Christie CineIPM-2K User manual

CineIPM-2K
USER’S MANUAL
020-100164-01

Cine-IPM 2K User’s Manual i
020-100164-01 Rev. 1 (01/08)
China RoHS Compliance Information
关于中国《电子信息产品污染控制管理办法》的说明
•Environmentally Friendly Use Period
环保使用期限
The year number in the centre of the label indicates the Environmentally Friendly Use Period, which is
required to mark on the electronic information product sold in China according to the China RoHS
regulations.
本标志中表示的年数是根据《电子信息产品污染控制管理办法》（2006年2月28日）以及《电子信息产品污染控制标识
要求》（2006年11月6日）制定的、适用于在中华人民共和国境内销售的电子信息产品的环保使用期限。
•Material Concentration Values Table
有毒有害物质含量表
Material Concentration
(有毒有害物质或元素)
Part Name 部件名称
铅
（Pb）
汞
（Hg）
镉
（Cd）
六价铬
(Cr 6+）
多溴联苯
（PBB）
多溴二联苯醚
（PBDE）
Low voltage power
supply 低压电源 X O O O O X
Power line filter 滤波电源插口 O O O O O O
Harness/cable 连接电线/缆 X O O O O X
Ten-bit image
processor module 十位图像处理模块 X O O O O O
Dual DVI output
module 双DVI输出模块 X O O O O O
Dual slot
backplane module 双槽底板模块 X O O O O O
Status display
module 状态显示模块 X O O O O O
Blower/Fan 吹风机/风扇 O O O O O O
Sensor 传感器 O O O O O O
Mechanical
enclosure* 机械附件 X O O O O O
Software CD 软件光盘 O O O O O O
Battery 电池 O O O O O O
Optional Input
Modules 可选输入模块 X O O O O O
Remote Keypad 遥控器 X O O O O O
Note:
O: indicates that the concentration value of the particular hazardous substance contained in all the homogeneous materials for this part,
according to EIP-A, EIP-B, EIP-C, is below the stipulated levels in China SJ/T11363-2006.
表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11363-2006规定的限量要求以下。
X: indicates that the concentration value of the particular hazardous substance contained in all the homogeneous materials for this part,
according to EIP-A, EIP-B, EIP-C, may be above the stipulated levels in China SJ/T11363-2006.
表示该有毒有害物质至少在该部件的某一均质材料中的含量可能超出SJ/T11363-2006规定的限量要求。
* This part uses metallic alloys, which may contain Lead. 因该部件使用金属合金材料，故可能含有铅。

Table of Contents
CineIPM 2K User’s Manual ii
020-100164-01 Rev. 1 (01/08)
Section Contents Page
1.1 Description........................................................................................................1-1
1.2 List of Components...........................................................................................1-2
1.3 Purchase Record and Service Contacts.............................................................1-2
1.4 Ethernet Settings for This Product....................................................................1-2
2.1 Installation ........................................................................................................2-1
2.2 Connecting Sources ..........................................................................................2-5
2.3 Connecting DVI Outputs ..................................................................................2-9
2.4 Connecting Communications..........................................................................2-11
2.5 Setting Up the TPC for Source Selection .......................................................2-14
2.6 Linking Multiple Cine-IPM 2Ks.....................................................................2-15
2.7 Converting the Keypad ...................................................................................2-19
3.1 Cine-IPM 2K Basics .........................................................................................3-1
3.2 Using the Keypad .............................................................................................3-3
3.3 Navigating the Menus.......................................................................................3-9
3.4 Using Inputs and Channels .............................................................................3-13
3.5 Adjusting the Image........................................................................................3-18
3.6 Adjusting System Parameters and Advanced Controls ..................................3-32
3.7 Working with PIP or Seamless Switching......................................................3-45
3.8 Status Menu ....................................................................................................3-48
3.9 Cine-IPM 2K Source Selection via TPC.........................................................3-48
3.10 Remote Control of the Cine-IPM 2K..............................................................3-49
3.11 Using Multiple Cine-IPM 2Ks........................................................................3-50
3.12 Error Conditions .............................................................................................3-60
4.1 Warnings and Guidelines..................................................................................4-1
4.2 Maintaining Proper Cooling .............................................................................4-2
5.1 Power ................................................................................................................5-1
5.2 Ethernet.............................................................................................................5-1
5.3 Displays ............................................................................................................5-1
6.1 Specifications....................................................................................................6-1
A Glossary ...........................................................................................................A-1
B Remote Keypad ............................................................................................... B-1
C Serial Communication Cables..........................................................................C-1
D System Integration ...........................................................................................D-1
E Optional Input Modules................................................................................... E-1
NOTE: Due to continuing research, all information in this manual is subject to change without notice.
1Introduction
2Installation &
Setup
3Basic Operation
4Maintenance
5Troubleshooting
6Specifications
Appendices

