Chipolino QUICK FOLD User manual

This product is produced in accordance with Toy
safety Directive 2009/48/EC of the European Parliament and the Council, the
standards applicable for this toy and the regulations of national legislation.
PLEASE READ CAREFULLY THIS INSTRUCTION MANUAL
AND KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE!
KIDS’ TOY
TRICYCLE
„QUICK FOLD”

1
FOLLOW ALL WARNINGS, INSTRUCTIONS AND RECCOMENDATIONS IN
THIS MANUAL IN ORDER TO GUARANTEE THE SAFE USE OF THIS PRODUCT:
WARNING! USE ONLY UNDER DIRECT ADULT SUPERVISION!
WARNING! THIS TOY HAS NO BRAKES!
WARNING! THE TOY IS NOT SUITBALE FOR CHILDREN UNDER 1,5 YEARS!
WARNING! USE FOR CHILDREN OLDER THAN 1,5 YEARS AND WEIGHT UP TO 25kg.
WARNING! DO NOT USE FOR CHILDREN OVER 25KG – DANGER OF OVERLOADING
THE TOY!
WARNING! BEFORE USING THE TRICYCLE, TEACH THE CHILD THE CORRECT WAY TO USE
IT AND THE SAFETY RULES.
WARNING! USE THE TOY ONLY FOR ITS PURPOSE.
WARNING! USE THE TOY ONLY DURING THE DAY ON EVEN PLAYGROUNDS AND AT A SAFE
DISTANCE FROM STREETS OR ROAD LANES FOR VEHICLES.
WARNING! KEEP AWAY FROM FIRE OR OTHER HEAT SOURCES!
WARNING! TO AVOID THE DANGER OF INJURY ALWAYS REMOVE THE PUSH HANDLE
WHENEVER THE CHILD IS RIDING THE TOY ON HIS OWN!
Adult assembly required!
DO NOT allow presence of children under 3 years before assembly of the TOY is complete.
In this way, you will avoid their access to small or loose parts!
The TOY is intended for one child at a time ONLY!
DO NOT let other children push the tricycle!
The TOY is NOT suitable for running or skating!
 CeaseusingtheTOYifyoundmissingordamagedparts.
DO NOT let the child stand on the footrest or the seat to avoid injury.
The child must wear shoes when using the TOY!
DO NOTtiestringsoraccessoriestotheTOYinordertoavoidtheriskofsu󰀨ocation.
DO NOT place more than 0,2 kg load in the front storage basket.
DO NOT place more than 0,5 kg load in the rear storage basket.
DO NOT put items or luggage in the handle bar or the parent handle in order to avoid risk of injury
resulting from the toy’s instability and tipping over!
DO NOT place items or heavy objects in the TOY or on it during storage or transportation to avoid
damage to the frame.
DO NOT use another transport means to move the TOY by pulling it.
DO NOT allow the child using the TOY or other children around it to touch the wheels or put items in
them.
Use away from rivers, pools, stairs or hurdles!
 DonotmakechangesormodicationstotheTOYframe!Ifnecessary,contacttheretaileroran
authorized service center for advice and repair.
Use only spare parts, which are approved by the producer and recommended by the distributor or
 companyservice!Theproducerrevokesallresponsibilityincasepartsdi󰀨erentfromthe original
ones have been used.
 Keepnylonpackagesawayfromchildrentoavoidriskofsu󰀨ocation!
CAUTION! WARNINGS!

2
PRODUCT FEATURES
MAIN PARTS
This is a functional TOY whose purpose is to create in the child initial skills to coordinate its arms
and feet when riding a tricycle or bicycle.
IMPORTANT! Remove the parent handle when you are sure that the child can ride the tricycle on
his own and unaided.
Suitable for children older than 1,5 years with weight up to 25 kg
Can be driven by the child using the pedals;
Can be pushed by an adult and the child lays his feet on the foot rest
Two positions of the seat – forward facing and face-to-face mode – rotatable seat;
Safety bumper;
Parking device;
Adjustable canopy;
Front and rear storage baskets;
Toy can be folded for better storage.
Canopy
Seat
Handle
Handlebar
Fender
Pedal
Rear wheel
Rear basket
Front bumper
Safety belt
Push handle
Front
wheel

3
1Canopy, set – 1 pc 7Pedals - set 2 pcs
2Seat, set – 1 pc 8Front bumper– 2 pcs
3Push handle – 1 pc 9Front basket – 1 pc
4Frame – 1 pc 10 Handlebar – 1 pc
5Rear wheel – 2 pcs 11 Rear basket, set – 1 pc
6Front wheel, set – 1 pcs
Please, make sure if these parts are in the package.
Some of the parts may be pre-installed by the manufacturer.
Necessary tools: No tools are needed to assemble the tricycle.
ASSEMBLY INSTRUCTIONS
IMPORTANT! FOLLOW EXACTLY THE INSTRUCTIONS GIVEN AND CHECK THE PICTURES.
KEEP YOUR HANDS FROM ENTRAPMENT!
WARNING! AFTER EACH OPERATION, MAKE SURE THAT YOU HAVE FOLLOWED THE
INSTRUCTIONS CORRECTLY AND THE FIXING IS STABLE!
WARNING! Tighten the screws well but do not over do it. If screws are too loose, some parts may
disassemble and your child may be injured.

