CIS VCC-SXCXP1SW Quick start guide

Rev.905-0230-01
©2022 CIS Corporation. All rights reserved.
CoaXPress I/F
1.3M SWIR Camera
VCC-SXCXP1SW
Product Specifications
& Operational Manual
CIS Corporation

VCC-SXCXP1SW Rev.905-0230-01
©2022 CIS Corporation. All rights reserved.
Table of Contents
1. Precautions......................................................................................................................................1
1.1. Handling Precautions ......................................................................................................................1
1.2. Restrictions on Applications ..............................................................................................................1
1.3. Disclaimers (Exception Clause)..........................................................................................................1
1.4. Image Quality Limitations ................................................................................................................1
2. Product Outline ................................................................................................................................2
2.1. Features.......................................................................................................................................2
2.2. Accessories ...................................................................................................................................2
3. Specifications ...................................................................................................................................3
3.1. General Specifications .....................................................................................................................3
3.2. Input and Output Specifications ........................................................................................................5
3.2.1 12pins Circular Connector No.11 pin: TRIGGER_IN Circuit ..................................................................5
3.2.2 12pins Circular Connector No.6, 7, 8, 9, and 10 pin: SIGNAL_OUT Circuit..............................................5
3.3. External Connector Pin Assignment....................................................................................................6
3.3.1 12pins Circular Connector HR10-10R-12PA (73) (Hirose) or Equivalent .................................................6
3.3.2 75Ω BNC Connector ...................................................................................................................6
3.4. LED Indicator ................................................................................................................................7
3.5. Spectral Response ..........................................................................................................................7
4. Camera Functions .............................................................................................................................8
4.1. Control System ..............................................................................................................................8
4.2. How to Save and Initialize Settings ....................................................................................................8
4.3. Link Speed and Link Count ...............................................................................................................8
4.4. Pixel Format ..................................................................................................................................9
4.5. Flip..............................................................................................................................................9
4.6. Partial Scan (ROI) ..........................................................................................................................9
4.7. Frame Rate................................................................................................................................. 10
4.8. Internal Sync. Mode (Free Run Mode) .............................................................................................. 10
4.9. External Trigger Sync. Mode........................................................................................................... 11
4.10. Trigger Sync. Mode and Delay Time to Start Exposure ......................................................................... 12
4.11. Restrictions on Timing for Trigger Pulse Input .................................................................................... 13
4.12. Fixed Trigger Shutter Mode H Sync. Trigger (LineSync) ........................................................................ 14
4.13. FAST Fixed Trigger Shutter Mode CLK Sync. Trigger (ClockSync) ............................................................ 15
4.14. Pulse Width Trigger Shutter Mode H Sync. Trigger (LineSync)................................................................ 16
4.15. FAST Pulse Width Trigger Shutter Mode CLK Sync. Trigger (ClockSync).................................................... 17
4.16. Exposure Time............................................................................................................................. 18
4.17. Calculation Formula for Manual Shutter Values with H Sync. (LineSync) Mode........................................... 18
4.18. Manual Shutter Settings with CLK Sync. Mode.................................................................................... 18
4.19. Gain .......................................................................................................................................... 18
4.20. Gamma Correction........................................................................................................................ 19
4.21. Black Level Adjustment.................................................................................................................. 19
4.22. Image Quality Selection Mode......................................................................................................... 19
4.23. Fan Control / Temperature Control................................................................................................... 20
4.24. Shading Correction ....................................................................................................................... 20
4.25. Noise Filter ................................................................................................................................. 21
4.26. Defective Pixel Correction .............................................................................................................. 21
4.27. Test Pattern Indication .................................................................................................................. 24
4.28. Cursor Indication.......................................................................................................................... 24
4.29. LED Operational Mode ................................................................................................................... 24

