Circutor Compact DC-S SBT User manual

INSTRUCTION MANUAL
PLC PRIME Concentrator
COMPACT DC
(M086B01-03-22A)

2
COMPACT DC
Instruction Manual

3
Instruction Manual
COMPACT DC
SAFETY PRECAUTIONS
DANGER
Warns of a risk, which could result in personal injury or material damage.
ATTENTION
Indicates that special attention should be paid to a specific point.
Follow the warnings described in this manual with the symbols shown below.
If you must handle the unit for its installation, start-up or maintenance, the following should be
taken into consideration:
Incorrect handling or installation of the unit may result in injury to personnel as well as damage to the
unit. In particular, handling with voltages applied may result in electric shock, which may cause death
or serious injury to personnel. Defective installation or maintenance may also lead to the risk of fire.
Read the manual carefully prior to connecting the unit. Follow all installation and maintenance in-
structions throughout the unit’s working life. Pay special attention to the installation standards of the
National Electrical Code.
Refer to the instruction manual before using the unit
In this manual, if the instructions marked with this symbol are not respected or carried out correctly, it can result
in injury or damage to the unit and/or installations.
CIRCUTOR, SA reserves the right to modify features or the product manual without prior notification.
DISCLAIMER
CIRCUTOR, SA reserves the right to make modifications to the device or the unit specifications set
out in this instruction manual without prior notice.
CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the device specifica-
tions and the most updated manuals.
www.circutor.com
CIRCUTOR, recommends using the original cables and accessories that are supplied
with the device.

4
COMPACT DC
Instruction Manual
CONTENTS
SAFETY PRECAUTIONS .........................................................................................................................................................3
DISCLAIMER ..........................................................................................................................................................................3
CONTENTS.............................................................................................................................................................................4
REVISION LOG .......................................................................................................................................................................6
SYMBOLS...............................................................................................................................................................................6
1. VERIFICATION UPON RECEPTION....................................................................................................................................7
2. INTRODUCTION ...............................................................................................................................................................7
3. DEVICE INSTALLATION....................................................................................................................................................9
3.1.- PRELIMINARY RECOMMENDATIONS ........................................................................................................................9
3.2.- INSTALLATION .......................................................................................................................................................10
3.3.- DEVICE TERMINALS...............................................................................................................................................10
3.3.1.- COMPACT DC SBT, DC-S SBT, DC 3G and DC-S 3G MODELS ...........................................................................10
3.3.2.- COMPACT DC 4I and DC-S 4I MODELS ............................................................................................................11
3.3.3.- COMPACT DC 2 MODEL................................................................................................................................... 12
3.3.4.- COMPACT DC 2 3G MODELS............................................................................................................................13
3.3.5.- COMPACT DC-S BASIC MODEL........................................................................................................................ 14
3.3.6.- COMPACT DCS MINI MODEL ......................................................................................................................... 14
3.4.- CONNECTION DIAGRAMS.......................................................................................................................................15
3.4.1.- COMPACT DC SBT, DCS SBT, DC 3G, DCS 3G, DC 4I AND DCS 4I MODELS.................................................15
3.4.2.- COMPACT DC 2 AND DC 2 3G MODELS...........................................................................................................16
3.4.3.- COMPACT DCS BASIC AND DCS MINI MODELS........................................................................................... 17
3.5.- ETHERNET PORT CONNECTION............................................................................................................................. 17
3.6.- SIM CARD INSTALLATION (COMPACT DC 3G, DC-S 3G, DC 2 3G and DC-S BASIC Models) ..................................18
4. OPERATION ...................................................................................................................................................................19
4.1.- LED INDICATORS ....................................................................................................................................................19
4.1.1.- COMPACT DC SBT AND DC-S SBT MODELS .....................................................................................................19
4.1.2.- COMPACT DC 3G AND DC-S 3G MODELS ....................................................................................................... 20
4.1.3.- COMPACT DC 4I AND DC-S 4I MODELS ........................................................................................................... 21
4.1.4.- COMPACT DC 2 MODEL....................................................................................................................................22
4.1.5.- COMPACT DC 2 3G MODEL..............................................................................................................................23
4.1.6.- COMPACT DCS MINI MODEL..........................................................................................................................24
4.1.7.- COMPACT DCS BASIC MODEL........................................................................................................................25
4.2.- RESET .................................................................................................................................................................. 26
4.3.- DIGITAL INPUTS (COMPACT DC 4I, DC-S 4I and DC 2 models)............................................................................ 26
5. WEB PAGE ....................................................................................................................................................................27
5.1.- HOME SCREEN ........................................................................................................................................................27
5.2.- MAIN SCREEN........................................................................................................................................................ 28
5.2.1. AREA WITH INFORMATION ABOUT THE COMPACT DC.................................................................................... 29
5.2.2. MENU............................................................................................................................................................... 30
5.3.- METERS MENU: METER TABLE...............................................................................................................................32
5.3.1. METER INFORMATION MENU. ..........................................................................................................................33
5.4.- METERS MENU: NODE MAP ...................................................................................................................................43
5.5.- METERS MENU: METER UPDATE............................................................................................................................44
5.6.- METERS MENU: CYCLES TEST............................................................................................................................... 45
5.7.- METERS MENU: TOPOLOGY LOG............................................................................................................................ 46
5.8.- METERS MENU: INTRUDER LIST............................................................................................................................47
5.9.- METERS MENU: MANAGE GROUP ......................................................................................................................... 48
5.10.- METERS MENU: PASSWORDS.............................................................................................................................. 49
5.11.- CONCENTRATOR MENU: REPORTS....................................................................................................................... 50
5.12.- CONCENTRATOR MENU: STATISTICS..................................................................................................................... 51
5.13.- CONCENTRATOR MENU: INPUTS (COMPACT DC 4I, DC-S 4I and DC 2 models) ...................................................52
5.14.- CONCENTRATOR MENU: PARAMETERS.................................................................................................................52
5.14.1. GENERAL PARAMETERS ................................................................................................................................52
5.14.2. COMMUNICATIONS CONFIGURATION........................................................................................................... 53
5.14.3. SECONDARY CONFIGURATION...................................................................................................................... 54
5.14.4. STG CONFIGURATION.................................................................................................................................... 54
5.14.5. NTP CONFIGURATION ................................................................................................................................... 55
5.14.6. AUTHENTICATION CONFIGURATION ............................................................................................................ 55
5.14.7. SNMP CONFIGURATION................................................................................................................................. 56

