Cincoze CS-112HC/P2002 Series User manual

Sunlight Readable Panel PC
Version: V1.41
CS-100/P2002 Series
User Manual
Industrial Panel PC
High Performance Sunlight Readable Panel PC

CS-100/P2002 Series | User Manual 2
Contents
Preface ...................................................................................................................................................5
Revision..........................................................................................................................................5
Copyright Notice ............................................................................................................................5
Acknowledgement .........................................................................................................................5
Disclaimer.......................................................................................................................................5
Declaration of Conformity..............................................................................................................6
Product Warranty Statement.........................................................................................................6
Technical Support and Assistance..................................................................................................7
Conventions Used in this Manual ..................................................................................................8
Safety Precautions..........................................................................................................................8
Package Contents.........................................................................................................................10
Ordering Information...................................................................................................................10
Chapter 1 Product Introductions .........................................................................................................14
1.1 Overview ................................................................................................................................15
1.2 Highlights................................................................................................................................15
1.3 Product Pictures.....................................................................................................................16
1.4 Key Features...........................................................................................................................16
1.5 Hardware Specification ..........................................................................................................17
1.5.1 CS-112HC/P2002 Series ..............................................................................................17
1.5.2 CS-115C/P2002 Series.................................................................................................22
1.5.3 CS-117C/P2002 Series.................................................................................................27
1.5.4 CS-119C/P2002 Series.................................................................................................32
1.5.5 CS-W121C/P2002 Series .............................................................................................37
1.5.6 CS-W124C/P2002 Series .............................................................................................42
1.6 System I/O..............................................................................................................................47
1.6.1 Front............................................................................................................................47
1.6.2 Rear.............................................................................................................................48
1.6.3 Left ..............................................................................................................................48
1.6.4 Right ............................................................................................................................49
Chapter 2 Switches & Connectors........................................................................................................50
2.1 Location of the Switches/Connectors ....................................................................................51
2.1.1 Top View......................................................................................................................51
2.1.2 Bottom View ...............................................................................................................52
2.2 Definition of Switches/Connectors ........................................................................................53
2.3 Definition of Switches ............................................................................................................54
2.4 Definition of Connectors........................................................................................................57
Chapter 3 System Setup.......................................................................................................................63

CS-100/P2002 Series | User Manual 3
3.1 Removing Top Cover...............................................................................................................64
3.2 Installing Half Size Mini PCIe Card..........................................................................................65
3.3 Installing Full Size Mini PCIe Card ..........................................................................................67
3.4 Installing mSATA Card.............................................................................................................68
3.5 Installing Antenna(s) ..............................................................................................................69
3.6 Installing SO-DIMM Memory .................................................................................................71
3.7 Installing PCI(e) Card..............................................................................................................72
3.8 Installing Thermal Pad of Thermal Block................................................................................74
3.9 Installing CFM-IGN Module (Optional) ..................................................................................75
3.10 Installing CFM-PoE Module (Optional).................................................................................76
3.11 Installing Top Cover..............................................................................................................77
3.12 Installing SATA Hard Drive at Front Panel.............................................................................78
3.13 Installing SATA Hard Drive on Bottom Side ..........................................................................80
3.14 Installing SIM Card ...............................................................................................................83
3.15 Installing CFast Card .............................................................................................................84
3.16 Connecting with CS Display Module....................................................................................85
3.17 Installing VESA Mount..........................................................................................................88
3.18 Installing Panel Mount .........................................................................................................89
3.19 Installing Rack Mount...........................................................................................................93
Chapter 4 BIOS Setup...........................................................................................................................95
4.1 BIOS Introduction...................................................................................................................96
4.2 Main Setup.............................................................................................................................97
4.3 Advanced Setup .....................................................................................................................98
4.3.1 ACPI Settings ...............................................................................................................98
4.3.2 AMT Configuration......................................................................................................99
4.3.3 PCH-FW Configuration ................................................................................................99
4.3.4 F81866 Super IO Configuration.................................................................................100
4.3.5 Hardware Monitor ....................................................................................................101
4.3.6 S5 RTC Wake Settings................................................................................................102
4.3.7 Serial Port Console Redirection.................................................................................102
4.3.8 CPU Configuration.....................................................................................................103
4.3.9 SATA Configuration....................................................................................................104
4.3.10 CSM Configuration ..................................................................................................105
4.3.11 Asmedia SATA Controller Configuration..................................................................107
4.3.12 USB Configuration...................................................................................................108
4.4 Chipset Setup .......................................................................................................................109
4.4.1 System Agent (SA) Configuration..............................................................................109
4.4.2 PCH-IO Configuration................................................................................................110
4.5 Security Setup ......................................................................................................................112

