Chelino ChelinoBaby BOOGIE User manual

PRESS
Group0+ (0-13kg) suitable from birth up to 13kgs
BOOGIE
USR’S MANUAL
Stores: ChelinoBaby - Ormonde - JHB
ChelinoBaby - Fourways - JHB
ChelinoBaby - Menlyn - Pretoria
ChelinoBaby - Gateway- Durban
ChelinoBaby - Online - www.chelinobaby.co.za
Importer:
Anchor lnternational
Add: 12 Kimberlite Road , Theta Ext 5 Booysens
Reserve , JHB 2091 South Africa.
Tel: [phone]

NOTICE
1.This is a “Universal” child restraint; it is approved to Regulation No.
44,04 series of amendments, for general use in vehicles and it will fit
most ,but not all, car seats.
2.A correct fit is likely if the vehicle manufacturer has declared in the
vehicle handbook that the vehicle is capable of accepting a “Universal”
child restraint for this age group.
3.This child restraint has been classified as“Universal” under more
stringent conditions than those which applied to earlier designs which do
not carry this notice.
4.If in doubt, consult either the child restraint manufacturer or the
retailer.
Only suitable if the approved vehicles are fitted with 3-point
safety-belts, approved to UN/ECE
Regulation No.16 or other equivalent Standards.
Do not use in passenger seats equipped with airbags (SRS)
EXTREME HAZARD
INSTRUCTIONS MANUAL
Congratulations on your purchase of the
BOOGIE INFANT SEAT
This product has been designed and developed with safety, comfort and
functionality in mind. Please take the time to read this manual
carefully before using this product and keep it in a safe place for
future reference.
Due to variations in the style and design of our products, the
photographs and illustrations shown in this instruction manual are
generic, therefore products fabrics, colour and design may vary from
images shown. CHELINO reserves the right to alter product
specifications without notice as a result of our ongoing policy of
product improvement.
12
NOTES
Please read through these instructions carefully before using the infant
seat for first time.The instructions can be retained on the infant seat
for its life period.
Applicability:
The infant seat is suitable for weight categories 0+.
Group 0+: less than 13kg
WARNING
DO NOT use this rearward facing restraint in seating positions
where an active frontal airbag is installed.
Your child seat can only be installed rearward facing(in the
direction opposite the one in which you are travelling) with a 3
point safety harness.
Lap belt
Lap belt and
diagonal belt
This child seat is suitable for
conventional use in all cars
equipped with 3-point seat belts
that are fitted in accordance with
European standard
(ECE44 or equivalent standard)
Important:
This child seat must only be
installed using a lap and
diagonal seat belt.
Correct fitting/suitable
Incorrect fitting/not suitable
Not to be used on this seat if a
passenger front airbag is active.
Only use on this seat if a lap and
diagonal seat belt is fitted.
? 2
? 1
? 2 ? 1

SAFETY WARNINGS
•The instruction can be retrained on the child restraint for its life
period .
•This child restraint must be used with the harness for children of
less than 13kg in weight ,and heights less than 26 inches (66cm).
•This child restraint can only be installed rearward facing using a
three-point lap and diagonal seat belt.
•Only suitable if the approve vehicles are fitted a 3-point safety
belts with retractor, approved to UN/ECE Regulation No.16 or other
equivalent Standards.
•Rigid items and plastic parts of a child restraint system must be
likely located and installed so that they are not liable, during
everyday use of the vehicle, to become trapped by a moveable seat
or in a door of the vehicle.
•This rear-facing child restraint system can not be used in seating
position where there is an airbag enabled.
•This “Special Needs Restraint” is designed to give extra support
to children who have difficulty in sitting correctly in conventional
seats. Always consult your doctor to make sure that this restraint
system is suitable for your child.
•Ensure that the strap, holding the restraint to the vehicle, are as
tight as possible. Make sure that the straps ,restrain the child at
the correct height and are not twisted.
•In an event of an accident, the child restraint system MUST BE
REPLACED.
•For maximum protection, the center rear seat position is recommended
for the safest position in most vehicles for installing a child
restraint. Only when the seat is provided with a 3-point adult belt.
•Your child restraint should not be purchased or sold as a second hand
item.It is not recommended to use child restraint older than 6 years
old as the protection in an accident may be reduced.
•This safest seating position for this child car seat is on the rear
seat of a vehicle.
•It is dangerous to make any alterations or additions to the device
without the approval of the competent authority , and a danger of not
following closely the installation instructions provided by the child
restraint manufacturer .
•Do not leave your child unattended in the seat at any time .
•Never use the child seat without fastening the child in it and
without fastening it into the car.
•The seat should be kept away from sunlight if the seat is not
provided with a textile cover, otherwise it may be too hot for the
child’s skin.
•In the event of an emergency it is important that the child can be
released quickly .This means that the buckle is not fully tamper
proof and so your child must be taught never to play with the buckle.
Please read this user guide carefully before
install the child seat and for future reference.
34
PRESS
hardness
adjuster
hardness
adjuster strap
buckle
chest pad
carrying handle
shoulder
straps
red button
handle adjuster
light blue
lap belt
diagonal
belt guide
canopy frame
canopy frame
joint parts
harness
slot
•Any luggage or other objects liable to cause injuries in the event
of a collision shall be properly secured.
•Never use the seat as a shopping bag or as a means for transporting
sometime.
•The child restraint can not be used without the cover. The seat
cover should not be replaced with any other than the one recommended
by the manufacturer, because the cover constitutes an integral part
of the restraint performance.
•Periodically inspect the harness for wear , paying particular
attention to attachment points . stitching and adjusting devices.
•Ensuring that any lap straps is worn low down , so that the pelvis
is firmly engaged, shall be stressed.
•The seat device should be changed when it has been subject to violent
stresses in an accident.
•Do not use any load bearing contact points other than those described
in the instructions and marked in the child restraint.
Features

