INSTRUCTION MANUAL

(M136B01-03-20A)

Power analyzer

CVM-A1000 CVM-A1500

MEASURING EQUIPMENT

E237816

CVM-A1000 - CVM-A1500

Instruction Manual

SAFETY PRECAUTIONS

DISCLAIMER

CIRCUTOR, SA reserves the right to make modi cations to the device or the unit speci ca-

tions set out in this instruction manual without prior notice.

CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the device

speci cations and the most updated manuals.

www.circutor.com

CIRCUTOR, recommends using the original cables and accessories that are

supplied with the device.

DANGER

Warns of a risk, which could result in personal injury or material damage.

ATTENTION

Indicates that special attention should be paid to a speci c point.

Follow the warnings described in this manual with the symbols shown below.

If you must handle the unit for its installation, start-up or maintenance, the following

should be taken into consideration:

Incorrect handling or installation of the unit may result in injury to personnel as well as damage

to the unit. In particular, handling with voltages applied may result in electric shock, which may

cause death or serious injury to personnel. Defective installation or maintenance may also

lead to the risk of  re.

Read the manual carefully prior to connecting the unit. Follow all installation and maintenance

instructions throughout the unit’s working life. Pay special attention to the installation stan-

dards of the National Electrical Code.

Refer to the instruction manual before using the unit

In this manual, if the instructions marked with this symbol are not respected or carried out correctly, it can

result in injury or damage to the unit and /or installations.

CIRCUTOR, SA reserves the right to modify features or the product manual without prior noti cation.

Instruction Manual

CVM-A1000 - CVM-A1500

CONTENTS

SAFETY PRECAUTIONS ��3

DISCLAIMER ��3

CONTENTS��4

REVISION LOG��8

SYMBOLS��8

1�- VERIFICATION UPON RECEPTION�� 9

2�- PRODUCT DESCRIPTION��9

3�- DEVICE INSTALLATION �� 11

3�1�- PRIOR RECOMMENDATIONS�� 11

3�2�- INSTALLATION �� 11

3�3�- CVM-A1x00-FLEX: ROGOWSKI SENSORS��12

3�4�- DEVICE TERMINALS��13

3�4�1�- TERMINALS ON THE UPPER FACE �� 13

3�4�2�- TERMINALS ON THE LOWER FACE�� 14

3�5�- CONNECTION DIAGRAMS ��15

3�5�1�- THREE-PHASE NETWORK MEASUREMENT WITH A 4-WIRE CONNECTION

(CVM-A1x00-ITF)��15

3�5�2�- THREE-PHASE NETWORK MEASUREMENT WITH A 4-WIRE CONNECTION

(CVM-A1x00-FLEX)�� 17

3�5�3�- THREE-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION

(CVM-A1x00-ITF)� ��18

3�5�4�- THREE-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION (CVM-A1x00-

FLEX)� ��20

3�5�5�- THREE-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION AND 3 VOLTAGE

TRANSFORMERS (CVM-A1x00-ITF)� �� 21

3�5�6�- THREE-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION AND 3 VOLTAGE

TRANSFORMERS (CVM-A1x00-FLEX)� �� 22

3�5�7�- THREE-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION AND TRANS-

FORMERS WITH AN ARON CONNECTION (CVM-A1x00-ITF)�� 23

3�5�8�- TWO-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION (CVM-A1x00-ITF)� � 24