Section 1
Introduction
Cine-IPM 2K User’s Manual 1-1
020-100164-01 Rev. 1 (01/08)
The Cine-IPMTM 2K user’s
manual supports software
v1.4e or higher. The Cine-
IPMTM 2K expands the
functionality of Christie’s
CP2000 DLP CinemaTM
projector by processing a
variety of “alternative
content” non-cinema signals
such as computer graphics,
standard-definition video and
high-definition video (HDTV)
signals. The Cine-IPM 2K
outputs this RGB data in either 8-bit or 10-bit (selectable) DVI format having 2048 x 1080
display resolution to match that of the CP2000 (default) or one of 5 other display
resolutions. Rack-mount the Cine-IPM 2K directly into the projector’s pedestal or into a
19-inch equipment rack, or use as a stand-alone tabletop unit.
General
Choice of five different output resolutions from a variety of sources.
Versatile electronic scaling to automatically maximize for the display area
Digital processing selectable as 8-bit or 10-bit, always output through DVI ports
3RU enclosure for rack mounting or installation within the CP2000 pedestal.
4 Standard Inputs, 2 Option Slots
One analog RGBHV/YPbPr input with 5 BNCs
One DVI-I input for either digital (RGB/YCrCb) or analog (RGB/YPbPr) signals
One analog Composite video input
One analog S-video input
Built-in multi-standard decoder (NTSC, NTSC 4.43, PAL, PALM, PALN, PAL60, SECAM)
Two option slots for additional inputs
Up to 210 MHz pixel rate
Compatible with all current HDTV formats
Motion adaptive deinterlacing of 50 fps- and 60 fps-originated standard and high-
definition interlaced sources
Inverse telecine deinterlacing of film-originated standard and high-definition
interlaced material with 3:2 pulldown (60 fps) or 2:2 pulldown (50 fps).
Cine-IPM 2K
1.1 Description
Main Features
X

INTRODUCTION
1-2 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
Special Display Functions
Auto setup of non-cinema content
Electronic brightness uniformity, whitelevel edge blending and color matching
Optional image warping/blending for unusual angles and/or screens (ChristieTWIST
required)
Communications and Diagnostics
Remote keypad, convertible for IR or wired use
Front IR sensor
Ethernet, RS232 (with in/out loop-through), RS422 and GPIO control ports
Built-in ChristieNET™connectivity for automated operation and source switching
Interfaces with the Touch Panel Controller on the CP2000.
LCD text display window for status updates and error messages
Complete log files saved for downloading
The following components comprise a complete Cine-IPM 2K (see Figure 3.1):
Cine-IPM 2K with pre-installed ears for rack-mounting
Remote keypad with cable
Custom RS232 communication cable (for use with CP2000 only)
3-ft. DVI output cables (2)
10-ft. power cord
2 rear support screws
Cine-IPM 2K User’s Manual
Whether this product is still under warranty or the warranty has expired, Christie’s
highly trained and extensive factory and dealer service network is always available to
quickly diagnose and correct malfunctions. Service information is available to service
technicians.
Should you encounter a problem with this product and require assistance, please
contact your dealer or one of the Christie service depots listed on the back cover of
this manual. If you have purchased the product, fill out the form below and keep with
your records.
Purchase Record
Dealer:
Dealer Phone Number:
Cine-IPM 2K Serial Number:
Purchase Date:
* NOTE: Serial number is located on the rear panel of the product.
At manufacture, the following Ethernet settings were defined for the Cine-IPM 2K:
Factory-set Ethernet Settings for This Product
Default Gateway n/a
DNS Server n/a
Cine-IPM 2K Address 0.0.0.0 (DHCP server will auto-assign a valid IP address)
Subnet Mask 255.255.255.0 (fixed)
1.2 List of
Components
1.3 Purchase
Record and
Service
Contacts
1.4 Ethernet
Settings for
This Product

