CIS VCC-FC21FR19PCL Quick start guide

VCC-FC21FR19PCL Rev.900-760-31
©2016 CIS Corporation. All rights reserved.
Camera link I/F
4M Resolution CMOS
Color (RAW) PoCL
VCC-FC21FR19PCL
Product Specification
& Operational Manual
CIS Corporation
English

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
2
Table of Contents
PAGE
1. Scope of Application............................................................................................................................................3
2. Handling Precautions.............................................................................................................................................3
3. Product Outline...................................................................................................................................................5
4. Specification.......................................................................................................................................................5
4.1. General Specification................................................................................................................................5
4.2. Camera Output Signal Specification ...........................................................................................................7
4.3. CMOS Spectral Response (Representative Value) ........................................................................................8
4.4 Video Output Format ................................................................................................................................9
5. Function Settings .............................................................................................................................................. 10
6. External Connector Pin Assignment..................................................................................................................... 13
6.1. Camera Link Connector 12226-1100-00PL (SUMITOMO 3M)....................................................................... 13
6.2. Power LED ............................................................................................................................................ 13
7. Timing Chart .................................................................................................................................................... 14
7.1. Horizontal Synchronous Signals Timing (2Tap Base Configuration mode: 38fps) ......................................... 14
7.2. Vertical Synchronous Signals Timing (2Tap Base Configuration Mode: 38fps)............................................... 14
7.3. Horizontal Synchronous Signals Timing (4Tap Medium Configuration Mode: 75fps) *Initial Setting ................ 15
7.4. Vertical Synchronous Signals Timing (4Tap Medium Configuration Mode: 75fps) .......................................... 15
7.5. Horizontal Synchronous Signals Timing (8Tap Full Configuration Mode: 150fps)........................................... 16
7.6. Vertical Synchronous Signals Timing (8Tap Full Configuration Mode: 150fps)............................................... 16
7.7. Fixed Trigger Shutter Mode ..................................................................................................................... 17
7.8. Pulse Width Trigger Shutter Mode............................................................................................................ 18
8. Partial Scan Mode ............................................................................................................................................. 19
9. Remote Communication Function ....................................................................................................................... 21
10. Initial Settings .................................................................................................................................................. 22
11. CMOS Optical Axis Accuracy............................................................................................................................... 23
12. Dimensions ...................................................................................................................................................... 24
13. Cases for Indemnity (Limited Warranty) .............................................................................................................. 25
14. CMOS Pixel Defect ............................................................................................................................................ 25
15. Product Support................................................................................................................................................ 25

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
3
1. Scope of Application
This is to describe VCC-FC21FR19PCL, 4M resolution, Power over Camera Link Color CMOS Camera.
All specifications contained herein are subject to change without prior notice. Reproduction in whole or in
part is prohibited.
2. Handling Precautions
The camera must not be used for any nuclear equipments or aerospace equipments with which mechanical
failure or malfunction could result in serious bodily injury or loss of human life. Our warranty does not
apply to damages or defects caused by irregular and/or abnormal use of the product.
Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these precautions.
Do not use or store the camera in the following extreme conditions:
Extremely dusty or humid places.
Extremely hot or cold places (operating temperature –5℃to +45℃)
Close to generators of powerful electromagnetic radiation such as radio or TV transmitters.
Places subject to fluorescent light reflections.
Places subject to unstable (flickering, etc.) lighting conditions.
Places subject to strong vibration.
Remove dust or dirt on the surface of the lens with a blower.
Do not apply excessive force or static electricity that could damage the camera.
Do not shoot direct images that are extremely bright (e.g., light source, sun, etc.), and when camera
is not in use, put the lens cap on.
Follow the instructions in Chapter 6, “External connector pin assignment” for connecting the camera.
Improper connection may cause damages not only to the camera but also to the connected devices.
Confirm the mutual ground potential carefully and then connect the camera to monitors or
computers. AC leaks from the connected devices may cause damages or destroy the camera.
Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power
supply voltage may cause damages or malfunction of the camera.