3�5�9�- TWO-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION

(CVM-A1x00-FLEX)��25

3�5�10�- SINGLE-PHASE NETWORK MEASUREMENT, PHASE TO PHASE, WITH A 2-WIRE CONNEC-

TION (CVM-A1x00-ITF)� �� 26

3�5�11�- SINGLE-PHASE NETWORK MEASUREMENT, PHASE TO PHASE, WITH A 2-WIRE CONNEC-

TION (CVM-A1x00-FLEX)� �� 27

3�5�12�- SINGLE-PHASE NETWORK MEASUREMENT, PHASE TO NEUTRAL, WITH A 2-WIRE CON-

NECTION (CVM-A1x00-ITF)� �� 28

3�5�13�- SINGLE-PHASE NETWORK MEASUREMENT, PHASE TO NEUTRAL, WITH A 2-WIRE CON-

NECTION (CVM-A1x00-FLEX)�� 29

3�6�- STARTING UP THE DEVICE��30

4�- OPERATION ��36

4�1�- OPERATING PRINCIPLE��36

4�2�- MEASUREMENT PARAMETERS �� 37

4�2�1�- QUALITY PARAMETERS �� 38

4�2�2�- EVENT LOGGING �� 40

4�3�- KEYPAD FUNCTIONS��47

4�4�- DISPLAY ��48

4�4�1�- UPPER AREA��48

4�4�2�- LOWER AREA��49

4�4�3�- CENTRAL AREA �� 50

4�5�- LED INDICATORS��53

4�6�- INPUTS ��53

4�7�- OUTPUTS ��54

4�8�- DATALOGGER MODULE: DATA STORAGE ��54

4�8�1�- CONNECTION TERMINALS �� 54

4�8�2�- LEDs ��54

4�8�3�- CONNECTION DIAGRAM�� 55

5�- DISPLAY AND CONFIGURATION �� 56

CVM-A1000 - CVM-A1500

Instruction Manual

5�1�-MEASUREMENT DISPLAY MENU ��57

5�1�1�- DISPLAY 1 PARAMETER� �� 58

5�1�2�- DISPLAY 3 PARAMETERS� �� 86

5�1�3�- DISPLAY 4 PARAMETERS� �� 104

5�1�4�- QUALITY PARAMETERS�� 122

5�1�5�- PHASORS� �� 126

5�1�6�- STANDARD PHASORS� �� 127

5�1�7�- HARMONICS� �� 128

5�1�8�- OSCILLOSCOPE�� 130

5�1�9�- INTEGRATED FUNCTIONS� �� 131

5�1�10�- EXPANSION MODULES� �� 132

5�2�- QUALITY MENU ��134

5�2�1�- QUALITY EVENTS� �� 135

5�2�2�- TRANSIENTS� ��142

5�2�3�- EVENT CHARTS� �� 145

5�2�4�- TABLE DISPLAY� �� 149

5�3�- ENERGY CLOSES MENU ��150

5�3�1�- ACTIVE ENERGY CLOSES III OF THE TOTAL TARIFF AND OF REACTIVE ENERGY III OF THE

TOTAL TARIFF�� 151

5�4�- ALARM MENU ��153

5�5�- LOG MENU ��155

5�5�1�- ALARM LOG��156

5�5�2�- EVENT LOG ��158

5�6�- INFORMATION MENU ��159

5�6�1�- SYSTEM INFORMATION� �� 160

5�6�2�- INTEGRATED FUNCTIONS� �� 161

5�6�3�- EXPANSION MODULES� �� 162

5�6�4�- QUALITY �� 173

5�6�5�- CIRCUTOR S�A� ��175

5�7�- SETUP MENU ��176

5�7�1�- DATE AND TIME� �� 179

5�7�2�- TIME ZONE��180

5�7�3�- LANGUAGE��181

5�7�4�- ACCESS KEY� ��182

5�7�5�- MEASUREMENT CONNECTION MODE� �� 183

5�7�6�- RATIO OF VOLTAGE TRANSFORMERS� �� 184

5�7�7�- RATIO OF CURRENT TRANSFORMERS� ��185

5�7�8�- INSTALLATION DATA�� 187

5�7�9�- QUALITY �� 188

5�7�10�- DISPLAY OF VARIABLES� �� 192

5�7�11�- DEMAND�� 193

5�7�12�- ENERGY CONSUMPTION COSTS�� 194

5�7�13�- ENERGY GENERATION COSTS� �� 195

5�7�14�- CO2CONSUMPTION EMISSIONS�� 196

5�7�15�- CO2GENERATION EMISSIONS��198

5�7�16�- RELAY DIGITAL OUTPUTS� �� 199

5�7�17�- TRANSISTOR DIGITAL OUTPUTS�� 205

5�7�18�- DIGITAL INPUTS�� 211

5�7�19�- INTEGRATED COMMUNICATIONS��215

5�7�20�- PARAMETER RESET� �� 219

5�7�21�- USER INTERFACE�� 220

6�- INTEGRATED COMMUNICATIONS��227

6�1�- CONNECTIONS��227

6�2�- MODBUS PROTOCOL��228

6�2�1�- EXAMPLE OF MODBUS QUERY �� 228

6�3�- MODBUS MEMORY MAP ��229

6�3�1�- MEASUREMENT VARIABLES �� 229

6�3�2�- CURRENT ENERGY VARIABLES �� 231

