Cincoze CS-112HC/P2102 User manual

CS-100/P2102 Series
User Manual
Industrial Panel PC
High Performance Sunlight Readable Panel PC
Version: V1.12
Sunlight Readable Panel PC

CS-100-P2102 Series | User Manual 2
Contents
Preface..................................................................................................................................................................5
Revision ............................................................................................................................................................5
Copyright Notice...............................................................................................................................................5
Acknowledgement............................................................................................................................................5
Disclaimer.........................................................................................................................................................5
Declaration of Conformity................................................................................................................................6
Product Warranty Statement ...........................................................................................................................6
Technical Support and Assistance ....................................................................................................................7
Conventions Used in this Manual.....................................................................................................................8
Safety Precautions............................................................................................................................................8
Package Contents .......................................................................................................................................... 10
Ordering Information .................................................................................................................................... 10
Chapter 1 Product Introductions....................................................................................................................... 12
1.1 Overview.................................................................................................................................................. 13
1.2 Highlights................................................................................................................................................. 13
1.3 Key Features ............................................................................................................................................ 14
1.4 Hardware Specification ........................................................................................................................... 15
1.4.1 CS-112HC/P2102 Series.................................................................................................................... 15
1.4.2 CS-115C/P2102 Series ...................................................................................................................... 20
1.4.3 CS-117C/P2102 Series ...................................................................................................................... 25
1.4.4 CS-119C/P2102 Series ...................................................................................................................... 30
1.4.5 CS-W121C/P2102 Series................................................................................................................... 35
1.4.6 CS-W124C/P2102 Series................................................................................................................... 40
1.5 System I/O ............................................................................................................................................... 45
1.5.1 Front ................................................................................................................................................. 45
1.5.2 Rear................................................................................................................................................... 46
1.5.3 Left.................................................................................................................................................... 46

CS-100-P2102 Series | User Manual 3
1.5.4 Right.................................................................................................................................................. 47
1.5.5 Top.................................................................................................................................................... 47
Chapter 2 Switches & Connectors..................................................................................................................... 48
2.1 Location of Switches and Connectors ..................................................................................................... 49
2.1.1 Top View........................................................................................................................................... 49
2.1.2 Bottom View..................................................................................................................................... 49
2.2 Switches and Connectors Definition........................................................................................................ 50
2.3 Definition of Switches.............................................................................................................................. 51
2.4 Definition of Connectors ......................................................................................................................... 53
Chapter 3 System Setup .................................................................................................................................... 58
3.1 Removing Top Cover................................................................................................................................ 59
3.2 Installing Half Size Mini PCIe Card........................................................................................................... 60
3.3 Installing Full Size Mini PCIe Card............................................................................................................ 61
3.4 Installing M.2 E Key Card......................................................................................................................... 62
3.5 Installing Antenna(s)................................................................................................................................ 63
3.6 Installing SO-DIMM Memory................................................................................................................... 65
3.7 Installing PCI(e) Card ............................................................................................................................... 66
3.8 Installing Thermal Pad of Thermal Block................................................................................................. 70
3.9 Installing Top Cover................................................................................................................................. 70
3.10 Installing SATA Hard Drive at Front Panel ............................................................................................. 71
3.11 Installing SATA hard drive on Bottom Side............................................................................................ 74
3.12 Installing SIM Card................................................................................................................................. 77
3.13 Connecting with CS Display Module...................................................................................................... 78
3.14 Installing Panel Mount........................................................................................................................... 81
Chapter 4 BIOS Setup ........................................................................................................................................ 84
4.1 BIOS Introduction .................................................................................................................................... 85
4.2 Main Setup .............................................................................................................................................. 85
4.3 Advanced Setup....................................................................................................................................... 87
4.3.1 CPU Configuration ............................................................................................................................ 87