VCC-SXCXP1SW Rev.905-0230-01
©2022 CIS Corporation. All rights reserved.
4.30. Camera I/O................................................................................................................................. 25
4.31. User ID Save............................................................................................................................... 25
4.32. External Lighting Control................................................................................................................ 26
5. Factory Settings.............................................................................................................................. 28
6. Dimensions.................................................................................................................................... 29
6.1. Camera Dimensions ...................................................................................................................... 29
6.2. Optical Axis Accuracy .................................................................................................................... 30
7. Case for Indemnity (Limited Warranty)................................................................................................ 31
7.1. Product Warranty ......................................................................................................................... 31
7.2. CMOS Defective Pixels................................................................................................................... 31
7.3. Product Support........................................................................................................................... 31
8. Appendix : Points to Note on Image Quality Characteristics ..................................................................... 32

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
1
1. Precautions
1.1. Handling Precautions
□Do not use or store camera in dusty or humid places.
□Do not apply excessive force or static electricity that could damage camera. Handle camera with care.
□Do not shoot direct images that are extremely bright (e.g., light source, sun, etc.). When extremely strong light source
is shot, smear or blooming may occur. When camera is not in use, please put the lens cap on.
□Follow the instructions in Chapter 3.3. “External Connector Pin Assignment”for connecting camera. Improper
connection may cause damages not only to the camera but also to the connected devices.
□Confirm mutual ground potential carefully and connect camera to monitors or computers. AC leak from the connected
devices may cause damages or destroy the camera.
□Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage may
cause damages or malfunction of the camera.
Our warranty does not apply to damages or defects caused by irregular and/or abnormal use of the
product.
1.2. Restrictions on Applications
□The camera must not be used for any nuclear equipment or aerospace equipment with which mechanical failure or
malfunction could result in serious bodily injury or loss of human life.
□The camera must not be used under conditions or environments other than those specified in this manual.
□Usage of VCC-SXCXP1SW for military related purposes is prohibited by List Controls for Export Trade Control Order.
1.3. Disclaimers (Exception Clause)
CIS should not be liable for any damages or losses if;
□damages or losses are caused by earthquake, lightning strike, fire, flood, or other acts of God.
□damages or losses are caused by deliberate or accidental misuse by user, or failure to observe information and
instructions explained in this manual.
□damages or losses are caused by repair or modification conducted by user or any unauthorized party.
1.4. Image Quality Limitations
VCC-SXCXP1SW is a SWIR camera. Usage of SWIR sensor makes image quality characteristics of this model different
from those using normal silicon image sensors.
Please refer to “Appendix: VCC-SXCXP1SW Points to note on image quality characteristics” for details.

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
2
2. Product Outline
VCC-SXCXP1SW is a SWIR (Short Wave Infrared) camera with CoaXPress interface. Using 1.3M pixels resolution, 1/2”
global shutter type SWIR sensor, this model is capable of inspecting invisible part of objects with detecting wavelength
spectrum from 400nm to 1700nm. Must have function ready for FA applications, such as external trigger, ROI (vertical),
gamma correction, shading correction, and defective pixel correction. Suitable and useful for various inspection
applications.
2.1. Features
□65mm(H) × 65mm(W) × 65mm(D) cubic in size
□Global shutter type visible + SWIR image sensor
□Complies with CoaXPress Ver1.1.1. Supports CXP-3
□Supports PoCXP
□Exposure, Gain settings
□External trigger mode (Fixed trigger shutter mode / Pulse width trigger shutter mode)
□Complies with GenICam
□C lens mount
2.2. Accessories
□Standard Accessory
・Lens cap

