XENEA
Indoor packaged air-to-water heat pump
1
HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
60
Heating capacity: 6 to 10 kW
USE
The XENEA heat pump has been designed for heating applications in new homes.
It can be connected quickly and easily to any type of heat emitter (underfloor heating, fan coil units, radiators and mixed systems, etc.) thanks to numerous
standard components.
RANGE
The XENEA range consists of 4 single-phase and three-phase models of
6, 8 and 10 kW.
If the heat pump is the only source of heat:
 Operation in heating mode up to -20°C/+45°C. A separate
source of heat must be used if outdoor temperatures drop below -20°C.
If the heat pump is used to back up a boiler:
 Operates down to the balance point (temperature below which the heat
pump can no longer keep up with heating needs). Below this point, the heat
pump and boiler run either alternately (heat pump OR boiler) or at the same
time (heat pump AND boiler).
CONFORMITY
LVD 2006/95/EC
NF C15-100
EMC 2004/108/EC
PED 97/23/EC Category 1
NF EN 60-335
Radio standard EN 300-220
DEEE 2002/96/EC
 RoHS 2002/95/EC
option
Plug & Heat ready to use heat pump
Quick and easy to install
Equipped with HomeConnect control
HFC
R410A
C
E
R
T
I
F
I
É
P
A
R
C
E
R
T
I
T
A
HEATING
30/35 - 40/45

HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
XENEA
2
Indoor packaged air-to-water heat pump
Casing
Casing in RAL 9016 white lacquered steel
 Casing panel in RAL 9016 matching ABS
Rain guard grille in RAL 9001 lacquered panel and bird screen
Angle bars in galvanised steel and foam pads for flow separation kit
Wall rubber bushes and anti-vibration feet
Compressor - R410A
Hermetic on/off SCROLL on anti-vibration mounts
Built-in electric motor cooled by suction gas
Motor protected by internal winding sensor
Noise insulation
Crankcase heater
Brazed-plate condenser
End plates and internal plates in AISI 316 stainless steel
High-performance, optimised plate patterns
Thermal insulation
Evaporator
Coil made of bent copper tubes and aluminium fins
Standard components
Cycle reversing valve
Suction accumulator
Liquid tank
Pressure-relief expansion valve
PSU and controller board
Safety components
HP pressure switches
 LP pressure sensors
 Frost protection sensors (exchanger refrigerant/water outlets)
 Water supply sensor on the exchanger
 Water safety valve (4 bar)
 Short cycle protection
Built-in hydraulic module
 3-speed accelerator pump
 Differential water pressure switch
 8 L expansion vessel
 Manual air bleed valve
 Pressure switch and valve assembly
 Filter valve
 Hydraulic hoses
 Staged auxiliary electric heater
HomeConnect control
 Temperature display
 Wireless external temperature sensor