6�3�3�- MAXIMUM DEMAND VARIABLES �� 235

6�3�4�- VOLTAGE AND CURRENT HARMONICS��235

6�3�5�- COST VARIABLES�� 239

6�3�6�- ANGLE VARIABLES �� 239

Instruction Manual

CVM-A1000 - CVM-A1500

6�3�7�- QUALITY VARIABLES�� 239

6�3�8�- QUALITY EVENT AND DISTURBANCE METERS �� 240

6�3�9�- QUALITY EVENTS ALARM FLAG �� 240

6�3�10�- DEVICE CONFIGURATION VARIABLES �� 241

6�3�11�- OTHER DEVICE VARIABLES�� 255

6�3�12�- DELETING PARAMETERS �� 258

6�4�- BACnet PROTOCOL�� 259

6�5�- PICS MAP�� 260

7�- EXPANSION MODULES �� 263

7�1�- INSTALLATION �� 263

7�2�- RELAY DIGITAL INPUTS/OUTPUTS �� 265

7�2�1�- CONNECTION TERMINALS �� 265

7�2�2�- CONNECTION DIAGRAMS �� 266

7�2�3�- CONFIGURATION �� 267

7�2�4�- MODBUS COMMUNICATIONS�� 271

7�3�- TRANSISTOR DIGITAL INPUTS/OUTPUTS �� 278

7�3�1�- CONNECTION TERMINALS �� 278

7�3�2�- CONNECTION DIAGRAMS �� 279

7�3�3�- CONFIGURATION �� 280

7�3�4�- COMUNICACIONES MODBUS�� 282

7�4�- ANALOGUE INPUTS/OUTPUTS �� 293

7�4�1�- CONNECTION TERMINALS �� 293

7�4�2�- CONNECTION DIAGRAMS �� 295

7�4�3�- CONFIGURATION �� 296

7�4�4�- MODBUS COMMUNICATIONS�� 302

7�5�- MODBUS/TCP BRIDGE COMMUNICATIONS MODULE �� 307

7�5�1�- CONNECTION TERMINALS �� 307

7�5�2�- LEDs �� 307

7�5�3�- CONNECTION DIAGRAM�� 308

7�5�4�- CONFIGURATION �� 308

7�5�5�- MODBUS COMMUNICATIONS�� 313

7�6�- LONWORKS COMMUNICATIONS MODULE�� 315

7�6�1�- CONNECTION TERMINALS �� 315

7�6�2�- CONNECTION DIAGRAM�� 315

7�6�3�- CONFIGURATION �� 316

7�6�4�- MODBUS COMMUNICATIONS�� 318

7�6�5�- LIST OF LONWORKS LOGS�� 318

7�7�- PROFIBUS COMMUNICATIONS MODULE�� 326

7�7�1�- CONNECTION TERMINALS �� 326

7�7�2�- LEDs �� 326

7�7�3�- CONNECTION DIAGRAM�� 327

7�7�4�- CONFIGURATION �� 328

7�7�5�- VARIABLES PROFIBUS GSD FILE �� 329

7�8�- MBUS COMMUNICATIONS MODULE�� 335

7�8�1�- CONNECTION TERMINALS �� 335

7�8�2�- CONNECTION DIAGRAM�� 335

7�8�3�- CONFIGURATION �� 336

7�8�4�- MODBUS COMMUNICATIONS�� 337

7�8�5�- M-BUS COMMUNICATIONS�� 338

7�9�- MODBUS/TCP Switch COMMUNICATIONS MODULE �� 340

7�9�1�- CONNECTION TERMINALS �� 340

7�9�2�- LEDs �� 340

7�9�3�- CONNECTION DIAGRAM�� 341

7�9�4�- CONFIGURATION �� 341

7�9�5�- MODBUS COMMUNICATIONS�� 345

8�- SOFTWARE UPDATE �� 346

8�1�- DEVICE SOFTWARE UPDATE�� 347

8�2�- UPGRADING THE FIRMWARE OF THE DATALOGGER MODULE�� 347

8�3�- EXPANSION MODULES UPDATE�� 349

9�- TECHNICAL FEATURES �� 350

10�- TECHNICAL FEATURES OF EXPANSION MODULES�� 355

CVM-A1000 - CVM-A1500

Instruction Manual

10�1�- TRANSISTOR DIGITAL INPUTS/OUTPUTS �� 355

10�2�- RELAY DIGITAL INPUTS/OUTPUTS �� 356

10�3�- ANALOGUE INPUTS/OUTPUTS �� 357

10�4�- MODBUS TCP (Bridge) COMMUNICATIONS�� 358

10�5�- LONWORKS COMMUNICATIONS �� 359

10�6�- PROFIBUS COMMUNICATIONS �� 360

10�7�- MBUS COMMUNICATIONS �� 361

10�8�- MODBUS TCP (Switch) COMMUNICATIONS�� 362

11�- MAINTENANCE AND TECHNICAL SERVICE�� 363

12�- GUARANTEE�� 363

13�- CE CERTIFICATE�� 364

ANNEX A: XML SERVICES�� 367

A�1�- /services/user/devices�xml �� 367

A�2�- /services/user/deviceInfo�xml?id=device?�� 367

A�3�- /services/user/varInfo�xml?var=device�variable?��?id=device?�� 368