CS-100-P2102 Series | User Manual 4
4.3.2 PCH-FW Configuration...................................................................................................................... 88
4.3.3 Trusted Computing........................................................................................................................... 88
4.3.4 ACPI Settings..................................................................................................................................... 89
4.3.5 F81866 Super IO Configuration ........................................................................................................ 90
4.3.6 Hardware Monitor............................................................................................................................ 91
4.3.7 S5 RTC Wake Settings....................................................................................................................... 91
4.3.8 Serial Port Console Redirection........................................................................................................ 92
4.3.9 USB Configuration ............................................................................................................................ 92
4.3.10 CSM Configuration.......................................................................................................................... 93
4.3.11 NVMe Configuration....................................................................................................................... 94
4.3.12 Network Stack Configuration ......................................................................................................... 94
4.4 Chipset Setup........................................................................................................................................... 95
4.4.1 System Agent (SA) Configuration ..................................................................................................... 95
4.4.2 PCH-IO Configuration ....................................................................................................................... 96
4.5 Security Setup........................................................................................................................................ 100
4.6 Boot Setup............................................................................................................................................. 101
4.7 Save & Exit............................................................................................................................................. 102
Chapter 5 Product Application ........................................................................................................................ 103
5.1 Digital I/O (DIO) application .................................................................................................................. 104
5.1.1 Digital I/O Programming Guide ...................................................................................................... 104
5.2 P2102 Digital I/O (DIO) Hardware Specification.................................................................................... 111
5.2.1 P2102 DIO Connector Definition .................................................................................................... 112
Chapter 6 Optional Modules & Accessories.................................................................................................... 114
6.1 Pin Definition and Settings of IGN Module............................................................................................ 115
6.2 Installing CFM-IGN Module ................................................................................................................... 116
6.3 Installing CFM-PoE Module ................................................................................................................... 117
6.4 Installing VESA Mount ........................................................................................................................... 119
6.5 Installing Rack Mount............................................................................................................................ 120

CS-100-P2102 Series | User Manual 5
Preface
Revision
Revision
Description
Date
1.00
First Release
2020/01/13
1.01
Correction Made
2020/04/09
1.02
Correction Made
2020/10/05
1.03
Correction Made
2020/11/02
1.04
Correction Made
2020/11/13
1.05
Add DC_IN1 Warning
2021/04/20
1.06
Correction Made
2021/06/28
1.07
Add CS-W115FHC Display Module
2021/11/25
1.08
Add CS-W121C Display Module
2021/12/28
1.09
Add CS-W124C Display Module
2022/02/25
1.10
Separate Display module & PC module
Remove CS-W115FHC Display Module
2022/10/21
1.11
Correction Made
2023/04/14
1.12
Correction Made
2024/02/07
Copyright Notice
© 2020 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified,
or reproduced in any form or by any means for commercial use without the prior written permission
of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only
and remain subject to change without prior notice.
Acknowledgement
Cincoze is a registered trademark of Cincoze Co., Ltd. All registered trademarks and product names
mentioned herein are used for identification purposes only and may be trademarks and/or
registered trademarks of their respective owners.
Disclaimer
This manual is intended to be used as a practical and informative guide only and is subject to
change without notice. It does not represent a commitment on the part of Cincoze. This product
might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of
the publication.

CS-100-P2102 Series | User Manual 6
Declaration of Conformity
FCC
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
CE
The product(s) described in this manual complies with all application European Union
(CE) directives if it has a CE marking. For computer systems to remain CE compliant,
only CE-compliant parts may be used. Maintaining CE compliance also requires
proper cable and cabling techniques.
Product Warranty Statement
Warranty
Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and
workmanship for 2 years from the date of purchase by the original purchaser. During the warranty
period, we shall, at our option, either repair or replace any product that proves to be defective
under normal operation. Defects, malfunctions, or failures of the warranted product caused by
damage resulting from natural disasters (such as by lightening, flood, earthquake, etc.),
environmental and atmospheric disturbances, other external forces such as power line disturbances,
plugging the board in under power, or incorrect cabling, and damage caused by misuse, abuse, and
unauthorized alteration or repair, and the product in question is either software, or an expendable
item (such as a fuse, battery, etc.), are not warranted.
RMA
Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA
number from us. Our staff is available at any time to provide you with the most friendly and
immediate service.
◼RMA Instruction
⚫Customers must fill in Cincoze Return Merchandise Authorization (RMA) Request
Form and obtain an RMA number prior to returning a defective product to Cincoze

