CIS VCC-5CL4M Quick start guide

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
Camera Link I/F
5.01M Pixels CMOS B/W Camera
VCC-5CL4M
Product Specifications
& Operational Manual
CIS Corporation

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
1
Table of Contents
PAGE
1. Handling Precautions .......................................................................................................................................3
2. Product Outline ...............................................................................................................................................4
3. System Configuration.......................................................................................................................................4
3.1. Camera...................................................................................................................................................4
3.2. Optional Accessories ................................................................................................................................4
3.3. Free Software..........................................................................................................................................4
3.4. Packaging................................................................................................................................................4
4. Specifications..................................................................................................................................................5
4.1. General Specifications ..............................................................................................................................5
4.2. Camera Input and Output Signals Specifications .........................................................................................6
4.3. CMOS Spectral Response..........................................................................................................................7
4.4 Video Output Format................................................................................................................................8
5. Camera Function Settings.................................................................................................................................9
5.1. The List of Preset Shutter .......................................................................................................................12
5.2. Formula to Calculate Manual Shutter Values .............................................................................................12
5.3. Manual Shutter Settings with CLK Sync Mode (FAST Trigger Mode).............................................................12
5.4. Notes for Function Settings.....................................................................................................................12
6. External Connector Pin Assignment .................................................................................................................13
6.1. 12pins Circular Connector HR10-10R-12PA(73) (HIROSE) or equivalent ....................................................13
6.2. Camera Link Connector 12226-1100-00PL (SUMITOMO 3M)......................................................................14
6.3. PoCL/CL Selection Switch (SW1)..............................................................................................................14
7. Timing Chart.................................................................................................................................................15
7.1. Horizontal Synchronous Signals Timing (2Tap Base configuration mode).....................................................15
7.2. Vertical Synchronous Signals Timing (2Tap Base configuration mode).........................................................15
7.3. Horizontal Synchronous Signals Timing (3Tap Base configuration mode).....................................................16
7.4. Vertical Synchronous Signals Timing (3Tap Base configuration mode).........................................................16
7.5. Horizontal Synchronous Signals Timing (4Tap Medium configuration mode) ................................................17
7.6. Vertical Synchronous Signals Timing (4Tap Medium configuration mode) ....................................................17
7.7. Horizontal Synchronous Signals Timing (8Tap configuration mode).............................................................18
7.8. Vertical Synchronous Signals Timing (8Tap configuration mode).................................................................18
7.9. Fixed Trigger Shutter Mode.....................................................................................................................19
7.10. FAST Fixed Trigger Shutter Mode.............................................................................................................20
7.11. Pulse Width Trigger Shutter Mode............................................................................................................21
7.12. FAST Pulse Width Trigger Shutter Mode ...................................................................................................22
8. Partial Scan Mode..........................................................................................................................................24
9. Remote Communication Function....................................................................................................................26
10. Pixel Defect Correction...................................................................................................................................28
11. User Data SAVE/ReadOut Function..................................................................................................................31
11.1. SAVE User Data .....................................................................................................................................31
11.2. Reading Out of User Data.......................................................................................................................31
12. Factory Settings.............................................................................................................................................32
13. Sensor Optical Axis Accuracy ..........................................................................................................................33
14. Dimensions...................................................................................................................................................34
15. Case for Indemnity (Limited Warranty)............................................................................................................35

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
2
16. CMOS Pixel Defect.........................................................................................................................................35
17. Product Support ............................................................................................................................................35
18. Ordering Information.....................................................................................................................................35

