Chroma Magic Box PS12 User manual

Magic Box PS12 Quick Start Guide V1.1 Magic Box PS12 Quick Start Guide V1.1 PN: 134-0103
Approvals & Disclaimer
The information contained herein is offered in good faith and is believed to be accurate. However,
because conditions and methods of use of our products are beyond our control, this information should
not be used in substitution for customer's tests to ensure that Chroma Q products are safe, effective,
and fully satisfactory for the intended end use. Suggestions of use shall not be taken as inducements to
infringe any patent. Chroma Q sole warranty is that the product will meet the Chroma Q sales
specifications in effect at the time of shipment. Your exclusive remedy for breach of such warranty is
limited to refund of purchase price or replacement of any product shown to be other than as warranted.
Chroma Q reserves the right to change or make alteration to devices and their functionality without notice
due to on going research and development.
The Chroma Q Magic Box PS12 has been designed specifically for the professional entertainment
lighting industry. Regular maintenance should be performed to ensure that the products perform well in
the entertainment environment.
If you experience any difficulties with any Chroma Q products please contact your selling dealer. If your
selling dealer is unable to help please contact support@chroma q.com. If the selling dealer is unable to
satisfy your servicing needs, please contact the following for full factory service:
Outside Nort America:
::
: Nort America:
::
:
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
support@chroma q.com support@chroma q.com
For further information please visit the Chroma Q website at www.chroma q.com.
Chroma Q is a trademark, for more information on this visit www.chroma q.com/trademarks.
The rights and ownership of all trademarks are recognised.
Quick Start Guide
Magic Box™ PS12
For a full product manual please visit www.chroma q.com

Magic Box PS12 Quick Start Guide V1.1 Magic Box PS12 Quick Start Guide V1.1
1. Product Description
The Chroma Q Magic Box PS12 supplies power and data to the Chroma Q range of colour changers and
compatible products (see below). A maximum capacity of 12PU (Power Units), it can be controlled
remotely via ANSI E1.11 USITT DMX 512 A and delivers power and data via 3 XLR 4 outputs.
2. Operation
1. Connect power through a fused male IEC chassis connector with input power of 100 240V, 50 –
60 Hz. The standard fuse is a 5x20mm 6A GMA 125V. It provides 3 circuits of 24VDC.
2. Connect input data ANSI E1.11 USITT DMX 512 A from an external source or lighting control
console through a male XLR 5. A pass through connection is available on the female XLR 5. Power
and data outputs are from 3 individual female XLR 4 to the colour changer units.
3. The red LED indicates mains power is present and the green LED indicates a DMX signal is
present.
4. ‘PU’ (Power Unit) is used to calculate the load requirements of the Chroma Q system. The PS12
will supply up to 12 PU’s, so you can plug in 12 Chroma Q Plus (12 x 1PU = 12PU).
Note:
::
: Data termination is built in at the input.
3. System Diagram
The PS12 has been designed for cable loops of up to 60m (~200ft.) per output. Closing the loop with a
return cable will enhance the stability of the power and data delivered.
4. Compatibility
The Chroma Q PS12 is compatible with all Chroma Q colour changers – Chroma Q Plus, Original,
Broadway, Universal, Cascade, M5, M8, Mirror, Junior gobo rotator, Twin Effects gobo rotator, Twin DMX
gobo rotator.
5. Power Units
Product Power Unit Product Power Unit
Plus 1PU M5 1.5PU
Broadway 1PU M8 1.5PU
Cascade 1.5PU Moving Mirror 1.5PU
Universal 1.5PU DMX Gobo Rotator .6PU
6. Control and Power Cables
The Chroma Q utilises an XLR 4 pin cable system that is used to supply power and data transfer. Pins 1
and 4 supply 24VDC power and Pins 2 and 3 supply ANSI E1.11 USITT DMX 512 A control protocol with
ground drain wire to the connector shell.
Only genuine Tourflex Datasafe cable is recommended for use of the Chroma Q colour changing system.
Damage will occur if the power connections short circuit to the data or ground/shield connections. When
assembling XLR 4 pin cables, heat shrink sleeves should be used on each individual data pin and the
drain wire to prevent short circuits.
The XLR 4 cable is wired pin to pin, in the following format:
Pin Function
1 0V DC
2 Control Data Minus
3 Control Data Plus
4 +24V DC
Chassis Ground Bonding
The XLR 5 cable is wired pin to pin, in the following format:
Pin Function
1 Ground (Screen)
2 Data Minus
3 Data Plus
4 Spare Data Minus
5 Spare Data Plus
7. Installation
Unique Magic Box interlocking enclosure facilitates easy rack mounting when used in pairs and easy
truss mounting via captive nut insert. Rack mounting brackets are available in single unit and dual unit
versions.
Note:
: :
: for truss mounting, we recommend the use of a ½" 13UNC x ¾" long bolt to avoid damage.
8. Further Information
Please refer to the Chroma Q Magic Box PS12 manual for more detailed information. A copy of the
manual can be found at the Chroma Q website – www.chroma q.com – under Support.