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
4
The voltage ripple of camera power DC +12V±10% shall be within ±50mV. Improper power
supply voltage may cause noises on the video signals.
The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please
avoid noises like chattering when rising.
Precautions to observe when using partial mode.
At vertical partial scan mode, the smaller the value of read-out lines setting is set, the faster the
camera exposure output speed goes, and the more the power consumption is required at the same
time.
Power requirement of when the minimum read-out line is set with partial scan will be approx 1.5
times more than the one with full frame scan. Naturally, heat of the camera will be increased.
Especially when the read-out line is set in the range of 100 lines to 1 line, heat dissipation is
recommended to install the camera.
Installation recommended.
・Install the camera to the place with ambient temperature under 40 ℃.
・Install the camera to a metallic component.
10 4020 30 50
10
11
12
[V]
Voltage Rising Time [ms]
9
8
7
60 70
Power Supply Voltage

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
5
3. Product Outline
VCC-FC21FR11PCL is a Power over Camera Link interfaced and 4M resolution industrial color video
camera module. 4M pixels CMOS sensor with diagonal length 15.930mm is utilized. Entire pixels can
be read out within 1/75s at Medium Configuration output.
Features
□Global shutter CMOS sensor is utilized.
□Camera Link Base, Medium, and Full Configuration are supported.
□Fixed trigger shutter mode, pulse width trigger shutter mode are operable.
□Full frame rates and video output format are as follows.
□Free Software
CIS control panel software for evaluation purpose only is downloadable via our web.
4. Specification
4.1. General Specification
(1) Pickup Device
Device Type
Diagonal Length 15.930mm, Global Shutter type, Color CMOS
Effective pixel number
2048(H) x 2048(V)
11.264
11.264
(単位:mm)
15.930
Unit cell size
5.5μm(H) x 5.5μm(V)
Image Circle
φ15.930mm
(2) Video Output Frequency
Pixel Clock
80 MHz
2Tap
Base Configuration Mode:
Horizontal frequency:
77.519 kHz
Horizontal clock
1032 CLK
Vertical frequency:
37.558 Hz
Scanning lines
2064 H
4Tap
Medium Configuration Mode:
Horizontal frequency:
155.039 kHz
Horizontal clock
516 CLK
Vertical frequency:
75.116 Hz
Scanning lines
2064 H
8Tap
Full Configuration Mode:
Horizontal frequency:
310.078 kHz
Horizontal clock
258 CLK
Vertical frequency:
150.231 Hz
Scanning lines
2064 H
(3) Sync. System
Internal Sync. System.
(4) Video Output
2Tap Base Configuration
4Tap Medium Configuration (Initial Setting)
8Tap Full Configuration
(5) Resolution
2048 TV Lines
(6) Output Format
Sensor AD
10bit
Camera Link output
8bit / 10bit (Fixed to 8bit at Full Configuration mode.)
Color (RAW) output.
2Tap Base Configuration Mode
38fps
8bit/10bit
4Tap Medium Configuration Mode
75fps
8bit/10bit
8Tap Full Configuration Mode
150fps
8bit
Factory Setting: 4 Tap Medium
75fps
8bit