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
3
3. Specifications
3.1. General Specifications
Electrical Specifications
Image sensor
Sensor type
1/2” Global shutter type Visible + SWIR
Effective pixels
1296 (H) × 1032 (V)
Unit cell size
5µm(H) × 5µm(V)
Interface
Complies with CoaXPress Ver,1.1.1, CXP-3 x 1
Video output
frequency
Pixel clock frequency 74.25MHz
Video output format
Mono8 / Mono10 / Mono12
Frame rate
CXP-3 8bit / 10bit / 12bit
134.73fps / 125.26fps / 71.52fps (with LineSync)
Sync. system
Internal sync. system
Resolution (The maximum pixel size)
1296(H) × 1032(V)
Video signals
White clip level
255
With Mono8, Gainx1, ClkSync
Set up level
0~1dig
With Mono8, Gainx1, ClkSync
Dark shading 6dig or less for both
horizontal and vertical.
With Mono8, Gainx1, ClkSync
Gain variable range x1~x128 (0dB~+42dB)
※With 8bit mode, camera internally adds x4.00 offset gain.
Shutter speed
Manual
Trigger mode
Free run mode (Camera internal trigger)
Trigger mode (Host, External terminal)
・Fixed trigger shutter
・
Pulse width trigger shutter
Power requirements
PoCXP: 18.5~26V
Power consumption (Max)
3.6W [with free run]
Mechanical Specifications
Dimensions
H: 65mm W: 65mm D: 65mm excluding projection.
Weight
Approx. 300g
Lens mount
C mount

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
4
Environmental Specifications
Safety/Quality standards UL: Complies with UL standard including materials.
CE: EMC
2014/30/EU
EN61000-6-4:2007+A1:2011 for Emission
EN61000-6-2:2005 for Immunity
RoHS: 2011/65/EU
、
2015/863/EU EN50581(RoHS2)
Durability Vibration
Acceleration
: 98m/s
2
(10G)
Frequency
: 20 ~ 200Hz
Direction
: X, Y, and Z 3 directions
Testing time
: 120min each
Shock No malfunction with 980m/s2 (100G) for ±X ,±Y, and ±Z,
6 directions without packaging.
Operational temperature
Recommended temperature
0℃ ~ +45°C Humidity 20 ~ 80%RH with no condensation.
0℃ ~ +30°C
Humidity 20 ~ 80%RH with no condensation.
Storage temperature
-25℃ ~ +60°C
Humidity 20 ~ 80%RH with no condensation.

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
5
3.2. Input and Output Specifications
3.2.1 12pins Circular Connector No.11 pin: TRIGGER_IN Circuit
□5.0V, 3.3V CMOS level / TTLlevel
Input voltage Vt-: 0.84Vdc (Min.), Vt+: 2.1Vdc (Max.)
3.2.2 12pins Circular Connector No.6, 7, 8, 9, and 10 pin: SIGNAL_OUT Circuit
□5.0V CMOS logic level output
Output voltage Low: 0.35Vdc (Max), High: 4.5Vdc (Min)
Camera internal circuit
100
SN74LVC1G14(Equivalent)
1
2
3
5
4
+3.3V
1K
TRIGGER_IN
(CAMERA_INTERNAL)
+5.0V
SN74LV1T32 (Equlvalent)
1
2
3
4
5
SIGNAL_OUT
(CAMERA_INTERNAL)
Camera internal circuit

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
6
3.3. External Connector Pin Assignment
3.3.1 12pins Circular Connector HR10-10R-12PA (73) (Hirose) or Equivalent
HR10-10R-12PA (Hirose) or equivalent
Pin No.
Signals
Description
1
GND
Ground camera chassis
2
NC
3
GND
Ground camera chassis
4
NC
5
NC
6
Line1
General output
7
Line2
General output
8
Line3
General output
9
Line4
General output
10
Line5
General output
11
Line0
Trigger input
12
GND
Ground camera chassis
※NC=Non-Connection. Do not connect anything to the terminal.
3.3.2 75ΩBNC Connector
BCJ-BPLHA (CANARE)

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
7
3.4. LED Indicator
□With LED indicator Active, lighting patterns show the camera status by its way of lighting.
LED STATUS
Description
OFF
No power supply.
Green/Orange Fast Blinking [12.5Hz]
Disconnection of cables.
Green
Lighting
Completion of connection between device and host.
Green Fast Blinking [12.5Hz] ※
Transmitting video data.
Orange Slow Blinking [1Hz]
Waiting for a trigger input.
Red Fast Blinking [12.5Hz] ※
System error.
※When Trigger Mode is off, LED blinks with 12.5Hz. When Trigger Mode is On, LED blinks with trigger cycle.
(With high speed trigger, blinking may look like lighting.)
3.5. Spectral Response
※Excludes characteristics of lens and light source.