 Water law configuration
 Monitors the operating and safety settings
 Boiler backup configuration and control
 Optimised defrosting
Electrical panel
 Unit complies with NFC-15100, EN 60-335 and EN 330-220
 Earth connection
Options (for installation on site)
 Charging kit
 DHW kit
 Swimming pool kit
 Floor limiter thermostat kit
COMPOSITION

XENEA
Indoor packaged air-to-water heat pump
3
HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
QUICK SELECTION
Xenea 20H 28H 35H 35HT
Heating capacity to 7/6°C 30/35°C kW 6,49 8,46 10,23 10,19
Power input kW 1,49 2,23 2,65 2,64
COP 4,36 3,79 3,86 3,86
Heating capacity to -7/-8°C */35°C kW 3,85 5,03 6,00 5,99
Power input kW 1,6 2,21 2,58 2,58
COP 2,39 2,28 2,33 2,32
Heating capacity to 7/6°C 40/45°C kW 5,97 7,81 9,49 9,47
Power input kW 1,83 2,54 3,07 3,06
COP 3,26 3,08 3,09 3,09
Heating capacity to -7/-8°C */45°C kW 3,54 4,51 5,58 5,57
Power input kW 1,93 2,54 2,99 2,98
COP 1,83 1,78 1,87 1,87
Net capacities certified by NFPAC in accordance with test standard EN14511-2
Power input integrating compressor + control + fan + accelerator pump + defrosting cycles
HYDRAULIC MODULE PRINCIPLE DIAGRAM
Brazed-plate heat exchanger
Heater
Manual air bleed valve
4-bar pressure relief valve
Expansion vessel
Temperature sensors
Differential pressure switch
Accelerator pump
Built-in filter valve
System 1’’ return hose
System 1’’ supply hose
INLET
OUTLET
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
6
6
7
8
9
10
11

HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
XENEA
4
Indoor packaged air-to-water heat pump
OPERATING LIMITS
Water return temperature (P281)
External temperature (P250)
55°C
30°C
25°C
-20°C 0°C +5°C
Mix of pure water + anti-
freeze fluid (example:
40% MPG)
Pure water
Minimum water return temperature during operation:
+ 10°C pure water/+5°C glycol/water mix
Maximum water return temperature: + 55°C
WATER FLOW RATES AND HYDRAULIC CONNECTIONS TO OBSERVE
System water flow rates and piping diameters*
Xenea Minimum flow rate
(m3/h)
Nominal flow rate
(m3/h)
hot water production
Copper pipe hydraulic
connection
Steel pipe hydraulic
connection
PE (polyethylene) pipe
hydraulic connection
20 H 0,75 1,1 28x1 33/42 - DN32 1’’ 1/4 32x2.9
28 H 0,75 1,45 28x1 33/42 - DN32 1’’ 1/4 32x2.9
35 H(T) 1,05 1,75 32x1 33/42 - DN32 1’’ 1/4 32x2.9
* Minimum diameters calculated for a hydraulic connection for your machine 15 m away from its connection to the system.
AVAILABLE PRESSURE IN SYSTEM
The available pressure curves are given for pure water.
Subtract 5 kPa from the available pressures in the case of systems using 40% monopropylene glycol (heating mode).
70
60
50
40
30
20
10
0
0,5 1 1,5 2
70
60
50
40
30
20
10
0
1,0 1,5 22,5 3