CS-100/P2002 Series | User Manual 4
4.6 Boot Setup............................................................................................................................113
4.7 Save & Exit............................................................................................................................114
Chapter 5 Product Application...........................................................................................................115
5.1 Digital I/O (DIO) application.................................................................................................116
5.1.1 Digital I/O Programming Guide.................................................................................116
5.2 Digital I/O (DIO) Hardware Specification .............................................................................124

CS-100/P2002 Series | User Manual 5
Preface
Revision
Revision
Description
Date
1.00
New Release
2018/03/06
1.10
Added New CS-100/P2002 Series Products Information
2018/09/07
1.20
Correction Made
2018/11/20
1.30
LAN Chip Information Updated
2019/05/17
1.31
Correction Made
2020/04/09
1.32
New Format Updated
2020/10/22
1.33
Correction Made
2020/11/13
1.34
Add DC_IN1 Warning
2021/04/20
1.35
Correction Made
2021/06/28
1.36
Add CS-W115FHC Display Module
2021/11/25
1.37
Add CS-W121C Display Module
2021/12/28
1.38
Add CS-W124C Display Module
2022/02/25
1.39
Separate Display module & PC module
Remove CS-W115FHC Display Module
2022/10/21
1.40
Correction Made
2023/04/14
1.41
Correction Made
2024/02/07
Copyright Notice
© 2018 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified,
or reproduced in any form or by any means for commercial use without the prior written permission
of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only
and remain subject to change without prior notice.
Acknowledgement
Cincoze is a registered trademark of Cincoze Co., Ltd. All registered trademarks and product names
mentioned herein are used for identification purposes only and may be trademarks and/or
registered trademarks of their respective owners.
Disclaimer
This manual is intended to be used as a practical and informative guide only and is subject to
change without notice. It does not represent a commitment on the part of Cincoze. This product
might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of

CS-100/P2002 Series | User Manual 6
the publication.
Declaration of Conformity
FCC
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
CE
The product(s) described in this manual complies with all application European Union
(CE) directives if it has a CE marking. For computer systems to remain CE compliant,
only CE-compliant parts may be used. Maintaining CE compliance also requires
proper cable and cabling techniques.
Product Warranty Statement
Warranty
Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and
workmanship for 2 years from the date of purchase by the original purchaser. During the warranty
period, we shall, at our option, either repair or replace any product that proves to be defective
under normal operation. Defects, malfunctions, or failures of the warranted product caused by
damage resulting from natural disasters (such as by lightening, flood, earthquake, etc.),
environmental and atmospheric disturbances, other external forces such as power line disturbances,
plugging the board in under power, or incorrect cabling, and damage caused by misuse, abuse, and
unauthorized alteration or repair, and the product in question is either software, or an expendable
item (such as a fuse, battery, etc.), are not warranted.
RMA
Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain a RMA
number from us. Our staff is available at any time to provide you with the most friendly and
immediate service.
◼RMA Instruction
⚫Customers must fill in Cincoze Return Merchandise Authorization (RMA) Request

CS-100/P2002 Series | User Manual 7
Form and obtain an RMA number prior to returning a defective product to Cincoze
for service.
⚫Customers must collect all the information about the problems encountered and
note anything abnormal and describe the problems on the “Cincoze Service Form”
for the RMA number apply process.
⚫Charges may be incurred for certain repairs. Cincoze will charge for repairs to
products whose warranty period has expired. Cincoze will also charge for repairs to
products if the damage resulted from acts of God, environmental or atmospheric
disturbances, or other external forces through misuse, abuse, or unauthorized
alteration or repair. If charges will be incurred for a repair, Cincoze lists all charges,
and will wait for customer’s approval before performing the repair.
⚫Customers agree to ensure the product or assume the risk of loss or damage during
transit, to prepay shipping charges, and to use the original shipping container or
equivalent.
⚫Customers can be sent back the faulty products with or without accessories (manuals,
cable, etc.) and any components from the system. If the components were suspected
as part of the problems, please note clearly which components are included.
Otherwise, Cincoze is not responsible for the devices/parts.
⚫Repaired items will be shipped along with a "Repair Report" detailing the findings
and actions taken.
Limitation of Liability
Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use,
whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed
the original selling price of the product. The remedies provided herein are the customer’s sole and
exclusive remedies. In no event shall Cincoze be liable for direct, indirect, special or consequential
damages whether based on contract of any other legal theory.
Technical Support and Assistance
1. Visit the Cincoze website at www.cincoze.com where you can find the latest information about
the product.
2. Contact your distributor or our technical support team or sales representative for technical
support if you need additional assistance. Please have following information ready before you
call:
⚫Product name and serial number
⚫Description of your peripheral attachments
⚫Description of your software (operating system, version, application software, etc.)
⚫A complete description of the problem
⚫The exact wording of any error messages