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
6
(7) Sensitivity
F5.6 2000lx (at Shutter speed 1/75s (OFF), Gain 0dB, and Medium Configuration mode)
(8) Minimum illumination
F1.4 30.0lx (at Shutter speed 1/75s (OFF), Gain +12dB, and Medium Configuration mode)
(9) Dust or stains in optical
system
No dust or stain shall be detected on the testing screen with setting the camera aperture at F16.
(10) Power requirements
PoCL
(11) Power consumption
2.7W (4Tap Medium Configuration mode, Full frame scan output): Initial setting.
4.0W (8Tap Full Configuration mode, Partial scan 100lines output)
(12) Dimensions
Refer to overall dimension drawing. (H:29mm W:29mm D:45mm excluding projection)
(13) Weight
Approx. 75g
(14) IR Cut Filter
With
(15) Lens mount
C Mount * Refer to overall dimension drawing.
(16) Optical axis accuracy
Refer to drawing for CMOS Optical Axis Accuracy.
(17) Gain variable range
0dB ～+12dB (Guaranteed range)
(18) White Balance Adjustment
Range
2800～9000K (Manual White Balance ) (Guaranteed range)
(19) Shutter speed variable
range
OFF ～1/50000s
(20) Trigger shutter mode
Fixed Shutter Trigger Mode/ Pulse Width Shutter Trigger Mode
(21) Partial Scan
Full Frame Scan ～1 line (1 line / step)
(22) Safety/Quality standards
UL: Conform to UL Standard including materials and others.
CE:
EN55022:2010 Class A for Emission
EN61000-6-2:2005 for Immunity
RoHS:
Conform to RoHS.
FCC:
To be applied to FCC Class A digital Device
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
(23) Durability
Vibration
Acceleration
: 98m/s2(10G)
Frequency
: 20～200 Hz
Direction
: X,Y, and Z 3 directions
Testing time
: 120min for each direction
Shock
No malfunction shall be occurred with 980m/s2(100G) for ±X,±Y, and ±Z,
6 directions. (without package)
(24) Operation Environment
Temperature
Performance guaranteed temperature: 0℃～+40℃
Camera operation guaranteed temperature: -5℃～+45℃
※All the specifications specified in this manual is guaranteed under
performance guaranteed temperature.
※All the camera functions operate normally under operation guaranteed
temperature.
Humidity
RH 20～80% with no condensation.
(25) Storage Environment
Temperature
-25℃～+60℃
Humidity
RH 20～80% with no condensation.

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
7
4.2. Camera Output Signal Specification
(1) Video output data
Effective Video Output
2048(H) × 2048(V)
At full frame scan mode
(2) Sync. Signal
output
LVAL
Camera Link output (LVDS):
FVAL
DVAL
SP
Optical Pulse
(3) Camera Control
Signals input
CC2・CC3・CC4
Camera Link Input (LVDS)
(4) Trigger Input
Polarity
Positive/Negative Selectable
Polarity is selectable with
Address 011
Pulse Width
1HD (min.) ～Approx. 2 frames
・2Tap Base Configuration mode
: 1HD (12.9us)
・4Tap Medium Configuration mode
: 1HD (6.45us)
・8Tap Full Configuration mode
: 1HD (3.225us)
Functionally, no upper limitation is set but noises such as dark
noises and shadings might be noticeable at long time exposure.
Trigger Input
：CC1
Camera Link input (LVDS)
(5) Serial
Communication
SerTC (Serial to Camera)
Camera Link input (LVDS）
SerTFG (Serial to Frame Grabber)
Camera Link output (LVDS)
(6) Video Signals
White Clip Level
At Digital 10bit
At Digital 8bit
: 3FFh
: FFh
Setup Level
At Digital 10bit
At Digital 8bit
: under 004h
: under 01h
(Condition: Gain 0dB)
Dark Shading
At Digital 10bit
At Digital 8bit
: Both horizontal and vertical
should be under ±00Fh.
: Both horizontal and vertical
should be under 03h.
(Condition: Gain 0dB)
※2 seconds shall be waited after turning on power to get the camera operate properly.

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
8
4.3. CMOS Spectral Response (Representative Value)
* Lens characteristics and luminous source characteristics are not considered.

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
9
4.4 Video Output Format
(1) 2Tap Base Configuration Mode : 38fps
(2) 4Tap Medium Configuration Mode : 75fps (Initial Setting)
(3) 8Tap Full Configuration Mode : 150fps
・・・
～
～～ ～
2048 Line
2048pixel
GBGB
1 2 3 4
・・・
～
～～ ～
2048 Line
2048pixel
GBGBGBGB
1 2 3 4 5 6 7 8

