APS Series
LWU650-APS, LWU530-APS
Service Manual
020-001522-01

SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
Multimedia LCD Projector
Service Manual
LWU650-APS
LWU530-APS
Be sure to read this manual before servicing. To assure safety from re, electric shock, injury, harmful
radiation and materials, various measures are provided in this Multimedia Projector.
Be sure to read cautionary items described in the manual to maintain safety before servicing.
Caution
1. This projector is provided with a high voltage circuit. Do not touch the electric parts of power unit
(circuit), after turn on the projector.
2. Do not touch the exhaust fan during operation.
3. Use the cables which are included with the projector or specied.
Service Warning
1. Features------------------------------------------------------3
2. Specications -----------------------------------------------4
3. Names of each part---------------------------------------- 6
4. Install/Maintenance ----------------------------------------7
5. Troubleshooting ------------------------------------------ 10
6. Diagnosis--------------------------------------------------- 18
7.Internal System------------------------------------------- 24
8. Replacement Parts list---------------------------------- 29
9. Disassemble/Assemble--------------------------------- 34
10. Adjustment------------------------------------------------- 81
11.Technical Information ----------------------------------- 90
Contents
The technical information and parts shown in this manual are not to be used for: the development, design,
production, storage or use of nuclear, chemical, biological or missile weapons or other weapons of mass
destruction; or military purposes; or purposes that endanger global safety and peace. Moreover, do not sell,
give, or export these items, or grant permission for use to parties with such objectives. Forward all inquiries
to the supplier.
Warning

2
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
CAUTION FOR SAFETY
Please read this page before the repair work. This page explains the indications of the following
items to keep safety and prevent an accident.
Entries with graphical symbol explanation
WARNING This entry warns of a risk of personal serious injury or even death.
CAUTION
This entry warns of a risk of personal injury, physical or property damage.
Typical graphical symbols explanation
This symbol indicates
warnings and cautions. This symbol indicates hazard of high voltage. This symbol indicates mandatory actions.
This symbol indicates
hazard of explosion. This symbol indicates hazard of hand crush. This symbol indicates coercing to unplug.
This symbol indicates
hazard of high temperature.
This symbol indicates
hazard of laser radiation. This symbol indicates
prohibited actions.
WARNING
Follow the instructions.
The warning labels or markings are on the parts which need special attention.
Follow those notes and the User's Manual - Safety Guide.
Never disassemble the laser light source unit.
Avoid electric shock.
Be careful and unplug the power cord as far as possible during the work. Be sure to
unplug when disassembling or assembling.
The projector has high voltage portion and possibly charged portion. If you touch such a
place or other live part, it cause electric shock and may lead to death.
Use specied or recommended components.
Use the components which have same characteristic especially about incombustibility
and voltage proof as previous for keeping safety and reliability. Be particularly sure to
use the components marked with in the replacement parts list and circuit diagram.
Using un-specied or non-recommended components may cause electric shock or re.
Keep same style of wiring and components.
This product uses insulating tapes or tubes, and has some components assembled
keeping distance from particular portion to keep safety and reliability. Also the cables
are wired so that they keep away from high temperature or voltage part.
Be sure to restore them to prevent an electric shock and a re after you have changed them.
Do safety inspection after repair work.
Check if the all is restored (removed parts and wiring are same condition as previous)
after repair work. Also check if any damage are around the repaired or replaced part.
Measure the insulation resistance with megohmmeter after visual inspection. If the
resistance is less than 4M ohm, it may cause electric shock and re.
CAUTION
Do not touch the fan motor while it is rotating.
Do not touch the fan motors when you have turned on the projector with the UPPER
CASE removed. It may injure you.

3
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
1. Features
ü This projector has a variety of I/O ports that supposedly cover for any business scene. The
HDMITM and HDBaseTTM ports can support various image equipment which have digital
interface to get clearer pictures on a screen.
ü This projector can be controlled and monitored via LAN connection.
Furthermore, you can use the designated USB wireless adapter (optional) to establish wireless
LAN connection.
ü The built-in 16W speaker can deliver sufcient sound volume in a large space like a classroom
without external speakers.
ü Has an HDCR and an eClarity features which are original image stabilizer for a clearer image.

