Chery Karry series User manual

Preface
1
ADVICE
User’s Manual clarifies the agreement between Chery
Automobile Co., Ltd. and the User on the product quality
warranty responsibility and the establishment and termination of
after-sales service rights and responsibilities. Please read this
User’s Manual carefully before using our products.
User’s Manual for Chery Karry series
Sincere congratulations on your own of one Chery Karry! Also, with great appreciation on your great favor on our company and our
products.
The personnel of Chery authorized service station are trained with good professional trainings, who will sincerely provide you with the top
quality services.
Chery Karry features advanced technology and prominent performances. Your choice of Chery Karry will prove that you have extra-high
requirements on the vehicle performance and design.
Please read this manual carefully, since the information contained in this manual can let you understand how to operate and maintain your
vehicle properly so as to achieve the driving pleasure to the maximum extent.
This user’s manual applies to the Chery Karry.
Chery Automobile Co., Ltd.

Preface
2
This manual is established based on the
detailed conditions of Karry vehicles
manufactured by Chery Automobile Co.,
Ltd., which only applies to the Karry
vehicles manufactured by Chery
Automobile Co., Ltd. This manual
included the latest information up to the
date when this manual is printed. Chery
Automobile Co., Ltd. will be wholly
responsible for the modification and
explanation of this manual and reserved
the rights for product replacement after the
print of this manual without any prior
notice. Some pictures in this manual are
illustrations for reference only. The real
article should take precedence in case of
any conflict between the pictures and the
real articles.
This manual is the main evidence for
vehicle quality warranty. Please keep this
manual in your vehicle so that it’s
available whenever you need it. When you
resell this vehicle, please hand over this
manual and all the documentation attached
with this vehicle to the new owner so that
they are available whenever the new
owner needs them.
Special Statement
Please make sure to read this manual
before using this product, especially
“Quality warranty service” chapter,
avoiding exempted from the right to enjoy
quality warrantee service provided by our
company due to violating operation
manual.
Chery Automobile Co., Ltd. (hereafter
referred as “Our Company” or “Chery
Company”) defined the technical
maintenance regulations of the new
vehicle run in and of maintenance at
various stages for the products, of which
including the first 5,000 km maintenance.
Please make sure to abide by above
regulations since above defined
maintenances are vital to the safety
operation and the maintaining of good
running conditions of your vehicle.
Your claim right will be forfeited in case
of the failure of your vehicle or vehicle
parts that arising from the abuse,
negligence, improper use, the maintenance
not in accordance with the specified
mileage/period, or the warranty evidence
not signed or stamped in accordance with
the requirements, or any unauthorized
refit/attachment. Therefore, any direct or
indirect warranty application thereof will
not be accepted by the Chery authorized
service station.
Any problems of Our Company’s products
during use must be overhauled by the
Chery authorized service station. During
the overhaul process, Chery authorized
service station is entitled to decide based
on the conditions to perform the repair by
means of repair or the replacement of
equivalent parts.
If you encountered anything unclear
during the careful reading of this manual,
Chery Company and Chery authorized
service station will give you the detailed
explanation. Also, the precious advices of
vast users are highly welcomed.
Chery Automobile Co., Ltd. reserved all
copyrights of this manual
Wish you pleasant driving!

