Circa Enterprises Inc. Guardian Telecom CIR-41-SWIVEL Guide

Correctional Institute Ringdown Telephone
Model CIR-41-SWIVEL
Installation & Operation
P007910 Rev. A 200713 7/13/2020 3:10 PM

Installation and Operation
CIR41-SWIVEL
Page 2
Table of Contents
Package Contents ........................................................................................2
Overview ......................................................................................................3
Features .......................................................................................................3
Installing the CIR-41 .....................................................................................6
Operating the CIR-41....................................................................................6
Specifications ...............................................................................................7
Replacement Parts .......................................................................................8
Storage.........................................................................................................8
Cleaning Tips for Guardian Telephones........................................................8
Warranty.......................................................................................................9
Disclaimer.....................................................................................................9
Warning ........................................................................................................9
Service Telephone Number ..........................................................................9
Feedback......................................................................................................9
Guardian Product Return ............................................................................10
Table of Figures
Figure 1 - Features .......................................................................................4
Figure 2 - Dimensions...................................................................................4
Figure 3 - Mounting.......................................................................................5
Figure 4 - Electrical Connections ..................................................................5
Package Contents
(1) CIR-41-SWIVEL Telephone P6976
(1) Installation & Operation Manual
(1) Tamper Resistant Screw Driver Bit

Installation and Operation
CIR41-SWIVEL
Page 3
Overview
CIR-41 Correctional Institute Ringdown Telephone
The CIR-41 is a rugged, ringdown telephone designed to provide safe and reliable communication in
locations prone to abuse and vandalism. Calls may be received on this telephone however outgoing
calls will only be connected to a single number – if the PABX is programmed to perform this function
or if a Guardian AD-10 Autodialer is installed and programmed.
Features
Enclosure and Faceplate
•16 Gauge steel, zinc dichromate plated and powder coated, faceplate
secured with vandal resistant screws.
Handset
•
high impact ABS with locked on caps
Hook Switch
•
magnetic reed hook switch, no moving parts
Surge Arrestor and Fuse
•prevents damage to the electronic circuits in the event of a high
voltage spike on the telephone line
Noise Reducing Microphone
•
aids in clarity of transmission in noisy areas
Armored Handset Cord
•
withstands vandalism and severe use
Hearing-Aid Compatible
•
compatible with inductively coupled hearing-aid devices

Installation and Operation
CIR41-SWIVEL
Page 4
Figure 1 - Features
Figure 2 - Dimensions

Installation and Operation
CIR41-SWIVEL
Page 5
Figure 3 - Mounting
Figure 4 - Electrical Connections

Installation and Operation
CIR41-SWIVEL
Page 6
Installing the CIR-41
•
Follow all appropriate electrical codes and use only approved electrical
fittings for the installation.
•
Choose a wall location that is free of obstructions and permits space for
cable or conduit runs.
See: Figure 2 - Dimensions
•
Ensure mounting can support 4lbs (1.8kg) and any additional load to which
the telephone may be subjected.
•
Ensure that none of the electrical connection circuits are live.
•Bring Tip, Ring and Ground wiring to the location where the wiring access
opening in the back of the CIR-41 will be when the telephone is installed.
Tip: The CIR-41 may be
wired directly to the terminal
block or an RJ11 connector
may be used.
•
Remove the eight (8) cover screws from the front of the unit and carefully
remove the front cover assembly. NOTE that the handset and all electronics
are attached to the front plate. The front cover may be separated from the
back box by disconnecting the harness plug.
Tip: Use the driver bit
provided to remove the
tamper resistant screws.
•Use the enclosure as a template to locate and drill holes for #8 or M4
mounting screws or other suitable attachments.
See: Figure 3 - Mounting
•Feed Tip, Ring and Ground wiring through the wiring access opening and
secure the unit to the wall.
•Attach individual wires from the exchange (Tip/Ring/Ground) to the terminal
strip (Tip & Ring are not polarity sensitive), or plug the RJ11 connector into
the socket if this termination method was chosen. Even if an RJ11
connector is used, an approved earth ground must still be provided to the
ground connection on the terminal strip.
See: Figure 3 - Mounting
Note: An approved earth
ground must be connected
to the ground position on
the terminal strip regardless
of Tip and Ring wiring
method.
•
Ensure all connections are tight, then replace and secure the cover.
•
Connect the telephone into the system.
•
Test the unit by calling to and from another unit on the exchange.
Operating the CIR-41
•The CIR-41 Autodialer phone is designed for receiving calls and for
connecting to a single number if the PABX is programmed to perform this
function. Calling out is automatic simply by removing the handset from the
cradle.