Section 2
Installation & Setup
Cine-IPM 2K User’s Manual 2-1
020-100164-01 Rev. 1 (01/08)
This section explains how to install, connect, and get the Cine-IPM 2K up and running. For operating details, refer to
Section 3.
Follow these steps for a quick install of the Cine-IPM 2K in the rear of the CP2000
pedestal.
WARNING
Qualified service technician required.
1. Unlock and open the
CP2000 pedestal doors.
2. Remove the 2 rack
protector posts from the
CP2000 pedestal rear.
Screws are accessed from
within the pedestal.
See right.
3. Remove 3 security slats to
create a 3RU opening for the Cine-IPM 2K.
Install Cine-IPM 2K
1. POSITION EARS AS
DESIRED: To recess
the Cine-IPM 2K so
that its front source
connections route
through the
pedestal and out the
front toe, move the
Cine-IPM 2K
mounting ears to
their forward
position (see Figure
2.1 Installation
Ste
p
1
X
Figure 2.1. Remove Rack Protector Posts (2)
Ste
p
2
X
Figure 2.2. To Recess the Cine-IPM 2K

INSTALLATION AND SETUP
2-2 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
2.2). Alternatively, move the ears to their rear mounting location to position
the Cine-IPM 2K so that its front panel remains accessible and flush with the
rear of the CP2000 pedestal. Always use 4 screws to mount the ears.
2. INSTALL THE Cine-IPM 2K:Insert the rear
of the Cine-IPM 2K into the open area of
the pedestal. Use 2-4 screws to secure
each mounting ear to the pedestal frame.
3. Re-install the 2 rack protector posts.
Connect Sources
Connect your desired sources to the appropriate connectors on the front input panel
of the Cine-IPM 2K. For more information, see 2.2, Connecting Sources.
•INPUT 1 – RGB input or Extra Video*via BNC connectors
•INPUT 2 – Digital or analog signals (DVI-I) from a computer
•INPUT 3 – Composite video
•INPUT 4 – S-video
•INPUT 5 – optional input module #1
•INPUT 6 – optional input module #2
*NOTE: Extra video is only available with models that have a BNC
connector at INPUT 3 and will not work with previous Christie models, which
include a RCA
connector at that input.
In a recessed installation, pass
the source cable ends through
the ears and down to exit via the
front toe of the pedestal, then
connect at the source (Figure
2.3).
See the CP2000 User’s Manual
for further cable routing details.
Ste
p
3
X
Figure 2.3. Suggested Cable Routing

INSTALLATION AND SETUP
Cine-IPM 2K User’s Manual 2-3
020-100164-01 Rev. 1 (01/08)
Connect DVI Output
TO PROJECTOR: Connect a DVI cable between the DVI-1 port on the Cine-IPM 2K
rear panel and the DVI-1 port on the CP2000. See Figure 2.4.
Distance for DVI Output DVI Cable Required
Up to 3 ft. / 1m Use DVI cables provided (2)
4 ft. – 16 ft. / 1.25 – 5m Use a standard DVI cable
Over 16 ft. / 5m Use a fiber-optic (or similar) cable
— Contact Christie
Figure 2.4. Standard DVI Connection for 8-bit Output on the CP2000
TO 2nd DEVICE: To use an additional display device such as a digital monitor or
second projector, connect the second DVI cable between DVI-2 on the Cine-IPM 2K
rear panel and the
extra device (Figure
2.5). Display devices
connected to DVI-2
must accept DVI, i.e.
they must be digital—
the DVI-VGA adapter
is for DVI-1 use only.
In addition, the device
must accept the Cine-
IPM 2K format
selected.
Ste
p
4
X
Figure 2.5. Adding a 2nd Display Device

