CHAUVET manuals are available at CHAUVET’s web
site (www.chauvetlighting.com).
Document
Revision
The Legend™1200E Spot User Manual Rev. 02c supersedes all previous
versions.
Please discard all older versions of this manual.
Fixture at
a Glance
Use on Dimmer
Auto Programs
Outdoor Use
Autoswitching
Power Supply
Sound Activated
Replaceable Fuse
DMX
User Serviceable
Master/Slave
CMY Color Mixing

Legend™1200E Spot User Manual I 8/13/2009 10:57 AM
Table of Contents
1. Before You Begin...................................................................................................................................... 1
WHAT IS INCLUDED..................................................................................................................................................................................... 1
UNPACKING INSTRUCTIONS ......................................................................................................................................................................... 1
TEXT CONVENTIONS ................................................................................................................................................................................... 1
ICONS ....................................................................................................................................................................................................... 2
SAFETY INSTRUCTIONS ............................................................................................................................................................................... 2
2. Introduction............................................................................................................................................... 3
FEATURES ................................................................................................................................................................................................. 3
Additional Features................................................................................................................................................... 3
DESCRIPTION............................................................................................................................................................................................. 4
23 DMX Channel Mode 1.......................................................................................................................................... 4
31 DMX Channel Mode 2.......................................................................................................................................... 4
DMX CHANNEL SUMMARY .......................................................................................................................................................................... 5
PRODUCT OVERVIEW ................................................................................................................................................................................. 6
PRODUCT DIMENSIONS ............................................................................................................................................................................... 7
3. Setup.......................................................................................................................................................... 8
AC POWER ............................................................................................................................................................................................... 8
FUSE REPLACEMENT .................................................................................................................................................................................. 8
FIXTURE LINKING ....................................................................................................................................................................................... 8
Data Cabling............................................................................................................................................................. 9
DMX Data Cable....................................................................................................................................................... 9
DMX Cable Connectors ............................................................................................................................................ 9
3-Pin to 5-Pin Conversion Chart.............................................................................................................................. 10
DMX Data Connection ............................................................................................................................................ 10
MOUNTING .............................................................................................................................................................................................. 11
Orientation.............................................................................................................................................................. 11
Rigging ................................................................................................................................................................... 11
Orientation(bracket installation)............................................................................................................................... 12
Lamp ...................................................................................................................................................................... 13
Lamp Installation..................................................................................................................................................... 14
Maximizing the life of your lamp.............................................................................................................................. 14
Replacing Gobos .................................................................................................................................................... 15
4. Operating Instructions.............................................................................................................................16
NAVIGATING THE CONTROL PANEL ............................................................................................................................................................ 16
MENU MAP .............................................................................................................................................................................................. 17
OPERATION ............................................................................................................................................................................................. 18
Home Screen.......................................................................................................................................................... 18
DMX Operation....................................................................................................................................................... 18
Resetting the Fixture............................................................................................................................................... 18
Factory Default Reset ............................................................................................................................................. 18
Lamp Dousing......................................................................................................................................................... 19
Fixture Maintenance ............................................................................................................................................... 19
Lamp Settings......................................................................................................................................................... 19
MENU MAP (CONT.) ................................................................................................................................................................................. 20
Home position Adjustment ...................................................................................................................................... 20
ERROR MESSAGES .................................................................................................................................................................................. 21
DMX CHANNEL VALUES ........................................................................................................................................................................... 22
23 channel mode (Basic) ........................................................................................................................................ 22
31 channel mode (Basic) ........................................................................................................................................ 23
GOBO WHEEL LAYOUT .............................................................................................................................................................................. 25
COLOR WHEEL LAYOUT ............................................................................................................................................................................ 25
5. Technical Information..............................................................................................................................26
GENERAL MAINTENANCE .......................................................................................................................................................................... 26
AIR FILTER CLEANING .............................................................................................................................................................................. 27
RETURNS PROCEDURE ............................................................................................................................................................................. 28
CLAIMS ................................................................................................................................................................................................... 28
CONTACT US........................................................................................................................................................................................... 28
TECHNICAL SPECIFICATIONS ..................................................................................................................................................................... 29
6. Appendix...................................................................................................................................................31