A�4�- /services/user/values�xml?var=device�variable?��?id=device?�� 370

A�5�-/services/user/forceVariables�xml?id=device �� 370

A�6�-/services/user/records�xml?begin=…?end=…?var=…?period=900�� 371

A�7�-/services/user/events�xml?begin=…?end=…?id=… �� 374

A�8�-/services/user/recordsEve�xml?begin=…?end=…?id=… �� 375

Instruction Manual

CVM-A1000 - CVM-A1500

REVISION LOG

Table 1: Revision log�

Date Revision Description

05/17 M136B01-03-16A Initial Version

10/17 M136B01-03-17A Changes in the following sections:

3.5. - 7.7. - 8.

12/17 M136B01-03-17B Changes in the following sections:

7.3.2.

03/18 M136B01-03-18A Changes in the following sections:

5.2.1.1.1.- 5.2.3. - 9.-10.

06/18 M136B01-03-18B Changes in the following sections:

4.2.2. - 4.2.2.3.

08/18 M136B01-03-18C Changes in the following sections:

2. - 4.2.2.3. - 4.5. - 5.2.1.1.1.2. - 5.2.3.2. - 5.7.7. - 6.3.1. - 6.3.4. - 6.3.10.6.

01/19 M136B01-03-19A

Changes in the following sections:

2. - 3.3. - 3.4.2. - 3.5. - 4.2.1. - 4.2.2.3 - 5.1.1.1.1. - 5.1.2.1.1. - 5.1.3.1.1. - 5.1.7.-

5.7.5. - 5.7.7. - 6.3.1. - 6.3.10.5. - 6.3.10.6. - 6.3.10.20. - 6.3.12. - 9. - 10.1

09/19 M136B01-03-19B

Changes in the following sections:

2.- 3.6. - 4.2. - 4.2.2.2.- 4.2.2.3.- 4.4.3. - 5.1.1.2.1.1.4.- 5.1.4.- 5.1.4.1.- 5.1.4.1.1.

- 5.2.1.1.2. - 5.2.2.1.1. - 5.6. - 5.6.4. - 5.6.5. - 5.7.3. - 5.7.9. - 5.7.9.3. - 5.7.16. -

6.3.7. - 6.3.10.3. - 6.3.10.7. - 6.3.10.10. - 6.3.10.13.- 9.

05/20 M136B01-03-20A Changes in the following sections:

Note: Device images are for illustrative purposes only and may differ from the actual device.

SYMBOLS

Table 2: Symbols�

Symbol Description

In compliance with the relevant European directive.

According to direct CMiM

Safety category of the device : Class II

Device covered by European directive 2012/19/EC. At the end of its useful life, do not

leave the device in a household waste container. Follow local regulations on electronic

equipment recycling.

DC current

~AC current

UL certied

CVM-A1000 - CVM-A1500

Instruction Manual

1�- VERIFICATION UPON RECEPTION

Check the following points upon receiving the device:

a) The device meets the specications described in your order.

b) The device has not suffered any damage during transport.

c) Perform an external visual inspection of the device prior to switching it on.

d) Check that it has been delivered with the following:

- An installation guide,

- 4 Retainers used to attach the device,

- 5 plug-in connectors with screws,

- 1 seal,

If any problem is noticed upon reception, immediately contact the transport

company and/or CIRCUTOR's after-sales service.

2�- PRODUCT DESCRIPTION

The CVM-A measures, calculates, displays and records the main electrical parameters and

the quality parameters in single-phase networks, two-phase networks with and without neutral,

balanced three-phase networks, with ARON (1) measurement or unbalanced. The measurement

is taken in TRMS, via four AC voltage inputs and four or three current inputs (according to ver-

sion).