INSTALLATION AND SETUP
2-4 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
NOTES: 1) Based on some monitor resolution limitations, Cine-IPM 2K output may
not be accepted. 2) For any installation, connect either DVI-1 or DVI-2 to a
compatible display device; output data is the same until 10-bit mode is activated. 3)
For complete information, such as how to connect for 10-bit operation, see 2.3,
Connecting DVI Outputs.
Connect Communications
All Cine-IPM 2K functions can be accessed and controlled using its keypad. Use the
keypad as an IR remote, or connect it to the Cine-IPM 2K’s front input panel using
the keypad cable (wired configuration is required when the Cine-IPM 2K is
permanently hidden within the pedestal).
For the option of using
the CP2000’s Touch
Panel Controller to
select Cine-IPM 2K
sources, you must also
connect the Cine-IPM
2K’s RS232 “B” cable
(see right):
1. Connect the custom
RS232 cable
(provided) to the
RS232 B port on rear
of the Cine-IPM 2K.
2. Connect the other end to the RS232 B port on the CP2000. Refer back to Figure
2.4.
IMPORTANT
Do not use RS232 “B” ports and cable with other
equipment or in other configurations.
Connect to Power
Connect the Cine-IPM 2K power cord to the convenience outlet within the pedestal
(refer back to Figure 2.4), or to an external supply as desired. See Specifications for
power requirements.
WARNING
Do not attempt operation if the AC level is not within
the specified range for the Cine-IPM 2K.
Turn on the Projector
Follow the complete power-up instructions provided in the CP2000 User’s Manual.
Turn on the Cine-IPM 2K
At the front of the Cine-IPM 2K, set the “Power” switch to ON. Then press
(power) on the remote keypad.
Ste
p
5
X
Figure 2.6. Connecting Communication to TPC
STEP 6
X
STEP 7
X
STEP 8
X
Co n t r o l l e r
T
o
u
c
h
P
a
n
e
l

INSTALLATION AND SETUP
Cine-IPM 2K User’s Manual 2-5
020-100164-01 Rev. 1 (01/08)
Select a Source
Using the remote keypad, press
Input 1
,
Input 2
,
Input 3
,
Input 4
,
Input 5
or
Input 6
to select the
corresponding source connected in Step 3. The image from this source will be
projected as a 2048 x 1080 display (default).
If desired, an installer, administrator or advanced user can configure the TPC for
Cine-IPM 2K source switching—see 2.5, Setting Up the TPC for Source Selection.
Press
Auto
Setup
and/or
Menu
to refine other display parameters for this source as desired, or
to change to 10-bit output and/or a different resolution. See also 3.4, Using Inputs
and Channels.
Close/Lock Pedestal Doors
With the Cine-IPM 2K fully installed, you should need no further access to the
interior of the pedestal. In a recessed installation where the Cine-IPM 2K is
inaccessible, make sure to leave the Cine-IPM 2K main switch permanently set to
“on”.
Sources connect to the front panel of the Cine-IPM 2K. See Figure 2.7. To add a
source when the Cine-IPM 2K is recessed and secured within the CP2000, a qualified
service technician must unlock and open the pedestal for access.
Input Panel
The upper right corner (INPUT 1) typically accepts an RGB signal from an external
analog RGB source, or it can also be used for YPbPr signals. Adjacent to these
BNCs, the DVI-I connector (INPUT 2) accepts digital or analog display signals from a
computer. Connect analog composite video at INPUT 3 or S-video at INPUT 4 from
devices such as VCRs, laser disk players or DVD players.
USING THE OPTIONAL SLOTS: There are also several optional interfaces available for
connecting additional sources. These interfaces slide into the option slots #1 (INPUT
5)or #2 (INPUT 6),and may be removed or installed while the Cine-IPM 2K is
powered up, if desired. Insert carefully along installation guides, making sure not to
touch the main board installed near the roof of the open slot.
Figure 2.7. Cine-IPM 2K Input Panel
NOTES: 1) See Section 6, Specifications for details regarding compatible inputs. 2)
For all connections, use high quality shielded cables only.
STEP 9
X
STEP 10
X
2.2 Connecting
Sources