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
3
1. Handling Precautions
The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical failure or
malfunction could result in serious bodily injury or loss of human life. Our warranty does not apply to damages or defects
caused by irregular and/or abnormal use of the product.
Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these precautions.
Do not use or store the camera in the extremely dusty or humid places.
Do not apply excessive force or static electricity that could damage the camera.
Do not shoot direct images that are extremely bright (e.g., light source, sun, etc.), and when camera is not in use, put
the lens cap on.
Follow the instructions in Chapter 6, “External connector pin assignment” for connecting the camera. Improper
connection may cause damages not only to the camera but also to the connected devices.
Confirm the mutual ground potential carefully before connecting the camera to monitors or computers. Any AC leaks
from the connected devices may cause damages or destroy the camera.
Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage may
cause damages or malfunction of the camera.
The voltage ripple of camera power DC +12V±10% shall be within ±50mV. Improper power supply voltage may
cause noises on the video signals.
The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please avoid noises like
chattering when rising.
10 4020 30 50
10
11
12
電 源 電 圧 [V]
電源 電圧 立ち 上 がり 時間[ ms]
9
8
7
60 70
Voltage rising time [ms]
Power supply
voltage [V]

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
4
2. Product Outline
VCC-5CL4M is a Camera Link interfaced and 5M resolution, small industrial B/W camera module. 5.01M pixels, 2/3
type (diagonal length 11.1mm) B/W CMOS sensor is utilized. Entire pixels can be read out at 1/114s with Full
configuration output.
Features
□Global shutter CMOS sensor
□Camera Link 2tap 8/10bit, 3tap 8bit, 4tap 8/10bit, and 8tap 8/10bit are supported.
□Fixed trigger shutter mode, Pulse width trigger shutter mode
□Full frame rate and video output are as below.
3. System Configuration
3.1. Camera
□Camera, VCC-5CL4M
3.2. Optional Accessories
□M42-C lens mount conversion ring
□M42-F lens mount conversion ring
3.3. Free Software
□CIS control panel software for evaluation purpose only is downloadable via our web.
3.4. Packaging
□Individual carton
□Master carton (20pcs/carton)
Note) Master carton may vary depends on the quantity to be shipped.
2Tap Base configuration
28fps
8bit/10bit
3Tap Base configuration
42fps
8bit
4Tap Medium configuration
57fps
8bit/10bit
8Tap Full, 8tap10bit configuration
114fps
8bit/10bit
Factory setting:
Medium 4Tap8bit configuration

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
5
4. Specifications
4.1. General Specifications
(1) Pickup device
Device type
Diagonal length 11.1mm type (2/3type) Global shutter B/W CMOS
Effective pixel number
2448(H) x 2048(V)
Unit cell size
3.45μm(H) x 3.45μm(V)
(2) Video output frequency
Pixel clock
74.25MHz
2Tap Base configuration mode:
Horizontal
frequency
60.12kHz Horizontal clock 1235CLK
Vertical frequency
28.71Hz
Scanning lines
2094H
3Tap Base configuration mode:
Horizontal
frequency
90kHz Horizontal clock 825CLK
Vertical frequency
42.98Hz
Scanning lines
2094H
4Tap Medium configuration mode:
Horizontal
frequency
119.8kHz Horizontal clock 620CLK
Vertical frequency
57.19Hz
Scanning lines
2094H
8Tap Full , 8Tap10bit
configuration mode:
Horizontal
frequency
239.5kHz Horizontal clock 310CLK
Vertical frequency
114.38Hz
Scanning lines
2094H
(3) Sync. system
Internal sync. system
(4) Video output
2Tap Base configuration
3Tap Base configuration
4Tap Medium configuration
8Tap Full configuration
8Tap 10bit
configuration
(5) Resolution
2048TV lines
(6) Output format
Sensor AD
10bit
Camera Link output
8bit / 10bit B/W output
(7) Sensitivity
F4 400lx (Shutter speed 1/58s (OFF), Gain 0dB, 4tap8bit configuration mode)
(8) Minimum illumination
F1.4 0.19lx (Shutter speed 1/58s(OFF), Gain+36dB,4tap8bit configuration mode)
(9) Power requirements
DC+12V±10% 12pins circular connector or PoCL
(10) Power consumption 2.9W (DC+12V IN, 4Tap Medium configuration mode, Full frame scan output)
3.1W (DC+12V IN, 8Tap 10bit configuration mode, Full frame scan output)
(11) Dimensions
Refer to overall dimension drawing. (H:55mm W:55mm D:25mm excluding projection)
(12) Weight
Approx. 100g
(13) Lens mount
M42 mount ※Refer to overall dim ension drawing.
(14) Optical axis accuracy
Refer to drawing for CMOS optical axis accuracy.
(15) Gain variable range
0dB ~ +36dB (Guaranteed range)
(16)
Shutter speed variable
range
OFF ~ 1/55,0000s (at 8tap mode)
(17) Trigger shutter mode
Fixed shutter trigger mode, Pulse width shutter trigger mode
(18) Partial scan
Full frame scan ~ 4 lines (4 lines/step)
(19) Safety/Quality standards
UL: Conform to UL Standard including materials and others.
CE:
Emission
: EN55022:2010(Class A)
Immunity
: EN61000-6-2:2005
RoHS:
Conform to RoHS.
(20) Durability
Vibration
Acceleration
: 98m/s2(10G)
Frequency
: 20 ~ 200 Hz
Direction
: X,Y, and Z 3 directions
Testing time
: 120min for each direction
Shock
No malfunction shall be occurred with 980m/s
2
(100G) for ±X,±Y, and ±Z, 6 directions.

