CHN Spec CS-810 User manual

R
V. 2022.1
China’s leading expert of color and gloss analysis
www.hzcaipu.com

0201 www.hzcaipu.comwww.hzcaipu.com

0403 www.hzcaipu.comwww.hzcaipu.com

0605 www.hzcaipu.comwww.hzcaipu.com

0807 www.hzcaipu.comwww.hzcaipu.com

1009 www.hzcaipu.comwww.hzcaipu.com

1211 www.hzcaipu.comwww.hzcaipu.com

²+²+ ²
1413 www.hzcaipu.comwww.hzcaipu.com

SERIES OF
SPECTROPHOTOMETER
OPERATION MANUAL
www.chnspec.com
Service hotline:[phone]
Address:No.166 of Wenyuan Road,Jianggan District,Hangzhou City,China
WARNING
Please do not disassemble the product without the assistance of
customer support center, If you have any questions, please contact the
local agency.
China’s leading expert of color
and gloss analysis
R
V. 2022.1

CATALOGUE
01
01
02
03
04
04
06
09
10
13
14
14
15
[ I ] Terms of use
[ II ] Notes
[ III ] Technical Specifications
[ IV ] Appearance and structure
[ V ] Instrument installation
[ VI ] Driver Installation
[ VII ] Instrument Operation
[ VIII ] Testing
[ IX ] Calibration
[ X ] System deployment diagram
[ XI ] Trouble Shooting
[ XII ] Testing Result Analysis
[ XIII ] Company’s statement

0201
Our spectrophotometer is the first model in China that adopts spectrum
splitting technology. IIt is mainly used to measure the sample spectral
value, color value, color difference value,etc. It is bench-top model with
compact structure which makes it easy to carry out, accurate and high
precise.
Our spectrophotometer is widely used in factories, labs and on spot. It can
achieve great color measurement result in the quality control of almost all
fields.
The warranty period starts from date you purchase the spectrophotometer.
If you need warranty service, please contact local agency or visit our
website www.chnspec.com to contact us.
To avoid damage to instrument accuracy or precision, please do not
disassemble the instrument. Damage to the instrument caused by
disassembly or improper use is NOT included in the warranty.
1.
Carefully put the instrument on a flat surface.
This instrument is not moisture proof,moisture may damage the instrument.
Large force, or sharp objects may damage the screen.
It is recommended to use the original power adapter with the instrument.
To ensure that the instrument works properly, please do not store, or use
the instrument in places that are too hot or too cold; please do not put the
machine in damp locations, or directly under sunlight. Do not use the
instrument in severe environment such as strong shock or quake.
Check battery before usage.
Please avoid strong electromagnetic interference in usage.
Please do not use the instrument to measure surfaces that are not flat.
Please keep the instrument steady; do not shake the instrument in usage.
Please put the instrument directly on the spot to be measured, but do not
apply strong force.
Please store the instrument in a dry area. If it is not used in a long time,
please take the battery out.
If this user manual is further updated, we are not obliged to notify you. If
you have further questions, please ask on the website.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Terms of use
Notes
2.
3.
4.
www.chnspec.com www.chnspec.com
Technical Specifications
Model
Illumination mode
CLEDs (total spectrum LED light source)
dual light path sensor array
400~700nm
10nm
5nm
0~200%
0.0001
2°/10°
Transmittance Value and Figure, chromatic values, color difference values, pass/fail
results, color deviation, color simulation, color simulation history, input standard
samples, test results
1second
1second
Illumination Light
source
Sensor
Wavelength interval
Half spectral width
Transmittance/reflectivity
range
Spectral resolution
Observer angle
Data displayed
Test intervals
Test time
Measurement caliber
Color space
Color difference formulas
Measurement light source
CS-810
d/0 (diffused illumination, 0 degree observer angle), conform to CIE No.15, ISO 7724/1, ASTM
E1164, DIN 5033 Teil7, and JIS Z8722 Condition c standards
Size of integrating sphere
Wavelength range
USB
5 years,1.5 million tests
-25℃to 55℃，relative humidity 80% or below（at 35°C ）， no condensation
20000 measurementsData storage
Working temperature
range
Data port
Storing data Mass storage(PC)
Light source longevity
Power cable, color QC software, driver software, USB cables, black calibration
tile, glass cell
Storage temperature
range
Size
0℃to45℃，relative humidity 80% or below（at 35°C ）,no condensation
Standard accessories
Optional Accessories
Repeatability
Other color indices
WI(ASTM E313-00,ASTM E313-73, CIE/ISO, Hunter, Taube, Berger Stensby),YI(ASTM
D1925,ASTM E313-00,ASTM E313-73), Tint(ASTM E313-00), Milm, color stain, color
fastness, APHA, Pt-Co, Gardner,Saybolt,Astm color,Hazen
(When
a white tile is measured 30 x at 5-second intervals after white calibration),0.03 Max
A,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,
CWF,U30,DLF,NBF,TL83,TL84
CIE Lab,LCh,CIE Luv,XYZ,Yxy, transmittance ,Hunter Lab,Musell,MI,CMYK

Instrument Installation
Driver Installation
Appearance and structure
0403 www.chnspec.com
www.chnspec.com

Instrument Operation
0605 www.chnspec.com
www.chnspec.com

0807 www.chnspec.com
www.chnspec.com

Testing
Calibration
1009 www.chnspec.com
www.chnspec.com

1211 www.chnspec.com
www.chnspec.com

1. Check battery or power cable
1.Make sure instrument is lying
flat
2.Put a thick piece of white paper
under sample
3.Only check single color
1.Check if the instrument is lying
stably on a flat sample
2.Check if the sample is too thin
3.Check if there are multiple colors
in the test area
1. Unable to switch on
2.Exception in meas-
urement results
3.Unreasonable
measurement results
Error Analysis
Check if the tolerance setting
is reasonable
Handling
Install connect power
cable to power source
Check and change tolerance
settings
Trouble Shooting
Testing Result Analysis
System deployment diagram
1413 www.chnspec.com
www.chnspec.com

1.The company promises that our spectrophotometer offers one year of warranty
from the purchase date. Non-artificial damage under normal use is subjected to
free warranty. The company offers repair services for artificial damage, or
damage after the warranty period ; however, the repair services would require
fees relative to the damage.
2.The warranty only holds for the person, or company who purchased the
instrument. Damage occurred by the third party usage would not be eligible for
warranty service.
3.The company is not responsible for data loss because of error, repairing, or
power outages. To prevent loss of important data, please save copies of the
data on your PC.
4.The copyright ownership of the instrument and its associated software belong
to CHNSpec and is protected by the Copyright Laws of People’s Republic of
China.
5.Our company sells the instrument does not mean we transfer the copyright, or
any intellectual property’s ownership to the user.
6.The specifications and information in this manual are subjected tofurther updates
without notice.
Company’s statement
15