Table of Contents
Legend™1200E Spot User Manual II 8/13/2009 10:57 AM
DMX PRIMER .......................................................................................................................................................................................... 31
Starting Address..................................................................................................................................................... 31
Personalities........................................................................................................................................................... 31
Assigning Addresses .............................................................................................................................................. 31
DMX Fixture Connection......................................................................................................................................... 31

Before you Begin
Legend™1200E Spot User Manual 1 8/13/2009 10:57 AM
1. Before You Begin
What is
Included
1 x Legend™1200E Spot
2 x Omega Brackets with hanging trigger clamps
1 x Warranty Card
1 x User Manual
Unpacking
Instructions
This product ships in a flight case.
Immediately upon receiving the
fixture, carefully examine the flight
case; check the contents to ensure
that all parts are present, and have
been received in good condition. If
any parts appear damaged from
shipping or the carton itself shows
signs of mishandling, notify the
shipper immediately and retain the
packing material for inspection.
Save all packing materials because,
in the event that you have to return
the fixture to the factory, you may
return it in its original factory flight
case.
.
Text
Conventions
CHAUVET manuals use the following text conventions, whether within the regular
text or inside tables.
CONVENTION
MEANING
1~512
A range of values
50/60
A set of mutually exclusive values in the text
[10]
A DIP switch to be configured
<SET>
A key to be pressed on the fixture’s control panel
Settings
A menu option that can be selected but not modified
MENU > Settings
A sequence of menu options to be followed
[1~10]
A range of menu values of which one can be selected
Yes/No
A set of mutually exclusive menu options to choose
ON
A value to be entered or selected
Omega Bracket
Hanging Trigger
clamp

Introduction
Legend™1200E Spot User Manual 2 8/13/2009 10:57 AM
Icons
CHAUVET manuals use the following icons to indicate information that requires
special attention on the part of the user.
ICONS
MEANING
This paragraph contains critical installation, configuration
or operation information. Failure to comply with this
information may render the fixture partially or completely
inoperative, cause damage to the fixture or cause harm to
the user.
This paragraph contains important installation or
configuration information. Failure to comply with this
information may prevent the fixture from functioning
correctly.
This paragraph reminds you of useful, although not
critical, information.
Safety
Instructions
Please read the following instructions carefully because they include important
safety information about the installation, usage, and maintenance of this product.
There are no user serviceable parts inside the unit. Any reference to unit
servicing you may find from now on in this User Manual will only apply to
properly CHAUVET certified technicians. Do not open the housing or attempt
any repairs unless you are one of them.
In the event that your unit may require service, please contact CHAUVET at
[phone].
Keep this manual for future consultation. If you sell the fixture to another user,
make sure that they also receive this manual.
Always make sure that you are connecting the fixture to the proper voltage, as
per the specifications in this manual or on the fixture.
Always disconnect the fixture from the power source before servicing.
This product is for indoor use only! To prevent risk of fire or shock, do not
expose fixture to rain or moisture.
Make sure there are no flammable materials close to the fixture while operating.
Always secure the fixture to a fastening device using a safety chain.
Maximum ambient temperature (Ta) is 104° F (40° C). Do not operate the fixture
at a higher temperature.
In the event of a serious operating problem, stop using the fixture immediately!
Never connect this fixture to a dimmer pack.
Make sure the power cord is not crimped or damaged.
Never disconnect the power cord by pulling or tugging on the cord.
Avoid direct eye exposure to the light source while it is on.
Please refer to all applicable local codes and regulations for proper
installation of this fixture.