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
6
100ΩFVAL Output
LVAL Output
DVAL Output
Exposure Output
+5.0V(VCC)
Trigger Input
HD74LV1GT32ACME(RENESAS)
Voh:3.8V(Min)
Vol:0.55V(Max)
1KΩ
HD74LV1GT14ACME(RENESAS)
Vt-:0.5(Min)
Vt+:1.9V(Max)
100Ω
(21) Operational environment Temperature: Performance guaranteed temperature: 0℃~ +40℃
Camera operation guaranteed temperature: -5
℃
~ +45
℃
Humidity:
RH 20 ~ 80% with no condensation.
※All the specifications specified in this manual is guaranteed under performance guaranteed
temperature.
※All the camera functions operate normally under operation guaranteed temperature.
(22) Storage environment
Temperature:
-25℃~ +60℃
Humidity:
RH 20 ~ 80% with no condensation.
4.2. Camera Input and Output Signals Specifications
(1)
Video output data
Effective video output
2448(H) × 2048(V)
At full frame scan mode
(2) Sync. signal input
and output
LVAL
:No. 6 pin
12pins circular connector
(LVTTL output)
FVAL
:No. 7 pin
EXPOSURE
:No. 9 pin
DVAL
:No.10pin
LVAL
Camera Link output (LVDS)
FVAL
DVAL
SP (EXPOSURE)
(3) Trigger input
Polarity
Positive/Negative
selectable
Pulse width
1H(min) ~ Approx. 2 frames
Functionally, no upper limitation is set but at long time
exposure, dark noises and shading noises might be noticeable.
Trigger input
: No.11 pin
12pins circular connector (LVTTL)
: CC1
Camera Link input (LVDS)
(4) Serial
communications
SerTC
(Serial to Camera)
Camera Link input (LVDS)
SerTFG (Serial to Frame Grabber)
Camera Link output (LVDS)
(5) Video signals
White clip Level
At Digital 10bit
: 3FFh
Setup level At Digital 10bit
:
8±3h
(Condition: Gain 0dB)
Dark shading At Digital 10bit
: Both horizontal and vertical should be
under 00Fh. (Condition: Gain 0dB)
IO Interface of 12pins Circular connector at rear

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
7
4.3. CMOS Spectral Response
※The lens characteristics and illuminant characteristics are excluded.