Installation and Operation
CIR41-SWIVEL
Page 7
Specifications
E
LECTRICAL
P
ERFORMANCE
AUDIBLE RANGE FREQUENCY RESPONSE 300 –3400 HZ
TRANSMIT OBJECTIVE LOUDNESS RATING (TOLR) -38 +/-3dB
RECEIVE OBJECTIVE LOUDNESS RATING (ROLR) TYPICAL 50 +/-3dB
SIDE TONE OBJECTIVE LOUDNESS RATING (SOLR) TYPICAL 11 +/-3dB
RINGER OUTPUT 75 dB MAX
FCC RINGER EQUIVALENCE 0.8B
SET IMPEDANCE 600 OHMS NOMINAL
MAXIMUM LOOP 15,000 FT (4,600 M) OF 22 AWG COPPER
E
LECTRICAL
R
EQUIREMENTS
RINGER SENSITIVITY 40 –100 V, 16 –25 HZ
LINE VOLTAGE 24 –56 VDC
LOOP CURRENT 20 -120 MA
CONNECTION METHOD TERMINAL STRIP OR RJ11 CONNECTOR
E
NVIRONMENTAL
TEMPERATURE -40O TO +60O C(-40O TO +140O F)
HUMIDITY
0TO 95% RH
DUSTPROOF
FULL ENCLOSURE GASKET
M
ECHANICAL
HOOK SWITCH (CRADLE SWITCH)LIFE >1 000 000 OPERATIONS
BODY AND FACEPLATE CONSTRUCTION 16 GAUGE STEEL,ZINC DICHROMATE PLATED
A
ND
P
OWDER
C
OATED
DIMENSIONS (H X WX D) 9 X 5X 5.2 INCHES (229 X 127 X 132 MM)
NET WEIGHT 5 LBS (2.3 KG)
SHIPPING DIMENSIONS 15 X 5X 11.5 INCHES (381 X 127 X 293 MM)
SHIPPING WEIGHT 5.5 LBS (2.5 KG)
HANDSET MATERIAL HIGH IMPACT ABS
MICROPHONE NOISE REDUCING ELECTRET
OPTIONAL MICROPHONE NOISE CANCELING DYNAMIC
RECEIVER HEARING AID COMPATIBLE
STANDARD MOUNTING VERTICAL WALL
WIRING ACCESS REAR OPENING 1.5 X 1.5 INCHES (38 X 38 MM)
HARDWARE MATERIAL STAINLESS STEEL

Installation and Operation
CIR41-SWIVEL
Page 8
Replacement Parts
Part No.
Description
P002782 Floyd Bell Ringer
P002786
Handset Cradle
P002787
Faceplate Gasket
P002970
PCB Mounting Bracket
P002991
Fuse –Glass 0.25 Amp 250V
P002992
Surge Arrestor
P004023
Faceplate
P004119 Harness For PCBA
P004244 Cradle Gasket
P004245 Gasket For Floyd Bell Ringer
P005138 Harness With Three Fork Lugs
P005210
RJ11 Jack
P005582
Potted Volume Control PCBA
P005682
Tamper Resistant Screw
P005706
Bit For Tamper Resistant Screws
P005917
Heavy Duty Reed Switch
P006184
PCBA Gasket
P007802
Housing
P007813 Handset – C/W 16” Armored Cord and Swivel
Storage
General Storage (All situations):
•Note any stacking limits or warnings on packaging (if any).
•Do not store in temperatures over +80C.
•Store in original packaging if possible until needed.
Long Term Storage (> 6 Months):
•If area is air-conditioned and not subject to high changes in humidity, continue to store in original packaging.
•If wide humidity shifts are expected, then use these steps:
oRemove product from packaging (including plastic bags) and store on shelf in open air.
oIf area is subject to a high degree of dust, to help maintain cosmetic appearance you can cover with cloth
(Do not cover with plastic or materials that will trap moisture) or clean periodically.
oDo not store out of packaging long term where they are exposed to sunlight. Long-term exposure to UV may
cause fading on plastic parts.
Cleaning Tips for Guardian Telephones
Guardian Telephones may occasionally need to be cleaned to maintain appearance. Generally, wiping the surface with a
clean, water-dampened cloth will remove most films or residues. If the soiling is too stubborn for plain water, a mild detergent
solution may be used. Be sure to wipe away any detergent residue with a plain water dampened cloth. The Telephone may be
cleaned with any general-purpose household glass and surface type cleaner. Do not spray the telephone directly! Spray the
cleaner on a soft cloth then wipe the surface. Pre-treated cloths, like those used for eyeglasses or cameras, may be used to
clean the Telephone. Premoistened towelettes may also be used, however, avoid those containing lanolin or aloe, as they will
leave a slippery residue. The handset and surface of the telephone may be cleaned with disinfectants used for general
cleaning in a medical environment. Isopropyl alcohol may be used applied with a cloth. Avoid using alcohol on silicon-based
keypads, since doing so may significantly degrade legibility.
•Do not use furniture polishes, waxes or plasticizer-based cleaner (Armor All etc.)
•Do not use lanolin, aloe, glycerin or other skin care type products.
•Do not apply any solvent such as acetone, mineral spirits etc.
•Do not directly spray or immerse the handset.