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
10
5. Function Settings
(Camera functions can be set with serial communications.)
Function
Address
Data
Gain
001
0:
0
dB : Fixed Gain
1:
+
3
dB : Fixed Gain
2:
+
6
dB : Fixed Gain
3:
+
12
dB : Fixed Gain
4:
Manual Gain: over 0～+12dB (Refer to Address 032 and 033.)
Shutter
002
2Tap Mode
4Tap Mode
8Tap Mode
0:
1/38s(OFF)
1/75s(OFF)
1/150s(OFF)
1:
1/75s
1/75s(OFF)
1/150s(OFF)
2:
1/150s
1/150s
1/150s(OFF)
3:
1/350s
1/350s
1/350s
4:
1/500s
1/500s
1/500s
5:
1/750s
1/750s
1/750s
6:
1/1000s
1/1000s
1/1000s
7:
1/2500s
1/2500s
1/2500s
8:
1/5000s
1/5000s
1/5000s
9:
1/7500s
1/7500s
1/7500s
10:
1/10000s
1/10000s
1/10000s
11:
1/15000s
1/15000s
1/15000s
12:
1/20000s
1/20000s
1/20000s
13:
1/30000s
1/30000s
1/30000s
14:
1/30000s
1/40000s
1/40000s
15:
1/30000s
1/40000s
1/50000s
16:
Manual Shutter (Refer to Address 036 and 037.)
White Balance
003
0:
Through
1:
3200K
2:
Through
3:
Through
4:
Manual White Balance
(Refer to the address 046&047, 048&049, and 050&051.)
Trigger Shutter Mode
004
0:
Normal Shutter Mode (Trigger OFF)
1:
Fixed Trigger Shutter Mode (Shutter speed can be set with address 002.)
2:
Pulse Width Trigger Shutter Mode
(Shutter speed can be set with trigger pulse width.)
Trigger Polarity
011
0:
Positive
1:
Negative
Output Data Selection
013
0:
8bit Output
1:
10bit output (10bit cannot be output at 8Tap Full Configuration mode.)
Partial Scan Mode
015
0:
Full Frame Scan Mode
1:
Partial Scan Mode
Output image flip vertical
021
0:
Normal
1:
Flip Vertical
Gain CC Control ON/OFF
023
0:
OFF
1:
ON (Gain and WB can be controlled via CC2, CC3, and CC4.)

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
11
Function
Address
Data
Table Selection for Gain CC
Control
024
0～7:
CC2
CC3
CC4
0:
L
L
L
1:
H
L
L
2:
L
H
L
3:
H
H
L
4:
L
L
H
5:
H
L
H
6:
L
H
H
7:
H
H
H
Table Read/Write for Gain
CC Control
025
0:
Nop
1:
Table Read
2:
Table Write
The following manual gain is written in to the table specified with
Address 024.
Manual Gain (Address 032&033),
Manual WB R (Address 046&047), Manual WB B (Address 048&049),
and Manual WB G (Address 050&051).
3:
Clear Table
Baud Rate
030
0:
9600bps
1:
19200bps
2:
38400bps
3:
57600bps
4:
115200bps
Camera Mode
031
0:
8Tap Full Configuration Mode (150fps)
1:
4Tap Medium Configuration Mode (75fps)
2:
2Tap Base Configuration Mode (38fps)
Manual Gain
032&033
0～767:
0:0dB ～767:+12dB
Manual Shutter
036&037
0～2047:
2Tap mode: Shutter Speed =16.641us + (2048 - (036&037))×12.9us
Min. value 0: 26.436ms(1/38s), Max. value 2047:29.541us(1/30000s)
4Tap mode: Shutter Speed =16.641us + (2048 - (036&037))×6.45us
Min. value 0: 13.226ms(1/75s), Max. value 2047:23.091us(1/40000s)
8Tap mode: Shutter Speed =16.641us + (2048- (036&037))×3.225us
Min. value 0: 6.621ms(1/150s), Max. value 2047: 19.866us (1/50000s)
※Set the data of the address 002 to 016.
Manual White Balance R
046&047
0～767:
0:0dB ～767:+12dB
Set the data of the address 003 to 004.
Manual White Balance B
048&049
0～767:
0:0dB ～767:+12dB
Set the data of the address 003 to 004.
Manual White Balance G
050&051
0～767:
:0dB ～767:+12dB
Set the data of the address 003 to 004.
Cursor Indication ON/OFF
058
0:
OFF
1:
ON
Cursor X Address
061&060
0～2047:
Cursor Y Address
063&062
0～2047:

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
12
Function
Address
Data
Partial scan start position 1
064&065
0～2047:
Partial scan start position 2
066&067
0～2047:
Partial scan start position 3
068&069
0～2047:
Partial scan start position 4
070&071
0～2047:
Partial scan start position 5
072&073
0～2047:
Partial scan start position 6
074&075
0～2047:
Partial scan start position 7
076&077
0～2047:
Partial scan start position 8
078&079
0～2047:
※Set the data of the address 015 to 001.
Partial scan effective line numbers 1
080&081
1～2048:
Set 0 when not in use.
Partial scan effective line numbers 2
082&083
1～2048:
Set 0 when not in use.
Partial scan effective line numbers 3
084&085
1～2048:
Set 0 when not in use.
Partial scan effective line numbers 4
086&087
1～2048:
Set 0 when not in use.
Partial scan effective line numbers 5
088&089
1～2048:
Set 0 when not in use.
Partial scan effective line numbers 6
090&091
1～2048:
Set 0 when not in use.
Partial scan effective line numbers 7
092&093
1～2048:
Set 0 when not in use.
Partial scan effective line numbers 8
094&095
1～2048:
Set 0 when not in use.
※Set the data of the address 015 to 001.
Initial Settings
126
Input 083 to set the camera back to the initial settings.
Data Save
127
Input 083 to save the data to EEP-ROM.
※The data set with 2 Byte shall be set with High Byte (even address) first, then set with Low Byte (odd
address). The camera rewrites the internal resister when receiving Low Byte.

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
13
6. External Connector Pin Assignment
6.1. Camera Link Connector 12226-1100-00PL (SUMITOMO 3M)
Connector (CN1) Connector (CN2)
6.2. Power LED
(1) Power LED is lit when power is supplied to the camera via the frame grabber board.
※Power to the camera shall be supplied only via CN1 of the Base connector side. CN1 power line of the Medium or Full
configuration connector side shall be kept open. Do not plug and unplug the camera link cables since it may cause the
camera malfunction.
Pin
No.
Pin
No.
Pin
No.
Pin
No.
1
GND/+12V(PoCL)
14
GND
1
NA
14
GND
2
X0-
15
X0+
2
Y0-
15
Y0+
3
X1-
16
X1+
3
Y1-
16
Y1+
4
X2-
17
X2+
4
Y2-
17
Y2+
5
Xclk-
18
Xclk+
5
Yclk-
18
Yclk+
6
X3-
19
X3+
6
Y3-
19
Y3+
7
SerTC+
20
SerTC-
7
100Ω
20
Terminated
8
SerTFG-
21
SerTFG+
8
Z0-
21
Z0+
9
CC1-(Trigger IN -)
22
CC1+ (Trigger IN +)
9
Z1-
22
Z1+
10
CC2+
23
CC2-
10
Z2-
23
Z2+
11
CC3-
24
CC3+
11
Zclk-
24
Zclk+
12
CC4+
25
CC4-
12
Z3-
25
Z3+
13
GND
26
GND/+12V(PoCL)
13
GND
26
NA

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
14
7. Timing Chart
7.1. Horizontal Synchronous Signals Timing (2Tap Base Configuration mode: 38fps)
7.2. Vertical Synchronous Signals Timing (2Tap Base Configuration Mode: 38fps)

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
15
7.3. Horizontal Synchronous Signals Timing (4Tap Medium Configuration Mode: 75fps) *Initial Setting
7.4. Vertical Synchronous Signals Timing (4Tap Medium Configuration Mode: 75fps)

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
16
7.5. Horizontal Synchronous Signals Timing (8Tap Full Configuration Mode: 150fps)
7.6. Vertical Synchronous Signals Timing (8Tap Full Configuration Mode: 150fps)