4
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
2. Specications
Liquid crystal
panel
Drive system TFT active matrix
Panel size 0.64"
Number of pixels 1920 (H) x 1200 (V)
Light Source Laser Diode
Digital
audio/video
signal
HDMI1
HDMI2
Type: T.M.D.S
Signal level: DC 3.3V±5%, AC 0.15-1.56Vp-p
Audio signal: Linear PCM format, Sampling frequency 48kHz, 44.1kHz, 32kHz
Computer
signal
COMPUTER IN 1 (Dsub)
Video: Analog 0.7Vp-p (75Ω termination)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
COMPUTER IN 2 / MONITOR OUT
Video:Analog 0.7Vp-p, 75Ω output impedance (positive)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
Video signal VIDEO 1.0Vp-p (75Ω termination)
HDBaseT* (RJ45) Signal type: PAM16
Differential signal level: 1.9~2.1V
Audio signal AUDIO IN
1
500mVrms, input impedance 47kΩ or more (max. 2Vrms)2
3 (L/R)
AUDIO OUT 500mVrms, output impedance 1kΩ (max. 2Vrms)
RS-232C Input: Hi: Max. 20V, Min. 2.6V Lo: Typ. –20.0V, Max. 0.8V
Output: Hi: Typ. 8.0V, Min. 5.0V Lo: Typ. –7.0V, Max. –5.0V
USB
TYPE A
( wireless LAN **)
I/O Level
Amplitude of
differential signal (D+)-(D-)>0.2V and D+>2.0V or (D-)-(D+)>0.2V and D->2.0V
I/O Level
Amplitude of
signal
INPUT: “L” 0.8V or less, “H” 2.0V or more
OUTPUT: “L” 0.3V or less, “H” 2.8V~3.6V
USB mini B
(Service port)
I/O Level
Amplitude of
differential signal (D+)-(D-)>0.2V and D+>2.0V or (D-)-(D+)>0.2V and D->2.0V
I/O Level
Amplitude of signal
INPUT: “L” 0.8V or less, “H” 2.0V or more
OUTPUT: “L” 0.3V or less, “H” 2.8V~3.6V
Wired LAN LAN* (RJ45) System: 100Base-TX / 10Base-T
Differential signal level: 1.9~2.1V (100Ω termination)
Wireless LAN ** IEEE802.11a/b/g/n/ac See the user's manual of the optional USB wireless adapter.
Speaker 16W×1
Power supply LWU650-APS : 4.3A (AC 100V-120V), 2.1A (AC 220V-240V)
LWU530-APS : 3.8A (AC 100V-120V), 1.9A (AC 220V-240V)
Power consumption LWU650-APS : 420W (AC 100V-120V), 400W (AC 220V-240V)
LWU530-APS : 370W (AC 100V-120V), 360W (AC 220V-240V)
Dimensions 506 (W) x 136 (H) x 424 (D) mm
* Not including protruding parts.
Weight LWU650-APS : approx. 8.5 kg
LWU530-APS : approx. 8.2 kg
Temperature range
0~40°C (Operating)
35~40°C (The brightness of the light source is reduced automatically.)
Storage : -15~60°C
Accessories
Remote control x 1 Security label x 1 Cable tie for power code x 1
Power cord x 3 or 1 Computer cable x 1 Cable tie for HDMI cable x 2
Screw x 1 Hook metal x 1 HDMI cable holder x 2
Lens cover x 1 User’s manual (Book x 1)
* DC power cannot be provided from these ports.
** Wireless network function requires the optional USB wireless adapter. The communication speed (and standard) is restricted
depending on circumstances like encryption, communication mode and so on.