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
8
4.4 Video Output Format
(1) 2Tap Base configuration mode : 28fps
(2) 3Tap Base configuration mode : 42fps
(3) 4Tap Medium configuration mode : 57 fps
(4) 8Tap Full , 8tap10bit configuration mode : 114fps
・・・D D
～
～～ ～
2048lines
2448pixels
1 2
DD
D D ・・・
～
～～ ～
2048line
2448pixels
1 2 3 4
D D D DD D D D ・・・
～
～～ ～
2048lines
2448pixels
12345678
DD
D・・・
～
～～
～
2048line
2448pixels
123

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
9
5. Camera Function Settings
Camera functions can be set with serial communications.
Function
Address
Data
Description
Camera mode
1
0
2Tap
8bit/10bit
1
3Tap
8bit
2
4Tap
8bit/10bit
3
8Tap
8bit/10bit
Output data selection
2
0
8bit output
1
10bit output (Invalid at 3Tap mode).
Trigger shutter mode
※FAST trigger mode is forced to be
disabled at normal shutter mode.
To enable FAST trigger mode, fixed
trigger shutter mode or pulse width
trigger shutter model shall be selected
3 0 Normal shutter mode (free-run)
(Shutter speed can be set with address 23 and 24).
1 Fixed trigger shutter mode
(Shutter speed can be set with address 23 and 24).
2 Pulse width trigger shutter mode
(Shutter speed can be set with trigger pulse width).
Trigger polarity
4
0
Positive
1
Negative
Trigger input
5
0
Camera Link CC1
1
12pins circular connector No. 11 pin (TTL)
FAST trigger mode selection
※Trigger mode to capture the trigger
input
with H cycle or the mode to
capture the trigger input with CLK
sync is switchable.
However, please be noted that
overlapped operation cannot be
operative at CLK sync mode.
This mode is effective to avoid hunting
at high speed shutter operation.
6 0 H sync mode (Trigger is taken with H sync.).
※A trigger during outputting images can be input (Overlap
operation is doable).
※Exposu re tim e durin g norm al sh utter m ode an d fixed trig g er
shutter mode can be set per H.
1 FAST trigger mode (Trigger is taken with CLK sync.).
※A trigger during outputting images cannot be input (Overlap
operation is not doable).
※Exposu re tim e of m an u al sh u tter durin g fixed trig g er shu tter
mode is changed to be set per μs (approximate value).
Test pattern 7
0
OFF
1
Gray scale (Valid only when cursor is OFF)
2
Horizontal ramp (Valid only when cursor is OFF)
3
Vertical ramp (Valid only when cursor is OFF)
Cursor display ON/OFF
8
0
OFF
1 ON (Cursor output has its priority when test pattern output is
ON).
Cursor X coordinate 9 0 ~ 2447 Horizontal 2448 pixels (Factory setting is 0.
When operating coordinate, it is reset to (0, 0).)
Cursor Y coordinate 10 0 ~ 2047 Vertical 2048 lines (Factory setting is 0.
When operating coordinate, it is reset to (0, 0).)
Output image horizontal flip
11
0
Normal
When operating the cursor is reset to
(0, 0).)
1 Horizontal flip
Output image vertical flip
When operating the cursor is reset to
(0, 0).)
12
0
Normal
1 Vertical flip
Defective pixel correction
13
0
OFF
1
ON

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
10
Function
Address
Data
Description
Serial communications
Baud rate selection
※I NI T Command is excluded
14
0
9,600 baud
1 115,200 baud
Black level adjustment 16 0 ~ 100 Black level adjustment
(To be restored to the factory settings with INIT command).
Gain
20
0
0dB fixed gain
1
+ 6dB fixed gain
2
+12dB fixed gain
3
+18dB fixed gain
4
+24dB fixed gain
5
+30dB fixed gain
6
+36dB fixed gain
11
Manual gain (Refer to the address 21)
Manual gain
21
0 ~ 480
0 ~ +48dB
(1dig=0.1dB)
Shutter 23 0 ~ 15 Preset shutter
(Refer to Section 5.1. The List of Preset Shutter)
16
Manual shutter (Refer to the address 24)
Manual shutter 24 1 ~ 2048
1line/step (Refer to Section 5.2. Formula to Calculate
Manual Shutter Values)
Manual shutter at FAST trigger 14 ~ 200,000 Specify exposure time with μs (approximate value).
Refer to the manual shutter settings of FAST trigger mode
(CLK sync. mode).
Vertical partial (lump settings) 50 3 parameters The 1st parameter: Partial number (0~7)
The 2nd parameter: Start line (0~2044 per 4 lines)
The 3rd parameter: Effective line numbers (4~2048 per 4
lines)
1 parameter
at acquisition
Specify the partial numbers (0~7).
Vertical partial mode
54
0
OFF
1 Reflect the value set by
the address 50, then set vertical
partial ON.
Factory settings
INIT
None
Restore the settings to the factory settings.
Data save
SAVE
None
Save the camera settings.
White defect detection by users
100
2 parameters
Detect the later occurred white defects and register them.
Addition of defect pixels by users
101
2 parameters
Register the defective pixels specified with (x, y).
Deletion of defect pixels by users
102
2 parameters
Delete the defective pixels specified with (x, y).
Complete deletion of defect pixels
by users
103 1 (fixed) Delete all the defect pixels detected and registered by the
user.