Content
3
Summary...............................................................6
Equipment Scope ..................................................................6
Alarm Symbols within This Manual .....................................6
New Vehicle Inspection.........................................................6
Run in of New Vehicle ..........................................................7
Common Vehicle Symbol Instruction..................................15
Driving ...............................18
Start ..................................................................................... 18
Caution of Vehicle Exhaust Fume .......................................19
Engine Control System Self-adaptive Function ..................20
Vehicle Speed Limit ............................................................20
Engine stall..........................................................................20
Brake...................................................................................21
Operation of Manual Transmission .....................................24
Steering ...............................................................................24
Paddling ..............................................................................25
Three-Way Catalytic Converter...........................................25
Parking ................................................................................26
Fuel Consumption ...............................................................26
Radiator Fan........................................................................27
I. Introduction of Vehicle Functions .................................... 30
Steering wheel lock/ ignition switch ...................................30
Horn ....................................................................................30
Windscreen wiper and cleaning system............................... 31
Interior rearview mirror....................................................... 32
Electrical window control switch ( )...............................33
Ashtray, cigarette lighter .....................................................34
Use of protection net ...........................................................34
Light Control......................... 34
Headlamp switch.................................................................34
Conversion of high beam/ dipped headlight........................35
Flicker of headlamp.............................................................35
Front fog lamp switch .........................................................35
Rear fog lamp switch...........................................................35
Turning indicator.................................................................36
Lower left button on the instrument panel...........................36
Adjusting button of instrument illumination .......................36
Front interior ceiling lamp...................................................36
Rear interior ceiling lamp....................................................37
Danger flash alarm lamp switch ..........................................37
Braking lamp.......................................................................37
Reversing lamp....................................................................37
Sound system.......................... 37
Panel ( ).........................................................................38
Instruction of Panel .............................................................39
Operation Method ...............................................................40
A/C System .........................................................................43
Ventilation ...........................................................................43
Instrument Panel...................... 52
Key......................................................................................60
Door lock.............................................................................60
Rear side door .....................................................................61
Back door ............................................................................61
Central lock system ( ).....................................................61
Engine bonnet......................................................................62

Content
4
Open....................................................................................62
Close ...................................................................................62
Fuel filler cap and fuel tank cover.......................................62
Seats & Safety Protection .............64
Seat & safety protection ..............65
Seat......................................................................................65
Seat safety belt ....................................................................69
Air bag（ ）.................................................................... 70
Child safety seat ..................................................................72
Emergency Procedures ..................75
Hazard warning flasher lamp ..............................................75
Duly refuel ..........................................................................75
Replace the bulb..................................................................76
Fuse and relay .....................................................................78
Central fuse box ..................................................................79
Driver Tool ..........................................................................81
Replace the wheel ...............................................................81
Battery.................................................................................84
Engine battery-assisted start method ...................................85
Tow truck ............................................................................86
Care & Maintenance ....................88
Items you must follow.........................................................88
Engine Compartment Maintenance Items ...........................90
Tire......................................................................................94
Driving belt .........................................................................95
Wash vehicle .......................................................................96
Regulations on the regular maintenance..............................99
First 5000km Maintenance Card ..................................................104
First 5000km Maintenance Card .......................................105
Maintenance Record................... 106
Safety Protection System................................................... 112
Warranty for a complete vehicle........................................ 115
Quality warranty period for special parts (limited to the
original quality problems only) ......................................... 115
Vehicle Identification Description.....................................121
Fuel ...................................................................................122
Engine oil ..........................................................................123
Vehicle fluids..................................................................... 123
Weight ...............................................................................124
Capacity ............................................................................125
Mass Parameters................................................................126
Wheel and Tire .................................................................. 127
Engine Data....................................................................... 128
Vehicle dimension .............................................................130

