Cincoze Performance & Power Efficient Series User manual

Version: V1.56
Industrial Panel PC
Power Efficient Series
CV-100/P1101 Series
User Manual
Industrial Panel PC

CV-100/P1101 Series | User Manual 2
Contents
Preface ...................................................................................................................................................5
Revision ..........................................................................................................................................5
Copyright Notice ............................................................................................................................5
Acknowledgement .........................................................................................................................5
Disclaimer.......................................................................................................................................5
Declaration of Conformity..............................................................................................................6
Product Warranty Statement.........................................................................................................6
Technical Support and Assistance..................................................................................................7
Conventions Used in this Manual ..................................................................................................8
Safety Precautions..........................................................................................................................8
Package Contents.........................................................................................................................10
Ordering Information ...................................................................................................................10
Chapter 1 Product Introductions .........................................................................................................14
1.1 Overview ................................................................................................................................15
1.2 Highlights................................................................................................................................15
1.3 Product Pictures.....................................................................................................................16
1.4 Key Features...........................................................................................................................16
1.5 Hardware Specification ..........................................................................................................17
1.5.1 CV-108/P1101 Series...................................................................................................17
1.5.2 CV-110/P1101 Series...................................................................................................21
1.5.3 CV-110H/P1101 Series ................................................................................................25
1.5.3 CV-112H/P1101 Series ................................................................................................29
1.5.4 CV-115/P1101 Series...................................................................................................33
1.5.5 CV-W115/P1101 Series...............................................................................................37
1.5.6 CV-117/P1101 Series...................................................................................................41
1.5.7 CV-119/P1101 Series...................................................................................................45
1.5.8 CV-W121/P1101 Series...............................................................................................49
1.5.9 CV-W124/P1101 Series...............................................................................................53
1.6 System I/O..............................................................................................................................57
1.6.1 Front............................................................................................................................57
1.6.2 Rear .............................................................................................................................57
1.6.3 Side (Right)..................................................................................................................58
1.6.4 Side (Left) ....................................................................................................................58
1.6.5 Top...............................................................................................................................59
Chapter 2 Switches & Connectors........................................................................................................60
2.1 Location of Switches and Connectors ....................................................................................61
2.1.1 Top View......................................................................................................................61
2.1.2 Bottom View ...............................................................................................................62
2.2 Switches and Connectors Definition ......................................................................................63

CV-100/P1101 Series | User Manual 3
2.3 Definition of Switches ............................................................................................................64
2.4 Definition of Connectors........................................................................................................66
Chapter 3 System Setup.......................................................................................................................70
3.1 Removing Top Cover...............................................................................................................71
3.2 Installing SO-DIMM Memory .................................................................................................72
3.3 Installing Mini-PCIe Card........................................................................................................73
3.4 Installing Antenna(s) ..............................................................................................................74
3.5 Installing CPU Thermal Pad ....................................................................................................76
3.6 Installing Top Cover ................................................................................................................77
3.7 Installing SATA Hard Drive ......................................................................................................78
3.8 Installing SIM Card .................................................................................................................80
3.9 Connecting with CV Display Module......................................................................................81
3.10 Installing VESA Mount..........................................................................................................83
3.11 Installing Panel Mount .........................................................................................................84
Chapter 4 BIOS Setup...........................................................................................................................88
4.1 BIOS Introduction...................................................................................................................89
4.2 Main Setup.............................................................................................................................90
4.3 Advanced Setup .....................................................................................................................91
4.3.1 ACPI Settings ...............................................................................................................91
4.3.2 F81866 Super IO Configuration...................................................................................92
4.3.3 Hardware Monitor ......................................................................................................93
4.3.4 S5 RTC Wake Settings..................................................................................................94
4.3.5 Serial Port Console Redirection...................................................................................94
4.3.6 CPU Configuration.......................................................................................................95
4.3.7 Network Stack Configuration ......................................................................................95
4.3.8 CSM Configuration ......................................................................................................96
4.3.9 USB Configuration .......................................................................................................97
4.4 Chipset Setup .........................................................................................................................98
4.4.1 North Bridge................................................................................................................98
4.4.2 South Bridge................................................................................................................99
4.4.3 South Cluster Configuration......................................................................................100
4.5 Security Setup ......................................................................................................................103
4.6 Boot Setup............................................................................................................................104
4.7 Save & Exit............................................................................................................................105
Chapter 5 Product Application...........................................................................................................106
5.1 Digital I/O (DIO) application.................................................................................................107
5.1.1 Digital I/O Programming Guide.................................................................................107
5.2 Digital I/O (DIO) Hardware Specification .............................................................................113
5.2.1 DIO Connector Definition..........................................................................................113
Chapter 6 Optional Modules and Accessories ...................................................................................115
6.1 Location of the Connectors and Switches............................................................................116

