Cisco 1003 and Cisco 1004 User Guide 1
Cisco 1003 and Cisco 1004
User Guide
This publication provides procedures for installing and configuring the Cisco 1003 and
Cisco 1004 routers.
Note All Cisco technical documentation and additional literature are available on
UniverCD, Cisco’sonlinelibraryofproductinformation. UniverCDis updatedandshipped
monthly, so it might be more up to date than printed documentation. UniverCD is available
both as a single CD and as an annual subscription. To order UniverCD, contact your local
sales representative or call Customer Service.
Throughout the text, “the router” means both the Cisco 1003 and Cisco 1004 routers,
unless indicated otherwise.

2Cisco 1003 and Cisco 1004 User Guide
Overview of the Cisco 1003 and Cisco 1004 Routers
Overview of the Cisco 1003 and Cisco 1004 Routers
The Cisco 1003 and Cisco 1004 routers provide Integrated Services Digital Network
(ISDN) capability in a small, desktop router. The routers connect small, remote sites with
Ethernet LANs to WANs.
The main difference between the two routers is that the Cisco 1004 router includes an
integrated network termination 1 (NT1) device and the Cisco 1003 router does not. The
ISDN service provider supplies the NT1 connection worldwide, except in North America,
where the NT1 device is supplied by the customer. Therefore, the Cisco 1004 router is for
use in North America, and the Cisco 1003 router is ideally suited for use elsewhere.
From the front, the outward appearance of the routers is the same.
H3864

Cisco 1003 and Cisco 1004 User Guide 3
Overview of the Cisco 1003 and Cisco 1004 Routers
From the back, the routers are the same with the following exceptions:
•The ISDN BRI (RJ-45) port is labeled “ISDN S/T” on the Cisco 1003 router and
“ISDN U” on the Cisco 1004 router.
•The product name—Cisco 1003 or Cisco 1004—is stamped on the chassis at the upper
left side (not shown).
Both routers include the following connectors:
•ISDN BRI (RJ-45)
•10BaseT Ethernet (RJ-45)
•Console (RJ-45)
•PCMCIA (Flash memory card) slot
•12 VDC power input
H2845
PCMCIA DC power
input
ISDN
(BRI)
10BaseT
Console

4Cisco 1003 and Cisco 1004 User Guide
System Specifications
System Specifications
Following are the specifications for the routers:
1. NVRAM = nonvolatile random-access memory.
2. The ISDN BRI port is labeled “ISDN S/T” on the Cisco 1003 router and “ISDN U” on the Cisco 1004
router. The Cisco 1004 router includes an integrated NT1 device.
Description Specification
Dimensions (H x W x D) 1.75 x 8.0 x 8.3" (4.4 x 20.3 x 21.1 cm)
Weight 2.6 lb (1.2 kg)
Input voltage, frequency,
and power dissipation 12 VDC output, minimum 0.5 A
Desktop external power supply: 100 to 240 VAC at
50 to 60 Hz, 1.0A input
Wall-mount external power supply: 120 VAC at 60 Hz input
Memory 4 MB DRAM (SIMM)
1 MB boot PROM
8 KB NVRAM1
WAN interface 1 ISDN BRI (RJ-45)2
Ethernet interface 1 10BaseT (RJ-45)
PCMCIA slot 1 Flash memory card (Type 2)
Console interface 1 asynchronous serial (RJ-45)
Operating environment 32 to 104
°
F (0 to 40°C)
Operating humidity 10 to 90%, noncondensing
EMI compliance Cisco 1003 router: FCC Class B, VDE Class B, Canadian
DOC Class B, EN55022 Class B (CISPR22 B), VCCI Class 2
Cisco 1004 router: FCC Class B, Canadian DOC Class B
Safety compliance Cisco 1003 router: UL 1950, CSA 22.2 No. 950,
EN60950:1992
Cisco 1004 router: UL 1950, CSA 22.2 No. 950