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
11
Function
Address
Data
Description
Indication of defect pixels
104
0 at set up
Turn OFF the indication of bright point
1 at set up
Indicate the position of the correcting pixel with lighting.
1 at setup Indicate the list of data at ex-
factory and the registered
data by the user.
2 at setup
Indicate only the list of the registered data by the user.
3 at setup
Indicate the registered number of the defect pixels per
reed.
4 at setup Line up and indicate the registered
number of the defect
pixels per reed.
User data settings 200 2 parameters
All 0xFF at
ex-factory
Set any data for the user area (32 byte).
Save with SAVE command.
※Do not set any address or data other than specified the above.

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
12
5.1. The List of Preset Shutter
2448dot X 2048line
Data
2Tap mode
3Tap mode
4Tap mode
8Tap mode
0
1/29(OFF)
1/44(OFF)
1/58(OFF)
1/117(OFF)
1
1/60
1/60
1/60
1/117(OFF)
2
1/100
1/100
1/100
1/117(OFF)
3
1/150
1/150
1/150
1/150
4
1/200
1/200
1/200
1/200
5
1/250
1/250
1/250
1/250
6
1/500
1/500
1/500
1/500
7
1/1000
1/1000
1/1000
1/1000
8
1/2000
1/2000
1/2000
1/2000
9
1/2500
1/2500
1/2500
1/2500
10
1/5000
1/5000
1/5000
1/5000
11
1/10000
1/10000
1/10000
1/10000
12
1/15000
1/15000
1/15000
1/15000
13
1/21000
1/28000
1/25000
1/25000
14
1/33000
1/40000
1/33000
1/45000
15
1/33000
1/40000
1/45000
1/55000
5.2. Formula to Calculate Manual Shutter Values
Formula : Exposure time = Time for 1 line (Refer to the below) x Address 24 set value + 13.73μs
Camera Mode
Time for 1 line
2Tap Base configuration mode
16.633μs
3Tap Base configuration mode
11.111μs
4Tap Medium configuration mode
8.350μs
8Tap configuration mode
4.175μs
※The minimum setting value shall be 1 and the maximum setting value shall be clipped with 2048 or the total line number
for partial settings.
5.3. Manual Shutter Settings with CLK Sync Mode (FAST Trigger Mode)
・The minimum setting value: 14μs (approximate value)
・The maximum setting value: 200ms (approximate value)
※With long exposure setting, bright spot may be noticeable.
・Setting unit: Per 1μs (approximate value)
※Slight differences may occur since it is generated by 74.25MHz clock.
5.4. Notes for Function Settings
※2 seconds shall be waited after power is turned on for the camera to operate properly.
※When gain settings + 36dB is exceeded, deterioration in the image quality is inevitable.
We recommend you to evaluate it first to use.
※When camera mode (Tap mode) is changed, please re-set other functions, too.
※When gain is set to over +36dB, image quality deterioration is inevitable. Please evaluate first.