CV-100/P1101 Series | User Manual 4
6.2 Installing CFM-IGN Module..................................................................................................116
6.3 Installing CFM-PoE Module..................................................................................................118

CV-100/P1101 Series | User Manual 5
Preface
Revision
Revision
Description
Date
1.00
First Release
2018/09/07
1.10
Corrections made
2018/10/17
1.20
Corrections made
2018/11/20
1.30
CV-W124 Product Info and Mechanical Dimensions Added
2019/01/14
1.40
CV-108C Product Info and Mechanical Dimensions Added
2019/02/15
1.50
LAN Chip Information & Power Adapter Updated
CV-W124G Product Info and Mechanical Dimensions
Added
2019/05/17
1.51
Correction Made
2020/04/09
1.52
New Format Updated
2020/10/22
1.53
Add DC_IN1 Warning
2021/04/20
1.54
Correction Made
2021/06/28
1.55
Separate Display module & PC module
2022/10/21
1.56
Correction Made
2023/04/14
Copyright Notice
© 2018 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified,
or reproduced in any form or by any means for commercial use without the prior written permission
of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only
and remain subject to change without prior notice.
Acknowledgement
Cincoze is a registered trademark of Cincoze Co., Ltd. All registered trademarks and product names
mentioned herein are used for identification purposes only and may be trademarks and/or
registered trademarks of their respective owners.
Disclaimer
This manual is intended to be used as a practical and informative guide only and is subject to
change without notice. It does not represent a commitment on the part of Cincoze. This product
might include unintentional technical or typographical errors. Changes are periodically made to the
information herein to correct such errors, and these changes are incorporated into new editions of
the publication.

CV-100/P1101 Series | User Manual 6
Declaration of Conformity
FCC
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
CE
The product(s) described in this manual complies with all application European Union
(CE) directives if it has a CE marking. For computer systems to remain CE compliant,
only CE-compliant parts may be used. Maintaining CE compliance also requires
proper cable and cabling techniques.
Product Warranty Statement
Warranty
Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and
workmanship for 2 years from the date of purchase by the original purchaser. During the warranty
period, we shall, at our option, either repair or replace any product that proves to be defective
under normal operation. Defects, malfunctions, or failures of the warranted product caused by
damage resulting from natural disasters (such as by lightening, flood, earthquake, etc.),
environmental and atmospheric disturbances, other external forces such as power line disturbances,
plugging the board in under power, or incorrect cabling, and damage caused by misuse, abuse, and
unauthorized alteration or repair, and the product in question is either software, or an expendable
item (such as a fuse, battery, etc.), are not warranted.
RMA
Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an
RMA number from us. Our staff is available at any time to provide you with the most friendly and
immediate service.
◼RMA Instruction
⚫Customers must fill in Cincoze Return Merchandise Authorization (RMA) Request
Form and obtain an RMA number prior to returning a defective product to Cincoze
for service.
⚫Customers must collect all the information about the problems encountered and
note anything abnormal and describe the problems on the “Cincoze Service Form”
for the RMA number apply process.