CS-100/P2002 Series | User Manual 8
Conventions Used in this Manual
Safety Precautions
Before installing and using this device, please note the following precautions.
1. Read these safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Disconnected this equipment from any AC outlet before cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must
be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
8. Use a power cord that has been approved for using with the product and that it matches the
voltage and current marked on the product’s electrical range label. The voltage and current
rating of the cord must be greater than the voltage and current rating marked on the product.
9. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
This indication alerts operators to an operation that, if not strictly observed, may result in
severe injury.
(Cette indication avertit les opérateurs d'une opération qui, si elle n'est pas strictement
observée, peut entraîner des blessures graves.)
WARNING
(AVERTIR)
This indication alerts operators to an operation that, if not strictly observed, may result in
safety hazards to personnel or damage to equipment.
(Cette indication avertit les opérateurs d'une opération qui, si elle n'est pas strictement
observée, peut entraîner des risques pour la sécurité du personnel ou des dommages à
l'équipement.)
CAUTION
(ATTENTION)
This indication provides additional information to complete a task easily.
(Cette indication fournit des informations supplémentaires pour effectuer facilement
une tâche.)
NOTE
(NOTE)

CS-100/P2002 Series | User Manual 9
13. Never open the equipment. For safety reasons, the equipment should be opened only by
qualified service personnel.
If one of the following situations arises, get the equipment checked by service personnel:
⚫The power cord or plug is damaged.
⚫Liquid has penetrated into the equipment.
⚫The equipment has been exposed to moisture.
⚫The equipment does not work well, or you cannot get it work according to the user's
manual.
⚫The equipment has been dropped and damaged.
⚫The equipment has obvious signs of breakage.
14. CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of
Used Batteries According to the Instructions.
ATTENTION: Risque d'explosion si la batterie est remplacée par un type incorrect. Mettre au
rebus les batteries usagées selon les instructions.
15. Equipment intended only for use in a RESTRICTED ACCESS AREA.
16. Ensure to connect the power cord of power adapter to a socket-outlet with earthing
connection.
17. Dispose of used battery promptly. Keep away from children. Do not disassemble and do not
dispose of in fire.

CS-100/P2002 Series | User Manual 10
Package Contents
Before installation, please ensure all the items listed in the following table are included in the
package.
Item
Description
Q’ty
1
Panel PC
1
2
Screw Pack
1
3
Power Terminal Block Connector
1
4
Fan Terminal Block Connector
1
5
DIO Terminal Block Connector
2
6
Power On/Off Terminal Block Connector
1
7
Panel Mounting Kit(The quantity varies with the size of the display
module, please refer to the datasheet for the actual quantity)
1
Note: Notify your sales representative if any of the above items are missing or damaged.
Ordering Information
Model No.
Product Description
CS-112HC/P2002-i5
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i5-6300U Processor and P-Cap. Touch
CS-112HC/P2002E-i5
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i5-6300U Processor, P-Cap. Touch and 1x Reserved
Expansion Slot
CS-112HC/P2002E-i5-E4
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i5-6300U Processor, P-Cap. Touch and 1x PCIe x4
Expansion Slot1x PCIex4 Expansion
CS-112HC/P2002E-i5-PI
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i5-6300U Processor, P-Cap. Touch and 1x PCI Expansion
Slot
CS-112HC/P2002-i3
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i3-6100U Processor and P-Cap. Touch
CS-112HC/P2002E-i3
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i3-6100U Processor, P-Cap. Touch and 1x Reserved
Expansion Slot
CS-112HC/P2002E-i3-E4
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i3-6100U Processor, P-Cap. Touch and 1x PCIe x4
Expansion Slot1x PCIex4 Expansion
CS-112HC/P2002E-i3-PI
12.1" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with
Intel® Core™ i3-6100U Processor, P-Cap. Touch and 1x PCI Expansion