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
8
4. Camera Functions
4.1. Control System
Complies with CoaXPress ver. 1.1.1 standard.
4.2. How to Save and Initialize Settings
UserSets
UserSetSelector Default
UserSet0
UserSetLoad
(Execute)
UserSetSave
(Execute)
□Select UserSet0 (User save area) with UserSetSelector and execute “UserSetSave” to save settings into camera non-
volatile memory.
※User cannot save settings as default settings.
※Values of UserSetSelector is not subject to UserSetSave. Please set values before executing UserSetLoad /
UserSetSave.
□UserSetLoad loads default settings (factory setting) or UserSet0 (User save area) selected by UserSetSelector.
※Do not execute UserSetLoad while grabbing (acquiring) images.
□User ID and defective pixel correction data are not subject to UserSetLoad fordefault setting.
□Camera keeps Pixel Format and Image Quality Mode settings in operation even when executing UserSetLoad.
If you wish to change Pixel Format and Image Quality Mode, please set them via serial commands.
UserSetSelector
UserSetLoad >Excute
UserSetSave >Excute
Default
UserSet0
UserSetLoad >Excute = Initialize(Factory setting)
= Initialize(User setting)
= User setting Save
4.3. Link Speed and Link Count
Transfer Control
ConnectionConfig
CXP3_X1
・CXP-3 : Link speed = 3.125Gbps, Link count = 1 (fixed)

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
9
4.4. Pixel Format
ImageFormatControl
PixelFormat Mono8 Mono10
Mono12
・Mono8 : Monochrome 8bit
・Mono10 : Monochrome 10bit
・Mono12 : Monochrome 12bit
※Please do not change PixelFormat while grabbing (acquiring) images.
4.5. Flip
ImageFormatControl
ReverseX
True / False
・ReverseX : Flip the image with X direction.
※Please do not change Flip while grabbing (acquiring) images.
4.6. Partial Scan (ROI)
This is to increase frame rate by cutting and reducing line number to read out.
Supports only single ROI. Fixed number for horizontal dot.
ImageFormatControl
RegionSelector
EffectiveRegion / Region1
RegionMode
On
※Fixed
RegionDestination
Stream0
※Fixed
Width
1296
※Fixed
Height
8~1032
(per 8 pixels)
OffsetX
0
※Fixed
OffsetY
0~1024
(per 8 lines)
・RegionSelector : Select Region 1 for ROI operation.
Make sure to set RegionSelector to EffectiveRegion to start capturing images.
・RegionMode : ROI mode. Fixed with ON.
・RegionDestination : Selection of Stream to output. Fixed with Stream0.
・Width : Width of Region. Fixed with 1296.
・Height : Height of Region.
・OffsetX : Offset for X direction of Region. Fixed with 0.
・OffsetY : Offsetfor Y direction of Region.
※Total number of OffsetY and Height must be less than 1032.
※1 frame after switched full frame scan mode and partial scan mode, or changed partial settings
becomes invalid. Especially with fixed trigger shutter mode and pulse width trigger shutter mode, input
dummy trigger 8 times, and use 9th and later trigger signals as legitimate imaging signals.

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
10
4.7. Frame Rate
The following formula calculate framerateaccording to “Pixel format”, “ROI (height)”, and “Exposure time with ClockSync”.
①For internal sync mode (free run mode), H sync (LineSync) mode
Frame rate = 1,000,000/{Tline[us] x (Height + 36)} [fps]
②For internal sync mode (free run mode), CLK sync (ClockSync) mode
Frame rate = 1,000,000/{Tline[us] x (Height + 46) + Exposure time[us] - 7.372[us]} [fps]
Refer to the table below for Tline (=Time for 1H) [µs].
PixelFormat
Width=1296
Mono8
6.94949
Mono10
7.47475
Mono12
13.09091
4.8. Internal Sync. Mode (Free Run Mode)
□This is a mode to use internal triggers continuously generated.
□Turn off TriggerMode and set TriggerSelector to AcquisitionStart.
□With ClockSync setting, function automatically sets Exposure Time and Effective Line not to overlap.
[Note] Do not change sync mode setting while grabbing (acquiring) images.
FVAL Out
Effective Line : 1032H
Effective Line
LVAL Out
～ ～
Effective Line
～ ～
V Blanking
32H
Exposure Time
Exposure Out
1
0
3
2
1
0
3
2
1 1
Video Out
Header
Idle Stream data
Cxp Stream Idle Image
Header Stream data
Approx.33H
Shutter
stabilization
wait time
(Blank4H) is
inserted
Shutter
stabilization
wait time
(Blank4H) is
inserted
Vertical sync. timing (with free run): TriggerMode = Off, TriggerSyncMode = LineSync

