Cisco Aironet Dual-Band Omni-Directional
Antenna (AIR-ANT2568VG-N)
First Published: July 2015
Last Updated: November 15, 2018
This describes the Cisco Aironet AIR-ANT2568VG-N dual-band omni-directional antenna, and provides specifications
and mounting instructions. The antenna is designed for outdoor use with Cisco Aironet Outdoor Access Points with
radios operating in the 2.4 GHz and 5 GHz frequency bands.
These topics are discussed:
Technical Specifications, page 2
System Requirements, page 4
Safety Precautions, page 4
Installation Notes, page 4
Obtain Documentation and Submit a Service Request, page 5

2
Cisco Aironet Dual-Band Omni-Directional Antenna (AIR-ANT2568VG-N)
Technical Specifications
Technical Specifications
Antenna Type Omni-directional
Operating Frequency Range 2400–2483 MHz; 5150–5925 MHz
VSWR 1.5:1 (2400–2483 MHz)
2:1 (5150–5925 MHz)
Nominal Input Impedance 50 Ohms
Gain 6 dBi (2400–2483 MHz)
8 dBi (5150–5925 MHz)
Polarization Vertical
Azimuth Plane Ripple 2 dB (Max)
Elevation Plane 3 dB Beamwidth 24° (2400–2483 MHz)
11° (5150–5925 MHz)
Azimuth Plane 3 dB Beamwidth Omni-directional
Length 14.8 in (377 mm)
Diameter 1.25 in (31.75 mm)
Weight 7.2 oz. (204.1 g)
Connector N-Male
Operational Temperature -22–158°F (-30–70°C)
Storage Temperature -40–185°F (-40–85°C)
Water/Foreign Body Ingress IP67
Wind Rating (Operational) 100 mph (161 kph)
Wind Rating (Survival) 136 mph (218 kph)

3
Cisco Aironet Dual-Band Omni-Directional Antenna (AIR-ANT2568VG-N)
Technical Specifications
Azimuth Radiation Pattern (2.4 GHz) Elevation Radiation Pattern (2.4 GHz)
Azimuth Radiation Pattern (5 GHz) Elevation Radiation Pattern (5 GHz)

4
Cisco Aironet Dual-Band Omni-Directional Antenna (AIR-ANT2568VG-N)
System Requirements
System Requirements
This antenna is designed for use with the Cisco Aironet Outdoor Access Points.
Safety Precautions
Warning: Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it
can come into contact with such circuits. When installing the antenna, take extreme care not to come into contact
with such circuits, as they may cause serious injury or death. For proper installation and grounding of the antenna,
please refer to national and local codes (e.g. U.S.: NFPA 70, National Electrical Code, Article 810, Canada: Canadian
Electrical Code, Section 54). Statement 280
For your safety, read and follow these safety precautions.
1. Before you install an antenna, contact your Cisco account representative to explain which mounting method to use
for the size and type of antenna that you are about to install.
2. Find someone to help you—installing an antenna is often a two-person job.
3. Select your installation site with safety, as well as performance, in mind. Remember that electric power lines and
phone lines look alike. For your safety, assume that any overhead line can kill you.
4. Contact your electric power company. Tell them your plans and ask them to come look at your proposed installation.
5. Plan your installation carefully and completely before you begin. Each person involved in an installation should be
assigned to a specific task and should know what to do and when to do it. One person should be in charge of the
operation to issue instructions and watch for signs of trouble.
6. When installing your antenna, follow these guidelines:
a. Do not use a metal ladder.
b. Do not work on a wet or windy day.
c. Dress properly: wear shoes with rubber soles and heels, rubber gloves, and a long-sleeved shirt or jacket.
7. If the assembly starts to drop, move away from it and let it fall. Because the antenna, mast, cable, and metal guy
wires are all excellent conductors of electrical current, even the slightest touch of any of these parts to a power line
completes an electrical path through the antenna and the installer.
8. If any part of the antenna system should come in contact with a power line, do not touch it or try to remove it yourself.
Call your local power company to have it removed safely.
9. If an accident should occur with the power lines, call for qualified emergency help immediately.
Installation Notes
The antenna is designed to connect to a dedicated antenna port on the access point. No special tools are required to
install the antenna.
The antenna is resistant to the full range of outdoor environments. After the antenna is attached to the access point, seal
the connections to prevent moisture and other weathering elements from affecting performance. Cisco recommends
using a coax seal (such as CoaxSeal) for outdoor connections. Silicone sealant or electrical tape are not recommended
for sealing outdoor connections.

5
Cisco Aironet Dual-Band Omni-Directional Antenna (AIR-ANT2568VG-N)
Installation Notes
Choosing a Mounting Location
The antenna is designed to create an omni-directional broadcast pattern. To achieve this pattern, the access point should
be mounted clear of any obstructions to the sides of the radiating element. If the mounting location is on the side of a
building or tower, the antenna pattern is degraded on the building or tower side.
Generally, the higher an antenna is above the ground, the better it performs. A practice is to install your antenna about 5
to 10 ft (1.5 to 3 m) above the roof line and away from all power lines and obstructions.
Tools and Equipment Required
No tools are required to mount the antenna to the access point. However, you may need a ¾ in. (19 mm) open end or
combination wrench (or adjustable wrench) to remove the antenna port covers.
For information about tools required to mount the access point, see the appropriate access point documentation.
Mounting the Antenna
To connect the antenna to the access point:
1. If necessary, remove the antenna port cover.
2. Align the antenna N connector with the appropriate antenna port.
3. Gently push the antenna into the port.
4. Tighten the antenna hand tight.