CS-100/P2002 Series | User Manual 11
Slot
CS-115C/P2002-i5
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor and P-Cap. Touch
CS-115C/P2002E-i5
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x Reserved Expansion
Slot
CS-115C/P2002E-i5-E4
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x PCIe x4 Expansion
Slot
CS-115C/P2002E-i5-PI
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x PCI Expansion Slot
CS-115C/P2002-i3
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor and P-Cap. Touch
CS-115C/P2002E-i3
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x Reserved Expansion
Slot
CS-115C/P2002E-i3-E4
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x PCIe x4 Expansion
Slot
CS-115C/P2002E-i3-PI
15" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x PCI Expansion Slot
CS-117C/P2002-i5
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor and P-Cap. Touch
CS-117C/P2002E-i5
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x Reserved Expansion
Slot
CS-117C/P2002E-i5-E4
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x PCIe x4 Expansion
Slot1x PCIex4 Expansion
CS-117C/P2002E-i5-PI
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x PCI Expansion Slot
CS-117C/P2002-i3
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor and P-Cap. Touch
CS-117C/P2002E-i3
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x Reserved Expansion
Slot
CS-117C/P2002E-i3-E4
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x PCIe x4 Expansion

CS-100/P2002 Series | User Manual 12
Slot1x PCIex4 Expansion
CS-117C/P2002E-i3-PI
17" TFT-LCD 1500 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x PCI Expansion Slot
CS-119C/P2002-i5
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor and P-Cap. Touch
CS-119C/P2002E-i5
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x Reserved Expansion
Slot
CS-119C/P2002E-i5-E4
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x PCIe x4 Expansion
Slot
CS-119C/P2002E-i5-PI
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i5-6300U Processor, P-Cap. Touch and 1x PCI Expansion Slot
CS-119C/P2002-i3
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor and P-Cap. Touch
CS-119C/P2002E-i3
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x Reserved Expansion
Slot
CS-119C/P2002E-i3-E4
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x PCIe x4 Expansion
Slot
CS-119C/P2002E-i3-PI
19" TFT-LCD 1600 nits Sunlight Readable Touch Panel PC with Intel®
Core™ i3-6100U Processor, P-Cap. Touch and 1x PCI Expansion Slot
CS-W121C/P2002-i5
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Fanless Computer, CFM Interface,
CDS Interface
CS-W121C/P2002E-i5
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM
Interface, CDS Interface
CS-W121C/P2002E-i5-E4
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCIex4 Expansion
CS-W121C/P2002E-i5-PI
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCI Expansion
CS-W121C/P2002-i3
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Fanless Computer, CFM Interface,
CDS Interface

CS-100/P2002 Series | User Manual 13
CS-W121C/P2002E-i3
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM
Interface, CDS Interface
CS-W121C/P2002E-i3-E4
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCIex4 Expansion
CS-W121C/P2002E-i3-PI
21.5" TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCI Expansion
CS-W124C/P2002-i5
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Fanless Computer, CFM Interface,
CDS Interface
CS-W124C/P2002E-i5
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM
Interface, CDS Interface
CS-W124C/P2002E-i5-E4
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCIex4 Expansion
CS-W124C/P2002E-i5-PI
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i5-6300U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCI Expansion
CS-W124C/P2002-i3
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Fanless Computer, CFM Interface,
CDS Interface
CS-W124C/P2002E-i3
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM
Interface, CDS Interface
CS-W124C/P2002E-i3-E4
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCIex4 Expansion
CS-W124C/P2002E-i3-PI
24” TFT-LCD Full HD 16:9 Panel PC with Projected Capacitive Touch
and Intel 6th Gen. Core i3-6100U Expandable Fanless Computer, CFM
Interface, CDS Interface, 1x PCI Expansion