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
11
4.9. External Trigger Sync. Mode
□This is a mode to capture images with preferred timings by inputting external trigger signals.
□Set TriggerSelector to AcquisitionStart and set TriggerSource to any one of Software/LinkTrigger0/Line0.
Turn On TriggerMode.
Acquisition Control
TriggerSelector AcquisitionStart
FrameStart
TriggerMode
On/Off
SensorSyncMode LineSync
ClockSync
TriggerActivation
RisingEdge
FallingEdge
LevelHigh
LevelLow
TriggerSource Software LinkTrigger0
Line0
TriggerSoftware
(Execute)
□TriggerSelector : (Equivalent to TriggerMode below.)
Select how to start capturing video.
・AcquisitionStart : Free run mode [Internal sync. mode]
・FrameStart : External trigger mode
□TriggerMode :
・On : Enable trigger selected with TriggerSource. (TriggerSelector = FrameStart)
・Off : Disable trigger selected with TriggerSource. (TriggerSelector = AcquisitionStart)
LineSync/ClockSync is selectable even when TriggerMode is off.
With ClockSync setting, function automatically sets frame cycle not to overlap.
※Do not change TriggerMode while grabbing (acquiring) images.
□SensorSyncMode :
・LineSync : H sync. mode (Controls exposure time per line)
Free run / Fixed-trigger shutter / Pulse width trigger shutter
Valid overlapping operation. (Exposure while reading out images)
・ClockSync : CLK sync. mode (Controls exposure time per sensor clock)
Free run / FAST fixed / FAST pulse width trigger shutter
Invalid overlapping operation. (Exposure while reading out images)
※Do not change SensorSyncMode while grabbing (acquiring) images.
※Change Sensor Sync Mode when there is no trigger input.

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
12
□TriggerActivation:
This is to select type and polarity of external trigger signals out of the followings.
・RisingEdge : Fixed trigger shutter mode : Exposure starts with rising edge.
・FallingEdge : Fixed trigger shutter mode : Exposure starts with falling edge.
・LevelHigh : Pulse width trigger shutter mode : Exposure for High-Level period.
・LevelLow : Pulse width trigger shutter mode : Exposure for Low-Level period.
※Do not change TriggerActivation while grabbing (acquiring) images.
※When set LinkTrigger0, disturbance images may occur when start grabbing for the first time after setting
FallingEdge and LevelLow.
□TriggerSource :
This is to select where to send external triggers.
・Software : Trigger input by TriggerSoftware command.
(Software Trigger is invalid with Rising Edge mode.)
・LinkTrigger0 : External trigger input from CoaXPress Host Device.
Please refer to specification manuals for Host Device to know how to generate triggers.
・Line0 : External trigger input from 12pins circular connector.
※Do not change TriggerSource while grabbing (acquiring) images.
□TriggerSoftware : Software trigger
Camera generates a trigger to capture one frame image by executing this command.
Make sure to set TriggerSource to Software to execute.
・RisingEdge(Timed)
・FallingEdge(Timed)
TriggerMode OFF (Free RUN)
ON
(TriggerSelector)(AcquisitionStart)
(FrameStart)
SensorSyncMode TriggerActivation
TriggerSource
= Timed
ClockSync
(No overlap)
LineSync
・LinkTrigger0
・Line0
・TriggerSoftware >Excute
・LevelHigh(TriggerWidth)
・LevelLow(TriggerWidth)
ClockSync
LineSync
= Timed (No overlap)
SensorSyncMode
4.10. Trigger Sync. Mode and Delay Time to Start Exposure
H sync. Trigger mode (LineSync) : 1H of jitter occurs from inputting trigger to exposure.
(Valid overlapping operation).
CLK sync. Trigger mode (ClockSync) : Capable of precise trigger operation with less delay time from trigger
input. (Invalid overlapping operation).
Trigger sync. mode and delay time to start exposure
CXP3_X1
Delay time to start exposure with H sync. trigger (LineSync)
Approx. 1H ~ 2H
Delay time to start exposure with CLK sync. trigger (ClockSync)
Approx. 0.13µs

