Cisco Catalyst IR1800 Rugged Series User manual

Cisco Catalyst IR1800 Rugged Series Router Hardware Installation
Guide
First Published: 2021-02-03
Last Modified: 2021-08-12
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: [phone]
800 553-NETS (6387)
Fax: [phone]

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL:
https://www.cisco.com/c/en/us/about/legal/trademarks.html. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a
partnership relationship between Cisco and any other company. (1721R)
©2021 Cisco Systems, Inc. All rights reserved.

CONTENTS
Preface 1
CHAPTER 1
Overview of Preface 1
Objective 1
Audience 1
Conventions 2
Safety Warnings 2
Related Documentation 9
Searching Cisco Documents 9
Product Overview 11
CHAPTER 2
Overview of Features 11
Cisco IR1800 Series Platform Features 12
Cisco IR1821 Router 13
Cisco IR1831 Router 14
Cisco IR1833 Router 15
Cisco IR1835 Router 15
Front Panel Overview 15
Rear Panel Overview 16
Pluggable Modules 17
Pluggable Interface Module (PIM) 17
SSD Module 17
GNSS Module 17
SFP Modules 17
Wi-Fi Module 18
Gigabit Ethernet Combo Port 18
Gigabit Ethernet Copper Ports 18
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
iii

Power over Ethernet 19
Front Panel LEDs 19
Reset Button 20
Supported Cisco Antennas and Antenna Accessories 20
Modem Support 21
Power Supply 22
Serial Ports 22
USB Ports 23
Installing the Router 25
CHAPTER 3
Overview 25
Safety Information 25
Equipment, Tools, and Connections 26
Items Shipped with Your Router 26
Additional Items 26
Installing the Router 27
Mounting on a Wall, Table, or Other Flat Surface 27
Installing a DIN Rail 29
Mounting the DIN Rail Bracket on the Router (Horizontal) 30
Attaching the Bracket to the DIN Rail 30
Changing the Bracket Orientation 32
Bracket Disassembly 33
Bracket Reassembly 34
Mounting the DIN Rail Bracket on the Router (Vertical) 36
Installing the Router Ground Connection 37
Antenna Selection and Installation 39
CHAPTER 4
Introduction to Selecting Antennas 39
Antenna Installation Best Practices 39
Supported Antennas for the IR1800 Series Router 41
Pluggable Interface Modules 41
Wi Fi Modules 42
Indoor Antennas 42
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
iv
Contents

Outdoor Antennas 43
Outdoor and Transportation Antennas 43
Supported Extension Bases and Cables 44
Pluggable Interface Modules 45
CHAPTER 5
Introduction to Installing Pluggable Interface Modules 45
Installing a PIM 46
SSD Module 51
CHAPTER 6
Introduction to the Solid State Drive in the IR1800 Series 51
Installing an SSD Module 52
GNSS Field Replaceable Unit Module 55
CHAPTER 7
Overview of the GNSS FRU Module 55
GNSS Specifications 55
Installation and Removal of a GNSS FRU Module 56
Digital I/O, Ignition, and CAN Bus Connectivity 59
CHAPTER 8
Overview of the Digital I/O, Ignition, and CAN Bus Connectivity 59
Digital I/O Features 59
The Digital I/O Connector 59
Digital I/O Specifications 61
Controller Area Network Bus Features 61
Can Bus Power Connector 62
On-Board Diagnostic (OBD-II) 62
Connecting the Router 65
CHAPTER 9
Overview of the IR1800 Connecting Process 65
Preparing to Connect the Router 65
Preventing Damage to the Router 65
Connecting a PC, Server, or Workstation 66
Connecting a PC to the Console Port 66
Connecting to DC Power and CAN Bus Wiring 67
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
v
Contents

Plugs and Pinouts 67
Verifying Connections 68
Installing the IP54 Kit 69
CHAPTER 10
Overview of the IP54 Kit 69
Installing the IP54 Kit 71
Installing the Front Cover 71
Installing the Back Cover 73
Technical Specifications 75
CHAPTER 11
Overview of Technical Specifications for IR1800 Series Routers 75
Router Specifications 75
Regulatory Compliance 77
CHAPTER 12
Related Documentation 77
Installation Warning and Caution Statements 78
Hazardous Locations Standards and Marking Strings 79
EMC Information 79
Class A Notice for FCC 79
Industry Canada 80
Canadian Compliance Statement 80
European Community, Switzerland, Norway, Iceland, and Liechtenstein 81
Declaration of Conformity with Regard to R-ED Directive 2014/53/EU 81
Declaration of Conformity for RF Exposure 82
RF Exposure 82
This Device Meets International Guidelines for Exposure to Radio Waves 82
This Device Meets FCC Guidelines for Exposure to Radio Waves 82
FCC Radiation Exposure Statement 83
This Device Meets the Industry Canada Guidelines for Exposure to Radio Waves 83
ISED Radiation Exposure Statement 84
Additional Information on RF Exposure 84
EMC Class A Notices and Warnings 85
Declaration of Conformity with Regard to EU Directive 2014/53/EU 85
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
vi
Contents