CS-100-P2102 Series | User Manual 7
for service.
⚫Customers must collect all the information about the problems encountered and
note anything abnormal and describe the problems on the “Cincoze Service Form”
for the RMA number apply process.
⚫Charges may be incurred for certain repairs. Cincoze will charge for repairs to
products whose warranty period has expired. Cincoze will also charge for repairs to
products if the damage resulted from acts of God, environmental or atmospheric
disturbances, or other external forces through misuse, abuse, or unauthorized
alteration or repair. If charges will be incurred for a repair, Cincoze lists all charges,
and will wait for customer’s approval before performing the repair.
⚫Customers agree to ensure the product or assume the risk of loss or damage during
transit, to prepay shipping charges, and to use the original shipping container or
equivalent.
⚫Customers can be sent back the faulty products with or without accessories (manuals,
cable, etc.) and any components from the system. If the components were suspected
as part of the problems, please note clearly which components are included.
Otherwise, Cincoze is not responsible for the devices/parts.
⚫Repaired items will be shipped along with a "Repair Report" detailing the findings
and actions taken.
Limitation of Liability
Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use,
whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed
the original selling price of the product. The remedies provided herein are the customer’s sole and
exclusive remedies. In no event shall Cincoze be liable for direct, indirect, special or consequential
damages whether based on contract of any other legal theory.
Technical Support and Assistance
1. Visit the Cincoze website at www.cincoze.com where you can find the latest information about
the product.
2. Contact your distributor or our technical support team or sales representative for technical
support if you need additional assistance. Please have following information ready before you
call:
⚫Product name and serial number
⚫Description of your peripheral attachments
⚫Description of your software (operating system, version, application software, etc.)
⚫A complete description of the problem
⚫The exact wording of any error messages

CS-100-P2102 Series | User Manual 8
Conventions Used in this Manual
Safety Precautions
Before installing and using this device, please note the following precautions.
1. Read these safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Disconnected this equipment from any AC outlet before cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must
be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
8. Use a power cord that has been approved for using with the product and that it matches the
voltage and current marked on the product’s electrical range label. The voltage and current
rating of the cord must be greater than the voltage and current rating marked on the product.
9. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
This indication alerts operators to an operation that, if not strictly observed, may result in
severe injury.
(Cette indication avertit les opérateurs d'une opération qui, si elle n'est pas strictement
observée, peut entraîner des blessures graves.)
WARNING
(AVERTIR)
This indication alerts operators to an operation that, if not strictly observed, may result in
safety hazards to personnel or damage to equipment.
(Cette indication avertit les opérateurs d'une opération qui, si elle n'est pas strictement
observée, peut entraîner des risques pour la sécurité du personnel ou des dommages à
l'équipement.)
CAUTION
(ATTENTION)
This indication provides additional information to complete a task easily.
(Cette indication fournit des informations supplémentaires pour effectuer facilement
une tâche.)
NOTE
(NOTE)

CS-100-P2102 Series | User Manual 9
13. Never open the equipment. For safety reasons, the equipment should be opened only by
qualified service personnel.
If one of the following situations arises, get the equipment checked by service personnel:
⚫The power cord or plug is damaged.
⚫Liquid has penetrated into the equipment.
⚫The equipment has been exposed to moisture.
⚫The equipment does not work well, or you cannot get it work according to the user's
manual.
⚫The equipment has been dropped and damaged.
⚫The equipment has obvious signs of breakage.
14. CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of
Used Batteries According to the Instructions.
ATTENTION: Risque d'explosion si la batterie est remplacée par un type incorrect. Mettre au
rebus les batteries usagées selon les instructions.
15. Equipment intended only for use in a RESTRICTED ACCESS AREA.
16. Ensure to connect the power cord of power adapter to a socket-outlet with earthing
connection.
17. Dispose of used battery promptly. Keep away from children. Do not disassemble and do not
dispose of in fire.