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
13
4.11. Restrictions on Timing for Trigger Pulse Input
□With LineSync mode, user can input a trigger for the next frame while camera is reading out signals. However, do
not input a trigger pulse to end exposure while camera is reading out signals. In other words, a trigger pulse to start
reading out signals for the next frame before completion of reading out signals for the prior frame is restricted.
Exposure Out
TRIG IN
Readout
(FVAL Out)
(Video Out)
Effective Line
(A)
・If there is a trigger input with restricted timing as explained in the above, “IllegalTriggerFlag” becomes “1”.
Acquisition Control
IllegalTriggerFlag
0 or 1
Device Control
ErrorFlagReset
(Execute)
This is to reset IllegalTriggerFlag to “0”.

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
14
4.12. Fixed Trigger Shutter Mode H Sync. Trigger (LineSync)
(TriggerMode=On, SensorSyncMode=LineSync, TriggerActivation= RisingEdge)
□This is a mode to start exposure with external trigger input and expose for a period set by Exposure Time.
□Trigger operation is H sync. V-sync. reset.
□Delay time (Exposure Time Delay) from detecting the trigger edge in camera to actually starting exposure is
1H~2H.
□Since external trigger signals synchronize with camera internal H signals, 1H jitter occurs to Exposure Time Delay.
□Input a trigger pulse with more than 1H width. For time of 1H, please refer to Section 4.7 for details.
□There is an exposure time period for approx. 7.372μs at the trailing edge of Exposure output.
□Camera accepts triggers while outputting video images. However, do not input any trigger signals to start outputting
the next video before completion of prior video output.
□Camera ignores trigger input during exposure time. (Refer to (A) in the drawing below). Do not use any trigger
cycle shorter than 1 frame.
Effective Line : 1032H
Effective Line
～ ～
Exposure Out
1
2
4
8
1
TRIG IN
LVAL Out
FVAL Out
Video Out
～ ～
1
2
4
8
1
Effective Line
Trigger input ignore period
Exposure Time
Exposure Time Delay
(A)
TRIG IN
Exposure Out
Exposure time delay
Header
Idle Stream data Stream dataIdle Idle
Header
Cxp Stream
ExposureActive
approx. 7.372μs
actual exposure period

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
15
4.13. FAST Fixed Trigger Shutter Mode CLK Sync. Trigger (ClockSync)
(TriggerMode=On, SensorSyncMode=ClockSync, TriggerActivation=RisingEdge)
□This is a mode to start exposure with external trigger input and expose for a period set by Exposure Time.
□Trigger operation is CLK sync. V-sync. reset. Delay time (Exposure Time Delay) from detecting the trigger edge in
camera to actually starting exposure is approx. 0.13μs. Input a pulse with more than 1μs width as a trigger.
□There is an exposure time period for approx. 7.372μs at the trailing edge of Exposure output.
□Camera does not accept any triggers while outputting video images. Camera ignores trigger input during exposure
time and while reading out signals. (Refer to (A) and (B) in the drawing below)
Effective Line : 1032H
Effective Line
～ ～
Exposure Out
1
TRIG IN
LVAL Out
FVAL Out
Video Out
Trigger input ignore period
Exposure Time
Exposure Time Delay
(A)
TRIG IN
Exposure Out Exposure time delay
(B)
～ ～
1
Effective Line
Next trigger rise prohibited period : 3082H
Header
Idle Stream data Stream data Idle
Header
Cxp Stream
ExposureActive
approx. 7.372μs
actual exposure period

