Quick Start Guide
Cisco 1811 and 1812 Integrated Services Router Cabling and
Installation
INCLUDES LICENSE AND WARRANTY INFORMATION
1Cisco One-Year Limited Hardware Warranty Terms
2Overview
3Unpacking the Box
4Connecting the Router
5Connecting Antennas to the Router RP-TNC Connectors
6Configuring the Router Using Cisco Router and Security Device Manager
7Connecting a PC to the Router Console Port
8Verifying Your Installation
9Obtaining Documentation and Submitting a Service Request
Note: For localized versions of these instructions, please see the following URL:
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/1800fix/qsgs/index.htm

2
1 Cisco One-Year Limited Hardware Warranty Terms
There are special terms applicable to your hardware warranty and various services that you can use during the warranty period.
Your formal Warranty Statement, including the warranty applicable to Cisco software, is included on the CD that accompanies
your Cisco product. Follow these steps to access and download the Cisco Information Packet and your warranty document from
the CD or from Cisco.com.
1. Launch your browser, and go to this URL:
http://www.cisco.com/univercd/cc/td/doc/es_inpck/cetrans.htm
The Warranties and License Agreements page appears.
2. To read the Cisco Information Packet, follow these steps:
a. Click the Information Packet Number field, and make sure that the part number 78-5235-02F0 is highlighted.
b. Select the language in which you would like to read the document.
c. Click Go.
The Cisco Limited Warranty and Software License page from the Information Packet appears.
d. Read the document online, or click the PDF icon to download and print the document in Adobe Portable Document
Format (PDF).
You must have Adobe Acrobat Reader to view and print PDF files. You can download the reader from Adobe’s website:
http://www.adobe.com
3. To read translated and localized warranty information about your product, follow these steps:
a. Enter this part number in the Warranty Document Number field:
78-10747-01C0
b. Select the language in which you would like to view the document.
c. Click Go.
The Cisco warranty page appears.
d. Read the document online, or click the PDF icon to download and print the document in Adobe Portable Document
Format (PDF).
You can also contact the Cisco service and support website for assistance:
http://www.cisco.com/en/US/support/.
Duration of Hardware Warranty
One (1) Year
Replacement, Repair, or Refund Policy for Hardware
Cisco or its service center will use commercially reasonable efforts to ship a replacement part within ten (10) working days after
receipt of a Return Materials Authorization (RMA) request. Actual delivery times can vary, depending on the customer location.
Cisco reserves the right to refund the purchase price as its exclusive warranty remedy.
To Receive a Return Materials Authorization (RMA) Number
Contact the company from whom you purchased the product. If you purchased the product directly from Cisco, contact your
Cisco Sales and Service Representative.

3
Complete the information below, and keep it for reference.
2 Overview
This document describes the steps for installing the Cisco 1811 and the Cisco 1812 integrated services routers. The Cisco 1811
and Cisco 1812 routers are fixed-configuration routers. They each include an integrated 8-port 10/100-Mbps Ethernet switch,
two onboard Fast Ethernet WAN ports, two dual USB 2.0 ports, and optional 802.11a/b/g wireless LAN support. The switch
ports and the onboard 10/100-Mbps Ethernet ports support 802.1Q virtual LAN (VLAN) encapsulation and enable you to
configure demilitarized zones (DMZs), using VLANs and Cisco IOS firewall features. The switch ports are also optionally
upgradable to include inline power support for IP phones.
The Cisco 1811 and Cisco 1812 integrated services routers provide secure Internet connectivity and dial backup if your primary
connection fails. The Cisco 1811 router provides dial backup through a V.92 analog modem port. The Cisco 1812 router
provides dial backup through an ISDN S/T port.
Additional documentation can be found on Cisco.com.
Product Serial Number Location
The serial number label for the Cisco 1811 and Cisco 1812 routers is located on the back of the chassis, above and to the right
of the power switch. You need this serial number when calling Cisco for support. To see specifically where the serial label is on
your router, go to the following link:
http://tools.cisco.com/Support/CPI/index.do
3 Unpacking the Box
When you unpack the box containing your Cisco 1811 or Cisco 1812 router, you should find the items shown in Figure 1.
Note The Cisco 1811 and Cisco 1812 routers have a wireless upgradable option. If this option is chosen, an antenna kit
should have been shipped with your router in addition to the items listed in Figure 1.
Company product purchased from
Company telephone number
Product model number
Product serial number
Maintenance contract number

4
Figure 1 Items Included with the Cisco 1811 and Cisco 1812 Integrated Services Router
The shipment should include the following items:
•One Cisco 1811 router or one Cisco 1812 router
•One blue RJ-45-to-DB-9 console cable
•One DB-9-to-DB-25 adapter
•One black power supply cord
•One Power over Ethernet (PoE) power supply, if the router was purchased with the PoE option
•Product documentation
•One CD-ROM containing Cisco Router and Security Device Manager (SDM)
•One antenna kit (optional)
Items You Need to Provide
Depending on your network environment, you may need to provide some of the following items so that you can install the
router:
•Straight-through Ethernet cables (RJ-45-to-RJ-45) to connect the router to a broadband (xDSL or cable) modem and to a
hub or switch
•Ethernet hub or switch to connect the router to the local network, or an xDSL or cable modem to connect the router to the
service provider
•Server or other computer with a network interface card (NIC) or other networked device (such as a hub or a switch) to
connect to the integrated 8-port 10/100-Mbps Ethernet switch
1Cisco 1811 or Cisco 1812 router 4PoE power supply and cable (optional)
2Power cable 5DB-9 to DB-25 adapter
3Console cable (light blue, RJ-45 to DB-9) 6Product documentation
121550
CD-ROM
Other
Documentation
Quick Start
Guide
1
2
3
4
5
6