INSTALLATION AND SETUP
2-6 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
INPUT 1 consists of 5 BNCs (connectors) for linking to a variety of sources. The
typical connection would be to an RGB source such as a PC, Mac, DEC, Sun, SGI
and others. The Cine-IPM 2K supports multiple sync types with RGB signals: sync-
on-green, composite sync, and separate H & V syncs.
NOTE: Depending on your source, you may need a custom adapter cable with BNC
connectors at the projector end and a different type of connector at the other (such as
a 15-pin "D" connector for some computer sources). Contact your dealer for details.
Connect the SYNC BNC input(s). Then connect the red, green and blue source outputs
to the RED, GREEN, and BLUE BNCs on the INPUT 1 panel. If the source uses sync-
on-green, only the red, green, and blue connections are required. If the source
provides a composite sync output, connect it to the SYNC input labeled HOR/COMP. If
the source provides separate horizontal and vertical sync outputs, connect horizontal
sync to the SYNC input labeled HOR/COMP and connect vertical sync to SYNC input
labeled VERT. See Figure 2.8.
Figure 2.8. Connecting an RGB source
NOTES: 1) If for some reason the projector fails to recognize a signal as an RGB
signal, specify this Color Space option within the Image Settings menu. See 3.5,
Adjusting the Image. 2) To connect YPbPr signals–such as from DVDs or analog HDTV
sources–to INPUT 1, use the red, green and blue BNCs as described in YPbPr Signals
(below). 3) This input does not route to the decoder and cannot be used for Composite
Video or S-Video.
Connect a YPbPr signal (component video) to INPUT 1 or INPUT 2 as shown in Figure
2.9.
NOTES: 1) If, for some reason, the projector fails to recognize a YPbPr signal,
specify this Color Space option within the Image Settings menu. See 3.5, Adjusting
the Image. 2) Do not connect digital component signals (known as YCbCr) to INPUT
1or INPUT 2. Use the appropriate optional digital interface installed in INPUT 5 or 6
only. 3) With v1.1 software, digitally encrypted source material (HDCP) cannot be
processed and will be displayed as a blank screen.
RGB Si
g
nals
X
YPbPr Signals
X
(COMPONENT VIDEO)

INSTALLATION AND SETUP
Cine-IPM 2K User’s Manual 2-7
020-100164-01 Rev. 1 (01/08)
Figure 2.9. Connecting a YPbPr Source
INPUT 3 and INPUT 4 provide simultaneous connection of both a composite video
source (INPUT 3)and an S-Video source (INPUT 4). See Figure 2.10.
Figure 2.10. Connecting Composite Video and/or S-Video
Video
X

INSTALLATION AND SETUP
2-8 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
If you want to use an extra video source in addition to the video source(s) connected
at INPUT 3 or INPUT 4 connect either a Composite or S-video source to INPUT 1 as
shown.
NOTES: 1) Do not simultaneously connect Composite and S-video to INPUT 1. 2) You
can switch between video sources connected at INPUT 1 and INPUT 3 or INPUT 4.
3) Extra video is only available with models that have a BNC connector at INPUT 3
and will not work with previous Christie models, which include a RCA connector at
INPUT 3.
Figure 2.11. Connecting an Extra Video Source to Input 1
Optional input modules allow you to increase your total number of inputs and/or
accommodate different signal types, whether analog or digital. Install in the areas
labeled INPUT 5 or INPUT 6. These interfaces include:
•RGB 500 Input Module
•RGB 400 Active Loop Thru Input Module
•RGB 400 Buffered Amplifier Input Module
•PC250 Analog Input Module
•Serial Digital Input Module
•Digital HDTV Module
•DVI Input Module
•Dual SD/HD-SDI Module
For even more sources, connect a 3rd-party switcher to the RS232 IN port, or, if
RS422-compatible, to any of the three RS422 ports. Note that any sources in a
switcher can be selected only at the switcher, not via the keypad or TPC.
NOTES: 1) Connect analog HDTV signals directly to INPUT 1 or to any other
“RGB” input module installed—the optional HDTV Input Module used in earlier
projectors is not needed or recommended. 2) See Appendix E, Optional Input
Modules for a brief description of each interface.
Extra Video
X
O
p
tional In
p
uts
X