CS-100-P2102 Series | User Manual 10
Package Contents
Before installation, please ensure all the items listed in the following table are included in the
package.
Item
Description
Q’ty
1
Panel PC
1
2
Thermal Pad (for CPU Thermal Block)
1
3
Power Terminal Block Connector
1
4
Remote Power On/Off Terminal Block Connector
1
5
DIO Terminal Block Connector
2
6
Screws Pack
5
7
PCI / PCIe Card Installation Kit (For CS-100/P2102E Only)
1
8
Panel Mounting Kit (The quantity varies with the size of the display
module, please refer to the datasheet for the actual quantity)
1
Note: Notify your sales representative if any of the above items are missing or damaged.
Ordering Information
Model No.
Product Description
CS-112HC/P2102-i5
12.1" 1500 nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i5-8365UE
Quad Core Processor and P-Cap. Touch
CS-112HC/P2102E-i5
12.1" 1500nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i5-8365UE Quad Core Processor and P-Cap. Touch
CS-112HC/P2102-i3
12.1" 1500nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i3-8145UE
Quad Core Processor and P-Cap. Touch
CS-112HC/P2102E-i3
12.1" 1500nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i3-8145UE Quad Core Processor and P-Cap. Touch
CS-115C/P2102-i5
15" 1600nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i5-8365UE
Quad Core Processor and P-Cap. Touch
CS-115C/P2102E-i5
15" 1600nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i5-8365UE Quad Core Processor and P-Cap. Touch
CS-115C/P2102-i3
15" 1600nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i3-8145UE
Quad Core Processor and P-Cap. Touch
CS-115C/P2102E-i3
15" 1600nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i3-8145UE Quad Core Processor and P-Cap. Touch
CS-117C/P2102-i5
17" 1500nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i5-8365UE
Quad Core Processor and P-Cap. Touch
CS-117C/P2102E-i5
17" 1500nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i5-8365UE Quad Core Processor and P-Cap. Touch

CS-100-P2102 Series | User Manual 11
CS-117C/P2102-i3
17" 1500nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i3-8145UE
Quad Core Processor and P-Cap. Touch
CS-117C/P2102E-i3
17" 1500nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i3-8145UE Quad Core Processor and P-Cap. Touch
CS-119C/P2102-i5
19" 1600nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i5-8365UE
Quad Core Processor and P-Cap. Touch
CS-119C/P2102E-i5
19" 1600nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i5-8365UE Quad Core Processor and P-Cap. Touch
CS-119C/P2102-i3
19" 1600nits TFT-LCD Sunlight Readable and Modular Panel PC with 8th Gen. Intel Core i3-8145UE
Quad Core Processor and P-Cap. Touch
CS-119C/P2102E-i3
19" 1600nits TFT-LCD Sunlight Readable, Modular and Expandable Panel PC with 8th Gen. Intel Core
i3-8145UE Quad Core Processor and P-Cap. Touch
CS-W121C/P2102-i5
21.5" Full HD TFT-LCD Modular Panel PC with 8th Gen. Intel Core i5-8365UE Quad Core Processor and
P-Cap. Touch
CS-W121C/P2102E-i5
21.5" Full HD TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel Core i5-8365UE Quad Core
Processor and P-Cap. Touch
CS-W121C/P2102-i3
21.5" Full HD TFT-LCD Modular Panel PC with 8th Gen. Intel Core i3-8145UE Dual Core Processor and
P-Cap. Touch
CS-W121C/P2102E-i3
21.5" Full HD TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel Core i3-8145UE Dual Core
Processor and P-Cap. Touch
CS-W124C/P2102-i5
24" Full HD TFT-LCD Modular Panel PC with 8th Gen. Intel Core i5-8365UE Quad Core Processor and
P-Cap. Touch
CS-W124C/P2102E-i5
24" Full HD TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel Core i5-8365UE Quad Core
Processor and P-Cap. Touch
CS-W124C/P2102-i3
24" Full HD TFT-LCD Modular Panel PC with 8th Gen. Intel Core i3-8145UE Dual Core Processor and
P-Cap. Touch
CS-W124C/P2102E-i3
24" Full HD TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel Core i3-8145UE Dual Core
Processor and P-Cap. Touch