4
ASSEMBLY
1. ASSEMBLY OF REAR WHEELS
Placetherearwheelaxleintheopeningontheframeandpressuntilthewheelisxedandyouhear
a click.
To remove the wheel press the button and take out the wheel.
2. INSTALLING PEDALS
Insertthepedalinthefrontwheelopeningandpressuntilyouhearaclickandpedalisxed.Installthe
other pedal.
Press the button to remove the pedal.
3. ASSEMBLY OF FRONT WHEEL TO THE FRAME
Insert the front wheel in the front tube, as shown in the picture.
4. ASSEMBLY OF HANDLEBAR
Placethehandlebarinthefrontwheeltubeandpressuntilitisxedandyouhearalick.
To remove it, press the red button.
5. ASSEMBLY OF FRONT BASKET
Place the front basket with pressure as shown in the picture.
6. INSTALLING THE SEAT
6 a and b – Loosen the screws on the bottom of the seat (4 pieces).
6 c – Place the seat on the frame as shown in the picture.
6d–Tightenthescrewstoxtheseat.
7. INSTALLING THE SAFETY BUMPER
7a–Inserteachofthebumperarmsintheopeningsonthesidesofthebackrest.Whenbumperisxed,
you will hear a click and the buttons will show through the holes.
7b – Thread on of the arms through the fabric as shown in the picture. Join both arms.
To remove the bumper, split the arms, press the buttons and take them away from the backrest.
8. INSTALLING THE CANOPY
Insert the two ends of the canopy in the seat corresponding groves as shown in the picture.
9. INSTALLIN THE REAR STORAGE BASKET
Placethebaskettotheframestubesandpresstoxit.
10. INSTALLING THE PUSH BAR
Insert the push bar in the opening at back of the frame, press the button (1), push the handle down and
release the button.
Note!Makesurethehandleisxedbytryingtopullitout!

5
11. FOLDING AND UNFOLDING OF CANOPY
Pull the canopy to the front in order to unfold it and push it back with your hand to fold it.
12. ROTATION OF THE SEAT 360°
Press the button and rotate the seat.
Aftertheseatisrotateditcanbexedintowpositions–forwardfacingandrearwardfacing.Wheneach
positionisxedyouwillhearaclick.
13. PARKING DEVICE
Press the pedal down in order to park the toy.
Release the pedal up, so the parking device is released and the tricycle can move.
14. ADJUSTING THE PUSH HANDLE HEIGHT
The push handle can be adjusted in three height levels (1, 2, 3).
Pull up the lever, press the button and move the handle up or down to the desired position. When each
positionisxed,thepinwillshowthoughtheholeandyouwillhearaclick.Whenpositionischosen,
pressthelevertothetubeinordertoxit.
15. FOLDING/UNFOLDING OF THE TRICYCLE
15 a, b, c – FOLDING/UNFOLDING OF THE HANDLEBAR
Folding: Move the red button up and fold the handlebar as shown in pictures a, b and c.
Unfolding: Move the red button up (c) and unfold the handlebar to vertical position.
15d,е–FOLDINGTHEBACKREST
Folding:Pullupthebackrestmechanismandfolditasshowninpictures15d,е.
Unfolding: Pull up the backrest mechanism and erect the backrest in vertical position.
15 f, g – FOLDING/UNFOLDING OF REAR WHEELS
Folding:Pressthefoldingbutton(1)andfoldtherearpartofframe.Whenfoldingisxed,thebutton
(2) will stick out.
Unfolding: Press the button (2) and unfold the frame. When the frame is unfolded the button (1) will
stick out.
16. FOOTREST
The pedals can be used as footrest.
Remove the pedals form the front wheel. Place each pedal in the frame opening and press until you
hear a click.
Press the buttons and pull out the pedals form the frame.
17. GUIDING THE TRICYCLE BY USING THE PUSH HANDLE
18. DRIVING THE TRICYCLE BY THE CHILD (AFTER REMOVING THE PUSH HANDLE)
WARNING!Removethepushhandlewhenyouarecondentthatthechildcandrivethetricycleonitsown.
FUNCTIONS

6
“click”
“click”
rear basket
install/removal button
“click”
screw
screw
tighten
the screws
ab
78
9
2
1
10
“click”
“click”
removal
button
removal
button
123
removal
button
“click”
45
abcd
6

7
11 12 13
14
unfolding folding
press
released
Adjusting button
Lever
pin 1
2
3
engaged
Rotate seat button Parking device

8
15
16
button
unfolding button
folding button
removal
button
“click“ “click“
pedal
a b c
d e
c
f g

9
MAINTENANCE GUIDELINES
Periodically check the good working order of the tricycle parts.
Do not wash it and do not soak it in water. Use a soft damp cloth and water or neutral liquid
detergent.
Do not use aggressive detergents, containing abrasive particles, ammonia, bleach or spirits.
Regularly oil the moving parts.
Do not use on sand surfaces.
Do not store the tricycle in hot environment, in order to avoid the plastic parts from deforming.
Store the product in clean and dry place indoors. Do not expose to direct sunlight, moisture or harsh
weather!
Always let the tricycle to dry out fully before storing or using it, in order to avoid mold and rust.
Contact your authorized dealer if consultation or repair is needed
Materials used: plastic, metal, textile – 100% polyester.
TRKQF023xxx / B70

Bulgaria, Plovdiv, Str. Golyamokonarsko shosse № 1
www.chipolino.com