Introduction
Legend™1200E Spot User Manual 3 8/13/2009 10:57 AM
2. Introduction
Features
.
23 or 31-channel USITT DMX512-A moving yoke
.
Pan: 540⁰in 2.8 sec/tilt: 270⁰in 1.6 sec
.
Color wheel
7 colors + white
Red, pink, green, magenta, orange, UV, and blue
Split/linear colors
Rainbow color spin at variable speeds
.
Indexed, rotating gobo wheel with gobo shake
6 glass, slot-n-lock gobos + open
2 Multicolor, 4 B/W
Gobo wheel spin at variable speeds
16-bit gobo rotation
.
Indexed, rotating gobo wheel with gobo shake
6 glass, slot-n-lock gobos + open
1 Multicolor, 5 B/W
Gobo wheel spin at variable speeds
16-bit gobo rotation
.
Variable frost
.
Variable CTC filter (3200 K)
.
CMY color mixing system with vector speed adjustments
.
3-facet, 5-facet, 3D and infinite prism with macros
.
Variable shutter
.
Variable iris
.
Variable focus
.
Variable 16-bit dimming (0~100%)
.
Linear zoom (15⁰~30⁰)
.
Individual reset of pan/tilt, color, gobo, shutter, prism, focus
.
Move-in-black for pan/tilt, color, gobo
.
Remote fixture reset, lamp on/off and vector control speed adjustments
.
Built-in movement macros with range adjustments
.
Built-in color macros
Additional
Features
.
3-pin and 5-pin DMX connections
.
2 additional free glass gobos
.
User-configurable lamp ignition delay
.
User-configurable maintenance reminder
.
Electronic ballast with power factor correction
.
Electronic power supply
.
Automatic pan & tilt correction
.
Pan & tilt locks
.
Lamp & fixture use timers
.
Power saver mode

Introduction
Legend™1200E Spot User Manual 4 8/13/2009 10:57 AM
Description
The Legend™1200E Spot is a moving yoke fixture with a 1200 W short arc
discharge lamp.
It contains an LCD control panel (display) through which all of the settings can be
set/modified.
An electronic ballast and power supply provide power to the lamp and electronics
of the fixture.
This fixture operates at 200~240 VAC, 50/60 Hz. There is no internal power
selection switch/terminal. It uses an autoswitching power supply and electronic
ballast with power factor correction.
23 DMX Channel
Mode 1
The DMX 23 channel mode (Basic) provides 16-bit resolution for the Pan/Tilt
functions, and 8-bit resolution for the gobos and prism/effect wheels.
31 DMX Channel
Mode 2
The DMX 31 channel mode (Advanced) provides 16-bit resolution for the Pan/Tilt
functions, and 16-bit resolution for the gobos and prism/effect wheels, and
dimmer. This also includes additional channels for pan/tilt movement macros,
CMY/CTO Speed, and color macros & presets

Introduction
Legend™1200E Spot User Manual 5 8/13/2009 10:57 AM
DMX Channel Summary
23 Channel Mode
CHANNEL
ATTRIBUTE
CHANNEL
ATTRIBUTE
1
Pan
13
Gobo 1
2
Pan fine
14
Gobo 1 rotation
3
Tilt
15
Gobo 2
4
Tilt fine
16
Gobo 2 rotation
5
Pan/tilt speed
17
Focus
6
Dimmer
18
Zoom
7
Shutter
19
Effect/prism
8
Color
20
Effect/prism rotation
9
Cyan
21
Iris
10
Magenta
22
Frost
11
Yellow
23
Function
12
3200 K (CTO)
Filter
31 Channel Mode
CHANNEL
ATTRIBUTE
CHANNEL
ATTRIBUTE
CHANNEL
ATTRIBUTE
1
Pan
12
Yellow
23
Effect/prism
2
Pan fine
13
3200K (CTO)
24
Effect/prism rotation
3
Tilt
14
CMY/CTO Filter
Speed
25
Iris
4
Tilt fine
15
Gobo 1
26
Frost
5
Pan/tilt speed
16
Gobo 1 rotation
27
Pan/tilt Movement macro
6
Dimmer
17
Gobo 1 rotation
fine
28
Pan/tilt Movement macro
range
7
Dimmer fine
18
Gobo 2
29
Preset Color
8
Shutter
19
Gobo 2 rotation
30
Color macro (CMY)
9
Color
20
Gobo 2 rotation
fine
31
Function
10
Cyan
21
Focus
11
Magenta
22
Zoom