5
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
・Suspended from the ceiling ・On a horizontal surface
(1920 x 1200, ±10%)
Screen
type
16 : 10 16 : 9 4 : 3
Screen Size Projection distance Screen Size Projection distance Screen Size Projection distance
H V a min. amax. H V a min. amax. H V a min. amax.
m m inchminch mmm inchminch mmm inchminch m
30 0.6 0.4 31 0.8 57 1.4 0.7 0.4 32 0.8 59 1.5 0.6 0.5 36 0.9 65 1.7
40 0.9 0.5 43 1.1 78 2.0 0.9 0.5 44 1.1 80 2.0 0.8 0.6 50 1.3 89 2.3
50 1.1 0.7 55 1.4 98 2.5 1.1 0.6 57 1.4 101 2.6 1.0 0.8 63 1.6 112 2.8
60 1.3 0.8 67 1.7 119 3.0 1.3 0.7 69 1.8 123 3.1 1.2 0.9 77 2.0 136 3.4
70 1.5 0.9 80 2.0 140 3.6 1.5 0.9 82 2.1 144 3.7 1.4 1.1 91 2.3 159 4.0
80 1.7 1.1 92 2.3 161 4.1 1.8 1.0 94 2.4 165 4.2 1.6 1.2 105 2.7 183 4.6
90 1.9 1.2 104 2.6 182 4.6 2.0 1.1 107 2.7 187 4.7 1.8 1.4 118 3.0 206 5.2
100 2.2 1.3 116 2.9 202 5.1 2.2 1.2 119 3.0 208 5.3 2.0 1.5 132 3.4 230 5.8
120 2.6 1.6 140 3.6 244 6.2 2.7 1.5 144 3.7 251 6.4 2.4 1.8 160 4.1 277 7.0
150 3.2 2.0 177 4.5 307 7.8 3.3 1.9 182 4.6 315 8.0 3.0 2.3 201 5.1 348 8.8
200 4.3 2.7 238 6.0 411 10.4 4.4 2.5 244 6.2 422 10.7 4.1 3.0 270 6.9 466 11.8
250 5.4 3.4 298 7.6 515 13.1 5.5 3.1 307 7.8 529 13.4 5.1 3.8 339 8.6 583 14.8
300 6.5 4.0 359 9.1 619 15.7 6.6 3.7 369 9.4 636 16.2 6.1 4.6 407 10.3 701 17.8
Laser warning
Product Label: The position of the label is shown in the drawing below.
•
This projector is classied as a class 1 laser product that complies with IEC60825-
1:2014 and JIS C 6802:2014, and as a class 3R laser product that complies with
IEC60825-1:2007. Improper handling may cause injury. Be careful of the following.
• If an abnormality occurs in the projector, turn it off immediately, unplug the power
cord from the outlet, and consult your dealer or service company. If you continue
to use it, it may cause not only electric shock or re but also vision disorder.
• Do not disassemble or modify the projector. The projector has a high-power
laser device inside. It may cause serious injury.
• Do not look into the beam while projecting an image. Do not look into the lens
through optical devices such as magniers or telescopes. It may cause vision
disorder.
• Make sure that nobody is looking into the lens when you turn on the projector by
remote control away from the projector.
• Do not let children operate the projector. If children could possibly operate the
projector, they must be accompanied by an adult.
• Do not expose optical devices such as magniers or reection mirrors to a
projected image. It may cause bad effects on the human body if you continue to
use it. It may also cause re or accidents.
• Do not disassemble the projector when you dispose of it. Dispose of it according
to laws and regulations of each country or region.
CAUTION
►Use of controls or adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
Laser evaluation standard
IEC60825-1: 2007, IEC60825-1: 2014, EN60825-1: 2014
Internal Laser Specifications
Max. Output: 115W (LWU650-APS) / 95W (LWU530-APS)
Wave Length: 449 - 461nm
LASER ENERGY – EXPOSURE NEAR APERTURE MAY CAUSE BURNS
As with any bright source, do not stare
into the direct beam,
RG2 IEC 62471-5:2015 Top view
Laser aperture QL58131
LASER APERTURE
OUVERTURE LASER
LASERÖFFNUNG
雷射窗口

6
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
3. Names of each part
Part names
Projector
(16) Spacer (x 2)
(17) Battery cover
►Do not open or remove any portion of the product, unless the
manuals direct it.
►Do not subject the projector to unstable conditions.
►Do not apply a shock or pressure to this product.
►Do not look into the lens and the openings on the projector while the light
source is on, since the projection ray may cause a trouble on your eyes.
►Keep any object away from concentrated projection light beam. Blocking the
beam by something causes high temperature and could result in re or smoke.
WARNING
►Do not touch around the exhaust vents during use or
just after use, since it is too hot.
►Do not attach anything onto the lens except the lens cover of this
projector because it could damage the lens, such as melting the lens.
CAUTION
(6) (9) (10) (8)
(4)
(5) (12)
(2)(7)
(13)
(12) (16) (3) (7)
(1) (12)
(11)
(14)
(15)
(17)
(1) Speaker
(2) Filter cover
The air filter and intake vent are inside.
(3) Elevator feet (x3)
(4) Remote sensor
(5) Lens
(6) Lens cover
(7) Intake vents
(8) Control panel
(9) FOCUS ring
(10) ZOOM ring
(11) AC (AC inlet)
(12) Exhaust vent
(13) Ports
(14) Security bar
(15) Security slot
Control panel
(1) STANDBY/ON button
(2) INPUT button
(3) MENU button
(4) STATUS DETAIL indicator
(5) POWER/STATUS indicator
Ports
(1) LAN port
(2) WIRELESS port
(3) HDMI 1 port
(4) HDMI 2 port
(5) HDBaseT port
(6) AUDIO IN1 port
(7) AUDIO IN2 port
(8) AUDIO IN3 (R,L) ports
(9) AUDIO OUT port
(10) COMPUTER IN1 port
(11) COMPUTER IN2 / MONITOR OUT port
(12) CONTROL port
(13) VIDEO port
(10)
(8)
(3)(2) (4)
(13)
(12)
(11)
(1)
(7)(5)(9) (6)
NOTE • Any button marked with “*” is not supported on this projector.
Back of
the remote control
(1) INPUT button
(2) MY BUTTON-1 button
(3) MY BUTTON-2 button
(4) STANDBY/ON button
(5) ASPECT button
(6) PbyP button
(7) AUTO button
(8) FREEZE button
(9) MAGNIFY ON button
(10) FOCUS + button *
(11) ZOOM + button *
(12) VOLUME + button
(13) MAGNIFY OFF
button
(14) FOCUS - button *
(15) ZOOM - button *
(16) VOLUME - button
(17) PAGE UP button
(18) GEOMETRY button
(19) PICTURE button
(20) MUTE button
(21) PAGE DOWN button
(22) INTERACTIVE button *
(23) NETWORK button
(24) BLANK button
(25) ESC button
(26) MENU button
(27) ENTER button
(28) OSD MSG button
(29) RESET button
(30) ▲/▼/◄/►cursor buttons
(31) Battery cover
(3)
(4)
(7)
(8)
(11)
(12)
(15)
(16)
(20)
(19)
(24)
(23)
(26)
(27)
(29)
(31)
ASPECT
BLANK
ESC MENU
RESET
AUTO
PAGE
DOWN
ON
OFF
FREEZE
UP
ENTER
FOCUS
-
+
ZOOM
-
+
INPUT
INTERACTIVE
MYBUTTON
12
PbyP
MAGNIFY VOLUME
-
+
GEOMETRY PICTURE MUTE
NETWORK
OSD MSG
(2)
(1)
(6)
(5)
(10)
(9)
(14)
(13)
(17)
(18)
(21)
(22)
(25)
(30)
(28)
Remote control
(1) (3)
(2) (5)
(4)