There are 2 device models:

CVM-A1000, with a 3.5’’ display.

CVM-A1500, with a 5.6’’ display.

There are 2 versions of the device depending on the current input:

CVM-A1x00-ITF, the current is indirectly measured using /5, /1 A transformers or efcient

MC1 and MC3 series transformers and an input for neutral current measurement.

CVM-A1x00-FLEX, current measurement using Rogowski sensors. As there is no meas-

urement input, the device calculates the neutral current.

(1)The CVM-A1x00-FLEX version includes an ARON connection.

Instruction Manual

CVM-A1000 - CVM-A1500

It is a modular device that can be expanded using expansion modules with different functions.

The device features:

- 3 keys that allow you to browse between the various screens and program the device.

- 3 indicator LEDs: CPU, ALARM and on the navigation keys.

- LCD Display, for displaying all parameters.

- 2 digital inputs, to select the tariff, detect the logic state of external signals or as act

as an impulse input.

- 2 transistor digital outputs, fully programmable.

- 2 relay digital outputs, fully programmable.

- RS-485 communications, with two serial protocols: MODBUS RTU ® and BACnet.

- Built-in Datalogger module, which can be used to check data via a conventional web

browser. The PowerStudio external software is needed to download the data to a PC or

server.

The CVM-A can be expanded with the following expansion modules:

 M-CVM-AB-8I-8OTR, expansion module with 8 transistor digital inputs and 8 tran-

sistor digital outputs.

M-CVM-AB-8I-8OR, expansion module with 8 relay digital inputs and 8 relay digital

outputs.

M-CVM-AB-4AI-8AO, expansion module with 4 analogue inputs and 8 analogue out

puts.

M-CVM-AB-Modbus/TCP(Bridge), expansion module for connecting the device to a

Modbus/TCP network and as an Ethernet to RS-485 gateway.

M-CVM-AB-LON, expansion module for connecting the device to a LonWorks net-

work.

M-CVM-AB-Probus, expansion module for connecting the device to a Probus net-

work.

M-CVM-AB-MBus, expansion module for connecting the device to a M-Bus network.

M-CVM-AB-Modbus/TCP(Switch), expansion module for connecting the device to a

Modbus/TCP network and as an Ethernet to Ethernet gateway.

CVM-A1000 - CVM-A1500

Instruction Manual

3�- DEVICE INSTALLATION

3.1.- PRIOR RECOMMENDATIONS

In order to use the device safely, it is critical that individuals who handle it follow

the safety measures set out in the standards of the country where it is being used,

use the necessary personal protective equipment, and pay attention to the vari-

ous warnings indicated in this instruction manual.

The CVM-A device must be installed by authorised and qualied staff.

The power supply plug must be disconnected and measuring systems switched off before

handling, altering the connections or replacing the device. It is dangerous to handle the device

while it is powered.

Also, it is critical to keep the cables in perfect condition in order to avoid accidents, personal

injury and damage to installations.

The manufacturer of the device is not responsible for any damage resulting from failure by the

user or installer to observe the warnings and/or recommendations set out in this manual, nor for

damage resulting from the use of non-original products or accessories or those made by other

manufacturers.

If an anomaly or malfunction is detected in the device, do not use it to take any measurements.

Inspect the work area before taking any measurements. Do not take measurements in danger-

ous areas or where there is a risk of explosion.

Disconnect the device from the power supply (device and measuring system

power supply) before maintaining, repairing or handling the device's connections.

Please contact the after-sales service if you suspect that there is an operational

fault in the device.

3.2.- INSTALLATION

The device is installed on a panel. All connections are located inside the electric panel.

Table 3: Panel drill holes for installation�

Model Panel drill hole (according to DIN 43700)

CVM-A1000 92+0.8 x 92+0.8 mm

CVM-A1500 138+0.8 x 138+0.8 mm

Terminals, opening covers or removing elements can expose parts that are haz-

ardous to the touch while the device is powered. Do not use the device until it is

fully installed.

Instruction Manual

CVM-A1000 - CVM-A1500

The device must be connected to a power circuit that is protected with gL fuses (IEC 269) or

M fuses, with a rating of 1 to 2 A. It must be tted with a circuit breaker or equivalent device for

disconnecting the device from the power supply mains.