5
4 Connecting the Router
Figure 2 shows a typical installation of a Cisco 1811 or Cisco 1812 router.
Figure 2 Typical Installation of a Cisco 1811 or Cisco 1812 Router
Follow these steps to connect the router to the power supply, your local network, and your service provider network:
Step 1 Connect power to the router as shown in Figure 2:
a. Connect the separate power cord to the power socket on the back panel of the router.
b. Connect the other end of the separate power cord to a power outlet.
Note If you have a router with the PoE option, you must connect the PoE power supply to the PoE socket on the
back of the router, connect the female end of the PoE power cable to the PoE power supply, and connect the
male end of the PoE power cable to a power outlet.
c. Turn on the router by pressing the power switch to the on ( | ) position.
d. Confirm that the router has power by checking that the SYS OK LED on the front panel is on.
Step 2 To connect the router to your network, connect one end of an Ethernet cable (RJ-45) to an Ethernet switch port
(FE 2–FE 9), and connect the other end of the cable to a port on a hub or switch, as shown in Figure 2.
Note The example in Figure 2 shows connectivity to a hub. The router Ethernet switch ports can be connected to
another networked device, such as a switch or computer with a network interface card (NIC). If you are
connecting a computer to the switch port on the router, it will take about 30 seconds for connectivity to be
established.
PC
DSL/Cable Modem
121549
Ethernet Hub
Internet Service
Provider
1
5
4
3
2

6
Step 3 To use Cisco Router and Security Device Manager (SDM) to configure your router, you must connect a PC to the first
Ethernet switch port. Connect one end of an Ethernet cable to one of the Ethernet switch ports (FE 2–FE 9), and connect
the other end to the Ethernet port on your PC.
Caution Always connect the Ethernet cable to an Ethernet port on the router. Accidentally connecting the cable to the wrong
port can damage your router.
Step 4 To connect the router to your service provider network, connect one end of an Ethernet cable to a 10/100 Fast Ethernet
port (these ports are labeled FE 0 and FE 1); connect the other end of the cable to a network port on your service
provider’s broadband (xDSL or cable) modem equipment, as shown in Figure 2.
Caution Always connect the Ethernet cable to an Ethernet port on the router. Accidentally connecting the cable to the wrong
port can damage your router.
Step 5 (Optional) The Cisco 1811 router supports a 230-kbps dialup connection to your service provider network through its
V.92 modem port. The Cisco 1812 router supports a 144-kbps dialup connection to your service provider network
through its ISDN S/T port. These connections can serve as a backup to your service provider if your primary connection
goes down. To make a backup connection to your service provider network, connect one end of a straight-through
RJ-11 cable to the V.92 modem port (for the Cisco 1811) or a straight-through RJ45 cable to the ISDN S/T port (for
the Cisco 1812) on the router, as shown in Figure 2, and connect the other end of the cable to your telephone wall jack.
Note To configure your router for a backup dialup connection, you must use the Cisco IOS command-line
interface (CLI). For more information, see the Cisco 1800 Series Integrated Services Routers (Fixed) Software
Configuration Guide.
5 Connecting Antennas to the Router RP-TNC Connectors
If your router has the wireless LAN option, connect the antennas by screwing the antenna connectors in a clockwise direction
onto the reverse-polarity threaded Neill-Concelman (RP-TNC) connectors on the back panel of the router. Figure 3 shows an
example of how to connect the swivel-mount dipole antennas to the router.
Note The location and position of your router antennas are crucial to effective wireless connectivity. For more information
about the antennas compatible with the Cisco 1801, Cisco 1802, and Cisco 1803 routers, see the online documents
located at the following URL:
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/1800fix/antennas/index.htm

7
Figure 3 Connecting Antennas to the Router
For information about configuring the wireless LAN functionality of your router, see the Cisco Access Router Wireless
Configuration Guide at the following URL:
http://www.cisco.com/en/US/docs/routers/access/1800/wireless/configuration/guide/awg.html
6 Configuring the Router Using Cisco Router and Security Device Manager
Cisco Router and Security Device Manager (SDM) is a web-based configuration tool that allows you to configure LAN and
WAN interfaces, routing, Network Address Translation (NAT), firewalls, VPNs, and other features on your router. If SDM is
installed on your router, configure the router by following the instructions in the Cisco Router and Security Device Manager
(SDM) Quick Start Guide. If this document was not shipped with your router, you can obtain the SDM software and instructions
for installing it on your router from the following location:
http://www.cisco.com/pcgi-bin/tablebuild.pl/sdm
To obtain the SDM release notes and other SDM documentation, go to the following URL and click the Technical
Documentation link.
http://www.cisco.com/go/sdm
7 Connecting a PC to the Router Console Port
This step is optional; it is required only if you want to use the Cisco IOS CLI instead of SDM to configure or troubleshoot the
router. To use Cisco IOS, you must connect the router to a terminal or to a PC with terminal emulation software. Terminal
emulation software should be configured with the following settings:
•9600 baud
•8databits
•No parity bits
•1 stop bit
The Cisco 1800 Series Integrated Services Routers (Fixed) Software Configuration Guide describes how to configure the router
by using Cisco IOS software.
127937