CS-100-P2102 Series | User Manual 12
Chapter 1
Product Introductions

CS-100-P2102 Series | User Manual 13
1.1 Overview
The CS-100/P2102 series is a TFT-LCD sunlight readable panel PC that offers sufficient screen
brightness for better image quality in outdoor usage. The panel PC is powered by Intel® 8th
generation Core™ U series processor that brings outstanding computing performance boost up to
84% at a TDP of 15 watts, compared to 6th generation Intel® Core™ U series. To enable faster
responsiveness and deal with multi tasks with ease, the CS-100/P2102 series is equipped with two
DDR4 2400 SODIMM sockets for up to 64 GB memory.
With its slim design, the CS-100/P2102 series offers extensive I/O to fulfill different connectivities
and can easily fit into almost any space limited environment. For wireless connectivity, the
CS-100/P2102 series has 1x M.2 2230 E key and 2x full-size Mini-PCIe expansions which can be
installed various add-on cards to enable Wi-Fi, 3G, and LTE communication. For expansion
requirements, the CS-100/P2102E series has 1x PCI/PCIe x4, 1x M.2 2230 E key and 2x full-size
Mini-PCIe expansions which can be installed various add-on cards to increase desired functions.
Besides, the CS-100/P2102 series supports Control Function Module (CFM) Technology to install
optional CFM modules for increasing power over ethernet and power ignition sensing functions
according to user’s specific applications. Featuring rigorous industrial protections, wide range
operating temperature (-20°C to 70°C), IP65 dust/waterproof front panel, and wide range DC power
input (9 to 48VDC), the CS-100/P2102 series is appropriate for tough outdoor applications under
direct sunlight.
Furthermore, the CS-100/P2102 series supports Cincoze patented Convertible Display System (CDS)
technology, allowing users to replace display module or computer module on-site easily and thereby
reducing maintenance costs and downtime.
1.2 Highlights
High Performance Per Watt
Powered by 8th generation Intel® Core ™U series processor (up to 4 cores, 4.10 GHz) at a TDP of only 15W,
the CS-100/P2102 series can fulfill a variety of applications that require high-performance computing and
low power budget simultaneously.
Sunlight Readable
Featuring ultra-high brightness, and high resolution, the CS-100/P2102 series provides excellent viewing
experience under all lighting conditions including direct sunlight.
Built for Extreme Temperature
Built with wide operating temperature ranges and a special selection of industrial-grade components, the
CS-100/P2102 series is suitable for deploying under extreme environments and severe climate.

CS-100-P2102 Series | User Manual 14
1.3 Key Features
⚫12.1”~24” TFT-LCD with Ultra-high Brightness and high resolution
⚫Onboard 8th Generation Intel® Core™ U Series Processor
⚫2x DDR4 SO-DIMM Socket, Supports Up to 2400MHz, 64GB
⚫Supports Triple Independent Display
⚫Integrated USB 3.2 Gen 2 supports up to 10Gbps
⚫M.2 E Key Socket for Wireless Module or Intel CRF Module
⚫Supports Ignition Sensing Function (IGN) (with optional CFM module)
⚫Supports 2x PoE+ Function (with optional CFM module)
⚫1x PCI or 1x PCIe Slot for Add-on Card Expansion: Max. Length 180mm
including Bracket (with optional riser card) (For CS-100/P2102E series only)
⚫Wide Range Operating Temperature -20°C to 70°C
⚫Designed with Rugged Aluminum Die-casting Front Bezel
⚫True Flat IP65 Compliant Front Panel Protection
⚫Supports Panel / VESA / Rack Mounting