7
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
■Installing the Batteries
■Replacing the internal clock battery
Please insert the batteries into the remote control before using it. If the remote control starts to malfunction,
try to replace the batteries. If you will not use the remote control for long period, remove the batteries from
the remote control and store them in a safe place.
1.
2. Align and insert the two AA batteries according to their plus and minus
terminals as indicated in the remote control. (Use the appropriate AA
carbon-zinc or alkaline batteries (non-rechargeable) in accordance with
laws and regulations.)
3. Put the battery cover back to the former state.
►Always handle the batteries with care and use them only as directed.
Improper use may result in battery explosion, cracking or leakage, which could result in
re, injury and/or pollution of the surrounding environment.
• Be sure to use only the specied batteries. Do not use batteries of different types at the
same time. Do not mix a new battery with used one.
• Make sure the plus and minus terminals are correctly aligned when loading a battery.
• Keep a battery away from children and pets.
• Do not recharge, short circuit, solder or disassemble a battery.
• Do not place a battery in a re or water. Keep batteries in a dark, cool and dry place.
• If you observe battery leakage, wipe out the leakage and then replace a battery.
If the leakage adheres to your body or clothes, rinse well with water immediately.
• Obey the local laws on disposing the battery.
WARNING
Remove the battery cover.
Installing the battery is required in some cases. A battery is not contained at the time of factory shipment.
Please replace a battery according to the following procedure.
1. Turn the projector off, and unplug the power cord. Allow the projector to cool sufciently.
2. Turn the battery cover fully counterclockwise using a coin or the like, and pick the cover up
to remove it.
3. Pry up the battery using a athead screwdriver or the like to take it out. Do not use any
metal tools. While prying it up, put a nger lightly on the battery since it may pop out of the
holder.
4. Replace the battery with a new MAXELL,
Part No.CR2032 or CR2032H.
Slide the battery in under the plastic claw, and push it into the holder until it clicks.
5. Replace the battery cover in place, then turn it clockwise to x by using a coin or the like.
WARNING ► Always handle the batteries with care and use them only as directed.
Battery may explode if mistreated. Do not recharge, disassemble or dispose of in re.
And also improper use may result in cracking or leakage, which could result in re,
injury and/or pollution of the surrounding environment.
・ Be sure to use only the batteries specied.
・
Make sure the plus and minus terminals are correctly aligned when loading a battery.
・Keep a battery away from children and pets. If swallowed, consult a physician
immediately for emergency treatment.
・ Do not short circuit or solder a battery.
・ Do not allow a battery in a re or water. Keep batteries in a dark, cool and dry
place.
・ If you observe battery leakage, wipe out the leakage and then replace a battery. If
the leakage adheres to your body or clothes, rinse well with water immediately.
・ Obey the local laws on disposing a battery.
4. Install/Maintenance
Battery Cover
90°
90°

8
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
Cleaning and replacing the air lter
Check and clean the air lter periodically. When the indicators or a message
prompts you to clean the air lter, comply with it as soon as possible.
1.
Turn the projector off, and unplug the power cord. Allow the projector to
sufciently cool down.
2.
Use a vacuum cleaner on and around the lter cover.
3.
Pick and pull up the lter cover knobs to take it off.
4.
Press up slightly the bottom side knobs to unlock the
bottom side of the air lter, and take it off.
5.
Use a vacuum cleaner on both sides of the air lter
while holding it so it will not be sucked in.
If the air lter is damaged or heavily soiled, replace
it with the new one. Request for an air lter with
the following type number from your dealer when
purchasing a new one.
Type number: 003-006612-01
6.
Use a vacuum cleaner for the lter vent of the
projector.
7.
Put back the air lter and lter cover into their place.
8.
Turn the projector on and reset the lter hours using
the FILTER HOURS item in the EASY MENU.
(1) Press the MENU button to display a menu.
(2) Point at the FILTER HOURS using the ▲/▼ buttons, then press the ►
button. A dialog will appear.
(3) Press the ► button to select “OK” on the dialog. It performs resetting the
lter hours.
Filter cover
Filter cover knobs
Air lter
Air lter knobs
2
3
45
6Filter vent
►Before taking care of the air lter, make sure the power cord is
not plugged in, then allow the projector to cool sufciently. Taking care of the air
lter in a high temperature state of the projector could cause an electric shock, a
burn or malfunction to the projector.
►Use only the air lter of the specied type. Do not use the projector without the
air lter or the lter cover. It could result in a re or malfunction to the projector.
►Clean the air lter periodically. If the air lter becomes clogged by dust or the
like, internal temperatures rise and could cause a re, a burn or malfunction to
the projector.
WARNING
• Replace the air lter when it is damaged or heavily soiled.
• Reset the lter hours only when you have cleaned or replaced the air lter, for
a suitable indication about the air lter.
• The projector may display the message such as “CHECK THE AIR FLOW” or
turn off the projector, to prevent the internal heat level rising.
NOTE