Introduction
Legend™1200E Spot User Manual 6 8/13/2009 10:57 AM
Product Overview
Power
input
Enter
button
Jog
Wheel
LCD
Display
Power
button
DMX in
(3-pin)
DMX out
(3-pin)
Fuseholder
(Main)
Tilt lock
Carrying handle
(1 of 2)
Pan lock
Control panel
Menu
button
DMX in
(5-pin)
DMX out
(5-pin)
Fuseholder
(Lamp)
DMX
LED
indicator
Power
LED
indicator

Introduction
Legend™1200E Spot User Manual 7 8/13/2009 10:57 AM
Product Dimensions

Setup
Legend™1200E Spot User Manual 8 8/13/2009 10:57 AM
The fuse is located
inside this
compartment.
FUSE
3. Setup
AC Power
This fixture has an auto-switching power supply that can work with an input
voltage range of 200~240 VAC, 50/60 Hz.
Always connect the fixture to a protected circuit with an appropriate electrical
ground to avoid the risk of electrocution or fire.
To determine the power requirements for a particular fixture, see the label affixed
to the back plate of the fixture or refer to the fixture’s specifications chart. A
fixture’s listed current rating indicates its average current draw under normal
conditions.
Never connect the fixture to a rheostat (variable resistor) or dimmer circuit,
even if the rheostat or dimmer channel serves only as a 0 to 100% switch.
Fuse
Replacement
1. With a Phillips #2 screwdriver, unscrew the fuse holder from its housing.
2. Remove the damaged fuse from its holder and replace with exact same
type and rating fuse.
3. Screw the fuse holder back in its place and reconnect power.
Disconnect the power cord before replacing the fuse and always replace it
with a fuse of the same type and rating.
Fixture
Linking
If using multiple DMX compatible fixtures, it is possible to control them individually
with a single DMX controller or to run them synchronized in a master/slave
operating mode. DMX compatible fixtures use a serial data link between them.
The connection between fixtures follows a daisy chain pattern (the DMX output of
a fixture connects to the DMX input of the next fixture, and so on).
When using a DMX controller, the combined number of channels required by all
the fixtures on the serial data link determines the number of fixtures the DMX
controller can support.
To comply with the EIA-485 standard, which is the base for the DMX standard,
do not connect more than 32 fixtures without using a DMX optically-isolated
splitter. Doing otherwise may result in deterioration of the digital DMX signal.

Setup
Legend™1200E Spot User Manual 9 8/13/2009 10:57 AM
120 ohm ¼ W
resistor between
pin 2 (DMX -) and
pin 3 (DMX +) on
the output of the
last fixture.
Data Cabling
You must use DMX compliant data cables to link two or more DMX compatible
fixtures together. You may purchase CHAUVET certified DMX cables directly from
a dealer/distributor or construct your own cable.
USITT recommends limiting the total length of the DMX cable (from the first
fixture/controller to the last fixture) to 300 ~ 455 m (985 ~ 1,500 ft).
If you choose to create your own cable, make sure to use data-grade cables that
can carry a high frequency signal and are less prone to electromagnetic
interference. Use a Belden© 9841 or equivalent cable, which meets the
specifications for EIA RS-485 applications.
Do not use standard microphone cables for DMX applications because they
cannot transmit DMX data reliably over long distances.
DMX Data Cable
The data cable must have the following characteristics:
Type: shielded, 2-conductor twisted pair
Maximum capacitance between conductors: 30 pF/ft
Maximum capacitance between conductor and shield: 55 pF/ft
Maximum resistance: 20 ohms/1000 ft
Nominal impedance: 100 ~ 140 ohms
DMX Cable
Connectors
Each DMX cable must have a male, 3 or 5-pin XLR
connector on one end and a female, 3 or 5-pin XLR
connector on the other end.
To avoid signal transmission problems and interference, it is always advisable to
connect a DMX signal terminator, as seen below.
Test all DMX cables with an ohmmeter to verify their correct polarity and to
make sure that there are no short-circuits between any of the pins, or between
any pin and ground. If the Common wire touched the chassis ground, a
ground loop could form, which may cause the fixture to perform erratically.
120 ohm, ¼ W
resistor between
pin 2 (DMX -) and
pin 3 (DMX +) on
the output of the
last fixture.
1
3
2
To DMX Input
(Female)
DMX Connector Configuration
Common
DMX +
DMX -
1
3
2
1
3
2
To DMX Output
(Male)

