Cisco ANT-4G-PNL-OUT-N User manual

CHAPTER
6-1
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
6
Cisco Multiband Panel Outdoor 4G MIMO
Antenna (ANT-4G-PNL-OUT-N)
This chapter describes the technical specifications and installation instructions for the Cisco Multiband
Panel Outdoor 4G MIMO antenna, hereafter referred to as the antenna. The antenna is a dual-port
antenna designed to cover cellular 4G bands. The supported bands are:
•LTE700/Cellular/PCS/AWS/MDS
•global GSM900/GSM1800/UMTS/LTE2600
•WiMAX 2300/2500
The antenna supports the following Cisco Connected Grid and IR800 Industrial Integrated Services
routers:
•CGR 1120
•CGR 1240
•CGR 1240
•IR809
•IR829
Caution Read the information in “Safety Precautions” section on page 6-20 before installing or
replacing antennas.
The topics included are:
•Antenna Overview, page 6-2
•Technical Specifications, page 6-3
•Installing the Antenna, page 6-18
•Obtaining Documentation and Submitting a Service Request, page 6-22

6-2
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Antenna Overview
Antenna Overview
•Antenna Features, page 6-2
•Antenna Model, page 6-2
•Antenna Assembly, page 6-2
Antenna Features
The antenna features:
•3G, 4G, and WiMAX 2300/2500 operation
•698–960, 1710–2700 MHz band support
•4G directional panel, dual-polarized/MIMO
•Indoor or outdoor location
•Wall mount or mast mount installation
•Dual type N female connector
Antenna Model
Antenna Assembly
Figure 6-1 Cisco ANT-4G-PNL-OUT-N Antenna
Table 6-1 Cisco Multiband Panel Outdoor 4G MIMO antenna
Antenna Model Description
ANT-4G-PNL-OUT-N Cisco Multiband Panel Outdoor 4G MIMO antenna

6-3
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
Technical Specifications
•Radio Frequency Specifications, page 6-3
•Antenna Radiation Patterns, page 6-3
•Environmental Specifications, page 6-17
•Mechanical Specifications, page 6-18
•Power Specifications, page 6-18
Radio Frequency Specifications
Antenna Radiation Patterns
•698 MHz Antenna Radiation Pattern, page 6-4
Table 6-2 Antenna Radio Frequency Specification
Specification Description
Antenna type 4G directional panel, dual-polarized/MIMO
Frequency •698 to 960MHz
•1710 to 2700 MHz
Nominal impedance 50 ohms
VSWR 2.0:1 Maximum
Gain The gain values (dBi) for each frequency range
are:
•698 to 960 MHz—8.0 to 10.0 dBi
•1710 to 2170 MHz—6.0 to 8.5 dBi
•2200 to 2400 MHz—6.5 to 9.5 dBi
•2500 to 2700 MHz—8.5 to 9.5 dBi
3 dB beamwidth (vertical plane) •55 to 70 degrees—698 to 960 MHz
•53 to 98 degrees—1710 to 2200 MHz
•60 to 70 degrees—2200 to 2500 MHz
•55 to 70 degrees—2500 to 2700 MHz
3 dB beamwidth (horizontal plane) •55 to 70 degrees—698 to 960 MHz
•50 to 90 degrees—1710 to 2200 MHz
F/B ratio •> 15 dB, typical 20 dB—698 to 960 MHz
•> 17 dB, typical 23 dB—1700 to 2700 MHz
Isolation •> 30 dB
Polarization Slant +/- 45 degrees
Radiation Pattern Directional

6-4
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Technical Specifications
•880 MHz Antenna Radiation Pattern, page 6-6
•960 MHz Antenna Radiation Pattern, page 6-8
•1710 MHz Antenna Radiation Pattern, page 6-10
•1950 MHz Antenna Radiation Pattern, page 6-12
•2170 MHz Antenna Radiation Pattern, page 6-14
•2700 MHz Antenna Radiation Pattern, page 6-16
698 MHz Antenna Radiation Pattern
•698 MHz Antenna Radiation Pattern—Horizontal Plane, page 6-4
•698 MHz Antenna Radiation Pattern—Vertical Plane, page 6-5
698 MHz Antenna Radiation Pattern—Horizontal Plane
Figure 6-2 698 MHz Antenna Radiation Pattern—Horizontal Plane
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349220
Line Color Description
Blue (—)Port1
Red (—)Port2

6-5
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
698 MHz Antenna Radiation Pattern—Vertical Plane
Figure 6-3 698 MHz Antenna Radiation Pattern—Vertical Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349221