9
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
Other care
To ensure the safe use of your projector, please have it cleaned and inspected by
your dealer about once a year.
1. Turn the projector off, and unplug the power cord. Allow the projector to cool
sufciently.
2. After making sure that the projector is cool adequately, wipe lightly the lens
with a commercially available lens-cleaning wipe. Do not touch the lens
directly with your hand.
If the lens is awed, soiled or fogged, it could cause deterioration of display
quality. Please take care of the lens, being cautious of handling.
Inside of the projector
Caring for the lens
• Use commercially available lens tissue to clean the lens (used to clean cameras,
eyeglasses, etc.).
• If the lens is heavily soiled, wipe it with a cloth moistened with little water.
• Never use polishing agents, detergents, chemicals, or solvents such as benzine
or thinner.
• Excepting for lens, use a soft cloth to clean. When excessively soiled, dilute a
neutral detergent in water, wet and wring out the soft cloth.
►Before caring, make sure the power cord is not plugged in,
and then allow the projector to cool sufciently. The care in a high temperature
state of the projector could cause a burn and/or malfunction to the projector.
►Never try to care for the inside of the projector personally. Doing it is so
dangerous.
►Avoid wetting the projector or inserting liquids in the projector. It could result in
a re, an electric shock, and/or malfunction to the projector.
• Do not put anything containing water, cleaners or chemicals near the projector.
• Do not use aerosols or sprays.
WARNING
►Please take right care of the projector according to the
following. Incorrect care could cause not only an injury but adverse inuence
such as discoloration, peeling paint, etc.
►Do not use cleaners or chemicals other than those specied in this manual.
►Do not polish or wipe with hard objects.
NOTICE ►Do not directly touch the lens surface with hands.
CAUTION
1. Turn the projector off, and unplug the power cord. Allow the projector to cool
sufciently.
2. After making sure that the projector is cool adequately, lightly wipe with gauze
or a soft cloth.
If the projector is extremely dirty, dip soft cloth in water or a neutral cleaner
diluted in water, and wipe lightly after wringing well. Then, wipe lightly with a
soft, dry cloth.
Incorrect care could have adverse inuence such as discoloration, peeling paint,
etc.
Caring for the cabinet and remote control

10
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
5-1 Notice of AUTO adjustment
Use of AUTO adjustment with the image through analog RGB input optimizes V_POSI, H_POSI,
and H_PHASE automatically.
In case that display image has dark tone around its peripheral, AUTO operation sometimes makes
artifacts in the image, shifts capture area and so on. Those failures are caused by period of image
data is not exactly distinguished to period of blanking on signal processing.
To avoid such phenomena, AUTO function should be used with the full size picture that has bright
tone on its peripheral.
NOTE:
• The phenomenon of the failure of AUTO adjustment depends on resolution of input source, scene
of picture etc.
• There is no above failure of AUTO with video source through VIDEO port. The reason is
recognition of input signal’s standard does not need to search the capture range from input signal
itself.
Image when AUTO operates correctly. Image when AUTO fails.
• Noting image of top or bottom lines.
• Shift of the image to East or West.
• Artifacts on image. Etc.
AA
5. Troubleshooting