CS-100/P2002 Series | User Manual 14
Chapter 1
Product Introductions

CS-100/P2002 Series | User Manual 15
1.1 Overview
CS-100/P2002 Series is a TFT-LCD sunlight readable touch panel PC offering ultra-high brightness and high
resolution. The system is equipped with high-performance Intel® 6th generation Core™ U series processor
and provides extensive I/O including 2x GbE, 5x USB, 6x RS232/422/485, 8x DI/8x DO, 1x VGA and 1x DVI-D. It
also supports 2x Mini-PCIe slot and 1x SIM socket for a variety of wireless connections, such as BT/WiFi and
3G/LTE. In addition, there are 3 types of storage devices including 2.5" SATA HDD (RAID 0/1), mSATA and
CFast. The accessible design of these storage devices allows quick data access and easy maintenance.
CS-100/P2002 Series supports Convertible Display System (CDS) technology. Comparing to regular standalone
panel PCs, it can lower maintenance cost and reduce unplanned downtime. For greater flexibility,
CS-100/P2002 Series has PCI/PCIe expandable version and PoE/power ignition functions by additional CFM
(Control Function Module). Furthermore, CS-100/P2002 Series is a truly rugged display system supporting
wide range operating temperature (-20°C to 70°C), IP65 dust/waterproof front panel, wide range DC power
input (9 to 48VDC) and rigorous industrial protections.
1.2 Highlights
Sunlight Readable
Providing ultra high brightness and high resolution up to CS-100/P2002 Series is suitable for all lighting
conditions including direct sunlight.
High Performance
Powered by Intel® 6th Gen. Core™ Processor U Series, CS-100/P2002 Series Panel PC has greatly increased
computing performance and power efficiency.
Wide Temperature
CS-100/P2002 Series supports wide range operating temperature from -20°C to 70°C and is suitable for
deploying in extreme and harsh environments.

CS-100/P2002 Series | User Manual 16
1.3 Product Pictures
1.4 Key Features
⚫12.1” ~ 24” TFT LCD with Ultra High Brightness up to 1,600nits
⚫Onboard Intel® 6th Generation Core™ Processor U Series (15W)
⚫Supports 2x DDR4 SO-DIMM Socket, up to 32 GB
⚫Integrated Intel® HD Graphics 520, Triple Display Support
⚫2x 2.5” SATA Drive Bay, 1x mSATA, and 1x CFast Socket
⚫Rich I/O (2x GbE LAN, 6x COM, 5x USB, 16x Isolated DIO)
⚫2x Full-size Mini-PCIe Socket for Wireless and I/O Expansion
⚫Wide Range Operating Temperature -20°C to 70°C
⚫Designed with Aluminum Die-casting Front Frame
⚫True Flat IP65 Front Panel Protection
⚫Supports Panel / VESA / *Rack Mounting (*with optional mounting kit)
⚫Convertible Display System (CDS) Technology Supported

CS-100/P2002 Series | User Manual 17
1.5 Hardware Specification
1.5.1 CS-112HC/P2002 Series
Model Name
CS-112HC
Display
LCD Size
•12.1" (4:3)
Max. Resolution
•1024 x 768
Brightness (cd/m2)
•1500
Contract Ratio
•700 : 1
LCD Color
•16.7M
Pixel Pitch
•0.24 (H) x 0.24 (V)
Viewing Angle
•160 / 160
Backlight MTBF
•30,000 hrs (LED Backlight)
Touchscreen
Touch Type
•Projected Capacitive
Physical
Dimension (WxDxH)
•345 x 265.3 x 57 mm
Weight
•3.16 kg
Construction
•Flat Rugged Aluminum Die-casting Bezel
Environment
Front Panel Protection
•IP 65 Compliant
Operating Temperature
•Ambient with Air flow: -20°C to 70°C (extended temperature peripherals)
Storage Temperature
•-20°C to 70°C
Relative Humidity
•80% RH @ 40°C (non-condensing)
Safety
•UL, cUL, CB, IEC, EN 62368-1
Model Name
P2002
P2002E
System
Processor
•Onboard 6th Intel® Core™U processors (Skylake)
- Intel® Core™i5-6300U processor (3M Cache, up to 3.00 GHz)
- Intel® Core™i3-6100U processor (3M Cache, 2.30 GHz)
- TDP: 15 W
Memory
•2x DDR4 2133 MHz SO-DIMM Sockets
•Support Un-buffered and Non-ECC Type up to 32 GB
BIOS
•AMI 64Mbit SPI BIOS
Graphics