National Restrictions 87
Denmark 87
Italy 87
Latvia 87
Intended Use of equipment 88
Changing Output Power 88
Obtaining Documents from Cisco.com 88
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
vii
Contents

Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
viii
Contents

CHAPTER 1
Preface
This preface contains the following sections:
•Overview of Preface, on page 1
•Objective, on page 1
•Audience, on page 1
•Conventions, on page 2
•Safety Warnings, on page 2
•Related Documentation, on page 9
•Searching Cisco Documents, on page 9
Overview of Preface
This preface describes the objectives, audience, organization, and conventions of this guide and describes
related documents that have additional information.
The documentation set for this product strives to use bias-free language. For purposes of this documentation
set, bias-free is defined as language that does not imply discrimination based on age, disability, gender, racial
identity, ethnic identity, sexual orientation, socioeconomic status, and intersectionality. Exceptions may be
present in the documentation due to language that is hardcoded in the user interfaces of the product software,
language used based on RFP documentation, or language that is used by a referenced third-party product.
Note
Objective
This guide provides an overview of and explains how to install and connect your Cisco IR1800 Router.
Audience
This guide is intended for people who have a high level of technical ability, although they may not have
experience with Cisco software.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
1

Conventions
This section describes the conventions used in this guide.
Means reader take note. Notes contain helpful suggestions or references to additional information and material.
Note
This symbol means reader be careful. In this situation, you might do something that could result in equipment
damage or loss of data.
Caution
Means the following information will help you solve a problem . The tip information might not be troubleshooting
or even an action, but could be useful information.
Tip
Means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be
aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing
accidents. Use the statement number provided at the end of each warning to locate its translation in the
translated safety warnings that accompanied this device.
Warning
Safety Warnings
If this product will be installed in a hazardous location, read the compliance information shipped with the
device.
Caution
This product is a class A device for FCC compliance. Any mention of a class B compliance rating does not
indicate this product meets those guidelines.
Attention
This warning symbol means danger. You are in a
situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards
involved with electrical circuitry and be familiar with
standard practices for preventing accidents. Use the
statement number provided at the end of each warning
to locate its translation in the translated safety
warnings that accompanied this device. Statement
1071
Warning
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
2
Preface
Conventions

BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. U
verkeert in een situatie die lichamelijk letsel kan
veroorzaken. Voordat u aan enige apparatuur gaat
werken, dient u zich bewust te zijn van de bij
elektrische schakelingen betrokken risico's en dient
u op de hoogte te zijn van de standaard praktijken om
ongelukken te voorkomen. Gebruik het nummer van
de verklaring onderaan de waarschuwing als u een
vertaling van de waarschuwing die bij het apparaat
wordt geleverd, wilt raadplegen.
BEWAAR DEZE INSTRUCTIES
Waarschuwing
TÄRKEITÄ TURVALLISUUSOHJEITA
Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi
aiheuttaa ruumiillisia vammoja. Ennen kuin käsittelet
laitteistoa, huomioi sähköpiirien käsittelemiseen
liittyvät riskit ja tutustu onnettomuuksien yleisiin
ehkäisytapoihin. Turvallisuusvaroitusten käännökset
löytyvät laitteen mukana toimitettujen käännettyjen
turvallisuusvaroitusten joukosta varoitusten lopussa
näkyvien lausuntonumeroiden avulla.
SÄILYTÄ NÄMÄ OHJEET
Varoitus
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous
vous trouvez dans une situation pouvant entraîner des
blessures ou des dommages corporels. Avant de
travailler sur un équipement, soyez conscient des
dangers liés aux circuits électriques et
familiarisez-vous avec les procédures couramment
utilisées pour éviter les accidents. Pour prendre
connaissance des traductions des avertissements
figurant dans les consignes de sécurité traduites qui
accompagnent cet appareil, référez-vous au numéro
de l'instruction situé à la fin de chaque avertissement.
CONSERVEZ CES INFORMATIONS
Attention
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
3
Preface
Safety Warnings

WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befinden
sich in einer Situation, die zu Verletzungen führen
kann. Machen Sie sich vor der Arbeit mit Geräten mit
den Gefahren elektrischer Schaltungen und den
üblichen Verfahren zur Vorbeugung vor Unfällen
vertraut. Suchen Sie mit der am Ende jeder Warnung
angegebenen Anweisungsnummer nach der
jeweiligen Übersetzung in den übersetzten
Sicherheitshinweisen, die zusammen mit diesem Gerät
ausgeliefert wurden.
BEWAHREN SIE DIESE HINWEISE GUT AUF.
Warnung
IMPORTANTI ISTRUZIONI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La
situazione potrebbe causare infortuni alle persone.
Prima di intervenire su qualsiasi apparecchiatura,
occorre essere al corrente dei pericoli relativi ai
circuiti elettrici e conoscere le procedure standard
per la prevenzione di incidenti. Utilizzare il numero di
istruzione presente alla fine di ciascuna avvertenza
per individuare le traduzioni delle avvertenze riportate
in questo documento.
CONSERVARE QUESTE ISTRUZIONI
Avvertenza
VIKTIGE SIKKERHETSINSTRUKSJONER
Dette advarselssymbolet betyr fare. Du er i en
situasjon som kan føre til skade på person. Før du
begynner å arbeide med noe av utstyret, må du være
oppmerksom på farene forbundet med elektriske
kretser, og kjenne til standardprosedyrer for å
forhindre ulykker. Bruk nummeret i slutten av hver
advarsel for å finne oversettelsen i de oversatte
sikkerhetsadvarslene som fulgte med denne enheten.
TA VARE PÅ DISSE INSTRUKSJONENE
Advarsel
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você está em
uma situação que poderá ser causadora de lesões
corporais. Antes de iniciar a utilização de qualquer
equipamento, tenha conhecimento dos perigos
envolvidos no manuseio de circuitos elétricos e
familiarize-se com as práticas habituais de prevenção
de acidentes. Utilize o número da instrução fornecido
ao final de cada aviso para localizar sua tradução nos
avisos de segurança traduzidos que acompanham
este dispositivo.
GUARDE ESTAS INSTRUÇÕES
Aviso
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
4
Preface
Safety Warnings

INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para
su integridad física. Antes de manipular cualquier
equipo, considere los riesgos de la corriente eléctrica
y familiarícese con los procedimientos estándar de
prevención de accidentes. Al final de cada
advertencia encontrará el número que le ayudará a
encontrar el texto traducido en el apartado de
traducciones que acompaña a este dispositivo.
GUARDE ESTAS INSTRUCCIONES
¡Advertencia!
VIKTIGA SÄKERHETSANVISNINGAR
Denna varningssignal signalerar fara. Du befinner dig
i en situation som kan leda till personskada. Innan du
utför arbete på någon utrustning måste du vara
medveten om farorna med elkretsar och känna till
vanliga förfaranden för att förebygga olyckor. Använd
det nummer som finns i slutet av varje varning för att
hitta dess översättning i de översatta
säkerhetsvarningar som medföljer denna anordning.
SPARA DESSA ANVISNINGAR
Varning!
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
5
Preface
Safety Warnings

INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você se
encontra em uma situação em que há risco de lesões
corporais. Antes de trabalhar com qualquer
equipamento, esteja ciente dos riscos que envolvem
os circuitos elétricos e familiarize-se com as práticas
padrão de prevenção de acidentes. Use o número da
declaração fornecido ao final de cada aviso para
localizar sua tradução nos avisos de segurança
traduzidos que acompanham o dispositivo.
GUARDE ESTAS INSTRUÇÕES
Aviso
VIGTIGE SIKKERHEDSANVISNINGER
Dette advarselssymbol betyder fare. Du befinder dig
i en situation med risiko for legemesbeskadigelse. Før
du begynder arbejde på udstyr, skal du være
opmærksom på de involverede risici, der er ved
elektriske kredsløb, og du skal sætte dig ind i
standardprocedurer til undgåelse af ulykker. Brug
erklæringsnummeret efter hver advarsel for at finde
oversættelsen i de oversatte advarsler, der fulgte med
denne enhed.
GEM DISSE ANVISNINGER
Advarsel
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
6
Preface
Safety Warnings

When installing the product, please use the provided or designated connection cables/power cables/AC
adapters. Using any other cables/adapters could cause a malfunction or a fire. Electrical Appliance and
Material Safety Law prohibits the use of UL-certified cables (that have the “UL”shown on the code) for any
other electrical devices than products designated by CISCO. The use of cables that are certified by Electrical
Appliance and Material Safety Law (that have “PSE”shown on the code) is not limited to CISCO-designated
products. Statement 371
Warning
Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct hardware
or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
Statement 378
Warning
Read the installation instructions before connecting the system to the power source. Statement 1004
Warning
Class 1 laser product. Statement 1008
Warning
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network voltage
(TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some LAN and WAN
ports both use RJ-45 connectors. Use caution when connecting cables. Statement 1021
Warning
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
7
Preface
Safety Warnings