Setup
Legend™1200E Spot User Manual 10 8/13/2009 10:57 AM
3-Pin to 5-Pin
Conversion Chart
It may be necessary to use a 3-pin to 5-pin adapter. Please see the chart below
for further explanation.
3-PIN TO 5-PIN CONVERSION CHART
Conductor
3-Pin Female (Output)
5-Pin Male (Input)
Ground/Shield
Pin 1
Pin 1
Data ( - ) signal
Pin 2
Pin 2
Data ( + ) signal
Pin 3
Pin 3
Not used
Pin 4
Not used
Pin 5
You may use the 3-pin input with the 5-pin output. You may also use 5-pin
input with the 3-pin output. However, you may NOT use both the 3-pin and the
5-pin outputs simultaneously.
DMX Data
Connection
The fixture uses the DMX data connection for its DMX 23 & 31 Channel modes.
See the “Introduction”chapter for a description of the two DMX Channel modes
and the “Operation Instructions”chapter to learn how to configure the fixture
appropriately for this mode.
1. Connect the male connector of the first DMX cable to the DMX Output connector
(female) of the DMX controller.
2. Connect the, female connector of the first DMX cable coming from the controller
to the DMX Input connector (male) of the first fixture.
3. Connect the male connector of the second DMX cable to the DMX Output
connector (female) of the first fixture.
4. Connect the female connector of the second DMX cable coming from the first
fixture to the DMX Input connector of the second fixture.
5. Continue linking the other fixtures in the same way.
DMX Data
Connection
Diagram
CHAUVET Certified
DMX Data Cables
Order Code Description
DMX1.5 DMX Cable 1.5 m/4.9 ft
DMX4.5 DMX Cable 4.5 m/14.8 ft
DMX10 DMX Cable 10 m/32.8 ft
2nd fixtures
1st fixture
DMX
Output
DMX
Input
DMX
Input
DMX
Output
Universal
DMX
Controller
1st DMX
Cable
2nd DMX
Cable
3rd DMX
Cable
Next fixture

Setup
Legend™1200E Spot User Manual 11 8/13/2009 10:57 AM
Mounting
Orientation
Only mount this fixture in a horizontal position, either hanging or standing, as
indicated in the diagram below. Be sure that there is adequate room for
ventilation and for the pan/tilt motion of the fixture. Doing otherwise may void
this fixture’s warranty and cause damage to the fixture.
Rigging
The Legend™1200E Spot ships in a flight case specially designed to fit the fixture.
There are two omega brackets with clamps included in the flight case.
When selecting an installation location, consider ease of access to the fixture for
operation, lamp replacement, programming adjustment(s) and routine
maintenance.
Never mount the fixture in places where rain, high humidity, extreme temperature
changes or restricted ventilation may affect it.
Make sure that the location where you are mounting the fixture can support its
weight. Please see the “Technical Specifications” section of this manual for the
weight requirement of this fixture.
Omega brackets
with clamps
Standing position
Hanging position
Safety
Standing position

Setup
Legend™1200E Spot User Manual 12 8/13/2009 10:57 AM
Orientation
(bracket
installation)
The brackets in this fixture may be mounted on either side of the mounting plate,
thus allowing for a 90° rotation of the fixture. Please see the diagram below for
further explanation.
Location 1
Location 2
Control Panel
Control Panel

Setup
Legend™1200E Spot User Manual 13 8/13/2009 10:57 AM
Lamp
When replacing the lamp, please wait at least 15 minutes after powering down
to allow the unit to cool! More time may be necessary.
Always disconnect from main power prior to lamp replacement.
Do not touch the envelope (glass area) of the bulb with bare hands. If this
happens, clean the lamp with isopropyl alcohol and wipe it with a lint free
cloth before installation.
You should use cotton or latex gloves to avoid from touching the lamp
envelope with your bare hands.
Lamp cover
¼ - turn screws
Lamp alignment screws
Lamp