Summary
5
Chapter 1 Summary

Summary
6
Before reading this User’s
Manual, you should
understand following things.
Thanks for your purchase of Chery vehicle.
In order to operate your vehicle properly
and guarantee your rights and benefits,
please spend some time to read this
manual carefully.
This manual provides the important
instructions and hints on the daily driving
and regular maintenance and care, with the
purpose for your familiarity with the
operation of your vehicle. Only the more
understanding to your vehicle can
guarantee the safety and economy of the
vehicle driving as well as enjoy the
pleasure thereof.
Any improper operation may damage your
vehicle as well as may be deprived of your
claim right.
The periodical maintenance to your
vehicle will help maintain the driving
performance and used value of your
vehicle. The Chery authorized service
stations all over the country boasted
numerous repair experts to provide you
with service anytime. The repair personnel
of all authorized service stations, who
passed the professional trainings, can
properly repair your vehicle and vehicle
equipment. The spare parts in Chery
authorized service station are of Chery
genuine spare parts.
Equipment Scope
This manual defined the maximum
possible equipment scope installed in
accordance with the series Karry model
plan till the print date, namely for all the
standard equipment and optional
equipment in series Karry model, some
equipment may be supplied in the future
or may be only available in certain
markets. Therefore, some items in this
manual may not apply to your vehicle.
Alarm Symbols within
This Manual
During the vehicle operation,
how do you reduce the damage to
the vehicle and the vehicle
equipment, and how do you avoid the
person injury? In this manual, the answer
for such question is included in the
explanation for the alarm symbols with
triangle. Please read carefully and abide
by the contents thereof.
The equipment marked with
asterisk (*) is only used in lot
size on certain model structures, which is
supplied as optional equipment for some
models or is only available in certain
markets.
When this symbol is present on
the vehicle, make sure to read
the related chapters of this
manual before any operations.
We must contribute our
responsibility and liability in the
working of environmental
protection. It’s the important step to
achieve such objective by operating your
vehicle properly and disposing the used
cleaning articles and lubricating materials
in accordance with the laws and
regulations. This manual displayed the
information on this aspect by means of
tree symbol.
New Vehicle Inspection
Before deliver the vehicle to you, the
dealer of Chery Company has already
performed the vehicle inspection in
accordance with the regulations of Chery
Automobile Co., Ltd. The dealer of Chery
Company should fill in the vehicle
delivery date in the "Vehicle Delivery
Inspection Certificate” column of this

Summary
7
manual and seal with the stamp of dealing
agency.
The dealer should verify the entire vehicle
performance and introduce the operation
knowledge of the vehicle against the
“Chery Vehicle Sale & Delivery Card”
that to be dually signed by the salesman
and the user.
Run in of New Vehicle
Due to the manufacture and assembling
deviations, the frication resistances
between the moving components of the
new vehicle at the initial stage of
operation will be much greater than the
ones of normal condition. The run in
effects of the vehicle at the initial stage of
operation will exert great influence on the
use lifetime, working reliability and
economy of the vehicle, therefore, the use
of new vehicle must abide by the run in
regulations strictly.
Run in Regulation within 1,000 km
yFull speed driving is absolutely
prohibited.
yGenerally, do not drive the vehicle at
the speed above 100 km/h.
yAvoid driving at the top speed at
whichever gear.
Run in Regulation from 1,000 km
to 1,500 km
yIncrease to the top speed gradually or
drive at the allowable max engine
speed.
Notice during Run in Period
For the driving of vehicles with engine
tachometer, the allowed short period top
engine speed is 6,000 rpm. During the
manual gearshift, make sure to shift to the
next high gear when the engine tachometer
indicator reached red indication area at the
latest.
Avoid the running of engine at
unnecessary high speed. The
earliest shift to high gear will
help save the fuel, reduce the
working noise as well as diminish the
environmental pollution.
The engine speed should not be excessive
low during driving. Shift to proper gear at
reasonable time.
When at cold condition, do not run the
engine at top speed no matter at neutral
gear or any other drive gear.
The new tires don’t have best adhesion at
the beginning of use; therefore, the tires
also need run in. The vehicle speed should
be relative low during first 100 km driving
and the driving should be extremely
careful.
The new brake friction lining also needs
run in, since the brake doesn't have ideal
friction force during first 200 km driving.
During this period the brake effects are a
little poor, therefore the pressure on brake
pedal may be reasonably increased. Such
condition also applies to the each time
when replaced with new friction lining.
When the new vehicle traveled for 800km,
the wheel nuts must be re-tightened to the
specified torque. Please refer to the
chapter “Specification and Parameters” of
this manual for correct torque values. Also,
if the wheel has been replaced or the
wheel nuts have been loosened, then the
wheel nuts should be re-tightened in
accordance with the specified torque after
traveled for 800km.
“One-To-One” Service
In order to provide you with better service
and vehicle use, the dealer of Chery
Company will appoint one service counsel
to serve you at the purchase of your
vehicle. In case of any problems during
your vehicle use, you may contact your
service counsel, who will provide you
with best services.