11
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
5-2 Regarding the indicator
When operation of the POWER/STATUS and STATUS DETAIL indicators differs from usual, check
and cope with it according to the following table.
See also diagnosis owchart in chapter 6 when some error happens.
POWER/STATUS
indicator
STATUS
DETAIL
indicator Description
Lighting
In Orange Turned off The projector is in a standby state.
Please refer to the section “Power on/off”.
Blinking
In Green Turned off The projector is warming up.
Please wait.
Lighting
In Green Turned off The projector is in an on state.
Ordinary operations may be performed.
Blinking
In Orange Turned off The projector is cooling down.
Please wait.
Blinking
In Red
3 times
Blinking
In Red
0～5 times
The light source does not light. There is a
possibility that interior portion has become
heated, or that the power supply is unstable.
Please turn the power off, and allow the projector to
cool down at least 20 minutes. After the projector has
sufficiently cooled down, please make confirmation of
the following items, and then turn the power on again.
• Is there blockage of the air passage aperture?
• Is the air filter dirty?
• Does the peripheral temperature exceed 40°C?
Blinking
In Red
7 times
Blinking
In Red
1～7 times
The cooling fan is not operating.
Please turn the power off, and allow the projector to
cool down at least 20 minutes. After the projector has
sufficiently cooled down, please make confirmation
that no foreign matter has become caught in the fan,
etc., and then turn the power on again.
If the same indication is displayed after the remedy,
please contact your dealer or service company.
Blinking
In Red
2 times
Turned
off
The internal temperature is rising.
It is time to clean the air filter.
Please turn the power off, and allow the projector to
cool down at least 20 minutes. After having confirmed
the following items, please turn the power on again.
• Is there blockage of the air passage aperture?
• Is the air filter dirty?
• Does the peripheral temperature exceed 40°C?
Blinking
In Red
1 time
Turned
off
Please immediately turn the power off, and clean or
change the air filter referring to the section “Cleaning
and replacing the air filter”. After cleaning or changing
the air filter, please be sure to reset the filter hours.
After the remedy, turn the power on.

12
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
POWER/STATUS
indicator
STATUS
DETAIL
indicator Description
Blinking
In Red
9 times
Blinking
In Red
1～4 times
There is a possibility that the interior portion
has become overcooled.
Please use the unit within the usage temperature
parameters (0°C to 40°C).
After the treatment, turn the power on.
Blinking
In Red
9 times
Blinking
In Red
5～7 times
The illuminance system is operating in degraded
mode.
The image color may not be projected correctly.
Normally lighting in
Orange.
Blinking In Green 2
times for approx. 3
seconds.
Turned
off
STANDBY MODE is set to QUICK START.
Refer to STANDBY MODE.
Blinking In Green for
approx. 3 seconds. Turned off
At least 1 "Power ON" schedule is saved to the
projector.
Please refer to Schedule Settings section of
User’s Manual - Network Guide.
Lighting
In Green
Blinking
In Red
1 time
The projector received the remote control signal
when ALL is selected for REMOTE CONTROL in
KEY LOCK.
CONTROL PANEL was operated when ALL is
selected for CONTROL PANEL in KEY LOCK.
Lighting
In Orange.Blinking In
Red 1 time
PIN LOCK or TRANSITION DETECTOR function
is active.
Please see SECURITY menu > PIN LOCK or
TRANSITION DETECTOR
If the same indication is displayed after the remedy,
please contact your dealer or service company.
Normally lighting in
Green.
Blinking 1 time for
approx. 3 seconds.
Turned
off
Blank(black) or AV Mute(black) is on.
Press any button on the remote control or on the
control panel to disable Blank or AV Mute.
• When the interior portion has become overheated, for safety purposes,
the projector is automatically shut down, and the indicator lamps may also be
turned off. In such a case, disconnect the power cord, and wait at
After the projector has sufficiently cooled down, turn the power on again.
least 20 minutes.
NOTE
Blinking
In Red
2 times
Blinking
In Red
1～4 times
The interior portion has become heated.
Turn the power off, and allow the projector to cool
down at least 20 minutes. After the projector has
sufficiently cooled down, confirm the following items,
and then turn the power on again.
• Is there blockage of the air passage aperture?
• Is the air filter dirty?
• Does the peripheral temperature exceed 40°C?
• Is the setting for ALTITUDE appropriate?
• Is the exhaust air (hot/cold) from peripheral
equipment blowing against the ventilation opening
of projector?
For details on ALTITUDE, refer to ALTITUDE of
SERVICE in the OPTION menu. If the projector is
used with a wrong setting, it may cause damage to
the projector itself or the parts inside.
Other than those above Other error has occurred.
Contact your dealer or service company.