8
Follow these steps to connect the router to a terminal or PC:
Step 1 Connect the RJ-45 end of the console cable to the CONSOLE port on the back panel of the router, as shown in Figure 4.
Figure 4 Connecting the Console Cable to the Router
Step 2 Connect the DB-9 end of the console cable to the console port (also called the serial port) on your PC. If this adapter
does not fit your PC console port, you must provide an adapter that fits.
8 Verifying Your Installation
You can verify that you have correctly installed your router by checking the LEDs as described in Table 1.
Table 1 LEDs That Verify Installation
LED Meaning
SYS OK Steady green—Router has successfully booted up and the software is functional.
Blinking green—Router is booting or in ROM monitor mode.
POE1Off—Inline power supply not installed.
Steady green—Inline power supply OK.
Amber—Power denied.
FE 0–9 Steady green—Ethernet link is established.
Blinking green—Activity on the Ethernet link.
Off—No link.
CD2Steady green—Modem connection established (carrier detect).
Off—No connection established.
SPD2Steady green—Connection at high speed (V.90).
Off—Connection at low speed (V.32/V.32b/V.34).
BUSY2Blinking green—Activity over modem line.
Off—No activity.
LINK3Steady green—ISDN S/T connection established.
Off—No ISDN S/T connection established.
B13Blinking green—Activity on first B channel.
Off—No activity on first B channel.
B23Blinking green—Activity on second B channel.
Off—No activity on second B channel.
To PC
or Terminal 1
120373

9
9 Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, submitting a service request, and gathering additional information, see the monthly
What’s New in Cisco Product Documentation, which also lists all new and revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html
Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be
delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS version
2.0.
PPP Steady green—At least one PPP connection established.
Off—No PPP link established.
VPN Steady green—At least one VPN tunnel established.
Off—No VPN tunnel established.
CF Blinking green—CompactFlash memory being accessed. Do not remove CompactFlash memory.
Off—CompactFlash memory is not being accessed. It is safe to remove CompactFlash memory.
1. Inline power is a field-upgradable option only. It is not installed by default.
2. This LED is on the Cisco 1811 router only.
3. This LED is on the Cisco 1812 router only.
Table 1 LEDs That Verify Installation (Continued)
LED Meaning

Corporate Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]
European Headquarters
Cisco Systems International BV
Haarlerbergpark
Haarlerbergweg 13-19
1101 CH Amsterdam
The Netherlands
www-europe.cisco.com
Tel: [phone]
Fax: [phone]
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
www.cisco.com
Tel: [phone]
Fax: [phone]
Asia Pacific Headquarters
Cisco Systems, Inc.
168 Robinson Road
#28-01 Capital Tower
Singapore 068912
www.cisco.com
Tel: [phone]
Fax: [phone]
Cisco Systems has more than 200 offices in the following countries. Addresses, phone numbers, and fax numbers are listed on the
Cisco Website at www.cisco.com/go/offices
Argentina • Australia • Austria • Belgium • Brazil • Bulgaria • Canada • Chile • China PRC • Colombia • Costa Rica • Croatia • Cyprus • Czech Republic • Denmark
Dubai, UAE • Finland • France • Germany • Greece • Hong Kong SAR • Hungary • India • Indonesia • Ireland • Israel • Italy • Japan • Korea • Luxembourg • Malaysia
Mexico • The Netherlands • New Zealand • Norway • Peru • Philippines • Poland • Portugal • Puerto Rico • Romania • Russia • Saudi Arabia • Scotland • Singapore
Slovakia • Slovenia • South Africa • Spain • Sweden • Switzerland • Taiwan • Thailand • Turkey • Ukraine • United Kingdom • United States • Venezuela • Vietnam • Zimbabwe
© 2005 Cisco Systems, Inc. All rights reserved.
Printed in the USA on recycled paper containing 10% postconsumer waste.
78-16695-02
DOC-7816695=
CCVP, the Cisco logo, and Welcome to the Human Network are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn is a service mark of Cisco Systems, Inc.; and Access Registra
r,
Aironet, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo
,
Cisco Unity, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS, iPhone, IP/TV, iQ Expertise, the iQ logo, iQ Ne
t
Readiness Scorecard, iQuick Study, LightStream, Linksys, MeetingPlace, MGX, Networkers, Networking Academy, Network Registrar, PIX, ProConnect, ScriptShare, SMARTnet, StackWise, The Fastest Way t
o
Increase Your Internet Quotient, and TransPath are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
(0711R)