Summary
8
Vehicle Delivery Inspection Evidence
This is to certify that this vehicle has
completed the vehicle delivery inspection
defined by Chery Automobile Co., Ltd. and its
quality met with the technical specification of
Chery Automobile Co., Ltd.
VehicleDeliveryDate:
Dealer Stamp:
Vehicle Owner Name (Unit) Responsible Service Station Name
—————————————————— —————————————————————
—————————————————— —————————————————————
Address————————————— Responsible————————————
————————————————————
Tel:————————————————— Tel: —————————————————

Summary
9
Vehicle information
Vehicle delivery
Dealer stamp
Model
Bod
y
VIN No:
T
ransmission No:
Engine
No:

Summary
10
Chery Vehicle Sale & Delivery Sheet
Category No. Item Whether inspected OK and
clearly explained
1 Engine. Yes □ No □
2 Engine oil, brake liquid, steering liquid, coolant, battery liquid, windscreen
cleaning liquid.
Yes □ No □
3 VIN number, engine serial number, nameplate and other identifications. Yes □ No □
4 Entire vehicle locks. Yes □No □
5 Entire vehicle lamps including head lamp, turn lamp, fog lamp, combined
lamp, compartment lamp, brake lamp, backup lamp, tail lamp, reading lamp,
and instrument lamp.
Yes □No □
6 Windscreen glass and body paint. Yes □No □
7 Speedometer, engine tachometer, odometer. Yes □No □
8 Hub cap, spare tire, vehicle attached tools and entire vehicle operation manual. Yes □No □
9 Safety belt, seat, cigarette lighter, A/C switch and vent, glove box and sun
visor.
Yes □No □
Entire
Ve h i c l e
Performance
10 Glass lifter, rear view mirror, wiper, washer, horn, radio. Yes □No □

Summary
11
1 93# gasoline fuel. Yes □ No □
2 Normal operation during run in. Yes □ No □
3 Operation of entire vehicle lamps. Yes □No □
4 Meaning of alarm indicators. Yes □No □
5 Correct maintenance period and mileage. Yes □No □
6 Vehicle maintenance items in winter and summer. Yes □No □
7 Correct understanding of cooling system/coolant usage. Yes □No □
8 Correct operation of A/C. Yes □No □
9 Notices for vehicle start. Yes □No □
Operation
Knowledge
10 Correct operation of audio equipment. Ye s □No □
SalesmanSignature: Date: UserSignature: Date:

Summary
12
“One-To-One” Counseling Service Card
(Service Station)
User Name: Vehicle Purchase Date:
Sales Agency: Model:
Vehicle VIN Number:
Following items should be validated by the user:
I. Related items confirmation at vehicle delivery (“√” for Yes as
“×” for No)
□Basic vehicle operation method has been introduced and the
onsite delivery inspection is certified OK.
□Quality warranty policy has been introduced.
□Vehicle driving notice has been introduced.
□The importance of vehicle periodical maintenance and
maintenance period/mileage has been introduced.
□The importance of vehicle maintenance/repair at Chery
authorized service station has been noted.
□User’s Manual has been handed over and the reading is
reminded.
□The function and operation method of service hotline of Chery
Company has been noted.
II. “One-To-One” counseling service mode introduction (“√” for
Yes as “×” for No)
□Contact the service counsel instead of anyone else in case of
any problems or needs.
□The service counsel appointed by the service station is the
exclusive person to communicate and contact with the user.
□One user is only served by one service counsel: “One-To-One”
□User may choose other service counsel when dissatisfied with
current service counsel.
III. Major job introduction of service counsel (“√” for Yes as “×”
for No).
□Repair maintenance service reception
□Complaint acceptance
□Periodical maintenance reminding visits
□Repair/Maintenance counsel explanation
□Periodical greeting visits
□Repair/maintenance reservation acceptance
□Service activity reminding visits
□Annual authentication reminding/acceptance
□Important festival greeting
□Other activities of user’s needs
IV. Establishment of “One-To-One” counseling service
relationship.
Service Counsel Card
User Signature/Date: Service Counsel Signature/Date
Form one--- Saved by customer