CV-100/P1101 Series | User Manual 7
⚫Charges may be incurred for certain repairs. Cincoze will charge for repairs to
products whose warranty period has expired. Cincoze will also charge for repairs to
products if the damage resulted from acts of God, environmental or atmospheric
disturbances, or other external forces through misuse, abuse, or unauthorized
alteration or repair. If charges will be incurred for a repair, Cincoze lists all charges,
and will wait for customer’s approval before performing the repair.
⚫Customers agree to ensure the product or assume the risk of loss or damage during
transit, to prepay shipping charges, and to use the original shipping container or
equivalent.
⚫Customers can be sent back the faulty products with or without accessories (manuals,
cable, etc.) and any components from the system. If the components were suspected
as part of the problems, please note clearly which components are included.
Otherwise, Cincoze is not responsible for the devices/parts.
⚫Repaired items will be shipped along with a "Repair Report" detailing the findings
and actions taken.
Limitation of Liability
Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use,
whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed
the original selling price of the product. The remedies provided herein are the customer’s sole and
exclusive remedies. In no event shall Cincoze be liable for direct, indirect, special or consequential
damages whether based on contract of any other legal theory.
Technical Support and Assistance
1. Visit the Cincoze website at www.cincoze.com where you can find the latest information about
the product.
2. Contact your distributor or our technical support team or sales representative for technical
support if you need additional assistance. Please have following information ready before you
call:
⚫Product name and serial number
⚫Description of your peripheral attachments
⚫Description of your software (operating system, version, application software, etc.)
⚫A complete description of the problem
⚫The exact wording of any error messages

CV-100/P1101 Series | User Manual 8
Conventions Used in this Manual
Safety Precautions
Before installing and using this device, please note the following precautions.
1. Read these safety instructions carefully.
2. Keep this User’s Manual for future reference.
3. Disconnected this equipment from any AC outlet before cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must
be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
8. Use a power cord that has been approved for using with the product and that it matches the
voltage and current marked on the product’s electrical range label. The voltage and current
rating of the cord must be greater than the voltage and current rating marked on the product.
9. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.

CV-100/P1101 Series | User Manual 9
13. Never open the equipment. For safety reasons, the equipment should be opened only by
qualified service personnel.
If one of the following situations arises, get the equipment checked by service personnel:
⚫The power cord or plug is damaged.
⚫Liquid has penetrated into the equipment.
⚫The equipment has been exposed to moisture.
⚫The equipment does not work well, or you cannot get it work according to the user's
manual.
⚫The equipment has been dropped and damaged.
⚫The equipment has obvious signs of breakage.
14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer.
15. Equipment intended only for use in a RESTRICTED ACCESS AREA.

CV-100/P1101 Series | User Manual 10
Package Contents
Before installation, please ensure all the items listed in the following table are included in the
package.
Item
Description
Q’ty
1
Panel PC
1
2
Screw Pack
1
3
Panel Mounting Kit (The quantity varies with the size of the display
module, please refer to the datasheet for the actual quantity)
1
4
Power Terminal Block Connector
1
5
Remote Power On/Off Terminal Block Connector
1
6
DIO Terminal Block Connector
1
7
Thermal Pad (for CPU Thermal Block)
1
Note: Notify your sales representative if any of the above items are missing or damaged.
Ordering Information
Model No.
Product Description
CV-108C/P1101-E50
8.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and P-Cap.
Touch
CV-108R/P1101-E50
8.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and Resistive
5-wire Touch
CV-108C/P1101-N42
8.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and P-Cap.
Touch
CV-108R/P1101-N42
8.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-110HC/P1101-E50
10.4" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and P-Cap.
Touch
CV-110HR/P1101-E50
10.4" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and Resistive
5-wire Touch
CV-110HC/P1101-N42
10.4" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and P-Cap.
Touch

CV-100/P1101 Series | User Manual 11
CV-110HR/P1101-N42
10.4" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-110C/P1101-E50
10.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and P-Cap.
Touch
CV-110R/P1101-E50
10.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and Resistive
5-wire Touch
CV-110C/P1101-N42
10.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and P-Cap.
Touch
CV-110R/P1101-N42
10.4" TFT-LCD SVGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-112HC/P1101-E50
12.1" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and P-Cap.
Touch
CV-112HR/P1101-E50
12.1" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and Resistive
5-wire Touch
CV-112HC/P1101-N42
12.1" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and P-Cap.
Touch
CV-112HR/P1101-N42
12.1" TFT-LCD XGA 4:3 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-115C/P1101-E50
15" TFT-LCD XGA 4:3 Modular Touch Panel PC with Intel®
Atom® E3950 Quad Core Processor and P-Cap. Touch
CV-115R/P1101-E50
15" TFT-LCD XGA 4:3 Modular Touch Panel PC with Intel®
Atom® E3950 Quad Core Processor and Resistive 5-wire
Touch
CV-115C/P1101-N42
15" TFT-LCD XGA 4:3 Modular Touch Panel PC with Intel®
Pentium® N4200 Quad Core Processor and P-Cap. Touch
CV-115R/P1101-N42
15" TFT-LCD XGA 4:3 Modular Touch Panel PC with Intel®
Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-117C/P1101-E50
17" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Atom® E3950 Quad Core Processor and P-Cap. Touch

