CHEFOOK 16WSTERILIZER User manual

CLEANING
Before cleaning the machine make
sure it has been unplugged.
Clean the machine only with water
and neutral detergents, never use
abrasive products, water jets and va-
pour, easily inflammable detergents,
utensils, brushes and anything else
that could damage the machine.
TECHNICAL ASSISTANCE
Make sure that the technical assistance is carried out only by trained personnel.
To order spare parts or for any other information relative to the machine contact the assistance centre and always state the se-
rial number and the model of the machine shown on the technical plate placed on its side.
ELECTRIC CIRCUIT DIAGRAM
UVA SMALL - LONG STERILIZER
INSTRUCTIONS FOR THE INSTALLATION, USE AND MAINTENANCE OF THE
Take the sterilizer out of the package.
Before connecting the machine to the electrical outlet make sure that the tension is the same
as the one on the serial number-technical plate placed on the side of the machine.
N.B.: connect the machine on the ground in accordance with the norms in force.
ATTENTION
The short ultraviolet radiations (emission spectrum 253.7 nm) emitted by the lamps are
extremely damaging to all living organisms; avoid exposing eyes to the direct radiation.
TURNING ON AND TURNING OFF
To turn on the machine push the lit switch into the “ON” position and turn the timer clock-
wise until reaching the desired time. At the end of the set time the lamp will automatically
turn off. To turn off the machine simply push the lit switch into the “OFF” position.
USE
Before starting to use the machine clean it with a neutral detergent and a damp cloth, then
rinse and dry it.
The sterilizer must be used only on previously washed utensils. The knives must be inserted in the extractable plexiglass
knifeholder shelf, and they must be exposed at least 1hr and 30' to obtain the bactericide effect. It is not necessary to turn
them in that both sides are exposed to U.V.A. rays.
DESCRIPTION
•The U.V.A. electric sterilizer, which can be fastened on a wall, is made entirely in AISI 430 stainless steel;
•the door which perfectly closes the chamber and keeps the ultraviolet rays is made of smoked plexiglass;
•the knifeholder is made of transparent plexiglass and can be extracted for better cleaning and enables sterilizing up to
15 knives without having to turn them;
•the 16W mercury vapour lamp is controlled by a timer 0÷120 min. and is located in the upper part of the sterilizer,
protected by a metallic net;
•the sterilizer is equipped with a safety microswitch that turns off the lamp when the door is opened.
TECHNICAL DATA TABLE:
MODEL INPUT N°LAMPS
AND POWER
TIMER CAPACITY
N°KNIVES
DIMENSIONS
mm
ASSORPTIONS
16WSTERILIZER 230 V / 50 Hz N°1 16 W LAMP 0
÷
120 min.
≅
15 KNIVES 400 x 140 x 620 POWER
≅
70W
ELECTRICITY
≅
0.3A
terminal board switch
timer microswitch reactor

UVA STERILIZER
INSTRUCTIONS FOR THE INSTALLATION, USE AND MAINTENANCE OF THE
Take the sterilizer out of the package.
Before connecting the machine to the electrical outlet make sure that the tension is the
same as the one on the serial number-technical plate placed on the side of the machine.
N.B.: connect the machine on the ground in accordance with the norms in force.
ATTENTION
The short ultraviolet radiations (emission spectrum 253.7 nm) emitted by the lamps
are extremely damaging to all living organisms; avoid exposing eyes to the direct ra-
diation.
TURNING ON AND TURNING OFF
To turn on the machine push the lit switch into the “ON” position and turn the timer
clockwise until reaching the desired time. At the end of the set time the lamp will auto-
matically turn off. To turn off the machine simply push the lit switch into the “OFF” posi-
tion. The sterilizer is equipped with a courtesy lamp, which switches on at the opening
door with the switch positioned “ON”. The sterilizer is provided with a safety microswitch
which at the opening interrupts the functioning of the germicide lamps.
USE
Before starting to use the machine clean it with a neutral detergent and a damp cloth, then rinse and dry it.
The sterilizer must be used only on previously washed utensils. The knives must be inserted in the extractable plexiglass
knifeholder shelf, and they must be exposed at least 1hr and 30' to obtain the bactericide effect. It is not necessary to turn
them in that both sides are exposed to U.V.A. rays.
DESCRIPTION
•The U.V.A. electric sterilizer, which can be fastened on a wall or placed on a table, is made entirely in AISI 430
stainless steel;
•the door which perfectly closes the chamber and keeps the ultraviolet rays is made of smoked plexiglass;
•the knifeholder is made of transparent plexiglass and has a practical collecting tray for drops from the knives and can
be extracted for better cleaning and enables sterilizing up to 20 knives without having to turn them;
•the 3 8W mercury vapour lamps are controlled by a timer 0÷120 min.; one is located in the upper part of the sterilizer
and two are under, all are protected by a metallic net;
•the courtesy lamp placed above turns on only if the switch in the “ON” position and the timer has stopped or every
time the door is opened while the machine is running;
•the sterilizer is equipped with a safety microswitch that turns off the neon when the door is opened and turns on the
courtesy lamp; vice versa for closing.
TECHNICAL DATA TABLE
MODEL INPUT N°LAMPS
AND POWER
TIMER CAPACITY
N° KNIVES
DIMESIONS
mm
ASSORPTIONS
24W STERILIZER 230 V / 50 Hz N°3 8W LAMPS 0
÷ 120 min. ≅20 KNIVES 400 x 300 x 620 POWER ≅ 100W
ELECTRICITY
≅
0.5A

CLEANING
Before cleaning the machine make sure it has been unplugged. clean the machine only with water and neutral detergents,
never use abrasive products, water jets and vapour, easily inflammable detergents, utensils, brushes and anything else that
could damage the machine.
TECHNICAL ASSISTANCE
Make sure that the technical assistance is carried out only by trained personnel.
To order spare parts or for any other information relative to the machine contact the assistance centre and always state the
serial number and the model of the machine shown on the technical plate placed on its side.
terminal board switch
timer
microswitch
reactor
reactor
reactor
courtesy lamp
ELECTRIC CIRCUIT DIAGRAM