XENEA 20H - 28H XENEA 35 H (T)
Available static pressure (kPa)
Available static pressure (kPa)
water flow rate (m3/h) water flow rate (m3/h)
+45°C

XENEA
Indoor packaged air-to-water heat pump
5
HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
NET HEATING CAPACITIES
Power input integrating compressor + control + fan + accelerator pump + defrosting cycles
XENEA
Outdoor
air temp.,
°C
Hot water outlet temp. (°C)
25 30 35 40 45 50 55 60
Pi kW Hc kW Pi kW Hc kW Pi kW Hc
kW Pi kW Hc kW Pi kW Hc kW Pi kW Hc kW Pi kW Hc kW Pi kW Hc kW
20H
-20 1,3 2,4 1,4 2,4 1,5 2,3 1,6 2,2
-15 1,3 3,5 1,4 3,2 1,5 2,9 1,6 2,8 1,8 2,7
-10 1,4 3,7 1,4 3,6 1,6 3,5 1,7 3,4 1,9 3,2 2,1 3,2
-7 1,4 4,1 1,5 4,0 1,6 3,8 1,7 3,8 1,9 3,5 2,1 3,5 2,4 3,5
-5 1,4 4,3 1,5 4,3 1,6 4,2 1,7 4,1 1,9 3,9 2,2 3,7 2,4 3,7
0 1,4 5,0 1,5 5,0 1,6 4,9 1,7 4,8 1,8 4,6 2,2 4,3 2,4 4,2 2,6 4,0
2 1,4 5,3 1,5 5,2 1,5 5,2 1,7 5,0 1,8 4,8 2,2 4,6 2,4 4,4 2,6 4,3
5 1,4 5,9 1,5 5,8 1,5 5,7 1,7 5,5 1,8 5,4 2,2 5,0 2,4 4,9 2,7 4,8
7 1,4 6,7 1,5 6,6 1,5 6,5 1,7 6,2 1,8 6,0 2,2 5,6 2,4 5,4 2,7 5,6
10 1,4 6,9 1,5 6,8 1,5 6,8 1,7 6,6 1,9 6,4 2,2 6,1 2,4 5,9 2,7 5,9
15 1,4 7,8 1,4 7,7 1,5 7,6 1,7 7,5 1,9 7,3 2,1 6,8 2,4 6,5 2,7 6,4
20 1,3 8,7 1,4 8,6 1,5 8,4 1,7 8,2 1,9 8,0 2,1 7,7 2,4 7,5 2,6 7,3
25 1,3 8,9 1,4 8,7 1,5 8,5 1,7 8,3 1,9 8,1 2,1 7,9 2,3 7,7 2,6 7,5
30 1,2 9,1 1,4 8,9 1,5 8,7 1,7 8,5 1,9 8,3 2,1 8,2 2,3 8,0 2,6 7,8
35 1,2 9,3 1,4 9,1 1,5 8,9 1,7 8,8 1,9 8,6 2,1 8,4 2,3 8,3 2,6 8,1
40 1,2 9,4 1,4 9,3 1,5 9,1 1,7 9,0 1,9 8,8 2,1 8,7 2,3 8,6 2,6 8,4
45 1,2 9,6 1,4 9,5 1,5 9,3 1,7 9,2 1,9 9,1 2,1 9,0 2,3 8,8 2,6 8,7
28H
-20 2,1 3,4 2,1 3,4 2,2 3,5 2,3 3,5
-15 2,1 3,9 2,1 3,9 2,2 4,0 2,3 4,0 2,5 3,7
-10 2,1 4,6 2,1 4,7 2,2 4,7 2,3 4,6 2,5 4,2 2,8 4,2
-7 2,1 5,0 2,1 5,0 2,2 5,0 2,4 4,8 2,5 4,5 2,8 4,5 3,1 4,3
-5 2,1 5,5 2,1 5,5 2,2 5,5 2,4 5,3 2,5 4,9 2,8 4,7 3,1 4,5
0 2,0 6,7 2,1 6,7 2,2 6,6 2,3 6,2 2,5 6,0 2,9 6,0 3,1 5,8 3,5 5,7
2 2,0 7,0 2,0 7,0 2,2 7,0 2,3 6,5 2,5 6,4 2,8 6,3 3,1 6,1 3,5 5,9
5 2,0 7,7 2,0 7,7 2,2 7,4 2,3 7,4 2,5 7,0 2,8 6,8 3,1 6,6 3,5 6,4
7 2,0 8,6 2,0 8,6 2,2 8,5 2,3 8,2 2,5 7,8 2,8 7,5 3,1 7,3 3,5 7,1
10 2,0 7,8 2,1 7,8 2,3 7,8 2,4 7,8 2,6 8,2 2,9 8,1 3,2 7,9 3,5 7,1
15 2,0 9,3 2,1 9,2 2,3 9,0 2,4 8,8 2,6 9,1 2,9 8,6 3,2 8,5 3,5 8,3
20 2,0 10,5 2,1 10,4 2,3 10,3 2,4 10,1 2,6 10,0 2,9 9,7 3,2 9,5 3,5 9,4
25 1,9 10,7 2,1 10,5 2,3 10,4 2,4 10,2 2,6 10,1 2,9 9,8 3,2 9,6 3,4 9,5
30 1,9 10,8 2,0 10,7 2,3 10,5 2,4 10,3 2,6 10,2 2,9 9,9 3,2 9,7 3,4 9,6
35 1,8 10,9 2,0 10,8 2,2 10,6 2,4 10,4 2,6 10,3 2,9 10,0 3,2 9,9 3,4 9,7
40 1,8 11,0 2,0 10,9 2,2 10,7 2,4 10,5 2,5 10,4 2,8 10,2 3,1 10,0 3,4 9,8
45 1,8 11,2 2,0 11,0 2,1 10,8 2,3 10,6 2,5 10,4 2,8 10,3 3,1 10,1 3,3 9,9
35H
-20 2,1 4,5 2,2 4,3 2,5 4,1 2,6 4,1