PRESSPRESS
Pull the shoulder straps upwards to
remove the whole harness then pull
the adjuster strap until the harness
is fully tightened.
To release the harness (see point AD
JUSTING THE SHOULDER HEIGHT), press
the red button on the buckle downwards.
The harness should be adjusted as
tightly as possible without causing
discomfort to you child.
Tighten the shoulder harness
SECURING THE INFANT CARRIER
Please read the operating handbook in your vehicle to inform yourself
about the basics concerning children’s seat in vehicle .
DO NOT place this baby seat on seat with front airbgs.
This baby car seat can only be installed using a three-point vehicle
belt.
The baby car seat must be installed rearwards facing (in the direction
opposite the one in which you are traveling) .
Step 1: Adjust the handle to the
upright position .Place the child
safety seat on the vehicle's seat
ensuring it is firmly pressed
against the car seat backrest.
Step1
6
5
Step2. Slide the lap belt of the vehicle’s 3-point seatbelt through
both Lap belt guides .Let the tongue plate snap in the belt lock with
a clearly audible ”click”.Pull the shoulder belt in arrow direction
to tighten the lap belt.Check to make sure the tongue plate is locked
by pulling on the belt .
Step3.Place the diagonal belt in thediagonal belt guide at the back
of the seat
Step4.Tighten the vehicle’s own 3-pointseatbelt by pulling hard on
the positions .
click
Step 5 : Adjust the handle to the forward position .Place the child
safety seat on the vehicle's seat ensuring its handle must be firmly
against the car seat backrest.
The satisfactory position of the adult safety-belt buckle relative to
the child car seat is as the following picture. You can contact the
child car seat manufacturer if in doubt about this point.
Step2 Step3
Step4 Step5

press
ADJUST THE HANDLE
Make sure all the belts` position is right and they has not become
twisted. Also check that the cover is not impeding the movement or
fit of the belt webbing in any way.
To release your baby car seat following the above instructions in
reverse order.
The handle for the baby car seat can
be adjusted into 4 stable positions.
To adjust the handle ,please press
the red button of handle on both sides
at the same time .Now it can be
adjusted.
The carry handle has four positions:
1.Forward facing installed in the car .This position (only this position)
is suitable for the baby car seat installed on the vehicle seat .
2.Straight up for carrying .
3.Handle clicked back to initiate the rocking feature .
4.Down to support baby for feeding and play .
Ensure that the handle is locked in a position ,the harness is
correctly fitted and buckle fastened before carrying your car seat.
2 3 4 1
78
1. Adjust the handle to the position same as the following picture
2. Insert frame through sleeve of canopy.
3. Insert both ends of canopy frame into the canopy frame joint
parts which locate on the both side of the car seat and above the
handle.
4 Fix the bottom of the canopy cover to the top of the car seat back,
see the following picture.
5. Rotate the canopy frame joint parts and the canopy will reach the
proper position you want.
6. Rotate the handle and the handle will reach the proper position
you want.
When you do not need canopy just take off it in reverse order of the
above instruction.
CANOPY ASSEMBLY
12
34
56

910
These instructions are important .Please read carefully and retain
for future reference.
The child restraint can not be used without the cover.
The seat cover should not be replaced without one recommended by the
manufacturer .Because the cover constitutes an integral part of the
restraint performance.
Don’t use any car seat again after impact or accident.
Please remove the car seat out of vehicle when it is not used and
keep out reach of child.
Please always fasten the car seat when it is inside the vehicle.
Please always read the manual before use it, and the manual is
locate in the back of car seat, under the cover bag.
The cover is removable and washable at 30℃,line dry only.
If you are in doubt about using or fitting of this product or you
require any replacement parts ,please contact our customer hotline.
European safety child seat is sweeping the whole world now
Cleaning & maintenance
30℃
P
Machine
wash,cpld
Do not
bleach
Dryclean,any
solvent except
trichloroethylene
Do not
tumbel dry
Do not
iron
European safety standard
ECE 044/04
Cerficifed to ECE 044/04
Washing instruction:
