Chery V5 User manual

Preface
1
ADVICE
User’s Manual clarifies the agreement between Chery Automobile Co., Ltd. and the User on the product
quality warranty responsibility and the establishment and termination of after-sales service rights and responsibilities.
Please read this User’s Manual carefully before using our products.
User’s Manual for Chery V5
Sincere congratulations on your own of one Chery V5! Also, with great appreciation on your great favor on our company and our products.
The personnel of Chery authorized service station are trained with good professional trainings, which will sincerely provide you with the top
quality services.
Chery V5 features advanced technology and prominent performances. Your choice of Chery V5 will prove that you have extra-high
requirements on the vehicle performance and design.
Please read this manual carefully, since the information contained in this manual can let you understand how to operate and maintain your
vehicle properly so as to achieve the driving pleasure to the maximum extent.
This user’s manual applies to the Chery V5.
Chery Automobile Co., Ltd.

Preface
2
This manual is established based on the
detailed conditions of V5 vehicles
manufactured by Chery Automobile Co.,
Ltd., which only applies to the V5 vehicles
manufactured by Chery Automobile Co.,
Ltd. This manual included the latest
information up to the date when this
manual is printed. Chery Automobile Co.,
Ltd. will be wholly responsible for the
modification and explanation of this
manual and reserved the rights for product
replacement after the print of this manual
without any prior notice. Some pictures in
this manual are illustrations for reference
only. The real article should take
precedence in case of any conflict between
the pictures and the real articles.
This manual is the main evidence for
vehicle quality warranty and first free
maintenance. Please keep this manual in
your vehicle so that it’s available
whenever you need it. When to resell this
vehicle, please hand over this manual and
all the documentation attached with this
vehicle to the new owner so that they are
available whenever the new owner needs
them.
Special Statement
Please make sure to read this manual
before using this product.
Chery Automobile Co., Ltd. (hereafter
referred as “Our Company” or “Chery
Company”) defined the technical
maintenance regulations of the new
vehicle run in and of maintenance at
various stages for the products, of which
including the first 5,000 km maintenance.
Please make sure to abide by above
regulations since above defined
maintenances are vital to the safety
operation and the maintaining of good
running conditions of your vehicle.
Your claim right will be forfeited in case
of the failure of your vehicle or vehicle
parts that arising from the abuse,
negligence, improper use, the maintenance
not in accordance with the specified
mileage/period, or the warranty evidence
not signed or stamped in accordance with
the requirements, or any unauthorized
refit/attachment. Therefore, any direct or
indirect warranty application thereof will
not be accepted by the Chery authorized
service station.
Any problems of Our Company’s products
during use must be overhauled by the
Chery authorized service station. During
the overhaul process, Chery authorized
service station is entitled to decide based
on the conditions to perform the repair by
means of repair or the replacement of
equivalent parts.
If you encountered anything unclear
during the careful reading of this manual,
Chery Company and Chery authorized
service station will give you the detailed
explanation. Also, the precious advices of
vast users are highly welcomed.
Wish you pleasant driving!
Chery Automobile Co., Ltd. reserved all
copyrights of this menu

Summary
3
Chapter 1
Summary

Summary
4
Before reading this
User’s Manual, you
should understand
following things.
Thanks for your purchase of Chery vehicle.
In order to operate your vehicle properly
and guarantee your rights and benefits,
please spend some time to read this
manual carefully.
This manual provides the important
instructions and hints on the daily driving
and regular maintenance and care, with the
purpose for your familiarity with the
operation of your vehicle. Only the more
understanding to your vehicle can
guarantee the safety and economy of the
vehicle driving as well as enjoy the
pleasure thereof.
Any improper operation may damage your
vehicle as well as may be deprived of your
claim right.
The periodical maintenance to your
vehicle will help maintain the driving
performance and used value of your
vehicle. The Chery authorized service
stations all over the country boasted
numerous repair experts to provide you
with service anytime. The repair personnel
of all authorized service stations, who
passed the professional trainings, can
properly repair your vehicle and vehicle
equipment. The spare parts in Chery
authorized service station are of Chery
genuine spare parts.
Equipment Scope
This manual defined the maximum
possible equipment scope
installed in accordance with the
series V5 model plan till the print date,
namely for all the standard equipment and
optional equipment in series V5 model,
some equipment may be supplied in the
future or may be only available in certain
markets. Therefore, some items in this
manual may not apply to your vehicle.
Alarm Symbols
within This Manual
During the vehicle operation, how to
reduce the damage to the vehicle and the
vehicle equipment and how to avoid the
person injury? In this manual, the answer
for such question is included in the

Summary
5
explanation for the alarm symbols with
triangle. Please read carefully and abide
by the contents thereof.
The equipment marked with
asterisk (*) is only used in lot
size on certain model structures, which is
supplied as optional equipment for some
models or is only available in certain
markets.
When this symbol is present on
the vehicle, make sure to read
the related chapters of this manual before
any operations.
We must contribute our
responsibility and liability in the working
of environmental protection. It’s the
important step to achieve such objective
by operating your vehicle properly and
disposing the used cleaning articles and
lubricating materials in accordance with
the laws and regulations. This manual
displayed the information on this aspect by
means of tree symbol.
New Vehicle
Inspection
Before deliver the vehicle to you, the
dealer of Chery Company has already
performed the vehicle inspection in
accordance with the regulations of Chery
Automobile Co., Ltd. The dealer of Chery
Company should fill in the vehicle
delivery date in the "Vehicle Delivery
Inspection Certificate” column of this
manual and seal with the stamp of dealing
agency.
The dealer should verify the entire vehicle
performance and introduce the operation
knowledge of the vehicle against the
“Chery Vehicle Sale & Delivery Card”
that to be dually signed by the salesman
and the user.
Run in of New Vehicle
Due to the manufacture and assembling
deviations, the frication resistances
between the moving components of the
new vehicle at the initial stage of
operation will be much greater than the
ones of normal condition. The run in
effects of the vehicle at the initial stage of
operation will exert great influence on the
use lifetime, working reliability and
economy of the vehicle, therefore, the use
of new vehicle must abide by the run in

Summary
6
regulations strictly.
Run in Regulation within 1,000
km
yFull speed driving is absolutely
prohibited.
yGenerally, do not drive the vehicle at
the speed above 100 km/h.
yAvoid driving at the top speed at
whichever gear.
Run in Regulation from 1,000 km
to 1,500 km
yIncrease to the top speed gradually or
drive at the allowable max engine
speed.
Notice during Run in Period
For the driving of vehicles with engine
tachometer, the allowed short period top
engine speed is 6,000 r/min. During the
manual gearshift, make sure to shift to the
next high gear when the engine tachometer
indicator reached red indication area at the
latest.
Avoid the running of engine at
unnecessary high speed. The
earliest shift to high gear will help save the
fuel, reduce the working noise as well as
diminish the environmental pollution.
The engine speed should not be excessive
low during driving. Shift to proper gear at
reasonable time.
When at cold condition, do not run the
engine at top speed no matter at neutral
gear or any other drive gear.
The new tires don’t have best adhesion at
the beginning of use; therefore, the tires
also need run in. The vehicle speed should
be relative low during first 100 km driving
and the driving should be extremely
careful.
The new brake friction lining also needs
run in, since the brake doesn't have ideal
friction force during first 200 km driving.
During this period the brake effects are a
little poor, therefore the pressure on brake
pedal may be reasonably increased. Such
condition also applies to the each time
when replaced with new friction lining.
When the new vehicle traveled for 800km,
the wheel nuts must be re-tightened to the
specified torque. Please refer to the
chapter “Specification and Parameters” of
this manual for correct torque values. Also,

Summary
7
if the wheel has been replaced or the
wheel nuts have been loosened, then the
wheel nuts should be re-tightened in
accordance with the specified torque after
traveled for 800km.
“One-To-One” Service
In order to provide you with better service
and vehicle use, the dealer of Chery
Company will appoint one service counsel
to serve you at the purchase of your
vehicle. In case of any problems during
your vehicle use, you may contact your
service counsel, who will provide you
with best services.

Summary
8
Vehicle Register No.:
Vehicle Delivery Inspection Evidence
This is to certify that this vehicle has completed the
vehicle delivery inspection defined by Chery Automobile Co., Ltd.
and its quality met with the technical specification of Chery
Automobile Co., Ltd.
Vehicle Delivery Date: _____________
Dealer Stamp:
Vehicle Owner Name (Unit) Responsible Service Station Name
—————————————————— —————————————————————
—————————————————— —————————————————————
Address————————————— Responsible————————————
——————————————————————
Tel:————————————————— Tel:——————————————

Summary
9
Vehicle Delivery Date Dealer Stamp
Model:
Bod
y
VIN No:
Engine Serial No.:
Transmission Serial No.:

Summary
10
Chery Vehicle Sale & Delivery Sheet
Catego
ry
No. Item Whether inspected OK and
clearly explained
1 Engine Yes □No □
2 Engine oil, brake liquid, steering liquid, coolant, battery liquid, windscreen
cleaning liquid.
Yes □No □
3 VIN number, engine serial number, nameplate and other identifications Yes □No □
4 Entire vehicle locks Yes □No □
5 Entire vehicle lamps, including head lamp, turn lamp, fog lamp, combined lamp,
compartment lamp, brake lamp, backup lamp, tail lamp, reading lamp, door
lamp, and instrument lamp.
Yes □No □
6 Windscreen glass and body paint Yes □No □
7 Speedometer, engine tachometer, odometer Yes □No □
8 Hub cap, spare tire in luggage boot, vehicle attached tools and entire vehicle
operation manual
Yes □No □
9 Safety belt, seat, cigarette lighter, A/C switch and vent, glove box and sun visor. Yes □No □
Entire Vehicle Performance
10 Glass lifter, rear view mirror, wiper, washer, horn, sunroof, backup radar, vehicle
telephone, radio (CD player) and antenna.
Yes □No □

Summary
11
1 93# gasoline fuel Yes □No □
2 Normal operation during run in. Yes □No □
3 Operation of entire vehicle lamps Yes □No □
4 Meaning of alarm indicators Yes □No □
5 Correct maintenance period and mileage Yes □No □
6 Vehicle maintenance items in winter and summer. Yes □No □
7 Correct understanding of cooling system/coolant usage. Yes □No □
8 Correct operation of A/C Yes □No □
9 Notices for vehicle start Yes □No □
10 Correct operation of audio equipment Yes □No □
Oper
ation
Kno
wled
ge
11 Correct operation of sunroof Yes □No □
SalesmanSignature: Date: UserSignature: Date:

Summary
12
“One-To-One” Counseling Service Card
UserName: VehiclePurchaseDate
SalesAgency: Model:
Vehicle VIN Number:
Following items should be validated by the user:
I. Related items confirmation at vehicle delivery (“√" for Yes as
“×” for No)
□Basic vehicle operation method has been introduced and the
onsite delivery inspection is certified OK.
□Quality warranty policy has been introduced.
□Vehicle driving notices has been introduced.
□The importance of vehicle periodical maintenance and
maintenance period/mileage has been introduced.
□The importance of vehicle maintenance/repair at Chery
authorized service station has been noted.
□User’s Manual has been handed over and the reading is
reminded.
□The function and operation method of service hotline of Chery
Company has been noted.
II. “One-To-One” counseling service mode introduction (“√” for
Yes as “×” for No)
□Contact the service counsel instead of anyone else in case of any
problems or needs.
□The service counsel appointed by the service station is the
exclusive person to communicate and contact with the user.
□One user is only served by one service counsel: "One-To-One”
□ User may choose other service counsel when dissatisfied with
current service counsel.
III. Major job introduction of service counsel (“√” for Yes as “×”
for No).
□Repair maintenance service reception
□Complaint acceptance
□Periodical maintenance reminding visits
□Repair/Maintenance counsel explanation
□Periodical greeting visits
□Repair/maintenance reservation acceptance
□Service activity reminding visits
□Annual authentication reminding/acceptance
□Important festival greeting
□Other activities of user’s needs
IV. Establishment of “One-To-One” counseling service
relationship.
Service Counsel Card
User Signature/Date: Service Counsel Signature/Date:
FormOne