CV-100/P1101 Series | User Manual 12
CV-117R/P1101-E50
17" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Atom® E3950 Quad Core Processor and Resistive 5-wire
Touch
CV-117C/P1101-N42
17" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Pentium® N4200 Quad Core Processor and P-Cap. Touch
CV-117R/P1101-N42
17" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-119C/P1101-E50
19" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Atom® E3950 Quad Core Processor and P-Cap. Touch
CV-119R/P1101-E50
19" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Atom® E3950 Quad Core Processor and Resistive 5-wire
Touch
CV-119C/P1101-N42
19" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Pentium® N4200 Quad Core Processor and P-Cap. Touch
CV-119R/P1101-N42
19" TFT-LCD SXGA 5:4 Modular Touch Panel PC with Intel®
Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-W115C/P1101-E50
15.6" TFT-LCD WXGA 16:9 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and P-Cap.
Touch
CV-W115R/P1101-E50
15.6" TFT-LCD WXGA 16:9 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and Resistive
5-wire Touch
CV-W115C/P1101-N42
15.6" TFT-LCD WXGA 16:9 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and P-Cap.
Touch
CV-W115R/P1101-N42
15.6" TFT-LCD WXGA 16:9 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-W121C/P1101-E50
21.5" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and P-Cap.
Touch
CV-W121R/P1101-E50
21.5" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and Resistive
5-wire Touch
CV-W121C/P1101-N42
21.5" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and P-Cap.
Touch

CV-100/P1101 Series | User Manual 13
CV-W121R/P1101-N42
21.5" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-W124C/P1101-E50
24" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and P-Cap.
Touch
CV-W124R/P1101-E50
24" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Atom® E3950 Quad Core Processor and Resistive
5-wire Touch
CV-W124C/P1101-N42
24" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and P-Cap.
Touch
CV-W124R/P1101-N42
24" TFT-LCD Full HD 16:9 Modular Touch Panel PC with
Intel® Pentium® N4200 Quad Core Processor and Resistive
5-wire Touch
CV-117G/P1101-E50
17" TFT-LCD SXGA 5:4 Modular Panel PC with Intel®
Atom™ E3950 Quad Core Processor and without Touch
CV-117G/P1101-N42
17" TFT-LCD SXGA 5:4 Modular Panel PC with Intel®
Pentium™ N4200 Quad Core Processor and without Touch
CV-119G/P1101-E50
19" TFT-LCD SXGA 5:4 Modular Panel PC with Intel®
Atom™ E3950 Quad Core Processor and without Touch
CV-119G/P1101-N42
19" TFT-LCD SXGA 5:4 Modular Panel PC with Intel®
Pentium™ N4200 Quad Core Processor and without Touch
CV-W121G/P1101-E50
21.5" TFT-LCD Full HD 16:9 Modular Panel PC with Intel®
Atom™ E3950 Quad Core Processor and without Touch
CV-W121G/P1101-N42
21.5" TFT-LCD Full HD 16:9 Modular Panel PC with Intel®
Pentium™ N4200 Quad Core Processor and without Touch
CV-W124G/P1101-E50
24" TFT-LCD Full HD 16:9 Modular Panel PC with Intel®
Atom™ E3950 Quad Core Processor and without Touch
CV-W124G/P1101-N42
24" TFT-LCD Full HD 16:9 Modular Panel PC with Intel®
Pentium™ N4200 Quad Core Processor and without Touch