5
Instruction Manual
COMPACT DC
5.14.8. FTP CONFIGURATION ....................................................................................................................................57
5.14.9. FRAMES LOG CONFIGURATION .................................................................................................................... 58
5.14.10. PRIME REMOTE TOOLS ............................................................................................................................... 58
5.14.11. METER COMMUNICATIONS CONFIGURATION ..............................................................................................59
5.14.12. OTHER PARAMETERS.................................................................................................................................. 60
5.14.13. SEND PARAMETERS FILE B07, G17, C04 OR CERTIFICATE........................................................................ 61
5.14.14. TIME CONFIGURATION ................................................................................................................................ 61
5.15.- CONCENTRATOR MENU: TASKS............................................................................................................................ 61
5.16.- CONCENTRATOR MENU: TASK STATUS ................................................................................................................62
5.17.- MODEM MENU: REPORTS (COMPACT DC 3G, DC-S 3G, DC 2 3G and DC-S BASIC Models).................................63
5.18.- MODEM MENU: PARAMETERS (COMPACT DC 3G, DC-S 3G, DC 2 3G and DC-S BASIC Models) .........................64
5.18.1. GENERAL PARAMETERS................................................................................................................................64
5.18.2. SIM 1 CONFIGURATION..................................................................................................................................64
5.18.3. SIM 2 CONFIGURATION..................................................................................................................................65
5.18.4. CONNECTION MONITORING...........................................................................................................................65
5.18.5. SECURITY CONFIGURATION ......................................................................................................................... 66
5.18.6. DynDNS CONFIGURATION ............................................................................................................................ 66
5.19.- MODEM MENU: STATUS (COMPACT DC 3G, DC-S 3G, DC 2 3G and DC-S BASIC Models) ...................................67
5.20.- MODEM MENU: FACTORY RESET (COMPACT DC 3G, DC-S 3G, DC 2 3G and DC-S BASIC Models).....................67
5.21.- GENERAL MENU: FIREWALL ................................................................................................................................67
5.22.- GENERAL MENU: NETWORK TOOLS ................................................................................................................... 68
5.23.- GENERAL MENU: UPDATE .................................................................................................................................. 68
5.24.- GENERAL MENU: REBOOT.................................................................................................................................. 69
6. TECHNICAL FEATURES..................................................................................................................................................70
7. MAINTENANCE AND TECHNICAL SERVICE....................................................................................................................74
8. WARRANTY....................................................................................................................................................................74
9. CE CERTIFICATE ............................................................................................................................................................75

