Chord Poly Quick start guide

www.moon-audio.com919-649-5018[email protected]
Chord Poly Wireless Streamer
Connecting to a WiFi Network
What You Need
Instructions
2.4Ghz WiFi network
Phone, tablet or computer
Network name (SSID) and password
Full battery charge
The P.status light will flash from blue to green when Poly enters Access Point
Mode. It is now ready to be configured.
2.
Attach your fully-charged Poly to your
Mojo and turn on the Mojo.
1.
This guide will help you attach Poly onto a 2.4Ghz WiFi network. To do so we need
access to Poly so we can tell it what WiFi network to connect to. To complete this
process Poly will need a 2.4Ghz WiFi network to connect to, a phone, tablet or a
computer. You will need to know the name(SSID) of the 2.4Ghz WiFi network you
want Poly to connect to and its password. If your network does not have a password
you will need to create one for it. Poly should also be fully charged before setup is
attempted. Poly must be setup with WiFi before Bluetooth can be used.
*If the P.status light is not flashing blue and green, use the included Sim Card Tool to
press the button inside the Config port hole for 7 seconds. Remove the Sim Card Tool
and wait 10 seconds for the flashing to begin.

www.moon-audio.com919-649-5018[email protected]
Chord Poly Wireless Streamer
Connecting to a WiFi Network
In Access Point Mode, Poly creates its own wireless network. Connect to this
Wi-Fi network from a computer or mobile device to set up and control your Poly.
Look for Poly’s network in your device’s WiFi settings and connect to it. Examples
of different systems are shown below.
3.
Attach your fully-charged Poly to your
Mojo and turn on the Mojo.

www.moon-audio.com919-649-5018[email protected]
Chord Poly Wireless Streamer
Connecting to a WiFi Network
Do not click save until next step.
Poly will only work as a Roon endpoint.
For everything else, including UPnP/DLNA, MPD, Airplay, and
Bluetooth. If you are not using a Roon, choose Other.
Roon Mode:
Other Mode:
Once connected to Poly’s Hotspot a web browser pop-up window will appear.
Scroll down in this window to Poly Mode Settings.
There are two primary Play Modes:
4.
Attach your fully-charged Poly to your
Mojo and turn on the Mojo.
*All three fields must be completed or Poly will not set up properly.

www.moon-audio.com919-649-5018[email protected]
Chord Poly Wireless Streamer
Connecting to a WiFi Network
Do not click save until next step.
From Poly Mode Settings, select WiFi Settings and enter the nickname,
network ID (SSID), and password for your wireless network.
Check the box next to Reboot on save, then click the Save button.
5.
After clicking Save, a pop-up confirmation will appear and remain on-screen
while the Poly reboots and attempts to connect to the WiFi network.
If Poly successfully connects to the network, the P.status LED will be solid. (The
color will vary depending on the charge of the battery.)
6.
*Cell 1: Enter a network name that will help you remember which network you are
connecting to or where it is located, such as a room or building name.
*Cell 2: Enter the name of your wifi network exactly as it appears in the WiFi network list
and in your network configurations.