INSTALLATION AND SETUP
Cine-IPM 2K User’s Manual 2-9
020-100164-01 Rev. 1 (01/08)
All input signals processed by the Cine-IPM 2K are routed to the identical DVI
outputs located on the rear panel of the unit. Connect DVI-1 to the DVI-1 connector on
the CP2000 (cable provided). If desired, connect an additional display device such as
a digital monitor using DVI-2. Shown are 4 typical applications for the Cine-IPM 2K:
• 8-bit mode for one CP2000 (Figure 2.12A)
• 8-bit mode for CP2000 and a digital monitor (Figure 2.12B)
• 8-bit mode for two CP2000s (Figure 2.12C)
• 8-bit or 10-bit mode for one CP2000 (Figure 2.12D)
Figure 2.12. Connecting for 8-bit vs. 10-bit Use
If desired, such as when you have digital progressive source data, you can output it in
10-bit format for a single CP2000 connected to the Cine-IPM 2K. This is shown in
Figure 2.12D above. Because Cine-IPM 2K’s 10-bit output is divided between the
two DVI ports, with DVI-1 handling the most-significant 8 bits and DVI-2 handling the
remaining least-significant 2 bits, 10-bit mode requires both outputs connected to the
corresponding CP2000 DVI ports.
Selecting 8-bit or 10-bit Mode
With the Figure 2.12D configuration, you can use either 8-bit or 10-bit Cine-IPM 2K
mode for all sources. Make sure to set this mode (a.k.a. “Data Format”) in 2 places:
2.3 Connecting DVI
Outputs
Connecting fo
r
X
10-bit Use

INSTALLATION AND SETUP
2-10 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
1. In the Cine-IPM 2K
Configuration menu, select
the Output Format submenu.
2. Select the desired “Output
Format”— use “Single Link
8-bit” or “Twin Link 10-bit”.
The latter improves displays
of digital progressive source
data.
The Cine-IPM 2K outputs all
sources according to the
choice set here.
3. In the TPC, go to the Custom menu (password required). Set “Input” to the
current DVI route:
For 8-bit mode via a DVI-1 connection, select “DVI-A”
For 8-bit mode via a DVI-2 connection, select “DVI-B”.
For 10-bit mode via a double connection, select “DVI-TWIN”.
Figure 2.14. TPC Settings (10-BIT EXAMPLE)
4. Still in the TPC Custom menu, set “Data Format” to match the Cine-IPM 2K
format chosen in Step 2.
NOTE: When using the Cine-IPM 2K with two display devices, both outputs are 8-bit
duplicates of one another and 10-bit mode is not available.
For complete setup information and control of other Cine-IPM 2K options such as
resolution, refer to 2.5, Setting Up the TPC for Source Selection. See also Section 3.
Figure 2.13

INSTALLATION AND SETUP
Cine-IPM 2K User’s Manual 2-11
020-100164-01 Rev. 1 (01/08)
As an alternative to keypad and/or TPC control, you may wish to communicate with
the Cine-IPM 2K using a PC or other controller. Such a device sends commands and
receives feedback via serial links (2 types), Ethernet or GPIO communications. All
types of communication methods are described below.
If desired, connect a wired (tethered) version of the Cine-
IPM 2K remote keypad to the 3.5mm phono jack on the
front panel. Note that response to a wired keypad must also
be enabled in the Communications menu—see 2.7,
Converting the Keypad for more information.
If you have connected the rear RS232 “B” port of the Cine-
IPM 2K to the RS232 “B” port in the CP2000, you can use
the Touch Panel Controller for selecting sources connected
to the Cine-IPM 2K. Refer back to Figure 2.6. The RS232
connection also enables Cine-IPM 2K status updates at the
TPC.
NOTE: The TPC can select a specific Cine-IPM 2K source
(#1-6) only if the CP2000 is connected via DVI-1. If
connected via DVI-2, the TPC can select this port (called
DVI-B), but you must use the Cine-IPM 2K keypad to select
the source (#1-6).
The rear Ethernet port on the Cine-IPM 2K is an alternative
route planned for TPC communications, but is currently
non-functional.
RS232 Serial Communications
From most computers, connect a standard RS232 serial communication cable
between the computer and the Cine-IPM 2K serial port labeled RS232 IN. Then set the
Cine-IPM 2K baud rate to match that of your computer.
Changing the baud rate is done in the Cine-IPM 2K’s Communications submenu. See
3.6, Adjusting System Parameters and Advanced Controls.
Figure 2.15. Connecting Serial Communications via RS232
RS422 Serial Communications
Some computers can provide RS422 serial communications (often through a plug-in
adapter or external converter) rather than the more common RS232 standard. RS422
communication has differential “transmits-and-receives” and is generally better
2.4 Connecting
Communications
Remote Ke
yp
ads
X
TPC
X
Other Controllers
X

