Chrysler Uconnect 3.0 Configuration guide

Owner’s Manual Supplement
Uconnect®3.0
First Edition
Uconnect®3.0
Chrysler Group LLC
Printed in the USA
15UC3-526-AA

TABLE OF CONTENTS
SECTION PAGE
1UCONNECT® 3.0 .............................................................3
2RADIO MODE ...............................................................7
3MEDIA MODE ..............................................................13
4SAFETY GUIDELINES .........................................................17
1
2
3
4

Uconnect® 3.0
CONTENTS
䡵Uconnect® 3.0 SYSTEM ....................4
1

Uconnect® 3.0 SYSTEM 1 — RADIO
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM, FM and
SXM (if equipped) can be selected by pushing the RADIO
button on the faceplate until the desired tuner mode is
displayed.
2 — INFO
Push the INFO button on the faceplate for a RBDS station
(one with call letters displayed). The radio will return
a Radio Text message broadcast from an FM station
(FM mode only).
3 — A-B-C
Push the A-B-C button on the faceplate to select the A, B
or C preset list.
4 Uconnect® 3.0

4 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
5 — SEEK UP
Push the SEEK UP button on the faceplate to tune the
radio to the next listenable station or channel.
6 — BACK
Push the BACK button on the faceplate to return to a
previous menu or screen.
7 — MENU
Push the MENU button on the faceplate to scroll between
the setting sub-menus.
8 — PLAY/PAUSE/MUTE
Push to Play, Pause or Mute the music.
9 — AUDIO
Push the AUDIO button on the faceplate to adjust the
Bass, Mid Range, Treble, Balance or Fade.
10 — SEEK DOWN
Push the SEEK DOWN button on the faceplate to tune
the radio to the previous listenable station or channel.
11 — ON/VOLUME
Push the ON/VOLUME control knob to turn on the
radio. Push the ON/VOLUME control knob a second
time to turn off the radio.
1
Uconnect® 3.0 5

The electronic volume control turns continuously (360
degrees) in either direction without stopping. Turning the
ON/VOLUME control knob to the right increases the
volume and to the left decreases it.
12 — PRESETS 1–6
These buttons on the faceplate tune the radio to the
stations that you commit to memory AM (A, B, C), FM
(A, B, C) and Satellite (A, B, C) — 18 AM, 18 FM and
18 SAT stations.
13 — MEDIA
Pushing the MEDIA button on the faceplate will allow
you to switch from AM/FM/SXM modes to Media mode
(CD – if equipped, USB/iPOD®, AUX).
6 Uconnect® 3.0

RADIO MODE
CONTENTS
䡵RADIO MODE ..........................8
▫ON/OFF Volume Control .................8
▫ENTER/BROWSE & TUNE/SCROLL Control . . .8
▫Seek Functions .........................8
▫Setting Presets .........................9
▫SiriusXM Satellite Radio Mode — If Equipped. . .9
▫Audio ..............................10
▫Clock Setting .........................11
2

RADIO MODE
The radio is equipped with the following modes:
•FM
•AM
•SXM SiriusXM Satellite Radio (if equipped)
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM, FM, and
SXM, can then be selected by pushing the RADIO button
until the desired tuner mode is displayed.
ON/OFF Volume Control
Push the ON/OFF Volume Control knob to turn on the
radio. Push the ON/OFF Volume Control knob a second
time to turn off the radio.
When the audio system is turned on, the sound will be
set at the same volume level as last played.
ENTER/BROWSE & TUNE/SCROLL Control
Turn the rotary TUNE/SCROLL control knob clockwise
to increase or counterclockwise to decrease the radio
station frequency.
When scrolling a list, push the ENTER/BROWSE button
on the faceplate to choose a selection.
Seek Functions
SEEK UP
Push and release the SEEK UP button on the faceplate
to tune the radio to the next listenable station or channel.
During a SEEK UP function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
8 RADIO MODE

SEEK DOWN
Push and release the SEEK DOWN button on the
faceplate to tune the radio to the next listenable station or
channel.
During a SEEK DOWN function, if the radio reaches the
starting station after passing through the entire band two
times, the radio will stop at the station where it began.
Setting Presets
The Presets are available for all Radio Modes, and are
activated by pushing any of the six PRESET buttons on
the faceplate.
When you are receiving a station that you wish to
commit into memory, push and hold the desired num-
bered button on the faceplate for more that two seconds
or until you hear a confirmation beep.
The Radio stores up to 18 presets in each of the Radio
modes. Push the A-B-C button on the faceplate to select
the A, B or C preset list.
SiriusXM Satellite Radio Mode — If Equipped
SiriusXM Satellite Radio uses direct satellite-to-receiver
broadcasting technology to provide clear digital sound,
coast to coast. The subscription service provider is
SiriusXM Satellite Radio. This service offers over 130
channels of music, sports, news, entertainment, and
programming for children, directly from its satellites
and broadcasting studios. A one-year SiriusXM Satellite
Radio subscription is included.
SiriusXM and all related marks and logos are trademarks
of SiriusXM Radio Inc. and its subsidiaries. SiriusXM
Satellite Radio requires a subscription, sold separately
after trial subscription included with vehicle purchase.