Summary
13
“One-To-One” Counseling Service Card
(Customer)
User Name: Vehicle Purchase Date:
Sales Agency: Model:
Vehicle VIN Number:
Following items should be validated by the user:
V. Related items confirmation at vehicle delivery (“√” for Yes as
“×” for No)
□Basic vehicle operation method has been introduced and the
onsite delivery inspection is certified OK.
□Quality warranty policy has been introduced.
□Vehicle driving notice has been introduced.
□The importance of vehicle periodical maintenance and
maintenance period/mileage has been introduced.
□The importance of vehicle maintenance/repair at Chery
authorized service station has been noted.
□User’s Manual has been handed over and the reading is
reminded.
□The function and operation method of service hotline of Chery
Company has been noted.
VI. “One-To-One” counseling service mode introduction (“√” for
Yes as “×” for No)
□Contact the service counsel instead of anyone else in case of
any problems or needs.
□The service counsel appointed by the service station is the
exclusive person to communicate and contact with the user.
□One user is only served by one service counsel: “One-To-One”
□User may choose other service counsel when dissatisfied with
current service counsel.
VII. Major job introduction of service counsel (“√” for Yes as “×”
for No).
□Repair maintenance service reception
□Complaint acceptance
□Periodical maintenance reminding visits
□Repair/Maintenance counsel explanation
□Periodical greeting visits
□Repair/maintenance reservation acceptance
□Service activity reminding visits
□Annual authentication reminding/acceptance
□Important festival greeting
□Other activities of user’s needs
VIII. Establishment of “One-To-One” counseling service
relationship.
Service Counsel Card
User Signature/Date: Service Counsel Signature/Date
Form one--- Saved by customer

Summary
15
Common Vehicle Symbol Instruction
Symbol Definition Symbol Definition Symbol Definition
Engine
self-examination
trouble light
Anti-lock brake
system Position lamp
Interior lamp switch
indicator Safety warning
Engine oil pressure
alarm lamp
Rear fog light
Cigarette lighter
Coolant temperature
overheating alarm
(red indicator)
Front fog light
Brake system trouble
alarm lamp Windscreen cleaning
A/C A/C system Fasten the safety belt Horn

Summary
16
Symbol Definition Symbol Definition Symbol Definition
Battery
Danger flash alarm
lamp
Windscreen
defrosting
High beam lamp Power + pole Air bag identification
Low beam lamp
Air bag trouble
indicator External air
circulation
Head lamp switch
Low fuel level alarm
indicator Internal air
circulation
Parking brake
indicator
Right turn indicator Left turn indicator

Driving
17
Chapter 2 Driving

Driving
18
Driving
Start
Preparation before Start
The engine start is controlled by the
engine electrical control system.
Do not step on the accelerator before start
and during start when starting the
electrical injection engine. The accelerator
should be used only when having difficult
start. Please refer to the section “Engine
Start” for the details of vehicle start.
The long period high speed
idling running of the engine
will result in the overheating
of the engine and the exhaust system,
which may result in the danger of fire
or other damages. Therefore, do not
park, idling run or driving on the
ground covered with dry grass and
other dry coverings. The exhaust
system will increase the temperature
of the engine compartment and the
exhaust pipe that may cause fire.
Do not start the vehicle in
the closed garage or other
closed locations since the
vehicle exhaust gas is poisonous.
Make sure to open the garage gate
before the engine start. Refer to the
section “Caution of Vehicle Exhaust
Fume” for details.
Safety Notice
The idle speed of the engine is controlled
by the electrical control system. The idle
speed at engine start is quite high to help
increase the engine temperature. The idle
speed should reduce automatically when
the engine temperature is increased. Please
deliver your vehicle to the Chery
authorized service station for overhaul if
the idle speed can’t reduce automatically.
Do not run the engine at the speed higher
than specified idle speed for more than 10
min.
Before Vehicle Start
1. Make sure all passengers are
fastened with safety belt. Please
refer to the chapter "Seat and Safety
Protection” for the details of safety
belt and its correct operation
method.
2. Make sure the front head lamp and
other electrical fittings are turned
off.
3. Make sure to lift up the handbrake.
4. Make sure that the gear selector
lever is at neutral gear or parking
gear.
5. Switch the ignition switch to (2), but
not to (3).
If the rotation of the key needs great effort,
it may rotate the steering around, till the
key can rotate freely. The occurrence of
such condition may have following
causes:
yDeflection of front wheel.
yThe front wheel touched with the
road curb.
yThe steering wheel is rotated during
get-on and get-off (self-lock of the
steering wheel).
6. At the same time when the ignition
key is turned on, make sure that the
dashboard alarm lamp lights shortly.
If not, then it needs to deliver your
vehicle to the Chery authorized
service station for overhaul.
If the driver safety belt is fastened
before turning on the ignition key, then
the safety belt alarm lamp won’t light.