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
17
7.7. Fixed Trigger Shutter Mode
□This is the mode to start exposure with external input trigger signals, and set the exposure time with
serial commands.
□Trigger operation is H Sync. V-Sync Reset. The delay time (Exposure Time Delay) from
detecting trigger edge in the camera to starting exposure is max. 1HD.
□Triggers can be accepted even when outputting video signals. However, trigger signals for
exposure to start the next video output prior to the completion of video transmission for the prior
video output signals cannot be accepted.
□If the next trigger is input prior to the completion of video transmission for the prior video output
signals, the image may be impacted.
□Trigger input during exposure time should be ignored. (Refer to the below A).

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
18
7.8. Pulse Width Trigger Shutter Mode
□This is the mode to start exposure with external input trigger signals, and set the exposure time with
pulse width of the trigger signals.
□Trigger operation is H Sync. V-Sync Reset. The delay time (Exposure Time Delay) from
detecting trigger edge in the camera to starting exposure, and from detecting trigger end edge to
completing exposure is max. 1HD.
□Pulse width is min. 1HD to approx. 2 frames. Functionally, there is no upper limitation, but noises
such as dark noises and shadings may be noticeable at long time exposure.
□Triggers can be accepted even when outputting video signals. However, trigger signals for
exposure to start the next video output prior to the completion of video transmission for the prior
video output signals cannot be accepted.
□If the next trigger is input prior to the completion of video transmission for the prior video output
signals, the image may be impacted.

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
19
8. Partial Scan Mode
□Maximum 8 partial areas can be set by serial commands.
Example ：3 partial areas to be set.
①：V Blanking Line Number
②:Partial Area 1
③：Partial Area 2
④：Partial Area 3
⑤：Total Frame Line Number
FVAL
LVAL
①
⑤
②
③
④
Video Out
Partial Scan Setting
Partial scan start position 1
(
Address 064 & 065)
④
Partial scan start position 3
(
Address 068 & 069)
③
Partial scan effective lines 2
(Address 082&083)
Partial scan start position 2
(
Address 066 & 067)
②
Partial scan effective lines 3
(Address 084&085)
0
2047
Partial scan effective lines 1
(Address 080&081)
④
③
Partial scan effective lines 2
(Address 082&083)
②
Partial scan effective lines 3
(Address 084&085)
Partial scan effective lines 1
(Address 080&081)
Data sequence of output video

VCC-FC21FR19PCL Rev. 900-760-31
©2016 CIS Corporation. All rights reserved.
20
□When setting several partial scan areas, please set the start position and effective lines trying not to
overlap the areas.
□When setting several areas, please set the areas in the numerical order of starting position.
□Entire frame line numbers = V blanking line numbers (16H fixed) ＋
Partial effective lines 1 + Partial effective lines 2 + ・・・ + Partial effective lines 8
Note that “Sum total of partial effective line numbers (except V blanking lines) ≦2048”should be met.
□Frame rate = 1 / (Entire frame line numbers x Time for 1 line)
Time for 1 line
Camera Mode
Time for 1 Line
2Tap Base Configuration Mode
12.9us
4Tap Medium Configuration Mode
6.45us
8Tap Full Configuration Mode
3.225us
□Setting Example
□Line numbers at partial scan setting can be set from 1 line. However, consumption current will
increase several hundreds mA more so that the margin of camera power capacity shall be considered.
Effective
Lines
Entire
Frame Lines
Frame Rate (Entire frame lines)
2Tap Mode
4Tap Mode
8Tap Mode
1(Min)
1 H
17H
4560fps
9120fps
18240fps
・
・
Vertical:VGA
equivalent
480 H
496H
156fps
313fps
625fps
・
・
Vertical:XGA
equivalent
768 H
784H
99fps
198fps
396fps
・
・
Vertical:SXGA
equivalent
1024 H
1040H
75fps
149fps
298fps
・
・
Vertical:UXGA
equivalent
1200 H
1216H
64fps
127fps
255fps
・
・
2048
(Max:Full Frame)
2048 H
2064H
38fps
75fps
150fps