CS-100/P2002 Series | User Manual 18
Graphics Engine
•Intel® HD Graphics 520
Maximum Display Output
•Supports Triple Independent Display (1x CDS, 1x VGA, 1x DVI-D)
VGA
•1x VGA Connector (Up to 1920 x 1080 @ 60Hz), DB-15
DVI-D
•1x DVI-D Connector (Up to 1920 x 1080 @ 60Hz)
Audio
Audio Codec
•Realtek® ALC888, High Definition Audio
I/O
LAN
•2x GbE LAN (Supports WoL, Teaming, Jumbo Frame & PXE), RJ45
- GbE1: Intel® I219-LM
- GbE2: Intel® I210
PoE+
•2x PoE+ (with Optional CFM PoE Module)
- Comply with IEEE 802.3at, Offers Up to 25.5W Per Port
USB
•4x USB 3.2 Gen1 (Type A), 1x USB 2.0(Type-A)
Serial Port
•6x RS-232/422/485 with Auto Flow Control Support 5V/12V, DB9
(Compatible with slim type serial cable with connector length below 25mm.)
DIO
•16x Isolated Digital I/O (8in/8out), 10-Pin Terminal Block
Line-out & Mic-in
•1x Line-out & 1x Mic-in, Phone Jack 3.5mm
Power Mode Switch
•1x AT/ATX Mode Switch
Power Switch
•1x Power On/Off Switch
Reset Button
•1x Reset Button
Remote Power On/Off
•1x Remote Power On/Off Connector, 2-pin Terminal Block
External Fan
•1x External FAN Connector, 4-Pin Terminal Block
Storage
SSD/HDD
•2x 2.5” SATA HDD/SSD Bay, Support RAID 0/1 (Gen3)
mSATA
•2x mSATA (One Shared by Mini-PCIe Socket) (Gen2)
CFast
•1x CFast Socket (Gen3)
Expansion
PCI Express
•1x PCI or 1x PCIex4 Expansion slot
•Optional Riser Card: 1x PCI, 1x PCIex4
•Support maximum dimension of add-on
card (H x L): 111mm x 202mm
Mini PCI Express
•2x Full-size Mini-PCIe Socket
SIM Socket
•1x SIM Socket
CFM (Control Function Module)
Interface
•Optional CFM IGN Module for Power Ignition Function
•Optional CFM PoE Module for Power over Ethernet Function
CDS (Convertible Display
Systems) Technology
•1x CDS Interface, Compact PCI Connector
I/O Brackets
•1x Universal I/O Bracket

CS-100/P2002 Series | User Manual 19
Antenna Hole
•4x Antenna Hole
Other Function
Audio Codec
•Realtek® ALC888, High Definition Audio
Instant Reboot
•Support Instant Reboot Technology (0.2 sec)
OSD Function
•LCD On/Off, Brightness Up, Brightness Down for CDS Display Module
Internal Speaker
•AMP 2W + 2W
CMOS Battery Backup
•SuperCap Integrated for CMOS Battery Maintenance-free Operation
Watchdog Timer
•Software Programmable Supports 256 Levels System Reset
Power
AT/ATX Power
•Support AT, ATX Mode
Power Input
•1x 3-pin Terminal Block Connector with Power Input 9~48VDC
Power Adapter (Optional)
•1x Optional AC/DC 12V/5A, 60W or 24V/5A 120W
Physical
Dimension
( W x D x H )
•254.5 x 220 x 54mm
•254.5 x 220 x 72 mm
Weight Information
•2.92 kg
•3.18 kg
Mechanical Construction
•Extruded Aluminum with Heavy Duty Metal
Mounting
•Support Wall / VESA / CDS Mounting
Physical Design
•Fanless Design
•Jumper-less Design
Reliability & Protection
Reverse Power Input
•Yes
Over Voltage Protection
•Protection Range: 51-58V
•Protection Type: shut down operating voltage,
•re-power on at the present level to recover
Over Current Protection
•15A
CMOS Battery Backup
•SuperCap Integrated for CMOS Battery Maintenance-free Operation
Operating System
Microsoft® Windows®
•Windows®10, Windows® 8.1, Windows® 7
Linux
•Linux® Kernel 4.4
Environment
Operating Temperature
•Operating Temperature: -25°C to 70°C
(With extended temperature peripherals; Ambient with air flow
According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
Storage Temperature
•Storage Temperature: -40°C to 85°C
Relative humidity
•Relative Humidity: 95% RH @ 40°C (Non-condensing)
Shock
•Operating, 50 Grms, Half-sine 11 ms Duration

CS-100/P2002 Series | User Manual 20
(with SSD, according to IEC60068-2-27)
Vibration
•Operating, 5 Grms, 5-500 Hz, 3 Axes
(with SSD, according to IEC60068-2-64)
* Product Specifications and features are for reference only and are subject to change without prior
notice. For more information, please refer to the latest product datasheet from Cincoze's website.