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
16
4.14. Pulse Width Trigger Shutter Mode H Sync. Trigger (LineSync)
(TriggerMode=On, SensorSyncMode=LineSync, TriggerActivation=LevelHigh)
□This is a mode to start exposure with external trigger input and expose for a period of pulse width.
□Trigger operation is H sync. V-sync. reset.
Delay time (Exposure Time Delay ①) from detecting the trigger edge in camera to actually starting exposure is
1H~2H. Delay time (Exposure Time Delay ②) from detecting the end edge in camera to actually end exposure is
1H~2H＋7.372μs.
□Since external trigger signals synchronize with camera internal H cycle, approx. 1H jitter occurs to Exposure Time
Delay ①and ②. With pulse width trigger mode, jitters may occur for both exposure start edge and exposure end
edge. Exposure time changes and flicker may become noticeable, especially with high-speed shutter setting. Fixed
trigger shutter mode might eliminate those flickers. However, synchronizing trigger pulse with camera H cycle (LVAL)
to input will solve this problem.
□Functionally, there is no upper limitation, but noises such as dark noise shadings may become noticeable with long
time exposure. Please note that increase of white defective pixels is inevitable with this image sensor.
□There is an exposure time period for approx. 7.372μs at the trailing edge of Exposure output.
□Camera ignores trigger input during exposure time. Do not use any trigger cycle shorter than 1 frame.
□Camera accepts triggers while outputting video images. However, do not input any trigger signals to start outputting
the next video before completion of prior video output. (Refer to (A) in the drawing below)
Effective Line : 1032H
Effective Line
～ ～
Exposure Out
1
2
4
8
1
TRIG IN
LVAL Out
FVAL Out
Video Out
～ ～
1
2
4
8
1
Effective Line
Trigger input ignore period
Exposure Time
Exposure Time Delay①Exposure Time Delay②
(A)
TRIG IN
Exposure Out
Exposure time delay
①
Header
Idle Stream data Stream data
Idle Idle
Header
Cxp Stream
②
ExposureActive
approx. 7.372μs
actual exposure period

VCC-SXCXP1SW Rev.905-0230-01
©2021 CIS Corporation. All rights reserved.
17
4.15. FAST Pulse Width Trigger Shutter Mode CLK Sync. Trigger (ClockSync)
(TriggerMode=On, SensorSyncMode=ClockSync, TriggerActivation=LevelHigh)
□This is a mode to start exposure with external trigger input and expose for a period of pulse width.
□Trigger operation is CLK sync. V-sync. reset.
Delay time (Exposure Time Delay ①) from detecting the trigger edge in camera to actually starting exposure is
Approx. 0.13μs. Delay time (Exposure Time Delay ②) from detecting the end edge in camera to actually end
exposure is approx. 7.372μs.
□Pulse width 2.628μs (Min.) ~ approx. 2 frames
Functionally, there is no upper limitation, but noises such as dark noise shadings may become noticeable with long
time exposure. Please note that increase of white defective pixels is inevitable with this image sensor.
□There is an exposure time period for approx. 7.372µs at the trailing edge of Exposure output.
□Camera ignores trigger input during exposure time. Refer to (A) in the drawing below.
Effective Line : 1032H
Effective Line
～ ～
Exposure Out
3
0
0
0
1
TRIG IN
LVAL Out
FVAL Out
Video Out
Effective Line
Trigger input ignore period
Exposure Time
Exposure Time Delay①Exposure Time Delay②
(A)
TRIG IN
Exposure Out
Exposure time delay
① ②
Effective Line
～ ～
1
Next trigger rise prohibited period : 3082H
Header
Idle Stream data Stream dataIdle Image
Header
Cxp Stream
ExposureActive
approx. 7.372μs
actual exposure period