Driving
19
Engine Start
1. Rotate the ignition switch to the 3
position but not step down the
accelerator, release the key after the
engine start and the key will return
to the 2 position.
2. If the temperature is higher than -12
℃, then the engine should not be
started within 5s during the first start.
Instead, it should rotate the key to
the OFF position and wait for 10s
before retry.
3. If the temperature is lower than -12
℃, then the engine should not be
started within 15s during the first
start. Instead, it should rotate the key
to the OFF position and wait for 10s
before retry. If the two consecutive
starts all fail, then step down the
accelerator to the end and hold
before rotating the key to the 3
position. After the engine start,
release the key and release the
accelerator pedal slowly following
the increasing of the engine speed.
4. After the engine start, run at idle
speed for several seconds, step down
the clutch, shift to the drive gear,
release the handbrake and prepare
the driving.
5. The normal environment
temperature condition of the engine
start is -25 ~40 (it may present℃℃
other abnormal conditions when the
environment temperate is out of such
scope).
Caution of Vehicle
Exhaust Fume
In despite of without colour or smell, the
vehicle exhaust fume contains the carbon
monoxide, of which the danger must be
cautioned. The certain contents in the
engine exhaust gas and the certain
chemicals contained or emitted by certain
vehicle components may result in the
cancer, the defect of the new born or other
damage of the genital system.
If you smell the fume
peculiar smell within the
vehicle, please deliver
your vehicle to the Chery
authorized service station for
overhaul immediately. Do not
continue to drive. The exhaust fume
is one poisonous substance that
may endanger the life.
The exhaust system and the vehicle
ventilation system should be checked
under following conditions:
yWhen the vehicle is lifted for
overhaul.
yWhen the sound of exhaust system is
changed.
yWhen the vehicle is damaged due to
the collision.
Ventilation Notice
When the vehicle is parked in the open
field for long period idle or when the
persons rest in the vehicle, the window
should be opened for at lease 2.5cm. Or
open the A/C system ventilation function
to let the fresh air into the vehicle.
Vent

Driving
20
Clean the snow, leaf fall
or other foreign articles
blocked in the air inlet so
as to improve the vehicle ventilation
capability.
Engine Control System
Self-adaptive Function
If the battery cable is once removed from
the battery before refit, then the vehicle
may present some abnormal evidences
during the initial period of the driving.
This is the engine control system is
re-learning to adapt to the engine, which
belongs to normal condition.
Vehicle Speed Limit
According to Karry vehicle working
conditions, we offer a max. vehicle speed
limit and we adding the following function
for EFI：
When the vehicle speed reaches 135km/h,
the fuel supply is cut off automatic to limit
the speed. When the vehicle speed
decreases to 120km/h,the engine resumes
fuel supply.
It’s recommended that you
reduce the accelerator
actively when the speed is
close to 135km/h lest the vehicle fuel
supply is cut off and resumed again and
again, causing higher exhaust
temperature.
Engine stall


Release the accelerator pedal. Wait the
engine to lower to idle speed and then turn
off the ignition switch.
Please do not step down
the accelerator pedal
before turning off the
engine.
After long period high speed driving, do
not turn off the engine immediately after
parking. Run the engine at the speed
higher than idle speed for two more
minutes so as to lower the engine
temperature gradually.
Turn off the ignition switch, the
temperature will still be
very high after the turn-off
of the engine and the
radiator electrical cooling fan will
still keep running. Even the cooling
fan stops running, it may run
suddenly again due to excessive high
temperature. Therefore, cautions
should be taken when working near
the engine so as to avoid the
scalding.