6
COMPACT DC
Instruction Manual
REVISION LOG
Table 1: Revision log.
Date Revision Description
12/15 M086B01-03-15B Initial Version
08/17 M086B01-03-17A
Changes in the following sections:
1.- 2.- 3.3.1.- 3.3.2.- 3.4.1.- 3.6.- 4.1.1.- 4.1.2.- 4.1.3.- 4.3.- 5.2.2.2.-
5.2.2.3.- 5.20.- 5.21.- 5.22.- 5.23.- 6.
03/22 M086B01-03-22A Changes in the following sections:
1.- 2.- 3.3.- 3.4.- 3.6.- 4.1.- 5.- 6.
Note: The images of the devices are for illustrative purposes only and may differ from the original device.
SYMBOLS
Table 2: Symbols.
Symbol Description
Compliant with the relevant European directive.
Device covered by European Directive 2012/19/EC. At the end of its useful life, do not discard of
the device in a household refuse bin. Follow local regulations on electronic equipment recycling.
Direct current.
~Alternating current.

7
Instruction Manual
COMPACT DC
1.- VERIFICATION UPON RECEPTION
Check the following points when you receive the device:
a) The device meets the specifications described in your order.
b) The device has not suffered any damage during transport.
c) Perform an external visual inspection of the device prior to switching it on.
d) Check that it has been delivered with the following:
- An installation guide,
- COMPACT DC SBT, COMPACT DC-S SBT, COMPACT DC 3G and COMPACT DC-S 3G models,
3 connection terminals.
- COMPACT DC 4I and COMPACT DC-S 4I models, 4 connection terminals.
- COMPACT DC 2 model, 6 connection terminals.
- COMPACT DC-S MINI and COMPACT DC-S BASIC models, 2 connection terminals.
- COMPACT DC 2 3G model, 5 connection terminals.
If any problem is noticed upon reception, immediately contact the transport com-
pany and/or CIRCUTOR's after-sales service.
2.- INTRODUCTION
The COMPACT DC concentrator is a device that manages and reads single-phase and three-phase
energy meters with PRIME communications connected to the same low voltage network.
The COMPACT DC concentrator is typically installed in the transformer substation and enables tele-
management of the energy meters, whether by reading the information they supply or by carrying out
actions on this type of device, such as modifying tariffs, activating the circuit breaker, etc.
There are 10 device models:
COMPACT DC SBT. COMPACT DC-S SBT. COMPACT DC-S BASIC.
COMPACT DC 3G. COMPACT DC-S 3G. COMPACT DC-S MINI.
COMPACT DC 4I. COMPACT DC-S 4I.
COMPACT DC 2. COMPACT DC 2 3G.