This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence
of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician
if you are uncertain that suitable grounding is available . Statement 1024
Warning
Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV) requirements
in IEC 62368 and IEC 60950 based safety standards. Statement 1033
Warning
When installing or replacing the unit, the ground connection must always be made first and disconnected last.
Statement 1046
Warning
Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it can
come into contact with such circuits. When installing the antenna, take extreme care not to come into contact
with such circuits, because they may cause serious injury or death. For proper installation and grounding of
the antenna, please refer to national and local codes (for example, U.S.:NFPA 70, National Electrical Code,
Article 810, Canada: Canadian Electrical Code, Section 54). Statement 1052
Warning
No user-serviceable parts inside. Do not open. Statement 1073
Warning
Installation of the equipment must comply with local and national electrical codes. Statement 1074
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
Ultimate disposal of this product should be handled according to all national laws and regulations. Statement
1040
Warning
The covers are an integral part of the safety design of the product. Do not operate the unit without the covers
installed. Statement 1077
Warning
Hot surface. Statement 1079
Warning
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
8
Preface
Safety Warnings

Intended for installation in a restricted access location.
Warning
Related Documentation
All of the IR1800 documentation can be found here:
https://www.cisco.com/c/en/us/support/routers/catalyst-ir1800-rugged-series-routers/series.html
Searching Cisco Documents
To search an HTML document using a web browser, press Ctrl-F (Windows) or Cmd-F (Apple). In most browsers,
the option to search whole words only, invoke case sensitivity, or search forward and backward is also
available.
To search a PDF document in Adobe Reader, use the basic Find toolbar (Ctrl-F) or the Full Reader Search
window (Shift-Ctrl-F). Use the Find toolbar to find words or phrases within a specific document. Use the Full
Reader Search window to search multiple PDF files simultaneously and to change case sensitivity and other
options. Adobe Reader’s online help has more information about how to search PDF documents.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
9
Preface
Related Documentation

Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
10
Preface
Searching Cisco Documents

CHAPTER 2
Product Overview
This chapter contains the following sections:
•Overview of Features, on page 11
•Cisco IR1800 Series Platform Features, on page 12
•Front Panel Overview, on page 15
•Rear Panel Overview, on page 16
•Pluggable Modules, on page 17
•Gigabit Ethernet Combo Port, on page 18
•Gigabit Ethernet Copper Ports, on page 18
•Power over Ethernet, on page 19
•Front Panel LEDs, on page 19
•Reset Button, on page 20
•Supported Cisco Antennas and Antenna Accessories, on page 20
•Modem Support, on page 21
•Power Supply, on page 22
•Serial Ports, on page 22
•USB Ports, on page 23
Overview of Features
This chapter provides an overview of the features available in the Cisco Catalyst IR1800 Rugged Series Router
(referred to as the IR1800 in the rest of this document).
The IR1800 is a next-generation modular industrial router based on Cisco IOS-XE, with advanced features such
modular Wi-Fi, modular cellular WAN, Controller Area Network (CAN bus), solid-state drive (SSD), digital I/O,
and GPS or GNSS dead reckoning.
The IR1800 features a base platform with modularity that includes:
•Pluggable Interface Module (PIM) slot(s)
•Wi-fi Interface Module (WIM) slot
Wi-Fi available after first shipment of the product in a future software release.
Note
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
11

•SSD Module slot
•GNSS Module slot
The IR1800 consists of four SKUs:
•IR1821
•IR1831
•IR1833
•IR1835
The following table shows the differences among the features of these SKUs.
Table 1: Differences in IR1800 SKU Features
IR1835IR1833IR1831IR1821Feature
1200 MHz600 MHz600 MHz600 MHzProcessor Frequency
8GB4GB4GB4GBDDR Memory
8GB4GB4GB4GBFlash Storage
2221PIM Slot
1111Wi-Fi Pluggable Module Slot
YesYesNoNoPoE
YesYesNoNoSSD Module Slot
YesYesNoNoGNSS FRU Module Slot
YesNoNoNoDigital I/O
(1) RS232 DTE
(1) RS232 DCE/RS485
(1) RS232
DTE
(1) RS232
DCE
(1) RS232
DTE
(1) RS232
DCE
(1) RS232
DTE
Asynchronous Serial
Interface
Cisco IR1800 Series Platform Features
This section describes the different components of the router.
Cisco Catalyst IR1800 Rugged Series Router Hardware Installation Guide
12
Product Overview
Cisco IR1800 Series Platform Features