-15 2,1 5,2 2,2 5,0 2,5 4,8 2,7 4,7 2,9 4,6
-10 2,1 6,1 2,3 5,9 2,5 5,5 2,7 5,5 2,9 5,3 3,2 5,1
-7 2,1 6,6 2,3 6,3 2,6 6,0 2,8 5,8 3,0 5,6 3,3 5,5 3,6 5,2
-5 2,1 6,9 2,3 6,7 2,5 6,5 2,8 6,2 3,0 6,1 3,3 6,0 3,6 5,8
0 2,1 8,1 2,3 7,8 2,5 7,6 2,8 7,4 3,1 7,0 3,4 6,9 3,7 6,7 4,2 6,4
2 2,1 8,5 2,3 8,3 2,5 8,2 2,9 8,0 3,0 7,5 3,4 7,2 3,7 7,1 4,2 6,8
5 2,1 9,2 2,4 9,1 2,6 9,0 2,9 8,8 3,1 8,3 3,4 8,1 3,7 7,9 4,2 7,7
7 2,1 10,9 2,4 10,3 2,6 10,2 2,9 9,7 3,1 9,5 3,4 9,3 3,8 9,0 4,2 8,7
10 2,2 10,8 2,5 10,6 2,7 10,5 3,0 10,1 3,1 10,0 3,4 9,8 3,8 9,6 4,2 9,3
15 2,2 12,5 2,5 12,3 2,7 12,1 3,0 11,8 3,1 11,7 3,4 11,4 3,8 11,1 4,2 10,4
20 2,2 14,1 2,4 13,8 2,7 13,5 3,0 13,2 3,1 12,9 3,5 12,6 3,8 12,2 4,2 11,8
25 2,2 13,9 2,4 13,6 2,7 13,4 3,0 13,1 3,1 12,9 3,4 12,6 3,8 12,2 4,1 11,9
30 2,1 13,7 2,4 13,5 2,7 13,2 3,0 13,0 3,1 12,8 3,4 12,5 3,8 12,3 4,1 12,0
35 2,1 13,5 2,4 13,3 2,6 13,1 2,9 12,9 3,1 12,7 3,4 12,5 3,8 12,3 4,0 12,1
40 2,1 13,3 2,4 13,1 2,6 13,0 2,9 12,8 3,1 12,7 3,4 12,5 3,7 12,3 4,0 12,1
45 2,1 13,1 2,4 13,0 2,6 12,9 2,9 12,7 3,1 12,6 3,4 12,5 3,7 12,4 3,9 12,2
35HT
-20 2,1 4,5 2,2 4,3 2,5 4,1 2,6 4,1
-15 2,1 5,2 2,2 5,0 2,5 4,8 2,7 4,7 2,9 4,6
-10 2,1 6,0 2,3 5,8 2,5 5,5 2,7 5,4 2,9 5,3 3,2 5,1
-7 2,1 6,5 2,3 6,3 2,6 6,0 2,7 5,8 3,0 5,6 3,3 5,5 3,6 5,2
-5 2,1 6,9 2,3 6,6 2,5 6,5 2,8 6,2 3,0 6,1 3,3 6,0 3,6 5,8
0 2,1 8,0 2,3 7,8 2,5 7,5 2,8 7,4 3,1 7,0 3,4 6,9 3,7 6,7 4,2 6,4
2 2,1 8,5 2,3 8,3 2,5 8,2 2,9 8,0 3,0 7,4 3,4 7,2 3,7 7,0 4,2 6,8
5 2,1 9,2 2,4 9,1 2,6 9,0 2,9 8,8 3,1 8,3 3,4 8,1 3,7 7,9 4,1 7,6
7 2,1 10,8 2,4 10,2 2,6 10,2 2,9 9,7 3,1 9,4 3,4 9,2 3,7 9,0 4,2 8,7
10 2,2 10,8 2,5 10,6 2,7 10,5 2,9 10,0 3,1 9,9 3,4 9,8 3,8 9,6 4,2 9,3
15 2,2 12,5 2,4 12,2 2,7 12,0 2,9 11,8 3,1 11,6 3,4 11,3 3,8 11,0 4,2 10,3
20 2,2 14,1 2,4 13,8 2,7 13,5 3,0 13,2 3,1 12,9 3,4 12,5 3,8 12,2 4,1 11,8
25 2,2 13,9 2,4 13,6 2,7 13,3 2,9 13,1 3,1 12,8 3,4 12,5 3,8 12,2 4,1 11,8
30 2,1 13,7 2,4 13,4 2,6 13,2 2,9 13,0 3,1 12,8 3,4 12,5 3,8 12,2 4,1 11,9
35 2,1 13,5 2,4 13,3 2,6 13,1 2,9 12,9 3,1 12,7 3,4 12,5 3,8 12,2 4,0 12,0
40 2,1 13,3 2,4 13,1 2,6 12,9 2,9 12,8 3,1 12,6 3,4 12,5 3,7 12,3 4,0 12,1
45 2,1 13,0 2,4 12,9 2,6 12,8 2,9 12,7 3,1 12,6 3,4 12,4 3,7 12,3 3,9 12,2
Pi = Power input Hc = Heating capacity Domestic hot water mode in the summer

HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
XENEA
6
Indoor packaged air-to-water heat pump
TECHNICAL DATA
SOUND LEVELS
Outdoor/indoor sound power levels certified by NFPAC dB(A) 62 / 55 67 / 56 67 / 58
Outdoor sound pressure (2) dB(A) 40 45
Indoor sound pressure (2) dB(A) 33 34 36
(1) Calculated for water at 40°C. If a higher capacity is needed, install an additional or a larger expansion vessel.