CS-100-P2102 Series | User Manual 15
1.4 Hardware Specification
1.4.1 CS-112HC/P2102 Series
Model Name
CS-112HC
Display
LCD Size
•12.1" (4:3)
Max. Resolution
•1024 x 768
Brightness (cd/m2)
•1500
Contract Ratio
•700 : 1
LCD Color
•16.7M
Pixel Pitch
•0.24 (H) x 0.24 (V)
Viewing Angle
•160 / 160
Backlight MTBF
•30,000 hrs (LED Backlight)
Touchscreen
Touch Type
•Projected Capacitive
Physical
Dimension (WxDxH)
•345 x 265.3 x 57 mm
Weight
•3.16 kg
Construction
•Flat Rugged Aluminum Die-casting Bezel
Environment
Front Panel Protection
•IP 65 Compliant
Operating Temperature
•Ambient with Air flow: -20°C to 70°C (extended temperature peripherals)
Storage Temperature
•-20°C to 70°C
Relative Humidity
•80% RH @ 40°C (non-condensing)
Safety
•UL, cUL, CB, IEC, EN 62368-1
Model Name
P2102
P2102E
System
Processor
•Onboard 8th Intel® Core™U Processors (Whiskey Lake)
- Intel® Core™i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz)
- Intel® Core™i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz)
- TDP: 15 W
Memory
•2x DDR4 2400 MHz 260-Pin SO-DIMM Socket
•Support Un-buffered and Non-ECC Type up to 64 GB
Graphics
Graphics Engine
•Integrated Intel® UHD Graphics 620

CS-100-P2102 Series | User Manual 16
Maximum Display Output
•Supports Triple Independent Display (1x CDS, 1x VGA, 1x DisplayPort)
VGA
•1x VGA Connector (1920 x 1200 @60Hz)
DP
•1x DisplayPort Connector (4096 x 2304 @ 60Hz)
Audio
Audio Codec
•Realtek® ALC888, High Definition Audio
Speaker-out
•1x Speaker-out, Phone Jack 3.5mm
Mic-in
•1x Mic-in, Phone Jack 3.5mm
I/O
LAN
•2x GbE LAN (Supports WoL, Teaming, Jumbo Frame & PXE), RJ45
- GbE1: Intel® I219LM
- GbE2: Intel® I210
USB
•3x USB 3.2 Gen2 (Type A), 2x USB 2.0 (Type A)
Serial Port
•4x RS-232/422/485 with Auto Flow Control Support 5V/12V, DB9
DIO
•16x Isolated Digital I/O (8in/8out), 20-Pin Terminal Block
Power Mode Switch
•1x AT/ATX Mode Switch
Power Switch
•1x ATX Power On/Off Switch
Reset Button
•1x Reset Button
Clear CMOS Switch
•1x Clear CMOS Switch
Remote Power On/Off
•1x Remote Power On/Off Connector, 2-pin Terminal Block
Power Ignition Sensing
•1x Ignition DIP Switch (12V/24V, need to work with CFM module)
Storage
SSD/HDD
•2x 2.5” HDD/SSD Drive Bay (SATA 3.0), Supports RAID 0/1
Expansion
Mini PCI Express
•2x Full-size Mini-PCIe Sockets
PCI Express
•1x PCI or 1x PCIe x4 Expansion slot with
Optional Riser Card
* Support maximum dimension of
add-on card (H x L): 111mm x 169mm
M.2 E Key Socket
•1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module
SIM Socket
•1 x Front Accessible SIM Socket
Universal Bracket
•2x Universal I/O Bracket
CFM (Control Function Module)
Interface
•2x Control Function Module (CFM) Interface
CDS (Convertible Display
System) Technology
•1x Convertible Display System (CDS) Interface
Antenna Holes
•4x Antenna Holes
Other Function
Clear CMOS Switch
•1 x Clear CMOS Switch