Cisco 1003 and Cisco 1004 User Guide 5
Canadian Department of Communications Notice
Canadian Department of Communications Notice
The Canadian Department of Communications label identifies certified equipment. This
certification means that the equipment meets certain telecommunications network
protective operational and safety requirements. The Department does not guarantee the
equipment will operate to the user’s satisfaction.
Before installing the equipment, users should ensure that it is permissible to be connected
to the facilities of the local telecommunications company. The equipment must also be
installed using an acceptable method of connection. In some cases, the company’s inside
wiring associated with a single line individual service may be extended by means of a
certified connector assembly (telephone extension cord). The customer should be aware
that compliance with the above conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance
facility designated by the supplier. Any repairs or alterations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications company cause
to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the
power utility, telephone lines and internal metallic water pipe system, if present, are
connected together. This precaution may be particularly important in rural areas.
Caution Users should not attempt to make such connections themselves, but should
contact the appropriate electric inspection authority, or electrician, as appropriate.

6Cisco 1003 and Cisco 1004 User Guide
Preparing to Install Your Cisco 1003 or Cisco 1004 Router
Preparing to Install Your Cisco 1003 or Cisco 1004 Router
It takes just a few simple steps to install your router. But before you install your router,
please read the safety information in this section.
Note Translations of the safety warnings in this document are available at the end of this
publication in the section “Translated Safety Warnings.” Additional guidelines related to
regulatory compliance and safety are available in the
Cisco
1003 and Cisco 1004 Public
Network Certification publication.
Safety Recommendations
Warning The warning symbol means danger. You are in a situation that could cause
bodily injury. Before you work on any equipment, be aware of the hazards involved with
electrical circuitry and standard practices for preventing accidents. To see translated
versions of this warning, refer to the section “Translated Safety Warnings” at the end of this
publication.
Because any device that uses electricity must be treated with respect, follow these
guidelines to ensure general safety:
•Keep the area clear and dust-free during and after installation.
•Keep tools away from walk areas where you and others could trip over them.
•Wearsafety glasses when working under anyconditions that might be hazardous to your
eyes.
•Do not perform any action that creates a potential hazard to people or makes the
equipment unsafe.

Cisco 1003 and Cisco 1004 User Guide 7
Preparing to Install Your Cisco 1003 or Cisco 1004 Router
Warning Before working on equipment that is connected to power lines, remove jewelry
(including rings, necklaces, and watches). Metal objects will heat up when connected to
power and ground and can cause serious burns or weld the metal object to the terminals. To
see translated versions of this warning, refer to the section “Translated Safety Warnings” at
the end of this publication.
•Locate the emergency power-off switch for the room in which you are working. Then,
if an electrical accident occurs, you can act quickly to shut off power.
•There are no user serviceable parts inside the router. Return the router if service is
required.
•Disconnect all power before doing the following:
—Installing or removing the router
—Working near power supplies
•Do not work alone if potentially hazardous conditions exist.
•Never assume that power is disconnected from a circuit. Always check.
•Look carefully for possible hazards in your work area, such as moist floors, ungrounded
power extension cables, and missing safety grounds.
•If an electrical accident occurs, proceed as follows:
—Use caution; do not become a victim yourself. Disconnect power to the router.
—If possible, send another person to get medical aid. Otherwise, assess the condition
of the victim and then call for help.
—Determine if the person needs rescue breathing or external cardiac compressions;
then take appropriate action.

8Cisco 1003 and Cisco 1004 User Guide
Preparing to Install Your Cisco 1003 or Cisco 1004 Router
Inspecting Your Router
Keep the router in the shipping container to prevent accidental damage until you have
determined where you want to install it; then proceed with unpacking it. Check the packing
list to ensure that you received the following items:
•Cisco 1003 or Cisco 1004 router
•Console cable (RJ-45-to-RJ-45)
•RJ-45-to-DB-25 adapter, for use with the console cable
•External power supply, desktop or wall-mount model
Note If your router ships with the desktop power supply, a 6-foot (1.8-meter) power cord
is included with the appropriate plug for the country to which the router is shipped.
•Label printed with the serial number and Media Access Control (MAC) address, which
is attached to the outside of the shipping container
•The warranty package, which includes the Product Registration form, service and
support information, and the Ordering Cisco Documentation publication.
Depending on the options you selected, your order might also include the following items:
•Optional PCMCIA Flash memory card
•Optional equipment (network connection cables)
•Optional companion publications
Inspect all items for shipping damage. If anything appears to be damaged or missing,
contact your system administrator or customer service representative.