(2) 5 m from unit, 1.5 m from floor, free field, directivity 2.
ELECTRICAL POWER SUPPLY 230 V - 1-ph+N+Earth - 50 Hz 400V - 3ph -
50Hz + N + Earth
Compressor Maximum operating current A 12,47 13,5 16,5 6
Input power of heating element W 40
EC motor
turbine
Power W 100 150
Accelerator
pump
Power W 150 160
Auxiliary
heater
Power W 3 (1+1+1) 5 (3 x 1.67)
Maximum current A 13,0 21,7 7,4
Circuit breaker (not supplied) Am 16 25 10
PVC electric cables (not supplied) mm² 3 G 2.5 3 G6 5 G1.5
V2-K PVC power cables (not supplied) mm² 3 G1.5 3 G4 5 G1
Heater cable Power W 80
Maximum total current A14,1 15,4 18,4 7,9
Starting maximum current A< 45 < 45 < 45 20
PVC electric cables (not supplied) mm² 3 G2.5 3 G4 5 G1.5
V2-K PVC power cables (not supplied) mm² 3 G1.5 3 G2.5 5G1
C or D curve circuit breaker (not supplied) Am 16 20 10
ELECTRICAL CHARACTERISTICS
XENEA 20H 28H 35H 35HT
Compressor
Type hermetic scroll
Quantity 1
Oil capacity L 0,74 0,9
Refrigerant R410A - Charge kg 2,5 2,3 2,35
EC motor
turbine
Type and diameter EC motor turbine Ø500mm
Rotation speed rpm 520 600
Evaporator Type Coil made of grooved copper tubes with aluminium fins
Condenser Brazed plate - Water capacity L 0,96 1,44
Hydraulic
module
3-speed accelerator pump - available
pressure
kPa 51 37,5 49 49
Nominal flow rate m3/h 1 1,45 1,75 1,75
Expansion vessel L 8
Vessel precharge pressure bar 1,5
Maximum service pressure 4
Minimum pure water volume of system
L
45 57 70
Maximum pure water volume of system/40% MPG
(1)
235 / 133
Water connections ØMale 1” G
Weight Empty kg 172 186 189 190
In operation 175 189 192 193

XENEA
Indoor packaged air-to-water heat pump
7
HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
SCHEMATIC INSTALLATION DIAGRAM
Outdoor
sensor
Buffer tank
(optional)
Check valve +
pressure switch
Charging
(option)
Insulated
flexible connections
HomeConnect
control terminal
UHS
Note: an expansion vessel is required if the water content of the system exceeds the values indicated in the ‘‘Technical Data’’ table. The UHS limiter
thermostat kit is tted inside the machine (see installation and maintenance manual).