13
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
5-3 Related Messages
When some messages appear, check and deal with it according to the following table. Although
these messages automatically disappear after several minutes, they reappear when the power
is turned on.
104
Troubleshooting
Troubleshooting
If an abnormal operation should occur, stop using the projector immediately.
Otherwise if a problem occurs with the projector, the following checks and measures are
recommended before requesting repair.
If this does not resolve the problem, please contact your dealer or service company. They
will tell you what warranty condition is applied.
► Never use the projector if abnormal operations such as smoke,
strange odor, excessive sound, damaged casing or elements or cables, penetration
of liquids or foreign matter, etc. should occur. In such cases, immediately disconnect
the power plug from the power outlet. After making sure that the smoke or odor has
stopped, contact your dealer or service company.
WARNING
Related messages
When some message appears, check and cope with it according to the following table.
Although these messages will be automatically disappeared around several minutes, it will
be reappeared every time the power is turned on.
Message Description
There is no input signal.
Confirm the signal input connection, and the status of the
signal source.
Projector is waiting for an image le.
Check the hardware connection, settings on the projector
and network-related settings.
The computer-Projector network connection might be
disconnected. Re-connect using “Connect button” of the
“LiveViewer”.
(continued on next page)
Troubleshooting
105
Message Description
The horizontal or vertical frequency of the input signal is
not within the specified range.
Confirm the specs for your projector or the signal source
specs.
An improper signal is input.
Confirm the specs for your projector or the signal
source specs.
The COMPUTER IN2/MONITOR OUT port is selected as
the picture input source even though MONITOR OUT is
selected for COMPUTER IN2.
Select AUTO or SYNC ON G OFF in the dialog to project
the picture input to the COMPUTER IN2/MONITOR OUT
port. In this case, you cannot use the MONITOR OUT
function. Otherwise select other port for picture input.
The internal temperature is rising.
Turn the power off, and allow the projector to cool down
at least 20 minutes. After having confirmed the following
items, turn the power on again.
• Is there blockage of the air passage aperture?
• Is the air lter dirty?
• Does the peripheral temperature exceed 40°C?
A note of precaution when cleaning the air filter.
Turn the power off immediately, and clean or change the
air filter referring to the “Cleaning and replacing the air
filter” section of this manual. After you have cleaned or
changed the air filter, be sure to reset the filter hours.
The button operation is not available.
Troubleshooting
Related messages (continued)

14
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
5-4 Troubleshooting for other Network problems
Problem Likely Cause Things to Check
No image
The projector is not turned on. Is the projector’s light source on?
The projector’s input source is not
switched properly.
Is the proper input channel selected?
LAN: PC screen display via wired/wireless
LAN
Projector does not work
when the network cable
is connected.
The network packet congestion is
occurred. Check the cable connection diagram making sure no "ring" or "loop" connection is made
in the network that the projector is connected
to.
Time is not displayed
correctly.
The time has not been congured. Set the Date and Time in the OPTION -
SCHEDULE menu of the projector.
The projector displays "2015/1/1
0:00" as the Date and Time in the
Network Info after the AC power is
cut off because the projector has no
battery for the internal clock.
Set the Date and Time in the OPTION -
SCHEDULE menu of the projector every
time the projector is turned on.
The time is not adjusted by the
Daylight Saving Time correctly.
Congure the Daylight Saving Time in the
Date/Time Settings with a web browser.
The projector cannot get the time
from SNTP server.
Check the projector is connected to the
network correctly.
Congure the correct SNTP server address
in the Date/Time Settings with a web
browser.
The Time Difference is not
congured correctly.
Congure the Time Difference, and then do
the Current Date and the Current Time in the
Date/Time Settings with a web browser.
Connection to the Network
The projector
that you want
to connect to is
nowhere to be
found on the
list of available
projectors.
The PC and/or projector’s network
settings are not congured correctly.
Check the network congurations of the PC
and projector.
If you change the projector’s settings, turn
off the projector’s AC power and then turn it
on again. If you simply put the projector in
STANDBY power mode and then turn it on
again, the new settings might not take effect.
Firewall software other than
Windows Firewall is installed in
your PC.
Refer to the manual for the rewall software
and take one of the following actions:
- Exclude the “LiveViewer” from blocking
item list
- Disable the rewall while using the
“LiveViewer”
Cannot
communicate
The PC and/or projector's network
settings are not congured correctly.
Check the network congurations of the PC
and projector.
An access point is used, and your
PC is connected to the access point
via wireless LAN.
Use network utilities that may come with
your PC or wireless LAN card to establish
wireless network connection. For detail, refer
to the manual of the PC or the card.
Security software is blocking
network communication.
Change the security setting to allow
"LiveViewer" to use.
The number of PC connection
exceeds the limit (max. 50). Try again after one of session is disconnected. (nish "LiveViewer"
application)
(continued on next page)

15
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
Troubleshooting for other Network problems (continued)
Problem Likely Cause Things to Check
Network Presentation
Cannot Install
"LiveViewer"
The "LiveViewer" does not work on
Windows Vista without any Service
Pack.
Apply the latest Service Pack to your
PC.
The projected image is
rather slow compared
to that of the PC.
The projector cannot relay dynamic
images such as PowerPoint®
animation at full speed.
Switching the priority to ‘Transmission
Speed’ under the options menu may
help to improve speed.
The compression rate used for
transferring the images is too low.
Switching the priority to ‘Transmission
Speed’ under the options menu may
help to improve speed.
No Image Using screensaver with password. The "LiveViewer" cannot send PC screen data while using screensaver
with password.
Cannot display the
movies correctly.
In some combinations of PC's video
card and application software,
the true image, especially movies
played by media player, might not
be transferred to the projector with
the “LiveViewer”.
If there is a video acceleration level
adjustment function in your application,
please try to adjust it.
Refer to your application manual in
detail.
The LiveViewer cannot transfer
movie when DFMirage driver was
installed.
Remove DFMirage driver when you
need to display movie with LiveViewer.
Network connection
between the PC
and projector is
disconnected when
PC screen resolution
is changed during
Network Presentation.
The PC-Projector network
connection might be disconnected
when PC screen resolution is
changed while displaying picture.
Please re-connect them.
Click “Connect button” after changing
PC screen resolution, or change display
resolution before connecting with the
“LiveViewer”.
Images contain lots of
interference.
The compression rate used for
transferring the images is too high. Try setting the priority to 'Image Quality' in the “LiveViewer” Option menu. You
may experience a drop in speed.
Neither transparency
nor translucency
effects (Glass)
Using the “LiveViewer” with
Windows Aero®mode. Change the effect other than "Glass".
NOTE:
It is recommended to refer to the section “Troubleshooting” in the latest version of User’s Manual - Operating
Guide, Network Guide and the User’s manual of "LiveViewer" from web site.

