Quick Start Guide
Color Block 2 Plus™
For a full product manual please visit www.chroma q.com

Chroma-Q Color Block 2 Quick Start Guide Chroma-Q Color Block 2 Quick Start Guide
1. Overview
The Chroma Q™ Color Block 2 Plus™ is a higher output version of the original Color Block 2™ multi purpose LED
fixture that retains the same versatile modular ‘building block’ design, single colour RGBA optics, high light output and
theatrical grade dimming to create an exceptional all round feature set.
The control options incorporate a choice of HSI (Hue, Saturation and Intensity), RGBA (Red, Green, Blue, Amber), RGB
(Red, Green, Blue, with *Magic Amber), RGBI (Red, Green, Blue with *Magic Amber and Intensity) control modes, and a
dynamic Variable Effects Engine integrated in the software.
The Color Block PSU05B V2 and Color Block PSU30 V2 are DMX controlled power supply units available for the Color
Block 2 Plus fixtures.
2. Safety
Caution
1. This product is for professional use only. It is NOT intended for domestic or outdoor use.
2. The bright flash of light during power up may cause epileptic seizure.
3. Continuous strobe in the effects may cause epileptic seizure.
4. This product must be used with safety cable.
3. Cabling
Connect power and control data from the power supply unit through the XLR 4 pin cable system. Pin 1 = 0VDC, pin 2 =
control minus, pin 3 = control plus, pin 4 = +48VDC. The chassis should be ground bonded. A maximum of 5 daisy
chained Color Block 2 Plus fixtures can be connected to one output. Return lines are not required, the total cable length
of each chain must not exceed 60m/ ~200ft, and the cable for each adjacent units must not exceed 20m.
PSU-30 PSU-05B
4. Fixings
1. Integrated connection system: Connect two fixtures together by mating the two protruding pins from one fixture
into the keyhole slots of the other fixture. Slide the fixtures together and align to get past the extended catch
plate. Use the butterfly latch to secure the fixtures together tightly (maximum 5 units together).
2. Batten bracket kit for up to 5 fixtures: Used for floor mounting, direct wall mounting and truss mounting in
conjunction with hook clamps or half couplers.
3. Yoke kit for single fixture: used for floor mounting direct wall mounting and truss mounting in conjunction with
hook clamps or half couplers.
4. Dual mode yoke kit for single fixture: combines the function of the single yoke and the batten bracket.
5. Blinder frame for 4 fixtures: consists of end plates with two complete sets of fixture fixing holes. 1
st
set holds the
fixtures closely together ensuring equal centres for all 16 cells. 2
nd
set are adjustable to allow the blocks to be
splayed out at varying angles.
6. Hinge kit: used to fit between 2 blocks and offer an angle adjustment of 180deg. If used in multiples, unique
shapes can be achieved such as hexagons, octagons etc.
7. Wall bracket for single fixture: used to fix a single block to a wall or set piece. Keyhole slots are provided for
vertical or horizontal fixing.
5. Emulation Mode
The Color Block 2 Plus is fitted with an internal switch that adjusts the lumen output of the unit to simulate the original
LED engine of the Color Block 2 fixtures.
1. Remove the end plate with rivets.
2. The toggle switch on the edge of the PCB is on the horizontal position for normal Color
Block 2 Plus operation.
3. Press the toggle switch down to simulate the lumens output of the Color Block 2.
4. Replace the end plate.
6. Control
The Color Block 2 Plus is controlled via ANSI E1.11 USITT DMX512 A through the power supply, which can be set to
operate in 16 control modes by selecting “CB2” under “System” in the “Control Menu”. Single cell, block grouped and
all grouped outputs are available in 5 control options: FxHSI, HSI, RGB (with *Magic Amber), RGBA, RGBI (with *Magic
Amber), pre programmed looks and standalone effects. See relevant PSU user manual for full details.
Color Block PS -05B – Version 2.1 Color Block PS -30 – Version 2.1
Mode Ch Group Description Ch Group Description
1 67 Variable 7FX + 20xHSI 367 Variable 7FX + 120xHSI
2 60 Cell 20xHSI 360 Cell 120xHSI
3 60 Cell 20xRGB 360 Cell 120xRGB
4 21 Block 6FX + 5xHSI 96 Block 6FX + 30xHSI
5 15 Block 5xHSI 90 Block 30xHSI
6 15 Block 5xRGB 90 Block 30xRGB
7 9 All 6FX + HSI 9 All 6FX + HSI
8 3 All HSI 3 All HSI
9 3 All RGB 3 All RGB
10 80 Cell 20xRGBA 480 Cell 120xRGBA
11 80 Cell 20xRGBI(*Magic Amber) 480 Cell 120xRGBI(*Magic Amber)
12 20 Block 5xRGBA 120 Block 30xRGBA
13 20 Block 5xRGBI(*Magic Amber) 120 Block 30xRGBI(*Magic Amber)
14 4 All RGBA 4 All RGBA
15 4 All RGBI (*Magic Amber) 4 All RGBI(*Magic Amber)
16 1 Any Look Select 1 All Look Select
Control Options:
1. 3 Channel HSI (Hue, Saturation and Intensity): 2 colour channels for hue (255 colours) and saturation, and a
separate intensity channel.
2. 3 Channel RGB (Red, Green and Blue with *Magic Amber): 3 colour channels that directly affect the intensity of
the corresponding LED.
3. 3 channel RGB(A) + 1 intensity channel (Red, Green, Blue with *Magic Amber and Intensity): 3 control channels
directly affecting the intensity of the corresponding LED, and 1 channel affecting the intensity of all RGB(A)
channels.
4. 4 channel RGBA (Red, Green, Blue and Amber): 4 control channels directly affecting the intensity of the
corresponding LED.
5. Internal FX engine: The Color Block PSUs feature internal FX engine with 7 variable parameters. See full PSU05B
V2 and PSU30 V2 manuals for control details.
Channel description for mode 1, 4 & 7:
Mode 1 Mode 4/7 Effects Description
Ch 1 Grouping variable grouping facility to run FX between / within groups
Ch 2 Ch 1 Colour Speed variable speed of colour scrolling
Ch 3 Ch 2 Colour Fan variable fan of colour between / within groups
Ch 4 Ch 3 Colour Range variable limit of spectrum range for colour scrolling
Ch 5 Ch 4 Colour Step variable control of smoothness of colour scrolling
Ch 6 Ch 5 Intensity Effects wide selection of intensity fading and snapping effect
Ch 7 Ch 6 Intensity Fan variable fan of intensity effects
Note: All internal FX are referenced back to the group base HSI colour and intensity levels.

Chroma-Q Color Block 2 Quick Start Guide Chroma-Q Color Block 2 Quick Start Guide
* Magic Amber is the term used for the unit's ability to bring in Amber when mixing colors that require it with the use of
only 3 control channels.
7. Further Information
Please refer to the Chroma Q Color Block 2 Plus manual for more detailed information. A copy of the manual can be
found at the Chroma Q website – www.chroma q.com – under Support.