8
COMPACT DC
Instruction Manual
The device features:
- Indirect three-phase energy meter with low voltage monitoring functions, LV Monitor. (COMPACT
DC SBT, COMPACT DC 3G, COMPACT DC 4I, COMPACT DC 2, COMPACT DC-S SBT, COMPACT DC-S
3G, COMPACT DC-S 4I and COMPACT DC 2 3G models).
- 1 additional LV monitor: SBT-S (COMPACT DC 2 and COMPACT DC 2 3G Models).
- PLC PRIME communications.
-1 additional PLC PRIME communications: PLC-S (COMPACT DC 2 and COMPACT DC 2 3G Models).
- Ethernet port.
- Indicator LEDs.
- 2 pulse LEDs for active energy and reactive energy (COMPACT DC SBT, COMPACT DC 3G, COMPACT
DC 4I, COMPACT DC-S SBT, COMPACT DC-S 3G and COMPACT DC-S 4I Models).
- 4 pulse LEDs for active energy and reactive energy (COMPACT DC 2 and COMPACT DC 2 3G Models).
- 3G Modem (COMPACT DC-S 3G, COMPACT DC 2 3G and COMPACT DC-S BASIC Models).
- 4 digital inputs (COMPACT DC 4I, COMPACT DC-S 4I and COMPACT DC 2 Models).
The operating specifications of the COMPACT DC concentrator and monitor are defined in the following
documents:
- STG – DC Interface specification (version 3.1.c).
- STG – DC Interface specification (version 3.0).
- Standard companion for communication interfaces (version 1.06).
- Functional specifications for a telemanaged data concentrator (version 3 – Iberdrola).
- Functional specifications for a low voltage monitoring device (version 1.3– Iberdrola).
- Cycle methodology (Iberdrola).
- PRIME network topology (Iberdrola).
- LV concentrator - monitor (ES.04096.ES.RE.EMH – GNF).
In addition to the specifications in these documents, defined primarily by PRIME Alliance, Iberdrola
and Gas Natural Fenosa, the concentrator has other functionalities specific to Circutor. This document
explains the device's operations, in particular operating from the web site.
The COMPACT DC web site is an application that lets users interact with the concentrator. Many oper-
ations can be carried out through the web site:
 Managing energy meters.
Configuring the concentrator's parameters.
 Viewing the network topology map.
 Managing the concentrator's tasks.
 Updating the firmware of both the energy meters and the concentrator.
 Viewing the concentrator's statistics and logs.
 Doing one-off or bulk readings and configurations of energy meters.
 Viewing the current status of the concentrator.

9
Instruction Manual
COMPACT DC
3.- DEVICE INSTALLATION
3.1.- PRELIMINARY RECOMMENDATIONS
In order to use the device safely, it is critical that individuals who handle it follow the
safety measures set out in the standards of the country where it is being used, use the
personal protective equipment necessary, and pay attention to the various warnings
indicated in this instruction manual.
The COMPACT DC device must be installed by authorised and qualified staff.
The power supply plug must be disconnected and measuring systems switched off before handling, al-
tering the connections or replacing the device. It is dangerous to handle the device while it is powered.
Also, it is critical to keep the cables in perfect condition to avoid accidents, personal injury and damage
to installations.
The manufacturer of the device is not responsible for any damage resulting from failure by the user
or installer to heed the warnings and/or recommendations set out in this manual, nor for damage
resulting from the use of products or accessories that did not come with the device or that were made
by other manufacturers.
If an anomaly or malfunction is detected in the device, do not use the device to take any measurements.
Inspect the work area before taking any measurements. Do not take measurements in dangerous areas
or where there is a risk of explosion.
Disconnect the device from the power supply (device and measuring system power
supply) before maintaining, repairing or handling the device's connections.
Please contact the after-sales service if you suspect that there is an operational fault
in the device.

10
COMPACT DC
Instruction Manual
3.2.- INSTALLATION
The COMPACT DC is designed to be assembled on a DIN rail, with standard fixing points to attach it to
the rail.
Terminals, opening roofs or removing elements can expose parts that are hazardous to
the touch while the device is powered. Do not use the device until it is fully installed.
To connect the device, always start by connecting the neutral before the phases and
to disconnect it, firstly remove the phases and then the neutral. Otherwise, the device
could be damaged if there is voltage present during this process.
Warning: all the terminals must be fixed with side fixing screws to avoid false contacts.
3.3.- DEVICE TERMINALS
3.3.1.- COMPACT DC SBT, DC-S SBT, DC 3G and DC-S 3G MODELS
Table 3:List of COMPACT DC SBT, DC-S SBT, DC 3G and DC-S 3G terminals.
COMPACT DC SBT, DC-S SBT, DC 3G and DC-S 3G terminals
1: L, Auxiliary power supply 9: RR, S2 current output L1
2: N, Auxiliary power supply 10: S, S1 current input L2
3: L1, PLC connection 11: Vs, Voltage input L2
4: L2, PLC connection 12: SS, S2 current output L2
5: L3, PLC connection 13: T, S1 current input L3
6: N, PLC connection 14: Vt, Voltage input L3
7: R, S1 current input L1 15: TT, S2 current output L3
8: Vr, Voltage input L1 16: N, Voltage input neutral
L
N
L1
L2
L3
N
R
Vr
RR
S
Vs
SS
T
Vt
TT
N
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Figure 1:COMPACT DC SBT, DC-S SBT, DC 3G and DC-S 3G terminals.