Cisco 1003 and Cisco 1004 User Guide 9
Installing Your Cisco 1003 or Cisco 1004 Router
Installing Your Cisco 1003 or Cisco 1004 Router
Installing the router is quick and simple.
POWER SYSTEM SERIAL SERIAL LAN LAN COLLISION LINK
OK TX RX TX RX OK
POWER SYSTEM SERIAL SERIAL LAN LAN COLLISION LINK
OK TX RX TX RX OK
OR
Inspect your router.
Decide where to put your router:
on a desktop or wall.
Connect the cables to your network.
Connect the desktop
power supply (shown)
or the wall-mount
power supply.
Test your router installation.
Configure your router, if not
preconfigured, using your 
console terminal.
H4200
12VDC
Insert your Flash memory card
(if supplied).
12VDC
12VDC

10 Cisco 1003 and Cisco 1004 User Guide
Installing Your Cisco 1003 or Cisco 1004 Router
Required Tools and Parts
Following are the tools and parts required to install your router:
•A 3/16-inch (0.476 cm) flat-blade screwdriver or socket screwdriver
•Wall-mount hardware, including screws, which you must provide
•A console cable (RJ-45-to-RJ-45)
•RJ-45-to-DB-25 adapter, for use with the console cable
•One interface cable for the LAN port (10BaseT Ethernet)
•One interface cable for the BRI ISDN (WAN) port
•An NT1 device for access to an ISDN through the BRI port (Cisco 1003 only)
The ISDN service provider provides the NT1 connection worldwide, except in North
America, where the NT1 device is supplied by the customer. The Cisco 1004 router
contains an integrated NT1 device. If you have a Cisco 1003 router, a separate NT1 device
is required.
The router can be placed on any flat surface or installed in any orientation, such as upside
downor onaverticalsurface. Therouterisdesigned to allowtrouble-freeoperation without
cooling fans, special equipment closets, or racks.
To avoid the possibility of the cables becoming disconnected, install your router in a
manner that minimizes strain on the cables.
Setting Your Router on a Desktop
Caution If you place the router on a desk or table, do not place anything on top of it that
couldrestrictairflow around the router or weighs in excess of10pounds(4.5kg).Excessive
weight on top of the router could cause damage.

Cisco 1003 and Cisco 1004 User Guide 11
Installing Your Cisco 1003 or Cisco 1004 Router
To place your router on a desktop, shelf, or other flat, secure surface, perform the following
steps:
Step 1 Check that the plastic “feet” on the bottom of the router are turned so that they are
completely under the unit.
Step 2 Set the router on a flat, secure surface, but place it so that you have access to the
rear panel. This orientation allows easy access to the connectors on the rear panel.
Mounting Your Router
To mount your router on a wall or other flat surface, perform the following steps:
Step 1 Locate the plastic feet on the bottom of the router and turn them out 90 degrees so
that the holes in the feet are exposed.
Front
Plastic 
foot (4)
H2560

12 Cisco 1003 and Cisco 1004 User Guide
Installing Your Cisco 1003 or Cisco 1004 Router
Step 2 Attach the router to a wall or other flat surface, using the screws that you must
provide. Mount the router so that:
•The front-panel LEDs face up and are easily visible. Later, you will use these
LEDs to verify that your router is working properly. Mounting the router with
the LEDs facing up will also reduce strain on the cable connections.
•The desktop power supply does not hang from its cable. The desktop power
supply will disconnect from its cable if it is not supported. The wall-mount
power supply does not require support. (The power supplies are illustrated in
the section “Connecting the Power Supply,” later in this publication.)
Caution We recommend that you align the plastic feet with a vertical wall stud. If the
screws are not properly anchored in the wallboard, drywall, or a vertical stud, cable strain
could pull the chassis from the wall.
POWER SYSTEM SERIAL SERIAL LAN LAN COLLISION LINK
OK TX RX TX RX OK
H2853