The power and voltage measuring circuit must be connected with cables that have a minimum

cross-section of 1mm2 and the wires must to endure a temperature at least 77 degrees.

The secondary line of the current transformer will have a minimum cross-section of 2.5 mm2.

Current needs to be measured via external current transformers providing reinforced insulation.

3.3.- CVM-A1x00-FLEX: ROGOWSKI SENSORS

The CVM-A1x00-FLEX model measures currents using exible sensors, based on the Ro-

gowski coil principle.

The exibility of the sensor allows it to measure an alternating current irrespective of the posi-

tion of the conductor.

CIRCUTOR has a Rogowski sensor model that can be used with the CVM-A1x00-FLEX�

Table 5 shows the connection of the sensors and Table 4 the maximum position error.

Note: For more information, consult the corresponding sensor guide.

Table 4:Position error�

Position Error

A± 1%

BA ± 3%

Table 5:Probe cable terminal connections

Probe cable terminal connections

FLEX-MAG

Canal de medida / Measuring channel

Común / Common

Shield

Black : Shield (SHLD)

Blue: Common (C)

Green: Measuring channel (L1, L2, L3, N)

CVM-A1000 - CVM-A1500

Instruction Manual

3.4.- DEVICE TERMINALS

The CVM-A terminals are distributed between the upper and lower face of the device.

3�4�1�- TERMINALS ON THE UPPER FACE

Table 6:List of terminals on the upper face of the CVM-A�

Terminals of the top side of the device

1: VREF, Reference voltage input 10: T1, Digital output of transistor 1

2: NREF, Reference voltage neutral 11: T2, Digital output of transistor 2

3: N, Voltage input neutral 12: TC, Common digital output of transistor

4: VL3,Voltage input L3 13: A(+), RS485

5: VL2, Voltage input L2 14: B(-), RS485

6: VL1, Voltage input L1 15: S, GND for RS-485

7: I1, Digital input 1 16, 17: R1, Relay digital output 1

8: I2, Digital input 2 18, 19: R2, Relay digital output 2

9: Ic, GND for digital inputs 20: Ethernet

1234 5 6

11 13

16 17 18 19

Figure 1: CVM-A terminals, upper face�

Instruction Manual

CVM-A1000 - CVM-A1500

3�4�2�- TERMINALS ON THE LOWER FACE

21 22

23 24 25 26 27 28 29 30

Figure 2:CVM-A terminals, lower face�

3�4�2�1�- CVM-A1x00-ITF Model

Table 7:List of terminals on the lower face of the CVM-A1x00-ITF�

Device terminals

21 : Auxiliary power supply.

~ +, CVM-Axxxx-ITF

-, CVM-Axxxx-ITF-SDC

26: S2, Current input L2

22: Auxiliary power supply.

~ -, CVM-Axxxx-ITF

+, CVM-Axxxx-ITF-SDC

27: S1 , Current input L3

23: S1 , Current input L1 28: S2, Current input L3

24: S2, Current input L1 29: S1, Neutral current input, LN

25: S1 , Current input L2 30: S2, Neutral current input, LN

3�4�2�2�- CVM-A1x00-FLEX Model

Table 8:List of terminals on the lower face of the CVM-A1x00-FLEX�

Bornes del equipo

21 : Auxiliary power supply.

~+, CVM-Axxxx-ITF

-, CVM-Axxxx-ITF-SDC

26: C2, Common for Current input L2

22: Auxiliary power supply.

~-, CVM-Axxxx-ITF

+, CVM-Axxxx-ITF-SDC

27: L3 , Current input L3

23: L1, , Current input L1 28: C3, Common for Current input L3

24: C1, Common for Current input L1

29, 30: SHLD, GND for current inputs

25: L2, Current input L2

CVM-A1000 - CVM-A1500

Instruction Manual

3.5.- CONNECTION DIAGRAMS

3�5�1�- THREE-PHASE NETWORK MEASUREMENT WITH A 4-WIRE CONNECTION (CVM-

A1x00-ITF)�

Measurement system:

Secondary winding of the current transformer: (MC1 type transformer)

Secondary winding of the neutral current transformer:

Power

Supply

VL1

N V

L3 L2

VL1 VL2 VL3

A B

S1 S2 S1 S2 S1 S2

P1 P2

L2 L3

P1 P2 P1 P2

S1 S2

P1 P2

REF REF

S1 S2

P1 P2

POWER SUPPLY

VL2 VL3 NVREF

NREF

VREF

NREF

S1 S2

P1 P2 S1 S2

P1 P2

LOAD

Figure 3: Three-phase measuring with a 4-wire connection (transformer secondary: /1A, /5A or MC1 (/0�250))�

Note: The device can calculate the neutral current without having to measure it, option:

Calculated current .