CV-100/P1101 Series | User Manual 14
Chapter 1
Product Introductions

CV-100/P1101 Series | User Manual 15
1.1 Overview
CV-100/P1101 Series is a TFT-LCD touch panel PC. The system is based on Intel® Atom® / Pentium® processor
and supports triple independent displays (via VGA and DisplayPort outputs). CV-100/P1100 Series features
extensive connectivity including 2x GbE, 4x USB 3.0, 4x COM, and 8x isolated DIO. It also offers 2x full size
Mini-PCIe socket and 1x SIM socket for a variety of wireless data connections.
Through the ready-to-use CFM modules, users can easily add power ignition sensing and Power over
Ethernet (PoE) functions for a variety of applications. CV-100/P1101 Series also supports Convertible Display
System (CDS) technology. Comparing with regular standalone panel PCs, it is more flexible and reduces
maintenance cost dramatically.
Featuring with rigorous industrial protections, wide range operating temperature, IP65 dust/waterproof front
panel, and wide range DC power input (9 to 48VDC), CV-100/P1101 Series is appropriate for harsh
environments and critical applications.
1.2 Highlights
Power Efficient
CV-100/P1100 Series is an
energy-saving fanless panel PC.
Based on Intel® Atom® /
Pentium® processor, the system
can operate up to triple
independent displays and support
up to 4K display resolution (via
DisplayPort).
Multiple Functions
CV-100/P1100 Series provides
extensive I/O, Mini-PCIe slot, 2.5”
SATA drive bay, mSATA socket, and
SIM card slot. It also supports power
ignition sensing and PoE by adding
ready-to-use CFM modules.
CDS Technology
CDS (Convertible Display Systems)
is a Cincoze patented technology,
which allows for easy system
maintenance, upgrades or
replacement.

CV-100/P1101 Series | User Manual 16
1.3 Product Pictures
1.4 Key Features
⚫8.4” ~ 24” TFT LCD with Resistive 5-wire Touch, Projected Capacitive Touch or Glass
Only (Available on Selected Models)
⚫Onboard Intel® Atom® / Pentium® Processor
⚫Triple Independent Displays (via VGA and DisplayPort outputs)
⚫Rich I/O (2x GbE LAN, 4x USB 3.0, 4x COM, 8x Isolated DIO)
⚫2x Full Size Mini-PCIe, 1x 2.5” SATA Drive Bay, 1x mSATA Socket
⚫Designed with Rugged Aluminum Die-casting Front Bezel and Heavy Duty Metal Chassis
⚫True Flat IP65 Front Panel Protection
⚫Supports CDS Technology, Ignition Sensing and Power over Ethernet
⚫Supports Panel / VESA Mounting

CV-100/P1101 Series | User Manual 17
1.5 Hardware Specification
1.5.1 CV-108/P1101 Series
The table on this page refers to the specifications of CV-108 alone
Model Name
CV-108R
CV-108C
Display
LCD Size
•8.4" (4:3)
Max. Resolution
•800 x 600
Brightness( cd/m2)
•400
Contract Ratio
•600 : 1
LCD Color
•262K
Pixel Pitch(mm)
•0.213 (H) x 0.213 (V)
Viewing Angle( H-V)
•150 / 130
Backlight MTBF
•30,000 hrs(LED Backlight)
Touchscreen
Touch Type
•Resistive 5-wire
•Projected Capacitive
Physical
Dimension (WxDxH)
•262 x 186.2 x 56.2mm
Weight
•1.62kg
•1.58kg
Mechanical Construction
•Die-Casting Flat Surface
Reliability & Protection
Front Panel Protection
•IP 65 Compliant
Surge Protection
•2kV
Environment
Operating Temperature
•-20°C to 70°C (with Industrial Grade peripherals; Ambient with air flow)
Storage Temperature
•-30°C to 80°C
•-20°C to 70°C
Relative Humidity
•80% RH @ 50°C (Non-condensing)
•85% RH @ 50°C (Non-condensing)
EMC
•CE, UKCA, FCC, ICES-003 Class A