11
Instruction Manual
COMPACT DC
3.3.2.- COMPACT DC 4I and DC-S 4I MODELS
Table 4:List of COMPACT DC 4I and DC-S 4I terminals.
COMPACT DC 4I and DC-S 4I terminals
1: L, Auxiliary power supply 12: SS, S2 current output L2
2: N, Auxiliary power supply 13: T, S1 current input L3
3: L1, PLC connection 14: Vt, Voltage input L3
4: L2, PLC connection 15: TT, S2 current output L3
5: L3, PLC connection 16: N, Voltage input neutral
6: N, PLC connection 17: ED1, + Digital input 1
7: R, S1 current input L1 18: CED,- Common digital inputs
8: Vr, Voltage input L1 19: ED2, + Digital input 2
9: RR, S2 current output L1 20: ED3, + Digital input 3
10: S, S1 current input L2 21: CED,- Common digital inputs
11: Vs, Voltage input L2 22: ED4, + Digital input 4
L
N
L1
L2
L3
N
R
Vr
RR
S
Vs
SS
T
Vt
TT
N
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ED1
CED
ED2
ED3
CED
ED4
17
18
19
20
21
22
Figure 2:COMPACT DC 4I and DC-S 4I terminals.

12
COMPACT DC
Instruction Manual
3.3.3.- COMPACT DC 2 MODEL
Table 5:List of COMPACT DC 2 terminals.
COMPACT DC 2 terminals
1: L, Auxiliary power supply 19: TT, SBT: S2 current output L3
2: N, Auxiliary power supply 20: N, SBT: Voltage input neutral
3: L1, PLC : PLC connection 21: R, SBT-S: S1 current input L1
4: L2, PLC : PLC connection 22: Vr, SBT-S: Voltage input L1
5: L3, PLC : PLC connection 23: RR, SBT-S: S2 current output L1
6: N, PLC : PLC connection 24: S, SBT-S: S1 current input L2
7: L1, PLC-S : PLC connection 25: Vs, SBT-S: Voltage input L2
8: L2, PLC-S : PLC connection 26: SS, SBT-S: S2 current output L2
9: L3, PLC-S : PLC connection 27: T, SBT-S: S1 current input L3
10: N, PLC-S : PLC connection 28: Vt, SBT-S: Voltage input L3
11: R, SBT: S1 current input L1 29: TT, SBT-S: S2 current output L3
12: Vr, SBT: Voltage input L1 30: N, SBT-S: Voltage input neutral
13: RR, SBT: S2 current output L1 31: ED1, + Digital input 1
14: S, SBT: S1 current input L2 32: CED, - Common digital inputs
15: Vs, SBT: Voltage input L2 33: ED2, + Digital input 2
16: SS, SBT: S2 current output L2 34: ED3, + Digital input 3
17: T, SBT: S1 current input L3 35: CED, - Common digital inputs
18: Vt, SBT: Voltage input L3 36: ED4, + Digital input 4
7
8
9
10
11
12
13
14
15
16
17
18
19
20
L
N
1
2
3
4
5
6
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Figure 3:COMPACT DC 2 terminals.