6-6
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Technical Specifications
880 MHz Antenna Radiation Pattern
•880MHz Antenna Radiation Pattern—Horizontal Plane, page 6-6
•880MHz Antenna Radiation Pattern—Vertical Plane, page 6-7
880MHz Antenna Radiation Pattern—Horizontal Plane
Figure 6-4 880 MHz Antenna Radiation Pattern—Horizontal Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349222

6-7
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
880MHz Antenna Radiation Pattern—Vertical Plane
Figure 6-5 880 MHz Antenna Radiation Pattern—Vertical Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349223

6-8
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Technical Specifications
960 MHz Antenna Radiation Pattern
•960 MHz Antenna Radiation Pattern—Horizontal Plane, page 6-8
•960 MHz Antenna Radiation Pattern—Vertical Plane, page 6-9
960 MHz Antenna Radiation Pattern—Horizontal Plane
Figure 6-6 960 MHz Antenna Radiation Pattern—Horizontal Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349224

6-9
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
960 MHz Antenna Radiation Pattern—Vertical Plane
Figure 6-7 960 MHz Antenna Radiation Pattern—Vertical Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349225

6-10
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Technical Specifications
1710 MHz Antenna Radiation Pattern
•1710 MHz Antenna Radiation Pattern—Horizontal Plane, page 6-10
•1710 MHz Antenna Radiation Pattern—Vertical Plane, page 6-11
1710 MHz Antenna Radiation Pattern—Horizontal Plane
Figure 6-8 1710 MHz Antenna Radiation Pattern—Horizontal Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349226

6-11
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
1710 MHz Antenna Radiation Pattern—Vertical Plane
Figure 6-9 1710 MHz Antenna Radiation Pattern—Vertical Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349227

6-12
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Technical Specifications
1950 MHz Antenna Radiation Pattern
•1950 MHz Antenna Radiation Pattern—Horizontal Plane, page 6-12
•1950 MHz Antenna Radiation Pattern—Vertical Plane, page 6-13
1950 MHz Antenna Radiation Pattern—Horizontal Plane
Figure 6-10 1950 MHz Antenna Radiation Pattern—Horizontal Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349228

6-13
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
1950 MHz Antenna Radiation Pattern—Vertical Plane
Figure 6-11 1950 MHz Antenna Radiation Pattern—Vertical Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349229

6-14
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Technical Specifications
2170 MHz Antenna Radiation Pattern
•2170 MHz Antenna Radiation Pattern—Horizontal Plane, page 6-14
•2170 MHz Antenna Radiation Pattern—Vertical Plane, page 6-15
2170 MHz Antenna Radiation Pattern—Horizontal Plane
Figure 6-12 2170 MHz Antenna Radiation Pattern—Horizontal Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349230

6-15
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
2170 MHz Antenna Radiation Pattern—Vertical Plane
Figure 6-13 2170 MHz Antenna Radiation Pattern—Vertical Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349231

6-16
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Technical Specifications
2700 MHz Antenna Radiation Pattern
•2700 MHz Antenna Radiation Pattern—Horizontal Plane, page 6-16
•2700 MHz Antenna Radiation Pattern—Vertical Plane, page 6-17
2700 MHz Antenna Radiation Pattern—Horizontal Plane
Figure 6-14 2700 MHz Antenna Radiation Pattern—Horizontal Plane
Line Color Description
Blue (—)Port1
Red (—)Port2
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349232

6-17
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Technical Specifications
2700 MHz Antenna Radiation Pattern—Vertical Plane
Figure 6-15 2700 MHz Antenna Radiation Pattern—Vertical Plane
Environmental Specifications
Line Color Description
Blue (—)Port1
Red (—)Port2
Table 6-3 Environmental Specifications for the Cisco ANT-4G-PNL-OUT-N Antenna
Specification Description
Operating temperature range -40 to 158°F (-40 to 70°C)
Storage temperature range -40 to 185°F (-40 to +85°C)
30
25
20
15
10
5
0
5
10
0
30
60
90
120
150
180
210
240
270
300
330
349233

6-18
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Installing the Antenna
Mechanical Specifications
Power Specifications
Installing the Antenna
The antenna installation includes the following procedures:
•Contents of the Antenna Kit, page 6-19
•Safety Warnings, page 6-19
•Safety Precautions, page 6-20
•Tools and Equipment Required, page 6-21
•Preparing the Antenna for Installation, page 6-21
•Mounting the Antenna, page 6-21
•Connecting the Lightning Arrestor, page 6-22
•Connecting the Antenna to the Router, page 6-22
Table 6-4 Mechanical Specifications for the Cisco ANT-4G-PNL-OUT-N Antenna
Specification Description
Mount style Wall or mast mount
Location Indoor or outdoor
Connector Dual type N female direct connect
Dimensions (width x length x height) 11.61 x 11.61 x 3.23 in. (29.5 x 29.5 x 82 cm)
Weight 3.22 lbs (1.46 kg)
Wind rating 160 km/hr (93 mph)
IP rating IP55
Radome Polycarbonate, UV resistant, white
Material substance compliance ROHS compliant
Table 6-5 Power Specifications for the Cisco ANT-4G-PNL-OUT-N Antenna
Specification Description
Maximum Voltage 2.0:1
Nominal Impedance 50 ohms
Maximum input power per port 10 watts