Cisco 1003 and Cisco 1004 User Guide 13
Installing Your Cisco 1003 or Cisco 1004 Router
Installing the Flash Memory Card
This section explains how to install an optional PCMCIA Flash memory card. If a Flash
memory card did not come with your order, ignore this section and proceed with the next
section, “Making Network Connections.”
To install the optional Flash memory (PCMCIA) card, perform the following steps:
Step 1 While pressing down on the two tabs at the top of the door, rotate the top of the
door away from the rear panel. Then lift the door away from the rear panel.
H3124
12VDC
Tabs

14 Cisco 1003 and Cisco 1004 User Guide
Installing Your Cisco 1003 or Cisco 1004 Router
Step 2 Verify that the Flash memory card is set with write protection off. The
write-protect switch is located at the top edge of the card, when oriented with the
printed side up.
Flash card
Flash card 
write protection
Flash card 
shown with write
protection off
H2352

Cisco 1003 and Cisco 1004 User Guide 15
Installing Your Cisco 1003 or Cisco 1004 Router
Step 3 Insert the Flash memory card into the PCMCIA slot.
H2842
12VDC
Black plastic
eject button
Flash memory card
PCMCIA slot

16 Cisco 1003 and Cisco 1004 User Guide
Installing Your Cisco 1003 or Cisco 1004 Router
Step 4 Align the bottom of the door with the bottom of the PCMCIA slot. Then rotate the
top of the door toward the rear panel until the plastic tabs snap into place.
Replacing the door prevents dust from entering the chassis.
Note If you cannot close the door completely, the Flash memory card might not be firmly
seated in the connector (inside the router). Press the black plastic eject button at the right
side of the slot to eject the Flash memory card. Then reinsert the card and replace the door.
H3809
12VDC
Tabs

Cisco 1003 and Cisco 1004 User Guide 17
Installing Your Cisco 1003 or Cisco 1004 Router
Making Network Connections
You must provide interface cables to connect the router to the Ethernet and WAN lines.
Note Refer to the section “Pinouts” for cable specifications.
Warning Do not work on the system or connect or disconnect cables during periods of
lightning activity. (To see translated versions of this warning, refer to the section
“Translated Safety Warnings” at the end of this publication.)
To connect the cables to the router, perform the following steps:
Step 1 Connect an Ethernet cable (not provided) to the 10BaseT (Ethernet) port on the
router. You’ll need a straight-through Ethernet cable if you’re connecting to an
Ethernet concentrator (or hub). Or you’ll need a crossover Ethernet cable if you’re
connecting to a personal computer (PC) Ethernet network interface card (NIC).
H3596
12VDC
Ethernet cable
10BaseT port

18 Cisco 1003 and Cisco 1004 User Guide
Installing Your Cisco 1003 or Cisco 1004 Router
Step 2 Connect the other end of the Ethernet cable to your Ethernet network.
You can connect the Ethernet port in either of the following ways:
Connect to an Ethernet concentrator (or hub) using a straight-through Ethernet
cable.
H3585
AUI 871
10BaseT hub
Straight-through
Ethernet cable

Cisco 1003 and Cisco 1004 User Guide 19
Installing Your Cisco 1003 or Cisco 1004 Router
Or, you can connect the router to a PC Ethernet NIC using an Ethernet crossover
cable.
H3586
PC
AUX SER 0 ETH
OK
LAN
Ethernet 
crossover 
cable

20 Cisco 1003 and Cisco 1004 User Guide
Installing Your Cisco 1003 or Cisco 1004 Router
Step 3 Connect a straight-through BRI cable (not provided) to the BRI port on the router.
H2843
12VDC
Straight-through
BRI cable
ISDN BRI port