Setup
Legend™1200E Spot User Manual 14 8/13/2009 10:57 AM
Lamp Installation
The lamp in this fixture is not common and requires specific installation procedures.
Please see the diagram, along with the set of instructions, below for further
explanation.
1. Disconnect power from the fixture and allow it to cool.
2. Lock the head of the fixture.
3. Unscrew the two ¼ - turn screws (X & Y) to open the rear lamp cover (this will
remain attached via a rotating arm).
4. If you are replacing a lamp, you will need to remove the old lamp from the fixture.
Using your thumb and forefinger, grasp the ceramic base of the lamp and turn it
45° counterclockwise to the unlocked position. Then, pull it straight out of the
fixture, being careful not to touch the sides of the reflector or housing.
5. The lamp base has two metal contacts, one narrow and one wide, which fit into
the corresponding narrow and wide slots in the lamp holder. Align the new lamp
with these slots in the lamp holder, and slide the lamp into the fixture until the
contacts are fully inserted. Using your thumb and forefinger, grasp the ceramic
base of the lamp and turn it 45° clockwise to the locked position.
6. Close the rear lamp cover, and tighten the two ¼ - turn screws (X & Y).
7. After installing a new lamp, reset the lamp hour counter (see “Menu Map”for the
menu option to perform this reset).
You should use cotton or latex gloves to avoid from touching the lamp
envelope with your bare hands.
Maximizing the
Life of Your
Lamp
To ensure the longest and most efficient use of the lamp, always wait between 10~15 min
before re-applying power after a shutdown. Failure to do so could result in premature
aging of the lamp and failure of the electronics that drive it.
Never turn off the power to the unit while the lamp is striking. Always wait 15 min after
powering on the fixture before powering it down. Turning off the lamp during striking may
permanently damage the lamp.
Unlocked
Locked
Lamp

Setup
Legend™1200E Spot User Manual 15 8/13/2009 10:57 AM
Replacing Gobos
This fixture comes with slot-n-lock gobo wheels for easy gobo
replacement/installation. Please see the diagram, along with the set of instructions,
below for further explanation.
1. Unscrew the four ¼- turn screws (S2) to detach the front cover.
2. Remove the slot-n-lock gobo single assembly. Using your thumb and forefinger,
grasp the slot-n-lock gobo assembly and remove it from the gobo wheel.
3. Using a small prying tool, remove the gobo tension ring and remove it from the
gobo aperture.
Push the gobo with your finger from the back side following the same direction that
the tension ring was removed.
You should use cotton or latex gloves to avoid from touching the gobos with
your bare hands.
The tension ring could pop out abruptly and fall inside the fixture. Use caution
when removing it and, if necessary, use both hands.
Replace the slot-n-lock prism(s) on the prism/effect wheel using the same
method as the rotating gobo wheel.
S2
slot-n-lock gobo
single assembly

Operating Instructions
Legend™1200E Spot User Manual 16 8/13/2009 10:57 AM
4. Operating Instructions
Navigating the
Control Panel
Access the control panel functions using the two panel buttons located directly to
the right of the LCD Display. Please see the chart, diagram, and set of
instructions, below for further explanation.
Button
Function
<MENU>
Used to access the menu or to return to a
previous menu option
<ENTER>
Used to select and store the current menu
option within a menu
<JOG WHEEL>
Used to scroll through the menu options,
and to modify the value of a setting
The Control Panel LCD Display shows the menu items you select from the “menu
map” section. When a menu function is selected, the display will show the first
available option for the selected menu function.
To select a menu item, press <ENTER>.
Press <MENU> repeatedly until the home screen is displayed. Press <MENU>
one more time. This is the top of the menu map.
Use the <JOG WHEEL> to navigate the menu map and menu options.
Press <ENTER> to access the menu function currently displayed or to enable a
menu option.
To return to the previous option or menu without changing the value, press
<MENU>.
Jog Wheel
Menu button
Enter button