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
13
6. External Connector Pin Assignment
6.1. 12pins Circular Connector HR10-10R-12PA(73) (HIROSE) or equivalent
Pin No. Description
1 GND
2 Power input (DC+12V)
3 GND
4 NC
5 GND
6 LVAL output
7 FVAL output
8 GND
9 Exposure output
10
DVAL output
11 TRIGGER inputs
12 GND

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
14
6.2. Camera Link Connector 12226-1100-00PL (SUMITOMO 3M)
1
14
13
26
1
14
13
26
(Base Configuration)
(Medium/ Full Configuration)
CL
PoCL
(SW1)
CL1CL2
DC IN
Connector (CL2) Connector (CL1)
6.3. PoCL/CL Selection Switch (SW1)
(1) PoCL・・・To be selected when a PoCL frame grabber board is used and power is fed via the frame grabber
board.
(2) CL・・・To be selected when Non-PoCL frame grabber board is used.
Please make sure that power is OFF when changing the switch settings. If the switch setting was changed
while power is ON, it may cause malfunction or damages to the camera.
Pin
No.
Description Pin
No.
Description Pin
No.
Description Pin
No.
Description
1 NC/+12V(PoCL) 14 GND 1 NC/+12V(PoCL) 14 GND
2 Y0- 15 Y0+ 2 X0- 15 X0+
3 Y1- 16 Y1+ 3 X1- 16 X1+
4 Y2- 17 Y2+ 4 X2- 17 X2+
5 Yclk- 18 Yclk+ 5 Xclk- 18 Xclk+
6 Y3- 19 Y3+ 6 X3- 19 X3+
7
100Ω
20
Terminated
7 SerTC+ 20 SerTC-
8
Z0-
21
Z0+
8 SerTFG- 21 SerTFG+
9
Z1-
22
Z1+
9 CC1-(Trigger IN -) 22 CC1+ (Trigger IN +)
10 Z2- 23 Z2+ 10 CC2+ 23 CC2-
11 Zclk- 24 Zclk+ 11 CC3- 24 CC3+
12
Z3-
25
Z3+
12 CC4+ 25 CC4-
13
GND
26
NC/+12V(PoCL)
13 GND 26 NC/+12V(PoCL)

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
15
7. Timing Chart
7.1. Horizontal Synchronous Signals Timing (2Tap Base configuration mode)
LVAL Out
～ ～
Effective Data : 1224 CLK 11 CLK
DVAL Out
1H = 1235 CLK
～ ～
Camera Link Port B
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
Camera Link Port A
13・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
57
24682440 2442 2445 2447
2441 2443 2446 2448
12
Video Out 2
4
4
7
2
4
4
8
～ ～
Camera Link CLK : 74.25MHz
7.2. Vertical Synchronous Signals Timing (2Tap Base configuration mode)
FVAL Out
1Frame = 2094H
Effective Line : 2048H
Effective Line
DVAL Out
～ ～
LVAL Out
～ ～
Effective Line
～ ～～
～
V Blanking :46H
Exposure Time
SP Out(Exposure Out)
2
0
4
8
2
0
4
8
11
Video Out
～ ～ ～ ～
40Ｈ
1H = 16.56us
2Tap Base configuration mode: 28fps

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
16
7.3. Horizontal Synchronous Signals Timing (3Tap Base configuration mode)
Camera Link Port C
LVAL Out
～
～
Effective Data : 816 CLK 9 CLK
DVAL Out
1H = 825 CLK
～ ～
Camera Link Port B ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
Camera Link Port A 1
3
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
4
6
252443
2445
2446
2448
2444 2447
12
Video Out
2
4
4
7
2
4
4
8
34
～ ～
2
4
4
5
2
4
4
6
56
2
4
4
3
2
4
4
4
Camera Link CLK : 74.25MHz
7.4. Vertical Synchronous Signals Timing (3Tap Base configuration mode)
FVAL Out
1Frame = 2094H
Effective Line : 2048H
Effective Line
DVAL Out
～ ～
LVAL Out
～ ～
Effective Line
～ ～～
～
V Blanking :46H
Exposure Time
SP Out(Exposure Out)
2
0
4
8
2
0
4
8
11
Video Out
～
～ ～ ～
40Ｈ
1H = 11.04us
3Tap Base configuration mode: 42fps