16
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
Cannot communicate via wired network.
NO
Set IP address and Subnet Mask in the
NETWORK - WIRED SETUP menu.
YES
YES
Does the
LED on lower right of
the LAN port light in
green?
NO
YES
Are
both of
IP address and
Subnet mask in the
WIRED INFORMATION set to
“0.0.0.0” after waiting
more than 1
minute?
NO
Is
the DHCP in
the NETWORK - WIRED
SETUP menu set to
“ON”?
NO
Use new LAN cable.
YES
YES
Is
the STANDBY
MODE setting “NORMAL” or
“QUICK START”?
Set the STANDBY MODE
as “NORMAL” or “QUICK
START” in the SETUP menu.
NO Check the network hardware.
YES
Is the PC
connected with the projector
directly?
NO
Are there
any damage to the LAN
cable? Replace MAIN PCB.
Replace MAIN PCB.
YES
NO
Are the network
addresses of PC and
projector same?
Use the same network
address on PC and projector.
YES
NO
Make sure those settings of the
projector and PC are correct.
Is
there DHCP
server on the network
which the projector is
connected to?

17
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
Cannot communicate via wireless network.
NO
YES
YES
Wait more than 1 minute after the adapter is connected.
Is the USB
wireless adapter connected
properly?
Re-connect the USB wireless adapter properly.
NO
YES
Is LED on
the adapter blinking?
NO
Can SSID
of projector be found from
PC?
Turn off your PC and projector and try again.
If they still cannot be connected, try replacing
the wireless adapter.
NO
Can
MAC address
be read from WIRELESS
INFORMATION?
YES
Remove the projector and PC
from the place and try again.
YES
NO Reset the projector’s wireless
settings to default, and try again by
using Passcode.
Is there
another projector
nearby (within 100m) which
use same wireless
setting ?
Replace MAIN PCB
or
Try replacing the USB wireless adapter.

18
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
6. Diagnosis
■ Check points
NOTE:
1) The picture above shows the inside of the projector after the UPPER CASE is removed.
2) Wiring shown in this picture may differ from mass-products.
WARNING
Do not light the light source with the upper case opened because this projector is equipped with
a laser light source.
㻼㻣㻜㻝
㻼㻢㻜㻝
㻼㻡㻜㻝
E801 : Connected to (B PANEL FAN)
EW76 : Connected to (B Illuminance sensor)
EP02 : Connected to (CNFREM)
E803 : Connected to
(LD HEAT PIPE FAN 1)
EW34 : Connected to
(LD temperature sensor)
E804 : Connected to
(LD HEAT PIPE FAN 2)
E806 : Connected to
(PHOSPHOR WHEEL FAN)
EW35 : Connected to
(PHOSPHOR WHEEL temperature sensor)
EA01 : Connected to (SPEAKER)
EW71 : Connected to
(PHOSPHOR WHEEL motor flexible cable)
P501, P601, P701 :
Connected to (RGB panel flexible cable)
E802 : Connected to (G PANEL FAN)
E807 : Connected to (R PANEL FAN)
EW32 : Connected to CNFL2
(Internal air sensor PCB)
EW31 : Connected to CNFL1
(External air sensor PCB)
E805 : Connected to
(POWER UNIT CIRCUIT FAN)
EW77 : Connected to
(R Illuminance sensor)
E800 : Connected to CNMPW
(POWER UNIT CIRCUIT PCB)

19
LWU650-APS / LWU530-APS
LWU650-APS/LWU530-APS
Service Manual 020-001522-01 Rev. 1 (11-2018) LIT MAN SERV APS Series
Picture is not displayed correctly via wired/wireless* LAN.
NO
Update the LiveViewer to the latest version.
YES
NO Check the ow on page 16, 17.
YES
Can
communicate via wireless or
wired network?
* The USB wireless adapter is needed to use wireless LAN.
Check the section of Troubleshooting for other Network problems about
other problems.
NO
YES
Re-connect after nish LiveViewer of other PCs.
Is
total PC
connection number to
projector within
50?
Re-connect after disconnecting other projectors.
Is total
projector connection
number to a PC within
11?