The MC1 transformer secondary value is set to 0.250 A

The transformer for measuring the LN neutral current cannot be MC type.

Instruction Manual

CVM-A1000 - CVM-A1500

Measurement system:

Secondary winding of the current transformer: (MC3 type transformer)

Secondary winding of the neutral current transformer:

Power

Supply

VL1

N V

L3 L2

VL1 VL2 VL3

A B

3P1 2P1 1P1

3P2 2P2 1P2 Brown/Green

Grey/Pink

Green/White

Red/Blue

S1 S2 S1 S2 S1 S2

P1 P2

L2 L3

P1 P2 P1 P2

S1 S2

P1 P2

REF REF

S1 S2

P1 P2

POWER SUPPLY

VL2 VL3 NVREF

NREF

VREF

NREF

LOAD

Figure 4: Three-phase measuring with a 4-wire connection (MC3 type transformer (/0�250))�

Note: The device can calculate the neutral current without having to measure it, option:

Calculated current .

The MC3 transformer secondary value is set to 0.250 A.

The transformer for measuring the LN neutral current cannot be MC type.

CVM-A1000 - CVM-A1500

Instruction Manual

3�5�2�- THREE-PHASE NETWORK MEASUREMENT WITH A 4-WIRE CONNECTION (CVM-

A1x00-FLEX)�

Measurement system:

Alimentación auxiliar

Power Supply

VL1

N V

L3 L2

VL1 VL2 VL3

A B

REF REF

POWER SUPPLY

VL2 VL3 NVREF

NREF

VREF

NREF

CARGA / LOAD

L2 L3

CC C

SHLD SHLD SHLD

SHLD SHLDL1 L2 L3C1 C2 C3

Figure 5: Three-phase measuring with a 4-wire connection (transformer secondary: /100 mV~)�

It is mandatory connect the SHLD terminal of the probe.

Instruction Manual

CVM-A1000 - CVM-A1500

3�5�3�- THREE-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION (CVM-

A1x00-ITF)�

Measurement system:

Secondary winding of the current transformer: (MC1 type transformer)

Power

Supply

VL1 VL2 VL3

N V

L3 L2

VL1 VL2 VL3

A B

S1 S2 S1 S2 S1 S2

P1 P2

L2 L3

P1 P2 P1 P2

S1 S2

P1 P2

REF REF

S1 S2

P1 P2 S1 S2

P1 P2

POWER SUPPLY

LOAD

Figure 6: Three-phase measuring with a 3-wire connection (transformer secondary: /1A, /5A or MC1 (/0�250))�

The MC1 transformer secondary value is set to 0.250 A

CVM-A1000 - CVM-A1500

Instruction Manual

Measurement system:

Secondary winding of the current transformer: (MC3 type transformer)

Power

Supply

VL1 VL2 VL3

POWER SUPPLY

N V

L3 L2

VL1 VL2 VL3

A B

3P1 2P1 1P1

3P2 2P2 1P2 Brown/Green

Grey/Pink

Green/White

Red/Blue

S1 S2 S1 S2 S1 S2

P1 P2

L2 L3

P1 P2 P1 P2

S1 S2

P1 P2

REF REF

LOAD

Figure 7: Three-phase measuring with a 3-wire connection (MC3 type transformer (/0�250))�

The MC3 transformer secondary value is set to 0.250 A

Instruction Manual

CVM-A1000 - CVM-A1500

3�5�4�- THREE-PHASE NETWORK MEASUREMENT WITH A 3-WIRE CONNECTION (CVM-

A1x00-FLEX)�

Measurement system:

VL1 VL2 VL3

N V

L3 L2

VL1 VL2 VL3

A B

REF REF

POWER SUPPLY

Alimentación auxiliar

Power Supply

CARGA / LOAD

L2 L3

CC C

SHLD SHLD SHLD

SHLD SHLDL1 L2 L3C1 C2 C3

Figure 8: Three-phase measuring with a 3-wire connection (transformer secondary: /100 mV~)�

It is mandatory connect the SHLD terminal of the probe.

CVM-A1000 - CVM-A1500

Instruction Manual