INSTALLATION AND SETUP
2-12 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
suited for long distances than is RS232 communication. Note that RS422 is not
compatible with RS232—connecting a RS232-compatible PC to RS422 can damage
the equipment at either end. Consult the documentation provided with your PC if you
are unsure.
The 9-pin RS422 connector is located on the front input panel of the Cine-IPM 2K.
When using this port, make sure to set the baud rate to match that of your RS422
controlling device.
Figure 2.16. Connecting Serial Communications via RS422
CAUTION
Do not use an RS422 port unless you are using
equipment with RS422 capability. The voltage levels of
this signal can damage incompatible equipment.
Ethernet Communications
To add the Cine-IPM 2K to an Ethernet network with other equipment such as
controllers and other projectors, connect standard CAT5 Ethernet cable between your
Ethernet controller (or hub) and the Ethernet port on the Cine-IPM 2K front panel.
NOTES: 1) Ethernet crossover cable required if connecting directly to a PC only. 2)
Downloading new software to the projector via Ethernet is not supported.

INSTALLATION AND SETUP
Cine-IPM 2K User’s Manual 2-13
020-100164-01 Rev. 1 (01/08)
Figure 2.17. Connecting Ethernet
By default upon connection to an Ethernet network, a valid IP address for the Cine-
IPM 2K will be automatically assigned by a DHCP server. If there is no DHCP server
present on your network, or if you want to use a specific static IP address for the
Cine-IPM 2K, you can set this address in the Ethernet Settings menu or via an ASCII
serial command.
Regardless of how it is assigned, once a Cine-IPM 2K has a valid and unique address
it will respond immediately to commands sent to this address. To determine the Cine-
IPM 2K’s current IP address, consult the Status or Communications menus.
Refer to 3.6, Adjusting System Parameters and Advanced Controls for further
information about setting up and using a Cine-IPM 2K connected via Ethernet.
The GPIO Port
The General Purpose In-Out (GPIO) port enables integration of the Cine-IPM 2K
within an established control system so that other devices connected via GPIO can
operate in tandem with Cine-IPM 2K, or vice versa. ASCII commands sent via
standard serial ports can be stored in Cine-IPM 2K memory, where they can then
trigger a sequence of events in response to incoming or outgoing signals at the GPIO
port, depending on your programming of the GPIO pins. For example, you can
automatically dim the room lighting when the Cine-IPM 2K is turned on, or
automatically turn the unit off when the lights are raised.

INSTALLATION AND SETUP
2-14 Cine-IPM 2K User’s Manual
020-100164-01 Rev. 1 (01/08)
Figure 2.18. GPIO Port
For more information, refer to Appendix D.
At many CP2000 sites, users may prefer to select their non-cinema Cine-IPM 2K
sources with a simple button on the TPC Main menu. These buttons provide a
reliable and quick way to switch to a specific Cine-IPM 2K source, but they must
first be configured and defined by an installer, administrator, or advanced user having
access rights to the TPC Custom menu. See below.
NOTES: 1) This procedure assumes familiarity with the TPC. For complete
information, see the CP2000 User’s Manual provided with the projector. 2) The
RS232 “B” link is required for source selection at the TPC. 3) Currently the TPC
can be configured for switching sources only, not channels.
1. Make sure your CP2000 and Cine-IPM 2K are properly connected via both DVI
and RS232 “B”. Otherwise the two devices cannot communicate with each other.
2. Connect the desired
source(s) to the front of the
Cine-IPM 2K.
3. In the Cine-IPM 2K menus,
set the desired output
resolution and output (8-bit
vs. 10-bit; a.k.a. “Data
Format”). Remember that
10-bit output requires both
DVI connections. See right.
4. With the projector and
Cine-IPM 2K both powered up normally, go to the Custom menu of the TPC and
set the following options (see Figure 2.20):
•Define INPUT: Set whether your Cine-IPM 2K data link is via DVI-1 (called
“DVI-A” at the TPC) or DVI-2 (called “DVI-B” at the TPC), or whether the
incoming data is shared in a DVI-TWIN (10-bit) configuration utilizing both
DVI routes. With any of these three TPC input options, you must still use
the remote keypad to select the desired Cine-IPM 2K input (#1-6).
Alternatively, if you have multiple sources connected to the Cine-IPM 2K
for outputting on the 8-bit DVI-1 link, you may prefer to define a specific
2.5 Setting Up the
TPC for Source
Selection
Figure 2.19. Controlling Cine-IPM 2K Output
Co n t r o l l e r
T
o
u
c
h
P
a
n
e
l