CS-100-P2102 Series | User Manual 17
Instant Reboot
•Support 0.2sec
Watchdog Timer
•Software Programmable Supports 256 Levels System Reset
Internal Speaker
•AMP 2W + 2W
OSD Function
•LCD On/Off, Brightness Up, Brightness Down
Power
AT/ATX Power
•Support AT, ATX Mode
Power Input
•1x 3-pin Terminal Block Connector with Power Input 9-48VDC
Power Adapter (Optional)
•1x Optional AC/DC 12V/5A, 60W or 24V/5A 120W
Physical
Dimension
( W x D x H )
•254.5 x 190 x 41.5mm
•254.5 x 190 x 61 mm
Weight Information
•2.2 kg
•2.7 kg
Mechanical Construction
•Extruded Aluminum with Heavy Duty Metal
Mounting
•Wall / VESA / CDS / DIN Rail
Physical Design
•Fanless Design
•Jumper-less Design
Reliability & Protection
Reverse Power Input
•Yes
Over Voltage Protection
•Protection Range: 51-58V
•Protection Type: shut down operating voltage,
•re-power on at the present level to recover
Over Current Protection
•15A
CMOS Battery Backup
•SuperCap Integrated for CMOS Battery Maintenance-free Operation
MTBF
•231,243 hours
Operating System
Microsoft® Windows®
•Windows®10
Linux
•Supports by project
Environment
Operating Temperature
•Ambient with Air Flow: -40°C to 70°C (with Extended Temperature Peripherals)
Storage Temperature
•-40°C to 70°C
Relative humidity
•95% RH @ 70°C (Non-condensing)
Shock
•Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27)
Vibration
•Operating, 5 Grms, 5-500 Hz, 3 Axes (w/ SSD,
according to IEC60068-2-64)
•Operating, 5 Grms, 5-500 Hz, 3 Axes (w/
SSD, according to IEC60068-2-64)
•Operating, 1 Grms, 10-500 Hz, 3 Axes (w/
CV-W124 only, according to
IEC60068-2-6)

CS-100-P2102 Series | User Manual 18
Safety
•UL, cUL, CB, IEC/EN62368-1
Fire Protection
•EN45545-2
* Product Specifications and features are for reference only and are subject to change without prior
notice. For more information, please refer to the latest product datasheet from Cincoze's website.

CS-100-P2102 Series | User Manual 19
Dimension
CS-112HC/P2102 Unit: mm
CS-112HC/P2102E Unit: mm

CS-100-P2102 Series | User Manual 20
1.4.2 CS-115C/P2102 Series
Model Name
CS-115C
Display
LCD Size
•15" (4:3)
Max. Resolution
•1024 x 768
Brightness (cd/m2)
•1800
Contract Ratio
•800 : 1
LCD Color
•16.2M
Pixel Pitch
•0.297 (H) x 0.297(V)
Viewing Angle
•160 / 150
Backlight MTBF
•50,000 hrs (LED Backlight)
Touchscreen
Touchscreen Type
•Projected Capacitive Touch
Physical
Dimension (WxDxH)
•408 x 312.4 x 59.2 mm
Weight
•4.36kg
Construction
•Flat Rugged Aluminum Die-casting Bezel
Environment
Front Panel Protection
•IP 65 Compliant
Operating Temperature
•Ambient with Air flow: -20°C to 70°C (extended temperature peripherals)
Storage Temperature
•-20°C to 70°C
Relative Humidity
•80% RH @ 40°C (non-condensing)
Safety
•UL, cUL, CB, IEC, EN 62368-1