13
Instruction Manual
COMPACT DC
3.3.4.- COMPACT DC 2 3G MODELS
Table 6:List of COMPACT DC 2 3G terminals.
COMPACT DC 2 3G terminals
1: L, Auxiliary power supply 16: SS, SBT: S2 current output L2
2: N, Auxiliary power supply 17: T, SBT: S1 current input L3
3: L1, PLC : PLC connection 18: Vt, SBT: Voltage input L3
4: L2, PLC : PLC connection 19: TT, SBT: S2 current output L3
5: L3, PLC : PLC connection 20: N, SBT: Voltage input neutral
6: N, PLC : PLC connection 21: R, SBT-S: S1 current input L1
7: L1, PLC-S : PLC connection 22: Vr, SBT-S: Voltage input L1
8: L2, PLC-S : PLC connection 23: RR, SBT-S: S2 current output L1
9: L3, PLC-S : PLC connection 24: S, SBT-S: S1 current input L2
10: N, PLC-S : PLC connection 25: Vs, SBT-S: Voltage input L2
11: R, SBT: S1 current input L1 26: SS, SBT-S: S2 current output L2
12: Vr, SBT: Voltage input L1 27: T, SBT-S: S1 current input L3
13: RR, SBT: S2 current output L1 28: Vt, SBT-S: Voltage input L3
14: S, SBT: S1 current input L2 29: TT, SBT-S: S2 current output L3
15: Vs, SBT: Voltage input L2 30: N, SBT-S: Voltage input neutral
7
8
9
10
11
12
13
14
15
16
17
18
19
20
L
N
1
2
3
4
5
6
21
22
23
24
25
26
27
28
29
30
Figure 4:COMPACT DC 2 3G terminals.

14
COMPACT DC
Instruction Manual
3.3.5.- COMPACT DC-S BASIC MODEL
Table 7:List of COMPACT DC-S BASIC terminals.
COMPACT DC-S BASIC terminals
1: L, Auxiliary power supply 4: L2, PLC connection
2: N, Auxiliary power supply 5: L3, PLC connection
3: L1, PLC connection 6: N, PLC connection
L
N
L1
L2
L3
N
1
2
3
4
5
6
Figure 5:COMPACT DC-S BASIC terminals.
3.3.6.- COMPACT DCS MINI MODEL
Table 8:List of COMPACT DC-S MINI terminals.
COMPACT DC-S MINI terminals
1: L, Auxiliary power supply 4: L2, PLC connection
2: N, Auxiliary power supply 5: L3, PLC connection
3: L1, PLC connection 6: N, PLC connection
1
2
3
4
5
6
Figure 6: COMPACT DC-S MINI terminals.

15
Instruction Manual
COMPACT DC
3.4.- CONNECTION DIAGRAMS
3.4.1.- COMPACT DC SBT, DCS SBT, DC 3G, DCS 3G, DC 4I AND DCS 4I MODELS
L1
L1
L2
L3
N
CARGA / LOAD
L
N
L1
L2
L3
N
R
Vr
RR
S
Vs
SS
T
Vt
TT
N
S1
S2
P1P2
S1
S2
P1P2
S1
S2
P1P2
ALIMENTACIÓN AUXILIAR
POWER SUPPLY
L2
L N
L3
N
Vr Vs Vt NTT TSS S RR R
Figure 7: Three-phase measuring with a 4-wire connection (COMPACT DC SBT, DC-S SBT, DC 3G, DC-S 3G, DC 4I and DC-S 4I).

16
COMPACT DC
Instruction Manual
3.4.2.- COMPACT DC 2 AND DC 2 3G MODELS
L
N
ALIMENTACIÓN AUXILIAR
POWER SUPPLY
L1
L2
L3
N
CARGA / LOAD
S2
S1
P2P1
S2
S1
P2P1
S2
S1
P2P1
L2
L N
L3
N
Vr Vs Vt N
TTT
SSS
RRR
L1
L1
L2
L3
N
CARGA / LOAD
S1
S2
P1P2
S1
S2
P1P2
S1
S2
P1P2
Vr
Vs
Vt
N
R
RR
S
SS
T
TT
Figure 8: Power supply, SBT and PLC connections (COMPACT DC 2 and DC 2 3G).
L1
L2
L3
N
CARGA / LOAD
S2
S1
P2P1
S2
S1
P2P1
S2
S1
P2P1
L1
L2
L3
N
Vr Vs
Vt N
R RR S SS
TTT
Figure 9: SBT-S and PLC-S connections (COMPACT DC 2 and DC 2 3G).