Installation and Operation
CIR41-SWIVEL
Page 9
Warranty
Guardian Telecom, a division of Circa Enterprises Inc. warrants that its products are free from
defective workmanship and materials. Guardian Telecom will, within three years from the date of
final sale to the customer, replace or repair any such products provided they are returned to our
facilities for examination.
Freight costs (including brokerage if applicable), both to and from Guardian, are the sole
responsibility of the customer. This warranty does not extend to any items that are deemed to have
been misused, modified, neglected, improperly specified, improperly installed, or used in violation of
instructions or specifications approved by Guardian Telecom. Guardian Telecom, a division of Circa
Enterprises Inc. shall not be liable for incidental or consequential damage of any kind caused by any
defect in our product. The total liability shall not, under any circumstances, exceed the purchase
price of the products furnished by Guardian Telecom, a division of Circa Enterprises Inc.
Disclaimer
The products covered by this manual are designed for use in Industrial Environments and/or
Hazardous Locations. Due to the range of possible applications for these instruments the
manufacturer will not be responsible for damages or losses of any kind suffered as a result of the
use of this product, including consequential damages.
Warning
This device may be opened and reassembled by qualified personnel only, for the purposes of
installing the product and replacing fuses, following the instructions in the product manual.
High voltages may be present in this product when connected to telephone wiring.
Service Telephone Number
1-800-363-8010
Guardian Telecom provides a customer service telephone number which is toll-free within North
America. If you need assistance when installing or operating this product, please call the toll-free
telephone number between regular business hours (8:00AM-5:00PM), Mountain Standard Time. If
you are calling outside of regular business hours, please leave a detailed message, and a member
of Guardian Telecom’s Service Department will return your call as soon as possible. If your product
requires service, Guardian personnel will supply you with an RMA (return materials authorization)
number over the telephone or through our web site product return page. This number must be
included with your return address and the name of the person to contact.
Guardian Telecom, a division of Circa Enterprises Inc.
Toll-free 1-800-363-8010
Ph. [phone]
Fax. [phone]
www.guardiantelecom.com
E-mail: mailto:sal[email protected]
Feedback
Guardian Telecom continually strives to make reliable, durable, and easy to use products. If you, as
an installer or user of our equipment, have any suggestions for improvements to this or any of our
products or documents, including this manual, we would appreciate hearing from you.

Installation and Operation
CIR41-SWIVEL
Page 10
Guardian Product Return
Guardian products have been quality tested and are in full working order when shipped from
the factory, given the rugged nature of these products shipping is not expected to damage a
unit. In the unlikely event of a malfunction Guardian follows the three step procedure below.
Step I - On-Site Correction
•The most common source of difficulties with a new product is improper installation in one of
two ways: incorrect wiring connections or connection to an incorrect power source.
•Product wiring needs to be properly connected to the on-site wiring. Correct wiring
instructions are shown in the user manual included with the product.
•Connecting a telephone to a standard power source, rather than tip & ring, will blow the
telephone’s internal, user-replaceable fuse. In the event of fuse burnout, disconnect the
telephone from the power source, replace the fuse, and reconnect following the wiring
diagrams provided with the product.
Step II - Return Materials Authorization (RMA)
•When a product has been installed following user manual instructions and the unit
fails to operate, the user must contact Guardian Telecom to obtain authorization to
return the product. This can be done by completing an RMA form online at
https://www.guardiantelecom.com/support/rma/, or by calling the service telephone
number given in this manual.
•After providing information on the product, the owner and the nature of the problem,
Guardian will issue a RMA number, to be shown on documentation returned with the
product.
•In addition to the RMA number, shipping documents should include name, address and
telephone number of the owner along with contact information for the person responsible
for the repair and/or the user who identified the malfunction.
•(Where a product is being returned for repair from outside of Canada, customs
documentation must show the product’s serial number, date of export [date of purchase],
and a notation that the equipment is: “Canadian goods returning.”)
Step III - Factory Authorized Service
•Once received, each product is carefully inspected and tested. If the product is under
warranty, repairs are completed and the product returned to the owner, generally within
five working days of receipt by the factory.
•A product that has been subjected to misuse, neglect or accident or is beyond the warranty
period will be evaluated. The service department will provide the owner’s representative
with a repair cost estimate. Once approved, repairs are completed and the product
returned, generally within five working days.

Installation and Operation
CIR41-SWIVEL
Page 11
Notes:
Model No.
Part No.
Serial No.
Date of Purchase

Guardian Telecom, a division of Circa Enterprises Inc.
Toll-free 1-800-363-8010
Phone [phone]
Fax. [phone]
www.guardiantelecom.com
E-mail: [e-mail]
(Click to open message box)
Tough. Trusted. True.
© Guardian Telecom 2020