Insulated
flexible
connections
HomeConnect
control terminal
Buffer tank
(optional)
Check valve +
pressure switch
Outdoor
sensor
Outdoor
sensor
Buffer tank
(optional)
Check valve +
pressure switch
Insulated
flexible connections
HomeConnect
control terminal
UHS
DUO hydraulic
module (option) UHS safety
thermostat kit
(option)
Charging
(option)
Charging
(option)
- on underfloor heating system
- on comfort units (fan coil units or radiators)
- double zone (optional): underfloor heating system and comfort units
UHS safety
thermostat kit
(option)

HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
XENEA
8
Indoor packaged air-to-water heat pump
DIMENSIONS
Bear in mind the weight and dimensions given in this section when installing the unit.
XENEA 20H 28H 35H 35HT
Empty weight (kg) 172 186 189 190
Weight in operation (kg) 175 189 192 193
800 23
100
50 15
160
490
45
1530
600
740
760
712
120 1445
Position of heat pump wall mounting
points
Space
dimensions
665
+10
-0
1345
+10
-0
200
+15
-15
1345
330
660
275
1400
715
1212 275
12 12
Inside, place a
waterproof coating
BA13, for instance
placomarine

XENEA
Indoor packaged air-to-water heat pump
9
HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
INSTALLATION RECOMMENDATIONS
Pre-installation recommendations
Leave a space for air return and extraction in an outside wall. If possible, install in a mechanical room, laundry room or garage, protected from the
elements and frost, and where the ambient temperature does not exceed -9°C/+ 35°C. If possible, avoid installing the unit near a bedroom. To reduce
the condensation produced by the unit, it is preferable to install the XENEA in an unheated room. The XENEA must never be installed in a very humid
environment (air humidity level above 50%).
 The surface area of the ground or structure must be strong enough to bear the unit's weight.
 The surface of the wall against which the rear of the unit will be placed must be completely smooth to ensure a
perfect seal. If necessary, a smooth coating must be applied or a plywood frame fitted to guarantee a smooth surface.
 Ensure that the machine's condensate water can be drained from the area, in particular by using the supplied
drainage fitting (see opposite).
 Install the necessary electrical supplies and protection in compliance with NF C 15-100.
Location
The XENEA must be affixed to the wall in which a space has been created to allow for the return and extraction of
external air. The XENEA must be perfectly level. The unit has integrated adjustable feet equipped with anti-vibration
mounts.
Space to be left around the heat pump
The front and lateral parts of the unit must be accessible to allow for easy maintenance and servicing operations.
Outdoor air discharge
Outdoor air intake
Leave a clear space
with a radius of 5 m in
front of the grille.
Accessibility zone
0.8m
1 m
0.8m

HEAT PUMPS - AIR CONDITIONING - REFRIGERATION - AIR HANDLING - HEAT EXCHANGE - NA 12.692 A
XENEA
10
Indoor packaged air-to-water heat pump
Electrical connections
 All the information needed to wire the system is provided on the wiring diagram supplied with the unit. The diagram should be followed to the letter.
 Wiring must be carried out in accordance with accepted engineering practice and conform to the regulations in force.
 A cut-off switch or circuit breaker must be installed on the power supply line output by the installer.
Hydraulic connections
 Hydraulic connections are to be made in accordance with good engineering practice.
 The exchangers on a heat pump are susceptible to clogging; the water circuits must therefore be thoroughly flushed before any connections are made.
 Make sure you have the necessary number of essential accessories for installation:
Air vents at pipe high points
System water content sufficient (see heat pump technical data table) and expansion vessel suitable
Additional buffer capacity if necessary
Commissioning
Follow the instructions in the installation and maintenance manual.
Maintenance
Follow the instructions in the installation and maintenance manual.
CIAT recommends taking out an annual maintenance contract with a competent professional body.
This document is not legally binding. As part of its policy for continual product improvement, CIAT reserves the right to make any technical modification it considers necessary without prior notice.
CIAT Residential
ZA de Chautagne
73310 Serrières en Chautagne
Tel.: [phone]
Fax: [phone]
[e-mail] - www.ciat.com
CIAT Service Residential
Tel.: [phone] (0.15 €/min)
Fax: [phone] (0.15 €/min)
RESIDENTIAL
Compagnie Industrielle d’Applications Thermiques - S.A. with a registered capital of 26,728,480 €- R.C.S. Bourg-en-Bresse B 545 620 114