CV-100/P1101 Series | User Manual 18
Model Name
P1101
System
Processor
•Onboard Intel® Atom® x7-E3950 Quad Core Processor, up to 2.00 GHz
•Onboard Intel® Pentium® N4200 Quad Core Processor, up to 2.50 GHz
Memory
•1x DDR3L 1333/1600/1866 MHz 204-Pin SO-DIMM Socket
•Support up to 8 GB (un-buffered and non-ECC)
Graphics
Graphics Engine
•Integrated Intel® HD Graphics 505
Maximum Display Output
•Supports Triple Independent Display (1x CDS, 1x VGA, 1x DisplayPort)
VGA
•1x VGA Connector(1920x1200@60Hz)
DP
•1x DisplayPort Connector (4K x 2K @60Hz)
Audio
Audio Codec
•Realtek® ALC888, High Definition Audio
Line-out
•1x Line-out, Phone Jack 3.5mm
Mic-in
•1x Mic-in, Phone Jack 3.5mm
I/O
LAN
•2x GbE LAN (Supports WoL, Teaming, Jumbo Frame & PXE), RJ45
- GbE1: Intel® I210
- GbE2: Intel® I210
USB
•4x USB 3.2 Gen1 (Type A)
Serial Port
•4x RS-232/422/485 with Auto Flow Control Support 5V/12V, DB9
DIO
•8x Digital I/O (4in/4out) , 10-Pin Terminal Block
Power Mode Switch
•1x AT/ATX Mode Switch
Power Switch
•1x Power Switch
Reset Button
•1x Reset Button
Clear CMOS Switch
•1x Clear CMOS Switch
Remote Power On/Off
•1x Remote Power On/Off Connector, 2-pin Terminal Block
Storage
SSD/HDD
•1x 2.5” SATA HDD Bay (SATA3.0)
mSATA
•1x mSATA Socket (SATA 3.0, Shared by Mini-PCIe Socket)
Expansion
Mini PCI Express
•2x Full-size Mini PCIe Sockets
SIM Socket
•1 x SIM Socket
CFM (Control Function Module)
Interface
•Optional CFM IGN Module for Power Ignition Function
•Optional CFM PoE Module for Power over Ethernet Function
CDS (Convertible Display
System) Technology
•1x CDS Interface for Convertible Display Module
Antenna Holes
•4x Antenna Holes

CV-100/P1101 Series | User Manual 19
Model Name
P1101
Other Function
Instant Reboot
•Support 0.2sec
Watchdog Timer
•Software Programmable Supports 256 Levels System Reset
Internal Speaker
•AMP 2W + 2W
OSD Function
•LCD On/Off, Brightness Up, Brightness Down
Power
AT/ATX Power
•Support AT, ATX Mode
Power Input
•1x 3-pin Terminal Block Connector with Power Input 9-48VDC
Power Adapter (Optional)
•1x Optional AC/DC 12V/5A, 60W or 24V/5A 120W
Physical
Dimension( W x D x H )
•204.5 X 149 X 41.5 mm
Weight Information
•1.49kg
Mechanical Construction
•Extruded Aluminum with Heavy Duty Metal
Mounting
•Wall / VESA / CDS / DIN Rail
Reliability & Protection
Reverse Power Input
•Yes
Over Voltage Protection
•Protection Range: 51-58V
•Protection Type: shut down operating voltage,
•re-power on at the present level to recover
Over Current Protection
•15A
ESD Protection
•+/-8kV (air), +/-4kV (contact)
Surge Protection
•2kV
CMOS Battery Backup
•SuperCap Integrated for CMOS Battery Maintenance-free Operation
MTBF
•Time: 294,617 hours
Operating System
Microsoft® Windows®
•Windows®10
Linux
•Supports by project
Environment
Operating Temperature
•Ambient with Air Flow: -40°C to 70°C (with Industrial Grade Peripherals)
Storage Temperature
•-40°C to 85°C
Relative humidity
•90% RH @ 75°C (non-condensing)
Shock
•Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27)
Vibration
•Operating, 5 Grms, 5-500 Hz, 3 Axes (w/ SSD, according to IEC60068-2-64)
EMC
•CE, UKCA, FCC, ICES-003 Class A
Safety
•LVD IEC/EN 62368-1

CV-100/P1101 Series | User Manual 20
Dimension
CV-108/P1101