Summary
13
“One-To-One” Counseling Service Card
UserName: VehiclePurchaseDate
SalesAgency: Model:
Vehicle VIN Number:
Following items should be validated by the user:
I. Related items confirmation at vehicle delivery (“√" for Yes as
“×” for No)
□Basic vehicle operation method has been introduced and the
onsite delivery inspection is certified OK.
□Quality warranty policy has been introduced.
□Vehicle driving notices has been introduced.
□The importance of vehicle periodical maintenance and
maintenance period/mileage has been introduced.
□The importance of vehicle maintenance/repair at Chery
authorized service station has been noted.
□User’s Manual has been handed over and the reading is
reminded.
□The function and operation method of service hotline of Chery
Company has been noted.
II. “One-To-One” counseling service mode introduction (“√” for
Yes as “×” for No)
□Contact the service counsel instead of anyone else in case of any
problems or needs.
□The service counsel appointed by the service station is the
exclusive person to communicate and contact with the user.
□One user is only served by one service counsel: "One-To-One”
□ User may choose other service counsel when dissatisfied with
current service counsel.
III. Major job introduction of service counsel (“√” for Yes as “×”
for No).
□Repair maintenance service reception
□Complaint acceptance
□Periodical maintenance reminding visits
□Repair/Maintenance counsel explanation
□Periodical greeting visits
□Repair/maintenance reservation acceptance
□Service activity reminding visits
□Annual authentication reminding/acceptance
□Important festival greeting
□Other activities of user’s needs
IV. Establishment of “One-To-One” counseling service
relationship.
Service Counsel Card
User Signature/Date: Service Counsel Signature/Date:
FormTwo

Interior Device Operation and Adjustment
15
Common Vehicle Symbol Instruction
Symbol Definition Symbol Definition Symbol Definition
Engine
self-examination
trouble light
Anti-lock brake
system Position lamp
Glass lifter switch
prohibited Safety warning
Engine oil pressure
alarm lamp
Rear fog light Throttle trouble
indicator
Coolant
temperature
overheating alarm
(red indicator)
Front fog light
Cigarette lighter
Coolant
temperature
normal indicator
(green indicator)
A/C A/C system
Brake system
trouble alarm
lamp
Luggage boot door
opened

Interior Device Operation and Adjustment
16
Symbol Definition Symbol Definition Symbol Definition
Battery
Fasten the safety
belt
Windscreen
cleaning
High beam lamp
Danger flash
alarm lamp Horn
Low beam lamp Power + pole Seat heating
Head lamp switch
Air bag trouble
indicator
Windscreen
defrosting
Parking brake
indicator
Low fuel level
alarm indicator
Rear windscreen
heating indicator
Lock indicator
External rear view
mirror heating External air circulation

Interior Device Operation and Adjustment
17
Symbol Definition Symbol Definition Symbol Definition
Unlock indicator
Interior lamp
switch indicator Internal air circulation
Door and luggage
boot cover not
closed alarm lamp Sound alarm Air bag
identification
Ve h i c l e
maintenance
indicator
Right turn
indicator Left turn indicator

Interior Device Operation and Adjustment
18
Symbol Definition
Transmission gear
position indicator
Backup radar
distance display
Fuel consumption
display

Interior Device Operation and Adjustment
19
Chapter 2 Interior Device Operation and Adjustment

Interior Device Operation and Adjustment
20
Steering Wheel/
Ignition Switch
The combined steering wheel
lock/ignition switch has following key
positions:
LOCK - Ignition switch is turned off
as the steering wheel is locked.
When the key is pulled out from the
ignition switch, the steering wheel lock
will actuate to lock the steering wheel.
In order to lock the steering wheel,
rotate the steering wheel once after the
withdrawal of the key, till the
engagement sound as the steering
wheel is locked.
ACC – Unlock of steering system.
When the circuits of the electrical
accessories are turned on, the small
electrical appliances such as interior
lamp can be operated, however the
ignition switch and the main electrical
circuits are all turned off.
If it fails or has difficulty to rotate the
key from the LOCK position to such
position, the lock mechanism of the
steering wheel can be released by rotate
the steering wheel around slightly.
The ignition switch key should not be
left at such position overlong so as to
avoid the depletion of the battery
power.
ON – All electrical circuits can operate
once the ignition circuit is turned on.
The alarm lamp and the indicator will
light. This is the normal position of key
during driving as well as the position
must be selected during vehicle towing.
START – Turn on the start motor and
start the engine.
When the key is at such position, the
front headlamp and the electrical
devices with higher power
consumption will be turned off.
The ignition switch is equipped with
repeated start proof device internally.
Once the engine is running, such
device can prevent the mis-start of the
starter so as to avoid the damage to the
starter and the engine flywheel.
If the start fails, then it’s must to rotate
the ignition key to LOCK position
before rotate to this position for restart.
After start, the key will bounce back to
ON position when the key is released
Adjustment of Steering
Wheel
The key must be released
once the engine is started.
Do not hold at the START
position for much longer.