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
17
7.5. Horizontal Synchronous Signals Timing (4Tap Medium configuration mode)
Camera Link Port D
Camera Link Port C
LVAL Out
～ ～
Effective Data : 612 CLK 8 CLK
DVAL Out
1H = 620 CLK
～ ～
Camera Link Port B ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
Camera Link Port A 1
3
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
5
7
2
4
6
8
2441
2443
2445
2447
2442
2444
2446
2448
12
Video Out
2
4
4
7
2
4
4
8
34
～ ～
2
4
4
5
2
4
4
6
Camera Link CLK : 74.25MHz
7.6. Vertical Synchronous Signals Timing (4Tap Medium configuration mode)
FVAL Out
1Frame = 2094H
Effective Line : 2048H
Effective Line
DVAL Out
～ ～
LVAL Out
～ ～
Effective Line
～ ～～
～
V Blanking :46H
Exposure Time
SP Out(Exposure Out)
2
0
4
8
2
0
4
8
1 1
Video Out
～ ～ ～ ～
40Ｈ
1H = 8.28us
4Tap Medium configuration mode: 57fps

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
18
7.7. Horizontal Synchronous Signals Timing (8Tap configuration mode)
Camera Link Port D
Camera Link Port C
LVAL Out
～ ～
Effective Data : 306 CLK 4 CLK
DVAL Out
1H = 310 CLK
～ ～
Camera Link Port B ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
Camera Link Port A 1
3
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
2
4
2441
2443
2442
2444
12
Video Out
2
4
4
7
2
4
4
8
34
～ ～
2
4
4
5
2
4
4
6
Camera Link Port H
Camera Link Port G
Camera Link Port F ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
Camera Link Port E 5
7
6
8
2445
2447
2446
2448
5678
2
4
4
3
2
4
4
4
2
4
4
1
2
4
4
2
Camera Link CLK : 74.25MHz
7.8. Vertical Synchronous Signals Timing (8Tap configuration mode)
FVAL Out
1Frame = 2094H
Effective Line : 2048H
Effective Line
DVAL Out
～ ～
LVAL Out
～ ～
Effective Line
～ ～～
～
V Blanking :46H
Exposure Time
SP Out(Exposure Out)
2
0
4
8
2
0
4
8
11
Video Out
～ ～
～ ～
40Ｈ
1H = 4.17us
8Tap configuration mode: 114fps

VCC-5CL4M Rev.905-0060-04
©2016 CIS Corporation. All rights reserved.
19
7.9. Fixed Trigger Shutter Mode
□This is the mode to start exposure with external input trigger signals, and set the exposure time with serial commands.
□Trigger operation is H sync., and V-sync. restart system.
The delay time (Exposure Time Delay) from detecting trigger edge in the camera to starting exposure is 2H~3H.
Since the external trigger signals sync with camera internal H signals, 1H jitter occurs to Exposure Time Delay.
The trigger pulse with the minimum 1H and more shall be input (Refer to the below for the details of 1 line width).
Camera Mode
Time for 1 line
2Tap Base configuration mode
16.633μs
3Tap Base configuration mode
11.111μs
4Tap Medium configuration mode
8.350μs
8Tap configuration mode
4.175μs
□There is an exposure time period for approx. 13.73μs at the edge right after exposure output.
□Triggers can be accepted while outputting video output images. However, please note that a trigger signal to
start the next video outputting before completion of outputting the prior images should not be input.
□Trigger input during exposure time shall be ignored in the camera. (Refer to (A) in the drawing below).
Note that a trigger shorter than 1 frame cycle shall not be used.
Effective Line : 2048H
Effective Line
～ ～
2
0
4
8
1
～ ～
2
0
4
8
1
Effective Line
Trigger input ignore period
Exposure Time
Exposure Time Delay
(A)
TRIG IN
Exposure Out
(SP Out) Exposure time delay