6-19
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N) Installing the Antenna
Contents of the Antenna Kit
The antenna kit contains:
•1 x Cisco ANT-4G-PNL-OUT-N antenna
•1 x mounting bracket
Safety Warnings
Warning Avoid using or servicing any equipment that has outdoor connections during an electrical storm.
There may be a risk of electric shock from lightning. Statement 1088
Warning Do not work on the system, or connect or disconnect cables, during periods of lightning activity.
Statement 1001
Warning Do not locate the outdoor antenna near overhead power lines or other electric light or power
circuits, or where it can come into contact with such circuits. When installing the antenna, take
extreme care not to come into contact with such circuits, as they may cause serious injury or
death. For proper installation and grounding of the antenna, please refer to national and local
codes (for example, U.S.:NFPA 70, National Electrical Code, Article 810, Canada:Canadian
Electrical Code, Section 54). Statement 1052
Warning This equipment must be grounded. Never defeat the ground conductor or operate the equipment
in the absence of a suitably installed ground conductor. Contact the appropriate electrical
inspection authority or an electrician if you are uncertain that suitable grounding is available.
Statement 1024
Warning Only trained and qualified personnel should be allowed to install, replace, or service this
equipment. Statement 1030
Warning To report a gas leak, do not use a telephone in the vicinity of the leak. Statement 1039
Warning This warning symbol means danger. You are in a situation that could cause bodily injury. Before
you work on any equipment, be aware of the hazards involved with electrical circuitry and be
familiar with standard practices for preventingaccidents. Use the statement number provided at
the end of each warning to locate its translation in the translated safety warnings that
accompanied this device. Statement 1071. SAVE THESE INSTRUCTIONS.

6-20
Cisco CGR 1000 and 2000 Series Connected Grid Antennas Guide
Chapter 6 Cisco Multiband Panel Outdoor 4G MIMO Antenna (ANT-4G-PNL-OUT-N)
Installing the Antenna
Warning This product is not intended to be directly connected to the Cable Distribution System.
Additional regulatory compliance and legal requirements may apply for direct connection to the
Cable Distribution System. This product may connect to the Cable Distribution System ONLY
through a device that is approved for direct connection. Statement 1078
Safety Precautions
Warning Installation of this antenna near power lines is dangerous. For your safety, follow the installation
directions.
Each year hundreds of people are killed or injured when attempting to install an antenna. In many of
these cases, the victim was aware of the danger of electrocution, but did not take adequate steps to avoid
the hazard.
For your safety, and to help you achieve a good installation, please read and follow these safety
precautions. They may save your life!
For your safety, read and follow these safety precautions.
•If you are installing an antenna for the first time, for your own safety as well as others, seek
professional assistance. Your Cisco sales representative can explain which mounting method to use
for the size and type antenna you are about to install.
•Before you install an antenna, contact your Cisco account representative to explain which mounting
method to use for the size and type of antenna that you are about to install.
•Find someone to help you—installing an antenna is often a two-person job.
•Select your installation site with safety, as well as performance, in mind. Remember that electric
power lines and phone lines look alike. For your safety, assume that any overhead line can kill you.
•Contact your electric power company. Tell them your plans and ask them to come look at your
proposed installation.
•Plan your installation carefully and completely before you begin. Each person involved in an
installation should be assigned to a specific task, and should know what to do and when to do it. One
person should be in charge of the operation to issue instructions and watch for signs of trouble.
•When installing your antenna, follow these guidelines:
– Do not use a metal ladder.
– Do not work on a wet or windy day.
– Do dress properly—wear shoes with rubber soles and heels, rubber gloves, and a long-sleeved
shirt or jacket.
•If the assembly starts to drop, move away from it and let it fall. Because the antenna, mast, cable,
and metal guy wires are all excellent conductors of electrical current, even the slightest touch of any
of these parts to a power line completes an electrical path through the antenna and the installer.
•If any part of the antenna system should come in contact with a power line, do not touch it or try to
remove it yourself. Call your local power company to have it removed safely.
•If an accident should occur with the power lines, call for qualified emergency help immediately.