17
Instruction Manual
COMPACT DC
3.4.3.- COMPACT DCS BASIC AND DCS MINI MODELS
L1
L1
L2
L3
N
CARGA / LOAD
L
N
L1
L2
L3
N
POWER SUPPLY
L2
L N
L3
N
ALIMENTACIÓN AUXILIAR
Figure 10: Three-phase measuring with a 4-wire connection (COMPACT DC-S BASIC and DC-S MINI).
3.5.- ETHERNET PORT CONNECTION
The COMPACT DC concentrator has one Ethernet port.This type of communication creates an intranet
with IP communications. A modem-router, switch or computer can be connected to this port.
If the device connected to this port is a computer, the network cable must be a crossover Ethernet
cable, as shown in Figure 11.
Figure 11:RJ-45 connector: Crossover Ethernet connection diagram.

18
COMPACT DC
Instruction Manual
3.6.- SIM CARD INSTALLATION (COMPACT DC 3G, DC-S 3G, DC 2 3G and DC-S BASIC Models)
The COMPACT DC 3G, DC-S 3G, DC 2 3G and DC-S BASIC models has 3G so the device can be connect-
ed to and exchange data with other mobile devices without the need for a Wi-Fi connection.
The only requirement is 2 SIM cards.
To avoid electric shocks, disconnect the measuring and power supply terminals before
opening the device's cover.
Do not use the device without the cover in place.
The SIM cards are located under the MODEM-3G module and are installed as indicated in the following
steps:
1.- Remove the cover from the MODEM-3G module by sliding a flathead screwdriver into the anchor
slots. (Figure 12)
Figure 12:SIM card installation (Step 1)
2.- Insert the SIM cards into the slots provided for them. (Figure 13)
Figure 13:SIM card installation (Step 2)
3.- Replace the cover on the MODEM-3G module.

19
Instruction Manual
COMPACT DC
4.- OPERATION
4.1.- LED INDICATORS
The LED indicators that provide information on the concentrator status are located on the front panel.
4.1.1.- COMPACT DC SBT AND DC-S SBT MODELS
CPU PLC SBT
Power Power
PLC.Link
SBT.Link
ETH 1
R
Power
PLC.TX
PLC.RX
Power
20.000
imp/kWh
20.000
imp/kvarh
COMPACT DC SBT
2
3
4
5
1
67
8
ETH 1
10kV
iso
Figure 14:COMPACT DC SBT and DC-S SBT indicator LEDs
Table 9: Description of the LEDs, COMPACT DC SBT and DC-S SBT.
LED Description
1 Power Power supply to each of the modules: CPU, PLC and SBT.
2 PLC.Link Indicates whether there is connectivity with the PLC module
3 SBT.Link Indicates whether there is connectivity with the SBT module
4 ETH 1 Indicates whether there is an Ethernet connection
5 PLC.TX Concentrator output frame indication
6 PLC.RX Concentrator input frame indication
7 20000 imp/kWh Active energy pulses
8 20000 imp/kVArh Reactive energy pulses

20
COMPACT DC
Instruction Manual
4.1.2.- COMPACT DC 3G AND DC-S 3G MODELS
CPU PLC SBT MODEM-3G
Power Power
PLC.Link
SBT.Link
EXT.Link
ETH 1
R
Power
PLC.TX
PLC.RX
Power
20.000
imp/kWh
20.000
imp/kvarh
Power
Status
SIM1
SIM2
Coverage
COMPACT DC 3G
2
3
4
5
6
1
78
9
10
11
12
13
ETH 1
10kV
iso
Figure 15:COMPACT DC 3G and DC-S 3G indicator LEDs
Table 10: Description of the LEDs, COMPACT DC 3G and DC-S 3G.
LED Description
1 Power Power supply to each of the modules: CPU, PLC, SBT and MODEM-3G.
2 PLC.Link Indicates whether there is connectivity with the PLC module
3 SBT.Link Indicates whether there is connectivity with the SBT module
4 EXT.Link Indicates whether there is connectivity with the MODEM-3G module
5 ETH 1 Indicates whether there is an Ethernet connection
6 PLC.TX Concentrator output frame indication
7 PLC.RX Concentrator input frame indication
8 20000 imp/kWh Active energy pulses
9 20000 imp/kVArh Reactive energy pulses
10 Status
Indicates if the modem is connected to a telephone network
Power on
Connection established
Flashing
Negotiating connection
11 SIM 1
SIM card detected in bay 1
Power on
Inserted and operating correctly
Power off
SIM card not detected or not working
